感谢您选购我们的对讲机
支持4G
USER'S MANUAL
使用说明书
Thank you for choosing our two-way radios.
4G
Notes before using：
Do not use the walkie talkie in an explosive environment
(such as gas, dust, steam, etc.) or to charge the battery.
Please turn off the walkie-talkie while refueling or parking
at the gas station.
Do not adapt or modify the machine whether there is any
reason.
Do not let the walkie talkie by prolonged direct sunlight,
do not place it near a heating appliance too.
Do not put the walkie talkie at the extremely dusty, damp
and splashing place and do not place it on an unstable
surface.
The repair of the walkie talkie only can be carried out by
professional technicians, do not disassemble by yourself.
Note：
Please read above content carefully. It is very important
for walkie talkie users to gain general knowledge and
understanding of risk about the use of walkie talkie.
Radio Overview
(7)Antenna
(10)LOGO
(9)Speaker
(11)MIC
(8)Indicator
(5)Power/
volume knob
This guide is for reference only. Commitment does not
constituted any form of ,and products to prevai l in kind.
English
(2)Custom key F1
(1)PTT
(3)Custom key F2
(4)Custom key F3
(15)metal point for
desktop charger
(12)
Lanyard
hole
(13)Earphone
jack
(14)USB
(16)metal point
for desktop charger
Accessory Installation
To insert a SIM card
1
SIM2
SIM1
To insert a SD card
2
(6)SOS
SIM1
SIM2
English English
To install the battery
3
（a）Insert the battery to connect with the metal at the bottom
of the tank;
（b）Press down on the other end of the battery.
a
Install the belt clip
5
The belt clip should be aligned with the back screw hole
（a）
Install the belt clip by rotating screw
（b）
Uninstall the belt clip
Uninstall the belt clip by rotating screw until loose
SIM2
SIM1
b
Close the battery cover:
4
(a) Push the battery cover until it clicks into place;
(b) Push the battery cover down;
Open the battery cover: Pull up battery cover.
a
b
Install Lanyard
6
Belt clip
English English
Installing headset
7
Open the cover from the top of device to show the headset
sockets. Headset will work immediately after being
plugged in.
Functions Sheet
No.
Name
PT T button
1
2
Custom key
F1
Custom key
3
F2
Functions
PTT
Short press :(Auto exit after 5S)
Re-press F2 for group switch(up),
confirm by pressing PTT.
F3 for group switch (do wn), confirm by
press ing PTT.
Short press : voice playback
Long press : single call
Re-press F2 for single calls switch (up),
confirm by pressing PTT.
F3 for single calls switch (down), confirm
by pres sing PTT.
Attach/Remove the Antenna
8
Screw the antenna in to the connector on the top of radio
by holding the antenna at its base and turn the antenna
clockwise to fasten it.
Turn the antenna counter-clockwise until you can remove
it.
(Note:The antenna is neither a handle, a key ring retainer, nor a speaker/ microphone attachment
poi nt. U sing the a ntenn a in these ways may d amag e the ant enna and degrade your transceiver's
performance)
Antenna Antenna
4
Custom key
F3
Power/
5
volume knob
6
SOS
Short press : Voice message playback.
Long press : Voice prompt on battery
consumption.
Clockwise to turn on with a “click”.
Clockwise for volume up , counter
clockwise for volume down.
Short press : short press once to answer
call. Short press twice to
decline / hang up.
Long press : long press for 3s for SOS,
quit by pressing PTT.
English English
Basic functions
Power on
turn the knob (5) clockwise to power on.
Power off
Turn the knob (5) counter clockwise to power off. The red
indicator is on and battery staus will be shown if the
device is under charging.
User Log-in
Voice prompt on user information after log-in. (User
name, user No., connection mode, Sim card status)
Push to Talk
Green indicator blinks when P13 is ready for PTT.
Red indicator is on for PTT calling.
Green indicator is on for PTT called.
Green indicator blinks fast if no internet signal. To play
back record by pressing PTT.
PT T won’t work and red indicator blinks fast under busy
line.
press PTT repeatedly in short time, red indi cator blinks
fast.
Longest talk time limits in 35S. If exceeds, it will auto
release in due time. （ 60s can be set via APP ）
Voice message playback and Sing le call.
Short press button（3）to play latest 10 voice messages.
Press P TT to play back last voice message.
Long press button（3）for single call.
Then pre ss F2 for private call previ ous contacts page,
confirm by pressing PTT.
Press F3 for private call next contacts page
press ing PTT.
Current group
Short press button（4）for voice prompt on current group
and indicate channel.
No voice prompt if calling .
Battery consumption
Long press button（ 4） for voice prompt of batter y
consumption. It says “low, medium , high or full”.
No voice prompt if calling.
Group switch
Short press button （2）then button（3）for group switch
(up), confirm by pressing PTT.
Short press button（2）then button（4）for group switch
(down), confirm by pressing PT T.
PTT will be interrupted while calling. Red indicator blinks
once with voice prompt on current group. Group will be
indicated on display as well.
, confirm by
Security information
Before using the device operation, please read and
observe the following precautions to ensure optimum
device performance,and avoid dangerous or illegal
situations.
Electronic equipment
The place of civilization provisions that has prohibited the
use of wireless devices,don’t use the device,otherwise it
will lead to interference from other electronic devices or
other hazards.
Area with easy fir ing and explosion
Refueling point (service station)or near inflammable and
explosive materials,flammable and explosive chemical
agents in any area, and don’t use the device, the device
may cause an explosion or fire.
Operating environment
Don’t use the device in dusty, wet, dirty, or near
magnetic fields, so as to avoid internal circuit equipment
failure.
Don’t use this device in a thunderstorm, thunderstorms
could result in equipment malfunction or shock hazard.
Don’t place in direct sunlight for too long time.
Please avoid equipment and accessories to rain or
moisture, otherwise it may be caused a fire or electric
shock.
Don’t place the device near a heat source or exposed
flame sources, such as electric heaters, microwave, oven,
water heater, fire, candle s or other places may high
temperatures.
Accessories requirement
Don’t use unapproved or incompatible power supply,
battery charger, other wise, it may result in a fire, explosion
or other hazard.
Only use manufacturer-approved equipment and
equipment accessories for this model,if you use other
types of accessories,it will be lead to accidental damage to
the equipment, breach of warranty of the equipment.
The charger security
When fully charged or not charged, please disconnect the
charger from the device and unplug the charger from the
power outlet.
Don’t drop or bump the charger,if the charger is
damaged,don’t continue to use, to avoid accidents.
Don’t touch the device and charger with wet hands to
avoid short-circuiting device, malfunction or electric
shock.
English English
Battery Safe
Don’t use the metal objects with two poles of the battery
to docking, o r contact with the endpoint of the battery, to
avoid the batter y short circuit,
as well as damage caused by batter y overheating.
Don’t expose the battery to high temperature or fever
around the device, and battery overheating may cause an
explosion.
Don’t disassemble or modify the battery, insert foreign
objects or liquid intrusion, in order to avoid batter y
leakage, overheatin g, causing a fire or explosion.
If a battery leaks, don’t contact with skin or eyes. If
contact, immediately rinse with water and go to hospital
for medical treatment.
If the battery is in the process ofusing, charging or saving,
which havediscoloration, deformation, abnormal heating
phenomenon,please stop using and replace with new
battery.
Don’t throw batteries in a fire, otherwise it will cause fire
and explosion.
Don’t let children touch the battery, to avoid accidents .
Don’t use a damaged battery.
When the standby time of the device is significantly
shorter than normal, plea se replace the batter y.
Dispose of batteries according to local regulations,not
dispose as household waste.
FCC RF Exposure Information and Statement
This device meets the government's requirements for exposure to radio waves.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety margin
designed to assure the safety of all persons regardless of age or health.
The SAR limit of USA (FCC) is 1.6 W/kg averaged. Device types: walkie talkie
(FCC ID: 2AIV6-T520) has also been tested against this SAR limit. SAR
information on this and other pad can be viewed onÿline at
http://www.fcc.gov/oet/ea/fccid/. Please use the device FCC ID number for
search. This device was tested simulation typical 0mm to body and 25 mm front
of face. To maintain compliance with FCC RF exposure requirements, use
accessories should maintain a separation distance between the user's bodies
mentioned above, the use of belt clips, holsters and similar accessories
should not contain metallic components in its assembly,the use of
accessories that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures: - Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
Care and Cleaning
Do not lift up antenna or an external microphone directly.
Please use lint-free cloth to remove dust and stains from a
radio to avoid poor contact.
Please place the cover on headphone jacks when not in
use .
The keypad and sensors should be cleaned carefully with a
lint-free cloth moistened with clean water and a mild
washing liquid.Do not use strong corrosive solvents for
cleaning.
English
Loading...
