Insignia NS-65D260A13 User Manual
User Guide
65" 1080p LED TV
NS-65D260A13
Contents
CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Insignia Motion 120Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Game mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .5
Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 13
Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting a home theater system with multiple devices . . . . . . . . 19
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ii
www.insigniaproducts.com
Contents
Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Adjusting component video settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting the power on picture mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Displaying a banner at power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Automatically adjusting the aspect ratio . . . . . . . . . . . . . . . . . . . . . . . . . 34
Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . 39
Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 40
Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
www.insigniaproducts.com
iii
Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Turning Input Sensor on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Turning INlink on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Turning Device Auto Power Off on or off . . . . . . . . . . . . . . . . . . . . . . . . . 46
Turning TV Auto Power On on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Turning Audio Receiver on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Displaying a list of INlink-compatible (HDMI CEC) devices . . . . . . . . 47
Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contents
Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . 53
Programming a different universal remote control . . . . . . . . . . . . . . . 53
Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . 54
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
One-year limited warranty - Insignia Televisions . . . . . . . . . . . . . . . . . 55
iv
Definitions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
How long does the coverage last? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
What does this warranty cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
How to obtain warranty service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Where is the warranty valid? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
What does the warranty not cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
www.insigniaproducts.com
f
It makes a difference how and where you use
As you enjoy your new product, keep these
The issue
The home theater entertainment experience is a growing trend, and larger TVs are popular
purchases. However, TVs are not always supported on the proper stands or installed
according to the manufacturer’s recommendations. We and the consumer electronics
industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or
carts may fall over and cause injury.
Tune into safety
•
One size of TV stand does not fit all. Use only a TV stand
rated for the weight of your TV.
•
Carefully read and understand all enclosed instructions
for proper use of this product.
•
Don’t let children climb on or play with entertainment
system furniture and TVs.
•
Don’t place TVs on furniture that can easily be used as
steps, such as a crate or chest of drawers.
•
Remember that children can become excited while
watching a program, especially on a “larger-than-life” TV.
Make sure that you place or install the TV where it cannot
be pushed, pulled over, or knocked down.
•
Make sure that you route all cords and cables so that they
cannot be pulled or grabbed by curious children.
CHILD SAFETY
your flat panel display
safety tips in mind
Wall mounting
If you decide to wall mount your TV, always remember:
•
One size of wall mount does not fit all. Use only a wall mount rated for the weight of
your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory as suitable for your TV.
•
Follow all instructions supplied by the TV and wall mount manufacturers.
•
If you have any doubts about your ability to safely wall mount your TV, get help from a
professional installer.
•
Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks. If
you are unsure, ask a professional installer.
TVs can be heavy. At least two people are required for safe wall mount installation.
www.insigniaproducts.com
1
NS-65D260A13
Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within your TV. This
label is located on the back of your TV.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying your TV.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer.
12 Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold
with the apparatus. When a cart
is used, use caution when
moving the cart/apparatus
combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15 The wall plug is the disconnecting device. The
plug must remain readily operable.
16 An apparatus with three-prong, grounding-type
plug is a Class I apparatus which needs to be
grounded to prevent possible electric shock.
Make sure that you connect the Class I
apparatus to a grounding-type, three-prong
outlet.
17 Remote control batteries should not be exposed
to excessive heat such as sunshine, fire, or the
like.
18 The apparatus should not be exposed to
dripping or splashing, and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
WARN ING
Electric shock hazard
To reduce the risk of fire or electric shock, do not
remove any cover or expose the device to rain or
moisture. No user-serviceable parts are inside. Refer
servicing to qualified service technicians.
Lightning
For added protection for your device receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect any
antenna or cable system. This helps prevent
property damage and personal injury from
lightning and power line surges.
Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal.
Handling the LCD panel
• Your TV’s screen is made of glass. Do not drop
your TV or hit, jolt, or press hard against the LCD
panel. If the screen breaks, be careful of broken
glass.
• If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
• If the liquid gets in your mouth, immediately
gargle, rinse, and consult with your doctor. Also, if
the liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
Replacement parts
When replacement parts are required, make sure
that the service technician uses replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock,
personal injury, or other hazards.
Safety check
After completing any service or repair to this device,
ask the service technician to perform routine safety
checks to determine that your TV is in correct
operating condition.
2
www.insigniaproducts.com
Power source
Operate your TV only from the type of power source
indicated on the marking label. If you are not sure
of the type of power supplied to your home, consult
an electrician or your local power company.
Servicing
These servicing instructions are for use by qualified
service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that
contained in the operating instructions unless you
are qualified to do so.
CAUTION
Damage requiring service
Unplug this TV from the power outlet and refer
servicing to qualified service personnel under the
following conditions:
• When the power supply cord or plug is damaged
or frayed.
• If liquid has been spilled or objects have fallen
into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by following
the operating instructions. Adjust only those
controls that are covered by the operating
instructions because incorrect adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore your TV to its normal
operation.
• If your TV has been dropped or damaged in any
way.
• When your TV exhibits a distinct change in
performance.
Outdoor antenna grounding
If an outside antenna or cable system is connected
to your TV, make sure that the antenna or cable
system is grounded to provide some protection
against voltage surges and built-up static charges.
Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with
respect to correct grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
Antenna lead-in wire
1
Grounding clamp
2
Antenna discharge unit
3
Grounding conductors
4
Ground clamps
5
Power service grounding electrode system
6
Electric ser vice equipment
7
Note to CATV system installer
Article 820 of the National Electrical Code,
ANSI/NFPA No. 40 provides guidance for correct
grounding. Specifically, it states that the cable
ground must be connected to the grounding
system of the building as close to the point of cable
entry as practical.
Condensation
Moisture will form on the TV if the TV is brought
from cool surroundings into a warm room or if the
temperature of the room rises suddenly. When this
happens, the TV's performance may be impaired. To
prevent this, let the TV stand in its new
surroundings for about an hour before switching it
on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if
the TV is exposed to the breeze from an air
conditioner. In such cases, change the location of
the TV.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage, keep
your cordless and cellular telephones away from
the TV.
End of life directives
Your TV contains tin-lead solder. Disposal of this
material may be regulated for environmental
reasons. Your TV also contains material that can be
recycled and reused. For disposal or recycling
information, contact your local authorities to find a
recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp video
quality. Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV, and are not
considered defects.
www.insigniaproducts.com
3
NS-65D260A13 Insignia 65" 1080p LED TV
Insignia 65" 1080p LED TV
Introduction
Congratulations on your purchase of a high-quality
Insignia product. Your NS-65D260A13 represents
the state of the art in LED TV design and is designed
for reliable and trouble-free performance.
INlink
Enjoy the benefit of having HDMI CEC compatible
products plug and play! No setup is needed! CEC
technology lets different components discover and
communicate with each other. (See page 45
instructions on how to use INlink.)
for
Insignia Motion 120Hz
With a 120 Hz screen refresh rate twice the rate of a
60 Hz screen, a screen with 1,080 lines of resolution
(up from 720 lines in the last generation of HDTVs),
and special motion-detection technology, you will
experience a picture with clearer detail and
brightness, smoother transitions, and reduced
motion blurring, particularly when watching
fast-motion sports and action scenes. (See page 26
for instructions on how to adjust the TV picture.)
Game mode
Video games generally require adjustments to the
television picture settings to get the maximum
experience. By simply pressing a button on your
remote control, your television settings will
automatically adjust for video games. It couldn't be
easier. (See page 25
Game mode.)
for instruction on how to select
4
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Installing the stand or wall-mount bracket
Notes
• If you plan to wall-mount your T V, do not install
the stand.
• Store the stand and stand screws in case you
decide to use the stand in the future.
Installing the stand
To install the stand:
1 Carefully place your TV face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Secure the stand column to the TV using five
M6 x 18 mm screws (provided).
Screw type Screw length # of screws
M6 18 mm 5
Installing a wall-mount bracket
Warning
This TV is intended to be supported by a UL Listed
wall mount bracket with suitable weight/load. (See
“Miscellaneous
To attach your TV to a wall-mount bracket:
1 Carefully place your TV face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Remove the five screws that secure the stand
column to the TV, then remove the stand
column.
3 Attach the wall-mount bracket to your TV using
the mounting holes on the back of your TV. See
the instructions that came with the wall-mount
bracket for information about how to correctly
hang your TV.
Note
• The length of the wall-mount screws vary
depending on the wall-mount bracket you
purchased. See the instructions that came with
the wall-mount bracket for screw lengths.
• The mounting holes on the back of your TV take
type M6 screws.
” on page 53.)
3 Secure the TV stand base to the stand column
using seven M6 x 18 mm screws (provided).
Screw type Screw length # of screws
M6 18 mm 7
15.75 in. (400 mm)
15.75 in. (400 mm)
Wall-mount brackets
www.insigniaproducts.com
5
NS-65D260A13 Insignia 65" 1080p LED TV
TV components
Package contents
• Remote control and batteries (2 AAA)
• Stand column
• TV stand base
•Screws (12)
•Power cord
•Quick Setup Guide
• Important Information
Front
# Item Description
1
MENU
2
INPUT
3
VOL+/VOL– Press to increase or decrease the volume.
4
CHS/CH
T
5
(power)
6
Power indic ator
7
Remote control sensor
Press to open the on-screen menu. For more
information, see “Navigating the menus” on
page 24.
Press to open the INPUT SOURC E list, press or
to select the video input source, then press
INPUT again. For more information, see “Selecting
the video input source” on page 23.
In menu mode, press to confirm selections.
Press to go to the next or previous channel in the
channel list. For more information, s ee “Selecting a
channel” on page 24.
Press to turn your TV on or off (standby mode).
Warning: When your TV is off, power still flows
through it. To completely disconnect power, unplug
the power cord.
Turns off when your TV is on.
Lights red when your TV is off (standby mode).
Receives signals from the remote control. Do not
block.
Side
# Item Description
Connect a USB flash drive to this jack to view
1
USB
DIGITAL OUTPUT
2
(optical)
3
HDMI3
4
TV IN ANT/CABLE
5
/AUDIO OUT
compatible JPEG picture files. For more information,
see “Connecting a USB flash drive” on page 17 and
“Using a USB flash drive” on page 48.
Connect a digital audio amplifier or home theater
system to this jack to listen to TV audio through the
amplifier speakers. For more information, see “Using
digital audio” on page 18.
Connect an HDMI device to this jack. For more
information , see “Using HDMI (best)
or 17.
Connect an antenna or cable TV to this jack. For more
information, see “Connecting an antenna or cable TV
(no box)” on page 13.
Connect headphones, an analog audio amplifier, a
home theater system, or a sound bar to this jack. For
more information, see “Using analog audio” on
page 19.
” on pages 10, 13,
6
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Back
# Item Description
Connect an HDMI device to this jack. For more
information , see “Using HDMI (best)
1
HDMI2/ARC
2
HDMI1 (DVI)
3
PC IN AUDIO
4
PC IN VGA
COMPONE NT IN
Y/VIDEO, P
5
OR
AV I N Y /V ID EO
6
AV I N AUD IO L /R
B
, P
R
or 17.
If you are connecting a home theater system using
HDMI, connect it to this jack.
Connect an HDMI device to this jack. For more
information , see “Using HDMI (best)” on pages 10, 13,
or 17.
OR
Connect the video for a DVI device to this jack. For
more information, see “Using DVI (same as HDMI but
requires a sound connection)” on pages 11 or 14.
Connect the audio for a computer to this jack. For more
information see “Using VGA
OR
Connect the audio for a DVI device to this jack. For
more information see, “Using DVI (same as HDMI but
requires a sound connection)” on pages 11 or 14.
Connect the video (VGA) for a computer to this jack.
For more information, see “Using VGA” on page 16.
The CO MPONENT IN Y/VIDEO jack works as one of
the component video jacks or as a composite video
jack.
Connect the video for a component video device to
these jacks. For more information, see “Using
component video (better)” on page 11 or 14.
OR
Connect the video for a composite video device to the
Y/VIDEO jack. For more information, see “Using
composite video (good)” on page 12 or 15.
Connect the audio for a component video device to
these jacks. For more information, see “Using
component video (better)” on page 11 or 14.
OR
Connect the audio for a composite video device to
these jacks. For more information, see “Using
composite video (good)” on page 12 or 15.
” on pages 10, 13,
” on page 16.
www.insigniaproducts.com
7
NS-65D260A13 Insignia 65" 1080p LED TV
Remote control
# Button Description
Press to turn your TV on or off (standby mode).
1
(power)
2
Quick Launch Inputs
3
Numbers
4
5
ENTER Press to confirm selections or changes.
6
MENU Press to open the on-screen menu.
7
EXIT
8
INPUT
9
CH-LIST Press to open the channel list.
Warn ing: When your TV is off, power still flows
through it. To disconnect power, unplug the power
cord.
TV—Press to select the T V input source.
VIDEO —Press to select the composite video device
connected to the Y/VIDEO jack.
HDMI—Press one or more times to select the device
connected to the HDMI1 (DVI), HDMI2 (ARC), or
HDMI3 jack.
ACC—This button has no function.
Press to enter channel numbers and the parental
control password.
Press to enter a digital sub-channel number. For more
information, see “Selecting a channel
Press to close the on-screen menu.
Press to open the INPUT SOURCE list, press S or T on
the remote control to select the video input source,
then press ENTER. For more information, see
“Selecting the video input source” on page 23.
” on page 24.
# Button Description
10
/MUTE
11
VOL+/–
12
SLEEP
ZOOM
13
14
(return)
S T W X
15
16
HOME Press to open the on-screen menu.
17
INFO
18
CCD
19
FAVOR ITE
CH /CH
20
21
MTS/SAP
22
23
AUDIO
24
INlink Controls
Press to mute the sound. Press again to restore the
sound.
Press to increase or decrease the volume.
Press to set the sleep timer. You can select Off, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes. For more
information, see “Setting the sleep timer” on page 42.
Press to change how the picture looks on the screen
(aspect ratio). For more information, see “Aspect ratio
options ” on page 26.
In TV mode, press to return to the previous channel.
Press to nav igate in on-screen menus and to adjust
settings.
Press to display TV status information, such as the
channel number, channel name (if available), or signal
source. For more information, see “Viewing chann el
informati on” on page 24.
Press to turn close d capti oning o n or of f. You c an sel ect
CC Of f, CC On, or CC on When Mute. For more
information, see “Turning closed captioning on or off”
on page 39.
Press to open the Favo rite channel list. For more
information , see “Setting up a favorite channel list
page 32 and “Viewing a favorite channel” on page 32.
Press to change TV channels. For more information,
see “Selecting a channel” on page 24.
Press to select the picture mode. You can select Vivid,
Standard, Energy Savings, Theater, Game, or
Custom. For more information, see “Picture Mode” on
.
page 25
Press to select the audio mode for an analog program.
You can select:
• Mono—Select th is option if there is noise or
static on weak stereo broadcasts.
• Stereo—Select this option for programs
broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
Press to select the sound mode. You can select
Standard, Theater, Music, News, or Custom. For
more information, see “S ound Mode” in “Adjustin g
sound settings” on page 29.
Press to control INlink-compatible (HDMI CEC) devices.
For more information, see “Using INlink” on page 45.
” on
8
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Making connections
What connection should I use?
Your TV has several connection types for
connecting devices to your TV.
For the best video quality, you should connect a
device to the best available connection.
Use the following tables to identify cables:
Connection type
and jack
HDMI
video/audio
Component
video (requires
an audio
connection)
Video quality Cable connector
Best (use this
if your devices
have HDMI)
Better than
composite or
coaxial
Connection type
and jack
Optical digital
audio (SPDIF)
Analog audio
VGA (computer)
video and audio
Cable connectors
Composite video
(requires an
audio
connection)
Coaxial
video/audio
Better than
coaxial
Good
You can use the HDMI1 (DVI) jack on your TV to
connect a DVI device to your TV. You need to attach
an HDMI-to-DVI adapter to the end of the HDMI
cable that connects to the DVI device.
Cautions
• Check the jacks for position and type before
making any connections.
• Loose connections can result in image or color
problems. Make sure that all connections are
tight and secure.
• The external audio/video equipment shown
may be different from your equipment. If you
have questions, refer to the documentation that
came with your equipment.
• Always unplug the power cord when
connecting external equipment.
www.insigniaproducts.com
9
NS-65D260A13 Insignia 65" 1080p LED TV
Connecting power
To connect the power:
• Connect the AC power cord to the AC connector
on the back of your TV, then connect the other
end of the power cord to a power outlet.
Cautions
• Your TV should only be operated from the
power source indicated on the label.
• Always unplug the AC power cord from the
power outlet when you will not be using your
TV for an extended period of time.
Connecting a cable or satellite box
Many cable or satellite TV boxes have more than
one connection type. To get the best video, you
should use the best connection type available. For
more information, see “What connection should I
use?” on page 9.
Using HDMI (best)
To connect a cable or satellite box using HDMI:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI cable (not provided) to the
HDMI jack on the side or back of your TV and to
the HDMI OUT jack on the cable or satellite box.
Cable or satellite box
Side of TV
HDMI cable
Back of TV
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 20
Note
An HDMI cable carries both audio and video. You do
not need to use any audio cables.
.
10
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Using DVI (same as HDMI but requires a sound connection)
Note
You must use the HDMI1/DVI jack to connect a cable
or satellite box using DVI. If you use another HDMI
jack, you will not hear sound from the TV speakers.
To connect a cable or satellite box using DVI:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
cable or satellite box.
4 Connect the other end of the cable to the
HDMI1(DVI) jack on the back of your TV.
Using component video (better)
To connect a cable or satellite box using
component video:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a component video cable (not
provided) to the Y/VIDEO, P
jacks on the back of your T V and the component
video out jacks on the cable or satellite box.
Cables are often color-coded
to match color-coded jacks.
B
, and PR video
3.5mm audi o cable
HDMI cable with
HDMI-DVI adapter
Cable or satellite box
Back of TV
5 Connect a 3.5mm audio cable (not provided) to
the PC IN AUDIO jack on the back of your TV
and to the AUDIO OUT jacks on the cable or
satellite box.
Note
When you connect the audio using the PC IN AUDIO
jack, the audio output is analog.
6 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
7 Go through the Setup Wizard on page 20
.
Back of TV
Cable or satellite box
Component
video cable
Audio cable
4 Connect an audio cable (not provided) to the
AV IN AU DIO L/R jacks on the back of your TV
and to the audio out jacks on the cable or
satellite TV box.
Note
•The Y/VIDEO, PB, and PR video jacks (used to
connect a component device) share the
AV I N A UDI O L /R jacks with the Y/VIDEO jack
(used to connect a composite device).
• When you connect the audio using the
AV I N A UDI O L /R jacks, the audio output is
analog.
5 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
6 Go through the Setup Wizard on page 20
.
www.insigniaproducts.com
11
NS-65D260A13 Insignia 65" 1080p LED TV
Using composite video (good)
To connect a cable or satellite box using
composite video:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an AV cable (not provided) to the
Y/VIDEO jack and AV I N AU DIO L/R jacks on the
back of your TV and to the composite video and
audio out jacks on the cable or satellite box.
Note
•The Y/VIDEO, PB, and PR video jacks (used to
connect a component device) share
AV I N A UDI O L /R jacks with the Y/VIDEO jack
(used to connect a composite device).
• When you connect the audio using the
AV I N A UDI O L /R jacks, the audio output is
analog.
Cables are often color-coded to match color -coded jacks.
Note: The yellow video connector on the AV cable connects to the green Y/VID EO jack.
Using coaxial (good)
To connect a cable or satellite box using coaxial:
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a coaxial cable (not provided) to the
TV IN ANT/CABLE jack on the side of your TV
and to the coaxial out jack on the cable or
satellite box.
Cable or satellite box
Coaxial ca ble
Back of TV
Cable or satellite box
AV cable
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 20
.
Side of T V
4 Plug your TV’s power cord into a power outlet,
turn on your TV, then turn on the cable or
satellite box.
5 Go through the Setup Wizard on page 20
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
.
12
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Connecting an antenna or cable TV (no box)
To connect an antenna or cable TV (no box):
1 Make sure that your TV’s power cord is
unplugged, and all connected equipment is
turned off.
2 Connect a coaxial cable (not provided) to the
TV IN ANT/CABLE jack on the side of your TV
and to the antenna or cable TV wall jack.
Antenna or
cable TV (no box)
Connecting a DVD or Blu-ray player
Using HDMI (best)
To connect a DVD or Blu-ray player using HDMI:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an HDMI cable (not provided) to the
HDMI jack on the side or back of your TV and to
the HDMI OUT jack on the DVD or Blu-ray
player.
Coaxial ca ble
Back of TV
Side of TV
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Go through the Setup Wizard on page 20
Notes
• Use a coaxial cable to eli minate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
• If the antenna is not installed correctly, contact
qualified service personnel to correct the
problem.
• If the signal level for a channel is weak, the
picture may be distorted. Adjust the antenna or
use a highly directional outdoor or set-top
antenna with a built-in amplifier.
• If the picture quality is good on some channels
and poor on others, the problem may be caused
by a poor or weak signal from the broadcaster
or cable TV provider.
• If you connect to cable or satellite TV without a
set-top box and experience poor picture quality,
you may need to install a set-top box to improve
signal reception and picture quality. Contact
your cable or satellite TV provider about
upgrading to a set-top box.
• Many high-definition (HD) channels upscale
standard-definition (SD) content. The picture
displayed on your TV is still displayed as SD, thus
the picture quality will not be as clear or crisp as
it would be if the content was originally
recorded in HD.
.
DVD or Blu-ray playe r
HDMI cable
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the INPUT SOURCE list.
6 Press
S
or T to highlight HDMI1, HDMI2, or
HDMI3, then press ENTER.
Note
You can also press HDMI repeatedly to select the
DVD or Blu-ray player.
www.insigniaproducts.com
13
NS-65D260A13 Insignia 65" 1080p LED TV
Using DVI (same as HDMI but requires a sound connection)
Note
You must use the HDMI 1 (DVI) jack to connect a
DVD or Blu-ray player using DVI. If you use another
HDMI jack, you will not hear sound from the TV
speakers.
To connect a DVD or Blu-ray player using DVI:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
DVD or Blu-ray player.
3 Connect the other end of the cable to the
HDMI1(DVI) jack on the back of your TV.
Using component video (better)
To connect a DVD or Blu-ray player using
component video:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect a component video cable (not
provided) to the Y/VIDEO, P
the back of your TV and to the COMPONENT
OUT jacks on the component video device.
Cables are of ten color-coded to m atch color-coded j acks.
Back of TV
B
, and PR jacks on
3.5mm audio cable
DVD or Blu-ray player
HDMI cabl e with
HDMI-DVI adapter
Back of TV
4 Connect a 3.5mm audio cable (not provided) to
the PC IN AUDIO jack on the back of your TV
and to the AUDIO OUT jacks on the DVD or
Blu-ray player.
5 Plug your TV’s power cord into a power outlet,
then turn on your TV.
6 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
7 Press INPUT to open the INPUT SOURCE list.
8 Press
S
or T to select HDMI1, then press
ENTER.
Note
You can also press HDMI one or more times to select
the DVD or Blu-ray player.
Component vi deo cable
Audio cable
DVD or Blu-ray playe r
3 Connect an audio cable (not provided) to the
AV IN AU DIO L/ R jacks on the back of your TV
and to the L/R AUDIO OUT jacks on the DVD or
Blu-ray player.
Notes
•The Y/VIDEO, PB, and PR video jacks (used to
connect a component device) share the
AV I N A UDI O L /R jacks with the Y/VIDEO jack
(used to connect a composite device).
• When you connect the audio using the
AV I N A UDI O L /R jacks, the audio output is
analog.
4 Plug your TV’s power cord into a power outlet,
then turn on your TV.
5 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
6 Press INPUT to open the INPUT SOURCE list.
7 Press
S
or T to select Component, then press
ENTER.
14
www.insigniaproducts.com
Insignia 65" 1080p LED TV
Using composite video (good)
To connect a DVD or Blu-ray player using
composite video:
1 Make sure that your TV’s power cord is
unplugged and the DVD or Blu-ray player is
turned off.
2 Connect an AV cable (not provided) to the
Y/VIDEO jack and AV I N AUD IO L/R jacks on the
back of your TV and to the AV O UT jacks on the
DVD or Blu-ray player.
Note
•The Y/VIDEO, PB, and PR video jacks (used to
connect a component device) share the
AV I N A UDI O L /R jacks with the Y/VIDEO jack
(used to connect a composite device).
• When you connect the audio using the
AV I N A UDI O L /R jacks, the audio output is
analog.
Cables are of ten color-cod ed to match color- coded jacks.
Note: The yellow video connector on the AV cable connects to the green Y/VIDEO jack.
Connecting a VCR
To connect a VCR:
1 Make sure that your TV’s power cord is
unplugged and the VCR is turned off.
2 Connect an AV cable (not provided) to the
Y/VIDEO jack and AV IN AU DI O L /R jacks on
the back of your TV and to the AV OUT jacks on
the VCR.
Note
•The Y/VIDEO, PB, and PR video jacks (used to
connect a component device) share the
AV I N A UDI O L /R jacks with the Y/VIDEO jack
(used to connect a composite device).
• When you connect the audio using the
AV I N A UDI O L /R jacks, the audio output is
analog.
Cables are of ten color-coded to match color- coded jacks.
Note: The yellow video connec tor on the AV cable connects to the green Y/VIDEO jack.
Back of TV
AV cable
DVD or Blu-ray player
3 Plug your TV’s power cord into a power outlet,
then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the INPUT SOURCE list.
6 Press
S
or T to select AV, then press ENTER.
Notes
You can also press VIDEO to select the DVD or Blu-ray
player.
Back of TV
VCR
AV cable
3 Plug your TV’s power cord into a power outlet,
then turn on your TV and the VCR.
4 Press INPUT to open the INPUT SOURCE list.
5 Press
S
or T to select AV, then press ENTER.
Note
You can also press VIDEO to select the VCR.
www.insigniaproducts.com
15
