Intek EMTS-30 Parts List

PARTS LIST

ELECTRIC MODULAR SKILLETS

MODELS: EMTS-30

EMTS-40

CROWN FOOD SERVICE EQUIPMENT LTD.

70 OAKDALE ROAD, DOWNSVIEW, (TORONTO), ONTARIO, CANADA, M3N 1V9

TELEPHONE: [phone], FAX: [phone]

PART NUMBER 10002R3 1 2008-08-11

PRINTED IN CANADA

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

FIGURE 1

PART NUMBER 10002R3 2 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

FIGURE 1

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

1. 7386-2 Pan Cover with Vent 1
7387-2 Pan Cover with Vent 1

2. 9-3303 Pour Lip Strainer 1 1

3. 3703-2 Tilt Bracket 2 2

4. 3704-1 Bushing 2 2

5. 3209-1 Left Hand Door 1
3596-1 Left Hand Door 1

* 5-MC02 Magnetic Catch 2 2

6. 9-3443 Actuator Rod 18" 1 1

7. 9-3444 Actuator Rod Guide 1 1

8. 9-3345 Lock Collar 2 2

9. 9-3446 Spring 1 1

10. 4-M603-1 Limit Switch 1 1

11. 3838-1 Limit Switch Bracket 1 1

12. 3040-1 Control Panel Decal 1
3040-2 Control Panel Decal 1

13. 4-PL07-1 Pilot Light - Red 1 1

14. 4-TH47 Thermostat 1 1

15. 4-TB05 Bezel 1 1

** 16. 4-TK05 Dial 1 1
* 4737-1 Dial (C) 1 1
* 4736-1 Dial (F) 1 1

17. 9110-1 Power Switch 1 1

PART NUMBER 10002R3 3 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

18. 9111-1 Up/Down Switch 1 1

19. 4-PL06-1 Pilot Light - Amber 1 1

20. 2568-1 Panel Sub Assembly 1 1

21. 4-70EU Ground Lug 1 1

22. 4-TH45 High Limit Thermostat 1 1

** 23. 4-ND41 Contactor, 208V 2 2

4-NG41 Contactor, 240/380/415/480V, 600V 2 2

24. 4-33TB Terminal Block Section,

(220/380V, 240/415V)

4-33TB Terminal Block Section,

(208, 220, 240, 380, 415, 480, 600V)

4-33ES End Section 1 1

25. 3684-1 Component Box Cover 1 1

26. 3571-1 Right Door 1
3597-1 Right Hand Door 1

27. 3201-1 Side Panel 2 2

28. 3007-1 Element Enclosure Box 1
3007-2 Element Enclosure Box 1

29. 2532-1 Box Cover 1
2532-2 Box Cover 1

30. 8-2029 Lock Pin 2 2

31. 8-2035L End Lock Plate 2 2

4 4

3 3

32. 5428-1 Stationary Disc 2 2

33. 5430-1 Core 2 2

34. 8-2026 Spring 2 2

PART NUMBER 10002R3 4 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

35. 5429-1 Rotary Disc 2 2

36. 8-2021 End Stop Plate 2 2

37. 1-66S6 Cap Screws, 1/4 - 20 x 3/4 8 8

38. 3699-1 Hinge Support Assembly 2
3699-2 Hinge Support Assembly 2

39. 6388-1 Right Hand Element Insulation Cover 1
2854-1 Right Hand Element Insulation Cover 1

40. 6389-1 Left Hand Element Insulation Cover 1
2855-1 Left Hand Element Insulation Cover 1

41. 3686-1 Thermostat Bulb Enclosure 1 1

42. 3707-1 Element Clamp 9
2534-1 Element Clamp 9

** 43. 9-3051 Element, 208V, 4 kW 3

9-3051-1 Element, 277V, 4 kW, (480V) 3

9-3052-2 Element, 220V, 4 kW, (220/380V) 3
9-3051-3 Element, 347V, 4 kW (600V) 3
9-3052 Element, 240V, 4 kW (240/415V) 3
9-3333 Element, 208V, 5 kW 3
9-3334 Element, 240V, 5 kW, (240/415V) 3
9-3333-2 Element, 220V, 5 kW, (220/380V) 3
9-3333-3 Element,277V, 5 kW, (480V) 3
9-3333-8 Element, 347V, 5 kW, (600V) 3
9-3333-1 Element, 208V, 6 kW, (Optional) 3

** 43. 9-3333-4 Element, 240V, 6 kW, (240/415V),

(Optional)

3

PART NUMBER 10002R3 5 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

QUANTITY

ITEM PART NO. DESCRIPTION 30 40

** 43. 9-3333-5 Element, 220V, 6 kW (220/380V),

(Optional)
9-3333-6 Element, 277V, 6 kW, (480V), (Optional) 3
9-3333-7 Element, 347V, 6 kW, (600V), (Optional) 3

* ** 44. 9092-3 Fuse, 250V, 3A (208 - 240V Units) 2 2

9092-3 Fuse, 250V, 3A (220/380V and 240/415V

Units)
9001-2 Fuse, 600V, (1/2 A, 380 - 600V Units) 2 2

* ** 45. 9068-1 Fuse Holder, (280 - 240V Units), 2 2

9068-1 Fuse Holder, (220/380V and 240/415V

Units)
9002-1 Fuse Holder, (600V, 380 - 600V Units) 2 2

* ** 46. 4-T251 Transformer, 380 - 240V, 100VA 1 1

4-T251 Transformer, 415 - 240V, 100VA 1 1
4-T255 Transformer, 480 - 240V, 100VA 1 1

1 1

1 1

3

4-T260 Transformer, 600 - 240V, 100VA 1 1

47. 4139-1 Vent Cover 1 1

48. 4355-1 Swivel Spacer 1 1

49. 5817-1 Arm 1 1

50. 9248-1 Knob 1 1

51. 4354-1 Swivel Base 1 1

52. F01S-14 Washer, Stainless Steel, 1/4" 1 1

53. 1-55S3 Hex Screw, 1/4 - 20 x 3/8 S.S. 1 1

* NOT SHOWN.
** SELECT AS REQUIRED.

PART NUMBER 10002R3 6 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

FIGURE 2

PART NUMBER 10002R3 7 2008-08-11

PARTS LIST, ELECTRIC MODULAR SKILLETS, MODELS EMTS-30, EMTS-40

FIGURE 2

ITEM PART

NUMBER

1. 4511-1 Hose Assembly 2

2. 4512-1 Flow Control 2

3. 4513-1 Elbow 2

** 4. 4101-1 Motor 1/2 HP 115/208/230/1/60 1

4101-2 Motor 1/2 HP 380/480V, (Optional) 1
4101-3 Motor 1/2 HP, 220/50, (Optional) 1

** 5. 9119-1 Directional Valve, 110/120 VAC, 50/60 Hz 1
** 9119-2 Directional Valve, 220/240 VAC, 50/60 Hz 1
* ** 9118-1 Coil, 110/120 VAC, 50/60 Hz 2
* ** 9118-2 Coil, 220/240 VAC, 50/60 Hz 2

6. 9-3032 Pump complete with Integral Relief Valve 1

7. 4516-1 Manifold 1

DESCRIPTION QUANTITY

8. 9-3034 Breather 1

9. 9-3033 Tank, 1 Gallon 1

10. 9-3036 Pin complete with Clips 1

11. 4109-1 Street Elbow 2

12. 4112-1 Cylinder 1
9-3318 Cylinder Kit

13. 9-3036 Pin 1

14. 9-3035 Clevis 1

* NOT SHOWN.
** SELECT AS REQUIRED.

PART NUMBER 10002R3 8 2008-08-11
