Insignia NS-WF26FD9-1 Quick Setup Guide

QUICK SETUP GUIDE
Refrigerator Water Filter
NS-WF26FD9-1
PACKAGE CONTENTS
• Refrigerator water lter
Quick Setup Guide
FEATURES
• Works with Insignia French Door Refrigerators (NS-RFD26SS9, NS-RFD26CXSS0, NS-RFD21CXSS0, and NS-RFD21CISS0)
• NSF 53 certied to remove contaminants, including chlorine, asbestos, cysts, lead, mercury, o-dichlorobenzene, carbofuran, benzene, atrazine, and toxaphene
• Keeps benecial minerals that are good for your health
• Improves taste and removes odor for more palatable food and drinks
• Lasts up to six months or 300 gallons (1,136 L)
• Eliminates cloudiness for fresh, clear drinking water
GENERAL INSTALLATION GUIDELINES
• It is normal for black carbon particles to appear on the outside of your lter. This happens when the lter is moved during shipping. It is safe, simply wipe it o.
• The lter connectors are large to prevent leaks. You might have to twist the lter hard to make sure the connection is secure.
INSTALLING YOUR WATER FILTER
To drink the freshest and cleanest water from your refrigerator, change the lter every six months or when the icon starts blinking. 1 Shut o the water supply, then turn o the water shuto valve on
your refrigerator.
2 Turn the old water lter about 1/4 turn counter-clockwise, then pull
the lter out of the lter holder. Depending on water impurities, you may have to pull hard to remove the lter.
Note: When you pull out the water lter, a little water may leak from the
opening. This is normal. To minimize the water leakage, keep the lter horizontal when you pull it out.
3 Pull out the water lter tray, then empty the tray. Dry around the lter
opening with a dry cloth, then put the tray back in.
4 Insert the new water lter into the water lter holder. 5 While turning the new lter clockwise, push it all the way into the
holder until it locks into place.
6 Turn on the shuto valve and the water supply, then run water
through the dispenser until the water runs clear (about ve minutes). This cleans the water supply system and removes any trapped air.
7 Open the refrigerator door and make sure that no water leaks from
the water lter.
Note: If leaks occur, repeat the installation steps. If leaks persist, discontinue
use and call customer service.
8 After you install the new lter, press and hold both the On/O and
Super Freeze buttons for about three seconds to turn o the icon.
TROUBLESHOOTING
PROBLEM
My refrigerator is not dispensing water
My water dispenser is dripping
My water is cloudy or contains black carbon particles
My new lter is making noises or sputtering
My water tastes bad
SOLUTION
• Make sure that you soak your lter in water for 15 minutes before installing.
• Make sure that the lter is securely connected to the lter holder. Do not use tools to tighten the lter in place.
• Make sure that the water line to the refrigerator is turned on. The valve must be completely open for the refrigerator to receive water.
• Make sure that the refrigerator door is closed or the dispenser will not work.
• A few drops are normal. If the water is dripping constantly, have a service technician check your refrigerator’s water valve.
• Cloudy water is caused by microscopic air bubbles. Run two to three gallons of water from your dispenser to clear the air bubbles out.
• Black carbon particles in the water are normal and appear with all carbon lters. Run two to three gallons of water through your dispenser to remove loose carbon particles.
• Make sure that you soak your lter in water for 15 minutes before installing.
• Noises and sputtering are caused by trapped air pockets. Run two to three gallons of water from your dispenser to push the air out.
• If you do not use your water dispenser for more than four days, run two gallons of water through the dispenser before using it.
• Make sure that you replace your lter every six months to prevent bacteria growth.
STORAGE AND MAINTENANCE
• Replace your lter every six months to prevent bacteria and fungus growth in your lter, supply lines, and storage tank.
• Stored lters do not expire. Keep your unused lters in a cool, dark, and dry place until you need them.
• If you do not use your water dispenser for more than four days, run two gallons of water before using it to prevent bad tasting water.
Before using your new product, please read these instructions to prevent any damage.
OPERATION CONDITION AND NOTICE
Operating conditions:
Flow rate: 0.5 GPM (1.9 LPM)
Pressure: 30 - 125 psi (207-862kPa)
Temperature: 34-100 °F (1-38 °C)
Service life: 6 months
Capacity: 300 GAL (1,136 L)
Function: Chemical/mechanical reduction
Flushing: 5 minutes
Operating notices:
• Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection.
• Systems certied for cyst reduction may be used on disinfected water that may contain lterable cyst.
• For cold water only.
• Replace the lter at least every six months.
• Testing was performed under standard laboratory conditions. Actual performance may vary.
• Check for compliance with the state and local laws and regulations.
• Systems must be installed and operated in accordance with manufacturer’s recommended procedures and guidelines.
• Spent adsorption media will not be regenerated and used.
CONTACT MIRCOFILTER:
Manufactured by Microlter Co., Ltd. 15-1, Gwinong 3-gil, Deoksan-myun, Jincheon-gun, Chungcheongbuk-do, 27856 Made In Korea Tel : +82-43-531-7046
CERTIFICATIONS:
System tested and certied by NSF International against NSF/ANSI Standards 42 and 53 in Model WF26FD9-1 for reduction claims specied on the Performance Data Sheet.
Replacement Cartridge NO: NS-WF26FD9-1 NSF System NO: WF26FD9-1
SUBSTANCE
Chlorine, Taste, and Odor
Particulate, Class1 >0.5 to <1
Asbestos
Cyst
Lead pH6.5
Lead pH8.5
Mercury pH6.5
Mercury pH8.5
O-Dichlorobenzene
Carbofuran
Benzene
Atrazine
Turbidity
Toxaphene
Note: Testing was performed under standard laboratory conditions. Actual performance may vary. Tested using a ow rate of 0.5 GPM, pressure of 60 psi, temp of 68 ± 5 °F.
INFLUENT CHALLENGE
CONCENTRATION
2.0mg/L±10%
At least
10,000 partices/ml
7
10
to 108 bers/L
Min.50,000/L
0.15mg/L±10%
0.15mg/L±10%
0.006mg/L±10%
0.006mg/L±10%
1.8mg/L±10%
0.08mg/L±10%
0.015mg/L±10%
0.009mg/L±10%
11±1 NTU
0.015mg/L±10%
AVERAGE
REDUCTION
97.5%
99.7%
>99%
>99.99%
99.3%
>99.3%
96.6%
95.9%
>99.9%
98.7%
>97.0%
>94.8%
99.1%
>93.8%
REDUCTION
REQUIREMENT
≥50%
≥85%
99%
99.95%
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
MAX. PERMISSIBLE PRODUCT
WATER CONCENTRATION
N/A
N/A
N/A
N/A
0.010mg/L
0.010mg/L
0.002mg/L
0.002mg/L
0.6mg/L
0.04mg/L
0.005mg/L
0.003mg/L
0.5NTU
0.003mg/L
State of California
Department of Public Health
Water Treatment Device
Certicate Number
#3387
Trademark/Model Designation Replacement Elements
WF26FD9-1 NS-WF26FD9-1
The water treatment device(s) listed on this certicate have met the testing requirements Pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants:
Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants
Cysts Asbestos Turbidity Lead Mercury
Organic Contaminants
Atrazine Benzene Carbofuran O-Dichlorobenzene Toxaphene
Rated Service Capacity: 300 GAL Rated Service Flow: 0.5 GPM
Caution: Please refer to the owner’s manual for proper maintenance and operation. If this device
is not maintained and operated as specied in the owner’s manual, there is a risk of exposure to contaminants. For more information, visit the manufacturer’s internet web site at www.bestbuy.com or the California State Water Resources Control Board’s web site at www.waterboards.ca.gov.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richeld, MN 55423 U.S.A. ©2019 Best Buy. All rights reserved.
V3 ENGLISH 19-0606
