Page 1
INSTALLATION MANUAL
Centauri Series
Cree COB LED Spotlight
Your reliable LED lighting partner.
R
innovation. efficiency. sustainability.
www.innogreen-usa.com
InnoGreen USA, LLC
200 Innovation Boulevard, Technology Center
Suite 241, State College, PA 16803 USA
Phone: +1 814 272 0087
Fax: +1 814 272 0376
Email: [email protected]
InnoGreen Middle East Trading Company, LLC
Suite 601, Arenco Tower, Dubai Media City
PO Box 500403, Dubai, United Arab Emirates
Phone: +971 4 433 1251
Fax: +971 4 434 1289
Email: [email protected]
InnoGreen Canada, Incorporated
7703 Boulevard Newman, Suite 203
Lasalle Quebec, H8N 1X7 Canada
Phone: +1 514 508 9588
Fax: +1 514 508 9545
Email: [email protected]
InnoGreen Europe Limited
1 Hanger Green, Park Royal W5 2EL
London, United Kingdom
Phone: +44 208 930 2801
Fax: +44 792 221 2222
Email: [email protected]
Page 2
DESCRIPTION
Inn oGree n LED spo tligh t’s hea t sink is m ade of di e-cas t alumi num wit h sandb laste d silve r surfa ce fini sh.
Eff icien t heat di ssipa tion wi th cutt ing-e dge des ign. Ut ilize s CREE CO B chip fo r bette r durab ility .
Mos t commo n areas o f appli catio n are hot els, me eting r ooms, o ffice s, hosp itals , schoo ls, fac torie s,
com merci al ligh ting, s hoppi ng mall s, kitc hens, s howro oms, in door li ghtin g etc.
DESCRIPTION
DESCRIPTIONPARAMETERS
> 0.375A
Curren t (Max)
> 0.1A Other __ ________
Dimmab le
Dimmin g
- 20 to 40 deg C
Applic ation Enviro nment
Protec tion against E lectric Shoc k
IP20
IP Ratin g Lens Ang le:
Non-di mmable
DESCRIPTIONDIMENSIONS
INSTALLATION DRAWING
MR16 Gu10
INSTALLATION AND MAINTENANCE
1. Check if all the parts and accessories are enclosed.
2. Be sure to disconnect any power before installation.
3. Make sure the product is rmly mounted to lamp base before turning on the power supply.
SAFETY PRECAUTIONS
● Product is for indoor use only.
● Don't install around a humid environment.
● Don't drop, scratch, or squeeze the bulb.
● Don't take apart the product or replace mechanical and electronic components.
● Maintain safe distance from paper, fabric or other inammables.
● Tighten the bulb base into socket to prevent falling out.
● Don't touch the bulb with ngers after lamp works for some time. Bulb temperature is quite warm.
● Do not stare at the strong light for along time as it may cause injury to eyes.
The product should not be used for:
● For xtures and circuits with dimming functions unless specied.
● For xtures with internal control circuits (not including those which are ofcially allowed).
● For conventional direction lamp or exit lights.
● For mercury vapor lamps, sodium lamps or HID lamps
● For airtight or mechanically sealed xtures.
> 0.9
Power Fa ctor
Units: (mm)
20 deg Other __ ________
Gu10: 10 0 to 240V
Input Vo ltage
MR16: 12 V/24V AC/DC Other __ ________
INDOOR
CREE
20
o
Gu10
MR16
49.5
58.0
22.0
50
22
49.5
