INNOVATIVE CONCEPTS GROUP C K73 User Manual

TABLET

USER
GUIDE

Thank you for purchasing this device.
Please read all the operating instructions
before manipulating the device.

• Avoid the device to being dropped. Avoid
the display been shake seriously.

• Do not use a metal object to touch the
device to prevent it from short circuit.

• Please backup your data to avoid data
losses, specially when upgrading the

rmware.

• Do not disassemble. Do not wipe the screen
with alcohol, thinner or benzine.

• Do not disconnect or shutdown the
device while it is formatting or uploading/
downloading, or the procedures may lead
to erros.

• Avoid water or foreign objects enter the
device.

• Do not use the device in places that are
extremly hot, cold, dusty or humid.

• Specications are subject to change and
improvement without notice.

Device at glance Instructions

1 - Power on/o

To turn on the device
Press and hold the power switch for 5 seconds;
the unit displays the start-up logo and starts
loading.

To turn o the device

Press and hold the power switch for 2 seconds to

turn the unit o.

Sleep
While the device is at working status, press the

1. Volume +

2. Volume -

3. Power On/O

4. Reset

5. Back

6. Speaker

7. Front camera

8. Earphone Jack

9. Micro USB interface

10. SD Card interface

11. Rear camera

power switch, it enters the sleeping mode, and

the screen will be o then. Press the power

switch again, it shift to the normal mode. You
may use this function when you don’t’ use the
device temporary to save power.

2 - Charging the device

When the device prompts low battery, please
charge it with the carger provided.

3 - Main menu APP drawer

Make a swipe towards the top of the screen in the
home interface, the main menu APP Drawer is
appeared. It including the system setting, music
playback, video playback, web browser and other
applications you installed in the main menu APP
Drawer.

4 - Settings

Click “Settings” in the main APP Drawer to enter
the setting interface.
Click the corresponding setting items to operate.

5 - Date and Time Setting

Click “System/Date & time” in the setting interface
to set the date and time. You may set the date,
time zone, time, time format in the menu.

6 - Brightness

Select “Display” in the setting interface. Click
“Brightness level” to enter, and slide the bar to
adjust the brightness.

7 - Screen Timeout

Adjust the delay before the screen automatically

turns o. Select “Display” in the setting interface.

Click “Sleep” to enter, and click the time you want.

8 - Wi connection

Click “Settings/Network & Internet” in the APP
Drawer and click “Wi-Fi” to enter the Wi-Fi setting
interface. Click to turn on the WIFI.

9 - Bluetooth

Click “Settings/Connected devices” in the
APP Drawer and click “Bluetooth” to enter
the Bluetooth setting interface. Turn on the
bluetooth and pair a new device.

10 - Install/Uninstall and run applications

Install
There are many ways to install applications
under Android™, such as via USB, by third party
program. We introduce installation by Apps
Installer here.

Click the “Files ” in the APP Drawer. Select the

APK le you want and enter the application

installation interface. Click “Install” to install the
application automatically. After installation, it
prompts “Open” and “Done”. Click “Open” to

open the application. Click “Done” to exit.

Uninstall
You may also use the corresponding third party
software management tool or the installed
application management software of the device
to uninstall applications. Select “Setting/Apps &

notications” to select the installed applications

and check the attribute of it or uninstall it.

11 - Connect to the internet

After connecting with WIFI, open the browser
Chrome and input the web address, you can
browse the web then.

12 - Audio and video playback

Audio Playback
Click the “Play Music” in the APP Drawer to enter
the audio playback interface. It lists the audio

les in the device, and you may click the le name

to play it. In the audio playing interface, click the
icons to play/pause/ increase volume/ decrease
volume/ FF/ REW.

Video Playback
Click the “Video” in the APP Drawer to enter the

video playback interface. It lists the video les in
the device, and you may click the le name to play

it. In the video playing interface, touch the screen
to pop-up the operation icons and click the
icons to play/pause/ increase volume/ decrease

volume/ skip to next le/skip to previous le.

13 - Picture viewing

Click “Photos” in the main menu to enter the
picture folder list. Select and click the folder
you want to enter, it displays the pictures. Click
the thumbnail of the picture to view it. Touch
the screen to pop-up the operation icons while
viewing the picture.

14 - Camera Device specications

Click “Camera” in the main interface.
The camera has 2 modes. Camera and Video
mode.

Camera Mode
Click on the camera to take a picture. Click on the
camera settings cog wheel to set the resolution
and quality, capture sound and set the save
location.

Video Mode
Click on the video icon to start recording a video.

15 - Connect with a external device

Connect the device with the PC via the USB cable.
The PC appears two new disk symbols after
connected successfully. One is the TF card, and

the other is the built-in ash.

To enable data transfer, got to settings/
connected devices/ USB.

16 - Troubleshooting

What if the device is abnormal during operation?

1) Reboot the device to see if it works OK.

2) Charge the device by the charger to activate
the battery. Make sure it has power before you
operate it.

3) It is suggested to upgrade the OS of the device
by professional.

Why the standby time is so short sometimes?

The use time of the battery is all depend on
the temperature and use instance. If the
temperature is too high or too low, the use time

of the battery might be eected. It is suggest

using the device in normal temperature. The

using time is also aected by increased volume

and frequently operation.

DISPLAY: 7”, LCD IPS 1024*600 IPS Panel
CPU: Rockchip 3126C quad core
RAM/ROM DDR3 1GB+16 GB
EXTENDED MEMORY microSD

supports up 32gb

BATTERY 2500mah Li-ion Battery
WIFI
CAMERA 2*2 MPX (FRONT AND BACK)
ALTAVOZ: INTERNAL
MATERIAL: PLASTIC
OS: Android™ 8.1 (Go edition)

Android™ is a trademark property of Google LLC.

FCC Caution：

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.
