Intek EC-20T Parts List

PARTS LIST

SELF-GENERATING STEAM JACKETED TILTING KETTLE

MODEL: EC-20T

CROWN FOOD SERVICE EQUIPMENT LTD.

70 OAKDALE ROAD, DOWNSVIEW, (TORONTO), ONTARIO, CANADA, M3N 1V9

TELEPHONE: [phone], FAX: [phone]

PART NUMBER 10035R6 1 2010-05-11

PRINTED IN CANADA

PARTS LIST, SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL EC-20T

FIGURE 1

PART NUMBER 10035R6 2 2010-05-11

PARTS LIST, SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL EC-20T

FIGURE 1

ITEM PART NO. DESCRIPTION QUANTITY

1.

* 5184-1 Down Tube 1

2. 3-AV01 Air Vent Assembly 1

3. 2-KB01 Phenolic Knob 1

4. 5280-1 Handle 1

5. 3397-1 Console Cover 1

6. 3745-1 Console Cover Gasket 1

7. 9031-9 Acorn Nut, 1/2 - 13 NC 1

8. 4-LLP1 Probe 1

9. 2-686C Thermostat Probe Fitting 1

10. 8-6031 Inner Bearing 1

11. 9025-1 Set Screw, 3/8 - 16 x 1/2” 2

12. 3546-1 Actuating Collar 1

13. 9061-5 Hex Socket Set Screw,

3-SRV9-1 Relief Valve, 50 PSI 1

3/8 - 16 x 1/2”

1

* 9064-23H Spring Pin 1/4 x 2-1/4" LG 1

14. 7011-1 Cam Collar 1

15. 8-6030 Outer Bearing 1

16. 4-M605 Interlock Switch 1

17. 8-3147 Element Gasket 1

**

PART NUMBER 10035R6 3 2010-05-11

18. 7-5019 Element Assembly, 208V, 12 kW 1

7-5020 Element Assembly, 220/380V, 12 kW 1

7-5021 Element Assembly, 240/415V, 12 kW 1

7-5022 Element Assembly, 480V, 12 kW 1

9-3298-1 Element Assembly, 600V, 12 kW 1

PARTS LIST, SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL EC-20T

ITEM PART NO. DESCRIPTION QUANTITY

19. 7284-1 Trunnion Box Cover 1

20. 4-70EU Ground Lug 1

21. M50S51618-34 Hex Bolt 5/16-18 x 3/4" 4

**

22. 4-NG41 Contactor (208, 240V) 2

4-NG41 Contactor (380, 416, 480, 600V) 1

23. 4-22ES Terminal Block End Section 1

24. 4-22TB Terminal Block Section 3

25. 9-3237 Component Mounting Plate 1

26. 3974-2 Liquid Level Control 1

27. 8-1308 Flanged Adjustable Feet 4

28. 1-XR33 External Ring 1

29. 1-W3C7 Washer 2

30. 4623-1 Spring 1

31. 2-011R “O” Ring 1

32. 4608-1 Locking Pin 1

33. 7293-1 Base Assembly 1

34. 9-3186 Control Decal 1

35. 9126-1 Thermostat 1

36. 4-TB05 Bezel 1

37. 4-TK05 Dial 1

38. 1-65S4 Bolt 1

39. 8-2077 Bottom Cover 1

40. 4-PL08 Pilot Light 1

41. 4-PL08 Pilot Light 1

42. 9110-1 Power Switch 1

PART NUMBER 10035R6 4 2010-05-11

PARTS LIST, SELF-GENERATING STEAM JACKETED TILTING KETTLE, MODEL EC-20T

ITEM PART NO. DESCRIPTION QUANTITY

43. 4967-1 Pressure Gauge 1

44. 8-3097 Pressure Gauge Mounting Bracket 1

45. 3-664B Connector, 1/4" C x 1/4" FP 1

46. M33S1032-12 Screw, 10-32 x 1/2 3

* 47. 3-664B Connector, 1/4" C x 1/4" FP 1

* 48. 3-684C Pressure Gauge Kettle Fitting 1

* 49. 3414-1 Bearing Retainer 2

* ** 50. 4-T251 Transformer 380V/240V, 100VA 1

4-T251 Transformer 416V/240V, 100VA 1

4-T255 Transformer 480V/240V, 100VA 1

4-T260 Transformer 600V/240V, 100VA 1

* ** 51. 9092-3 Fuse, 250V, 3A, (208 - 240V Units) 2

9092-3 Fuse, 250V, 3A, (220/380V and

240/415V Units)

9001-2 Fuse, 600V, 1/2A, (380 – 600V

Units)

* ** 52. 9068-1 Fuse Holder, (208 - 240V Units) 2

9068-1 Fuse Holder, (220/380V and

240/415V Units)

9002-1 Fuse Holder, 600V, (380 - 600V

Units)

* 53. 4204-12 Wire Harness 1

* NOT SHOWN.

** SELECT AS REQUIRED.

1

2

1

2

PART NUMBER 10035R6 5 2010-05-11
