Intel AP450GX MP Configuration Manual

Configuration Guide
AP450GX MP Server System Quad Pentium® Pro Processor-Based Platform
AP450GX Configuration Guide
Revision History Date Version Modifications
2/98 1.0 Initial release
Information in this document is pro vided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warrant y, relatin g to sale and/or use of Intel products includin g liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel p r oducts are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future defi nition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The AR450GX may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from: Intel Corporation P.O. Box 7641 Mt. Prospect IL 60056-764
or call 1-800-879-4683 Pentium and LANDesk are registered trademarks of Intel Corporation.
MMX and EtherExpre ss are trademarks of Intel Corporation
Copyright © Intel Corporation 1998. Third-party brands and names are the property of their respective owners.
AP450GX Configuration Guide
AP450GX Configuration Guide
This document is a basic guide for the configuration of the AP450GX Server System. The document is in three sections.
The first is a complete description of each system.
The second is a checklist for configuring any one of the systems listed in Section 1.
The third is a detailed description of each accessory and option.
HOW TO USE THIS DOCUMENT:
1. Select the basic system you want to configure from Section 1.
2. Go to the part in Section 2 that matches your selection from Section 1.
3. Refer to Section 3 if you need more detail on accessories and options.
INTENDED AUDIENCE:
This document is intended for use by Intel OEM customers and distributors. It is not intended for direct use by end-users. If you are an end-user and interested in obtaining information on how to place an order, please contact an Intel OEM customer or distributor directly. A list of distributors is available on the Intel corporate web site: http://developer.intel.com/design/disti/index.htm
Section 1. System Configurations
:
Base System Configuration (ALPCD200512C)
This system configuration will support OEM customers. This configuration provides complete flexibility for customers to add memory and hard disks of their choice.
Please refer to the qualified memory list for a selection of memory SIMMs/DIMMs at:
http://support.intel.com/support/motherboards/server/ap450gx
Real World Applications:
Highly robust database applications
Engineering CAD design applications
Graphics intensive publishing applications
The configuration of the base system includes:
AP450GX Configuration Guide
Baseboard
Two slots for Pentium Pro processor modules
Slot connector to support DRAM memory module
6 PCI slots, 4 EISA slots
Integrated graphics controller – Cirrus Logic CL-GD5424 SVGA with 1MB
VRAM Integrated SCSI controller – dual channel SCSI-2 adapter, Adaptec AIC-7880
chipset
Processor Module with Processors
1MB processor module with two 200MHz / 512KB cache Pentium Pro
processors
Memory Module
2GB SIMM memory module (
memory not included
Terminator Card
Required when only one dual Pentium® Pro processor module is used in the system. The empty processor module slot must be filled with this card.
Base System Chassis
Two 420W power supplies with cord (supports expansion to 3 power
supplies) One floppy drive bay with a 3.5-inch diskette drive
Four 5.25-inch half-height peripheral bays for removable media devices
IDE CD-ROM drive in the top peripheral bay
Two bays mounted to a hot swap SCSI backplanes (each bay supports up to
six 3.5-inch standard 80-pin SCA-2 hard drives) Three system fans to cool the baseboard and adapter card area
Two power supply fans to cool the hard drives
Country Kit
The Country Kit contains system documentation and software drivers.
System Configuration II (ALPCD2001MC)
Real World Applications:
Professional multi-node clustering database systems
High speed Internet commerce transaction server
Mission critical applications with failover and failback capabilities
This system configuration is similar to the base system configuration; the difference is the 200 MHz / 1MB cache Pentium Pro processors. This configuration provides complete flexibility for customers to add memory and hard disks of their choice.
)
AP450GX Configuration Guide
Please refer to the qualified memory list for a selection of memory SIMMs/DIMMs at:
http://support.intel.com/support/motherboards/server/ap450gx
• Baseboard
Two slots for Pentium Pro processor modules
Slot connector to support DRAM memory module
6 PCI slots, 4 EISA slots
Integrated graphics controller – Cirrus Logic CL-GD5424 SVGA with 1MB
VRAM Integrated SCSI controller – dual channel SCSI-2 adapter, Adaptec AIC-7880
chipset
• Processor Module with Processors
1MB processor module with two 200MHz / 1MB cache Pentium Pro
processors
• Memory Module
2GB SIMM memory module (
• Terminator Card
Required when only one dual Pentium Pro processor module is used in the system. The empty processor module slot must be filled with this card.
• Base System Chassis
Two 420W power supplies with cord (supports expansion to 3 power
supplies) One floppy drive bay with a 3.5-inch diskette drive
Four 5.25-inch half-height peripheral bays for removable media devices
IDE CD-ROM drive in the top peripheral bay
Two bays mounted to a hot swap SCSI backplanes (each bay supports up to
six 3.5-inch standard 80-pin SCA-2 hard drives) Three system fans to cool the baseboard and adapter card area
Two power supply fans to cool the hard drives
• Country Kit
The Country Kit contains system documentation and software drivers.
memory not included
)
AP450GX Configuration Guide
AP450GX Application and Hardware Matrix
Recommended Configurations:
Hard
Drives
Memory
Processors
Pentium® Pro
200MHz/1 MB
RAID
Cache
CAD
9-27GB+
2GB+
2+
No
Video
Card
Add-on
Yes
Database
Developer
E-mail Server
File
Server
Graphics
Design
27-54GB+
18-36GB+
24-54GB+
27-54GB+
45-54GB+
4GB
2GB+
4GB
2GB+
4GB
4+*
2+
4+*
2+
4+*
Yes
No
Yes
Yes
No
No
Yes
No
No
Yes
Web
54GB+
Servers
* = clustering environment
4GB
4+*
Yes
Yes
AP450GX Configuration Guide
Section 2: AP450GX Configuration Checklist
Base System Configuration
Select a base system configuration:
System contains two Pentium Pro processors with 512KB cache
Processor Module with Processors Selection:
To add two more 200MHz / 512KB processors, check here To upgrade to two 200MHz / 1MB processors, check here
Note: 512KB and 1MB cache processors may not be mixed on a single system.
Memory Module Upgrade: (Memory not included)
To support up to 4GB of memory, check here
Third Power Supply: (optional)
The system includes two power supplies. Adding a third allows one to be replaced without Shutting down the system.(Hot-Swap enabled)
To add a third power supply, check here
Server Monitor Module (optional) Enables out-of-band monitoring of critical server functions. Enables remote diagnostics via modem.
Check here to select the Server Monitor Module
What do I do now?
Contact your Intel Representative to order.
ALPCD200512C
PALCPA2X200512 PALCPA2X2001M
ALMEM4GBM0
PPS420WHS
PSERVERMON1
AP450GX Configuration Guide
System Configuration II
Select a system configuration:
System contains two Pentium Pro processors with 1MB cache
Processor Module with Processors Selection:
To add two more 200MHz / 1MB processors, check here
Memory Module Upgrade: (Memory not included)
To support up to 4GB of memory, check here
Third Power Supply: (optional)
The system includes two power supplies. Adding a third allows one to be replaced without Shutting down the system.(Hot-Swap enabled)
To add a third power supply, check here
Server Monitor Module (optional) Enables out-of-band monitoring of critical server functions. Enables remote diagnostics via modem.
Check here to select the Server Monitor Module
What do I do now?
Contact your Intel Representative to order.
ALPCD2001MC
PALCPA2X2001M
ALMEM4GBM0
PPS420WHS
PSERVERMON1
AP450GX Configuration Guide
Section 3: Components and Accessories
Processor Module
One 1MB processor module with two 200MHz / 512KB cache Pentium Pro processors (PALCPA2X200512)
One 1MB processor module with two 200MHz / 1MB cache Pentium Pro processors
(PALCPA2X2001M)
Power Supply Upgrade:
The AP450GX system is capable of having 3 power supplies. With a third power supply, the system power is redundant and the power supplies are hot-swappable.
420W power supply for redundancy (PPS420WHS)
Heat Sink Kit
Passive heat-sink for 200MHz / 512KB Pentium Pro processor (ALCPUUPKIT)
Active heat-sink for 200MHz / 1MB Pentium Pro processor (ALFSINKKIT)
Check your local supplier for monitors, keyboards, mouse, and other accessories not listed here.
Hardware and Vendor List
For a complete up to date detailed listing of the hardware that have been tested with the AP450GX server system refer to the
Hardware/Operating Systems Test Cross-Reference List
please go to the following URL:
. To obtain the document,
http://support.intel.com/support/motherboards/server/ap450gx
CD-ROM Drives
MicroSolutions Backpack 8X (ext, EPP) MicroSolutions Backpack 4X (ext,EPP)
http://www.micro-solutions.com/
NEC CDR 271 (int, IDE) NEC PCDR-501 (SCSI) NEC CDR 502 (int, SCSI) NEC CDR 601 (int, SCSI)
http://www.nec.com/
Panasonic CR-563B (int, proprietary)
http://www.panasonic.com/pic/index-comput.html
Pioneer DRM-604X (ext, SCSI)
http://www.pioneerusa.com/massstorage.html
Plextor PX-6CH (int, SCSI) Plextor PX-8CH (int, SCSI)
AP450GX Configuration Guide
Plextor PX-43CH (int, SCSI) Plextor DM 3028 (SCSI)
http://www.plextor.com/product.htm
Sony CDU76S (int, SCSI) Sony CDU76SB (SCSI) Sony CSD76SB (int, SCSI II)
http://www.ita.sel.sony.com/products/storage/cddrives/
TEAC CD-56E (int, IDE)
http://www.teac.co.jp/dspd/
Toshiba XM-3401 (int, SCSI) Toshiba XM-3501B (int, SCSI) Toshiba XM-3701 (int, SCSI) Toshiba XM-5302B (int, IDE)
http://www.toshiba.com/taisdpd/products.htm#4
SCSI / RAID Controllers
Adaptec 1542CF (ISA/SCSI) Adaptec 2740A (EISA/SCSI) Adaptec 2740T (EISA/SCSI) Adaptec 2742T (EISA/SCSI) Adaptec 2930 (PCI/SCSI) Adaptec 2940 (PCI/SCSI) Adaptec 2940UW (PCI/SCSI ultra wide)
http://www.adaptec.com/products.html#server
BusLogic BT-747C (EISA/SCSI) BusLogic BT-948 (PCI/SCSI) BusLogic BT-958 (PCI/SCSI) Mylex DAC960PL-2A RAID (PCI/SCSI) Mylex DAC960-3 (EISA/SCSI)
http://www.mylex.com/
DPT 2022 (EISA/SCSI) DPT 2122 (EISA/SCSI)
http://www.dpt.com/products.html
Qlogic FastSCSI IQ (PCI/SCSI)
http://www.qlc.com/
Symbios 8251S (PCI/SCSI)
http://www.symbios.com/scsichra.htm
10
AP450GX Configuration Guide
Hard Drives
Seagate ST11950N (SCSI) Seagate ST12450W (SCSI wide) Seagate ST31220A (IDE) Seagate ST31230WC (SCSI fast wide) Seagate ST31250WC (SCSI fast wide) Seagate ST32550W (SCSI wide) Seagate ST51080N (SCSI) Conner CFP 1060S (SCSI) Conner CFP 1060W (SCSI wide) Conner CFP 1080S (SCSI) Conner CFP 1275A (Mode 4 EIDE) Conner CFP 2107E (SCSI)
http://www.seagate.com/disc/disctop.shtml
Fujitsu M1606SAU (SCSI)
http://www.fcpa.com/cgi-bin/goFrames.cgi/product/hd/hd_cat.html
Maxtor MXT1240S (SCSI) Maxtor MXT7345AT (IDE)
http://www.maxtor.com/products.html
Micropolis MC2217A (IDE)
http://www.micropolis.com/Prod.html
Quantum Pro-Lightening
http://www.quantum.com/products/
Western Digital AC1270 (IDE) Western Digital Caviar 2700 (IDE) Western Digital AC21000H (EIDE)
http://www.wdc.com/products/
Network Interface Cards
3Com 3C509B (EISA) 3Com 3C590 EtherLink III (PCI) 3Com 3C579 Etherlink III (EISA) 3Com 3C579TX 3Com 3C595-TX PCI 3Com TokenLink III (PCI)
http://www.3com.com/products/nic_modem.html
11
AP450GX Configuration Guide
IBM 10/100 Ethernet (PCI) IBM Token Ring 16/4 ISA-16 IBM Token Ring 16/4 II IBM Token Ring Auto 16/4 ISA IBM Token Ring Auto 16/4 II IBM Auto LANStreamer (PCI)
http://www.networking.ibm.com/netprod.html
Intel EtherExpressTM Pro 16 Intel EtherExpress 32 Intel EtherExpress PRO 10A (PnP) Intel EtherExpress PRO 10 (PCI) Intel EtherExpress PRO 10FX (PnP) Intel EtherExpress PRO/100 (PCI) Intel EtherExpress PRO 100B (PCI) Intel EtherExpress PRO 100E (PCI) Intel EtherExpress PRO 100SA (PCI) Intel Server Management Module Intel TokenExpressTM PRO (ISA) Intel TokenExpress Pro/16s Intel TokenExpress 16/4s Intel TokenExpress 32 (EISA)
http://www.intel.com/network/products/index.htm
Madge Smart 16/4 AT Ringnode Madge Smart 16/4 PCI Ringnode
http://www.madge.com/
SMC 9332DST SMC Elite 32C Ultra (EISA) SMC EtherEZ (ISA) SMC EtherPower PCI SMC EtherPower 10 PCI SMC EtherPower 10/100 PCI SMC TokenCard Elite (ISA) SMC UltraElite Combo
http://www.smc.com/network/adapt.html
ZNYX ZX312 EtherAction (PCI)
http://www.znyx.com/nb_over.htm
Sound Cards
Sound Blaster Pro II
12
AP450GX Configuration Guide
Sound Blaster 16 Value
http://www.soundblaster.com/sound/
Video Cards
#9 9FX Motion531 2MB (PCI) #9 GXE 64 2MB (PCI) #9 GXE 64 Pro 2MB (PCI) #9 GXE 64 Trio 2MB (PCI) #9 Imagine 128 2MB (PCI)
http://www.nine.com/products/index.html
ATI Graphics Xpression 2MB (PCI) ATI Pro Turbo 4MB (ISA) ATI Pro Turbo 4MB (PCI) ATI UltraPro EISA 2MB ATI Win Boost 2MB (PCI)
http://www.atitech.ca/products/
Diamond Stealth 64 4MB (PCI) Diamond Viper Pro 2MB (PCI)
http://www.diamondmm.com/
Hercules Dynamite Power 2MB DRAM (PCI) Hercules Graphite Terminator 64 2MB DRAM (PCI) Hercules Graphite Terminator 64 video w/MPEG 2MB DRAM (PCI) Hercules Graphite Terminator Pro 4MB VRAM (PCI) Hercules MGA Hercules Stingray 64/video 2MB DRAM (PCI) Hercules Stingray Pro PCI 1MB DRAM
http://www.hercules.com/presale/specs/
Matrox Millennium 3D 4MB (PCI)
http://www.matrox.com/mgaweb/products/products.htm
Orchid Fahrenheit 64 2MB (PCI) Orchid Kelvin 64 2MB (PCI)
http://www.orchid.com/
STB PowerGraph 64 1MB (PCI) STB PowerGraph 64V 2MB (PCI)
http://www.stb.com/products/products.html
13
