User manual
Thank you for purchase our music player for the car. Now, has a complete set of MP3 and WMA
music playback, w ith which you will enjoy y our trips with family or f riends. To make a proper us e
of this device, please, read this instruction manua l carefully before shut it on.
WIRELESS MP3 PLAYER FOR
HOM
E AND
CAR
INTRODUCTION
What’s CAR MP3?
CAR MP3 is a simply MP3 playe r that uses an internal FM trans mitter for transfer the so ngs to the
car radio.
How it works?
Thanks to its small radio transm itter, broadcast the music stored in y our memory like a local radi o
station involv ed, but with much lower pow er emission.
How it listen?
Since this is a small radio t o listen to just turn on a radio receiver and tune the radio station of the
CAR MP3.
GENERAL FUNCTIONS
• Designed for use in home or in a car.
• Supports MP3 and WMA music formats.
2
User manual
• Range of FM broadcast frequencies available between 87.5MHz and 108.0MHZ.
• Auto run when you insert the player into the cigarette lighter of your car or USB plug power.
• Re sume automatically after cut off electricity supplies.
• Inte grated Equalizer: Normal, Rock, Ambient,
• Works with control buttons and remote control.
Jazz, and
SRS.
USE TROUGHT INTEGRATED KEYS
Button C
Enter the menu selection freque ncy. This is determined by which station
will broadcast the M P3 music on our way through our car radio.
Button >>|
Forward button. In the frequency se lection mode, allows the top line
number. In playback mode, allowing moving songs.
Button |<<
Backward button. In the frequency selection mode , allows the tuning
down. In playback mode, it allows backward songs.
3
USE TROUGHT REMOTE CONTROLLER
Button >|
Play button. Let’s start playing or paus e the song displayed in the screen.
Button >>|
Forward button. In the frequency se lection mode, all ows tuning up. In
playback mode, it allows forward songs.
Button |<<
Backward button. In the frequency selection mode, allows tuning down.
In playback mode, it allows backward songs.
CH+ button
Up button frequency. Up 0.1MHZ the rad io transmitter frequency .
CH- button
Down button frequency. Down 0.1MHZ the radio t ransmitter frequency.
VOL+ button
Volume up button. Let’s turn up the volume of MP3.
VOL- button
Volume down button. Let’s turn down the volume of MP 3.
EQ button
EQ button. Allows you to select one of the EQ pre sets (Normal, Rock,
Ambient, Jazz, and SRS).
Numeric panel
Allows you to select the number s ong that you want to play.
User manual
4
HOW ADD MUSIC IN THE PLAYER?
1 .- Plug the device into the USB port of you r computer. See picture below for example:
User manual
2 .- Open "My Computer" and locate the new unit that will appear in your system.
3 .- Copy the songs that you want in M P3 or WMA format to play w ithin this unit.
4 .- Once you have copied all the songs, you can disconnect it from yo ur computer. The device is
ready to use in your home o r car.
HOW IT WORKS IN THE CAR?
1 .- Boot your car to allow t he implementation of his car radio and M P3 player.
2 .- Look at the way your car radio free radio emis sion. To recognize, locate a ll the frequencies
5
until you find a free space where you do not hear any music or voice broadcast. Once you have
found a freely number of frequency, note the frequency, since it should make when you get to
step 6.
3 .- Connect your MP3 into your car adapter included in the box. View image
User manual
4 .- Connect the whole CAR MP3 connector in the cigarette lighter of your car. View image below:
6
User manual
5 .- After connecting the MP3, will pow er on and display a logo on your scree n. Then, be ready to
operate.
6 .- Press the "CH" key located at down of the player to enter the selection mode emission line.
7 .- Select, using the |<< and >>| to get a free line emission. In this way, will complete the setup of
your CAR MP3.
If you performed the above steps correct ly, you should be listening to music s tored on your CAR
MP3 by the speakers of your car trough your car radio.
7
User manual
8
TROUBLESHOOT
No power on
Make sure the MP3 adapter car connector is inserted.
Verify that the connector of the car is powered with 12V concerned.
Not detect anything when is plugged i nto a computer.
Make sure the MP3 is plugged into a USB port enabl ed. It is always better to connect in the
back of your computer.
Re-install the motherboard drivers of your computer.
The radio does not detect the emission of the MP3.
Check that your car that is using that band ra nge FM.
Verif y that the radio i n your car is tuned the same as configured in your MP3.
To listen to your CAR MP3 please e nsure that both the MP3 player and the car stereo are tuned to the
same radio channel. Please ensure that the radio channel is free as otherwise radio interference will
affect the quality of the sound. Duri ng a journey different radio signals may interfere with the sound,
this may mean you need to change radi o channels.
Interference once tuned CAR MP3
Find a station which does not receive any radio signal. If you receive some sort of issue that is
not the MP3 itself, it will cause interference.
You can remove noise by increasing the volume of MP3. If the volume is very high, it can produce
distorted sound. In that case, try to gradually lower the volume until the distortion di sappears.
You can’t download the songs
Check USB connectio n is correct.
Check the operating system is Win2000 or higher.
Not play any song and they are all copied into the MP3
Make sure all the songs are copied into the main directory of the MP3. If the songs are copie d
organized by folders, the MP3 doesn’ t detect.
Not allowed to copy more than 600MB when transferring songs to MP3.
MP3 format with the file system ca lled FAT32.
The electrical and electronic equipment (EEE) contains materials , parts and chemicals
that may be hazardous to the environment and harmf ul to human health if the
disposal of e lectrical and electronic equipment (EEE) is unsucces sful.
Equipment marked with the WEEE logo (shown at left) should not be discarded with
household waste. Contact your local waste management, which can provide details
Through this, the manufacturer declares that the product complies with CAR MP3 essential
requirements and other re levant provisions of Directive 19 99/5/EC required.
If you want a copy of the EC Declarat ion of Conformity can be found at:
http://www.ingodevices. net/productos/descargas/3/confCE_ingo_carmp3.pdf
Specifications are subject to change without notice. It is prohibited to reproduce, transfer all or
part of this document by any means electronic or mechanical, including photocopying and
recording, or tra nslated into another language without the prior written consent of
the manufacturer. All trademarks and logos are the prope rty of their respective owners .
about the recycling options available in y our area.
