Intek ECTRS-16 Parts List

PARTS LIST

ROUND ELECTRIC COUNTER TILTING KETTLE

MODEL ECTRS-16

CROWN FOOD SERVICE EQUIPMENT LTD.

70 OAKDALE ROAD, DOWNSVIEW (TORONTO), ONTARIO, CANADA, M3N 1V9

TELEPHONE: [phone], FAX: [phone]

PART NUMBER 10014R3 1 2009-01-30

PRINTED IN CANADA

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL ECTRS-16

PART NUMBER 10014R3 2 2009-01-30

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL ECTRS-16

ITEM PART NO. DESCRIPTION QUANTITY

1. 4403-1 Cover Assembly 1

2. 4-70EU Ground Lug 1

3. 2-KB01 Knob - Red 1

4. 4368-1 Handle 1

5. 1-7850 Acorn Nut 1

6. 9036-114 Bearing 2

** 7. 3162-1 Element, 2.5 kW, 208V 3

3162-2 Element, 2.5 kW, 220V, (380V) 3
3162-3 Element, 2.5 kW, 240V, (415V) 3
3162-4 Element, 2.5 kW, 277V, (480V) 3
3162-5 Element, 2.5 kW, 347V, (600V) 3

8. 3686-1 Capillary Clamp 1

9. 6368-1 Element Clamp 1

10. 4360-1 Insulation Pan 1

11. 4370-1 Bottom Cover 1

12. 3167-1 Left Hand Console Cover 1

13. 3052-3 Right Hand Console Cover 1

14. 4-TH45 High-Limit Thermostat 1

15. 9110-1 Power Switch 1

16. 4-PL08 Pilot Light - Amber 1

** 17. 4736-1 Dial Assembly (°F) 1

4737-1 Dial Assembly (°C) 1

18. 4-TB05 Bezel 1

19. 4-TH47 Regulating Thermostat 1

PART NUMBER 10014R3 3 2009-01-30

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL ECTRS-16

ITEM PART NO. DESCRIPTION QUANTITY

20. 3174-1 Operation Panel Decal 1

21. 9-3217 Component Mounting Plate (3055) 1

** 22. 4-NG41 Contactor - 208, 220, 240V 2

4-NG41 Contactor - 380, 415, 220/380, 240/415,

480V, 600V

23. 4-22ES Terminal Block - End Section 1

** 24. 4-22TB Terminal Block Section -

208, 240, 380, 415, 480, 600V

4-22TB Terminal Block Section - 240/415, 220/380V 4

** 25. M93S-1420-112 Pan Head Screw, 1/4 - 20 NC x 1-1/2" 1

26. F01S-14 Flat Washer, 1/4" 2

27. 5830-1 Bushing 1

28. 4935-1 Knob 1

29. 5829-1 Handle Bar 1

30. 9030-1 Hex Nut, 1/4 - 20 UNC 1

31. S01X-14 Split Lock Washer, 1/4" 1

32. 5831-1 Spacer 1

33. 5828-1 Stop Bar 1

1

3

34. M68S-1420-38 Socket Head Screw, 1/4 - 20 NC x 3/8" 1

* ** 35. 4-T251 Transformer, 380/220V, 50/60 Hz, 100VA 1

4-T251 Transformer, 415/240V, 50/60 Hz, 100VA 1
4-T255 Transformer, 480/240V, 60 Hz, 100VA 1
4-T260 Transformer, 600/240V, 60 Hz, 100VA 1

* ** 36. 9092-3 Fuse, 250V, 3 Amp (208-240V Units) 2

9092-3 Fuse, 250V, 3 Amp (220/380V, 240/415V

Units)

* ** 36. 9001-2 Fuse, 600V, 1/2 Amp (380-600V Units) 2

PART NUMBER 10014R3 4 2009-01-30

1

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL ECTRS-16

ITEM PART NO. DESCRIPTION QUANTITY

* ** 37 9068-1 Fuse Holder (208 - 240V Units) 2

9092-3 Fuse Holder (220/380V, 240/415V Units) 1
9002-1 Fuse Holder (380 - 600V Units) 2

* NOT SHOWN
** SELECT AS REQUIRED.
