Page 1
Designed by
Innotech
support@myinnotech.com
832-964-5182
www.myinnotech.com
Page 2
OPERATING INSTRUCTIONS
Batteries installation
For CR2032 Model:
Make sure to remove the
battery pull-tab from the
back of your scales battery
hatch before using the
scale for the first time.
lace the scale on a hard flat surface (not carpet) to ensure
P
t
he greatest accuracy and reliability.
or AAA Model:
F
Insert the new batteries, making
sure the plus and minus(+/-)
poles are aligned properly
according to the diagram inside
the compartment.
Step onto the measurement platform
Stand with your weight evenly distributed on the measurement
platform and remain still until the measurement is complete.
2
Page 3
AUTO OFF
When you step off the scale, it will automatically switch off.
CALIBRATION
Simply place it on a hard, flat surface, then press it awake and
let it zero out. The scale will be calibrated once it goes to zero,
and then you can step on and reweigh yourself.
LOW BATTERY INDICATOR
The scale will display “ ” when the battery is low, please
replace the batteries immediately with two CR2032 batteries.
3
Page 4
OVERLOAD INDICATOR
When the scale is overloaded (over 397lb/180kg), the screen
will show “ Err ”. Please remove the weight immediately to
protect the scale.
MEASURING UNITS
lb pound
kg kilogram
st stone
Change the unit
You can change the unit to lb, kg or st by pushing the button
on the back of the scale.
POWER
Battery: CR2032 coin battery x2
Please read this instructions carefully before using this scale.
or AAA x 3
4
Page 5
CLEANING,MAINTENANCE,AND DISPOSAL
Cleaning
You can clean your scale using a lint-free cloth
dampened with water. If water is not enough to clean
it, you can also use a mild dish washing soap.
Changing the batteries
Open the battery cover, remove the old batteries and
replace it with new batteries.
Disposal
Dispose of this device in accordance with your local
regulations. Batteries should be disposed of separately from
household waste.
5
Page 6
TECHNICAL SPECIFICATIONS
Equipped with high precision gauge sensor
••Safety tempered glass platform
•
Capacity: 5kg-180kg/397lb
•
Graduation: 0.05kg/0.1lb 1/8 lb
•
Weight unit: lb / kg / st
•
Minimum weight: 5kg
•
Display: Negative LCD display
•
Automatic zero resetting
•
Auto-off function
•
Overload indicator
Working temperature: 32°F-104°F / 0°C-40°C
•
•
Working humidity: ≤90% RH
•
Storage temperature: -4°F - 140°F / -20°C- 60°C
6
Page 7
GENERAL ADVICE
•
Do not step on the scale when the surface or your feet
are wet to avoid slipping.
•
Protect the scale from hard knocks, moisture, dust,
chemicals, drastic changes in temperature, electromagnetic fields and sources of heat that are too close.
•
Never step on the edge of the scale, it could cause the
scale to tip.
•
Remove the batteries if the scale is not being used for a
long time.
•
Do not jump on the scale.
7
Page 8
Designed by Innotech
