1 getting stArted

Congratulations on your new phone purchase.

This guide will help you quickly come up to speed on the important features
of your phone.

Keep in mind your phone has:

• Fast Processor: Featuring the 1.6GHz Intel® Atom™ processor that enables
fast web browsing, super-responsive apps, and effortless multi-tasking, so
that enjoying the things you love to do has never been easier.

• Intelligent Camera: Featuring an advanced 8MP HD camera that lets you
capture images quickly - up to 10 photos a second - so you’ll never miss the
best shot, even in challenging environments.

• Great Entertainment: Easily create and share true HD-quality video, and
with super-smooth playback, your phone becomes a personal theatre you
can take with you anywhere. Maximize your entertainment experience by
projecting your smartphone screen to your HD TV through an HDMI cable.

NOTE: Screen images and icons are simulated for the purpose of this guide.
Actual displays may vary. Instructions in this guide may change depending on
the software version on your device.

1.1 Your Phone

Flash

Volume

Micro-SIM

Card Tray

Active Noise Cancellation

Microphone*

Rear-Facing
Camera

HDMI Port

Camera Button

Speaker

USB/Power Port

*NOTE: Do not block microphone while on phone calls.

Speaker

PAge : 41.0 getting started

1.2 Phone Buttons

Front-Facing

Camera

Buttons

3.5 mm Audio JackPower Button

Earpiece

Power button

Volume

Camera button

Press to go back to the previous screen or to close a

menu or dialog box.

Press to display actions and settings specific to the

current screen.

Press to return to the center panel of the Home

screen.

TIP: Press and hold to display shortcuts to your most
recently-used apps.

Press to search your phone and the web. See Search

for more information.

Press and hold to turn your phone on. To turn the phone
off, press and hold then follow the instructions onscreen.

When your phone is on, press to wake your phone or put it
into sleep mode.

Press on the top to increase the volume or on the bottom
to decrease the volume.

TIP: Press either top or bottom to silence an incoming call.

Press and hold to switch to the camera.

TIP: When in the camera app, press to take a picture, or to
start and stop recording a video.

Back

Menu Home

Search

1.3 Phone slots, Ports & JAcks

3.5 mm
audio jack

USB/Power port

Micro-SIM
card tray

HDMI port

Plug in headphones or other audio device.

Connect USB cord to phone and power adapter to charge
the phone.

NOTE: You can plug the USB cord to phone and connect
to your PC.

Remove or replace micro-SIM card, using the provided
SIM eject tool to open the tray.

Plug in HDMI cable and connect to TV or other electronics
to transmit HD images.

PAge : 51.0 getting started

1.4 chArge the BAtterY

1.5 insert Micro-siM cArd

Before using your phone for the first time, charge the phone for four hours.

To charge the battery:

1. Attach one end of the USB cord to the phone’s micro-USB port and the

other end to the plug.

2. Plug the phone into the wall.

Plug into wall.

Connect

this end to

phone’s

USB port.

Connect this end
to plug.

If your micro-SIM card is not already installed in your phone, follow these
procedures to insert a micro-SIM card.

To insert the micro-SIM card:

1. Open the micro-SIM card tray with the included SIM eject tool.

2. Insert the micro-SIM card into the tray, making sure that it matches the
illustration on the tray.

3. Push the tray back into the phone.

2. Insert Micro-SIM card
into tray.

SIM eject tool

1.4.1 BAtterY tiPs

For the best battery life, let your battery drain down to 20% or less (indicated
by an orange battery icon in the status bar) before recharging, and do not
leave your phone plugged in after it is fully charged.

To make your charge last as long as possible:

• Change the screen timeout rate and display brightness
(see Display Settings).

•Disable Wi-Fi and NFC when not in use (see Wireless & Networks Settings).

NOTE: For optimal charging, please use the USB cable and charger provided
with the phone.

1. Insert SIM eject tool
into hole to open tray.

3. Push tray back
into phone.

NOTE: Use SIM eject tool only as indicated.

PAge : 61.0 getting started

1.6 using the heAdset

You can use your headset to listen to music or make phone calls.

To use the headset:

1. Plug the headset into the audio jack on your phone.

2. Place the earbuds in your ears and position the microphone so that it picks
up your voice (if you’re making a call).

To turn the phone off:

•Hold down the power button and touch Power Off.

RL

TIP: Use the button near the right earbud to mute and unmute the
microphone.

1.7 turn on the Phone

To turn on the phone:

•Hold down the power button to turn the phone on.

Hold down the power button,
then touch Power off to turn
the phone off.

1.8 set uP Your Phone

The first time you turn on your phone, you will be stepped through all of the
settings for configuring your phone. Doing so will allow you to set up your
contacts easily.

1.9 sleeP & WAke

When your phone is on, you can put the phone in sleep mode and lock your
phone. Your phone will go into sleep mode if left idle, to save battery life.

Hold down the power button to
turn the phone on.

TIP: One press puts your phone into Sleep mode. Pressing and holding allows
you to choose Silent mode or Airplane mode.

You can wake and unlock your phone when you’re ready to use it.

To put the phone in sleep mode:

•Briefly press the power button.

Your phone goes into sleep mode, without disrupting any running
application, download, or phone call.

PAge : 71.0 getting started

NOTE: If you press the power button for too long, you’ll see the power off
menu.

To wake the phone:

1. Press the Power button.

2. Place your finger on and slide it all the way to the right.

3. Your phone’s screen will resume display.

NOTE: If your phone is secured, you must enter your password, pin, or pattern
to wake it. See Securing Your Phone for more details.

TIP: You can go directly to the Camera app by sliding the lock to on the
left after waking your phone.

1.10 touchscreen

Use your fingers on the touchscreen to perform actions, open objects, slide
the screen, and more.

Below are the different ways of interacting with your touchscreen.

• Drag: Touch and hold an object then drag the object to a new location. For
example, drag any icon on the Home screen to a new location.

• Double-touch: Quickly touch the screen twice to zoom in when using the

Gallery or on zoomed-out Browser pages. For example, double-touch a news
site to zoom in on the text.

• Pinch: When using Gallery or zoomed-out Browser pages, place two fingers

on the screen at once, then move your fingers together to zoom out or move
them apart to zoom in. For example, pinch your fingers apart to zoom out of
a news site in the Browser.

• Slide: Quickly move your finger from one edge of the screen to the opposite

edge to scroll the display up, down, left or right. For example, quickly move
your finger from the left side of the Home screen to the right to scroll the
Home screen to a different panel.

• Touch: Touch an object on the screen to select or open it. For example,

touch on the Home screen to open the Phone app.

When the phone is in sleep
mode and you want to wake
the phone, press the power
button and then drag the
lock to the right.

• Touch and hold: Touch an object on the screen and continue to hold it to

reveal other options. For example, touch and hold an empty spot on the
Home screen to reveal options for adding items to the screen.

1.11 tiPs on using the touchscreen

• Do not use sharp tools, such as pens or a stylus, on the touchscreen—these
might scratch the screen.

•Do not allow the touchscreen to come in contact with other electrical

devices. Electrostatic discharges can cause the touchscreen to malfunction.

•Do not allow the touchscreen to get wet. The touchscreen may malfunction

in humidity or when exposed to water.

•For the best performance, remove the screen protection film before using

the device and tap the screen with your fingertip.

PAge : 81.0 getting started

2 hoMe screen & BAsic FeAtures

The Home screen is a gateway to all of your phone’s applications and
features, and displays whenever you turn on your phone.

Touch Google to
search the web via
text input tray.

Touch and hold
to change the
wallpaper.

Slide left or
right to see more
panels.

To scroll the Home screen:

•Slide the screen to the left or right.

TIP: The blue bar at the bottom of the screen indicates which one of the five
panels is displayed.

To quickly access your phone’s main functions:

Touch to call or
send a message
to your contacts.

Touch to make
a call.

Touch to open the
App tray.

TIP: To move any icon, touch and hold the icon, then drag it to a
new location.

To open the Home screen:

•Open the Home screen at any time by pressing the button.

The Home screen is split into five panels, with the center panel displayed
when the Home screen opens.

Touch an app to
open it.

Touch to send a
message.

Touch to browse
the web.

• Touch
and Answering Calls.

• Touch to see your contacts. For more information on contacts, see
Make and Answer Calls.

• Touch to choose an app from the App Launcher. For more information
on apps and the App Launcher, see Manage Applications.

•Touch to send a message. For more information on Messaging, see

Send and Receive Messages.

•Touch to browse the web. For more information on the Browser app,

see Browse the Web.

to make a call. For more information on calling, see Making

PAge : 92.0 hoMe screen & BAsic FeAtures

2.1 custoMizing Your hoMe screen

You can easily customize your Home screen by changing the background
picture (or wallpaper).

TIP: Rearrange items on your screen by touching and holding them and then
dragging them to a new location. You can also delete them by touching and
holding and then dragging them to the trash.

You can perform the following actions with folders.

To customize your Home screen:

• Touch and hold an empty space on the Home screen, then touch the type of
item you want to add and follow the prompts.

To open a folder

To add items to a folder

To remove items from a
folder

To rename a folder

Touch the folder. To make a new folder, stack
apps on top of each other in the home screen.

Drag an item on your Home screen into the
folder.

NOTE: You cannot put shortcuts in a
contact folder.

Touch and hold an item in the folder,
then release it on the Home screen or on
the trash icon.

Open a folder, then touch and hold the title bar
and enter a new folder name.

2.2 stAtus & notiFicAtion icons

The status bar at the top of the screen displays important information about
your phone.

Notification icons Status icons

The following types of items are available:

• Live Wallpapers are animated background images for your screen.

• Social Gallery allows you to choose photos on your phone to set as the

background image for your screen.

• Wallpapers are static background images for your screen.

• Notification icons tell you about new and ongoing events, such as a new

email or ongoing download.

• Status icons tell you about critical phone functions, such as battery life and

signal strength.

PAge : 102.0 hoMe screen & BAsic FeAtures

2.2.1 stAtus icons

Below are the status and notification icons you can expect to see.

Drag down to

display

notifications.

Touch a

notification to

respond.

To open the notifications panel:

•Drag the status bar to the bottom of the screen.

To respond to a notification:

• Touch a notification in the panel to open its application. For example,
touching a new email notification opens the Email app’s inbox.

To clear notifications:

•Open the notifications panel and touch X at the top right.

Touch to clear
notifications.

NOTE: Installed apps may use their own unique notification icons.

Connected to mobile
network

Mobile network in use Vibrate mode

Mobile network strength Ringer silenced

Roaming Battery very low

No signal Battery low

No micro-SIM card
installed

Connected to Wi-Fi network Battery full

Bluetooth wireless
technology on

Connected to wireless
product featuring
Bluetooth technology

Airplane mode

Alarm set

Battery partially drained

Battery charging

GPS on

Receiving location data from
GPS

Ongoing notifications, such as active downloads, will remain on the list.

To close the notifications panel:

•Drag the status bar back to the top of the screen.

PAge : 112.0 hoMe screen & BAsic FeAtures

2.2.2 notiFicAtion icons

2.3 seArch

New text or
multimedia message

Problem with text
or multimedia
message delivery

New voicemail Call in progress using a

Upcoming event Missed call

Data syncing Call forwarding on

Problem with sign-in or
sync

USB storage full Uploading data

Open Wi-Fi
network available

Phone connected via
USB cable

Phone sharing its
data connection via
USB tethering

More notifications

Call in progress

Bluetooth headset

Song playing

Downloading data

Download finished

Connected to or disconnected
from virtual private network
(VPN)

Search on your phone and on the web with the built-in Search function.

To run a search:

1. Press .

2. Type a search term. As you type, Search displays matching results.

3. Touch a matching result to open it.

TIP: Touch the icon next to a result to enter that result as search text.

TIP: Find items in a search-enabled app, such as Email or Music, by opening

the app and pressing .

Phone sharing its data
connection as a Wi-Fi
hotspot

USB tethering and
Wi-Fi hotspot

Application update available

System update available

PAge : 122.0 hoMe screen & BAsic FeAtures

2.3.1 seArch settings

2.5 using the APP lAuncher

You can change the default Search settings.

To change Search settings:

•From the Search screen, press Search settings.

Searchable items

Google Search

Select which applications to search by default.

NOTE: Only the selected applications will display and
be searched within the Search application.

Set your location and manage your Google search
history.

2.4 securing Your Phone

You can configure your phone to require a password, PIN, pattern, or even
facial recognition in order to turn it on or wake it up. Securing your phone can
help keep its contents private.

To secure your phone:

1. From the Home screen, press System settings Security.

2. Touch Screen lock to change the current security lock.

3. Select one of the following settings:

•None disables screen locking.

•Slide lets you drag an icon across the screen to unlock your phone.

•Face Unlock lets you use facial recognition to unlock your phone.

Apps are small programs that add features to your phone. Many apps come
preinstalled, and additional apps can be purchased in the Play Store.

Widgets are apps that run directly on your Home screen, such as a music
player, newspaper, or clock.

You can use the App launcher to easily access all of your installed apps.

To use the app launcher:

•Touch , then touch an app to open it.

To add an app shortcut to the Home screen:

• Touch and hold an app. Once the Home screen displays, drop the app
onto an empty spot on the Home screen.

1. Touch to open the App tray.

2. Touch an app to open it.

TIP: Use the doubleTwist™
app to seamlessly transfer
your songs, photos, and other
personal media from your PC to
your phone.

•Pattern lets you draw a custom pattern to unlock your phone.

• PIN lets you use a 4- to 16-digit number combination to unlock

your phone.

• Password lets you use a 4- to 16-character password to unlock your

phone.
Password must contain at least one letter.

NOTE: Once you have selected a lock for your phone, you will need to enter
this lock each time you turn on or wake up your phone.

2.6 using the PlAY store

Almost any app you can imagine is available for purchase (and often for free)
in the Play Store.

To use the Play Store:

•Touch , then touch .

Search or browse for apps. You’ll be able to confirm that you want to purchase
an app, and see the permissions it requires, before installing it on your phone.

TIP: Google™ Play Store can only be used when Google account is activated.

PAge : 132.0 hoMe screen & BAsic FeAtures

3 onscreen keYBoArd BAsics

The onscreen keyboard lets you use your touchscreen to dial numbers, type
emails, enter URLs, and more.

To use the Onscreen Keyboard:

• Touch any text field to display the onscreen keyboard, then touch the
characters on the keyboard to enter text.

TIP: Move the insertion point by touching where you want to enter text.

onscreen keYBoArd oPtions

While using the onscreen keyboard, the following options are available.

Switch keyboard display Touch the ?123 key to enter numbers and

symbols, or the ABC key to enter letters.

To see additional symbols while in
symbol display, touch =\<.

Capitalize the next letter

Touch
you enter.

Touch twice to turn CAPS LOCK on.

to capitalize the next letter

To view the keyboard in landscape orientation:

• Turn your phone sideways to rotate the keyboard, making it larger and easier
to use.

Delete text

Change keyboard language

Touch
character entered.

Touch and hold to continuously
erase characters.

If your keyboard has multiple languages
enabled, slide your finger across the
spacebar to change which language the
keyboard uses. See Language & Keyboard
Settings for information on enabling
multiple languages.

to erase the last

3.1 suggestions And Auto-coMPlete

The keyboard includes suggestions and auto-complete to make entering long
words easy.

To close the onscreen keyboard:

•Press .

PAge : 143.0 onscreen keYBoArd BAsics

To use the suggestions feature:

1. Begin entering text in a text field or message.Your phone displays

suggested words and punctuation directly above the keyboard.

2. Touch a suggested word or punctuation mark to enter it, or drag the display

to the right to see more suggestions.

TIP: Touch the spacebar after entering a word to append a period.

TIP: Change the keyboard language from the Home screen by pressing

System settings Language & input Language, then selecting

desired language.

To use the auto-complete feature:

• Touch the spacebar (or any punctuation mark) to enter the highlighted word.

3.1.1 user dictionArY For suggested Words

You can modify the dictionary which the onscreen keyboard uses to
suggest words.

To add a word to the user dictionary:

1. Type a word. The current word is highlighted in white at the left of the

suggested word list.

2. Touch and hold the word to add it to the user dictionary.

3.2 sWYPe keYBoArd

Swype(TM) is a powerful tool that lets you ‘swipe’ your finger across the
keyboard to spell out and enter words.

Swype and Android Keyboard cannot both be enabled simultaneously.

To select your keyboard:

1. From the Home screen, press System settings Language & input
Default.

2. Touch English (US) Android Keyboard, SwiftKey X for Intel, or Swype to select

the desired input method.

NOTE: To learn more about Swype, follow the tutorial under

System settings Language & Keyboard Swype.

For information on editing and deleting words in the user dictionary,
see Language & Keyboard Settings.

PAge : 153.0 onscreen keYBoArd BAsics

4 MAking & AnsWering cAlls

The Phone app allows you to make calls and easily store and find
your contacts.

You can move between the phone dialer, call history, contacts, and
favorites by touching the tabs at the top of the Phone app.

4.1 using the Phone tAB

The Phone app’s Phone tab lets you make and manage calls.

To make a call:

1. From the Home screen, touch .

2. Touch the numbers on the dial pad to dial a number, using to make

corrections.

3. Touch to dial the number.

NOTE: For international calls, first touch and hold 0 to enter + and then dial
the number.

NOTE: You can switch to any application without ending the call. Return to
the phone screen by expanding the notifications bar and touching .

PAge : 164.0 MAking & AnsWering cAlls

The following actions are available while you are on a call.

To hold a call

Touch

to hold or resume the current call.

4.1.1 Working With MultiPle cAlls

You can make another call while on a call.

To mute a call

To use speakerphone

To use a Bluetooth
headset

To end a call

Touch

Touch

Warning! To avoid damage to your hearing, do not
hold the phone against your ear when speakerphone
is turned on.

Touch
to a connected Bluetooth headset. See Wireless
Bluetooth Connection for more information.

Touch

to mute or unmute the call.

to turn speakerphone on or off.

to automatically transfer your calls

To add a call:

•While on a call, touch Add Call and dial another number.

To move between calls:

•Touch the name of the caller.

•To merge calls into a conference call:

• Touch to join two or more calls together into a single conference call.

PAge : 174.0 MAking & AnsWering cAlls

The following options are available when on a conference call.

To drop a
participant

Touch Manage, then touch

.

4.2 AnsWering & reJecting cAlls

When you receive a call, you will see the following screen.

To talk privately
to a participant

To end the call

Touch Manage, then touch
talking privately, touch Merge Calls to add the participant
back to the conference call.

Touch
all callers.

to end the conference call and disconnect

. When you are done

To accept a call:

• Drag the circle to

If you are already in a call, that call will be placed on hold while you answer
the new call.

.

4.1.2 VoiceMAil

When you receive voicemail, the message notification icon appears in the
notifications panel.

To check voicemail:

•Within the Phone app, press and hold the 1 key.

TIP: You can also open the notifications panel and touch the
message notification.

To reject a call:

• Drag the circle to .

The rejected call will automatically be directed to your voicemail.

PAge : 184.0 MAking & AnsWering cAlls

4.3 using the cAll log tAB

The call log lists calls you have made, missed, and received. You can also call
entries, send messages, and add caller information to contacts from the call
log.

To use the call log:

•From the Phone app, touch .

The following options are available from the call log.

To see more details

To call the entry

To send a text
message

Touch an entry.

Touch

Touch the entry to see more details, then touch
Send Text Message.

For more information on messaging, see Sending &
Receiving Messages.

.

To add to contacts

To remove an entry
from the call log

To remove all entries
from the call log

Touch the entry to see more details, then touch

For more information on adding contacts, see Using
the Contacts Tab.

Touch and hold the entry, then touch
Remove Call from Log.

Press

Clear Call Log.

.

PAge : 194.0 MAking & AnsWering cAlls

4.4 using the contActs tAB

The Contacts tab displays the contacts from your accounts along with any
contacts you have added.

To communicate with contacts:

•Touch the contact, then touch one of the following icons:

4.4.1 contAct sYnchronizAtion

By default, contacts in your accounts and on your phone will be synchronized,
so that any changes to the contacts on your phone will be matched in your
accounts, and vice versa. See Accounts for more information.

Depending on your account settings, information you add or remove from your
phone will be synchronized with your external accounts. See Accounts for
more information.

To find a contact:

1. From the Phone app, touch the Contacts tab.

Scroll up and down to view all contacts.

2. Touch a contact to see more details.

Touch the phone number to call a contact.

Touch

Touch the email address to send an email.

To add a contact:

1. From the Contacts tab, press .

2. Enter contact information, filling in as many or as few of the fields

as desired.

3. Touch Done to create a new contact, or press Discard to discard

the new contact without saving.

NOTE: If you have multiple accounts, select the account to which you want to
add the new contact.

to send a text message.

PAge : 204.0 MAking & AnsWering cAlls

TIP: Use the following controls to add information about the contact:

• Touch the arrow at the end of the name field to view more name fields.

• Touch and follow the prompts to choose or take a photo for your

contact’s icon.

TIP: Log into your Google account to manage your contacts online. Add, edit
or remove contacts, and they’ll automatically sync to your phone.

NOTE: Read-only contact information—such as that from an external app—
will only be hidden, not deleted.

To join contacts:

1. From the homescreen, touch the Contacts icon and then touch a contact.

Press Edit Join.

2. Touch All contacts.

TIP: The name and picture of the contact you select first will be used for the
resulting joined contact.

NOTE: Contacts with the same name from two different accounts are
automatically joined.

To separate contacts:

• From the homescreen, touch the Contacts icon and then touch a contact.

Press Edit Separate.

To edit a contact:

1. From the homescreen, touch the Contacts icon and then touch a contact.

Press Edit.

2. Modify the contact information, as described above.

3. Touch Done.

To delete a contact:

1. From the homescreen, touch the Contacts icon and then touch a contact.

Press Delete.

2. Touch OK to confirm.

PAge : 214.0 MAking & AnsWering cAlls

4.5 Quick contActs

4.6 contAct settings

You can fine-tune how contacts are displayed with the following settings.

To set display options:

•From the Contacts tab, touch Settings.

Some applications let you use Quick Contacts to easily call, message,
or otherwise communicate with a contact. Just look for the Quick
Contacts icon .

To use quick contacts:

1. Touch , then touch one of the app icons to communicate with the
contact using the selected app.

For example, touch to message the contact.

Sort list by

View contact names

You can fine-tune a specific contact’s options with the following settings.

To set contact options:

• From the Contacts tab, touch a contact and then touch

Ringtone

Incoming calls

Set whether contacts are ordered by first
or last name.

Set whether contacts display their first or
their last name first.

.

Specify the desired ringtone.

Send the contact’s calls directly
to voicemail.

TIP: Drag the Quick Contacts list to the left or right to reveal additional
app icons.

4.0 MAking & AnsWering cAlls

PAge : 22

5 sending & receiVing MessAges

The Message app allows you to send and receive text and multimedia
messaging threads (groups of sent and received messages).

To open the messaging app:

•From the Home screen, touch .

To view a message:

•Within the Message app, touch a messaging thread.

The messages inside the thread display, with the newest message at the
bottom of the screen.

TIP: Threads with new messages are displayed in bold.

5.1 sending MessAges

To send a message:

1. From the Message app, touch .

2. Enter a recipient in the To field.

Matching numbers and contacts appear as you type.

3. Touch a matching contact or number to select it, or enter a new number to
message a new contact.

4. Touch the Type to Compose field and enter a message.

5. Touch

TIP: You can add smileys, subject headings, and more. See Message Options,
below, for more information.

to send your message.

To view a multimedia attachment:

• If the message has a multimedia attachment, touch the attachment to
view it.

TIP: Touch and hold an attachment to download it to your phone.

PAge : 235.0 sending & receiVing MessAges

To attach multimedia to a message:

1. Touch

2. Select the desired type of attachment (for example, a music file or a

captured picture), then follow the prompts to send the message.

.

MessAge oPtions

The following actions are available while composing a message.

5.2 MAnAging MessAges

To delete a messaging thread:

• Open the messaging window, and touch a messaging thread.
Then touch .

TIP: Press Delete all threads to delete all messaging threads.

Save message as a draft

Resume working on a draft

Discard a draft

Enter a smiley

Add a subject heading to
your message

Press .

ALTERNATE: Exiting the Message app will also
save any draft messages.

Touch a message thread marked “Draft.”

Clear the message text.

Press
smiley you want to insert.

ALTERNATE: Touch and hold :-) on the onscreen
keyboard and select a smiley.

ALTERNATE: Enter the characters that make up
the smiley.

Press
heading.

Insert Smiley and touch the

Add subject and enter the subject

To forward, lock, or view message details:

1. Open the messaging window, and touch a messaging thread.

2. Touch and hold a message, then choose one of the following:

•Touch Copy text to copy the message. Open a new message, touch and
hold in the text field, and then choose Paste.

• Touch Forward, enter a recipient, and then touch the arrow to forward
a message.

• Touch Lock to keep a message from being automatically deleted. Touch
Unlock to remove the lock from a message.

• Touch View details to see message details, such as when a message was
sent.

•Touch Delete to delete the message.

PAge : 245.0 sending & receiVing MessAges

5.3 MessAge settings

MultiMediA (MMs) MessAges

To specify message settings:

•From the main Messaging window, press System settings.

The following settings are available.

storAge settings

Delete old messages

Text message limit

Multimedia message limit

Automatically delete the oldest message in a
messaging thread whenever the message limits
are exceeded.

Set the number of text messages to save in
each messaging thread. If Delete old messages is
enabled, your oldest text message will be deleted
whenever this limit is exceeded.

Set the number of multimedia messages to save
in each messaging thread. If Delete old messages
is enabled, your oldest multimedia message will
be deleted whenever this limit is exceeded.

text (sMs) MessAges

Delivery reports

Input mode

Request a delivery report whenever you send a
text message.

Select an SMS input mode to compose
messages.

Delivery reports

Read reports

Auto-retrieve

Roaming auto-retrieve

Creation mode

notiFicAtion settings

Notifications

Choose ringtone

Vibrate

Request a delivery report whenever you send a
multimedia message.

Request reports when your multimedia messages
are read or deleted.

Automatically download attachments from
incoming multimedia messages.

Turn on auto-retrieve even when on another
carrier’s network.

NOTE: Turning off this option lets you prevent
data roaming costs.

Select an MMS creation mode for composing
messages.

Receive a notification whenever a new message
is received.

Select the ringtone that plays when you receive a
message notification.

TIP: Select the ringtone “silent” to turn off
message ringtones.

Select to have the phone vibrate when you
receive a new message.

Manage SIM card
messages

Send SMS mode

Open a window where you can work with
messages stored in a SIM card.

NOTE: This option can be useful for retrieving
messages from a previous phone’s SIM card.

Select an SMS send mode.

PAge : 255.0 sending & receiVing MessAges

6 tAke Photos And Videos

The Camera app lets you take and share pictures and videos.

To start the Camera app:

• Touch in the App Launcher or press and hold the camera button on the
side of the phone until the Camera app opens.

Camera buttons and icons

Once opened, the Camera app displays the following icons and buttons:

Touch the Mode button to switch between photo, video, burst, and
panorama modes. Selecting a new mode changes the icon on the
shutter button to match the current mode.

Use the Shutter button to take a picture or shoot a video.

Touch to select the front-facing camera for self-portraits or the
back-facing camera for high-quality pictures.

Touch to zoom in or out.

Touch the Face icon to toggle Face Recognition on or off.

Turning off Face Recognition does not disable the ability to

recognize and search faces later in the Gallery, it only turns off

the display of those faces in the Camera.

Touch to bring up the Flash Settings menu.

Touch the Brightness icon to adjust exposure settings.

Image Tools are activated by touching the tools icon.

Touch the Image Preview icon to open the Gallery.

To take a picture:

1. Frame your subject on the camera.

2. Touch the Shutter button to take your picture and save the image to the
Gallery.

Auto-Focus:

When Auto-focus is selected, hold down the camera button halfway to focus
the area in the white brackets onscreen, and then push the camera button all
the way down to take a photo. See Changing Picture and Video Settings below
to learn about changing focus and other settings.

To shoot a video:

1. From the Camera app, touch the Mode button, and then select

2. Touch the Shutter button to begin recording. When done, press the Shutter
button again to stop recording and save the video to the Gallery.

.

PAge : 266.0 tAking Photos & Videos

Change flash settings:

Press the Flash icon to choose a setting from the options displayed at the
bottom of the screen: Auto flash, Flash off, Flash on, and Fill flash.

Use image tools:

Press the Tools icon to display the Image Tools menu, which is a two-level
menu controlled by the up and down arrows on the left side.

The current flash selection is displayed at the top of the screen.

NOTE: Some flash options are not selectable in some modes (e.g. Panorama)
or with certain Scene Modes selected (e.g. Night Mode).

Change exposure settings:

Press the Brightness icon to bring up a slider bar to adjust the exposure
(brightness) of the image. The icon on the left of the slider toggles Backlight
Compensation on or off. When backlight is on, the camera will adjust the
exposure to correctly light subjects when a strong light is behind them.

The first level is “Scene Mode” and is used to select pre-sets for Landscape,
Portrait, Night Scene, and Fireworks. Selections are displayed at the top of
the screen.

The second level “Color Effects” is used to apply color filters to your images,
including: Vivid Color, Sepia, Monochromatic, and Negative.

Selections are displayed at the top of the screen.

PAge : 276.0 tAking Photos & Videos

Use shooting modes:

There are four shooting mode options:
Video
Burst
Panorama
Touch the Mode button beneath the red Shutter button to display these
options. Selecting a new mode changes the icon on the shutter button to
match the current mode.

Use burst mode:

When the camera is set to Burst mode, each shutter press will take a series
of ten images. On the left side of the screen, touching the burst rate indicator
will extend a menu that allows you to change the frame rate at which bursts
are captured: 15fps, 7fps, or 1fps.

Use panorama mode:

Select the Panorama mode to sweep across a screen (horizontally or vertically)
and capture multiple images that will be automatically stitched together
into a single panoramic image. During Panoramic capture, several on-screen
elements assist in capturing and aligning images:

•The arrow indicates the direction to move the camera for the next shot.

•Press the red stop button to finish capturing multiple images.

•The counter displays the number of images that have been collected for this

panorama.

•A semi-transparent overlay of the previous image assists in aligning the next

image in the sequence. Simply move the camera until key details on the
two images are aligned, and the next image is automatically captured.

NOTE: When using Panorama Mode, you must take at least 2 pictures but not
more than 10.

PAge : 286.0 tAking Photos & Videos

To change advanced settings:

Camera settings are available at any time by pressing
include: Photo size, Video size, Geo-tag, and About.

Two photo sizes are available. The default size is a widescreen 6MP image;
you may also choose an 8MP image that is in 4:3 format and appears
centered in the screen.

Three different video sizes are available: Full HD (1080p), HD (720p),
or SD (480p).

. These settings

6.1 FAce recognition

Your phone’s camera is equipped with a state-of-the-art face recognition
system that is designed to make it easy to connect to friends and family
through photography.

Recognized faces are indicated by surrounding the face with a green rectangle
and displaying the person’s name tag beneath the face (nickname or first
name & last initial). Your camera can store up to 30 individual faces to
recognize.

Geo-tagging can be turned on or off. When it is on, location information will
be captured and stored with your photos.

Unrecognized faces are indicated by surrounding the face with a red
rectangle.

Face recognition accuracy depends on:

•Sufficient light to illuminate facial features.

•Optimum distance of 3 to 4 meters.

•Sharp focus and avoidance of camera shake.

Accuracy is also improved after multiple images of the same person, in
different conditions, have been saved and identified. The camera gets smarter
after multiple images since it has more data to compare.

All face recognition systems, including this camera’s, can be confused by
poor conditions, such as:

•The subject is blurred, either from motion of the subject or motion of the

camera.

•There is low image contrast due to poor lighting.

PAge : 296.0 tAking Photos & Videos

•Portions of the face are obstructed.

•Faces are in profile or turned so that not all features are visible. As a general

rule, both eyes and the mouth must be visible.

6.2 VieW Your Pictures & Video

Pictures and videos taken with the Camera app are stored in the Social
Gallery app, but they can be previewed within the main camera screen also.
The Social Gallery app displays the pictures and videos you’ve taken on your
phone, downloaded from the web, or uploaded to a synchronized Picasa
account (Google’s web-based photo storage).

6.3 Audio eFFects For Video

The Audio Effects enhancement can be used when viewing videos.

NOTE: Surround sound effect is better experienced when audio is played over
headphones.

To use Audio Effects:

•Touch and then touch . (You may need to scroll a page to the right.)

Function Description

Normal Default audio.

Cinema A custom equalization that improves video

sound tracks, as well as enabling a 3D effect

for improved surround sound.

Concert A custom equalization for music that also

enables a 3D effect for improved surround

sound.

Home Video Removes the unwanted noise characteristic

of non-professional recordings. It removes
excessive ambient noise and noise from air
conditioners and wind. This setting also
emphasizes speech, making people in the
video more understandable.

•Select a video from the Gallery.

•From the Complete action using dialog box, select Movies. The video will

begin playing. Touch the box beside Use by default for this action to skip
this step in the future.

•Touch to open the Audio Effects drop down menu.

•Touch the desired preset audio effect.

PAge : 306.0 tAking Photos & Videos

7 BroWsing the WeB

The browser application lets you surf the web on your Android phone.

To open the browser application:

•Press .

The Browser window opens and displays your home page.

You can slide the screen up and down to scroll the browser window, and use
the touchscreen to interact with the web page.

To navigate the browser:

•Press to move to the previous page.

•Press Forward to move to the next page.

•Press

To enter a URL or search terms:

1. Touch the URL/Search field at the top of the screen.

2. Enter a URL or search term, using the on-screen keyboard.

As you enter information, matching search terms and websites display.

3. Touch
website to open it, or touch a matching term to search for it.

TIP: If the URL field is hidden, press .

To zoom in and out:

•Double-touch to zoom in and out.

Once zoomed in, slide the screen up, down, left, and right to view the entire
page.

ALTERNATE: Pinch the screen to zoom in and out. See Touchscreen for more
information on how to pinch.

Stop to stop loading a page.

to open a URL or search for entered text, touch a matching

TIP: Touch a phone number to open the number in the phone app; touch an
address on a web page to open the location in the Maps app; touch an email
address to open the address in the Email or Gmail app.

TIP: Touch and hold an object, such as an address or photo, to bring up a
menu of commands. For example, touch and hold a photo to save the photo
on your phone.

To search for text within a webpage:

• Press Find on Page, then enter the text you want to

search for.

As you enter text into the search field, matching text on the page is
highlighted.

TIP: Touch to scroll through all matching text.

PAge : 317.0 BroWsing the WeB

7.1 BookMArks, Most Visited & historY

7.2 using MultiPle BroWser WindoWs

Easily bookmark frequently-visited sites, as well as view your bookmarks,
history, and most-visited sites.

To bookmark a site:

1. Touch at the top of the screen.

2. Touch Add.

3. Edit the information if desired, then touch OK to confirm.

To view bookmarks, history, and most visited sites:

1. Touch Bookmarks.

2. Touch the Bookmarks, Saved Pages, or History tab.

3. Touch the window to open it.

TIP: Touch and hold a page to open a menu that lets you manage an entry by
editing, deleting, sharing, and so on.

To clear your browser history:

•Press Settings Privacy & security Clear history to clear your

browser history.

For information on configuring or disabling what Browser tracks, see
Changing Browser settings.

You can have up to eight different browser windows open at one time.

To switch to another window:

•Touch , then touch a window.

To close a window:

•Touch , then touch beside a window.

To open a new window:

•Touch then touch .

7.3 set Your hoMe PAge

Your home page opens when the browser is first launched, or when you open a
new browser window. You can set which website to use as your home page in
the Settings window.

To set your home page:

1. Press More Settings Set Home Page

2. Enter a URL or touch Use Current Page.

3. Touch OK.

PAge : 327.0 BroWsing the WeB

7.4 chAnging BroWser settings

You can configure a number of Browser settings, such as how pages display,
or whether to track private information.

To change your browser settings:

•Press More Settings

PoPulAr BroWser settings

Refresh

Forward

Bookmarks

Save to bookmarks

Share page

Find on page

Request desktop site

Save for offline reading

Settings

General

Privacy & security

Accessibility

Advanced

Reloads the current page.

Moves to the next page.

Displays bookmarked and saved pages.

Adds current page to bookmarked pages.

Shares the current page using choice you select.

Searches for text within the current page.

Loads the desktop version of the site instead of
the mobile version.

Adds current page to Saved pages for reading
without internet connection.

Displays additional options (see below).

Set your homepage and toggle on/ off form auto­fill and auto-fill text.

Clear your browser’s cache, cookies, history,
location. Also includes settings for remembering
passwords and form data.

Displays options for increasing text size and
improving readability.

Displays options for setting default search
engine, enabling JavaScript and plug-ins,
resetting default zoom, blocking pop-ups, and
more.

Bandwidth management

Labs

Save bandwidth by preloading search results and
toggling web page images off.

Toggle quick controls and fullscreen mode off/on.

PAge : 337.0 BroWsing the WeB

8 PlAYing Music

The Music app lets you listen to your music, see your music library, and
create and listen to playlists.

To open the Music app:

•From the App launcher, touch .

The Music app opens and displays your library.

To view music on your phone:

• Touch one of the four tabs at the top of the screen to display Artists,

Albums, Songs, or Playlists.

TIP: To use a song as a ringtone, touch and hold the song, then touch Use as
phone ringtone.

To play music:

• Touch a song to play it and all of the songs following it (for example, touch a

song in an album to start playing the album, or touch a song in a playlist to
start the playlist.

TIP: Touch and hold an artist, album, or playlist, then touch Play to play every
song for that artist, album, or playlist.

8.1 PlAYBAck screen

The Playback screen displays the current song and lets you shuffle your
music, pause a song, and more.

NOTE: If this is your first time using the Music app, the Music app may first
have to catalogue the audio and music files on your phone into a library.

PAge : 348.0 PlAYing Music

To see the current playlist

To play your songs in
random order

Touch

Touch .

.

Rename or delete a playlist:

1. From the music library, touch the Playlist tab.

2. Touch and hold a playlist, then touch Rename or Delete.

To repeat a playlist or song

To open audio effects

Play the next song

Play the previous song

Pause or resume playing

TIP: Touch
screen.

at the bottom of the library screen to return to the playback

Touch
or twice to repeat all songs; touch again to
repeat current song, and touch once more to
turn repeat off.

Touch
about changing playback settings.

Touch .

Touch

Touch
to resume.

once to repeat the current playlist,

. See “Audio Effects” below to learn

.

to pause the current song, or

8.2 Working With PlAYlists

You can use playlists to organize your music files into sets of songs.

To create a playlist:

1. Touch and hold a song, then touch Add to playlist New.

2. Enter the name of the new playlist, then touch OK.The playlist is created,

with the song you selected as the new playlist’s first song.

3. Continue adding songs to the playlist by touching and holding each song

you want to add, then touching Add to playlist and selecting the playlist.

Rearrange songs in a playlist:

1. From the music library, touch the Playlists tab, then touch a playlist.

2. Touch and hold the left side of a song entry, then drag a song up or down
to change its order in the playlist.

3. Press to save the new arrangement and exit the playlist.

Remove songs from a playlist:

1. From the music library, touch the Playlist tab, then touch a playlist.

2. Touch and hold a song, then touch Remove from playlist.

8.3 MAnAging Music on Your Phone

You can search for and delete music on your phone.

To search for music on your phone

• In the main Music screen, touch , then type the name of an artist,
album or song to search your music library.

To delete a song from your phone:

1. Find the song you want to delete.

2. Touch and hold the song, then touch Delete.

3. Touch OK to confirm.

8.3.1 trAnsFerring Music FroM coMPuter

To transfer music, audio, or playlist files from your computer to your phone,
following the instructions for transferring files described in Transfer Files
between your Phone and Computer.

Once transferred, the Music app will automatically find and catalogue all
supported music, audio, and playlist files (including MP3, M4a, AMR, MIDI,
M3U, WPL, and PLS, and OGG Vorbis, as well as music purchased from
online stores, and music copied from your CD collection).

8.4 Audio eFFects For Music

All-new audio effects have been added to the music player to enhance your
audio playback experience. The new capabilities include equalizer, bass
boost, treble, 3D surround controls, and visualization effects. You can select
from presets or customize your new settings.

To use Audio Effects:

•From the Music app, select a song.

•Touch to display the Audio Effects control panel.

•Touch Audio effects ON/OFF to toggle Audio Effects.

PAge : 358.0 PlAYing Music

eQuAlizer Functions

Function Description

Equalizer Displays current preset.

Equalizer Presets Touch the word current preset on the right to

open the drop down menu. Select a desired

preset.

Bass boost Touch and slide to increase/decrease the bass

boost to the desired level.

NOTE: This effect is available only with
headphones plugged in.

Treble Touch and slide to increase/decrease the

treble level.

3D effect Touch to enable/disable the surround sound

effect.

NOTE: Surround sound effect is better
experienced when audio is played over
headphones.

VisuAlizer Functions

Music visualizations can be displayed while your music is playing.

To use the Visualizer:

•While playing a song, touch anywhere on the Album Art. The Spectrogram

Analyzer visualization displays. Touch again to scroll through various
visualizations.

8.0 PlAYing Music

PAge : 36

9 connections

Your Android phone can connect to Wi-Fi networks, Bluetooth wireless
technology-enabled products (such as headsets), and your computer. You can
also connect to virtual private networks (or VPNs) and use your phone as a
hotspot.

9.1 using Wi-Fi

Your phone can connect to Wi-Fi networks. Once connected, you can use your
connection to browse the internet, check your email, and more.

Use a Wi-Fi network to help save on data costs for your phone.

To connect to a wireless network:

1. From the Home screen, press System settings Wi-Fi.

2. If Wi-Fi is not enabled, touch Wi-Fi to turn it on.

3. The available networks display.

4. Touch a network, then touch Connect.

NOTE: For secured networks, enter the requested security information, then
touch Connect.

TIP: If no networks are listed, make sure the Wi-Fi box has a checkmark.

To add a network:

1. From the Home screen, press System settings Wi-Fi.

2. Scroll to the bottom of the list of available networks and touch

Add network.

3. Enter the network’s SSID (the name of the network).

4. Touch Save. Your phone saves the information entered, and uses it to

connect to the network whenever it is available.

NOTE: If the network is secured, enter the security information by touching
Open (under Security) and selecting the type of network security which

the network uses (for example, WEP or WPA/WPA2 PSK). Then enter the
requested security information, such as a password.

To remove or modify a saved network:

1. From the Home screen, press System settings Wireless &

networks Wi-Fi settings.

2. Touch and hold the network, then touch Forget network or Modify network.

9.2 Wireless Bluetooth® connection

To connect to a Bluetooth wireless technology-enabled product for the
first time, you must pair it with your phone. Once paired, your phone will
automatically connect to paired products. You can use your phone to connect
to wireless products featuring Bluetooth technology up to eight meters away.

To pair phone with Bluetooth wireless technology-enabled product:

1. From the Home screen, press System settings Wireless &

networks.

2. If Bluetooth wireless technology is not enabled, touch Bluetooth to turn it

on.

3. Touch Bluetooth settings. The available Bluetooth wireless technology-

enabled products display.

4. Select the product you wish to pair.

5. Confirm the product number and touch Pair to pair the product. Once

paired, your phone will automatically connect with the product.

NOTE: If the product requires a pass code before pairing, try entering 0000
or 1234, or check the product’s documentation. If your phone doesn’t display
the Bluetooth wireless technology-enabled product, touch Search for devices
to rescan. See the documentation that came with your product to learn how to
configure it to be discoverable by phone.

PAge : 379.0 connections

To disconnect a Bluetooth wireless technology-enabled product:

1. From the Home screen, press System settings Wireless &
networks Bluetooth settings.

2. Touch a connected product, then touch OK to disconnect.

To reconnect a paired Bluetooth wireless technology-enabled product:

1. From the Home screen, press
networks Bluetooth settings.

2. Touch a paired product that you want to connect.

To unpair Bluetooth wireless technology-enabled product:

1. From the Home screen, press System settings Wireless &
networks Bluetooth settings.

2. Touch next to a paired but disconnected product, then touch Unpair.

System settings Wireless &

9.3 neAr Field coMMunicAtions (nFc)

NFC allows you to exchange information with other nearby smartphones and
similar devices with just a swipe or a tap. Possibilities include: using your
phone as a credit card; paying for public transportation, as well as receiving
up-to-date schedules; interacting with smart posters for more information on
select topics; sharing games, links and more with friends simply by tapping
phones.

NOTE: To use Near Field Communications, download an NFC-enabled app
from the Play Store.

To enable NFC:

•From the Home screen, press System settings Wireless &

networks touch NFC.

9.4 trAnsFer Files BetWeen Your Phone & coMPuter

Transfer files between your phone and computer by connecting your phone to
your computer’s USB port.

To transfer files between your phone and your computer:

1. Use the USB cable that came with your phone (the “cord” of
your phone’s power cord) to connect your phone to your computer’s
USB port.

Warning! Follow any instructions that appear on your computer when
connecting to the USB port. Failure to follow these instructions may result
in damage to your files.

2. Once connected, you will see Connected as a media device at the top of the
screen. Touch Connected as a media device to change connection options to
Camera (PTP) options.

3. Touch Turn on USB Storage, then touch OK.

Once connected, your phone’s storage will appear as an accessible drive on
your computer. You can open the drive and copy files from it and to it just
as you would with a flash drive or memory card.

NOTE: While your phone is connected to your computer, any applications
that require access to your phone’s files (such as Gallery and Music) will
be unusable.

To disconnect your phone from the computer:

1. On your phone, touch Turn off USB storage.

2. If this screen is no longer displaying, drag down the notification panel and
touch Turn off USB storage to redisplay the screen.

3. Once “Preparing USB card” stops displaying in the notification area,
click “Safely remove hardware and eject media” from your computer’s
system tray.

4. Select your phone from the displayed options.

5. Disconnect the USB cable from your phone and your computer.

PAge : 389.0 connections

9.5 connecting to VirtuAl PriVAte netWorks

9.6 shAring Your Phone’s dAtA connection

Virtual private networks (VPNs) allow you to connect to a secured local
network from outside the network. VPNs are commonly deployed by schools,
corporations, and other institutions that rely primarily on an on-location
network, but allow secure access from the outside.

To connect to a VPN for the first time, add that VPN to your phone. You can
then connect to it automatically at any time.

To add a VPN to your phone:

1. From the Home screen, press System settings More... (under
the Wireless & Networks section) VPN Add VPN network.

2. Select the type of VPN, based on instructions from your VPN administrator,
and then follow your network administrator’s instructions to configure each
component of the VPN’s settings.

3. When you are done configuring the VPN, touch Save.

Your phone saves the VPN’s configuration and connects.

To connect to a previously-added VPN:

1. From the Home screen, press System settings Wireless &
networks VPN settings.

The VPNs you have added are listed at the top of the screen.

2. Touch the desired VPN. Enter any requested information.

3. Touch Connect.

To disconnect from a VPN:

•Open the notifications panel, touch the active VPN notification, and touch

Disconnect.

You can share your phone’s data connection with a computer, allowing that
computer to access the internet by using your phone’s data stream. You can
share your phone’s data connection with a single computer by using USB
tethering, or with up to eight computers at a time by enabling the Portable
Wi-Fi hotspot setting.

NOTE: Not all carriers support sharing your phone’s data connection. Please
check with your carrier to find out more.

9.6.1 shAre Your Phone’s dAtA connection ViA usB tethering

You can share your phone’s data connection with a single computer via the
USB port. However, you can only do this when you are not currently using the
USB port to share files.

NOTE: Some operating systems, such as Windows XP, require you to prepare
your computer before enabling USB tethering. Visit www.android.com/tether
for more information.

To tether your phone:

1. Use the USB cable that came with your phone to connect your phone to
your computer’s USB port.

2. From the Home screen, press System settings Wireless &
networks Tethering & portable hotspot.

3. Touch USB tethering to enable tethering.

Your phone will begin sharing its data connection with your computer. For
help with setting up USB tethering on your computer, please use the Help
available on the Tethering & portable hotspot settings page on your phone.

4. When you are finished, uncheck USB tethering, or simply disconnect the
USB cable.

Go to intel.com/software/android for the latest drivers.

PAge : 399.0 connections

9.6.2 shAre Your Phone’s dAtA connection As A Wi-Fi hotsPot

You can turn your phone into a Wi-Fi hotspot to let other computers and
devices use your phone’s data connection as a wireless network.

To turn your phone into a Wi-Fi hotspot:

1. System settings More... (under the Wireless & Networks section)
Tethering & portable hotspot.

2. Touch Portable Wi-Fi hotspot to enable it.

Your phone will broadcast its Wi-Fi SSID, and can be connected to like
any other wireless network.

Uncheck the Portable Wi-Fi hotspot setting to stop sharing your phone’s
data connection.

secure Your PortABle Wi-Fi hotsPot

You can secure your phone’s Wi-Fi connection, so that other devices and
computers can only use it as a Wi-Fi hotspot after entering the required
security information.

To secure your phone’s portable Wi-Fi hotspot:

1. System settings More... (under the Wireless & Networks section)
Tethering & portable hotspot.

2. Ensure that Portable Wi-Fi hotspot is checked, then touch
Configure Wi-Fi hotspot.

3. Change any desired security settings, then touch Save.

PAge : 409.0 connections

10 Accounts

3. Touch to confirm deletion.

You can keep your phone synchronized with your Google, email, and corporate
accounts, as well as synchronizing contacts with other applications.

To open the Accounts screen:

•From the Home screen, press System settings Accounts & sync.

To add an account to your phone:

1. From the Accounts screen, touch Add Account.

2. Select the type of account to add, such as a corporate account
(using Microsoft Exchange) or a Google account.

3. Follow the on-screen instructions for configuring your account
(or configure your account manually).

NOTE: The first time you open an app using accounts (such as Email,
Calendar, or Gmail) you will be prompted to add an account. The process for
adding an account within these apps is identical to that described above.

To remove an account from your phone:

1. From Accounts & sync, touch the account to remove.

2. Press Remove account.

NOTE: You can only remove your first Google account by deleting all personal
information from your phone.

To change an account’s synchronization settings:

1. From Accounts & sync, touch the account synchronization setting you want
to change.

2. In the screen that opens, check or uncheck the type of information
you want synchronized. For example, your Google account lets you
enable or disable synchronization of your Contacts, Calendar, Google Play
Books, and Gmail.

NOTE: Previously synchronized data remains on your phone until you
manually delete it.

To turn background data on or off:

•From Accounts & sync, check or uncheck Background data.

NOTE: Turn this option off to extend battery life and lower data usage. Most
background transmissions, such as receiving Gmail messages and keeping
track of Calendar events will be stopped.

To turn automatic synchronization on or off:

•From Accounts & sync, check or uncheck Auto-sync.

NOTE: If this option is turned off, accounts and applications must be
synchronized manually.

To manually synchronize an account:

1. From Accounts & sync, touch the account to sync.

2. Touch the type of data to sync.

TIP: You can sync all types of data for the account by pressing

Sync now.

PAge : 4110.0 Accounts

11 eMAil

Use the Email app to access your web-based email (such as Yahoo or Hotmail)
and your corporate accounts (using Microsoft Exchange). The screen shots in
this chapter show a Gmail account set up using the Email app.

NOTE: Before using the Email app, first set up your accounts as
described below.

To use the Email app:

•Touch .

Your inbox displays, displaying new messages at the top and unread
messages bolded.

NOTE: If you have set up multiple email accounts, you will be able to
view one account’s inbox or a combined inbox with all your emails from all
accounts. This is described under Working with the Accounts screen.

TIP: To work with multiple messages in your inbox, touch the checkbox next to
each message you want to work with, and then touch Mark unread, Add star,
or Delete.

To add a new account:

If you’re launching the Email app for the first time, the Email Account Wizard
will open, and guide you through adding an account.

1. Enter your email address and password.

2. Touch Next, then wait for the Email app to connect with your mail provider.

3. Enter a display name (the name displayed to anyone to whom you send a
message.) You can also enter an optional account name, which will display
in the Email app’s list of accounts.

4. Touch Done to add the account.

NOTE: You can add another account at any time by pressing

Add Account in the Email app’s Accounts Screen.

To view an account’s folders:

1. Touch to view a list of the account’s folders.

2. Touch a folder to open it.

To check for new messages:

•Touch .

TIP: Synchronized accounts refresh automatically.

PAge : 4211.0 eMAil

To read a message:

•Touch a message to open it.

The following actions are available while working with a message.

To star a message

To open previous or
next message

To send a message:

1. Touch

2. Enter the recipient, subject, and message text.

3. Touch to send the message, press Save draft to save it as a
draft, or press Discard to discard unsaved drafts.

.

Touch

Touch

.

or at the bottom of the screen.

To open or save an
attachment

To display images Touch Show pictures to display images within

To reply

To forward

To delete

To mark a
message unread

Touch View or Save to open or save an attachment.

a message.

Touch
Reply all to reply to all recipients.

Touch

Touch

NOTE: Some accounts let you recover deleted
messages from a Trash folder.

Press

to reply to the sender or touch

Forward.

.

Mark as unread.

TIP: Add an attachment (such as a picture) by pressing Attach file
and selecting an attachment.

TIP: Add a Cc or Bcc recipient by pressing Add Cc/Bcc.

PAge : 4311.0 eMAil

11.1 Working With Accounts

If you have more than one Email account, you can switch between inboxes
using the Accounts screen.

NOTE: Only folders containing messages are displayed.

11.1.1 Account settings

NOTE: Adding and removing accounts is described in Accounts.

To open the Accounts screen:

•Press Accounts.

Unread messages

Read messages

Default email address

To change an account’s settings:

• From the Accounts screen, touch whose settings you want to change, then

touch Settings.

Account settings

You can change any of the following account settings.

Account name

Your name

Signature

Quick
responses

Inbox check
frequency

Default account

Enter your account’s account name.

Enter the name people see when you send a message from
this account.

Enter the signature to append to messages sent from this
account.

Edit text that you frequently insert when composing
emails.

Select how often the Email app checks this account for
new messages.

Select the default email account.

NOTE: The default email account is used by default
whenever you send an email without specifying which
account to send it from, such as when you click on a
contact’s email address.

To open an inbox:

• Touch an account to open that account’s inbox, or touch Combined View to
view all of your accounts’ messages in one inbox.

TIP: When working in the combined inbox, different account’s messages are
marked with colored bars.

TIP: Touch Starred or Drafts to view starred and draft messages from all of
your accounts.

To display an account’s folders:

•Touch next to an account to display an account’s folders, and then

touch a folder to open it.

Email
notifications

Choose ringtone

Vibrate

Incoming
and Outgoing
settings

Receive a notification whenever a new email arrives in this
account’s inbox.

Select the ringtone for new email notifications.
TIP: Select the ringtone Silent to turn off email ringtones.

Select to have the phone vibrate when you receive a new
message.

Configure the server settings for this account.

PAge : 4411.0 eMAil

12 cAlendAr

The Calendar app lets you create and manage events, meetings and
appointments. By default, your Calendar app automatically synchronizes with
any Google or Microsoft Exchange accounts you’ve added to your phone.

NOTE: See Accounts for information on how to add accounts to your phone,
and on how to configure the synchronization of existing accounts.

To use the Calendar app:

•Touch , then touch .

The Calendar app opens, displaying your events from all of your
synchronized accounts.

12.1 VieWing Your eVents

The Calendar has four views:

•Agenda: Lists an agenda of your events in chronological order.

• Day: Displays a calendar view of one day, with a red line indicating the

current time.

•Week: Displays a calendar view of one week.

• Month: Displays a calendar view of one month, with scheduled times marked

with a vertical colored bar.

TIP: Touch to see a day’s events.

NOTE: All-day and multiday events display at the top of the agenda, day,

and week views.

To change the calendar view:

• Press and select a view option, or touch Today to return to

today’s events.

TIP: Events from each account display in a different color.

TIP: Slide up and down to move backwards and forwards.

NOTE: The Calendar app synchronizes events from the previous month

through one year in the future.

PAge : 4512.0 cAlendAr

To view an event’s details:

•Touch an event to view its details.

The following actions are available while viewing an event’s details.

12.2 storing & disPlAYing cAlendArs

For each of your synchronized calendar accounts, you can set whether the
calendars are stored on the phone and whether they are visible.

To respond to an invitation Touch the drop-down menu below Attending,

then touch Snooze all or Dismiss all.

To add reminders

To remove reminders Touch X

To change a reminder Touch Reminder and choose when you want to

To edit an event Press

To delete an event Press

To create an event:

1. In any of the calendar views, press

ALTERNATE: In Day, Week, or Month view, touch and hold a spot on the
calendar, then touch New event.

2. Specify the event name and time.

Enter any details, such as guest emails to invite to the event or a
reminder you want to set. View additional details by pressing

Show Extra Options.

3. Touch Done.

NOTE: If you have more than one calendar, you can choose the calendar to
which to add the event.

TIP: You can credit, edit, and delete events by touching and holding an event
in the calendar view.

Touch

be reminded.

or under Reminder.

Edit Event.

Delete Event.

More New event.

NOTE: For information on adding and synchronizing accounts, see Accounts.

To specify whether calendars are stored and displayed:

1. Press Calendars to display.

2. Check the calendar you wish to display.

12.3 chAnging cAlendAr settings

To change calendar settings:

•Press Settings General settings.

You can change any of the following settings:

Hide declined
events

Show week
number

Week starts on

Use home
time zone

Home time zone Specify the time zone to use for Use home time zone.

Clear search
history

Notifications

Choose ringtone

Don’t show events which you have declined to attend.

Display the week of the year for the week shown.

Select which day starts the week.

When travelling, continue to show events in your home
time zone rather than the local time zone.

Remove all the searches you’ve performed.

Toggle off/on the options that follow below.

Select the ringtone for new event notifications.

TIP: Select the ringtone Silent to turn off event
ringtones.

Vibrate

Pop-up notification

Default reminder
time

Select to have the phone vibrate when you receive a new
event notification.

Toggle pop-up notifications off/on.

Select a default time to be reminded for events.

PAge : 4612.0 cAlendAr

13 gMAil

You can create a Gmail account for your phone, or sync your phone with your
existing Gmail account.

NOTE: Before using the Gmail app, first set up your accounts as described in
Accounts.

To use the Gmail app:

•Touch , then touch .

Your Gmail inbox displays.

To view account folders:

• Touch the name of the currently-opened folder (in the upper left corner of
the screen), then touch a folder to open it.

To read a message:

•Touch a conversation.

TIP: To display older messages, touch x read messages at the top
of the screen.

The following actions are available while working with a message.

To view or save an
attachment

To display images Touch Show pictures to display images within the text

Touch View or Save to open or save an attachment.

of a message.

NOTE: If you have multiple Gmail accounts, touch the top-left corner (with
the name of the Gmail account) to switch to another account.

To reply

To forward

To delete Touch Delete.

To mark a message
unread

To star a message

To open next or
previous message

To send a message

Touch
select Reply all.

Touch

NOTE: Deleted conversations are placed under the
Trash label, and are automatically deleted after thirty
days.

Press

Touch

Touch

and then select Forward.

.

to reply to the sender, touch and then

Mark unread.

or at the bottom of the screen.

PAge : 4713.0 gMAil

1. From the inbox, touch .

2. Enter the recipient, subject, and message text.

3. Touch to send the message.

TIP: Press Save draft to save the draft. Touch to discard a draft.

TIP: Add an attachment (such as a picture) to a message by pressing

Attach a file and selecting an attachment.

TIP: Add a Cc or Bcc recipient by pressing Add Cc/Bcc.

13.1 gMAil settings

To open Gmail settings

1. From your Inbox, press More Settings.

2. Touch General preferences to set Gmail settings or touch an account to

configure that account.

PAge : 4813.0 gMAil

14 other Phone Functions

Your phone has several other functions, including downloads, navigation, and
automatic updates.

14.1 uPdAting soFtWAre

As updated versions of your phone’s software become available, you can
download them directly onto your phone.

To check for and install updates:

1. Press System settings About Phone.

2. Touch System updates and then touch Check for Updates.

3. If updated software is available, touch Download and Install. You can

monitor the download in the Notifications Panel.

4. When the update is finished downloading, touch Agree to install the new

software.

NOTE: Updates may be downloaded to your computer and transferred to your
phone via USB. Visit Xolo Care website for more information.
(link to http://www.xolo.in/xolocare/xolo-support).

To delete a downloaded item:

•Touch the checkbox next to an item to select it, then touch .

TIP: You can uncheck the selected checkboxes.

14.3 MAnAging APPlicAtions

The Manage Applications screen lets you see and manage your installed
applications by uninstalling an application, changing where an application is
stored, and more.

14.2 doWnloAds

You can use the Downloads application to view, open, or delete your
downloaded items.

NOTE: All downloaded items are stored on your phone’s device memory,
under the Download directory. You can view and copy items from this folder
by connecting your phone to your computer, as described in Transfer Files
between your Phone and Computer.

To use the Downloads app:

1. Touch , then touch .

2. Touch an item to open it.

NOTE: You can touch a header (such as “Today” or “Last month”) to expand
or conceal all downloaded items under that header.

To manage applications:

1. From the Home screen, press , then touch Manage apps.

2. Touch the tabs at the top of the screen to select which list of apps to

display (apps which you downloaded onto your phone, apps which can be
run on your USB storage, apps which are currently running, or all apps.)

NOTE: Apps currently installed on your USB storage are marked with
a checkmark.

3. Touch an app to display its storage usage, software version, and what

actions it is permitted to perform.

PAge : 4914.0 other Phone Functions

To stop an application:

1. From the Apps screen, touch the Downloaded tab to view all applications
you have downloaded.

2. Touch the application you want to stop.

3. Touch Force stop.

Important. Forcibly stopping an application may cause temporary errors on your
phone, and require you to restart your phone to restore full functionality.

To uninstall an application:

1. From the Apps screen, touch the Downloaded tab to view all downloaded
applications.

2. Touch the application you want to uninstall.

3. Touch Uninstall, then touch OK to confirm.

14.3.1 chAnging Where An APP is stored

Apps can either be stored in the phone’s device memory or on the phone’s
USB storage. Since your phone’s device memory contains your private
information, it is tightly guarded by your phone’s operating system, and you
cannot directly access it when you connect your computer to your phone.
Storage space on your phone’s device memory is also very limited. You may
therefore wish to move an application from the phone’s device memory to the
USB storage.

14.4 clock

The Clock app displays the time and allows you to set alarms.

To open the Clock app:

•Touch , then touch .

To change where an app is stored:

1. From the Manage Applications screen, touch USB Storage to view all
applications currently, or potentially, installed on your phone’s USB
storage.

2. Touch the application whose location you want to change.

3. Touch Move to USB Storage to move the app from device memory to your
USB storage,
or touch Move to phone to move the app back to device memory.

To add an alarm:

1. Touch in the middle of the clock screen.

2. Touch Add alarm.

3. Set the alarm time.

4. Touch Set.

5. Customize any additional alarm settings, such as ringtone or repeat.

6. Touch OK.

To turn an alarm on and off:

1. Touch in the middle of the clock screen.

2. Touch the bar in front of the alarm to turn it on or off.

PAge : 5014.0 other Phone Functions

14.5 cAlculAtor

14.6 gloBAl Positioning sYsteM (gPs)

The calculator app lets you use your phone as a calculator.

To use the calculator app

•Touch , then touch .

You can use the touch screen to enter numbers, perform operations, and clear
the screen, just as you would on a basic calculator.

GPS is a satellite navigation system that provides incredibly accurate location
information. Receivers pull down information from an array of satellites to
calculate the user’s three-dimensional position. GPS technology can be found
in many devices, from phones and wristwatches, to ships and airplanes, to
ATMs and pet collars.

NOTE: The Google Maps and Google Nav apps are GPS-enabled. You can find
more apps that use GPS in the Play Store.

To enable GPS:

•From the Home screen, press System settings Location &
security touch Use GPS satellites.

TIP: Slide the screen to the left to see more advanced functions, such as pi,
sin, log, square root, and left and right parentheses.

PAge : 5114.0 other Phone Functions

14.6.1 MAPs

14.6.2 nAV

Google Maps lets you find any location using your phone.

To use Google Maps

1. Touch in the App Launcher.

2. Enter an address, a city, a business name, or a type of establishment in
the search box.

3. Touch or touch a suggested location.

Google Nav turns your phone into a GPS navigation device.

To use Google Nav

1. Touch in the App Launcher.

2. Enter an address.

3. Touch .

TIP: Select a contact or starred place to quickly navigate to a favorite location.

TIP: You can get directions or a street view for a location by touching the

location on the map and then choosing Directions or press

Street view.

PAge : 5214.0 other Phone Functions

15 chAnging Phone settings

Touch More... to access the following options.

The settings window displays all of the settings that affect how your phone
looks and works.

To open the settings window:

•From the Home screen, press System settings.

15.1 Wireless & netWorks

The Wireless & networks section configures your phone’s connections, such
as Wi-Fi and Bluetooth wireless technology. Support for Wi-Fi Direct lets you
connect directly to nearby peer devices over Wi-Fi, for more reliable, higher­speed communication. No internet connection or tethering is needed. Through
third-party apps, you can connect to compatible devices to take advantage
of new features such as instant sharing of files, photos, or other media;
streaming video or audio from another device; or connecting to compatible
printers or other devices.

Wi-Fi

Advanced Wi-Fi From Settings, touch Wi-Fi

Turn on Wi-Fi and configure any desired settings
under Advanced Wi-Fi.

For information on using Wi-Fi, see Using Wi-Fi.

press select

Advanced.

• Network notification: Receive a notification when an

open Wi-Fi network becomes available.

•Keep Wi-Fi on during sleep: Choose when to keep

Wi-Fi turned on.

•MAC address: Displays your current MAC address.

•IP address: Displays your current IP address.

Airplane mode

VPN

Tethering & portable
hotspot

NFC

Android Beam

Disable all wireless connections, including Bluetooth
wireless technology and 3G.

Activating airplane mode greys out some other
settings.

Configure your Virtual Private Network.

Configure your phone for tethering or for use as a
portable hotspot with the following settings.

•USB tethering: Share your phone’s mobile data

network connection with your computer via a USB
connection.

•Portable Wi-Fi hotspot: Share your phone’s mobile

data network connection as a portable Wi-Fi
hotspot.

•Bluetooth tethering: Share your phone’s mobile data

network connection via a Bluetooth connection.

Touch to enable Near Field Communications, which
allows you to exchange information with other nearby
smart phones and similar devices.

Allows you to transmit app content via NFC.

Bluetooth

Data usage Turn Mobile data on to see your phone’s data

Turn on Bluetooth wireless technology. To see available
devices, touch Bluetooth. From this Bluetooth screen,
press [Menu key] for options: Rename phone, Visibility
timeout, and Show received files.

For more information on pairing your phone with a
Bluetooth wireless technology-enabled product, see
Wireless Bluetooth Connection.

usage. You can also turn on Set mobile data limit.

PAge : 5315.0 chAnging Phone settings

Mobile networks

Configure your mobile data network using the
following settings.

•Data enabled: Clear this checkbox to prevent your

phone from transmitting data on any mobile
network. This is useful when you’re traveling
and wish to avoid charges for data use on a local
carrier’s network, and can also decrease the battery
usage.

Disabling data does not prevent your phone from
transmitting data on other networks, such as Wi-Fi
or Bluetooth wireless technology-enabled products.

• Data roaming: Clear this checkbox to prevent your

phone from using other carrier’s mobile networks
when your own is unavailable.

•Access Point Names: Select from the available

access points.

•Use only 2G networks: Touch to use only 2G

networks.

•Network operators: Scan for and select a network

operator.

Vibrate on touch

Display settings configure your phone’s screen, such as its brightness or

rotation.

Brightness

Wallpaper

Auto-rotate screen

Sleep

Font size

Wireless Display settings stream your phone to a wireless display enabled

device. For more information, see Wireless Display.

Turn on to make the phone vibrate when you touch
items.

Adjust the screen’s brightness automatically, or select
the desired brightness.

For the longest battery life, use the lowest comfortable
brightness.

Select an image on your phone to display as your
phone’s wallpaper.

Check to automatically rotate the orientation of the
screen as you turn the phone sideways or upright.

Set how long a phone will idle before the phone enters
sleep mode.

For the longest battery life, use the shortest timeout.

Change the size of the text displayed on your phone.

15.2 deVice

Sound settings let you configure your phone’s sounds.

Volumes

Silent mode

Phone ringtone

Default notification

Vibrate and ring

Dial-pad touch tones

Touch sounds

Screen lock sounds

Set the volume for each sound made by your phone,
such as media or incoming calls.

Set your phone sounds to Off, Vibrate, or Mute.

Select the ringtone for a phone call.

You can also select a song as a ringtone through the
Music App. See Playing Music for more information.

Select the notification ringtone.

Turn on to make the phone also vibrate when it rings.

Turn on to hear key presses when you dial numbers.

Turn on to hear sounds when you touch items.

Turn on to hear a sound when you lock/unlock the
screen.

Video Extend Mode uses video mode while playing videos.

Storage displays the usage of internal storage and USB storage.

Erase USB storage permanently erases everything on your phone’s USB

storage.

Battery displays the battery’s current charge, along with the battery usage of
applications.

Apps launches Manage apps.

PAge : 5415.0 chAnging Phone settings

15.3 PersonAl

Accounts & sync

Location services

Security

Language & input Touch Language to choose a new language from

Add, remove, and manage your accounts (including
Google and Microsoft Exchange accounts.) For
more information on working with accounts and
synchronizing data, see Accounts.

Toggle off/on GPS and search features that use your
current location.

Secure your phone with a Double-tap, Face Unlock,
Pattern, PIN, or password.

See Securing your phone for more information.

•Set up SIM card lock: Require a PIN each time it is

powered on.

•Make passwords visible: Turn on to briefly display

each character of your password.

Otherwise, only asterisks display.

menu.

•Spelling correction: Toggle off/on.

•Personal dictionaries: Display the user dictionaries

used to identify words you type.

Touch the red X next to a word to delete it. Touch
a word to edit it. Touch the plus sign to add a new
word.

•Keyboard & Input Method: Display the onscreen

keyboards available on your phone. Touch the
sliders on the right to configure a keyboard.

For more information, see Onscreen Keyboard
Basics.

•Voice Search: Change Language, alter your Safe

Search setting, and block offensive results.

•Text-to-speech output: Change the text-to-speech

engine, adjust the speed at which text is spoken,
and listen to an example.

•Pointer speed: Adjust the speed of any mouse or

track pad that is connected to or controlled by your
phone.

Backup & reset

Use this setting to manage your personal information.

•Back up my data: Back up certain personal data to

Google servers. If you replace your phone, you can
restore the data you’ve backed up.

The following data can be backed up and restored:
Wi-Fi passwords, Browser bookmarks, a list of the
applications you’ve installed, the words you’ve
added to the user dictionary, and most of your
configured settings. Some third-party applications
may also take advantage of this feature.

Unchecking this option stops backing up your data
and deletes any existing backups.

•Backup account: Set an account as your backup

account.

•Automatic restore: Restore your settings and other

data when you reinstall an application, using your
current Google account.

•Factory data reset: Erase all of your personal

data from internal phone storage. Resetting the
phone does not erase any software updates you’ve
downloaded.

You can also erase data downloaded to USB
storage.

After resetting your phone, you’ll be returned to the
Google wizard when you next restart your phone.

PAge : 5515.0 chAnging Phone settings

15.4 sYsteM

Date & time

Accessibility

The Date & time settings screen configures how the
date and time are displayed on your phone. You can
also use this screen to manually enter the date and
time, rather than obtaining the current time from the
mobile network.

•Automatic date & time: Uncheck to set the date and

time on the phone manually, rather than obtaining
the current time from the mobile network.

•Automatic time zone: Uncheck to set the time zone

on the phone manually, rather than obtaining the
current time zone from the mobile network.

•Set date/Set time/Select time zone: Manually set the

phone’s date, time zone, and time. This setting is
only available if the Automatic setting, above, is
unchecked.

•Use 24-hour format: Display the time using 24-hour

time format—for example, display 13:00 rather
than 1:00 PM.

•Select date format: Select the date format.

Toggle off/on large text, using the power button to end
calls, and auto-rotate screen. Configure the length of
the touch & hold delay, and install web scripts from
Google that make web content more accessible.

Sensor calibration

About phone

Use to calibrate your phone’s gyroscope and compass.

The About Phone settings screen displays information
about your phone.

•System updates: Check for Android system software

updates.

•Update from USB storage: Check for updates on

your USB storage.

•Update from OTA: Check for updates over the air.

•Status: Touch to open the Status screen.

•Legal information: Display legal information about

the software included with your phone.

PAge : 5615.0 chAnging Phone settings

16 trouBleshooting

•Make sure the phone is fully charged.

Use the following tips to troubleshoot any issues on your phone.

Outgoing calls are not connected:

•Ensure that you have touched to dial the number.

•Ensure that you’re connected to the correct cellular network.

•Ensure that you haven’t turned on outgoing call barring

(under Settings Call Settings).

Incoming calls are not connected:

•Ensure that your device is turned on.

•Ensure that you’re connected to the correct cellular network.

•Ensure that you haven’t turned on incoming call barring

(under Settings Call Settings).

Others cannot hear you speaking on a call:

•Ensure that you are not covering the built-in microphone.

•Ensure that the microphone is close to your mouth.

•If you’re using a headset, make sure that it is properly connected.

•Try turning the phone off, and then turning it back on.

•If the above doesn’t work, press and hold power button for 10 seconds until

the phone turns off. Then release the power button, and then turn the phone
back on.

Audio quality is poor:

•Ensure that you are not blocking the device’s internal antenna.

•When you are in an area with weak signals or poor reception, you may have

to move to another area for better reception.

When dialling from contacts, the call is not connected:

•Ensure that the correct number is stored in the contact list.

•Re-enter and save the number if necessary.

The device beeps and the battery icon flashes:

•Your battery is low. Recharge or replace the battery to continue using the

device.

Phone doesn’t respond:

Notice

The information contained herein is subject to change without notice. All statements, information and recommendations
contained herein do not constitute a warranty of any kind, either expressed or implied. Please review this product guide
thoroughly, with particular attention paid to any safety sections, to make sure that you use your phone safely.

Copyright © 2011-2012 Intel Corporation. All rights reserved.
This publication is protected by copyright. No part of the publication may be used, reproduced, or translated, in any form,

without the prior written consent of Intel Corporation.
Intel, Intel Atom, Intel Inside, and the Intel Inside logo are trademarks of Intel Corporation in the U.S. and/or other

countries.
doubleTwist is a trademark of doubleTwist Corp.
Google, Gmail, Google Maps, YouTube, Google Calendar, Android, and Play Store are trademarks of Google, Inc. Use of

these trademarks is subject to Google’s permissions.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
* Other names and brands may be claimed as the property of others.

For more information, see the User Guide at www.xolo.in.

PAge : 5716.0 trouBleshooting

17 sAFetY, regulAtorY & legAl inForMAtion

SAFETY AND OPERATIONAL GUIDELINES

IMPORTANT: Please review and adhere to these simple guidelines. Failure
to do so may be dangerous or illegal. All statements, information and
recommendations contained herein do not constitute a warranty of any kind,
either expressed or implied. The information contained herein is subject
to change without notice. Please read the complete user guide for further
information.

•Alwayscomplywithalllocallegalrequirementsorrestrictionswhenusing

the phone, for example, in airplanes, gas or petrol stations, in hospitals, or
while driving.

•Elementsofthephonearemadeofglass,andmaybreakorbecome

scratched if dropped or used improperly. You may be able to reduce the
chances of any such harm by utilizing a case for your phone.

•Aswithanyelectronicdevice,pleasekeepyourphoneawayfromanywater

including, for example, rain, wash basins or toilets.

•Donotattempttorepairormodifyyourphoneyourself.Thisincludesany

access to or attempted replacement of the battery. Any attempt to do so will
invalidate your warranty and regulatory approvals.

•YourmobilephonemaybeequippedwithGlobalPositioningSystem(GPS)

or Assisted GPS (AGPS) technology, which may be used to determine the
approximate location of the mobile phone. When connected to a wireless
network, the phone may transmit location-based information including to
third-party application providers. Please read your using manual and check
the settings of any installed applications to ensure that you manage these
location based services in accordance with your privacy preferences.

•Mobilephonescaninterferewiththefunctioningofmedicaldevicessuch

as hearing aids or pacemakers. Keep at least 20 cm (9 inches) between the
phone and pacemaker. When using the mobile phone hold it to the ear which
is furthest away from the pacemaker. For more information, consult your
doctor.

•Alwayskeepthephoneandaccessoriesoutofreachofsmallchildren.Small

parts such as the SIM card and SIM card eject tool can be dismantled and
swallowed by small children.

•Keepthephoneawayfromelectromagneticdatacarrierssuchascredit

cards, disk drives, etc. Information stored on them could be lost.

•Permanenthearinglossmayoccurifyouuseearphonesorheadphonesat

high volume. You can adapt over time to a higher volume, which may sound
normal but can be damaging to your hearing. Set your volume to a safe level.
If you experience discomfort or buzzing in your ears, reduce the volume or
discontinue use of your earphones or headphones.

•Ringtones,infotonesandhandsfreetalkingarereproducedthroughthe

loudspeaker. Do not hold the phone to the ear when it rings or when you have
switched on the handsfree function. Otherwise you risk serious permanent
damage to your hearing.

•Pleaseuseonlythepowersupplythatwassuppliedwithyourphone.Failure

to do so may damage the phone. The power supply must be plugged into an
easily accessible AC mains power socket when charging the battery. The only
way to turn off the charging device after charging the battery is to unplug it.

•Youmustnotopenthebatteryorbatterycoverunderanycircumstances.

All other changes to this device are strictly prohibited and will invalidate the
warranty and regulatory approvals.

•Thephonemaycauseinterferenceinthevicinityoftelevisionsets,radios,

computers and other electronic components.

•Disposeofunwantedbatteriesandphonesinaccordancewithlocallaw.

•Improperuseofthedevicewillinvalidatethewarranty!Thesesafety

instructions also apply to original accessories.

•Donotstorethephoneoranyofitsaccessoriesonornearanautomotiveair

bag, or air bag deployment area.

•Somepeoplemaybesusceptibletoblackouts,seizuresordebilitating

headaches when exposed to bright, flashing light such as, for example,
when playing video games or watching other video content on the device. If
you have experienced such medical issues in the past, please consult your
physician before engaging in such activity on this device.

•Pleasetakecarenottouseyourdeviceinpotentiallyexplosiveenvironments

such as, for example, fueling stations, fueling areas, fuel or chemical storage
facilities, or areas where the air may contain chemical or dust particles such
as grain particles or metal powders.

•Therepetitivemotionofcertainactions,suchaspressingkeysorother

repetitive finger motions, may cause discomfort in your hands, wrists, arms,
shoulders, neck and other parts of your body. If you experience any such

discomfort, please discontinue such actions until you have had an opportunity
to consult with your physician.

•Thisphoneincludesaradiotransmitterandreceivertotransmitandreceive,

respectively, electromagnetic energy operating at various radio frequencies
(RF energy). The device is designed to operate within local regulatory
requirements concerning the exposure of this RF energy to human beings,
referred to as the Specific Absorption Rate (SAR) guidelines (see below).
Nonetheless, however you use your phone, you should keep the phone 15mm
away from your body to limit your exposure to RF energy.

•ConnectonlytoUSBinterfaceswithUSB2.0versionorhigher.

•NOTE:Theoperatingtemperatureforthisdeviceis0Cto45C;ensurethe

operating temperature for the adapter is not higher than 40C.

•Whenusingawirelesshands-freesystem(headphoneorheadset),please

use a device with a low-power Bluetooth emitter.

•Pleasetrytolimitthelengthofyourcallsorsendatextmessageinstead.

This is particularly relevant to children, adolescents, and those who are or
may be pregnant.

•Pleaseusethedevicewhenthesignalqualityisgood.

Band/Mode Position

GSM 900 Head 0.571

Body 0.619

GSM 1800 Head 0.316

Body 0.421

WLAN

2.4GHz

Head 0.880

Body 0.225

1 gram

SAR W/kg

1 gram

SAR Limit

1.6 W/kg

CERTIFICATION AND COMPLIANCE

This device has been tested and determined to meet the requirements
necessary for compliance with the following regulatory certification standards:

•IMPORTANT:Theforegoingcerticationswereobtainedbasedontestingof

the phone as provided in the factory packaging. Any changes or modifications
to the product may render the electromagnetic compliance (EMC) and
wireless compliance void, and may negate your ability to legally operate the
product and invalidate your warranty.

LOCAL RESTRICTION OF 802.11A, 802.11B, AND 802.11G RADIO USAGE

Caution: Due to the fact that the frequencies used by 802.11a, 802.11b,

802.11g and 802.11n wireless LAN devices may not yet be harmonized in all
countries, 802.11a, 802.11b, 802.11g and 802.11n products are designed
for use only in specific countries, and are not allowed to be operated in
countries other than those of designated use. As a user of these products, you
are responsible for ensuring that the products are used only in the countries
for which they were intended and for verifying that they are configured with
the correct selection of frequency and channel for the country of use. Any
deviation from permissible settings and restrictions in the country of use
could be an infringement of national law and may be punished as such. Xolo
is intended for use in India.

USA—FEDERAL COMMUNICATIONS COMMISSION (FCC)

•ThisdevicecomplieswithPart15oftheFCCRules.Operationofthedevice

is subject to the following two conditions:

– This device may not cause harmful interference.

– This device must accept any interference that may cause undesired
operation.

•InterferenceStatement

This wireless device has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential area. This wireless device generates, uses, and can radiate
radio frequency energy. If the wireless device is not used in accordance with
the instructions, the wireless device may cause harmful interference to radio
communications. There is no guarantee, however, that such interference will

PAge : 591.0 getting started

not occur in a particular situation. If this wireless device does cause harmful
interference to radio or television reception (which can be determined by
turning the equipment off and on), the user is encouraged to try to correct the
interference by taking one or more of the following measures:

– Reorient or relocate the receiving antenna of the equipment experiencing
the interference.

– Increase the distance between the wireless device and the equipment
experiencing the interference.

– Connect the computer with the wireless device to an outlet on a circuit
different from that to which the equipment experiencing the interference is
connected.

– Consult the dealer or an experienced radio/TV technician for help.

NOTE: The wireless device must be used in strict accordance with the
manufacturer’s instructions as described in the user documentation that
comes with the product. Any other use will violate FCC Part 15 regulations.

Operation in the 5.15 to 5.25 GHz frequency range is restricted to indoor use
only. The FCC requires the Wi-Fi to be used indoors for the frequency range

5.15 to 5.25 GHz to reduce the potential for harmful interference to co-

channel Mobile Satellite systems. High power radars are allocated as primary
users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and /or damage the Wi-Fi device.

EUROPEAN UNION REGULATORY CONFORMANCE

The equipment complies with the RF Exposure Requirement 1999/519/EC,
Council Recommendation of 12 July 1999 on the limitation of exposure of
the general public to electromagnetic fields (0–300 GHz).

This equipment meets the following conformance standards:

Safety: EN 60950-1:2006/A11:2009

EMC: EN 301 489-1V1.8.1; EN 301 489-3 V1.4.1; EN 301 489-7 V1.3.1;
EN 301 489-17 V2.1.1; EN 301 489-24 V1.4.1

Radio: EN 301 511 V9.0.2; EN 301 908-1 V5.2.1; EN 301 908-2

V3.2.1; EN 300 328 V1.7.1; EN 300 440-1 V.106.1; EN 300 440-1 V.1.4.1

The conformity assessment procedure has been followed with the involvement
of the following Notified Body:

CETECOM ICT Services GmbHEC Identification number: 0682

DISPOSAL OF THIS DEVICE

WEEE (Waste Electrical & Electronic Equipment) is applicable in the
European Union and other countries with separate collection systems. This
marking on the product, accessories or literature indicates that the product
and its electronic accessories (e.g., charger, headset, USB cable) should
not be disposed of with other household waste at the end of their working
life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types
of waste and recycle them responsibly to promote the sustainable reuse
of material resources. Household users should contact either the retailer
where they purchased this product, or their local government office, for
details of where and how they can take these items for environmentally safe
recycling. Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for disposal.

SOFTWARE NOTICE & LICENSE

This phone may include copyrighted Intel and third-party software stored
in semiconductor memories or other media. Laws in the United States and
other countries preserve for Intel and third-party software provides certain
exclusive rights in their copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any copyrighted
software contained in this product may not be modified, reverse-engineered,
decompiled, analyzed, distributed or reproduced in any manner to the extent
allowed by law without the express, written consent of the copyright owner.
The purchase of this product shall not be deemed to grant either directly or
indirectly or by implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Intel or any third-party software
provider, except for the normal, non-exclusive, royalty-free license to use this
phone that arises by operation of law in the sale of the product.

DISCLAIMER & LIMITATION OF LIABILITY

All content and services accessible through this device belong to third
parties and may be protected by copyright, patents, trademarks and/or other
intellectual property laws. The content and services are provided solely for
your personal use and not for commercial use. You may not use them without
the expressed, written permission of the content owner or the service provider.

PAge : 601.0 getting started

Unless otherwise licensed to do so, you may not alter, copy, republish,
upload, post, transmit, translate, sell, create derivatives, distribute or exploit
in any manner or medium any content or services accessible through or
displayed by this device.

THE CONTENT AND SERVICES OF THIRD PARTIES ARE PROVIDED “AS
IS”. TO THE FULLEST EXTENT PERMITTED BY LOCAL LAW, NEITHER
LAVA NOR INTEL WARRANT THE CONTENT OR SERVICES PROVIDED,
EITHER EPRESSED OR IMPLIED, FOR ANY PURPOSE. INTEL AND LAVA
EXPRESSLY DISCLAIM ANY IMPLIED WARRANTIES INCLUDING, BUT NOT
LIMITED TO, THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. INTEL AND LAVA DO NOT GUARANTEE
THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS
OF THE CONTENT OR SERVICES PROVIDED THROUGH THIS DEVICE
AND UNDER NO CIRCUMSTANCES SHALL INTEL OR LAVA BE LIABLE,
WHETHER UNDER CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING FROM,
OR IN CONNECTION WITH, THE INFORMATION CONTAINED IN, OR AS
A RESULT OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY
THIRD PARTY, EVEN IF INTEL OR LAVA HAVE BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. TO THE EXTENT SOME JURISDICTIONS
DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR THE
LIMITATION OF LEGAL RIGHTS OF THE CONSUMER, IT IS POSSIBLE
THAT THESE EXCLUSIONS AND LIMITATIONS MAY NOT APPLY IN SUCH
JURISDICTIONS.

In addition to the foregoing, please note that the content or services of third
parties may be suspended or discontinued at any time, and neither Lava
nor Intel guarantee that any content or service will remain available for any
period of time. The content and services are provided by others, and may
utilize networks and transmission equipment outside the control of Intel or
Lava. Without limiting the generality of this section, Intel and Lava expressly
disclaim any and all liability for any interruption or suspension of the content
or service provided through this device. Neither Intel nor Lava are responsible
for customer service related to the content and services of third-parties.
Any question or request for service on such content or services must be
addressed directly to the respective content and service providers. Please note

that downloading content without the permission of the content owner may
infringe the intellectual property rights of the owner. Intel and Lava expressly
disclaim any and all liability associated with the downloading of content
by the user including, for example, infringement of third-party intellectual
property rights, or any damage done to the device or other devices due to the
download of malicious content using the device.

PRIVACY POLICY

Please note that certain applications on this device may use your location to
enhance its service and offerings. Please take care to read the operational
instructions associated with such applications and, if you prefer, please
disable the location-based services associated with such applications.

A note from Lava: To provide better products and services to our customers,
and for the purpose of keeping records of our Customers strictly for internal
purposes, we have embedded an application in the handset that will
automatically send your mobile number to our server by way of an SMS when
you switch on your handset for the first time. This SMS will be chargeable as
per your operator plan. Your personal information shall be governed as per the
privacy policy of the company, which can be visited at lavamobiles.com.

Intel’s Privacy Policy can be found at:

www.intel.com/privacy

COPYRIGHT & TRADEMARK NOTICE

Copyright © 2011-2012 Intel Corporation All rights reserved. This
publication is protected by copyright. No part of the publication may be used,
reproduced, or translated, in any form, without the prior written consent of
Intel Corporation.

Intel, Intel Inside, Intel Atom, and the Intel Inside logo are trademarks of
Intel Corporation in the US and/or other countries.

“LAVA” and “XOLO” trademarks, are exclusively owned by M/s Lava
International Limited. Any imitation of the trademarks and/or the label is
illegal and is a punishable offence.

doubleTwist is a trademark of doubleTwist Corp.

Google, Google Maps, YouTube, Google Calendar, Android and Android Market
are trademarks of Google Inc.

* Other names and brands may be claimed as the property of others.

PAge : 611.0 getting started

FCC Regulations:

Changes or modifications not expressly approved by the party responsible for compliance
could void the user‘s authority to operate the equipment.

RF Exposure Information (SAR)

This mobile phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to ex ceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government.

The exposure standard for wireless mobile phones employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
for SAR are conducted using standard operating positions accepted by the FCC with the
phone transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of
the phone while operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use only the poser required to
reach the network. In general, the closer you are to a wireless base station antenna, the
lower the power output.

The highest SAR value for the model phone as reported to the FCC when tested for use at the
ear is 1.024 W/kg and when worn on the body, as described in this user guide, is 0.933 W/kg
(Body-worn measurements differ among phone models, depending upon available
accessories and FCC requirements.)

While there may be differences between the SAR levels of various phones and at various
positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: O2Z-AZ510.

For body worn operation, this phone has been tested and meets the FCC RF exposure
guidelines for use with an accessory that contains no metal and the positions the handset a
minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance
with FCC RF exposure guidelines. If you do no t use a body-worn accessory and are not
holding the phone at the ear, position the handset a minimum of 1.5 cm from your body when
the phone is switched on.

*

Tests

Addendums and corrections
Please note the corrected SAR value table. This table supersedes the values as reported on
page 59.

 ‐MaxscaleSARathead(1cmGap)1.024W/kg
 ‐MaxscaleSARatbody(1cmGap)0.933W/kg

Standalone SAR

Band Position SAR 1g (W/kg) Scaled SAR 1g

(W/kg)

GSM 850 Head 0.72 0.797

GSM1900 Head 0.446 0.51
WCDMA Band V Head 0.695 0.818
WCDMA Band II Head 0.982 1.024

WLAN 2.4G Head 0.737 0.768

WLAN 5G Head 0.448 0.48

GSM850 Hot Spot (1cm Gap) 0.694 0.757

GSM1900 Hot Spot (1cm Gap) 0.4 0.446
WCDMA Band V Hot Spot (1cm Gap) 0.73 0.834
WCDMA Band II Hot Spot (1cm Gap) 0.895 0.933

WLAN 2.4G Hot Spot (1cm Gap) 0.175 0.182

WLAN 5G Hot Spot (1cm Gap) 0.114 0.131

GSM850 Body Worn (1cm

0.694 0.757

Gap)

GSM1900 Body W orn (1cm

0.438 0.501

Gap)

WCDMA Band V Body Worn (1cm

0.73 0.834

Gap)

WCDMA Band II Body Worn (1cm

0.895 0.933

Gap)

WLAN 2.4G Body W orn (1cm

0.18 0.188

Gap)

WLAN 5G Body Worn (1cm

0.623 0.667

Gap)


