SPEEDER 64
Double Tank Rack Conveyor Dishwasher
Automatic conveyor, rack type, double tank dishwasher with recirculating
wash and rinse and fresh water final rinse.
0.52 gallons/rack final rinse consumption
Capacity is 277- 20" x 20" racks per hour or 6,925 dishes per hour
CrossFire® Wash System provides superior cleaning
Error proof replacement with color-coded curtains
STANDARD FEATURES
Patented CrossFire® Wash System
Tank heat: 22.5 kW electric immersion heaters or steam injectors
Capillary thermometers for wash and rinse
In-line thermometer for final rinse
Vacuum breaker on all incoming water lines
Manifold clean-out brush
SureFire® Start-Up & Check-Out Service
Inspection door
Ventilation fan connection provision
S/S frame, legs and feet
S/S front enclosure panel
Automatic tank fill
Low water protection
Detergent connection provision
The patent-pending CrossFire® Wash System power
sprays water horizontally, as well as, from above and
below, cleaning and sanitizing the dirtiest of ware.
Elevated top mounted NEMA 12 control panel
Easily-cleaned crowned hood top
Simplified scrap screen design
Wide insulated swing-out doors
Door safety switch
Standard frame drip proof motors
Energy saver
Override switch for deliming
End caps/pipe plugs secured to prevent loss
Color-coded curtains
Timing belt conveyor drive
Project ________________
Item __________________
Quantity _______________
CSI - 11400 _____________
Approval _______________
Date ___________________
Speeder 64
OPTIONS
Stainless steel steam coil tank heat
Steam booster
Electric booster
Infrared tank heat (90,000 BTU, natural gas or propane
Single point electrical connection: motors, controls and tank heat.
(Booster requires a separate connection)
End cowls with vent and adjustable damper controls
S/S splash guards
Security package
Totally enclosed motors
Rack limit switch
Power Loader
Power Unloader
Door activated drain closers
Insulated hood and door
Plastic 20" x 20" racks (plate or silver)
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
SPEEDER 64
Double Tank Rack Conveyor Dishwasher
Capacity Per Hour 277 racks
6925 dishes
300-600 meals
Tank Capacity 12 gals. (wash) 13 gals. (rinse)
25.5 gals. (gas wash)
26 gals. (gas rinse)
Motor Size 1 hp (wash) 1 hp (rinse)
1/15 hp (conveyor)
Electric Usage 7.5 kW wash tank
15 kW rinse tank
15 kW booster 40° rise
27 kW booster 70° rise
Gas Consumption 90,000 BTUH
88 CFH nat. gas
36 CFH propane
Steam Consumption
at 20 psi min.
Final Rinse Peak Flow
at 20 psi min.
Final Rinse Consumption
at 20 psi min.
Exhaust Hood Requirement 350 CFM Load
Peak Rate Drain Flow 14 gallons/minute
Installation distance from
vertical combustible
service
Shipping Weight 800 lbs.
Machine Electrical
Motors, Controls, Tank Heat Steam Gas Electric
240/1/60
208/3/60
240/3/60
480/3/60
380/3/50
Note: Due to product improvement we reserve the right to change information
and specifications without notice.
81 lbs./hour tank
51 lbs./hour booster 40° rise
90 lbs./hour booster 70° rise
2.4 gallons/minute
144 gallons/hour
0.52 gallons/rack
350 CFM unload
2"
9.7
10.7
9.8
4.9
5.9
20.2
11.9
10.9
5.4
6.6
112.8
73.1
63.9
31.9
40.0
SPECIFICATIONS
CONSTRUCTION- Hood and tank constructed of 16 gauge type 304
S/S. Hood unit of all welded seamless construction. S/S frame,
legs and feet. All internal castings are non-corrosive lead free nickel
alloy, bronze or S/S.
DOORS- Extra large die formed 18-8 type 304 S/S front inspection
door riding in all S/S channels. A triple ply leading edge on the door
channels made of S/S with no plastic or nylon sleeves or liners
used. Two intermediate S/S door safety stops on door.
CONVEYORS- One S/S roller chain conveyor, with rack driving lugs
every sixth link, running along the front of the machine. Eleven
free spinning rollers placed along the back wall of the machine.
Conveyor accommodates all standard 20" racks. Conveyor drive
system includes direct drive gear motor with frictionless, troublefree clutch system, spring-loaded and automatically re-engaging.
Racks conveyed automatically through washing and rinsing
systems, powered by an independent 1/15 hp drive motor.
PUMP- Centrifugal type “packless” pump with a brass petcock
drains. Construction includes ceramic seal and a balanced cast
impeller on a precision ground stainless steel shaft, extension or
sleeve. All working parts mounted as an assembly and removable
as a unit without disturbing pump housing. 1 hp motor for each
wash and rinse pump: standard horizontal C-face frame, drip proof,
internally cooled with ball-bearing construction.
CONTROLS- Top mounted NEMA 12 control enclosure, with 3.5
inch air gap between hood and enclosure, housing motor overload
protection, contactors, transformers and all other dishwasher
controls. All controls safe low voltage 24 VAC.
ENERGY SAVER- Rack actuated lever automatically operates the
final rinse solenoid only when a rack passes, saving water and
energy. The lever also activates an adjustable timer control. If no
ware passes during the set time, the machine shuts down.
SPRAY SYSTEM- Spray arms made of type 304 stainless steel pipe.
Spray assemblies removable without the use of tools.
WASH- Upper and lower manifolds with the patented CrossFire®
Wash System. One manifold above with 3 power wash arms, each
with 9 high pressure cleaning slots and one manifold below with
3 power wash arms, each with 9 high pressure cleaning slots. The
slots are precision milled for water control producing a fan spray.
Wash arms are fillet welded to the S/S manifold. The CrossFire
Wash System provides 4 horizontally spraying high pressure
nozzles.
RINSE- Upper and lower manifolds. One manifold above with 3
power rinse arms, each with 9 high pressure rinsing slots and one
manifold below with 3 power rinse arms, each with 9 high pressure
rinsing slots. The slots are precision milled for water control
producing a fan spray. Rinse arms are fillet welded to the S/S
manifold.
FINAL RINSE- Six nozzles above and three nozzles below threaded
into S/S schedule 40 pipes. Nozzle assemblies produce a fan spray
reducing water consumption, maximizing heat retention.
DRAIN- Drain valve externally controlled. Overflow assembly with
skimmer cap is removable without the use of tools for drain line
inspection. Heater is protected by low water level control.
Note: Exhaust requirements are for pant leg connections only. For
hood type, CFM requirements vary, consult hood manufacturer for
specific sizing.
®
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
3_2012
SPEEDER 64
Double Tank Rack Conveyor Dishwasher
Speeder 64
This drawing is available on the Insinger Web stie at www.insingermachine.com
Contact Insinger Sales at 800-344-4802 for an Installation Drawing Specic to Your Application
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
SPEEDER 64
Double Tank Rack Conveyor Dishwasher
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
This drawing is available on the Insinger Web stie at www.insingermachine.com
Contact Insinger Sales at 800-344-4802 for an Installation Drawing Specic to Your Application
