TECHNICAL MANUAL

Intel H310/H370 Express Chipset

Based Mini-ITX M/B

NO. G03-NF893-F

Revision: 1.0

Release date: January 4, 2019

Trademark:

* Specifications and Information contained in this documentation are furnished for information use only, and are

subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize pollution and ensure environment protection of mother earth, please recycle.

ENVIRONMENTAL SAFETY INSTRUCTION ................................................................... iii

USER’S NOTICE ............................................................................................................. iv

MANUAL REVISION INFORMATION .............................................................................. iv

ITEM CHECKLIST ........................................................................................................... iv

CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD

1-1 FEATURE OF MOTHERBOARD............................................................................. 1

1-2 SPECIFICATION ..................................................................................................... 2

1-3 LAYOUT DIAGRAM ................................................................................................ 3

CHAPTER 2 HARDWARE INSTALLATION

2-1 JUMPER SETTING ................................................................................................. 9

2-2 CONNECTORS, HEADERS AND WAFERS ........................................................... 13

2-2-1 CONNECTORS ......................................................................................... 13

2-2-2 HEADERS & WAFERS .............................................................................. 20

CHAPTER 3 INTRODUCING BIOS

3-1 ENTERING SETUP ................................................................................................. 25

3-2 BIOS MENU SCREEN ............................................................................................ 26

3-3 FUNCTION KEYS ................................................................................................... 26

3-4 GETTING HELP ...................................................................................................... 27

3-5 MENU BARS .......................................................................................................... 27

3-6 MAIN MENU ........................................................................................................... 28

3-7 ADVANCED MENU ................................................................................................. 29

3-8 CHIPSET MENU ..................................................................................................... 40

3-9 SECURITY MENU ................................................................................................... 43

3-10 BOOT MENU .......................................................................................................... 46

3-11 SAVE & EXIT MENU ............................................................................................... 47

TABLE OF CONTENT

iii

Environmental Safety Instruction

l Avoid the dusty, humidity and temperature extremes. Do not place the product in

any area where it may become wet.

l 0 to 40 centigrade is the suitable temperature. (The temperature comes from the

request of the chassis and thermal solution)

l Generally speaking, dramatic changes in temperature may lead to contact

malfunction and crackles due to constant thermal expansion and contraction from the welding spots’ that connect components and PCB. Computer should go through an adaptive phase before it boots when it is moved from a cold environment to a warmer one to avoid condensation phenomenon. These water drops attached on PCB or the surface of the components can bring about phenomena as minor as computer instability resulted from corrosion and oxidation from components and PCB or as major as short circuit that can burn the components. Suggest starting the computer until the temperature goes up.

l The increasing temperature of the capacitor may decrease the life of computer.

Using the close case may decrease the life of other device because the higher temperature in the inner of the case.

l Attention to the heat sink when you over-clocking. The higher temperature may

decrease the life of the device and burned the capacitor.

USER’S NOTICE

COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.

THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA, INTERRUPTION OF BUSINESS AND THE LIKE).

PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT INTENT TO INFRINGE.

Manual Revision Information

Reversion Revision History Date

1.0 First Edition January 4, 2019

Item Checklist

Motherboard

DVD for motherboard utilities

User’s Manual

Cable

(s)

Chapter 1

Introduction of the Motherboard

1-1 Feature of Motherboard

l Intel® H310/H370 express chipset l LGA 1151 CPU socket supports Intel® Coffee Lake-S series processor (TDP ≤65

W).

l Support 2* DDR4 2400MHz SO-DIMM up to 32GB and dual channel function l Support 1 * Intel i219-V Gigabit Ethernet LAN chip l Support USB 3.1 data transport demand l Support 2 * SATAIII (6Gb/s) ports l Support 1* PCIE x1 slot, 1* M.2 E-key 2230 PCIe slot and 1* M.2 M-key

2242/2260/2280 slot

l Support 1 * HDMI + 1 * DP + 1* LVDS (option with eDP) l Support 1 * COM, optional 4/6 * USB 3.1 & 4 * USB 2.0 for rich IO expansion l Support Smart FAN function l Supports ACPI S3 Function l Compliance with ErP Standard l Support Watchdog Timer Technology

1-2 Specification

Spec

Description

Design

l Thin mini-ITX form factor; PCB size: 17.0x17.0cm

Chipset

l Intel H310/H370 Express Chipset

CPU Socket

l Intel® LGA 1151 Socket for Coffee Lake-S series processors

*Note: for detailed CPU support information please visit our website

Memory Slot

l 2*

DDR

4 SO-DIMM slot

l Support DDR4 2400/2666 MHz SO-DIMM up to 32GB l Support dual channel function

Expansion Slot

l 1* PCIE x1

slot (

PCI-

)

l 1* M.2 PCIE slot (

M2E

,2230 E-key PCIE interface)

Storage

l 2

* SATAIII 6G/s port

(SATA

1/2)

l 1* M.2 M-key slot, type-2242/2260/2280 with SATA interface (

M2M

*SATA/PCIE interface)

*Note: PCIE signal is supported by NF893-H370 series only.

LAN Chip

l Integrated with 1* Intel i219-V Gigabit PCI-E LAN chip l Support Fast Ethernet LAN function of providing 10/100/1000Mbps

Ethernet data transfer rate

Audio Chip

l Realtek ALC662-VD 4-channel Audio Codec integrated l Audio driver and utility included

BIOS l AMI Flash ROM

Multi I/O

Rear Panel I/O:

l 1*19V DC-in Power Jack l

4* USB 3.1 (Gen.1) port (Optional for NF893-H310 Series)

4* USB 3.1 (Gen.2) port (Optional for NF893-H370 Series)

l 1* HDMI port l 1* DP port l 1* RJ-45 LAN port l 1* Line-out port l 1* MIC port

Internal I/O Connectors & Headers:

l 1 *2-pin 19V internal power connector l 1* CPUFAN connector & 1* SYSFAN connector l 1* SATA Power-out connector l 1* MON_SW connector

l 1* Front panel header

l 1* PS/2 keyboard & mouse header l 1* Serial port header l 1* GPIO header l 2* 9-Pin USB 2.0 header for 4* USB 2.0 ports l 1* 19-Pin USB 3.1 (Gen.2) header for 2* USB 3.1 (Gen.2) ports

(Optional

for NF893-H370 Series)

l 1*Front panel audio header l 1* DMIC_CON digital microphone header l 1* Speaker header l 1* PN_LED header (for LAN activity LED/ Blue tooth activity LED/

WIFI

activity LED)

l 1* LVDS connector (Default) or 1* EDP connector (Optional by order) l 1*Inverter header

1-3 Layout Diagram

Rear IO Diagram

*Note: NF893-H310 series come with 4* USB 3.1 (Gen.1) ports which supports 5Gps data transfer

rate; NF893-H370 series come with 4* USB 3.1 (Gen.2) ports which supports 10Gps data transfer rate

MIC Port

Line-Out Port

RJ-45 LAN Port

Display Port

HDMI Port

USB 3.

1 Ports

19V DC

Power Jack

Motherboard Internal Diagram-Front

NF893-H310 Series:

LGA 1151

CPU Socket

H310 Chipset

DDR4

SODIMM Slots

(SODIMM1/2)

RJ-45

LAN Port

Line-Out

Port

MIC

Port

HDMI

Port Display

Port

USB 3.1

(Gen.1)Ports

19V DC

Power Jack

Internal 19V DC

Power Connector

SATAIII Ports

(SATA1/2)

SYSFAN

Connector

CPUFAN

Connector

Front Panel

Header

Inverter

USB 2.0 Port

Header

USB 2.0 Port

Header

GPIO Heade

M.2 M-Key Slot

(M2M)

PS2KBMS Header

M.2E-Key Slot

(

M2E)

Front Panel

Audio

Header

CIE X1 Slot

(PCI-E)

SPEAK_CON

Header

DMIC_CON

Header

PN_LED

Header

SATA Power

Connector

(SATAPWR)

LVDS

Connector

(Optional with

EDP)

MON_SW

Header

Serial Port

Header

NF893-H370 Series:

*Note: The product diagrams are for illustration purpose only and mostly come from Model

NF893-H370, unless otherwise noted.

LGA 1151

CPU Socket

H370 Chipset

DDR4

SODIMM Slots

(SODIMM1/2)

RJ-45

LAN Port

Line-Out

Port

MIC

Port

HDMI

Port Display

Port

USB 3.1

(Gen.2)Ports

19V DC

Power Jack

Internal 19V DC

Power Connector

SATAIII Ports

(SATA1/2)

SYSFAN

Connector

CPUFAN

Connector

Front Panel

Header

USB 2.0 Port

Header

USB 2.0 Port

Header

GPIO Header

Serial Port

Header

M.2 M-Key Slot

(M2M)

PS2KBMS Header

M.2 PCIE Slot

(

M2E)

Front Panel

Audio

Header

PCIE X1 Slot

(PCI-E)

MON_SW

Header

SPEAK_CON

Header

DMIC_CON

Header

PN_LED

Header

SATA Power

Connector

(SATAPWR)

* USB 3.1 (Gen.2)

Header

Inverter

LVDS

Connector

(Optional with

EDP)

Motherboard Internal Diagram-Back

*Note: The default board comes with LVDS connecoter.EDP connector is only optional by order.

Only one of them comes with a board.

EDP

Connector

(Optional

with LVDS)

Motherboard Jumper Position:

*Note: 1.JPTEST is for manufacture usage only;

2. The product diagram above is from Model NF893-H310.

AT_COPEN

JP1

JP2

*JPTEST

JBAT

Connectors

P/N Name

DCIN

19V DC-IN Power Jack

USB1/USB2

(For NF893-H310)

USB 3.1 (Gen.1) Port Connector X4

USB1/USB2

(For NF893-H370)

USB 3.1 (Gen.2) Port Connector X4

DP Display Port Connector HDMI HDMI Port Connector LAN RJ-45 LAN Connector FP_HP Audio Line-out Connector FP_MIC Audio MIC Connector ATX2P Internal 19V Power Connector SYSFAN System Fan Connector CPUFAN CPUFAN Connector SATA1/SATA2 SATAIII Connector X 2 SATAPWR SATA Power-out Connector SPEAK_CON 3W Amplifier Connector MON_SW Monitor Switch Connector LVDS LVDS Port Connector EDP(Optional) EDP Port Connector INVERTER Flat Panel Backlight Inverter

Headers & Wafer

P/N Name Description

JW_FP

Front Panel Header(PWR LED/ HD

LED/Power Button /Reset)

9-pin Block

PS2KBMS PS2 Keyboard & Mouse Header 6-pin Block COM Serial Port Header 9-pin Block GPIO GPIO Port Header 10-pin Block FP_USB3

(For NF893-H370)

USB 3.1 (Gen.2) Port Header 19-pin Block

FP_USB1/ FP_USB2 USB 2.0 Port Header 9-pin Block FP_AUDIO Front Panel Audio Header 9-pin Block

DMIC_CON Digital Microphone Header 4-pin Block PN_LED Connectivity LED Header

(LAN/Bluetooth/WIFI Activity LED)

6-pin Block

Jumper

P/N Name Description

JBAT Pin (1-2): Clear CMOS RAM Settings

Pin (3-4): Flash Descriptor Override Pin (5-6): PWROK Override

6-pin Block

AT_ COPEN

Pin (1-2): AT Mode Select

Pin (3-4): Case Open Display Select

4-pin Block

JP1 LCD Panel VCC Select 4-pin Block JP2 LCD Backlight Select 4-pin Block

Chapter 2

Hardware Installation

2-1 Jumper Setting

Pin 1&2 of JBAT (6-pin): Clear CMOS RAM Setting

1-2 Closed: Clear CMOS(One Touch).

1-2 Open: Normal(Default);

Pin 1&2 of JBAT→Clear CMOS

Pin1

JBAT

Pin 3&4 of JBAT (6-pin): Flash Descriptor Override Select

Pin1

Pin 3&4 of JBAT→

Flash Descriptor Override

3-4 Open: Normal(Default);

3-4 Closed: Disable Flash

Descriptor Security (override).

Pin 5&6 of JBAT (6-pin): PWROK Override Select

Pin1

5-6 Open: Normal(Default);

4 3 4

Pin 5&6 of JBAT→PWROK Override

5-6 Closed: PWROK Override.

5 5 6

* Note: PWROK override is for manufacturing test only.

JBAT

Pin 1&2 of AT_COPEN (4-pin):

AT Mode Select

Pin 1&2 of AT_COPEN

→

AT Mode Select

1-2 Open: ATX Mode

Selected(Default);

1-2 Closed: AT Mode Selected.

Pin1

Pin14

*ATX Mode Selected: Press power button to power on after power input ready; AT Mode Selected: Directly power on as power input ready.

Pin 3&4 of AT_COPEN (4-pin): Case Open Message Display Function Select

Pin1

Pin 3&4 of AT_COPEN

→

Case Open Detection

CASE

OPEN GND

Pin (3&4) short

: When Case open function pin short to GND, the Case open function was detected. When used, needs to enter BIOS and enable ‘Case Open Detect’ function. In this case if your case is removed, next time when you restart your computer, a message will be displayed on screen to inform you of this.

AT_COPEN

JP1 (4-pin): LCD Panel VCC Select

JP1→LCD VCC Select

1 3 5

4 6 2

2-4 Closed:

VCC=3.3V;

3-4 Closed:

VCC=5V;

4-6 Closed:

VCC=12V.

2 4 6

1 3 5 2 4 6 1 3 5

JP2 (3-pin): LCD Inverter Backlight VCC Select

2-3 Closed: Inverter backlight VCC=19V.

JP2→INVERTER Backlight VCC

1-2 Closed: Inverter backlight VCC= 12V;

3 1 3

JP1

JP2

2-2 Connectors, Headers and Wafers 2-2-1 Connectors

(1) Rear Panel Connectors

*Refer to Page-3 Rear IO Diagram.

Icon Name Function

19V DC-in Power

Connector

For user to connect compatible power adapter to provide power supply for the system.

NF893-H310 Series:

USB 3.1(Gen.1)Port

To connect USB keyboard, mouse or other devices compatible with USB specification. USB 3.1 (Gen.1) ports supports up to 5Gbps data transfer rate.

NF893-H370 Series:

USB 3.1(Gen.2)Port

To connect USB keyboard, mouse or other devices compatible with USB specification. USB 3.1 (Gen.2) ports supports up to 10Gbps data transfer rate.

Display Port

To the system to corresponding display device with compatible display port cable.

HDMI Port

To connect display device that support HDMI specification.

RJ-45 LAN Port

This connector is standard RJ-45 LAN jack for Network connection.

Line-Out Connector

For user to connect external speaker, earphones,

etc

to transfer system audio output.

MIC Connector

User can connect microphone device to this port.

(2) ATX2P (2-pin block): Internal 19V power connector

Pin1

Pin No.

Definition

1 GND

+19V

(3) CPUFAN/SYSFAN (4-pin): Fan Connector

Fan Speed

GND

Pin1

+12V Fan Power

Control

ATX2P

CPUFAN

SYSFAN

(4) SATA1/SATA2 (7-pin): SATA III Port connector

SATA1&SATA2 are high-speed SATAIII port that supports 6 GB/s transfer rate.

Pin No.

Definition

1 GND 2 TXP 3 TXN

4 GND

5 RXN 6 RXP 7 GND

(5) SATAPWR (15-pin block): SATA power connector

Pin1

SATA Power

Connector

Pin NO. Definition

Pin 1 NC

Pin 2 NC Pin 3 NC

Pin 4 GND

Pin 5 GND

Pin 6 GND

Pin 7 +5V

Pin 8 +5V

Pin 9 +5V

Pin 10 GND

Pin 11 NC

Pin 12 GND

Pin 13 +12V

Pin 14 +12V

Pin 15 +12V

SATAPWR

SATA1

SATA2

(6) SPEAK_CON (4-pin block): Speaker Connector

Pin1

Pin No.

Definition

1 L2 L+ 3 R+ 4 R-

(7) MON_SW (2-Pin): Monitor Switch Connector

Mon_SW is for LVDS or EDP display switch.

Pin1

GND

Display on/off

SPEAK_CON

MON_SW

(8) LVDS(40-pin): 48-bit LVDS Connector

No.

Pin Define

Pin N

Pin Define

Pin 1 LVDSA_DATAP3 Pin 2 LVDSA_DATAN3 Pin 3 LVDSA_DATAP2 Pin 4 LVDSA_DATAN2 Pin 5 LVDSA_DATAP1 Pin 6 LVDSA_DATAN1 Pin 7 LVDSA_DATAP0 Pin 8 LVDSA_DATAN0 Pin 9 LVDSB_DATAP3 Pin 10 LVDSB _DATAN3 Pin 11 LVDSB_DATAP2 Pin 12 LVDSB _DATAN2 Pin 13 LVDSB_DATAP1 Pin 14 LVDSB _DATAN1 Pin 15 LVDSB_DATAP0 Pin 16 LVDSB _DATAN0 Pin 17 GND Pin 18 LCD_VCC Pin 19 LCD_VCC Pin 20 LCD_VCC Pin 21 NC Pin 22 EDID_3V3 Option Pin 23 GND Pin 24 GND Pin 25 GND Pin 26 LVDS_CLKAP Pin 27 LVDS_CLKAN Pin 28 GND Pin 29 GND Pin 30 GND Pin 31 LVDS_DDC_CLK Pin 32 LCD_BKLT_EN Pin 33 LCD_BKLT_PWM Pin 34 LVDS_CLKBP Pin 35 LVDS_CLKBN Pin 36 LVDS_BKLT_PWR option Pin 37 LVDS_BKLT_PWR option Pin 38 LVDS_BKLT_PWR option Pin 39 NC Pin 40 LVDS_DDC_DATA

LVDS

(9) EDP(40-pin): EDP Connector

*EDP connector

is optional

by order.

No.

Pin Define

Pin N

Pin Define

Pin 1 NC Pin 2 GND Pin 3 EDP_DATA3N Pin 4 EDP_DATA3P Pin 5 GND Pin 6 EDP_DATA2N Pin 7 EDP_DATA2P Pin 8 GND Pin 9 EDP_DATA1N Pin 10 EDP_DATA1P Pin 11 GND Pin 12 EDP_DATA0N Pin 13 EDP_DATA0P Pin 14 GND Pin 15 EDP_AUXP Pin 16 EDP_AUXN Pin 17 GND Pin 18 LCD_VCC Pin 19 LCD_VCC Pin 20 LCD_VCC Pin 21 LCD_VCC Pin 22 NC Pin 23 GND Pin 24 GND Pin 25 GND Pin 26 GND Pin 27 EDP_HPD Pin 28 GND Pin 29 GND Pin 30 GND Pin 31 GND Pin 32 LCD_BKLT_EN Pin 33 LCD_BKLT_PWM Pin 34 NC Pin 35 NC Pin 36 LVDS_BKLT_PWR Option Pin 37 LVDS_BKLT_PWR Option Pin 38 LVDS_BKLT_PWR Option Pin 39 LVDS_BKLT_PWR Option Pin 40 NC

(10) INVERTER (8-pin): LVDS Inverter Connector

Pin 1

Pin No. Definition

1 Backlight Enable 2 Backlight Duty 3 PVCC 4 PVCC

5 GND 6 GND

7 Brightness up 8 Brightness down

Warning! Find Pin-1 location of the inverter and make sure that the installation direction is correct! Otherwise serious harm will occur to the board/display panel!!

INVERTER

2-2-2 Headers & Wafers

(1) JW_FP (9-pin): Front Panel Header

HDDLED+

GND

PWRLED+

GND

PWRLED-

HDDLED-

RSTSW

VCC

PWRBT

Pin 1

(2) PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header

GND

KB_CLK

KB_DATA

Pin1

MS_DATA

VCC

MS_CLK

JW_FP

PS2KBMS

(3) COM (9-Pin): RS232/RS422/RS485 Serial Port Header

Pin NO.

RS232

*RS422

(optional)

*RS485

(optional)

Pin 1 DCD

TX- DATA-

Pin 2

RXD

TX+ DATA+

Pin 3 TXD

RX+ NC

Pin 4

DTR

RX- NC

Pin 5 GND GND GND Pin 6 DSR

NC NC

Pin 7

RTS

NC NC

Pin 8 CTS

NC NC

Pin 9 RI

NC NC

Pin 1

*Notice: COM header can function as RS232/422/485 port header. In normal settings COMfunctions as RS232 header. With compatible COM cable COM can function as RS422 or RS 485 header. User also needs to go to BIOS to set ‘Transmission Mode Select’ (refer to Page-33) at first, before using specialized cable to connect different pins of this port.

(4) GPIO (10-pin): GPIO Header

GPIO 50

Pin1

GPIO 52

GPIO 54

GPIO 56

GND

GPIO51 GPIO53

GPIO 5

VCC

GPIO

COM

(5) FP_USB3(19-pin): USB 3.1 (Gen.2) Port Wafer

SSRX1- SSRX1+

GND SSTX1-

SSTX1+

GND

D1-

D1+

VBUS

Pin 1

D2+ D2

GND

SSTX2+ SSTX2-

GND

SSRX2+

SSRX2-

VBUS

*Note: FP_USB3 header is optional for Model NF893-H370.

(6) FP_USB1/FP_USB2 (9-pin): USB 2.0 Port Header

-DATA

GND

+DATA

GND

VCC

+DATA

Pin 1

VCC

-DATA

FP_USB1

FP_USB2

FP_USB3

(7) FP_AUDIO (9-pin): Line-Out, MIC-In Header

This header connects to Front Panel Line-out, MIC-In connector with cable.

Pin1

GND

DETECT

MIC_JD

MIC2_L

LINE_OUT2_R

SENSE

LINE_OUT2_L

LINE_OUT2_JD

MIC2_R

(8) DMIC_CON (4-Pin): Digital Microphone Header

DMIC

DATA

Pin 1

VCC3

GND

DMIC

CLK

FP_

AUDIO

DMIC_CON

(9) PN_LED (6-pin): LED Header

LAN_LED+

Pin1

BT_LED+

WIFI_LED+

LAN_LED-

BT_LED-

WIFI_LED-

PN_LED

Chapter 3

Introducing BIOS

Notice!

The BIOS options in this manual are for reference only. Different

configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard. Users are welcome to download the latest BIOS version form our official website.

The BIOS is a program located on a Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization. Only when these tasks are completed done it gives up control of the computer to operating system (OS). Since the BIOS is the only channel for hardware and software to communicate, it is the key factor for system stability, and in ensuring that your system performance as its best.

3-1 Entering Setup

Power on the computer and by pressing <Del> immediately allows you to enter Setup. If the message disappears before your respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the “RESET” button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt> and <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to Press

<Del>

to enter Setup.

3-2 BIOS Menu Screen

The following diagram show a general BIOS menu screen:

BIOS Menu Screen

3-3 Function Keys

In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here:

l Press←→ (left, right) to select screen; l Press ↑↓ (up, down) to choose, in the main menu, the option you want to confirm

or to modify.

l Press <Enter> to select.

Menu Bar

Menu Items

Current Setting Value

Function Keys

General Help Items

l Press <+>/<–> keys when you want to modify the BIOS parameters for the active

option.

[F1]:

General help.

[F2]:

Previous values.

[F3]:

Optimized defaults.

[F4]:

Save & Exit.

l Press

<Esc>

to exit from BIOS Setup.

3-4 Getting Help

Main Menu

The on-line description of the highlighted setup function is displayed at the top right corner the screen.

Status Page Setup Menu/Option Page Setup Menu

Press

[F1]

to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <

Esc

3-5 Menu Bars

There are six menu bars on top of BIOS screen:

Main To change system basic configuration Advanced To change system advanced configuration Chipset To change chipset configuration Security Password settings Boot To change boot settings Save & Exit Save setting, loading and exit options.

User can press the right or left arrow key on the keyboard to switch from menu bar. The selected one is highlighted.

3-6 Main Menu

Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item.

System Date

Set the date. Please use [Tab] to switch between data elements.

System Time

Set the time. Please use [Tab] to switch between time elements.

3-7 Advanced Menu

4 CPU Configuration

Press [Enter] to view current CPU configuration and make settings for the following sub-items:

Hyper-Threading

The optional settings: [Disabled]; [Enabled]. When set as [Disabled] only one thread per enabled core is enabled. [Enabled]: for Windows and Linux (OS optimized for Hyper-Threading Technology). [Disabled]: for other OS (OS optimized not for Hyper-Threading Technology).

*Note: ‘Hyper-Threading’ item may or may not show up, depending on different

CPU.

Intel (VMX) Virtualization Technology

The optional settings: [Enabled]; [Disabled]. When set as [Enabled], a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.

Intel(R) SpeedStep(tm)

This item allows more than two frequency ranges to be supported. The optional settings: [Disabled]; [Enabled].

C states

Use this item to enable or disable CPU power management. The optional settings: [Disabled]; [Enabled]. When set as [Enabled], it allows CPU to go to C states when it is not 100% utilized.

Turbo Mode

Use this item to enable or disable Turbo Mode.

*Note: This item might not be available depending on configuration.

4 SATA Configuration

Press [Enter] to make settings for the following sub-items:

SATA Configuration

SATA Controller(s)

The optional settings: [Disabled]; [Enabled]. When set as [Enabled], user can make further settings in the following items:

SATA Mode Selection

For NF893-H310 series: the optional setting is: [AHCI]. For NF893-H370 series: the optional settings are: [AHCI], [RAID].

M.2 (M2M)

Port

The optional settings: [Disabled]; [Enabled]. Use this item to enable or disable M2M port.

SATA1/SATA2

Port

The optional settings: [Disabled]; [Enabled]. Use this item to enable or disable device connected respective port.

Hot Plug

The optional settings: [Disabled]; [Enabled].

4 PCH-FW Configuration

Press [Enter] to view ME information and make settings in the following sub-item:

► Firmware Update Configuration

Use this item to configure Management Engine Technology parameters. Press [Enter] to make settings for ‘ME FW Image RE-Flash’.

ME FW Image Re-Flash

Use this item to enable or disable ME FW Image Re-Flash function. The optional settings: [Disabled]; [Enabled].

* In the case that user needs to update ME firmware, user should set ‘ME FW Image Re-Flash’ as [Enabled], save the settings and exit. The system will turn off

and reboot after 4 seconds. If the user goes to BIOS screen again will find this item is set again as [Disabled], but user can still re-flash to update firmware next time.

4 Trusted Computing

Press [Enter] to enable or disable ‘Security Device Support’.

Security Device Support

Use this item to enable or disable BIOS support for security device. The optional settings: [Disabled]; [Enabled].

*When set as [Enabled], user can make further settings in the following items:

Pending Operation

Use this item to schedule an operation for the security device. Your computer will reboot during restart to change state of device. The optional settings: [None]; [TPM Clear].

TPM2.0 UEFI Spec Version

Use this item to select the TCG2 Spec Version supported. The optional settings: [TCG_1_2]; [TCG_2].

4 ACPI Settings

Press [Enter] to make settings for the following sub-items:

ACPI Settings

ACPI Sleep State

Use this item to select the highest ACPI sleep state the system will enter when the suspend button is pressed. The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)].

4 Wake-up Function Settings

Press [Enter] to make settings for the following sub-items:

Wake-up System with Fixed Time

Use this item to enable or disable system wake on alarm event. The optional settings: [Disabled]; [Enabled]. When set as [Enabled], system will wake on the hour/min/sec specified.

Wake-up System with Dynamic Time

Use this item to enable or disable system wake on alarm event. System will wake on the current time + Increase minute(s). The optional settings: [Disabled]; [Enabled]. When set as [Enabled], system will wake on the current time + increased minute(s).

PS2 KB/MS Wake-up

Use this item to enable or disable PS2 KB/MS wake-up from S3/S4/S5. The optional settings: [Enabled]; [Disabled].

*Note: This function is supported when ‘ERP Support’ is set as [Disabled].

USB S3/S4 Wake-up

Use this item to enable or disable USB S3/S4 wakeup. This function is only supported when ERP function is disabled. The optional settings: [Enabled]; [Disabled].

*Note: This function is supported when ‘ERP Support’ is set as [Disabled].

USB S5 Power

Use this item to enable or disable USB power after power shutdown. The optional settings: [Enabled]; [Disabled].

*Note: This function is supported when ‘ERP Support’ is set as [Disabled].

Internal USB Port S5 Power

Use this item to enable or disable USB power after power shutdown. The optional settings: [Enabled]; [Disabled].

*Note: This function is supported when ‘ERP Support’ is set as [Disabled].

4 Super I/O Configuration

Press [Enter] to make settings for the following sub-items:

Super IO Configuration

ERP Support

The optional settings: [Disabled]; [Auto].

*Note: This item should be set as [Disabled] if you wish to have all active

wake-up functions.

► Serial Port 1 Configuration

Press [Enter] to make settings for the following items: Serial Port

Use this item to enable or disable serial port (COM).

Change Settings

Use this item to select an optimal setting for super IO device. Changing setting may conflict with system resources.

Transmission Mode Select

The optional settings are: [RS422]; [RS232]; [RS485].

Mode Speed Select

The optional settings are: [RS232/RS422/RS485=250kbps]; [RS232=1Mbps, RS422/RS485=10Mbps].

WatchDog Reset Timer

Use this item to enable or disable WDT reset function. When set as [Enabled], the following sub-items shall appear:

WatchDog Reset Timer Value User can select a value in the range of [10] to [255] seconds when ‘WatchDog Reset Timer Unit’ set as [Sec]; or in the range of [1] to [255] minutes when ‘WatchDog Reset Timer Unit ’ set as [Min]. WatchDog Reset Timer Unit

The optional settings are: [Sec.]; [Min.].

ATX Power Emulate AT Power

This item support Emulate AT power function, MB power On/Off control by power supply. Use needs to select ‘AT or ATX Mode’ on MB jumper at first (refer to Page

11 , Pin 1&2 of AT_COPEN jumper for ATX Mode & AT Mode Select).

Case Open Detect

Use this item to detect case has already open or not, show message in POST. The optional settings: [Disabled]; [Enabled]. When set as [Enabled], system will detect if COPEN has been short or not (refer to Page 11, Pin 3&4 of AT_COPEN jumper for case open detection); if COPEN is

short, system will show Case Open Message during POST.

4 Serial Port Console Redirection COM1

Console Redirection

The optional settings: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear:

4 Console Redirection Settings

The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. Press [Enter] to make settings for the following items:

Terminal Type

The optional settings: [VT100]; [VT100+]; [VT-UTF8]; [ANSI]. Emulation: [ANSI]: Extended ASCII char set; [VT100]: ASCII char set; [VT100+]: Extends VT100 to support color, function keys, etc.; [VT-UTF8]: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.

Bits per second

Use this item to select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. The optional settings: [9600]; [19200]; [38400]; [57600]; [115200].

Data Bits

The optional settings: [7]; [8].

Parity

A parity bit can be sent with the data bits to detect some transmission errors. The optional settings: [None]; [Even]; [Odd]; [Mark]; [Space]. [Even]: parity bit is 0 if the num of 1’s in the data bits is even; [Odd]: parity bit is 0 if num of 1’s in the data bits is odd; [Mark]: parity bit is always 1; [Space]: Parity bit is always 0; [Mark] and [Space] Parity do not allow for error detection.

Stop Bits

Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning). The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit.

The optional settings: [1]; [2].

Flow Control

Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a “stop” signal can be sent to stop the data flow. Once the buffers are empty, a “start” signal can be sent to re-start the flow. Hardware flow control uses two wires to send start/stop signals. The optional settings: [None]; [Hardware RTS/CTS].

VT-UTF8 Combo Key Support

Use this item to enable VT-UTF8 Combination Key Support for ANSI/VT100 terminals. The optional settings: [Disabled]; [Enabled].

Recorder Mode

With this mode enable only text will be sent. This is to capture Terminal data. The optional settings: [Disabled]; [Enabled].

Resolution 100x31

Use this item to enable or disable extended terminal resolution. The optional settings: [Disabled]; [Enabled].

Putty KeyPad

Use this item to select FunctionKey and KeyPad on Putty. The optional settings: [VT100]; [Linux]; [XTERMR6]; [SCO]; [ESCN]; [VT400].

Legacy Console Redirection

4 Legacy Console Redirection Settings

Press [Enter] to make settings for the following item:

Legacy Console Redirection Settings

Redirection COM Port

For user to select a COM port to display redirection of legacy OS and Legacy OPROM messages. The optional settings are: [COM1]; [COM1(Pci Bus0, Dev0, Func0) (Disabled)].

Resolution

This item is for user to select the number of Rows and Columns supported redirection. The optional settings are: [80x24]; [80x25].

Redirect After POST

The optional settings are: [Always Enable]; [Bootloader]. When [Bootloader] is selected, then Legacy Console Redirection is disabled before booting to legacy OS. When [Always Enabled] is selected, then Legacy Console Redirection is enabled for legacy OS. Default setting for this option is set to [Always Enabled].

Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS)

Console Redirection

The optional settings: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear:

4 Console Redirection Settings

Out-of-Band Mgmt Port

The optional settings: [COM1]; [COM1(Pci Bus0, Dec0,Func0) (Disabled)].

Terminal Type

The optional settings: [VT100]; [VT100+]; [VT-UTF8]; [ANSI]. [VT-UTF8] is the preferred terminal type for out-of-band management. The next best choice is [VT100+] and them [VT100]. See above, in Console Redirection Settings page, for more help with Terminal Type/Emulation.

Bits per second

Flow Control

The optional settings: [None]; [Hardware RTS/CTS]; [Software Xon/Xoff].

Data Bits

The default setting is: [8].

*This item may or may not show up, depending on different configuration.

Parity

The default setting is: [None].

*This item may or may not show up, depending on different configuration.

Stop Bits

The default setting is: [1].

*This item may or may not show up, depending on different configuration.

4 PC Health Status

Press [Enter] to view current hardware health status, make further settings in ‘SmartFAN Configuration’ and set value in ‘Shutdown Temperature’.

► SmartFAN Configuration

Press [Enter] to make settings for SmartFan Configuration:

SmartFAN Configuration

CPUFAN / SYSFAN Smart Mode

The optional settings are: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear:

CPUFAN / SYSFAN Full-Speed Temperature

Use this item to set CPUFAN/SYSFAN full speed temperature. Fan will run at full speed when above this pre-set temperature.

CPUFAN / SYSFAN Full-Speed Duty

Use this item to set CPUFAN/SYSFAN full-speed duty. Fan will run at full speed when above this pre-set duty.

CPUFAN / SYSFAN Idle-Speed Temperature

Use this item to set CPUFAN /SYSFAN idle speed temperature. Fan will run at idle speed when below this pre-set temperature. CPUFAN / SYSFAN Idle-Speed Duty Use this item to set CPUFAN/SYSFAN idle speed duty. Fan will run at idle speed when below this pre-set duty.

Shutdown Temperature

Use this item to select system shutdown temperature. The optional settings are: [Disabled]; [70oC/158oF]; [75oC/167oF]; [80oC/176oF]; [85oC/185oF]; [90oC/194oF].

4 USB Configuration

Press [Enter] to make settings for the following sub-items:

USB Configuration

Legacy USB Support

The optional settings are: [Enabled]; [Disabled]; [Auto]. [Enabled]: To enable legacy USB support. [Disabled]: to keep USB devices available only for EFI specification, [Auto]: To disable legacy support if no USB devices are connected.

XHCI Hand-off

This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. The optional settings are: [Enabled]; [Disabled].

USB Mass Storage Driver Support

The optional settings are: [Disabled]; [Enabled].

USB hardware delay and time-out:

USB Transfer time-out

Use this item to set the time-out value for control, bulk, and interrupt transfers. The optional settings are: [1 sec]; [5 sec]; [10 sec]; [20 sec].

Device reset time-out

Use this item to set USB mass storage device start unit command time-out. The optional settings are: [10 sec]; [20 sec]; [30 sec]; [40 sec].

Device power-up delay

Use this item to set maximum time the device will take before it properly reports itself to the host controller. ‘Auto’ uses default value: for a root port it is 100 ms, for a hub port the delay is taken from hub descriptor. The optional settings: [Auto]; [Manual].Select [Manual] you can set value for the following sub-item: Device Power-up delay in seconds, the delay range in from 1 to 40 seconds, in one second increments.

4 Network Stack Configuration

Press [Enter] to go to ‘Network Stack’ screen to make further settings.

Network Stack

Use this item to enable or disable UEFI Network Stack. The optional settings: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear:

Ipv4 PXE Support

The optional settings are: [Disabled]; [Enabled]. Use this item to enable Ipv4 PXE Boot Support. When set as [Disabled], Ipv4 boot option will not be created.

Ipv6 PXE Support

The optional settings are: [Disabled]; [Enabled]. Use this item to enable Ipv6 PXE Boot Support. When set as [Disabled], Ipv6 boot optional will not be created.

PXE boot wait time

Use this item to set wait time to press [ESC] key to abort the PXE boot.

Media Detect Count

Use this item to set number of times presence of media will be checked.

4 CSM Configuration

Press [Enter] to make settings for the following sub-items:

CSM Support

Use this item to enable or disable CSM Support The optional settings are: [Disabled]; [Enabled].

Option ROM execution

Network

This option controls the execution of UEFI and Legacy PXE OpROM. The optional settings are: [Do not launch]; [Legacy].

Storage

This option controls the execution of UEFI and Legacy Storage OpROM. The optional settings are: [Do not launch]; [UEFI]; [Legacy].

Other PCI devices

This item is for PCI devices other than Network, Mass storage or video defines which OpROM to launch.

The optional settings are: [Do not launch]; [UEFI]; [Legacy].

4 NVMe Configuration

Press [Enter] to check NVMe controller and driver information.

4 Intel(R) Ethernet Connection (7) I219-V- XX:XX:XX:XX:XX:XX

This item shows current network brief information.

3-8 Chipset Menu

4 System Agent (SA) Configuration

Press [Enter] to make settings for the following sub-items:

VT-d

The optional settings are: [Enabled]; [Disabled].

► Memory Configuration

Press [Enter] to view brief information for the working memory module.

► Graphics Configuration

Press [Enter] to make further settings for Graphics Configuration.

Graphics Configuration

Primary IGFX Boot Display

Use this item to select the video device which will be activated during POST. This has no effect if external graphics present. The optional settings are: [VBIOS Default]; [DP]; [HDMI]; [LVDS].

*Note: In the case that the ‘Primary IGFX Boot Display’ is select as [DP], [HDMI],

or [LVDS], user can make further settings in ‘Secondary IGFX Boot Display’:

Secondary IGFX Boot Display

Use this item to select the secondary Display device. The optional settings are: [Disabled]; [DP]; [HDMI].

Aperture Size

Use this item to select the Aperture Size. Above 4GB MMIO BIOS assignment is automatically enabled when selecting 2048MB aperture. To use this feature, please disable CSM Support. The optional settings are: [128MB]; [256MB]; [512MB]; [1024MB]; [2048MB].

DVMT Pre-allocated

Use this item to select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. The optional settings are: [32M]; [64M].

DVMT Total Gfx Mem

Use this item to select DVMT 5.0 Total Graphic Memory size used by the Internal Graphics Device. The optional settings are: [128M]; [256M]; [MAX].

Backlight Control

Use this item to select Back Light Control settings. The optional settings are: [PWM Inverted]; [PWM Normal].

*Note: This function is supported when ‘Primary IGFX Boot Display’ is set as

[LVDS].

Panel Type

Use this item to manually select LCD panel type. The optional setting are: [800x 480 18bit Single]; [800x 600 18bit Single]; [800x 600 24bit Single]; [1024 x 600 18bit Single]; [1024 x 768 18bit Single]; [1024 x 768 24bit Single]; [1280 x 768 24bit Single]; [1280 x 800 18bit Single]; [1280 x 800

24bit Single]; [1366 x 768 18bit Single]; [1366 x 768 24bit Single]; [1440 x 900 18bit Dual]; [1440 x 900 24bit Dual]; [1280 x 1024 24bit Dual]; [1680 x 1050 24bit Dual]; [1920 x 1080 24bit Dual].

*Note: This function is supported when ‘Primary IGFX Boot Display’ is set as

[LVDS].

LVDS FW Write Protect

Use this item to enable or disable support LVDS FW update/Protect. The optional settings are: [Enabled]; [Disabled].

*Note: This function is available when ‘Primary IGFX Boot Display’ is set as

[LVDS].

4 PCH-IO Configuration

Press [Enter] to make settings for the following sub-items:

PCH-IO Configuration

HD Audio

This item controls detection of the HD-Audio device. The optional settings are: [Disabled]; [Enabled]. [Disabled]: HDA will be unconditionally disabled. [Enabled]: HAD will be unconditionally enabled.

Onboard Lan Controller

Use this item to enable or disable corresponding onboard NIC device or controller. The optional settings are: [Disabled]; [Enabled].

*When set as [Enabled], the following sub-items shall appear:

Wake on LAN Enable

Use this item to enable or disable integrated LAN to wake the system. The optional settings are: [Disabled]; [Enabled].

PCI-E Slot

Use this item to enable or disable PCI-E slot PCI Express root port function. The optional settings are: [Disabled]; [Enabled].

Speed

Use this item to configure PCIe speed. The optional settings are: [Auto]; [Gen1]; [Gen2].

M2E Slot

Use this item to enable or disable M2E slot PCI Express root port function. The optional settings are: [Disabled]; [Enabled].

*M2M Slot

Use this item to enable or disable M2M slot PCI Express root port function. The optional settings are: [Disabled]; [Enabled].

*Note: ‘M2M Slot’ is only available for NF893-H370 series.

State After G3

Use this item to specify what state to go to when power re-applied after a power failure (G3 state). The optional settings are: [Always On]; [Always Off]; [Former State].

3-9 Security Menu

Security menu allow users to change administrator password and user password settings.

Administrator Password

If there is no password present on system, please press [Enter] to create new administrator password. If password is present on system, please press [Enter] to

verify old password then to clear/change password. Press again to confirm the new administrator password.

User Password

If there is no password present on system, please press [Enter] to create new administrator password. If password is present on system, please press [Enter] to verify old password then to clear/change password. Press again to confirm the new administrator password.

4 Secure Boot

Press [Enter] to make customized secure settings:

Secure Boot

The optional settings are: [Disabled]; [Enabled]. Secure Boot feature is active if Secure Boot is enabled, Platform Key (PK) is enrolled and the system is in User mode. The mode change requires platform reset.

Secure Boot Mode

The optional settings are: [Standard]; [Custom]. Set UEFI Secure Boot Mode to Standard mode or Custom mode. This change is effective after save. After reset, this mode will return to Standard mode. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication.

*When set as [Custom], user can make further settings in the following items that show up:

4 Restore Factory Keys Use this item to force system to User Mode, to install factory default Secure Boot key databases.

4 Reset To Setup Mode Use this item to delete all Secure Boot Key databases from NVRAM.

4 Key Management This item enables experienced users to modify Secure Boot variables, which includes the following items:

Factory Key Provision

This item is for user to install factory default secure boot keys after the platform

reset and while the system is in Setup mode. The optional settings are: [Disabled]; [Enabled].

4 Restore Factory Keys Use this item to force system into User Mode. Install factory default Secure Boot Key databases. 4 Reset to Setup Mode Use this item to delete all Secure Boot key databases from NVRAM. 4 Export Secure Boot variables Use this item to copy NVRAM content of Secure Boot variables to files in a root folder on a file system device. 4 Enroll Efi Image This item allows the image to run in Secure Boot Mode. Enroll SHA256 Hash certificate of a PE image into Authorized Signature Database (db).

Device Guard Ready

4 Remove ‘UEFI CA’ from DB Device Guard ready system must not list ‘Microsoft EFI CA’ Certificate in Authorized Signature database (db). 4 Restore DB defaults Use this item to restore DB variable to factory defaults.

Secure Boot Variable/Size/Keys/Key Source

4 Platform Key (PK)/Key Exchange Keys/Authorized Signature/Forbidden

Signature/ Authorized TimeStamps/OS Recovery Signatures

Use this item to enroll Factory Defaults or load the keys from a file with:

1. Public Key Certificate in: a) EFI_SIGNATURE_LIST

b) EFI_ CERT_X509 (DER encoded) c) EFI_ CERT_RSA2048 (bin) d) EFI_ CERT_SHAXXX (bin)

2. Authenticated UEFI Variable

3. EFI PE/COFF Image (SHA256) Key Source: Factory, External, Mixed.

3-10 Boot Menu

Boot Configuration

Setup Prompt Timeout

Use this item to set number of seconds to wait for setup activation key.

Bootup Numlock State

Use this item to select keyboard numlock state. The optional settings are: [On]; [Off].

Quiet Boot

The optional settings are: [Disabled]; [Enabled].

Boot Option Priorities

Boot Option #1/ Boot Option #2…

Use this item to decide system boot order from available options.

3-11 Save & Exit Menu

Save Options

Save Changes and Reset

This item allows user to reset the system after saving the changes.

Discard Changes and Reset

This item allows user to reset the system without saving any changes.

Default Options

Restore Defaults

Use this item to restore /load default values for all the setup options.

Save as User Defaults

Use this item to save the changes done so far as user defaults.

Restore User Defaults

Use this item to restore the user defaults to all the setup options.

Boot Override

UEFI: Built-in EFI Shell

Press this item and a dialogue box shall appear to ask if user wish to save configuration and reset.

Intel H310, H370 Technical Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
