Page 1
Micro 3000 Control Station
USER INSTRUCTIONS
Page 2
Page 2
© Mass Electronics Pty Ltd 2013
Edition 1.2 dated 19.11.2013
No part of this technical manual may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without prior written permission of Mass Electronics Pty Ltd.
Trademark
The term ‘Innotech’ used in this manual is a trademark of Mass Electronics Pty Ltd trading as Innotech Control Systems Australia.
Disclaimer
While great eorts have been made to assure the accuracy and clarity of this document, Mass Electronics Pty Ltd assumes no liability resulting from any omissions in this document, or from misuse of the information obtained herein. The information in this document has been carefully checked and is believed to be entirely reliable with all of the necessary information included. Mass Electronics Pty Ltd reserves the right to make changes to any products described herein to improve reliability, function or design, and reserves the right to revise this document and make changes from time to time in content hereof with no obligation to notify any persons of revisions or changes. Mass Electronics Pty Ltd does not assume any liability arising out of the application or any use of any product or circuit described herein; neither does it convey licence under its patent rights or the rights of others.
Page 3
Page 3
© Mass Electronics Pty Ltd 2013
Edition 1.2 dated 19.11.2013
Contents
Proprietary ........................................................................................................................ 2
Trademark ......................................................................................................................... 2
Disclaimer ......................................................................................................................... 2
About the Micro 3000 Control Station .............................................................................4
Control Station Menu Navigation ....................................................................................4
Control Station Interface .................................................................................................. 5
Control Station Primary Display ...................................................................................... 6
System Information .......................................................................................................... 6
View Controller Information ...............................................................................................6
View Control Station Information .......................................................................................6
Programming the Control Station ................................................................................... 6
Adjusting the Time and Date ..............................................................................................6
Configure Daylight Savings ................................................................................................. 6
Edit, Copy & Delete Schedules ........................................................................................ 7
Copy a Weekly Schedule ..................................................................................................... 7
Edit (Add) Weekly Schedule ................................................................................................ 7
Edit (Add) Yearly Schedule .................................................................................................7
Delete Weekly Schedule ...................................................................................................... 7
Delete Yearly Schedule ........................................................................................................ 7
View and Reset Aer Hours Time ..................................................................................... 8
Adjust Aer Hours Timer ..................................................................................................... 8
Reset Accumulated Aer Hours Run Time ......................................................................... 8
Customer Assistance ........................................................................................................8
Innotech Support ................................................................................................................8
Page 4
Micro 3000 Control Station User Instructions
Page 4
© Mass Electronics Pty Ltd 2013
Edition 1.3 dated 19.11.2013
About the Micro 3000 Control Station
The Innotech® Micro 3000 Control Station is a Human Machine Interface for the Innotech Micro 3000 Controller.
The Control Station incorporates an attractive design and intuitive Liquid Crystal Display (LCD) interface for viewing and adjusting various predefined variables on the Controller.
This user guide will help you to:
• Program the date and time,
• Program daylight savings time,
• Edit, copy, or delete schedules,
• View and clear accumulated aer hours time,
• View information about the Controller and Control Station.
Control Station Menu Navigation
The diagram below (Figure 1) illustrates the overall menu structure of the device. You can use the interface to easily navigate through the dierent menus as described in the following pages.
NOTE
Throughout this document, references to a "Control Station" refer to the Micro 3000 Control Station. References to a "Controller" refer to the Micro 3000 Controller. References to "M3K" refer to Micro 3000.
Figure 1: M3K Control Station Menu Navigation Overview
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
Default Screen
Clock After Hours (A/H)Year Schedule
OFF
ON
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
Schedule Delete
Schedule Edit
OFF
ON
Rhppm
kWh
%
Info
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
Controller
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
Control Station
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
Time
Daylight Savings
Date
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
START
Rhppm
kWh
%
Adjust A/H Time
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kW
%
Accumulated Run Time
Week Schedule
OFF
ON
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
Day Selection/Edit
OFF
ON
Rhppm
kWh
%
Schedule Delete
OFF
ON
Rhppm
kWh
%
Schedule Copy
This symbol is only visible on the Day Selection/Edit and Year Schedule Edit screen if a schedule exists.
M3K02 & M3K0 4 models only
Hold the Cent re Button for 5 seconds to acc ess the menu.
Clock Week Year After
Hours
Info
2
2
2
Pressing on the Info menu in the M3K01 & M3K03 models will show the After Hours Screen
1
1
Main
Menu
Pressing on the scree ns under the Main Menu will access the relevant settings.
Press to go back to the previous screen.
Page 5
Micro 3000 Control Station User Instructions
Page 5
© Mass Electronics Pty Ltd 2013
Edition 1.3 dated 19.11.2013
Control Station Interface
The buttons and features of the Control Station interface are shown below in Figure 2.
Figure 2: Control Station Interface
Function Procedure
Run Request / Aer Hours
Press the POWER button to cycle ON or OFF.
Adjust Set Point Temperature
Press the UP button to increase the set point, or DOWN button to decrease the set point.
Adjust Fan Speed Press the LEFT button to adjust the fan speed to the desired setting.
Enable / Disable Programmed Schedules
Hold down the LEFT button to enable or disable programmed schedules. When pro­grammed and enabled, Yearly Schedules have priority over Weekly Schedules.
Set Control Mode
Press the RIGHT button to cycle through the Automatic, Heating, Cooling & Fan Only control modes.
View Current Status
Press the CENTRE button to scroll through various information on the display. The display will show Time , Date , Control State, Set Point, Room Temperature, Ambient Temperature and Analogue Output Value. The display will return to the default screen aer 30 seconds.
Navigate Menus Use the LEFT, RIGHT and CENTRE buttons to navigate the menus.
Startup Defaults
Hold the CENTRE and RIGHT buttons to Set Default Start-up Values. The current settings are saved and the settings will be retained in case of power loss.
Table 2: M3K Control Station Operational Basics
Button Description
Power ON/OFF -
Press the POWER ON/OFF button to turn the system on or o.
Up and Down -
When adjusting a setting, use the UP button to increase the value, or the DOWN button to decrease the value.
Le Button
Use the LEFT Button to exit and return to the previous menu. Press repeatedly to return to the main menu. This button also adjusts the fan speed and enables and disables schedules.
Centre Button -
The CENTRE Button has several functions: Enter / Save / Copy / De­lete. These functions are available depending on which menu you are in, or what you are adjusting.
Right Button -
Use the RIGHT button to scroll through the dierent screens and settings.
Table 1: Control Station Buttons and Functions
ON
M3K02 & M3K0 4 models only
1
2
2 2
2
M3K03 & M3K0 4 models only
1
When Ae r Hours is disabled (set to - ---), the Power On/O butt on is disabled.
1
Primary Display
Right Button
Left Button
Secondary Display
Schedule Indicator
Up Button
Down Button
Power ON/OFF
Centre Button
Page 6
Micro 3000 Control Station User Instructions
Page 6
© Mass Electronics Pty Ltd 2013
Edition 1.3 dated 19.11.2013
Control Station Primary Display
View information about the system by pressing the CENTRE button to scroll between the screens in the order below.
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
Programming the Control Station
Access the programming menu from the default screen by pressing and holding the CENTRE button for 5 seconds. Scroll to desired parameter and adjust settings using the and buttons.
Adjusting the Time and Date
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
Press at the Clock screen.
Adjust Hour . Press . Adjust Minutes . Press .
Adjust Day . Press . Adjust Month . Press .
OFF
ON
SET
Rhppm
kWh
%
OFF
DAY
ON
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
Adjust Ye ar . Press .
Press at the Date screen.
Press at the Time screen.
OFF
ON
SET
Rhppm
kWh
%
Press at the Clock screen. Press
to display Date.
The date format is DD.MM, corresponds to 26th April. The time is 24 hour only.
Only the M3K02 & M3K04 models with Real Time Clocks can change details for Time, Date, Daylight Savings and Edit & Delete Weekly and Yearly Schedules.
Time and Da te available o n M3K02 & M3K0 4
models only
OFF
Rhppm%
OFF
DAY
ON
Rhppm
kWh
%
STOP
OFF
MONTH
ON
Rhppm
kWh
%
STOP
OFF
ON
SET
Rhppm
kWh
%
Press . Press
twice.
OFF
ON
SET
Rhppm
kWh
%
Press . Select ON or OFF.
OFF
ON
Rhppm
kWh
%
Press to turn o.
OFF
ON
Rhppm
kWh
%
Press to set the daylight s aving dates.
OFF
DAY
ON
START
Rhppm
kWh
%
OFF
MONTH
ON
START
Rhppm
kWh
%
Adjust Start Month with . Press .
Configure Daylight Savings
Adjust Stop Day with . Press .
Adjust Stop Month with . Press .
Adjust Sta rt Day with . Press .
M3K02 & M3K0 4 models only
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
View Control Station Information
At the Info scre en, press .
Press for the next screen.
At the Contro l Station screen. Press .
Press for the next screen.
Press to cycle through other inputs and b ack to the Typ e screen.
to Exit.
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
View Controller Information
At the Info scre en. Press .
Press for the next screen.
At to the Controller screen. Press .
Press for the next screen.
Press to cycle through other digital outputs and then to the next screen.
Press to cycle back to the Ty pe screen. to Exit.
Time Screen
System Information
Press and hold the CENTRE button for 5 seconds to access the Info menu.
Indicates time clock model
Indicates time clock model
DAY
MONTHSET
STARTSTOP
Rhppm
kWh
%
Press to select the CStn screen.
Page 7
Micro 3000 Control Station User Instructions
Page 7
© Mass Electronics Pty Ltd 2013
Edition 1.3 dated 19.11.2013
Edit, Copy & Delete Schedules
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
OFF
ON START
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
STOP
Edit (Add) Weekly Schedule
At the week screen. Press .
Select Day with . Press .
Press to create Schedule.
OFF
ON
START
Rhppm
kWh
%
Adjust Star t Hour . Press . Adjust Star t Mins . Press .
Adjust Stop Hour . Press . Adjust Stop Mins . Press to save and create the n ext schedule o r Press
to Exit.
Edit (Add) Yearly Schedule
OFF
ON
SET
Rhppm
kWh
%
At the year screen. Press .
OFF
ON
Rhppm
kWh
%
Press .
OFF
DAY
ON START
Rhppm
kWh
%
Adjust Sta rt Day with . Press .
OFF
ON
Rhppm
kWh
%
Select O . Press .
OFF
MONTH
ON
Rhppm
kWh
%
STOP
Adjust Stop Month . Press to save and edit nex t schedule. to cycle back to O. to Exit.
Exception to On and O (Weekly Override)
OFF
ON
Rhppm
kWh
%
Select On . Press .
OFF
DAY
ON START
Rhppm
kWh
%
Adjust Star t Day . Press .
OFF
MONTH
ON START
Rhppm
kWh
%
Adjust Star t Month .Press .
OFF
MONTH
ON START
Rhppm
kWh
%
Adjust Start Month with . Press .
OFF
DAY
ON
Rhppm
kWh
%
STOP
Adjust Stop Day . Press . 5
OFF
ON START
Rhppm
kWh
%
Adjust Start Time with . Press .
OFF
ON
Rhppm
kWh
%
STOP
Adjust Stop Time . Press to save and edit the n ext schedule. to cycle back to On. to Exit.
OFF
ON
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
OFF
ON
SET
Rhppm
kWh
%
Copy a Weekly Schedule
At the Week screen. Press .
Press to select schedule to copy. Press .
Press to copy the same sch edule to the next day or press
to Exit.
Select the Day . Select Copy with , Press .
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
At the Week screen. Press .
Select the Day with
. Press to select del. Press .
Select Schedule . Press .
Delete Weekly Schedule
OFF
ON START
Rhppm
kWh
%
Press to copy to the next day.
OFF
ON START
Rhppm
kWh
%
Press to delete the selected schedule.
OFF
ON
SET
Rhppm
kWh
%
OFF
ON
Rhppm
kWh
%
At the Year screen. Press .
Delete Yearly Schedule
Select Schedule . Press to select del. Press .
OFF
ON
Rhppm
kWh
%
Press to delete schedule.
OFF
ON
Rhppm
kWh
%
Create Schedule with .
3 Screen Visible
only if no schedule exists.
2 This symbol
is only visib le if a schedule exists.
1 M3K02 & M3K0 4
models only
2 3
1
4
4 This symbol is only
visible if a schedule exists.
Aer programming your schedule(s), ensure scheduling is enabled. See Page 5 for details.
5 If only one day exception to OFF
is required, the star t and stop day MUST be the same.
Page 8
Micro 3000 Control Station User Instructions
Page 8
© Mass Electronics Pty Ltd 2013
Edition 1.3 dated 19.11.2013
Innotech Support
Innotech provides technical information on the Web to assist you with using its products. At www.innotech.com.au, you can find technical manuals, user instructions, and data sheets for all our products.
For direct product support or product information, contact your local distributor, or an Innotech representative.
You can contact us via email, fax, or postal mail:
Website: www.innotech.com.au Email: sales@innotech.com.au Fax: +61 7 3421 9101 Mail: Innotech Control Systems
P.O. Box 292 Sunnybank QLD 4109 Australia
View and Reset Aer Hours Time
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
START
Rhppm
kWh
%
OFF
DAY
MONTH
ON
START
Rhppm
kWh
%
At the After H ours menu. Press .
Press .
Adjust using in half hour increments. Press when nished. to Exit.
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kWh
%
At the After H ours menu. Press .
After reset, Press
to Exit.
Press and hold to reset hour s.
Adjust Aer Hours Timer
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kW
%
Press to select Run Time. Press
to view After
Hours Run T ime.
Not display ed if Accumulated Run Time is ze ro
Each pre ss of the Aer Hour s button (Power But ton) at the default sc reen will add 0. 5 hours to the Accumu lated Aer Hour s Tota l.
Reset Accumulated Aer Hours Run Time
OFF
DAY
MONTH
ON
SET
STARTSTOP
Rhppm
kW
%
Aer Hour s Manual On/O  setting screen
Aer Hour s range is MAN to 24:00 hour s (0.5 hour increme nts).
When MAN is set, the con troller operate s in Manual On/O mode .
If using Ma nual On/O mode, d isable the sche dules by pressing and hold ing the le butto n from the default s creen.
Aer Hour s default is 2 hour s.
MAN is th e default setti ng for the M3K01 & M3K03 non -timeclock models.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
