Keypad

KEY-2.7

Instruction Manual

Precautions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Never expose the unit to moisture.

7. Suitable only for use Indoors.

8. Only connect specified supply volt­ages.

9. Connect only to the specified termi­nals.

For U.S. models

FCC information for User
CAUTION:

The user changes or modifications not
expressly approved by the party responsible

2

for compliance could void the user’s authority
to operate the equipment.

Note: This equipment has been tested and

found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful inter­ference in a residential installation.

For Canadian Models

NOTE: THIS CLASS B DIGITAL APPARA-

TUS COMPLIES WITH CANADIAN ICES-

003.

Modèle pour les Canadien

REMARGUE: CET APPAPEIL

NUMÉRIQUE DE LA CLASSE B EST
CONFORME À LA NORME NMB-003 DU
CANADA.

Table of Contents

Precautions ..................................... 2

Introduction...................................... 3

Features .......................................... 4

Part Names and Function................ 5

Installation ....................................... 8

System Wiring ................................. 9

Manual Programming .................... 11

Troubleshooting............................. 14

Specifications ................................ 14

Thank you for purchasing an Integra KEY-2.7
keypad.
Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will
enable you to obtain optimum performance
from your new keypad.
Please retain this manual for future reference.

Introduction

The Integra KEY-2.7 keypad simply controls
and provides status feedback of source selec­tion, power, mute and volume of an Integra
MZA-4.7 multi-zone amplifier.
The Keypad is programmed manually when
connected to the amplifier.

3

Features

• Standby, Volume Up/Down and 6 Source select keys.

• 32 Source select key-caps providing a selection of Source select key labels.

• Integra Zone setup; 32 zones with Amp or Preamplifier definition.

•Toggling Amp/Preamplifier control function.

• IR receiver (May be defeated).

• Blue Source Select indicators - tracks the amplifier selection, indicates amplifier ON status.

•Volume Level indicated by a full color LED.

• RJ45 crimp plug connection for simple & reliable installation.

•A white cover plate is supplied as standard.

4

Part Names and Function

Chassis

Source Keys

-

Membrane
Keypad

VOL VOL

Key Cap bracket

Set Key

+

System LED &
Volume indicator

IR Receiver

5

Part Names and Function

6

—Continued

Cover Plate

Infra-Red Window

Part Names and Function

Key Cap Membrane

Flush Box screws

RJ45 Connector

—Continued

CD

DMS

MCD

iPod

XM

SKY

WEB

PC

CD2

TU2

CAM1

Tuner

AUX

VID

iPod2

Sirius

DVR

Request

TAPE

TV

PROJ

CAM2

Cable

DVD

SAT

MP3

TIVO

FOX

Imerge

Lights

Room2

SCRN

CAM3

7

Installation

The KEY-2.7 chassis mounts directly to the wall
surface. The following steps outline the installation
procedure:

• Cut out the required mounting hole in the wall
above the flush-box.

•Terminate a RJ45 plug to the CAT5E cable
wiring instructions on page 9.

• Connect the RJ45 plug to the KEY-2.7.

• Secure the keypad in position using the supplied
flush-box screws.

• Program the keypad (see page 11).

• Select the required Source Key Cap’s, and
secure in position using the Key Cap Bracket.

• Push the keypad cover plate into position.

8

-

see

System Wiring

12345678

CAT5E cable terminated with a RJ45 plug is used to connect to the KEY-2.7.
Use the standard 568-B color code for the CAT5E termination:

Pin # Wire Color Keypad function

1 White/Orange +12V DC supply

2Orange 0V supply

3 White/Green IR output

4 Blue nc

5 White/Blue Data input

6 Green 0V supply

7 White/Brown nc

8 Brown nc

When cabling use CAT5E home runs with a maximum length of 200m.
“Daisy chaining” or parallel connection of up to four keypads per CAT5E cable may be used.

9

System Wiring —

Continued

Connecting to an Integra Multi-Zone amplifier MZA-4.7

KEY-2.7 keypads are wired to the
MZA-4.7 Interface port.
Integra controllers - keypad’s ­may be parallel connected.
IR emitters plug into the IR outputs
and are fixed to the source equip­ment’s IR windows.

Note: Ports IR1 and IR2 are Inter-

face port specific, while ports
IR1+IR2 relay the signals from
both interface ports.

10

Manual Programming

-

VOL VOL

+

The SET Key is used along with the Source Keys to put the keypad into various programming
modes.
The SET key is pushed first - System LED flashes Green followed by the relevant source or
function key.
The functions are:

S2 Integra Mode
S6 Reset
Standby IR Receiver Toggle
VOL+ Volume Level Indicator Dimming
–VOL Source Select Indicator Dimming

11

Manual Programming

-

VOL VOL

+

—Continued

Integra MODE = SET + S2

Push SET followed
by the S2 Key to enter
Integra mode. The
System LED flashes

-

VOL VOL

teal.
At the MZA-4.7 turn ON and OFF the zone
twice. The keypad detects the amplifier and
programs itself to address the zone and
device. Integra mode automatically exits.

RESET = SET + S6 + S6

To reset the keypad,
push SET followed
by two S6 pushes.
The System LED
will go from RED to
GREEN at the completion of the memory
wipe.

12

-

VOL VOL

IR RECIEVER TOGGLE = SET +
Standby

The IR receiver is
normally disabled. To

+

enable the receiver
press SET followed
by the Standby Key,
the System LED will flash Green/white. Push­ing Standby a second time toggles the IR
receiver OFF, system LED will flash RED/
white. Exit by pushing the SET key.

+

Manual Programming

—Continued

SOURCE INDICATOR DIMMING =
SET + –VOL

The source indicator brightness may be
adjusted: Push SET, then push – VOL to cycle
through 25%, 50% and 100% levels. Exit by
pushing the SET key.

VOLUME LEVEL INDICATOR
DIMMING = SET + VOL+

The Volume Level indicator brightness may
be adjusted:
Push SET, then push the VOL+ to cycle
through OFF, 50% and 100% levels. Exit by
pushing the SET key.

13

Troubleshooting

Specifications

No control at all.

– The KEY-2.7 forms just one part of an IR

system. There are potential issues with
connections, wiring, power supply, IR
receiver and emitter placement, plus
other optical and EM interference and
ground loop possibilities.

– It is best to strip the IR system back to just

one controller and debug from there.

–With no IR activity the IR terminal

should read 0V - if not then check all wir­ing and connections, ensure the keypad
programming is correct, and the keypad is
functioning correctly.

Keypad does not track the MZA-4.7.

– Ensure the data termination has integrity,

and is not shorted to other conductors in
the CAT5E. Ensure the keypad is cor­rectly zoned.

14

IR receiver

Passthrough of modulated infrared whose car­rier frequency is within the range of 32 KHz -

44.1 KHz.
Range: typically 8 m - Dependant on ambient
light level, angle of incidence and the remote
controls battery condition.

Wiring

Up to 200 m of CAT5E home run cable.

Voltage Current

12 V DC ±3 V
Typically 25 mA, Max = 60 mA

Dimensions

Cover Plate: Width = 75 mm,

Height = 120 mm,
Depth = 4.6 mm
Depth behind plate = 20 mm

Compliance

ICES-003, FCC.

Template 1

15

16

Template 2

17

18

Memo

19

Integra Division of

ONKYO U.S.A. CORPORATION

18 park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone]

http://www.integrahometheater.com

Integra Division of

ONKYO CORPORATION

Sales & Product Planning Div.: 2-1, Nisshin-cho
Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]

SN 29344403

(C) Copyright 2006

ONKYO CORPORATION Japan. All rights reserved.
