Insignia NS-BC130GP1 User Manual
130-Can
Beverage Cooler
NS-BC130GP1
USER GUIDE
Before using your new product, please read these instructions to prevent any damage.
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Control and display panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting up your beverage cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Before using your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Leveling your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reversing the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Grounding requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting to power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using your beverage cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Turning on your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting the temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Lighting your cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the adjustable shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Arranging your beverages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Filling your beer and beverage cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Maintaining your beverage cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning the interior of your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Defrosting your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Storing your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Moving your beverage cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2
www.insigniaproducts.com
130-Can Beverage Cooler
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-BC130GP1 represents the state of the art in beverage cooler design and is
designed for reliable and trouble-free performance.
IMPORTANT SAFETY
INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that
dangerous voltage constituting a
risk of electric shock is present
within your cooler.
This symbol indicates that there
are important operating and
maintenance instructions in the
literature accompanying your
cooler.
WAR NIN G
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this appliance near water.
6 Clean only with a damp cloth.
7 Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatuses (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched, particularly at plugs,
outlets, and the point where they exit from the appliance.
11 Do not use extension cords or ungrounded (two-prong) adapters.
www.insigniaproducts.com
3
NS-BC130GP1
12 Unplug this appliance during lightning storms or when it will not be used for
long periods of time.
13 Make sure that the available AC power matches the voltage requirements of
this appliance.
14 Do not handle the plug with wet hands. This could result in an electric shock.
15 Unplug the power cord by holding the plug, never by pulling the cord.
16 Do not turn the appliance on or off by plugging or unplugging the power
cord.
17 Turn off the appliance before unplugging it.
18 Refer all servicing to qualified service personnel. Servicing is required when
the appliance has been damaged in any way, such as when the power-supply
cord or plug is damaged, when liquid has been spilled or objects have fallen
into the appliance, or when the appliance has been exposed to rain or
moisture, does not operate normally, or has been dropped.
19 To reduce the risk of fire or electric shock, do not expose this appliance to rain,
moisture, dripping, or splashing, and do not place objects filled with liquids on
top of it.
WAR NIN G
Electric Shock Hazard
Failure to follow these instructions can result in electric
shock, fire, or death.
1 WAR NIN G–Keep ventilation openings in the appliance
enclosure or in the built-in structure clear of obstruction.
2 WAR NIN G–Do not touch the interior of the chiller
compartment with wet hands. This could result in frost bite.
3 WAR NIN G–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4 WAR NIN G–Do not damage the refrigerant circuit.
5 WAR NIN G–Do not use electrical appliances inside the food storage
compartment of the appliance, unless they are of the type recommended by
the manufacturer.
6 WAR NIN G–Never allow children to play with, operate, or crawl inside the
cooler.
Risk of child entrapment. Before you throw away your old cooler, refrigerator,
or freezer:
1) Take off the doors
2) Leave the shelves in place so that children may not easily climb inside
7 Unplug the cooler before carrying out user maintenance on it.
8 This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
4
www.insigniaproducts.com
130-Can Beverage Cooler
9 If a component part is damaged, it must be replaced by the manufacturer, its
service agent, or similar qualified persons in order to avoid a hazard.
10 Dispose of the cooler according to local regulations as the cooler contains
flammable gas and refrigerant.
11 Follow local regulations regarding disposal of the cooler due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which
under the guidelines of federal law must be removed before disposal. It is the
consumer's responsibility to comply with federal and local regulations when
disposing of this product.
12 This cooler is intended to be used in household and similar environments.
13 Do not store or use gasoline or any flammable liquids inside or in the vicinity
of this cooler.
14 Do not use extension cords or ungrounded (two prong) adapters with this
cooler. If the power cord is too short, have a qualified electrician install an
outlet near the cooler.
15 If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent, or a similarly qualified person in order to avoid a hazard.
Features
• 130-can, 4.6 cu. ft. capacity holds your favorite drinks
• Flexible 34~50° F (1~10° C) temperature range chills drinks to the perfect
temperature
• Touch controls and LED display for easy control
• 3 removable wood-trimmed shelves for additional storage options
• Reversible glass door for convenient entry options
• Adjustable legs keep your cooler stable
• Auto-defrost prevents ice and condensation from building up inside the
cooler
• White LED light makes it easy to find your drinks
*Interior cooler temperature may vary up to 4° F from displayed temperature.
Package contents
•130-Can beverage cooler
• Quick Setup Guide
www.insigniaproducts.com
5
Components
Control pa nel/
Display
Leveling feet
Shelf
Glass door
Fan
NS-BC130GP1
6
