Intel® Integrated RAID Module
RMS2AF040(AXXRMS2AF040) and
RMS2AF080(AXXRMS2AF080)
Hardware User’s Guide
Intel Order Number: E93119-002
DISCLAIMER
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL(R)
ODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY
PR
INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS
PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL
ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY
OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving,
life sustaining applications. Intel may make changes to specifications and product descriptions at
any time, without notice.
Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United
and other countries.
States
*Other names and brands may be clai
Copyright © 2008-2010 by Intel Corporation. Porti
rights reserved.
ii Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
med as the property of others.
ons Copyright 2005-2010 by LSI Corporation. All
Preface
This is the primary hardware guide for the Intel® Integrated RAID Module RMS2AF040
and RMS2AF080 (also known as Intel
RMS2AF080), which can be used to manage SAS and SATA disk drives. It contains
installation instructions and specifications.
For details on configuring the storage adapters, and for an overview of the software
drivers, see the Intel
Audience
This document assumes that you have some familiarity with RAID controllers/modules
and related support devices. The people who benefit from this book are:
• Engineers who are designing an Intel
for their RAID system.
• Anyone installing an Intel
RAID system.
Organization
®
Integrated RAID Controller RMS2AF040 and
®
RAID Software User’s Guide on the Resource CD.
®
RAID Module RMS2AF040 or RMS2AF080
®
RAID Module RMS2AF040 or RMS2AF080 in their
This document includes the following chapters and appendices:
• Chapter 1 provides a general overview of the Intel
RMS2AF040 and RMS2AF080.
®
Integrated RAID Module
• Chapter 2 describes the procedures for installing and configuring the RAID module.
• Chapter 3 provides the characteristics and technical specifications for the Intel
Integrated RAID Module RMS2AF040 and RMS2AF080.
®
• Appendix A explains drive roaming and drive migration.
• Appendix B provides safety instructions to be observed during installation and
assembly.
• Appendix C provides regulatory and certification information.
Related Publication
The Intel® RAID Software User’s Guide is included on the Resource CD that shipped with
the RAID module.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide iii
iv Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Table of Contents
Preface ........................................................................................................................iii
Audience ............................................................................................................................... iii
Organization ......................................................................................................................... iii
Related Publication ............................................................................................................... iii
Overview ......................................................................................................................1
Benefits of SAS and SATA ....................................................................................................1
®
RMS2AF040 and RMS2AF080 ....................................................................................2
Intel
Protocol Support ............................................................................................................3
Operating System Support ............................................................................................3
Usability .........................................................................................................................3
Redundancy and Error Handling ...................................................................................4
SAS/SATA Features of the LSI* LSISAS2008 Processor Chip .....................................5
Online Capacity Expansion and RAID Level Migration Rules .......................................5
Intel® Integrated RAID Module RMS2AF0x0 Hardware Installation .......................7
Requirements ........................................................................................................................7
Installing the RAID Module ....................................................................................................7
Configuring the RAID Module ..............................................................................................10
Replacing a Controller, Resolving a Config Mismatch .........................................................10
Intel® Integrated RAID Module RMS2AF0x0 Characteristics ...............................11
Major Components ..............................................................................................................14
LSI* LSISAS2008 Processor Chip ...............................................................................14
Flash ROM ..................................................................................................................15
Boot Strap ROM (SEEPROM) .....................................................................................15
NVSRAM ..................................................................................................................... 15
Diagnostic Components ..............................................................................................15
SAS/SATA Connectors ................................................................................................15
Host Board Interface ....................................................................................................18
Technical Specifications ......................................................................................................20
Array Performance Features ...............................................................................................21
Fault Tolerance ............................................................................................................22
Electrical Characteristics .............................................................................................23
Thermal and Atmospheric Characteristics ...................................................................23
Safety Characteristics ..................................................................................................23
Operating Certifications .......................................................................................................23
Supported Device Technology .............................................................................................23
Support for Hard Disk Drive Devices ...........................................................................24
SAS Expander Support ...............................................................................................24
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide v
Support for Non-Hard Disk Drive Devices ...................................................................24
Enclosure Management Support .................................................................................24
RAID Functionality and Features ........................................................................................24
Hierarchy .....................................................................................................................24
SAS Bus and ID Mapping ...........................................................................................26
A. Drive Roaming and Drive Migration Install ........................................................27
Drive Roaming .....................................................................................................................27
Drive Migration ....................................................................................................................28
B. Installation/Assembly Safety Instructions .........................................................29
English ................................................................................................................................. 31
Deutsch ............................................................................................................................... 32
Français ............................................................................................................................... 33
Español ............................................................................................................................... 35
Italiano ................................................................................................................................. 36
C. Regulatory and Certification Information ..........................................................39
Product Safety and EMC Compliance .................................................................................39
vi Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
List of Figures
Figure 1. Installing the Barrel Standoff...................................................................................... 8
Figure 2. Installing Intel
Figure 3. Connecting Cable between the RAID Module and Drives/Backplane........................ 9
Figure 4. Card Layout.............................................................................................................. 11
Figure 5. RMS2AF040 Hardware Block Diagram.................................................................... 13
Figure 6. RMS2AF080 Hardware Block Diagram.................................................................... 14
Figure 7. Intel
Figure 8. SAS/SATA Interface................................................................................................. 16
Figure 9. SAS/SATA Cable..................................................................................................... 17
Figure 10. PCI Interface.......................................................................................................... 18
®
Integrated RAID Module RMS2AF0x0 SAS/SATA Connectors..................... 16
®
Integrated RAID Module RMS2AF0x0.............................................. 8
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide vii
viii Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
List of Tables
Table 1. Jumper Description ...................................................................................................12
Table 2. SAS/SATA Connector Pin-out ..................................................................................17
Table 3. Host Board Interface Connector Pin-Out ...................................................................19
Table 4. Technical Specifications ............................................................................................20
Table 5. Array Performance Features .....................................................................................21
Table 6. Fault Tolerance Features ..........................................................................................22
Table 7. RAID Physical Drive Status .......................................................................................25
Table 8. RAID Virtual Drive Status ..........................................................................................25
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide ix
x Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
1 Overview
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 is a highperformance intelligent custom board-to-board PCI Express* 2.0 compliant SAS/SATA
RAID module that offers reliability, high performance, and fault-tolerant disk subsystem
management based on the Intel
solution that meets the internal storage needs of workgroup, department, or enterprise
systems to use cost-effective SATA or high performance SAS media.
®
SAS Hardware RAID Software Stack. This is a RAID
As a second generation PCI Express* storage controller, the Intel
Module RMS2AF040 and RMS2AF080 addresses the growing demand for increased data
throughput and scalability requirements across entry level, midrange, and enterprise
server platforms.
The controller can be connected to up to four drives (RMS2AF040) or eight drives
(RMS2AF080) directly and allows the use of expanders to connect to additional drives.
For more information about the use of expanders, see the ANSI SAS Standard, version 2.0
specification.
SATA and SAS are serial, point-to-point, device interfaces that use simplified cabling,
smaller connectors, lower pin counts, and lower power requirements than parallel SCSI.
Benefits of SAS and SATA
SAS is a serial, point-to-point, enterprise-level device interface that leverages the proven
SCSI protocol set. SAS is a convergence of the advantages of SATA, SCSI, and FC, and is
the future mainstay of the enterprise and high-end workstation storage markets. SAS
offers a higher bandwidth per pin than parallel SCSI and improves signal and data
integrity.
The SAS interface uses the proven SCSI command set to ensure reliable data transfers,
while providing the connectivity and flexibility of point-to-point serial data transfers. The
serial transmission of SCSI commands eliminates clock skew challenges. The SAS
interface provides improved performance, simplified cabling, smaller connectors, lower
pin count, and lower power requirements than parallel SCSI.
®
Integrated RAID
SAS controllers leverage a common electrical and physical connection interface that is
compatible with Serial ATA technology. The SAS and SATA protocols use a thin, 7-wire
connector instead of the 68-wire SCSI cable or 40-wire ATA cable. The SAS/SATA
connector and cable are easier to manipulate, connect to smaller devices, and do not
inhibit airflow. The point-to-point SATA architecture eliminates difficulties created by the
legacy ATA master-slave architecture, while maintaining compatibility with existing ATA
firmware.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 1
Intel® RMS2AF040 and RMS2AF080
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 are intelligent
custom board-to-board PCI Express* 2.0 compliant interface RAID adapters with an
integrated LSI* LSISAS2008 Processor Chip, providing both a SAS controller and RAID
engine. With four (RMS2AF040) or eight (RMS2AF080) independent ports supporting 6Gbps and 3 Gbps SAS data transfers using four or eight individual SAS/SATA connectors,
this controller supports up to 32 enterprise-class SAS or SATA devices and 64 logical
drives. The PCI Express* connector fits into a 50 pin connector capable of performance
up to 5 Gbps per lane.
The RAID modules are designed to fit the following Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
• Intel
®
Server Board S5500WB
®
Server Board S5520UR
®
Server Board S5520HC / S5520HCT
®
Server Board S5500HCV
®
Workstation Board S5520SC
®
Server Board S3420GP
®
Server System SR1600UR
®
Server System SR2600UR
®
Server System SR2625UR
®
Server System SR1625UR
®
Workstation System SC5650SCWS
®
Server System SC5650HCBRP
®
Server System SR1690WB
®
Server System SR1695WB
®
Server System SR2612UR
®
Server System SR1630GP/SR1630HGP
®
Server Boards and Systems:
®
Note: Additional Intel
list, see the Compatibility section under the link for this Intel
http://www.intel.com/support/go/mo
The SAS RAID controllers support the SAS protocol as desc
Server Boards and Systems may be supported. For the most up-to-date
®
RAID Module at
therboards/server/index.htm.
ribed in the Serial Attached
SCSI Standard, Version 2.0. The controllers also support the Serial ATA II (SATA II)
protocol defined by the Serial ATA Specification, Version 1.0a and the Serial ATA II:
Extension to the Serial ATA Specification, Version 1.1. SATA II is an extension to SATA
1.0a.
2 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Protocol Support
Each port on the SAS controllers supports SAS devices, SATA II devices, or both using
SSP, SMP, STP, and SATA II as follows:
• Serial SCSI Protocol (SSP) to enable communication with other SAS devices.
• SATA II Protocol to enable communication with other SATA II devices.
• Serial Management Protocol (SMP) to share topology management information
with expanders.
• Serial Tunneling Protocol (STP) support for SATA II through expander interfaces..
Operating System Support
• Windows Server 2008* R2, Windows 7*, Windows Server 2003*, Windows Vista*
• Red Hat* Enterprise Linux 5.0
• SuSE* Linux Enterprise Server 10 and 11
• VMWare* ESX 4.0
• Solaris* 10
Usability
The operating systems supported may not be supported by your server board. Se
Tested operating system list for your server board at
http://www.intel.com/support/go/motherboards/server/index.htm.
To make sure the RAID module supports your operating system, see also the Tested
Hardware and Operating System List for the Intel
RMS2AF040 and RMS2AF080.
®
Integrated RAID Module
e the
• Small, thin cabling with up to 6.0 Gb/s serial, point-to-point data transfer rates.
• Support for non-disk devices and mixed capacity drives.
• Support for intelligent XOR RAID levels 0, 1, 5, 10, and 50.
• Dedicated or global hot spare with auto rebuild if an array drive fails.
• User-defined strip size per drive: 8, 16, 32, or 64 KB.
• Advanced array configuration and management utilities provide:
— Online Capacity Expansion (OCE) adds space to
See Appendix A: Drive Roaming and Drive Migration Install for limitations on
OCE and RAID migration.
— Online RAID level migration (upgrade of RAID mode may require OCE)
existing drive or new drive.
— Drive migration
— Drive roaming
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 3
— No reboot necessary after expansion
— Load Balancing
• Upgradeable Flash ROM interface.
• Allows for staggered spin-up, hot-plug, and lower power consumption.
• User specified rebuild rate (percent of system resources to use from 0-100%).
Caution: Exceeding 50%
controller access.
rate may cause operating system errors due to waiting for
• Background operating mode can be set for Rebuilds, Consistency Checks,
Initialization (auto restarting Consistency Check on redundant volumes), Migration,
OCE, and Patrol Read.
Redundancy and Error Handling
• SGPIO, In-band and out-band SES2 Enclosure management support.
• Drive coercion (auto-resizing to match existing disks).
• Auto-detection of failed drives with transparent rebuild. There must be disk activity
(I/O to the drive) for a missing drive to be marked as failed.
• Auto-resume on reboot of initialization or rebuild (must be enabled before virtual
disk creation).
• Smart initialization automatically checks consistency of virtual disks if there are five
or more disks in a RAID 5 array, which optimizes performance by enabling readmodify-write mode. RAID 5 arrays of only three or four drives use Peer Read mode.
• Smart Technology predicts failures of drives and electronic components.
• Patrol Read checks drives and maps bad sectors.
• Commands are retried at least four times.
• Firmware provides best effort to recognize an error and recover if possible.
• Failures are logged from controller and drive firmware, and SMART monitor.
• Failures are logged in NVRAM, viewable from OS Event Log, Intel® RAID Web
Console 2; CIM, LEDs.
• Access policy:
— RW: allow read and write I/O
— Read Only: allow read I/O only
— Blocked: deny read and write I/O
• Redundancy through:
— Configuration stored in non-volatile RAM and on the drives (COD).
— Hot-swap support.
4 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
SAS/SATA Features of the LSI* LSISAS2008 Processor Chip
See “LSI* LSISAS2008 Processor Chip” for SAS/SATA features of the LSI*
LSISAS2008 Processor Chip.
Online Capacity Expansion and RAID Level Migration Rules
• Migration must occur to the same or larger capacity configuration.
• Migration cannot occur if there is more than one virtual disk in an array.
• Migration and OCE cannot be done on Spanned Arrays (RAID 10 and 50).
• Migrations supported are RAID 1 to RAID 0, RAID 5 to RAID 0.
• With OCE, migrations supported are RAID 0 to RAID 1, RAID 0 to RAID 5, and
RAID 1 to RAID 5.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 5
6 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
2 Intel
®
RMS2AF0x0 Hardware Installation
Requirements
Integrated RAID Module
®
Integrated RAID Module RMS2AF040 and RMS2AF080, with the provided
standoffs
the RAID Module”)
Note: I
• Intel
• A host system with one available 50-pins PCI Express* 2.0 connector
• Resource CD, which contains drivers and documentation
• SAS or SATA 6.0 hard drives
• Four provided SAS/SATA cables (for cable requirements, see step 6 in “Installing
ntel Corporation strongly recommends using an uninterruptible power supply (UPS).
Installing the RAID Module
To install the RAID Module, follow these steps:
1. Turn off the power to the system, all drives, enclos
Remove the power cord(s).
2. Remove the server cover. For instructions, see
3. Insert the three barrel standoffs into the
board. To locate the matching module card slot on your server/workstation board,
see your server/workstation board documentation.
The Intel
standoff hole locations could be different (see Figure 1).
4. Attach the Intel
server/workstation board connector, and press the module card firmly to engage the
barrel standoffs installed in step 3 (see Figure 1). The Intel
RM2AF080 is shown for illustrative purpose (se
®
Server Board SR5520UR is shown for illustrative purpose. Actual
®
Integrated RAID Module RMS2AF0x0 to the matching
ures, and system components.
your server system documentation.
matching holes in the server/workstation
®
RAID Module
e Figure 2).
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 7
Figure 1. Installing the Barrel Standoff
AF003487
5. Press down gently but firmly to ensure that
the card is properly seated in the
connectors, and then insert the three pin standoffs into the barrel standoffs
respectively ( see Figure 2).
AF003489
®
Figure 2. Installing Intel
6. Connect the SAS/SATA cables from the backpla
module (see Figure 3). For information regarding co
Integrated RAID Module RMS2AF0x0
ne (or hard drives) to the RAID
nnecting the recommended
Right-angle end or Vertical end of the SAS/SATA cable to the SAS connectors of
the controlle
r, see your server/workstation board or chassis documentation. Make
sure the cables are properly connected to the controller.
Note: S
ystem throughput problems can occur if non-standard SAS cables are used.
To minimize the potential for problems:
✧ Us
e cables no longer than ten meters for SAS and one meter for SATA. It is
better to use the shortest possible cables. The cable length should be reduced
by about one foot (.33 meters) if using a backplane.
✧ Y
ou may connect one device per SATA/SAS cable either as a device or as an
expander.
8 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
✧ Route SAS cables carefully.
✧ Use only “straight”
SAS cables, not “cross-over” SAS cables. .
AF003488
Figure 3. Connecting Cable between the RAID Module and Drives/Bac kplane
7. Install the server system cover and connect
the power cords. See your server system
documentation for instructions.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 9
Configuring the RAID Module
To configure the RAID Module, follow these steps:
1. Turn on the system power and check to make
power up before or at the same time as the system.
2. During the boot, the following BIOS message appe
need to press to enter the Intel
Press <CTRL><G> to run BIOS Console 2.
This message times out after several seconds. If you miss it, you need to restart the
system.
After you press the keys to enter the
firmware takes several seconds to initialize and then display the Intel
RAID module RMS2AF040 or RMS2AF080 number and firmware version. The
numbering of the RAID module follows the PCI slot scanning order used by the
server board.
3. Follow the instructions in the Intel
Number: D29305-0xx) to configure the RAID module and to install the operating
system drivers.
®
RAID BIOS Console 2:
Intel®RAID BIOS Console 2 software, the
®
RAID Software User's Guide (Document
sure that the SAS/SATA devices
ars to state the keys that you
®
Integrated
Replacing a Controller, Resolving a Config Mismatch
To replace the RAID module, see your server system documentation for instructions to
remove and then install an add-in adapter.
If the newly installed RAID module was previously configured, a message appears during
POST, stating that there is a configuration mismatch because the configuration data in the
NVRAM differs from that in the hard drives. Use these steps to resolve the mismatch:
1. Press <Ctrl> + <G> when prompted during boot up to access the BIOS
Configuration Uti
2. Select Configure > View/Add Configuration to see
configurations.
3. Since the drives contain the correct configuration,
4. Press <Esc> and select YES to update the NVRAM.
5. Exit and reboot.
10 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
lity.
the NVRAM and drive
use configuration from the disks.
3 Intel
AF003490
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
J11
RMS2AF0x0 Characteristics
®
Integrated RAID Module
Figure 4. Card Layout
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 11
s
Table 1. Jumper Description
Jumper Description Type Comments
J1-J8 Internal SAS/SATA Port
Connectors, Ports 0-7
J9 Keyed SGPIO Connector 4-pin keyed
connector
J10 Keyed SGPIO Connector 4-pin keyed
connector
J11 Keyed I2C Connector 3-pin keyed
connector
Connection to SAS/SATA devices:
• J1 = SAS/SATA Port 0
• J2 = SAS/SATA Port 1
• J3 = SAS/SATA Port 2
• J4 = SAS/SATA Port 3
• J5 = SAS/SATA Port 4
• J6 = SAS/SATA Port 5
• J7 = SAS/SATA Port 6
• J8 = SAS/SATA Port 7
J5 - J8 (Ports 4 - 7) are only available on Intel®
RAID Module RMS2AF080
Enclosure management (SGPIO) for Ports 4-7
The connector is not available on Intel
Module RMS2AF040
Enclosure management (SGPIO) for Ports 0-3
Out-of-band enclosure management (SES2)
®
RAID
12 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Figure 5. RMS2AF040 Hardware Block Diagram
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 13
Figure 6. RMS2AF080 Hardware Block Diagram
Major Components
LSI* LSISAS2008 Processor Chip
The LSI* LSISAS2008 Processor Chip provides the following functionality:
• Intel
• Supports SSP to enable communication with other SAS devices.
• Supports SMP to communicate topology management information.
• Supports single PHY or wide ports consisting of 2, 3, or 4 PHYs within a single
• Allows addressing of multiple SATA targets through an expander if using SATA 2.0-
®
Intergrade RAID Module RMS2AF080 provides eight independent PHYs,
®
Intergrade RAID Module RMS2AF040 provides four independent PHYs,
Intel
each supporting 6Gb/s and 3Gb/s SAS data transfers per PHY.
quad port.
compliant hard disk drives.
14 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
• Allows multiple initiators to address a single target (in a fail-over configuration)
through an expander.
For more information, see http://www
Note: Some of these c
RMS2AF040 and RMS2AF080.
hip features may not be supported by Intel® Integrated RAID Module
Flash ROM
An 16-MB CFI-compliant flash ROM is used to accommodate RAID firmware and RAID
BIOS Console 2 OpROM.
Boot Strap ROM (SEEPROM)
The serial bootstrap ROM is used to configure the LSI* LSISAS2008 Processor Chip
before the server board configures the PCI Express* registers. The bootstrap ROM sets
the Phase Lock Loop (PLL) dividers, bootstrap configuration, and so on.
NVSRAM
A 32-KB NVSRAM is used to store disk and drive setup information.
.lsi.com/.
Diagnostic Components
LED Placement and Function
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 contain the
following LEDs:
• One surface-mounted heartbeat (“DS1B1: SAS_HB_LED”) LED (Green Color) to
indicate LSISAS2008 activity.
• Another surface-mounted system error (“DS1B2: SAS_FLT_LED”) LED (Amber
Color) to indicate a board error.
SAS/SATA Connectors
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 provides four and
eight internal SAS/SATA signal port connectors.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 15
Figure 7. Intel® Integrated RAID Module RMS2AF0x0 SAS/SATA Connectors
AF003491
SAS/SATA Connectors X 8
SAS/SATA Connector Pin-out
The SAS/SATA connector shown in the following figure is the standard 7-pin SATA
internal connector used by the Intel
®
Integrated RAID Module RMS2AF040 and
RMS2AF080. These pin-outs for the serial ATA connector are not compatible with the
legacy PATA connector.
Figure 8. SAS/SATA Interface
16 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Table 2. SAS/SATA Connector Pin-out
Pin # Signal Description
1 GND Ground
2 TX0+ Transmitter differential pair
3 TX0- Transmitter differential pair
4 GND Ground
5 RXD- Receiver differential pair
6 RXD+ Receiver differential pair
7 GND Ground
Figure 9. SAS/SATA Cable
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 17
Host Board Interface
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 board interfaces
with the host system through a custom board-to-board interface that implements x8 PCI
Express* lanes signaling as defined in the PCI Express Specification 2.0. This interface
also provides +3.3 V power to the board.
Figure 10. PCI Interface
18 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Table 3. Host Board Interface Connector Pin-Out
Server Connector Pin Number RAID Module Pin number Description
1 1 P3V3_AUX
2 3 RST_PWRGD_PS_R
3 5 TP_FW_SW_RAID_MODE
4 7 GND
5 9 PE0_TX_DP0
6 11 PE0_TX_DN0
7 13 GND
8 15 GND
9 17 PE0_TX_DP1
10 19 PE0_TX_DN1
11 21 GND
12 23 GND
13 25 PE0_TX_DP2
14 27 PE0_TX_DN2
15 29 GND
16 31 GND
17 33 PE0_TX_DP3
18 35 PE0_TX_DN3
19 37 GND
20 39 FM_SAS_PRSNT_R
21 41 TP_PE_WAKE_N
22 43 FM_SAS_DISABLE_N
23 45 P3V3
24 47 P3V3
25 49 P3V3
26 2 P3V3_AUX
27 4 GND
28 6 PE0_RX_DP0
29 8 PE0_RX_DN0
30 10 GND
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 19
Server Connector Pin Number RAID Module Pin
31 12 GND
32 14 PE0_RX_DP1
33 16 PE0_RX_DN1
34 18 GND
35 20 GND
36 22 PE0_RX_DP2
37 24 PE0_RX_DN2
38 26 GND
39 28 GND
40 30 PE0_RX_DP3
41 32 PE0_RX_DN3
42 34 GND
43 36 GND
44 38 CLK_100M_IOP_DP
45 40 CLK_100M_IOP_D N
number Description
46 42 GND
47 44 LED_HDD_ACT_N
48 46 P3V3
49 48 P3V3
50 50 P3V3
Technical Specifications
Table 4. Technical Specifications
Specification
Processor LSI* LSISAS2008 PCI* Express-SAS/SATA I/O Processor
Operating voltage +3.3 V
Interface to host Custom board-to-board x8 PCI Express* 2.0 compliant
®
Integrated RAID Module RMS2AF040 and
Intel
chip, 150MHz
in
terface
RMS2AF080
20 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
In
Specification
SATA bus speed Upto 6 Gbps per port, point-to-point
SAS/SATA ports 4 internal ports, 16 devices
tel® Integrated RAID Module RMS2AF040 and
RMS2AF080
Physical and virtual drive
suppo
rt
Firmware 16 MB in reflashable flash ROM
Compatible devices
Up to 64 physical drives including up to 16 physical drives in
up to 16 RAID arrays per controller.
Drives not configured as part of a RAID array can be
configu
red as “pass through” drives in Non-RAID mode.
• .5-inch and 3.5-inch SAS or SATA II drives including SSD
drives
• Non disk devices including expanders
• Can support drives of mixed capacity
Cabling Small thin cables that do not restrict airflow and Shared
ectors for multiple drives
conn
Redundant configuration 32 KB NVRAM and config-on-disk (COD)
Enclosure management In-band and out-of-band SES2; out-of-band SGPIO
Enclosure support Assumes one SEP per enclosure
Array Performance Features
Table 5. Array Performance Features
®
Integrated RAID Module RMS2AF040 and
Specification
Host data transfer rate Upto 5.0 Gigabit/sec per PCI Express* lane
Drive data transfer rate Upto 6 Gigabit/sec per lane
Maximum scatter/gather 80 elements
Maximum size of I/O requests 6.4 Mbytes in 64 Kbyte stripes
Maximum queue tags per
dr
ive
Strip size 8, 16, 32, or 64 KB
Maximum concurrent
co
mmands
Support for multiple initiators Yes
Performance Native command queuing
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 21
Intel
RMS2AF080
As many as the drive can accept
1024 - 16
tel® Integrated RAID Module RMS2AF040 and
Specification
Flexibility • Drive migration
In
• RAID level migration
• Drive Roaming
• Online Capacity Expansion - without reboot
RMS2AF080
Background services
Cache policy
Fault Tolerance
Self Monitoring Analysis and
Re
porting Technology (SMART)
support
Drive Replacement • Auto detection of failure
Specification
• Rebuild
• Consistency Check
• Migration
• OCE
• Patrol Read
• Write-through
• Normal Read
• Direct I/O
Table 6. Fault Tolerance Features
Intel® Integrated RAID Module RMS2AF040 and
RMS2AF080
• Detects up to 70% of predictable disk drive failures
• Monitors the internal performance of all motors, heads,
and drive electronics.
• Hot-plug
• Hot-swap
Drive Rebuild Using Hot Spares
• Automatic at fail
• Dedicated per Array
• Global for any array
• Auto-resume of initialization or rebuild on reboot
Error Checking and Indication
• Parity generation and checking, automatic consistency
checking
• Patrol reads
• Activity and fault LEDs
• Multiple retries
• Logs in NVRAM, event log, CIM, Smart, Intel
Web Console 2
22 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
®
RAID
Electrical Characteristics
All power is supplied to the Intel® Integrated RAID Module RMS2AF040 and
RMS2AF080 through the board-to-board connector via PCI Express* 3.3 V rails.
The supply voltages are 3.3 V ± 9 percent from PCI edge connector only. The maximum
power for the +3.3 V rail is 18 W. The +3.3 V rail is used by the 3.3 V logic circuitry and
also used to generate the other required voltage rails of +1.0 V and +1.8 V.
Thermal and Atmospheric Characteristics
The thermal and atmospheric characteristics are:
• Relative humidity range: 20% to 80% non-condensing
• Maximum dew point temperature: 32°C
• Airflow must be at least 200 linear feet per minute (SFPM) to avoid operating above
the maximum ambient temperature.
The storage and transit environment conditions are:
• Temperature range from -30°C to 80°C (dry bulb)
• Relative humidity range: 5% to 90% non-condensing
• MTBF (electrical components) number: 298,900 hours at 40°C
Safety Characteristics
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 meets or exceeds the
requirements of UL flammability rating V0. Each bare board is marked with the supplier
name or trademark, type, and UL flammability rating.
Operating Certifications
The RAID controller in this document is qualified to get Microsoft Windows* Winqual
certification (WHQL) at product launch.
Supported Device Technology
The various device technologies supported by the Intel® Integrated RAID Module
RMS2AF040 and RMS2AF080 are described in the subsections that follow.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 23
Support for Hard Disk Drive Devices
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 integrates eight
internal high-performance SAS/SATA II ports that support SAS and enterprise-class
SATA hard drives. Each port supports both SAS and SATA devices using the SAS Serial
SCSI Protocol (SSP), Serial Management Protocol (SMP), and Serial Tunneling Protocol
(STP). The SSP protocol enables communication with other SAS devices. STP allows the
SAS RAID controller to communicate with SATA devices using the SATA commands.
SAS Expander Support
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 supports LSI*
expanders, Vitesse SAS expanders, and PMC expanders that are used as a component in
Intel enclosures. Other expanders may be supported post launch, based on market
conditions and customer requirements.
Support for Non-Hard Disk Drive Devices
As SAS-based non-hard drive devices were not available when this controller was in
development, support for these devices will be determined as they become available. For
information on support for non-hard drive devices, see the Intel
Module RMS2AF040 and RMS2AF080 Tested Hardware and Operating System List.
®
Integrated RAID
Enclosure Management Support
The Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 support SES2
enclosure management in-band to expander-based backplanes and out-of-band to directconnect backplanes. These RAID Controllers also support the SGPIO enclosure
management interface.
RAID Functionality and Features
Hierarchy
The fundamental purpose of a RAID system is to present a usable data storage medium
(virtual drive) with some level of redundancy to a host operating system. The Intel®
RAID firmware is based on the concept of associating physical drives in arrays and then
creating a virtual drive from that array that includes a functional RAID level. To create a
virtual drive and present it to the host operating system, the RAID firmware typically
follows these steps:
1. One or more physical drives are selected and ass
2. One or more arrays are associated and given a RAID level. This process creates a
virtual drive and
provides an option to initialize the virtual drive.
ociated as an array.
24 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
3. The RAID firmware presents the virtual drive to the operating system.
RAID Physical Drive Status
Drive State Code Description
Table 7. RAID Physical Drive Status
Unconfigured Good Unconfigured Good The drive is functioning normally, but is not part
Online ONLN The drive is online, is part of a configured virtual
Hot Spare HOTSP A physical drive that is configured as a hot spare.
Failed FAILED A physical drive that was originally configured as
Rebuilding REBUILD A physical drive to which data is being written to
Unconfigured Bad Unconfigured Bad A physical drive on which the firmware detects
Missing Missing A physical drive that was online, but which has
Offline Offline A physical drive that is part of a virtual drive but
None None A physical drive with an unsupported flag set. An
of a
configured virtual drive and is not a hot
spare.
dr
ive, and is functioning normally.
Onlin
e or Hot Spare, but on which the firmware
detects an unrecoverable error.
restore fu
an unrecoverable error; the physical drive was
Unconfigured Good or the physical drive could
not be initialized.
be
which has invalid data as far as the RAID
configuration is concerned.
Unco
has completed the 'prepare for removal'
operation.
ll redundancy for a virtual drive.
en removed from its location.
nfigured Good or Offline physical drive that
RAID Virtual Drive Status
Table 8. RAID Virtual Drive Status
Drive State Code Description
Optimal Optimal The drive operating system is g
Degraded Degraded The dr ive operating condi
Offline Offline The drive is not available to the operating system
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 25
ured drives are online.
because one of the configured drives has failed
or is offline.
an
d is unusable.
ood. All config-
tion is not optimal
RAID Controller Drive Limitations
Only drives that comply with the SAS and SATA specification extensions are supported.
SAS Bus and ID Mapping
Devices on the SAS bus are persistently mapped based on a SAS address.
26 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Appendix A: Drive Roaming and Drive
Migration Install
Drive Roaming
Drive roaming occurs when the hard drives are changed to different ports on the same
controller. When the drives are placed on different ports, the controller detects the RAID
configuration from the configuration data on the drives.
Note: I
f you move a drive that is currently being rebuilt, the rebuild operation will restart, not
resume.
To use drive roaming, follow these steps:
1. Turn off the power to the system, all drives, enclos
Remove the power cord(s).
2. Remove the server cover. For instructions, see
3. Move the drives to different positions on the backplane to change the
your server documentation for instructions to install and remove drives.
4. Determine the target requirements.
5. Make sure the drives are inserted properly.
6. Install the server cover. For instructions, se
7. Plug in and power on the system.
The controller detects the RAID configurat
(COD).
e your server system documentation.
ion from the configuration data on the drives
ures, and system components.
your server system documentation.
targets. See
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 27
Drive Migration
Drive migration moves a configured set of hard drives from one controller to another. The
drives must remain on the same port and be reinstalled in the same order as in the original
configuration. The controller to which you migrate the drives cannot have an existing
configuration.
Note: Only comple
migrated. Drive roaming and drive migration cannot be supported at the same time.
To migrate drives, follow these steps:
1. Clear the configuration on the system
This prevents a configuration data mis
NVRAM.
2. Turn off the power to the system, all drive
Remove the power cord(s).
3. Remove the server cover. For instructions,
4. Disconnect the cables from the drives to be migrated.
5. Remove the hard drives from the first
system. For instructions to install and remove drives, see your server
documentation.
6. Connect the data cables to the hard drives in the sec
they were connected in the first system. Make sure all the cables meet
specifications.
7. Determine the drive ta
8. Make sure all cables are properly attached
installed.
te configurations can be migrated; individual virtual disks cannot be
to which you migrate the drives.
match between the hard drives and the
s, enclosures, and system components.
see your server system documentation.
system and install them into the second
ond system in the same order as
rget requirements.
and the RAID module is properly
9. Install the server cover. For instructions, see
10. Plug in and power on the system.
When you start the system, the controller de
configuration data on the drives.
28 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
your server system documentation.
tects the RAID configuration from the
Appendix B: Installation/Assembly
Safety Instructions
As you use your computer system, observe these safety guidelines:
• Do not operate your computer system with any cover(s) (such as computer covers,
bezels, filler brackets, and front-panel inserts) removed.
• To help avoid damaging your computer, be sure the voltage selection switch on the
power supply is set to match the alternating current (AC) power available at your
location.
• To help avoid possible damage to the server board, wait five seconds after turning
off the system before removing a component from the server board or disconnecting
a peripheral device from the computer.
• To help prevent electric shock, plug the computer and peripheral power cables into
properly grounded power sources. These cables are equipped with 3-prong plugs to
ensure proper grounding. Do not use adapter plugs or remove the grounding prong
from a cable. If you must use an extension cable, use a 3-wire cable with properly
grounded plugs.
• To help protect your computer system from sudden, transient increases and
decreases in electrical power, use a surge suppressor, line conditioner, or
uninterruptible power supply.
• Be sure nothing rests on your computer system's cables and that the cables are not
located where they can be stepped on or tripped over.
• Do not spill food or liquids on your computer. If the computer gets wet, consult the
documentation that came with it.
• Do not push any objects into the openings of your computer. Doing so can cause fire
or electric shock by shorting out interior components.
• Keep your computer away from radiators and heat sources. Also, do not block
cooling vents. Avoid placing loose papers underneath your computer; do not place
your computer in a closed-in wall unit or on a rug.
When working inside your computer:
• Do not attempt to service the computer system yourself, except as explained in this
guide and elsewhere in Intel documentation. Always follow installation and service
instructions closely.
• Turn off your computer and any peripherals.
• Disconnect your computer and peripherals from their power sources. Also
disconnect any telephone or telecommunications lines from the computer.
Doing so reduces the potential for personal
injury or shock.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 29
Additional safety guidelines:
• When you disconnect a cable, pull on its connector or on its strain-relief loop, not on
the cable itself. Some cables have a connector with locking tabs; if you are
disconnecting this type of cable, press in on the locking tabs before disconnect the
cable. As you pull connectors apart, keep them evenly aligned to avoid bending any
connector pins. Also, before you connect a cable, make sure both connectors are
correctly oriented and aligned.
• Handle components and cards with care. Do not touch the components or contacts
on a card. Hold a card by its edges or by its metal mounting bracket. Hold a
component such as a microprocessor chip by its edges, not by its pins.
Protecting against electrostatic discharge
• Static electricity can harm delicate components inside your computer. To prevent
static damage, discharge static electricity from your body before you touch any of
your computer's electronic components, such as the microprocessor. You can do so
by touching an unpainted metal surface, such as the metal around the card-slot
openings at the back of the computer.
• As you continue to work inside the computer, periodically touch an unpainted metal
surface to remove any static charge your body may have accumulated. In addition to
the preceding precautions, you can also take the following steps to prevent damage
from electrostatic discharge (ESD).
• When unpacking a static-sensitive component from its shipping carton, do not
remove the component from the antistatic packing material until you are ready to
install the component in your computer. Just before unwrapping the antistatic
packaging, be sure to discharge static electricity from your body.
• When transporting a sensitive component, first place it in an antistatic container or
packaging.
• Handle all sensitive components in a static-safe area. If possible, use antistatic floor
pads and workbench pads.
30 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
English
Read all caution and safety statements in this document before performing any of the
instructions. See also Intel
®
Server Boards and Server Chassis Safety Information on the
Resource CD and/or at
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
The power button on the system does not turn off system AC po w er.
To remove AC power from the system, you must unplug each AC
power cord from the wall outlet or power supply.
The power cord(s) is considered the disconnect device to the main
(AC) power. The socket outlet that the system plugs into shall be
installed near the equipment and shall be easily accessible.
SAFETY STEPS: Whenever you remove the chassis covers to
access the inside of the system, follow these steps:
1. Turn off all peripheral devices connected to the system.
2. Turn off the system by pressing the power button.
3. Unplug all AC power cords from the system or from wall
outlets.
4. Label and disconnect all cables connected to I/O connectors
or ports on the back of the system.
5. Provide some electrostatic discharge (ESD) protection by
wearing an antistatic wrist strap attached to chassis ground of
the system-any unpainted metal surface-when handling
components.
6. Do not operate the system with the chassis covers removed.
After you have completed the six SAFETY steps above, you can
remove the system covers. To do this:
1. Unlock and remove the padlock from the back of the system if
a padlock has been installed.
2. Remove and save all screws from the covers.
3. Remove the cover(s).
For proper cooling and airflow, always reinstall the chassis covers
before turning on the system. Operating the system without the
covers in place can damage system parts. To install the covers:
1. Check first to make sure you have not left loose tools or parts
inside the system.
2. Check that cables, add-in cards, and other components are
properly installed.
3. Attach the covers to the chassis with the screws removed
earlier, and tighten them firmly.
4. Insert and lock the padlock to the system to prevent
unauthorized access inside the system.
5. Connect all external cables and the AC power cord(s) to the
system.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 31
Deutsch
Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor
Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu
Intel-Serverplatinen und -Servergehäusen auf der Ressourcen-CD oder unter
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
A microprocessor and heat sink may be hot if the system has been
running. Also, there may be sharp pins and edges on some board
and chassis parts. Contact should be made with care. Consider
wearing protective gloves.
Der Wechselstrom des Systems wird durch den Ein-/Aus-Schalter
für Gleichstrom nicht ausgeschaltet. Ziehen Sie jedes
Wechselstrom-Netzkabel aus der Steckdose bzw. dem Netzgerät,
um den Stromanschluß des Systems zu unterbrechen.
Die Stromkabel sind das "Unterbrechungsgerät" zur
Hauptstromquelle. Die Steckdose, in die das System gesteckt wird,
sollte sich in der Nähe des Gerätes befinden und leicht zugänglich
sein.
SICHERHEITSMASSNAHMEN: Immer wenn Sie die
Gehäuseabdeckung abnehmen um an das Systeminnere zu
gelangen, sollten Sie folgende Schritte beachten:
1. Schalten Sie alle an Ihr System angeschlossenen
Peripheriegeräte aus.
2. Schalten Sie das System mit dem Hauptschalter aus.
3. Ziehen Sie den Stromanschlußstecker Ihres Systems aus der
Steckdose.
4. Auf der Rückseite des Systems beschriften und ziehen Sie
alle Anschlußkabel von den I/O Anschlüssen oder Ports ab.
5. Tragen Sie ein geerdetes Antistatik Gelenkband, um
elektrostatische Ladungen (ESD) über blanke Metallstellen
bei der Handhabung der Komponenten zu vermeiden.
6. Schalten Sie das System niemals ohne ordnungsgemäß
montiertes Gehäuse ein.
32 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
SICHERHEITSMASSNAHMEN: Immer wenn Sie die
Gehäuseabdeckung abnehmen um an das Systeminnere zu
gelangen, sollten Sie folgende Schritte beachten:
1. Schalten Sie alle an Ihr System angeschlossenen
Peripheriegeräte aus.
2. Schalten Sie das System mit dem Hauptschalter aus.
3. Ziehen Sie den Stromanschlußstecker Ihres Systems aus der
Steckdose.
4. Auf der Rückseite des Systems beschriften und ziehen Sie
alle Anschlußkabel von den I/O Anschlüssen oder Ports ab.
5. Tragen Sie ein geerdetes Antistatik Gelenkband, um
elektrostatische Ladungen (ESD) über blanke Metallstellen
bei der Handhabung der Komponenten zu vermeiden.
6. Schalten Sie das System niemals ohne ordnungsgemäß
montiertes Gehäuse ein.
Zur ordnungsgemäßen Kühlung und Lüftung muß die
Gehäuseabdeckung immer wieder vor dem Einschalten installiert
werden. Ein Betrieb des Systems ohne angebrachte Abdeckung
kann Ihrem System oder Te ile darin beschädigen. Um die
Abdeckung wieder anzubringen:
1. Vergewissern Sie sich, daß Sie keine Werkzeuge oder Teile
im Innern des Systems zurückgelassen haben.
2. Überprüfen Sie alle Kabel, Zusatzkarten und andere
Komponenten auf ordnungsgemäßen Sitz und Installation.
3. Bringen Sie die Abdeckungen wieder am Gehäuse an, indem
Sie die zuvor gelösten Schrauben wieder anbringen. Ziehen
Sie diese gut an.
4. Bringen Sie die Verschlußeinrichtung (Padlock) wieder an und
schließen Sie diese, um ein unerlaubtes Öffnen des Systems
zu verhindern.
5. Schließen Sie alle externen Kabel und den AC
Stromanschlußstecker Ihres Systems wieder an.
Der Mikroprozessor und der Kühler sind möglicherweise erhitzt,
wenn das System in Betrieb ist. Außerdem können einige Platinen
und Gehäuseteile scharfe Spitzen und Kanten aufweisen. Arbeiten
an Platinen und Gehäuse sollten vorsichtig ausgeführt werden. Sie
sollten Schutzhandschuhe tragen.
Français
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce
document avant de suivre toute instruction. Consultez Intel
Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 33
®
Server Boards and Server
Notez que le commutateur CC de mise sous tension /hors tension
du panneau avant n'éteint pas l'alimentation CA du système. Pour
mettre le système hors tension, vous devez débrancher chaque
câble d'alimentation de sa prise.
C'est le câble d'alimentation qui est considéré comme le moyen de
se déconnecter du CA. La prise à laquelle le système est branché
doit se situer à proximité de l'équipement et être facilement
accessible.
CONSIGNES DE SÉCURITÉ -Lorsque vous ouvrez le boîtier pour
accéder à l'intérieur du système, suivez les consignes suivantes:
1. Mettez hors tension tous les périphériques connectés au
système.
2. Mettez le système hors tension en mettant l'interrupteur
général en position OFF (bouton-poussoir).
3. Débranchez tous les cordons d'alimentation c.a. du système
et des prises murales.
4. Identifiez et débranchez tous les câbles reliés aux
connecteurs d'E-S ou aux accès derrière le système.
5. Pour prévenir les décharges électrostatiques lorsque vous
touchez aux composants, portez une bande antistatique pour
poignet et reliez-la à la masse du système (toute surface
métallique non peinte du boîtier).
6. Ne faites pas fonctionner le système tandis que le boîtier est
ouvert.
Une fois TOUTES les étapes précédentes accomplies, vous pouv ez
retirer les panneaux du système. Procédez comme suit:
1. Si un cadenas a été installé sur à l'arrière du système,
déverrouillez-le et retirez-le.
2. Retirez toutes les vis des panneaux et mettez-les dans un
endroit sûr.
3. Retirez les panneaux.
Afin de permettre le refroidissement et l'aération du système,
réinstallez toujours les panneaux du boîtier avant de mettre le
système sous tension. Le fonctionnement du système en l'absence
des panneaux risque d'endommager ses pièces. Pour installer les
panneaux, procédez comme suit:
1. Assurez-vous de ne pas avoir oublié d'outils ou de pièces
démontées dans le système.
2. Assurez-vous que les câbles, les cartes d'extension et les
autres composants sont bien installés.
3. Revissez solidement les panneaux du boîtier avec les vis
retirées plus tôt.
4. Remettez le cadenas en place et verrouillez-le afin de
prévenir tout accès non autorisé à l'intérieur du système.
5. Rebranchez tous les cordons d'alimentation c. a. et câbles
externes au système.
34 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Español
Le microprocesseur et le dissipateur de chaleur peuvent être chauds
si le système a été sous tension. Faites également attention aux
broches aiguës des cartes et aux bords tranchants du capot. Nous
vous recommandons l'usage de gants de protection.
Lea todas las declaraciones de seguridad y precaucion de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel
®
Server Boards and Server Chassis Safety
Information en el CD Resource y/o en
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm
Nótese que el interruptor activado/desactivado en el panel frontal no
desconecta la corriente alterna del sistema. Para desconectarla,
deberá desenchufar todos los cables de corriente alterna de la
pared o desconectar la fuente de alimentación.
Estos cables actúan como dispositivo de desconexión. La toma de
corriente deberá estar situada cerca del equipo y ser de fácil
acceso.
INSTRUCCIONES DE SEGURIDAD: Cuando extraiga la tapa del
chasis para acceder al interior del sistema, siga las siguientes
instrucciones:
1. Apague todos los dispositivos periféricos conectados al
sistema.
2. Apague el sistema presionando el interruptor
encendido/apagado.
3. Desconecte todos los cables de alimentación CA del sistema
o de las tomas de corriente alterna.
4. Identifique y desconecte todos los cables enchufados a los
conectores E/S o a los puertos situados en la parte posterior
del sistema.
5. Cuando manipule los componentes, es importante protegerse
contra la descarga electrostática (ESD). Puede hacerlo si
utiliza una muñequera antiestática sujetada a la toma de tierra
del chasis - o a cualquier ti po de super ficie d e metal sin pi ntar.
6. No ponga en marcha el sistema si se han extraído las tapas
del chasis.
Después de completar las seis instrucciones de SEGURIDAD
mencionadas, ya puede extraer las tapas del sistema. Para ello:
1. Desbloquee y extraiga el bloqueo de seguridad de la parte
posterior del sistema, si se ha instalado uno.
2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las
tapas.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 35
Para obtener un enfriamiento y un flujo de aire adecuados, reinstale
siempre las tapas del chasis antes de poner en marcha el sistema.
Si pone en funcionamiento el sistema sin las tapas bien colocadas
puede dañar los componentes del sistema. Para instalar las tapas:
1. Asegúrese primero de no haber dejado herramientas o
componentes sueltos dentro del sistema.
2. Compruebe que los cables, las placas adicionales y otros
componentes se hayan instalado correctamente.
3. Incorpore las tapas al chasis mediante los tornillos extraídos
anteriormente, tensándolos firmemente.
4. Inserte el bloqueo de seguridad en el sistema y bloquéelo
para impedir que pueda accederse al mismo sin autorización.
5. Conecte todos los cables externos y los cables de
alimentación CA al sistema.
Si el sistema ha estado en funcionamiento, el microprocesador y el
disipador de calor pueden estar aún calientes. También conviene
tener en cuenta que en el chasis o en el tablero puede haber piezas
cortantes o punzantes. Por ello, se recomienda precaución y el uso
de guantes protectores.
Italiano
L'interruttore attivato/disattivato nel pannello anteriore non
interrompe l'alimentazione in c.a. del sistema. Per interromperla, è
necessario scollegare tutti i cavi di alimentazione in c.a. dalle prese
a muro o dall'alimentazione di corrente.
Il cavo è considerato il dispositivo d'interruzione dell'alimentazione
principale (in c.a.). La presa alla quale si collega il sistema deve
essere installata vicino all'unità e deve essere facilmente
accessibile.
36 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
PASSI DI SICUREZZA: Qualora si rimuovano le coperture del telaio
p
er accedere all'interno del sistema, seguire i seguenti passi:
1. Spegnere tutti i dispositivi periferici collegati al sistema.
2. Spegnere il sistema, usando il pulsante spento/acceso
ll'interruttore del sistema.
de
3. Togliere tutte le spine dei cavi del sistema dalle prese
elettr
iche.
4. Identificare e sconnettere tutti i cavi attaccati ai collegamenti
I/O od alle prese installate sul retro del sistema.
5. Qualora si tocchino i componenti, proteggersi dallo scarico
ostatico (SES), portando un cinghia anti-statica da polso
elettr
che è attaccata alla presa a terra del telaio del sistema qualsiasi superficie non dipinta - .
6. Non far operare il sistema quando il telaio è senza le
coperture.
Dopo aver seguito i sei passi di SICUREZZA sopracitati, togliere le
perture del telaio del sistema come seque:
co
1. Aprire e rimuovere il lucchetto dal retro del sistema qualora ve
ne f
osse uno installato.
2. Togliere e mettere in un posto sicuro tutte le viti delle
coperture.
3. Togliere le coperture.
Per il giusto flusso dell'aria e raffreddamento del sistema, rimettere
mpre le coperture del telaio prima di riaccendere il sistema.
se
Operare il sistema senza le coperture al loro proprio posto potrebbe
danneggiare i componenti del sistema. Per rimettere le coperture del
telaio:
1. Controllare prima che non si siano lasciati degli attrezzi o dei
componenti dentro il sistema.
2. Controllare che i cavi, dei supporti aggiuntivi ed altri
co
mponenti siano stati installati appropriatamente.
3. Attaccare le coperture al telaio con le viti tolte i n precedenz a e
avvitarle strettamente.
4. Inserire e chiudere a chiave il lucchetto sul retro del sistema
er impedire l'accesso non autorizzato al sistema.
p
5. Ricollegare tutti i cavi esterni e le prolunghe AC del sistema.
Se il sistema è stato a lungo in funzione, il microprocessore e il
d
issipatore di calore potrebbero essere surriscaldati. Fare
attenzione alla presenza di piedini appuntiti e parti taglienti sulle
schede e sul telaio. È consigliabile l'uso di guanti di protezione.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 37
38 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Appendix C: Regulatory and Certification
Information
Product Safety and EMC Compliance
This Intel® RAID Module has been evaluated for regulatory compliance as an Intel
end system, and is included as part of the end system certification. For information
on end system certification, refer to the product regulatory certification for the end
system level product.
Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide 39
40 Intel® Integrated RAID Module RMS2AF040 and RMS2AF080 Hardware User’s Guide
Loading...
