Professional Series
Page 1 of 2
www.innofil3D.com | info@innofil3d.com | PO Box 1146 | 7801BC Emmen | The Netherlands
Preparation date: 14-03-2018
Version No.: 1.0
Technical Data Sheet
PAHT CF by Innofil3D BV
Filament suitable for all commercially available leading brands 3D FDM/FFF printers
IDENTIFICATION OF THE MATERIAL
Trade name
PAHT Carbon Fiber
Chemical name
High temperature Polyamide with carbon fiber
Chemical family
Thermoplastic copolymer
Use
3D-Printing
Origin
Innofil3D BV
GUIDELINE FOR PRINT SETTINGS
Nozzle temperature
260 – 280 °C
Bed temperature
>50 °C
Bed modification
Clean glass
Active cooling fan
0%
Layer height
Minimum of 0.2 mm
Shell thickness
1.2 mm
Print speed
40 – 60 mm/s
Additional information
Nozzle diameter 0.6 mm minimal
Settings are based on a 0.6 mm nozzle
MATERIAL PROPERTIES
Test Method
Melt temperature
235 °C
ASTM D3418
Glass transition temperature
N/A
ASTM D3418
Melt Flow Rate
1
70.9 g/10 min
ISO 1133
Melt Volume Rate
1
66.6 cm3/10 min
ISO 1133
Density
1.18 g/cm3
ASTM D1505
Odor
Very little odor
/
Water solubility
Insoluble
/
1
Test conditions: T = 280 °C ; m = 5 kg
Professional Series
Page 2 of 2
www.innofil3D.com | info@innofil3d.com | PO Box 1146 | 7801BC Emmen | The Netherlands
MECHANICAL PROPERTIES*
Test Method
Tensile Strength
170 MPa
ISO 527
Elongation
2 %
ISO 527
E modulus
15 GPa
ISO 527
Charpy Impact Strength
47 kJ/m2
ISO 179
*
Data based on information obtained from the raw material supplier(s).
FILAMENT SPECIFICATIONS
Test Method
Diameter 1.75
1.75 ± 0.05 mm
Innofil3D
Diameter 2.85
2.85 ± 0.10 mm
Innofil3D
Max. roundness deviation 1.75
0.05 mm
Innofil3D
Max. roundness deviation 2.85
0.10 mm
Innofil3D
Net weight on reel
750 g ± 2%
Innofil3D
LIST OF COLORS AND CERTIFICATIONS**
Colour
Code
RAL nr.
Certifications/approvals
10/2011
1
FDA
2
2011/65
3
EN 71-3
4
Black N/A - - - -
**
This overview is generated using information obtained from the raw material supplier(s).
Certifications/approvals
Description
1
Regulation EU No 10/2011:
Union Guidelines on Regulation (EU) No 10/2011 on plastic materials
and articles intended to come into contact with food (Europe)
2
FDA:
Food and Drug administration approval (U.S.A.)
3
Directive 2011/65/EU:
The restriction of the use of certain hazardous substances in
electrical and electronic equipment (Europe)
4
Directive 2009/48/EC; EN 71-3:
Safety of toys – Part 3: Migration of certain elements (Europe)
