PARTS LIST
LISTE DES PIÈCES DÉTACHÉES
LISTA DE PIEZAS
A Top panel (1)
B Bottom panel (1)
C Front right panel (1)
D Front left panel (1)
E Front left and right side panels (2)
G Back left and right side panels (2)
H Back panel (1)
K Glass shelves (3)
screws (12)
dowels (16)
rubber feet (5)
shelf supports (6)
glue tube (1)
hex wrench (1)
Missing parts? Call 877-433-5776
Des pièces manquantes ? Appeler le (877) 433-5776
¿Faltan piezas? Llame al (877) 433-5776
A
G
H
E
D
K
G
K
K
1 Assemble front and front side panels 3 Assemble bottom and front panels
E
E
D
C
Note: panel ends with
small holes should
face up
(4) dowels
B
E
D
C
(6) screws
E
Tool required: mallet
screws [12) dowels (16) rubber feet (5)
E
B
C
2 Assemble bottom, back, and back side panels
B
G
H
G
(6) screws
4 Apply rubber feet to bottom panel*
Remove paper backing
before applying pad
(5) rubber feet
B
shelf supports (6) glue tube (1) hex wrench (1)
5 Install shelf supports
(6) shelf supports
G
7 Attach top panel
*not necessary on carpeted surfaces
ASSEMBLY INSTRUCTIONS
(12) dowels
INSTRUCTION DE MONTAGE
INSTRUCCIONES DE MONTAJE
A
glue tube (1)
6 Install glass shelves
Apply drop of glue to
each hole before
inserting dowel, then
again to top of dowel
B
Dry overnight for maximum strengthDry overnight for maximum strength
K
Enjoy your new TV stand!
Note: Do not put anything on the TV stand until the top panel is in place
20.9" (53.1 cm)
PR-TV101/102
TV STAND
40.16" (102 cm) 22.05" (56 cm)
