The dierence

MOLDED

Makes

Molded Flange Adapters from Integrity
Fusion Products have quickly become a
market leader. By injection molding our
flange adapters, we offer a high quality and
consistent product every time. The self
sealing design on the hub face eliminates
the need for a gasket for most applications.
Integrity Fusion ensures our Flanges meet
ASTM F2880 by conducting 100% X-Ray
inspection as an important part of our
Quality Control program.

IntegriFuse Fittings are manufactured from
the highest quality black high density
bimodal polyethylene copolymer designed
for use in, but not limited to, potable water,
natural gas, industrial, landfill, oil & gas,
and mining applications.

All IntegriFuse fittings meet ASTM –D2513
& ASTM D3261(where applicable).
FM Approved.

Integrity Fusion Products, Inc.
270 Parkade Court
Peachtree City, GA 30269
P: 1-888-770-6330 • P: 770-632-7530
F: 770-632-7540
E: [e-mail]

SDR 9 - (Standard Dimension Ratio) 125 PSI (Working Pressure at 73.4˚ F)

Nominal Size A (OD) B C D (length) E (wall) Weight Item Code Notes

2” IPS 2.375” 3.94” 0.55” 6.10” 0.264” 0.50 lbs. 100403 FM 250

3” IPS 3.500” 5.00” 0.67” 6.10” 0.389” 1.15 lbs. 100407 FM 250

4” IPS 4.500” 6.61” 0.79” 6.10” 0.500” 2.05 lbs. 100411 FM 250

6” IPS 6.625” 8.50” 1.02” 8.07” 0.736” tbd lbs. 100415 FM 250

8” IPS 8.625” 10.63” 1.02” 10.67” 0.958” tbd lbs. 100419 FM 250

10” IPS 10.750” 12.99” 1.18” 11.50” 1.194” tbd lbs. 100422 FM 250

12” IPS 12.750” 15.75” 1.38” 10.83” 1.417” tbd lbs. 100425 FM 250

SDR 7 - (Standard Dimension Ratio) 335 PSI (Working Pressure at 73.4˚ F)

Nominal Size A (OD) B C D (length) E (wall) Weight Item Code Notes

2” IPS 2.375” 3.94” 0.55” 6.10” 0.339” 0.65 lbs. 100402 FM 335

3” IPS 3.500” 5.00” 0.67” 6.10” 0.500” 1.30 lbs. 100406 FM 335

4” IPS 4.500” 6.61” 0.79” 6.10” 0.643” 2.25 lbs. 100410 FM 335

6” IPS 6.625” 8.50” 1.02” 8.07” 0.946” 5.95 lbs. 100414 FM 335

8” IPS 8.625” 10.63” 1.02” 10.67” 1.232” tbd lbs. 100418 FM 335

SDR 11 - (Standard Dimension Ratio) 200 PSI (Working Pressure at 73.4˚ F)

Nominal Size A (OD) B C D (length) E (wall) Weight Item Code Notes

4” DIPS 4.800” 6.56” 0.68” 6.00” 0.436” 1.65 lbs. 100446 FM 200

6” DIPS 6.900” 8.60” 1.00” 8.00” 0.627” 4.35 lbs. 100447 FM 200

8” DIPS 9.050” 10.72” 1.25” 9.00” 0.823” 8.00 lbs. 100448 FM 200

10” DIPS 11.100” 12.15” 1.35“ 9.00” 1.009“ 12.20 lbs. 100449 FM 200

12” DIPS 13.200” 15.94” 1.81” 10.78” 1.200” 20.075 lbs. 100450 FM 200
