Now that you have unpacked each box, you have everything you need to start
using your Inogen One G3 (IO-300). The set-up of your Inogen One G3 is quick
and simple. However, before using the Inogen One G3, please read the entire
User Manual.
www.inogenone.com www.OxygeNation.com
Place your Inogen One G3 in a well
ventilated location. Ensure both particle
filters are in place.
Insert the Inogen One® G3 battery
by sliding battery into place
until the latch returns to the
upper position.
Connect the AC Power Supply
cord to the Inogen One G3.
Plug the Power Supply
AC cord into the
nearest electrical
outlet.
Connect the nasal cannula
tubing into the metal
nozzle on your Inogen
One G3. Oxygen will only
be delivered while you are
breathing through the nasal
cannula connected to the
device.
Turn on the Inogen One G3 by
pressing the button.
Set the flow setting to the flow rate prescribed
by your clinical professional. The flow setting
can be changed by pressing the triangular flow
setting buttons that are marked with “+” and
“-” symbols. Position the nasal cannula on your
face and breathe normally through your nose.
NOTE: You must operate the Inogen One G3 on AC Power for approximately 3 hours to fully charge the battery.
