DA-3
Pot and Pan Washer
Automatic door type utensil washer with timed wash and rinse cycle
Capacity- 50 24” x 28” racks per hour or 276 bun/pans per hour or
184 steam table (2” thick) pans per hour
Fully automatic operation with power on/off button
Cycle starts when doors are closed
Rinse pressure regulator
Hold-Down Rack System for secure washing
Rollers make getting large racks in and out easier
STANDARD FEATURES
Wash tank heat: electric or steam injection
Pressure regulator
Single point electrical connection
Low water protection
Door safety switches
2 vent openings with adjustable damper
Rollers make getting large racks in and out of the pot
washer easier.
Inspection door
Vacuum breaker on all incoming water lines
Capillary thermometer for wash and final rinse
304 stainless steel construction
Stainless steel front panel
Automatic fill
Detergent connection provision
Hold-down rack system
Rollers for track
Manual bypass selector switch
Side-mounted control panel (NEMA 12)
Simplified scrap screen design
Interchangeable upper and lower spray arms
Standard frame drip proof motor
Rack assortment- 2 general utility, 2 bake sheets, 1 basket, 1 counter pan
Manifold clean-out brush
SureFire® Start-Up & Check-Out Service
Project ________________
Item __________________
Quantity _______________
CSI - 11400 _____________
Approval _______________
Date ___________________
DA-3
The Hold-Down Rack System keeps pots and pans
secure during washing, eliminating damage to ware
and equipment.
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
OPTIONS
Stainless steel steam coil tank heat
Steam booster
Electric booster
Security package
Totally enclosed motor
Pressure reduction valve and line strainer
DA-3
Pot and Pan Washer
Capacity Per Hour 50 racks/276 sheet pans
Tank Capacity 62 gallons
Motor Size (2) 5 hp
Electric Usage
(Electric booster must have 16
gallon holding tank)
Steam Consumption
at 20 psi
Final Rinse Peak Flow
at 20 psi min.
Final Rinse Consumption
at 20 psi min.
Exhaust Requirements 600 CFM
Peak Rate Drain Flow 16 gallons/minute
Shipping Weight 1500 lbs.
Current Draw Amps
208/3/60
230/1/60
240/3/60
480/3/60
380/3/50
5 kW wash tank
(2) 9 kW booster 40º rise
(2) 24 kW booster 70º rise
40º rise
20 lbs./hr. tank
50 lbs./hr. booster average
476 lbs./hr. booster peak
70º rise
20 lbs./hr. tank
88 lbs./hr. booster average
834 lbs./hr. booster peak
22.4 gallons/minute
5.6 gallons/cycle
140 gallons/hour
Steam
34.1
N/A
31.1
15.5
18.8
Electric w/o booster
48.0
N/A
43.1
21.5
26.4
SPECIFICATIONS
CONSTRUCTION- Hood and tank constructed of 14 gauge 18-8
type 304 S/S. Hood unit of all welded seamless construction. S/S
frame, legs and feet. All internal castings are non-corrosive lead
free nickel alloy or bronze.
DOORS- A front inspection/clean-out door and two
simultaneously opening operating doors. Operating doors
balanced by externally mounted springs. Extra large die formed
18-8 type 304 S/S doors ride in all S/S channels. A triple ply
leading edge on the door channels made of S/S.
PUMP- Centrifugal type “packless” pump with a brass petcock
drain. Construction includes ceramic seal and a balanced cast
impeller on a precision ground stainless steel shaft, extension or
sleeve. All working parts mounted as an assembly and removable
as a unit without disturbing pump housing. Two 5 hp motors,
standard horizontal C-face frame, drip proof, internally cooled
with ball-bearing construction.
CONTROLS- Side-mounted control cabinet, NEMA 12 rated,
housing motor controls and overload protection, transformer,
contactors and all dishwasher integral controls. All controls safe
low voltage 24 VAC.
SPRAY SYSTEM- Wash and rinse spray systems made of 18-8
type 304 S/S pipe threaded into cast hub assemblies. Upper and
lower spray assemblies are interchangeable and are removable
without the use of tools.
WASH- 4 power spinning wash arms above and 4 power spinning
wash arms below, each designed with 8 high pressure action
cleansing holes.
FINAL RINSE- 4 power spinning wash arms above and 4 power
spinning rinse arms below, each designed with 3 nozzles.
DRAIN- Drain valve externally controlled. Overow assembly with
skimmer cap is removable with the use of simple tools for drain
line inspection. Heater is protected by low water level control.
*Note: Exhaust requirements are for duct connections only.
Note: Due to product improvement we reserve the right to change information and specications without notice.
6245 State Road • Philadelphia, PA 19135 • PH: 800-344-4802 • FX: 215-624-6966 • www.insingermachine.com
3_2012
