BluPAL
Bluetooth Personal Audio Link
User Manual
Contents:
Introduction.................................................................................................................................................................................................3
Contents of Package....................................................................................................................................................................................4
Main Features..............................................................................................................................................................................................5
Operation.....................................................................................................................................................................................................6
Charging the Battery:.............................................................................................................................................................................. 6
Switching Profiles...................................................................................................................................................................................8
Pairing and Connecting to a Bluetooth Headset or Handsfree device:...................................................................................................9
Pairing and Connecting to Stereo Headphones:...................................................................................................................................10
Using with your TV:............................................................................................................................................................................. 11
Use the microphone:.........................................................................................................................................................................11
Use the headphone jack: ...................................................................................................................................................................11
Use the RCA audio output:............................................................................................................................................................... 11
Using as a Companion Microphone......................................................................................................................................................12
In Conversation:................................................................................................................................................................................12
In a Meeting:.....................................................................................................................................................................................12
In a Lecture Hall:..............................................................................................................................................................................12
Specifications............................................................................................................................................................................................ 13
Regulatory................................................................................................................................................................................................. 13
Introduction
BluPAL - you r Blue toot h P erson al Aud io Link - brings y o u clos er to the sounds you want to h ear.
In microphone mode, your BluPAL brings you closer to people – in conversation in a noisy environment, in a
meeting at a confere nce table, or in a crowded lecture hall.
In Auxiliary Input mode, BluPAL brings you closer to your electronics – your TV, your iPod™, or even your
computer can all stream wireless audio straight to your headset.
Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio Frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following m ea s ures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver- Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Contents of Package
• BluPAL Module
• Base
• AC/DC Power Converter
• Outlet Adapters for USA, EU, UK, and
Australia
• 3.5 mm stereo input cable
• RCA to 3.5 mm adapter cable
• Lanyard
• User Manual and Quick Start Guide
AC/DC Power Converter
3.5 mm stereo input cabl e
RCA to 3.5 mm adapter cable
AC Outlet Adapters
Main Features
Directional Microphone
Volume Up (+)
Volume Down (-)
LED
Omni Microphone
Three-way Input Selector
Master Control
Adjustable Tilt Cradle
Base Power Input
Base Audio Input
Operation
Charging the Battery:
BluPAL uses a rechargeable lithium-ion polymer battery. Unlike earlier rechargeable batteries, its performance
and operating time are not comprom is ed by partial charging or discha rgin g. Bl uPAL w ill charge c om ple tely in two
hours, and a full charge will provide up to five hours of streaming audio
To charge BluPAL in the base:
• Plug the AC/DC Converter into an AC power outlet and into the power input in the
base.
• Insert BluPAL into the Adjustable Tilt Cradle.
To charge BluPAL without the bas e :
• Plug the AC/DC Converter into an AC power outlet and into the power input in
BluPAL.
When BluPAL is charging, the LED will glow steadily red.
When BluPAL is fully charged the red LED will go off.
To turn BluP A L on a nd of f:
• To turn on, press and hold the Mas te r Cont rol for 3
seconds; the LED will flash green 3 times.
• To turn off, press and hold the Master Cont rol for 3
seconds; the LED will flash red 3 times.
Switching Profiles
BluPAL is designed to work with standard Bluetooth headsets and stereo headphones.
These devices use different Bluetooth profiles: “Headset” and “Advanced Audio”.
To switch between profiles:
• Turn BluPAL on.
• Press and hold both volume up (+) and volume down (-) for three seconds.
• The red LED will flash twice.
• When in Headset mode, the green LED will flash periodically.
• When in Advanced Audio mode, the green LED will be on most of the time, and
periodically will blink off.
Pairing and Connecting to a Bluetooth Headset or Handsfree device:
Bluetooth devices must be both Paired and Connected:
Pairing establishes a secure link between two Bluetooth devices.
Connecting creates an audio or control connection between two Bluetooth devices.
To Pair BluPAL to ELI or SoundPort:
• Make sure BluPAL is using the Heads et profile (see Switching Profiles).
• Turn both devices off.
• Put ELI into pairing mode by press ing and ho lding ELI’s Ma s ter Contr ol for 7 se c onds (or until the LED
flashes alternately red and green rapidly).
• Put BluPAL into auto-pairing mode by pres sing and h ol din g Blu PAL’s Master Control for 7 seconds (or
until the LED flashes red and green).
• BluPAL will now automatically pair to ELI.
To Connect BluPAL to ELI or SoundPort:
• Make sure the devices are paired (you only need to do this once).
• Turn on both BluPAL and ELI.
• Firmly press the Master Control on BluPAL.
• Listen for the “Ringtone” on ELI.
• Firmly press the Master Control on ELI.
Other Headsets:
BluPAL should work with most Bluetooth headsets and handsfree devices, provided the other device uses the
standard “0000” PIN code. Because of the simplified BluPAL auto-connect interface, other PIN codes are not
supported).
Pairing and Connecting to BluPAL Headphones:
• Make sure BluPAL is using the Advanced Audio profile (see Switching
Profiles).
• Turn both devices off.
• Put the BluPAL Headpho nes into Pairing mode: Turn on the Headph o ne s
while pressing and holding the Headphone Master Control for seven
seconds. The Headphone LED will flash red and blue.
• Put BluPAL into auto-pairing mode by pressing
and holding Master Control for 7 seconds (or
until the LED flashes red and green).
• BluPAL will automatically pair and connect to
the stereo headpho nes .
Using with your TV:
BluPAL can bring you TV audio in three different ways.
Use the microphone:
• Select the Omni Microphone
• Set BluPAL in front of your TV.
Use the headphone jack:
BluPAL includes a stereo input cable that plugs directly into most TV headphone jacks.
This will give you excellent sound quality but will turn off your TV’s speakers.
• Select the Auxiliary Input.
• Connect the Stereo Input cable to your TV’s headphone jack.
• Connect the other end of the cable to BluPAL (or put BluPAL in its base and
connect the stereo input cable to the Audio Input on the base).
Use the RCA audio output:
Your BluPAL comes with an RCA adapter cable. Many TVs have an RCA audio output
which does not disable your speakers. This gives the BluPAL user excellent sound quality
while others can enjoy the same en tertainment with separate volume control.
• Select Auxiliary Inpu t.
• Connect the RCA adapter cable to the “Audio Output” RCA jacks on your TV.
These are usually located on the back of the TV (and are easily confused with the
Audio Input).
• Connect the RCA adapter cable to the Stereo Input cable.
• Connect the stereo input cable directly to BluPAL (or to the base and insert BluPAL in the base).
Using as a Companion Microphone
In Conversation:
Give BluPAL to your spouse and carry on a conversation in a car or restaurant. Your spouse can use the provided
lanyard, clip BluPAL to his or her shirt, set BluPAL in the base, or simply hold BluPAL in the most comfortable
speaking position. A conversation in a tough environment is comfortable again.
In a Meeting:
Put BluPAL in its base, turn on the omni microphone and put it in the middle of the table to hear every word.
In a Lecture Hall:
Put BluPAL in its base and set it on the podium with the directional microphone on – it will sound like the s pea ker
is speaking directly to you.
서식 있음: 프랑스어(프
랑스)
Specifications
Dimensions 21.5(W) x 68(L) x 12.8(T)
Talk Time 5 hours
Standby 175 hours
Recharge Time 2 hours
Range 33 feet
Battery rechargeable lithium- ion pol ymer
Bluetooth Profiles Headset (HS), Handsfree (HF), and Adva nced Audio Distributio n Profile (A2DP)
Regulatory
FCC ID: SE4BP100
1177
CE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Caution: Changes or modifications not expressly approved
by the party responsible for compliance could
void the user’s authority to operate this device.
The BluPAL product is
in compliance with the essential
requirements and other relevant
provisions of Directives 1999/5/
EC and 93/42/EEC.
Manufactured by:
Starkey Laboratories
P.O. Box 9457, Minneapolis,MN 55344
Authorized European Representative:
Wm. F. Austin House, Bramhall Technology Park
Pepper Road, Hazel Grove, Stockport SK7 5BX
United Kingdom
For current product and
warranty information, please visit:
www.elihearing.com
Attention Pacemaker/Defibrillator Wearers:
Electronic devices have the potential to interfere with the
operation of cardiac rhythm devices, such as pacemakers and
defibrillators, and other active implantable medical devices.
Consult with your physician before use of this product on your person
if you are wearing any such device. Physicians should call
1.800.328.8602 and ask for the Regulatory Department.
