InSinkErator FGN1100PN Specifications

Instant Hot Water Dispensers

Model

F-GN1100

The Next

Necessity

Dimensions

5-1/2"

Minimum 4-3/8" required
from sink hole center
to backsplash

Hot Side
Water Supply

Inlet Tube
Flexible

Outlet Tube
Flexible

Vent Tube
1/4" Incoming

Water Supply

11"

6-3/4"

8-3/8"

8-3/4"

3-3/4"

5-1/2"

NOTE: Max counter thickness is 3".

6-1/8"

Our finest line of instant hot water dispensers
for use with our Stainless Steel Tank for filtered

™

near-boiling 200°F water

Tank and filter sold separately (SST-FLTR)

Submittal Sheet

• Hot Only – Dispenses near-boiling
200°F water

• Graceful high-arching spout swivels for
greater convenience and stylish integrated
levers provide a dramatic look

• Hot lever automatically shuts off

• Durable all brass faucet construction

• 5-Year We Come To You™ In-Home
Service Warranty*

• For use with InSinkErator Stainless Steel
Tank and F-201 Filtration System

• Available in these designer finishes:
white, biscuit, almond, French gold,
satin nickel, polished nickel, chrome,
brushed chrome, mocha bronze, oil rubbed
bronze, matte black and gloss black

Specifications

Valve

Shipping Weight

Required
Hole Diameter

Instant, self-closing

Approximately

4.0 lbs.

1 -1/4" – 1 -1/2"
standard sink hole

Sample Specification

Instant hot water dispenser(s) shall be
InSinkErator Model F-GN1100 with 2/3-gallon
stainless steel tank, adjustable temperature
from 160°F to 210°F and instant, self-closing
hot valve.

Warran ty:

5-year parts and in-home service.

* The complete InSinkErator warranty is included in the Care & Use
booklet packed with each unit.

Job Specifications

Rev. 02/01/2007

1-800-558-5700
www.insinkerator.com

Printed in USA HWD300-07B-45-10

The Emerson logo is a trademark and
service mark of Emerson Electric Co.

InSi nkErator is a division of
Emerson Electric Co.

© 2007 InSinkErator
