DESIGN
The GalleyMaster is engineered with an emphasis on dependability,
durability, and serviceability, safety in operation, ease of cleaning and
maintenance.
The modular "take-apart" design enables the dishwasher to go through a
26" x 66" watertight hatch and navigate interior passageway turns for
easy installation. In operation the seams are leak proof.
STANDARD FEATURES
• Patented CrossFire™ Wash System
• Modular "take-apart" design fits through a 26" x 66"
watertight hatch and navigates interior passageway turns
• Heat: Electric– 5 x 7.5 KW low watt density electric
immersion heaters and 54 KW electric booster with low
temp cut-off. Steam- 2 stainless steel steam coils and
steam booster with low temp cut-off
• Tank heaters easily removable from inside tank
• Integral vent cowl system with dampers
• Hermetically sealed and tank mounted thermometers for
wash and rinse designed to minimize breakage
• Vacuum breaker on all incoming water lines
• Pressure reduction valve and line strainer
• Locking plungers and keys on spray pipes
• Color-coded curtains
• Low water protection
• Permanent legs on the rinse tank, at the split line
• Porthole level indicator on wash and rinse tanks
• Premium ball valves on all water and steam lines
• “Loss proof” wire lanyards on suction strainers, overflow
tubes, and spray pipe end plugs
• Easily cleaned crowned hood top
GALLEYMASTER SERIES
ELECTRIC or STEAM HEAT
60, 85, 135, 185, 250
• External conveyor drive system (HTD) with frictionless
overload release.
• Inspection doors with welded handles and splash guards
• 2 safety catches on each door
• Electrical interlock switch on each door
• Hermetically sealed in-line thermometer for final rinse
• Manifold clean-out brush
• S/S frame, legs, feet and front panels
• Manual tank fills
• Connection points for detergent and rinse aid dispensers
• Detergent probe hole in bottom of wash tank
• Bulk-head mounted NEMA 12 control panel
• NEMA 4 control switches
• Simplified scrap screen design
• Standard frame TE motors
• Complies with ASTM specification F859-04
• 2 tech manuals
• Authorized tech rep in each port
• Exact footprint replacement for 20M-NSU Series
• Data plate and instructions in easy to read locations
• Plastic 20" x 20" racks
OPTIONAL ACCESSORIES
• Power loader
• Power unloader
• Rack limit switch
6245 State Road
Philadelphia, PA 19135-2996
215-624-4800
215-624-6966 FAX
800-344-4802
www.insingermachine.com
Live Tech Service is Available
24 hours/day 7 days/week
800-344-4802
service@insingermachine.com
GALLEYMASTER SERIES
Capacity per hour: 60, 85, 135, 185 or 250 racks per hour
Tank capacity: Wash: 24 gallons
Rinse: 24 gallons
Motor size: 1 hp (wash)
1 hp (rinse)
1/15 hp (conveyor)
Electric Heaters: 15 KW wash tank
22.5 KW rinse tank
54 KW rinse booster
Steam Consumption at 20 psi min: 55 lb/hr wash tank
82 lb/hr rinse tank
109 lb/hr rinse booster
Final rinse flow at 20 psig: 4.0 gal/min. (240 gal/hr) at 140° F min.
Exhaust requirements: 200 scfm entrance
500 scfm exit
Peak drain flow: 14 gal/min
Weight:
Shipping: 1175 lbs.
Operating: 950 lbs.
Current draw on 440/3/60:
Steam Heat: 4.9 amps
Electric Heat: 4.9 amps (motor and controls)
16.5 amps (wash tank heater)
24.8 amps (rinse tank heaters)
59.5 amps (rinse booster)
Power Loader: 0.8 amps additional
Power Unloader: 0.9 amps additional
