PN: C30703-08D6X-1710VA38
UPC: 83516800160-2
GPU Engine Specs:
CUDA Cores 5888
Boost Clock (MHz) 1785
Memory Specs:
Memory Clock (Gbps) 14.0
Memory Size (GB) 8.0
Memory Type GDDR6
Memory Interface Width 256-bit
Memory Bandwidth (GB/sec) 448
Feature Support:
Real-Time Ray Tracing Yes
NVIDIA GeForce Experience Yes
NVIDIA Ansel Yes
NVIDIA Highlights Yes
NVIDIA G-SYNC Compatible Yes
Game Ready Drivers Yes
Microsoft DirectX 12
Vulkan API Yes
OpenGL 4.6
Bus Support PCIe 4.0
Windows 10 Ready Yes
Linux Ready Yes
FreeBSDx86 Ready Yes
Display Support:
Max. Digital Resolution@60Hz 7680x4320
HDCP 2.3
HDMI 2.1 x1
Display Port 1.4a x3
EMAIL: sales@inno3d.com
The new NVIDIA GeForce RTX 30 Series GPUs, the 2nd generation of RTX,
features new RT Cores, Tensor Cores and streaming multiprocessors, bringing
stunning visuals, amazingly fast frame rates, and AI acceleration to games and
creative applications. Powered by the NVIDIA Ampere architecture, which
delivers increases of up to 1.9X performance-per-watt over the previous
generation, the RTX 30 Series effortlessly powers graphics experiences at all
resolutions, even up to 8K at the top end. The GeForce RTX 3090, 3080 and 3070
represents the greatest GPU generational leap in the history of NVIDIA.
Card Photos
Board Dimensions:
Length (mm) 300
Height (mm) 135
Width 3-slot
Power Specs:
Max. Board Power (W) 240
Min. System Power (W) 650
Ext. Power Connectors 8+8-pin
Accessories:
Quick Start X1
Power Guideline X1 Type Color Box DIM(LxWxH) PCS/CTN Master DIM. (LxWxH) G.W. Volume
Disclaimer: All specifications (i.e. PCB, components etc) are subject to change without notice. Last Update: 19 / 10 / 2020
Product Packing Information
BOX 390 x 112 x 230mm 5 610 x 416 x 245mm 11.14 0.06cbm
