Operator’s Manual
Issue 1
PS20/30
Z-fold
C-fold
V-fold
Contents
1. Introduction
General ........................................ 1
Which side is which? ................................. 2
How to use this manual ................................ 3
Safety precautions................................... 4
Operating environment................................. 4
Power requirements .................................. 5
If the PS20/30 is damaged............................... 6
2. Features
General ........................................ 7
Folder components .................................. 8
Form guides ................................... 8
Feed roller .................................... 8
In-feed tray.................................... 8
Fold plates .................................... 8
Fold rollers .................................... 8
Operator controls ................................... 9
Forms counter .................................. 9
Green start button ................................ 9
Red stop button ................................. 9
Jog function ................................... 9
Power and safety components ............................ 10
Mains lead ................................... 10
Power inlet ................................... 10
Lid....................................... 10
Sealing components ................................. 10
Pressure bolts ................................. 10
Sealing rollers.................................. 10
PS20/30 Iss. 1. Page v
3. Set-up
Setting up the PS20/30................................ 11
Opening the lid .................................... 12
Removing the first fold plate ............................. 13
Removing the second fold plate ........................... 14
Replacing the fold plates ............................... 15
Setting up the folder ................................. 16
C fold set-up .................................. 16
Z fold set-up .................................. 18
V fold set-up .................................. 20
Adjusting the form guides ............................ 22
4. Operation
General ....................................... 23
Operating process .................................. 23
Loading forms .................................... 24
Starting up and testing the PS20/30 ......................... 25
Verifying folder settings ............................. 26
Processing forms .................................. 27
Interrupting operation .............................. 27
5. Operation Errors
Error Conditions ................................... 29
Clearing mishandled forms .............................. 29
Jam in folder .................................. 29
Jam after folder ................................. 31
Pressure sealer bolt release ........................... 31
Troubleshooting ................................... 33
Page vi
PS20/30 Iss. 1.
6. Cleaning the PS20/30
Cleaning procedure.................................. 37
7. Specifications
Folder/Sealer Specifications ............................. 39
Construction .................................. 39
Sealer...................................... 39
Size....................................... 39
Weight ..................................... 39
Power ..................................... 39
Speed ..................................... 39
Environment .................................. 40
Feeder Capacity................................. 40
Noise ...................................... 40
Form Specification .................................. 40
Weights..................................... 40
Sizes ...................................... 40
Fold Configuration ............................... 40
Appendix A - Form Loading Guide
Service Visit Log
PS20/30 Iss. 1.
Page vii
1. Introduction
General
The PS20/30 Folder/Sealer produces finished mailable documents or "self-mailers" from
cut-sheet Pressure Seal forms. In one smooth operation it folds and seals single sheets
into self-mailers quickly and economically. Pressure activated cohesives provide an
instantly secure seal on all sides of the form, whether you use a "V", “C” or “Z” fold.
Features include:
•
Simple to load and operate
•
Easy to change the fold styles
•
C, V, offset V and Z fold styles
•
No adjustment required when changing the weight of forms used
•
Automatic stop when the in-feed tray is empty
•
In-feed forms electronic counter with reset (optional on PS20)
•
Form flow error detection
This operator manual describes the set-up and operation of the PS20/30 and is written as
a reference for an operator who is familiar with mailing operations and has received some
basic training in operating this model.
PS20/30 Iss. 1. Page 1
Figure 1: Types of fold produced
Which side is which?
The terms Front and Rear are used throughout this manual to identify the sides of the
PS20/30.
•
The Front contains the In-feed (where forms are loaded), the operator controls, power
connector and on/off switch.
•
The Rear contains the outfeed (where the forms exit after processing).
1. Introduction
Page 2
PS20/30 Iss. 1.
Figure 2: The sides of the PS20/30
How to use this manual
Here is a summary of what is contained in this manual and where:
•
Features (page 7) - describes the major components you use to set up and operate the
PS20/30. New operators should read this section to gain a basic understanding of how the
PS20/30 works. Experienced operators should read this section when they have a specific
question about the function of a particular feature.
•
Set-up (page 11) - outlines the tasks required to set up the PS20/30. Provides easy
step procedures for opening the lid, removing the fold plates and setting up the folder.
New operators should read each procedure as they perform the task. Experienced
operators should refer to relevant parts of the procedure to find answers to specific
questions.
•
Operation (page 23) - provides easy step-by-step procedures for loading and starting
the PS20/30.
•
Operation errors (page 29) - lists common operating problems and possible causes
and solutions.
•
Cleaning (page 37) - provides details of the cleaning required to keep the PS20/30 in
the best possible condition.
•
Specifications (page 39) - provides the technical details of the folder/sealer.
•
Form loading guide (page 41) - explains how to load forms based on the form
design, type of fold, condition of forms (if they are curled or not), and how the
folded/sealed forms should be orientated.
1. Introduction
PS20/30 Iss. 1. Page 3
Safety precautions
Although the design of your folder/sealer includes safeguards for set-up and operation,
yo
u must adhere to the following precautions.
Operating environment
•
Dress safely. Loose clothing, long hair and jewellery can become tangled in moving
parts.
•
Keep your work area and the PS20/30 clean and clear of dust or debris. Details of
ho
w to clean the PS20/30 thoroughly are given in Section 6 .
•
Do not place the PS20/30 on an unstable stand or table. The machine may fall,
causin
g serious damage or injury.
To avoid personal injury and damage to the PS20/30, it should
alway
s be lifted by two people.
•
Do not allow anything to rest on the mains lead. Do not relocate the machine where
anyon
e will walk on the mains lead.
•
Operate the machine only with the lid in place, the forms properly loaded in the in-feed
tra
y and the catch tray initially empty.
•
Keep hands clear of the in-feed and out-feed areas when the machine is running.
Except as explained elsewhere in this operator manual, do not
attemp
t to service the PS20/30. Doing so may expose you to
dangerou
s voltages or other risks. DO NOT REMOVE THE
PROTECTIV
E SIDE COVERS FROM THE PS20/30. Refer servicing to
an authorized service representative. Only trained, authorized
servic
e representatives should remove the protective side covers -
an
d then only for servicing purposes.
1. Introduction
Pag
e 4 PS20/30 Iss. 1.
Power requirements
The PS20/30 must be operated from the type of power source indicated on the voltage
setting label (see Figure 3). If you are unsure of the type of power available, consult your
authorized service representative or local power company.
1. Introduction
PS20/30 Iss. 1. Page 5
Figure 3: Voltage Setting Label Location
If the PS20/30 is damaged
Switch off the machine's power, unplug the PS20/30 from the wall outlet and refer
servicing to an authorized service representative under the following conditions:
q
If the mains lead is damaged or frayed
q
If liquid has been spilled into the PS20/30
q
If the PS20/30 has been exposed to rain or water
q
If the PS20/30 has been dropped or damaged
q
If the PS20/30 does not operate normally when the operating instructions are
followed. Adjust only those controls that are covered by the operating instructions,
since improper adjustment of other controls may result in damage.
q If the PS20/30 exhibits a distinct change in performance, indicating a need for a
service
1. Introduction
Page 6
PS20/30 Iss. 1.
2. Features
General
This section guides you through the features of the PS20/30. The component names
introduced in this section are used throughout this manual.
Please refer to Figure 4 below as you read about the features of the PS20/30.
PS20/30 Iss. 1. Page 7
Figure 4: Features of the PS20/30
Folder components
Form guides
The form guides keep the forms aligned so the feed roller feeds each one squarely. The
right-hand form guide is adjustable to accommodate various sheet widths.
Feed roller
The feed roller provides reliable single-sheet form feeding into the folding area. The feed
roller requires no adjustment.
In-feed tray
The in-feed tray holds the stack of forms allowing them to be fed by the feed roller. The
spring-loaded tray presses the forms against the feed roller, automatically providing the
correct pressure to allow only one form at a time to be fed into the folder.
Fold plates
These provide for simple "V" (centre or half) folds, "Z" (zigzag) folds or "C" (letter) folds.
The fold plates are adjustable to accommodate various form lengths.
Fold rollers
The fold rollers work in conjunction with the fold plates to produce folds. The rollers feed
the form into and out of the fold plates. The top roller is removable, which aids recovery
of mishandled forms (see page 29).
2. Features
Page 8
PS20/30 Iss. 1.
Operator controls
Forms counter (optional on PS20)
The forms counter on the panel below the in-feed indicates the number of forms in the current
batch (since it was last reset) and is set to zero by pressing the Reset button on the counter.
Green start button
Pressing the Green start button processes the forms in the in-feed tray.
Red stop button
Pressing the Red stop button stops the PS20/30 after the form currently being fed is
processed. You can stop the PS20/30 at any time while forms are processing.
Jog function
Pressing and holding down the Red Stop button and then pressing the Green Start button
operates the jog function. This operates the PS20/30 without feeding paper (see Clearing
mishandled forms on page 29).
2. Features
PS20/30 Iss. 1. Page 9
Figure 5: Operator controls
Power and safety components
Mains lead
The mains lead supplies electrical power to the PS20/30.
Power inlet
The power inlet contains a fuse that prevents excess current from entering the machine.
Should the fuse need replacing, the fuse holder can be pulled out and a new fuse inserted
(see Figure 3 on page 5).
Lid
The lid provides access to the folding components. The lid has two safety switches, these
disable operation of the PS20/30 when the lid is raised or not properly closed.
P
Note: The lid has a pre-determined upright position and must only be opened to this
position, any further may result in damage to the machine.
Sealing components
Pressure bolts
These allow you to release the pressure on the sealing rollers for clearing mishandled
forms. These bolts can be loosened using the allen key provided (see page 32).
Sealing rollers
The sealing rollers provide the pressure required to tightly seal the edges of the form.
2. Features
Page 10
PS20/30 Iss. 1.
3. Set-up
Setting up the PS20/30
This section provides instructions for:
•
Opening the lid
•
Removing the fold plates
•
Setting up the folder
Follow all the instructions in this section the first time you use the PS20/30 and whenever
you need to process a different style of form. Refer to the first two topics in this section
when you need to access folding and sealing components.
I
When accessing the folding or sealing components on the PS20/30
or any adjustments are being made, the power should be
disconnected from the machine.
PS20/30 Iss. 1. Page 11
Opening the lid
1. Switch the PS20/30's power off and unplug it from the mains outlet.
2. Lift the PS20/30's lid from the machine's front until it reaches its
pre-determined upright position.
3. When closing the lid, ensure it is properly in place. If the lid is not closed
properly the machine will not operate.
3. Set-up
Page 12
PS20/30 Iss. 1.
Figure 6: Raising the lid
Removing the first fold plate
1. Raise the lid.
2. Remove the two knurled knobs that secure the first fold plate.
3. Pull the fold plate out of the machine at approximately 45°.
3. Set-up
PS20/30 Iss. 1. Page 13
Figure 7: Removing the first fold plate
Removing the second fold plate
1. Raise the lid.
2. Grasp the second fold plate and pull it towards the fold rollers while lifting. This
will disengage the fold plate locators from their mounting studs.
3. Pull the fold plate away from the machine at approximately 45° and then clear
of the lid.
3. Set-up
Page 14
PS20/30 Iss. 1.
Figure 8: Removing the second fold plate
Replacing the fold plates
1. Slide the first fold plate into the machine, ensuring the locators are positioned
on the mounting studs. Secure the fold plate to the support bar with the two
knurled knobs.
2. Slide the second fold plate into the machine until the locators on each side of
the plates lock onto their respective mounting studs. Apply pressure to the rear
corner of fold plate until the rear fold plate locators lock into position.
3. Set-up
PS20/30 Iss. 1. Page 15
Figure 9: Replacing the fold plates
Setting up the folder
Once you've raised the lid into its predetermined upright position setting up the PS20/30’s
folder is carried out as follows:
P
Fold plates can be adjusted in situ.
C fold set-up
Refer to Figure 10 on page 17.
1. Measure the length of the folds required.
2. Adjust the form stop for each fold plate to the measurement you determined
previously in step 1 as follows:
· Loosen the locking knobs at each end of the form stop.
· Using the knobs as handles, slide the stop along the rods until the stop aligns
with the correct settings on the scales. Make sure the scales on each side of
the fold plate show the same settings otherwise the form will not fold squarely.
· Tighten the two locking knobs.
3. If the new form is a different width from the last form used, refer to ‘Adjusting
the form guides’ on page 22.
4. Lower the lid.
3. Set-up
Page 16
PS20/30 Iss. 1.
3. Set-up
PS20/30 Iss. 1. Page 17
Leading Edge
fold perforations
first fold
dimension
second fold
dimension
locking knobs
first fold dimension
setting
second fold dimension
setting
first fold plate
second fold plate
Figure 10: C Fold Set-up
Z fold set-up
Refer to Figure 11 on page 19.
1. Measure the length of the folds required.
2. Adjust the form stop for each fold plate to the measurement you determined
previously in step 1 as follows:
· Loosen the locking knobs at each end of the form stop.
· Using the knobs as handles, slide the stop along the rods until the stop aligns
with the correct settings on the scales. Make sure the scales on each side of
the fold plate show the same settings otherwise the form will not fold squarely.
· Tighten the two locking knobs.
3. If the new form is a different width from the last form used, refer to ‘Adjusting
the form guides’ on page 22.
4. Replace the lid.
3. Set-up
Page 18
PS20/30 Iss. 1.
3. Set-up
PS20/30 Iss. 1. Page 19
Leading Edge
fold perforations
first fold
dimension
second fold
dimension
locking knobs
first fold dimension
setting
second fold dimension
setting
first fold plate
second fold plate
Figure 11: Z Fold Set-up
V fold set-up
Refer to Figure 13 on page 21.
1. Measure the length of the fold required.
2. Adjust the form stop for the first fold plate to the measurement you determined
previously in step 1 as follows:
· Loosen the locking knobs at each end of the form stop.
· Using the knobs as handles, slide the stop along the rods until the stop aligns
with the correct settings on the scales. Make sure the scales on each side of the
fold plate show the same settings otherwise the form will not fold squarely.
· Tighten the two locking knobs.
3. If the new form is a different width from the last form used, refer to ‘Adjusting
the form guides’ on page 22.
4. Position the V-fold locating lugs of the 2nd fold plate on the V-fold locating
stubs and the rear lugs on the front fold plate locating stubs as shown in figure
12. Replace the lid.
3. Set-up
Page 20
PS20/30 Iss. 1.
Figure 12: Second-fold plate positioning
3. Set-up
Leading Edge
fold perforations
first fold
dimension
locking knobs
first fold dimension
setting
first fold plate
second fold plate
PS20/30 Iss. 1. Page 21
Figure 13: V Fold Set-up
Adjusting the form guide
Set the adjustable form guide on the in-feed tray to fit the width of the forms you are
processing as follows:
1. Raise the lid and remove the first fold plate.
2. Slacken the adjusting knob on the in-feed tray (see inset of Figure 14 ) and
widen the adjustable guide if necessary.
3. Place the forms on the in-feed tray and align their left edge with the fixed form guide.
4. Holding the forms in place, align the adjustable guide with the right-hand side of
the forms.
P
The form guides need to provide enough, but not too much clearance at
the sides of the form stack to eliminate misfeeding problems.
5. Secure the adjustable guide in place by tightening the adjusting knob.
3. Set-up
Page 22 PS20/30 Iss. 1.
Figure 14: Adjusting the form guides
4. Operation
General
This section explains in detail how to:
•
Load forms
•
Start up and test the machine
•
Process forms
Any problems that arise from the operation of the PS20/30 are addressed in the next
section, which includes a troubleshooting guide.
Operating process
Operating the machine is a simple three-step process:
1. Verify the machine is set for the fold style required by the forms and the catch
tray is pulled out into position.
2. Place the forms in the in-feed tray and adjust the form guide if necessary (see
page 22).
3. Start the machine.
I
Apart from adjusting the fold plates and clearing mishandled forms,
no internal adjustments should be made to the PS20/30. If
adjustments are needed, contact an authorized service
representative.
PS20/30 Iss. 1. Page 23
Loading forms
1. When you load forms make sure:
•
Visually check to see there are no mishandled forms in the folder. If there
are mishandled forms, refer to Clearing mishandled forms on page 29.
•
The fold rollers are clean and free of foreign matter
2. Fan the stack of forms to make sure they are not sticking together.
3. Align the stack so the forms feed correctly into the PS20/30. Form orientation depends
upon form design, the type of fold desired, presence of curl, and how the fold plates
are set up (see page 41).
4. Align the stack of forms so that the ends and sides of the stack are smooth and
square.
5. Raise the in-feed tray by lifting the handle.
6. Feed the stack between the form guides and into the PS20/30 until the stack
meets the guide plate.
7. Lower the in-feed tray.
8. Make sure the stack of forms is flat and not bowed due to the form guides
being too tight.
4. Operation
Page 24
PS20/30 Iss. 1.
Starting up and testing the PS20/30
This procedure describes how to start up and test the PS20/30 to make sure it is ready
to fold and seal your forms. Always perform this procedure at the start of each form
processing session to ensure the best results.
Before you start up and test the PS20/30, make sure all of the following conditions are
satisfied:
•
The fold plates are adjusted and installed properly for the fold you want.
•
The form guides are set correctly to provide enough, but not too much, clearance at
the sides of the form stack.
•
The lid is closed.
•
Forms are properly loaded.
•
The catch tray is pulled out into position.
4. Operation
PS20/30 Iss. 1. Page 25
Verifying folder settings
1. Press the green start button. The machine will process the first form only.
2. Check the form for proper fold and seal. Check that the folds are in the proper
place.
•
If the first fold is in the wrong place, adjust the first fold plate.
•
If the second fold is in the wrong place, adjust the second fold plate.
I
Make certain the first fold is correct before adjusting the second.
4. Operation
Page 26
PS20/30 Iss. 1.
Address
Address
Address
Figure 15: First and second folds
Processing forms
Before proceeding, make sure you have started up and tested the PS20/30 and that the
test form is properly folded and sealed.
1. Press the green start button and hold for more than one form.
The PS20/30 processes all the forms loaded, until the in-feed tray is empty.
The PS20/30 stops automatically after the last form is processed.
2. Remove the sealed forms from the catch tray.
3. When you have finished using the PS20/30, turn it off at the mains outlet.
Interrupting operation
Press the red stop button at any time to cease processing (if the PS20/30 is processing
a form when the red stop button is pressed, it will finish the current form).
I
Do not stop the PS20/30 by opening the lid as this may cause
damage.
4. Operation
PS20/30 Iss. 1. Page 27
5. Operation Errors
Error Conditions
In the event of a problem existing that prevents the PS20/30 from operating, follow the
instructions in this section.
Clearing mishandled forms
Jam in folder
If there is a form jammed in either the first or second fold plate, proceed as follows:
1. Switch off the power to the PS20/30, unplug it from the mains outlet and then
raise the lid (see page 12).
2. Remove the fold plates (see pages 13 and 14).
3. Lift the two snap levers holding the top-fold roller in place, (see Figure 16 on
page 30) and lift out the top-fold roller.
4. Remove the jammed form.
5. Replace the top-fold roller.
6. Close the two snap levers to hold the roller in place.
7. Replace the fold plates.
8. Lower the lid and restore power to the PS20/30.
9. Restart the PS20/30.
PS20/30 Iss. 1. Page 29
Jam after folder
1. Use the Jog function (press and hold down the red stop button and then press
the green start button) to eject the mishandled form out of the sealer rollers.
If the form doesn't eject, repeat. It may take several attempts.
5. Operation Errors
Page 30
PS20/30 Iss. 1.
Figure 16: Removing the top-fold roller
If, after several attempts, the mishandled form doesn't eject, carry out the Pressure
sealer bolt release procedure below.
P
The forms may need to acclimatize to the operating environment before folding and
sealing them. This can be achieved by allowing them to rest in the same room as
the PS20/30 for an hour or more after printing.
Pressure sealer bolt release
The pressure sealer bolts on the PS20/30 not only allow you to recover from severe
form mishandling situations, they also provide accurate sealing pressure. The pressure
on the sealing rollers can be relieved then reset to the original factory setting in the event
mishandled forms lodge between the sealing rollers, stopping the PS20/30 processing.
1. Switch off the PS20/30 and unplug it from the mains outlet.
2. Using the 4mm allen key provided, turn the four pressure bolts on the sealer
counter-clockwise to relieve the sealing roller pressure. (The allen key is
situated on the underside of the lid.)
3. With the lid closed, reconnect the power and switch the PS20/30 on.
4. Use the Jog function (press and hold down the red Stop button and then press
the green Start button) to eject the mishandled forms.
5. When you are sure that all mishandled forms have been cleared, switch the
PS20/30 off and unplug from the mains outlet.
6. Tighten each adjustment screw down on the sealer until you feel a significant
increase in resistance. This is a predetermined stop.
I
Do not overtighten the pressure bolts! Stop tightening the
bolts as soon as you feel a significant increase in
resistance. Ensure all bolts are correctly reset.
5. Operation Errors
PS20/30 Iss. 1. Page 31
7. Restore power to the PS20/30.
8. Restart the PS20/30.
Troubleshooting
The table following lists the possible causes and any corrective actions required for
conditions that may occur with your PS20/30. For conditions not covered below, contact
your authorized service representative.
5. Operation Errors
Page 32
PS20/30 Iss. 1.
Pressure Seal Bolts (2 each sid
e
of machine)
Figure 17: Relieving the sealing roller pressure
Condition Possible Cause Corrective Action
Forms are mishandled in the
folder or damaged during sealing.
Dirty fold rollers. Clean rollers with
recommended cleaning
solution. See page 39 .
Fold roller adjusted
improperly or worn;
sealing rollers adjusted
improperly.
Contact your authorized
service representative for
advice.
Forms not sealing. Pressure on sealing
rollers is relieved.
Reset pressure on the
sealing rollers. See page
32.
Forms have been
incorrectly stored, or are
older than their shelf life
(one year).
Use fresh forms.
Fold plate form stop(s)
adjusted improperly
causing poor registration
of adhesive strips.
Check and adjust
position of the fold plate
form stop(s). See page
16.
Sealing rollers adjusted
improperly.
Contact your authorized
service representative for
advice.
Forms are misfeeding. In-feed tray form guides
are set too tight or too
loose.
Set the guides so there is
just enough clearance to
allow the form to move
freely between the
guides.
Fold plates not installed
properly.
Install fold plates
properly.
Worn feed roller. Contact your authorized
service representative for
advice.
5. Operation Errors
PS20/30 Iss. 1. Page 33
Condition Possible Cause Corrective Action
Forms are wrinkled or badly
folded.
Forms not feeding
squarely against form
stop(s).
Adjust the form stop(s) to
squarely deflect the forms;
ensure the stop setting is
identical on both scales. See
page 16.
Top fold roller
improperly installed.
Ensure the top fold roller snap
levers are closed, holding the
roller in place. See page 30.
Dirty fold rollers. Clean rollers with
recommended cleaning
solution. See page 39.
Fold plate form stop(s)
adjusted improperly.
Check and adjust the position
of the fold plate form stop(s).
See page 16.
Fold rollers adjusted
improperly or worn;
sealing rollers
adjusted improperly.
Contact your authorized
service representative for
advice.
Two or more forms are feeding
into the folder together.
Forms in stack are
sticking together.
Fan form stack and reload
forms.
Worn feed roller. Contact your authorized
service representative for
advice.
5. Operation Errors
Page 34
PS20/30 Iss. 1.
Condition Possible Cause Corrective Action
The power-on indicator
does not light.
Mains lead not plugged
into an AC outlet.
Plug mains lead into an AC
outlet.
Power fuse blown. Replace fuse. If the
replacement fuse blows,
contact your authorized
service representative for
advice.
The PS20/30 does not
operate when the green
start button is pressed
(power on)
Form misfeed, jam
detected.
Clear mishandled forms.
Lid not fully closed. Close lid fully.
No forms loaded. Load forms.
Forms are mishandled in
the folder or damaged
during sealing.
Fold plate form stop(s)
adjusted improperly.
Check and adjust the position
of the fold plate form stop(s).
See page 16.
Debris in fold plates. Remove debris.
Top fold roller improperly
installed.
Ensure the top fold roller
snap levers are closed,
holding the roller in place.
See page 30.
5. Operation Errors
PS20/30 Iss. 1. Page 35
6. Cleaning the PS20/30
Cleaning procedure
The machine’s folding and sealing mechanisms should be cleaned in the following
manner:
Recommendations: Wear disposable gloves to avoid leaving finger-marks on the
PS20/3
0’s internal rollers. Wear a protective mask if you are susceptible to dust
allergies.
1. Be sure that the room is well ventilated.
2. Switch off the PS20/30's power and unplug it from the mains outlet.
3. Raise the lid.
4. Remove both fold plates (see page 13).
5. Lift the two levers holding the top-fold roller (see Figure 16 on page 30), and
lif
t out the roller.
6. Remove as much paper dust as possible using a soft brush (DO NOT USE
CANNE
D COMPRESSED AIR). Try to avoid letting the dust drift down into the
PS20/3
0 (vacuum if necessary).
Only use the recommended cleaning solution on this
machin
e (part number 70-0019-00, available from an
authorize
d service representative). InfoSeal cannot be
hel
d responsible for any damage to the PS20/30 caused by
th
e use of unauthorized solvents and cleaners.
PS20/30 Iss. 1. Page 37
I
Avoid breathing the fumes or getting the cleaning solution in
open wounds or other sensitive areas such as the eyes or
mouth. Read the container's label carefully before use.
7. Moisten a clean, lint-free cloth with the cleaning solution.
8. Wipe clean the surface of all the fold rollers using the moistened cloth. Rotate each roller
as you clean it. Wipe off any fingerprints from the rollers as they are turned.
P
The sealer rollers must only be cleaned by an authorized service
representative.
9. Align the flat faces on the two end bearings with their mounting slots when
reinstalling the top fold roller. Close the two snap levers to hold the roller in
place.
10. Replace the first and second fold plates.
11. Lower the lid and restore the machine's power.
6. Cleaning the PS20/30
Page 38
PS20/30 Iss. 1.
7. Specifications
Folder/Sealer Specifications
Construction
Steel with ABS shell
Sealer
Integral two-roller system (fixed pressure)
Size
Length: 17” (excl. output tray of 4.53”)
Width
: 19.5”
Height
: 15.17”
Weight
Approximately 155 lbs
Power
110/230V AC 10%
2.5A @ 230V
10%,
Speed
2000 forms per hour PS20
300
0 forms per hour PS30
PS20/30 Iss. 1. Page 39
Environment
Operating (50° to 100° F)
5% - 50% humidity
Non-operatin
g (41° to 122° F)
(idle - powe
r off) 5% - 80% humidity
Feeder Capacity
Approximately 100 sheets depending on paper weight (PS20)
Approximatel
y 150 sheets depending on paper weight (PS30)
Noise
71dB
Form Specification
Weights
Minimum: 24# - Maximum: 32# (Bond)
Sizes
(6
9
10
") x L ( 4") minimum
(8
1
2
") x L (14") maximum
Cu
t sheet
Fold Configuration
Z, V and C folds
7. Specifications
Pag
e 40 PS20/30 Iss. 1.
Appendix A - Form Loading
Guide
Many variables must be considered when setting up the folder/sealer, and loading forms
for processing. These include the form design, type of fold and condition of forms (if
they are curled or not).
This appendix attempts to address these variables in a way that helps you understand
the best way to set up your PS20/30 and to load the documents properly.
Figure 18 shows acceptable (flat or curl down), and unacceptable (curl up) curl
conditions. In some cases, forms that are curled up can be processed by loading them
differently.
PS20/30 Iss. 1. Page 41
Figure 18: Curled documents
Figure 19 shows you the general guidelines for various types of document.
Settings Settings Settings
First fold plate:
1/
2 of the form length.
Firs
t fold plate:
1/
3 of the form length
Firs
t fold plate:
2
3
of the form length.
Secon
d fold plate:
Us
e V-fold locating stubs
Secon
d fold plate:
1/
3 of the form length
Secon
d fold plate:
1
3
of the form length.
Feedin
g problems:
Rotat
e form 180 degrees.
Feedin
g problems:
Prin
t backside of form first, if
duplexed
Feedin
g problems:
Fli
p form then rotate 180
degrees.
Appendix A - Form Loading Guide
Pag
e 42 PS20/30 Iss. 1.
Figure 19: Document loading guidelines
Service Visit Log
Serial number:
Date Work done and comments
Engineer's
signature
Customer’s
signature
PS20/30 Iss. 1. Page 43
Loading...
