GA-8I865GVMK-775

Intel® Pentium® 4 LGA775 Processor Motherboard

User's Manual

Rev. 1002

12ME-I865GVMKT-1002

Motherboard

GA-8I865GVMK-775

Motherboard

GA-8I865GVMK-775

June 15, 2005

June 15, 2005

Copyright

© 2006 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.

The trademarks mentioned in the manual are legally registered to their respective companies.

Notice

The written content provided with this product is the property of Gigabyte.

No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without Gigabyte's prior written permission. Specifications and features are subject to change without prior notice.

Product Manual Classification

In order to assist in the use of this product, Gigabyte has categorized the user manual in the following:

For detailed product information and specifications, please carefully read the "Product User Manual".

For detailed information related to Gigabyte's unique features, please go to "Technology Guide" section on Gigabyte's website to read or download the information you need.

For more product details, please click onto Gigabyte's website at www.gigabyte.com.tw

Table of Contents

GA-8I865GVMK-775 Motherboard Layout .....................................................................

6

Block Diagram ................................................................................................................



7

Chapter 1 Hardware Installation ....................................................................................

9

1-1

Considerations Prior to Installation ....................................................................

9

1-2

Feature Summary ..........................................................................................

10

1-3

Installation of the CPU and Heatsink ...............................................................

11

1-3-1 Installation of the CPU ..........................................................................................

11

1-3-2 Installation of the Heatsink ..................................................................................

12

1-4

Installation of Memory ....................................................................................

13

1-5

Installation of Expansion Cards ......................................................................

15

1-6

I/O Back Panel Introduction ...........................................................................

16

1-7

Connectors Introduction ..................................................................................

17

Chapter 2 BIOS Setup ................................................................................................

27

The Main Menu (For example: BIOS Ver. : E1) .......................................................

28

2-1

Standard CMOS Features .............................................................................

30

2-2

Advanced BIOS Features ..............................................................................

32

2-3

Integrated Peripherals .....................................................................................

34

2-4

Power Management Setup .............................................................................

37

2-5

PnP/PCI Configurations .................................................................................

38

2-6

PC Health Status ...........................................................................................

39

2-7

Frequency/Voltage Control .............................................................................

40

2-8

Load Fail-Safe Defaults ...................................................................................

41

2-9

Load Optimized Defaults .................................................................................

41

2-10

Set Supervisor/User Password .....................................................................

42

2-11

Save & Exit Setup .........................................................................................

43

2-12

Exit Without Saving .......................................................................................

43

- 4 -

Chapter 3 Drivers Installation ......................................................................................

45

3-1

Install Chipset Drivers ....................................................................................

45

3-2

SoftwareApplication .......................................................................................

46

3-3

Software Information .......................................................................................

46

3-4

Hardware Information .....................................................................................

47

3-5

Contact Us .....................................................................................................

47

Chapter 4 Appendix

...................................................................................................

49

4-1

Unique Software Utilities ................................................................................

49



4-1-1

Xpress Recovery2 Introduction .........................................................................

49



4-1-2

Flash BIOS Method Introduction ........................................................................

51



4-1-3

2- / 4- / 5.1- Channel Audio Function Introduction ..........................................

60

4-2

Troubleshooting ...............................................................................................

64

- 5 -

GA-8I865GVMK-775 Motherboard Layout

KB_MS

ATX_12V

LPT

COMA

VGA

R_USB

USB

LAN

LPC47M997



AUDIO









F_AUDIO

LGA775

Intel 865GV

ATX

CPU_FAN

GA-8I865GVMK-775



IDE2

DDR1 DDR2

DDR3 DDR4

BAT

FDD

IDE1

CLR_CMOS

EP82562G

PCI1

Intel ICH5





BIOS







SATA0



PCI2



IR



SATA1





SPDIF





CODEC





PCI3









PWR_LED



F_USB1

F_USB2





CD_IN

COMB



F_PANEL







SYS_FAN

- 6 -

Block Diagram













LGA775



CPUCLK+/-(133/200MHz)













Processor









Host





VGA

Interface

DDR 400/333/266MHz DIMM











Intel



Dual Channel Memory





865GV



HCLK (133/200MHz)





GMCH









GMCHCLK (66MHz)

















66MHz









33MHz









14.318MHz









48MHz









BIOS

PCI Bus



Intel



2 Serial ATA











ICH5



ATA33/66/100











EP82562G



IDE Channels



RJ45





Floppy

















LPT Port









LPC47M997





CODEC



COM Ports









3 PCI



8 USB

PS/2 KB/Mouse



14.318MHz





MIC -LineOut Line-In

Ports

33MHz







PCICLK









(33MHz)









- 7 -

- 8 -

Chapter 1Hardware Installation

1-1 Considerations Prior to Installation

Preparing Your Computer

The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please follow the instructions below:

1.Please turn off the computer and unplug its power cord.

2.When handling the motherboard, avoid touching any metal leads or connectors.

3.It is best to wear an electrostatic discharge (ESD) cuff when handling electronic components (CPU, RAM).

4.Prior to installing the electronic components, please have these items on top of an antistatic pad or within a electrostatic shielding container.

5.Please verify that the power supply is switched off before unplugging the power supply connector from the motherboard.

Installation Notices

1.Prior to installation, please do not remove the stickers on the motherboard. These stickers are required for warranty validation.

2.Prior to the installation of the motherboard or any hardware, please first carefully read the information in the provided manual.

3.Before using the product, please verify that all cables and power connectors are connected.

4.To prevent damage to the motherboard, please do not allow screws to come in contact with the motherboard circuit or its components.

5.Please make sure there are no leftover screws or metal components placed on the motherboard or within the computer casing.

6.Please do not place the computer system on an uneven surface.

7.Turning on the computer power during the installation process can lead to damage to system components as well as physical harm to the user.

8.If you are uncertain about any installation steps or have a problem related to the use of the product, please consult a certified computer technician.

Instances of Non-Warranty

1.Damage due to natural disaster, accident or human cause.

2.Damage as a result of violating the conditions recommended in the user manual.

3.Damage due to improper installation.

4.Damage due to use of uncertified components.

5.Damage due to use exceeding the permitted parameters.

6.Product determined to be an unofficial Gigabyte product.

English

- 9 -

Hardware Installation

English

1-2 Feature Summary

CPU



Supports the latest Intel® Pentium® 4 LGA775 CPU





Supports 800/533MHz FSB



L2 cache varies with CPU

Chipset



Northbridge: Intel® 865GV Chipset





Southbridge: Intel® ICH5

Memory



4 DDR DIMM memory slots (supports up to 4GB memory) (Note)



Supports dual channel DDR 400/333/266 unbuffered DIMM



Supports 2.5V DDR DIMM

Slots



3 PCI slots

IDE Connections



2 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of





4 IDE devices

FDD Connections



1 FDD connection, allows connection of 2 FDD devices

Onboard SATA



2 Serial ATA ports from ICH5 controller (SATA0, SATA1)

Peripherals



1 parallel port supporting Normal/EPP/ECP mode



1 VGA port, 1 COMA port, onboard COMB connection



8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)



1 front audio connector





1 IR connector



1 PS/2 keyboard port



1 PS/2 mouse port

Onboard VGA



Built-in Intel® 865GV Chipset

Onboard LAN



Onboard EP82562G chip (10/100 Mbit)





1 RJ45 port

Onboard Audio



ADI AD1888 CODEC



Supports 2 / 4 / 5.1 channel audio



Supports Line In (Rear Speaker Out) ; Line Out (Front Speaker Out) ;





MIC (Center/Subwoofer Speaker Out)





SPDIF Out connection





CD In connection

I/O Control



SMSC LPC47M997

Hardware Monitor



System voltage detection



CPU / System temperature detection



CPU / System fan speed detection

BIOS



Use of licensed AWARD BIOS





Supports Q-Flash

Additional Features



Supports @BIOS

Form Factor



Micro ATX form factor; 24.4cm x 24.4cm

(Note) Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system startup.

GA-8I865GVMK-775 Motherboard

- 10 -

1-3 Installation of the CPU and Heatsink

Before installing the CPU, please comply with the following conditions:

1.Please make sure that the motherboard supports the CPU.

2.Please take note of the one indented corner of the CPU. If you install the CPU in the wrong direction, the CPU will not insert properly. If this occurs, please change the insert direction of the CPU.

3.Please add an even layer of heat sink paste between the CPU and heatsink.

4.Please make sure the heatsink is installed on the CPU prior to system use, otherwise overheating and permanent damage of the CPU may occur.

5.Please set the CPU host frequency in accordance with the processor specifications. It is not recommended that the system bus frequency be set beyond hardware specifications since it does not meet the required standards for the peripherals. If you wish to set the frequency beyond the proper specifications, please do so according to your hardware specifications including the CPU, graphics card, memory, hard drive, etc.

HT functionality requirement content :

Enabling the functionality of Hyper-Threading Technology for your computer system requires all of the following platform components:

-CPU: An Intel® Pentium 4 Processor with HT Technology

-Chipset: An Intel® Chipset that supports HT Technology

-BIOS: A BIOS that supports HT Technology and has it enabled

-OS: An operation system that has optimizations for HT Technology

1-3-1 Installation of the CPU





Metal Lever

Fig. 1

Fig. 2





Gently lift the metal

Remove the plastic













lever located on the

covering on the CPU







CPU socket to the

socket.







upright position.











Fig. 3

Fig. 4







Notice the small gold

Once the CPU is







colored triangle located

properly inserted,







on the edge of the CPU

please replace the







socket. Align the

plastic covering and







indented corner of the

push the metal lever

CPU with the triangle and gently insert the CPU into

back into its original

position.

position. (Grasping the CPU firmly between your





thumb and forefinger, carefully place it into the socket





in a straight and downwards motion. Avoid twisting or





bending motions that might cause damage to the CPU





during installation.)

























- 11 -

Hardware Installation

English

English

1-3-2 Installation of the Heatsink

Male Push Pin

The top of Female Push Pin

Female Push Pin

Fig.1

Please apply an even layer of heatsink paste on the surface of the installed CPU.

Fig. 3

Place the heatsink atop the CPU and make sure the push pins aim to the pin hole on the motherboard. Pressing down the push pins diagonally.

Fig. 5

Please check the back of motherboard after installing. If the push pin is inserted as the picture, the installation is complete.

Fig. 2

(Turning the push pin along the direction of arrow is to remove the heatsink, on the contrary, is to install.) Please note the direction of arrow sign on the male push pin doesn't face inwards before installation. (This instruction is only for Intel boxed fan)

Fig. 4

Please make sure the Male and Female push pin are joined closely. (for detailed installation instructions, please refer to the heatsink installation section of the user manual)

Fig. 6

Finally, please attach the power connector of the heatsink to the CPU fan header located on the motherboard.

The heatsink may adhere to the CPU as a result of hardening of the heatsink paste. To prevent such an occurrence, it is suggested that either thermal tape rather than heat sink paste be used for heat dissipation or using extreme care when removing the heatsink.

GA-8I865GVMK-775 Motherboard

- 12 -

1-4 Installation of Memory

Before installing the memory modules, please comply with the following conditions:

1.Please make sure that the memory used is supported by the motherboard. It is

recommended that memory of similar capacity, specifications and brand be used.

2.Before installing or removing memory modules, please make sure that the computer power is switched off to prevent hardware damage.

3.Memory modules have a foolproof insertion design. A memory module can be installed in only one direction. If you are unable to insert the module, please switch the direction.

The motherboard supports DDR memory modules, whereby BIOS will automatically detect memory capacity and specifications. Memory modules are designed so that they can be inserted only in one direction. The memory capacity used can differ with each slot.

English

Notch

DDR

Fig.1

The DIMM socket has a notch, so the DIMM memory module can only fit in one direction. Insert the DIMM memory module vertically into the DIMM socket. Then push it down.

Fig.2

Close the plastic clip at both edges of the DIMM sockets to lock the DIMM module.

Reverse the installation steps when you wish to remove the DIMM module.

- 13 -

Hardware Installation

English

Dual Channel DDR

GA-8I865GVMK-775 supports the Dual Channel Technology. After operating the Dual Channel Technology, the bandwidth of Memory Bus will double.

GA-8I865GVMK-775 includes 4 DIMM sockets, and each Channel has two DIMM sockets as following:

Channel A : DDR 1, DDR 2

Channel B : DDR 3, DDR 4

If you want to operate the Dual Channel Technology, please note the following explanations due to the limitation of Intel chipset specifications.

1.Dual channel memory cannot be used if one or three DDR memory modules are installed.

2.If two DDR memory modules are installed (same storage capacity), one must be added to the Channel A slot and the other in the Channel B slot in order to use dual channel memory. Dual channel memory cannot function if both DDR memory modules are installed on the same channel.

3.If four DDR memory modules are installed, please use memory of the same storage capacity in

order to use dual channel memory and for BIOS to detect all the DDR memory modules.

We'll strongly recommend our user to slot two DDR memory modules into the DIMMs with the same color in order for Dual Channel Technology to work.

The following table is for Dual Channel Technology combination: (DS: Double Side, SS: Single Side)



DDR 1

DDR 2

DDR 3

DDR 4

2 memory modules

DS/SS

X

DS/SS

X



X

DS/SS

X

DS/SS

4 memory modules

DS/SS

DS/SS

DS/SS

DS/SS











GA-8I865GVMK-775 Motherboard

- 14 -

1-5 Installation of Expansion Cards

You can install your expansion card by following the steps outlined below:

1.Read the related expansion card's instruction document before install the expansion card into the computer.

2.Remove your computer's chassis cover, screws and slot bracket from the computer.

3.Press the expansion card firmly into expansion slot in motherboard.

4.Be sure the metal contacts on the card are indeed seated in the slot.

5.Replace the screw to secure the slot bracket of the expansion card.

6.Replace your computer's chassis cover.

7.Power on the computer, if necessary, setup BIOS utility of expansion card from BIOS.

8.Install related driver from the operating system.

Installing a PCI expansion card:

English

- 15 -

Hardware Installation

English

1-6 I/O Back Panel Introduction

PS/2 Keyboard and PS/2 Mouse Connector

To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple).

Parallel Port

The parallel port allows connection of a printer, scanner and other peripheral devices.

COMA (Serial Port)

Connects to serial-based mouse or data processing devices.

VGA Port

Monitor can be connected to VGA port.

USB port

Before you connect your device(s) into USB connector(s), please make sure your device(s) such as USB keyboard, mouse, scanner, zip, speaker...etc. have a standard USB interface. Also make sure your OS supports USB controller. If your OS does not support USB controller, please contact OS ven dor for possible patch or driver upgrade. For more information please contact your OS or device(s) vendors.

LAN Port

The provided Internet connection provides data transfer speeds of 10/100Mbps.

Line In

Devices like CD-ROM, walkman etc. can be connected to Line In jack.

Line Out

Connect the stereo speakers or earphone to this connector.

MIC In

Microphone can be connected to MIC In jack.

You can use audio software to configure 2-/4-/5.1-channel audio functioning.

GA-8I865GVMK-775 Motherboard

- 16 -

1-7 Connectors Introduction

1

3

2



5



6

11

9





17



4

16

7

13



8

12 15 14 10

1)

ATX_12V

10)

F_PANEL

2)

ATX (Power Connector)

11)

F_AUDIO

3)

CPU_FAN

12)

CD_IN

4)

SYS_FAN

13)

SPDIF

5)

FDD

14)

F_USB1 / F_USB2

6)

IDE1 / IDE2

15)

COMB

7)

SATA0 / SATA1

16)

IR

8)

PWR_LED

17)

CLR_CMOS

9)

BAT





English

- 17 -

Hardware Installation

English

1/2) ATX_12V/ATX (Power Connector)

With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.

The ATX_12V power connector mainly supplies power to the CPU. If the ATX_12V power connector is not connected, the system will not start.

Caution!

Please use a power supply that is able to handle the system voltage requirements. It is recommended that a power supply that can withstand high power consumption be used (300W or greater). If a power supply is used that does not provide the required power, the result can lead to an unstable system or a system that is unable to start.

If you use a 24-pin ATX power supply, please remove the small cover on the power connector on the motherboard before plugging in the power cord ; otherwise, please do not remove it.

4 2

3 1

13 1

24 12



Pin No.

Definition





1

GND





2

GND





3

+12V





4

+12V











Pin No.

Definition



1

3.3V



2

3.3V



3

GND



4

+5V



5

GND



6

+5V



7

GND



8

Power Good



9

5V SB(stand by +5V)



10

+12V



11

+12V



12

3.3V





(Only for 24pins ATX)









13

3.3V



14

-12V



15

GND



16

PS_ON(soft On/Off)



17

GND



18

GND



19

GND



20

-5V



21

+5V



22

+5V



23

+5V



24

GND

GA-8I865GVMK-775 Motherboard

- 18 -

+ 54 hidden pages
