InFocus Play Big IN78 Technical Specifications

Play Big IN

78

Building your own home theater is a dream-

come-true for many; everyone else simply

doesn’t know what they are missing. But you

know that nothing is better than turning the

lights down, the volume up and seeing your

favorite movie or the big game projected in true

High Definition. InFocus is dedicated to providing

projectors for these experiences, which is why

we developed the new Play Big IN78.

Enhanced by Pixelworks’™ DNX™ video-processing

technology, it’s worthy of the hype of a Hollywood

premiere. If the IN78 can do all this for your

beloved films, just imagine what it could do for

your other in-home entertainment.

Show & tell, years later.

The onscreen images projected by the IN78 are

vivid, deep and undeniably rich. Every moment

with this projector is an indulgence, a treat and

something you deserve. Its clean, sleek, low-

profile design adds a subtle sophistication to any

room, and thanks to it’s black finish your show will

be distraction-free. The unique swivel base simpli-

fies tabletop setup and can be easily removed for

ceiling mounting. While we’re confident you’ll tell

every friend about your new IN78, it’s much nicer

to show them.

Low-maintenance, what a concept!

Just because the IN78 is a technical wonder

doesn’t mean it has to be complicated to use.

Every menu, feature and onboard technology is

designed to produce incredible video images with

great reliability, simple setup and smooth

installation options. Here’s how:

Enjoy setup in a snap with a simple keypad and

a new, full-featured remote control with patent­pending flashlight feature, direct source access,

programmable presets and more.

The internal level recognizes when the IN78

is ceiling-mounted, automatically flipping the
projected image. No hassles, no problems, just
beautiful images for all to enjoy.

An icon-based menu allows you to quickly scroll
and select your settings in your choice of 12

languages — without interrupting the show.

ISF Certified Calibration Controls allows for
professional setup of over 14 individual set­tings. Best of all, once programmed these
settings cannot be deleted unless intentionally
modified.

An easy to use, icon-based
menu allows you to quickly
scroll and select your
settings.

For the videophile in us all.

Play Big IN

78

The IN78 uses Pixelworks’ DNX video-processing tech­nology to dramatically improve the quality of video by
combining multiple enhancement techniques to deliver
clear, natural-looking standard and high-definition
images. DNX technology utilizes sophisticated digital
video processing to deliver a lifelike picture every time.
Here are a few more of the outstanding features
ensuring awe-inspiring home entertainment:

Native 1280 x 720 resolution creates high-definition
reality from any HD source.

The 720p DarkChip3™ DLP® from Texas Instruments™
provides breath-taking depth and picture sharp­ness, as well as true blacks and whites.

Thanks to 1000 video-optimized lumens with 3500:1
calibrated contrast ratio, you’ll get brilliant, dramatic
SMPTE (cinema-standard) brightness.

The advanced six-segment color wheel delivers intense,

precise colors that rival any movie theater screen.

Your time to shine.

Connecting to your home
entertainment devices is a snap.
You’ll be plugged in, powered up
and projecting in no time flat.

Enduring Quality

If you’re happy, InFocus is happy. That’s why the
InFocus Play Big IN78 projector comes with a stan­dard limited factory warranty (including parts
and labor) and a lamp replacement warranty.

For service program details in your region, please

visit: www.infocus.com/service

Optional Accessories

Ceiling Mount
Projection Screens
Performance Cables for Digital and HDTV
Cable Adapters

For more information about the IN78, any InFocus
home projector, optional accessories or service
programs please visit: www.infocus.com

InFocus Corporate Headquarters:

27500 SW Parkway Avenue
Wilsonville, Oregon 97070-9215, USA
Phone: [phone]
1-800-294-6400
Fax: [phone]

In Europe

Strawinskylaan 585
1077 XX Amsterdam
The Netherlands
Phone: [phone]
Fax: [phone]
Freephone: 008000 4636287 (008000 INFOCUS)

In Asia

19 Tanglin Road
7th Floor
Singapore 247909
Phone: [phone]
Fax: [phone]

InFocus, In Focus, INFOCUS (stylized), Play Big, Work Big, LP and SP are either registered trademarks or trademarks of InFocus Corporation in the United States and other
countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All other trademarks are used for identification purposes only and are the
property of their respective owners in this and other countries. ©2006 InFocus Corporation. All rights reserved. Part Number: 805-1126-00. PB_IN78_DS_E_083106.

INFOCUS TECHNICAL SPECIFICATIONS*

COMPATIBILITY

Video: Component and RGB HDTV (720p, 1035i, 1080i, 1080p-24Hz), 24p. DVI/HDMI with HDCP
for digital video and encrypted digital video. Component EDTV (480p, 576p progressive
scan), Component, Composite and S-Video standard video (480i, 576i, 576i RGB SCART
with adapter, NTSC, NTSC M 4.43, PAL: B, G, H, I, M, N; SECAM: M)
Computer: Digital and analog PC, Macintosh

®

, up to 1024x768 resolution through intelligent
resizing (Separately available M1-A (for analog sources) or M1-D (for digital sources)
cable required.)
Communication: USB (with separately available M1-DA cable).
RS-232

INPUTS AND OUTPUTS

1 - Component (RCA): HDTV, EDTV (progressive), and Standard TV component video (interlaced)
1 – S-Video: Standard TV Video
1 – Composite (RCA): Standard TV Video
1 – DVI: HDTV RGB, HDTV Component, Digital Visual Interface (DVI) with HDCP decryption,
computer, and USB, HDMI via available adapter
2 - HDMI**: SDTV, EDTV, HDTV Component (4:4:4 or 4:2:2) and RGB digital video, Interface (HDMI)
with HDCP decryption
1 – 3.5mm Mini-Jack: 12v screen drop trigger
SCART RGBS: RGBS through component and composite video connectors with separately available
adapter
1 – 9-pin D-connector: RS-232

IMAGING TECHNOLOGY

Imaging Technology: Texas Instruments

®

DLP® DarkChip3™ 720p 12° DMD
Resolution: 1280 x 720 (16:9 widescreen)
Projection Lens: Fully recessed 12 element zoom lens, all glass, F/2.4-2.8, 21-27mm focal length
(1.3:1 zoom ratio) with rack and pinion focus and zoom control
Color Wheel: Proprietary, 6-segment color wheel (6500K color temperature), D65 color calibration
Calibrated Contrast Ratio: 3500:1 full on/full off, typical
Lamp (dual mode): 160/200 Watt SHP, 3000 hours average lifetime***
Video Optimized Lumens: 1000 ANSI max
Projection Modes: Front/rear/ceiling mode
Focusing Distance: 5' (1.5m) to ∞
Keystone Correction: Digital, up to +/- 20° vertical
SMPTE Brightness: Up to 12' (3.7m) wide on a 1.0 gain screen
Video Processing: Pixelworks

™

DNX™ 10 bit video decoder and scaler, advanced motion adaptive

deinterlacing for Standard and High Definition sources (including 1080i) 3D comb filter

Throw Ratio: 1.52:1 – 1.92:1 (distance/width)

GENERAL

Product Dimensions: 4.7" (120mm) Height x 14.2"(360mm) Width x 14.2"(360mm) Depth, not including stand
Weight: 9.3 lb (4.2 kg)
Power Supply: 100V – 240V at 50/60 Hz
Operating Temperature: 50° F (10° C) – 95° F (35° C)
Operating Altitude: 0 – 7500’ (2300m)
Conformances: UL, c-UL, TUV GS, GOST, C-Tick, NOM, IRAM, FCC Class B, ICES-003 Class B, CISPR22/
EN55022, EN55024/CISPR 24, CB certified in accordance with IEC60950 1/EN60950 1,
MIC, CE, CCC, VCCI, WEEE
Ships with: Power cord, home entertainment remote control, composite cable, printed Quick Start
Card, M1-DA to HDMI adapter, CD-Rom with User’s Guide
Warranty: 2 year parts and labor, 90 days for accessories – Additional extended product
warranties available
Lamp Warranty: 180 days – Additional extended 1 year lamp warranty available
Menu Languages: English, Spanish, French, German, Japanese, Korean, Portuguese, Italian, Norwegian,
Russian, Chinese Traditional, Chinese Simplified

* InFocus reserves the right to alter product offerings and specifications at any time without notice.
** Second HDMI available using included M1-DA to HDMI adapter.
*** Actual lamp life may vary based on the ambient environment. Conditions that may affect lamp life

include temperature, altitude or rapidly switching the projector on and off.

®
