InFocus M810 Quick Start Manual

Quick Start Guide

M

8

10

Introduction

Thank you for choosing InFocus M810 phone. It is
recommended that you first read the

to understand the basic operation of the

Guide

phone.

Quick Start

Content

Your Phone ............................................... 2

Installing SIM Card and Memory Card ......3

Charging the Battery ................................. 4

Initial Start Up ............................................ 4

Home Screen ............................................ 4

Making Your First Call ............................... 5

Contacts ..

Sending a Text Message ........................... 7

Setting up WLAN ....................................... 7

Setting up Email Account .......................... 8

Sending and Receiving Emails .................. 8

Using Browser ........................................... 9

Using Bluetooth ....................................... 10

Taking Photos and Videos ...................... 10

Viewing Photos and Videos ..................... 12

Basic Phone Settings ..............................

1

.................................................. 6

13

Your Phone

Earpiece

Memory

Proximity

card tray Microphone

sensor

Front camera

Power button

Volume (+/-) button

Touch screen

Back

Home

Menu

Power LED

Speaker

tray

Rear camera
Flash

Micro USB MicrophoneSIM card

port

2

Headset jack

Installing SIM Card and
Memory Card

1. Locate the SIM card tray.

2. Use the included pin to
open the tray.

3. Place the SIM card on the
tray and slide the tray into
the phone.

Use the pin supplied in the box
only to open the card slot.

4. Locate the memory card
tray.

5. Use the included pin tool
to open the tray.

6. Place the memory card
on the tray. Slide the tray
back into the phone.

3

Charging the Battery

Before using the phone, it is recommended to fully
charge the battery first.

1. Connect the smaller end of the
USB cable to the USB port of
the device.

2. Connect the other end of the
cable to the USB charger or
other USB port with power
source (for example, laptop). The phone’s
Power LED lights on.

Warning

• Charge only indoors and in dry environments.

• For safety, the overheat protection will be active during
charging. If the system temperature reaches above the
maximum level, the device will automatically stop charging.
The device will only resume charging when normal
operating temperature is reached.

• If there is no response after you press the Power button or

touch the panel, press and hold the “Power button” for 8
seconds to force shutdown. If you hold the “Power button”
for 2 seconds more, it will restart.

Initial Start Up

After installing the SIM card and charging the
battery, the device is ready to be turned on.

Home Screen

From the Home screen,
you can quickly access
common features and
view notifications of
missed calls, received
messages, check battery
and connection status.
Swap the Home Screen
panels to access all the
applications and settings
of the device.

4

Making Your First Call

From the Home screen, tap .

To make a call

1. Enter the phone
number on the
keypad.

2. Tap to correct any
number. Tap and hold

to erase the entire

number.

NOTE:

To call a contact,

tap from the list.

3. Tap to make a
call.

4. To end the call, tap

.

To answer a call

To answer a call, tap and drag it to the right
().

NOTE:

When you tap , it automatically changes to .

5

Contacts

Adding contacts

1. From the Home screen, tap .

2. Tap to add a
contact.

3. Select one of the
location to store the
contact to (SIM-only
or Phone-only).

4. Enter the contact
information such as
name, phone
number, email
address, etc.

5. Tap to save
the contact.

Importing contacts

1. From the Home screen, tap .

2. Tap >

3. Select the contacts

6

Import/

Export

, and choose
to Import/export
contacts from or to
the SIM card/storage.

location that you
want to copy to or
copy from, and tap

.

Sending a Text Message

1. From the Home
screen, tap .

2. Tap .

3. In the

4. Compose your

5. Tap to send your

To

field, enter
the recipient’s phone
number or name.

message.

message.

Setting up WLAN

1. From the Home screen, tap .

2. In

WIRELESS &
NETWORKS
WLAN

on.

3. Available networks
are listed. Tap a
network to connect to

or tap to manually
add a connection.

NOTE:

secured network will
prompt for a password.
Enter the password, then
tap

7

and turn it to

Connecting to a

Connect

.

, tap

Setting up Email Account

1. From the Home screen, tap .

2. Enter your

address
Password
Next

3. Set the

checking frequency

settings and tap

4. Enter

Account display
name

5. Tap
account setup is
complete, the device
will automatically
retrieve your emails.

.

Name

.

Next

Inbox

Email

and

and tap

and

. Once the

Next

.

Sending and Receiving Emails

Composing and sending emails

1. From the Home
screen, tap , tap
an email account.

2. Tap .

3. In the

4. Enter the

5. Compose your email.

6. Tap to add an

7. Tap to send an

8

To

field, enter
the recipient’s email
address.

Subject

attachment.

email.

.

Receiving emails

Emails are automatically received in the Inbox
folder when the device connects to a network.To
manually retrieve new emails, swipe down to

Refresh

refresh or tap >

.

Using Browser

To open a web page

1. From the Home
screen, tap .

2. Tap the address bar.

3. Type the URL then tap

Go

.

4. Tap to open New
Tab page or add the
page to the Bookmarks.

5. Tap the address bar.

6. Type the URL then tap

Go

.

7. Tap to open New
Tab page or add the
page to the Bookmarks.

9

Using Bluetooth

1. From the Home screen, tap .

WIRELESS & NETWORKS

2. In
and turn it to on.

3. Available devices are listed. To search for a
new device, tap

4. Tap a detected device.

5. To start pairing, enter the

NOTE:

• The PIN of the device must be the same PIN on
the other bluetooth device.

• On some devices, tap

6. The paired Bluetooth device name is
displayed.

SEARCH FOR DEVICES

PIN

Pair

to start pairing.

, tap

Bluetooth

then tap OK.

Taking Photos and Videos

This device is equipped with rear and front
cameras to take photos and videos.

1. From the Home screen, tap .

NOTE:

.

10

To switch between
front and rear cameras,
tap .

2. Aim the device at the
subject.

• Pinch the screen to
zoom in or out.

to turn on or off

•Tap
the flash.

3. Tap to take the
shot.

To record video

1.

From the Home screen, tap .

2. Tap to enter video
mode.

NOTE:

To switch
between front and rear
cameras, tap .

3. Aim the device at the
subject.

4. Tap to stop
recording.

To take a panorama shot

1.

From the Home screen, tap .

2. Tap and select

3. Aim the device at the subject.

4. Tap to take the shot.

5.

Move the device slowly toward one direction
shown on the screen.

6. W

hen the shooting guide reaches the end of the
shooting point, the shooting ends. You can also
manually stop recording by tapping .

11

Panorama

.

Viewing Photos and Videos

1. From the Home screen,

2. Tap a folder to view the recorded files in
thumbnails.

3. Tap an image or a video to view in full screen.

tap

.

4. Swipe your finger to the left/right to view the
previous/next file.

• To share the image,

tap > Share, then
tap an application for
sharing.

• To delete the image,

tap , then tap OK.

• To play the video, tap
.

• To upload the file to

the cloud storage,

and login your

tap
cloud album.

• To play the

slideshow, or show
more options, tap .

rate the image,

•To

tap

.

• To edit the image, tap

12

.

Basic Phone Settings

Adjusting the volume

There are two ways to
adjust the volume:

• Press the volume
(+/-) button
repeatedly to adjust
the volume.

• Press the volume
button once.
Drag the volume
slider to adjust the
volume.

Setting an alarm

1. From the Home screen,

2. Tap .

3. To add an alarm, tap .

4. To set the time, slide the pointer, and tap

Done

.

5. To set repeat mode, check
the desired week days.

6. To set the ringtone, tap , and select the
alarm sound.

7. To vibrate when the alarm sounds, check

Vibrate

8. To enter an alarm label, tap

NOTE:

13

.

OK

.

By default the alarm is set on.

tap

.

Repeat

Label

and select

and tap

Changing the Launcher layer mode

1. From the Home screen,

2. Tap . The
Launcher+ page
opens.

3. Tap

Layer mode setting

4. Choose

One layer

or

Two layers

tap

tab.

.

.

The result is displayed as follows:

One layer

14

Two layers

Important Safety Information

Please read before proceeding

• DO NOT place objects on top of the device, as they may scratch
the screen.

• DO NOT drop your device or subject it to severe impacts.
Bending the body and pushing the display or keys with extreme
force could damage the device.

• DO NOT use a pen or any sharp object to tap the screen.

• DO NOT expose the device to dirty or dusty environments.

• DO NOT place the device on an uneven or unstable surface.

• DO NOT insert any foreign objects into the device.

• DO NOT expose the device to strong magnetic or electrical field.

• DO NOT use or store this equipment in a place where it will be

exposed to high temperatures, such as near an open flame or
heat-emitting equipment.

• DO NOT use

• Using this device for long periods of time may cause the device

it or store it where fluids such as water can splash

onto it. Raindrops, water spray, juice, coffee, steam, or other
types of liquids will also cause malfunctions.

to get warm. If you feel the device is too warm, avoid sustained
contact with exposed skin otherwise this might cause discomfort,
or eventually a burn.

• Refer to the rating label on the device and be sure that the power
adapter complies with the rating. Only use accessories specified
by the manufacturer.

• Disconnect the device from an electrical outlet and power off

• NEVER attempt to connect or disconnect the power adapter with

• Clean the touch screen with a soft cloth. If needed, dampen the

• DO NOT disassemble the device. Only a certified service

• Please check with your Local Authority or retailer for proper

• For USB connection, users must use a USB 2.0 (or higher

• The adapter shall be installed near the equipment and shall be

ing the device.

before clean

wet hands.

cloth slightly before cleaning. Never use abrasives or cleaning
solutions.

technician should perform repair.

disposal of electronic products.

version) cable.

easily accessible.

i

• The temperature of the device might increase while the CPU is
busy handling resource consuming activities such as high
resolution video decoding. The SW protection mechanism will
ensure stop charging whenever the temperature is over the
predefined threshold and prepare for shut down if necessary.
Please worry not.

Safety Precautions for Battery Use

• Keep the battery dry and away from any liquid since this may
cause a short circuit.

• Keep the battery away from metal objects since this may cause a
short circuit.

• Do not use damaged or deformed batteries.

• If the battery emits a foul odor, discontinue use.

• Keep the battery away from babies and small children.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with your skin,

eyes or clothing. If already in contact, rinse with clean water
immediately and seek medical advice.

• Keep the battery away from fire since this may cause the

battery to explode.

• Do not attempt to open or service the battery yourself.

• Do not dispose battery in fire or water.

• Recycle or dispose used batteries according to the
local regulations.

Road and Environmental Safety

• Turn off the phone in areas with a potentially explosive
atmosphere or where flammable objects exist such as gas
stations, fuel depots, and chemical plants among others. Sparks
from these areas could cause explosion or fire and result in
injury or even death.

• Do not use hand-held phones while driving a vehicle. Use hands­free devices as an alternative.

Safety in Aircraft

Do not use the phone on board an aircraft. The phone’s network
signals may cause interference to the navigation system. As a safety
measurement, it is against the law in most countries to use the phone
on board an aircraft.

Copyright Information

Copyright © InFocus Corporation, 2014. All rights reserved.

This product has an Android™ platform based on Linux, which c an
be expanded by a variety of JME-based application SW.

ii

Google、Google Play、Android and other marks are trademarks
of Google Inc.

microSD™ is a trademark of SD Card Association.

Bluetooth and the Bluetooth logo are trademarks owned by
Bluetooth SIG, Inc.
All products use in this device and trademarks mentioned herein are
trademarks or registered trademarks of their respective owners.
LTE is a trade mark of ETSI

Intellectual Property Right Information

Right to all technologies and products that comprise this device are
the property of their respective owners:
This product has an Android
be expanded by a variety of Java-Script-based application SW.

a) Use a wireless hands-free system (headphone, headset) with a
low power Bluetooth emitter.
b) Make sure the cell phone has a low SAR.
c) Keep your calls short or send a text message (SMS) instead. This
advice applies especially to children, adolescents and pregnant
women.
d) Use cell-phone when the signal quality is good.
e) People having active medical implants should preferably keep the
cell phone at least 15 cm away from the implant.

TM

platform based on Linux, which can

iii

Compliance Information

SAR Information

THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO
RADIO WAVES. Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These guidelines
were developed by the independent scientific organization ICNIRP
and include safety margins designed to assure the protection of all
persons, regardless of age and health.

The exposure guidelines for mobile devices employ a unit of
measurement kno
SAR limit stated in the ICNIRP guidelines is 2.0 W/kg averaged over
10 grams of tissue. Tests for SAR are conducted using standard
operating positions with the device transmitting at its highest certified
power level in all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because the
device is designed to use only the power required to reach the
network. That amount changes depending on a number of factors
such as how close you are to a network base station. The highest
SAR value under the ICNIRP guidelines for use of the device at the
ear is 1.400 W/kg and at the body is 0.519 W/kg (The measure
distance of 1.5 cm). Use of device accessori
may result in different SAR values. SAR values may vary depending
on national reporting and testing requirements and the network band.

wn as the Specific Absorption Rate or SAR. The

es and enhancements

WEEE Notice

The WEEE logo on the product or on its box indicates that this
product must not be disposed of or dumped with your other
household waste. You are liable to dispose of all your electronic or
electrical waste equipment by relocating over to the specified
collection point for recycling of such hazardous waste. Isolated
collection and proper recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help conserve
natural resources. Moreover, proper recycling of the electronic and
electrical waste equipment will ensure safety of human health and
environment. For more information about electronic and electrical
waste equipment disposal, recovery, and collection points, please
contact your local city center, household waste disposal servi
shop from where you purchased the equipment, or manufacturer of
the equipment.

ce,

RoHS Compliance

This product is in compliance with DIRECTIVE 2011/65/EU OF
THE EUROPEAN PARLIAMENT AND OF THE COUNCIL
of 8 June 2011,on the restriction of the use of certain
hazardous substances in electrical and electronic equipment
and its amendments.

European Union Regulatory Conformance

The equipment complies with the RF Exposure Requirement
1999/519/EC, Council Recommendation of 12 July 1999 on the
limitation of exposure of the general public to electromagnetic fields
(0–300 GHz). This equipment meets the following conformance
standards: EN50360, EN62209-1/-2, EN62311, EN62479,
EN60950-1, EN50332-1/-2, EN301489-1/-3/-7/-17/-24,EN55022,
EN55024, EN61000-3-2/-3-3, EN301511, EN301908-1/2/-13,
EN300328, EN301893, EN300440-1/2, EN302291-1-2, EN5081,
EN50566.

For the device which tests accordance to EN60950-1:2006, it is
mandatory to perform audio tests for EN50332.

This device have been tested to comply with the Sound Pressure
Level requirement laid down in the applicable EN 50332-1 and/or
EN 50332-2 standards.
earphones or headphones are used at high volume for prolonged
periods of time.

Prevention of Hearing Loss

Warning statement requirement under EN 60950-1:A12.

To prevent hearing damage, do not listen at high volume levels for long
periods.

Permanent hearing loss may occur if

iv

Note: For France, headphones/earphones for this device are

compliant with the sound pressure level requirement la id down
in the applicable EN50332-1:2000 and/or EN50332-2:2003
standard as required by French Article L.5232-1.

A pleine puissance, l’écoute prolongée du baladeur
peut endommager l’oreille de l’utilisateur.

The conformity assessment procedure has been followed with the
involvement of the following Notified Body:
Cetecom TESTLAB
Identification mark: CE0682
(Notified Body) CE

Changes or modifications to this product not authorized by the
manufacturer could void the EMC compliance and negate your
authority to operate the product. This product has demonstrated EMC
compliance under conditions that included the use of compliant
peripheral devices and shielded cables between system
components. It is important that you use compliant peripheral devices
and shielded cables between system components to reduce the
possibility of causing interference to radios, televisions, and other
electronic devices.

0682

We, hereby, declare that this Smartphone is in compliance with the
essential requirements and other relevant provisions of Directive
1999/5/EC.

This equipment may be operated in:

AT BE BG CH CY CZ DE DK

EE ES FI FR GB GR HU IE

IT IS LI LT LU LV MT NL

NO PL PT RO SE SI SK TR

This device is restricted to indoor use only when operating in the
5150 to 5350 MHz frequency range.

DFS controls related to radar detection shall not be accessible to the
user.

Warranty Statement

Limited warranty

InFocus provides “Product Warranty Statement”, at the time of its
original purchase, from the InFocus or its authorized distributor,
describing the product warranty service.

Notes: InFocus does not provide global cross border warranty.

v

This limited warranty (free of defects in materials and workm anship
causing malfunction and defective) shall last for twelve (12) months
for the device and six (6) months for the battery from the purchase
date. Other than battery, the in-box accessories, including cosmetic
parts, button, cables, earphone, AC ... etc. if applied; six (6) month
open-box functional failure warranty is provided. The customer shall
present the PROOF OF PURCHASE upon claiming the warranty.
Throughout the warranty period InFocus or its authorized agent will,
at own discretion and subject to section Non-Warranty below repair
or replace a defective product. All replaced defective parts or
components will become the property of InFocus after returning the
repaired/replaced product in good working condition. This repair on
the same symptom, one (1) month repair warranty is provided.

Non-Warranty

No warranty may be asserted or claimed if (1) the product serial
number, date code, IMEI, water indicator or the warranty seal has
been removed, erased, defaced or altered; or (2) the defect is found

t o be c aused by:

(1) By engineering judgement, the prod uct is mishandled/misused

carelessly or accidentally. Unauthorized disassembling or repair,
repair by use if unauthorized spare parts, or other actions beyond
the reasonable control of InFocus.

(2) Improper shipping and packing.

(3) Forces of nature of willful misconduct.

(4) Rough handling, exposure to moisture, dampness or extreme

thermal or environmental conditions or a rapid change in such
conditions, corrosion, oxidation, unauthorized modifications or
connections.

(5) Deterioration of the product due to normal wear and tear.

Products installed or integrated with software or applications
which are not made or authorized by InFocus.

Be sure to back up data and remove any confidential, proprietar y or
personal information from the product when asking service. InFocus
is not responsible for the damage to or loss of any programs, data, or
removable storage media inside or sent with the products. As to Non­warranty product, InFocus will check if a repair is economical/
available and provide a chargeable service to customer’s
consideration.

IN NO EVENT SHALL InFocus BE LIABLE UNDER THIS LIMITED
WARRANTY FOR LOSS OF PROFIT. LOSS OF ANTICIPATED
SAVINGS, LOSS OF DATA OR INDIRECT LOSS, LOSS OF THE
PRODUCT OR ANY ASSOCIATED EQUIPMENT, INCIDENTAL OR
CONSEQUENTAL LOSSES OR DAMAGES OF ANY NATURE
WHATSOEVER TO THE FULLEST EXTENT THAT THOSE
LOSSES OR DAMAGES CAN BE DISCLAIMED BY LAW.

vi
