InFocus M330 Quick Start Manual
Quick Start Guide
Introduction
Thank you for choosing InFocus M330 phone.
It is recommended that you first read this
Start
Guide
of the phone.
to understand the basic operation
Quick
Content
Your Phone ............................................... 2
Installing SIM Card(s) and Memory Card .. 3
Charging the Battery ................................. 4
Initial Start Up ............................................ 4
Home Screen ............................................ 4
Making Your First Call ............................... 5
Contacts .................................................... 6
Sending a Text Message ........................... 7
Setting up WLAN ....................................... 7
Setting up Email Account .......................... 8
Sending and Receiving Emails .................. 8
Using Browser ........................................... 9
Using Bluetooth ....................................... 10
Taking Photos and Videos ...................... 10
Viewing Photos and Videos ..................... 12
Basic Phone Settings .............................. 13
1
Your Phone
Earpiece
Front camera
Proximity sensor
Touch screen
Options key
Home key
Status
LED
Rear camera
Flash
Power
button
Back key
Speaker
Microphone Micro USB port
Headset jack
Volume (+/-) butto
2
n
Installing SIM Card(s) and
Memory Card
1. Place your phone face
down on a flat surface.
2. Locate the small gap
on the lower left corner
of the back cover,
gently pull up to release
the latches and slowly
remove the cover.
3. Insert the SIM card(s)
into the slot(s) as
illustrated.
NOTE:
• To remove the SIM card,
push the SIM card firmly
into the slot first to eject
it, then pull it out.
• When using the card adapter do not use
excessive force to remove the SIM card as
this can damage the card.
he SIM1 supports 3G data network.
•T
However, the SIM2 only supports voice call.
4. Insert the memory
card into the slot with
gold connectors
facing down.
5. Replace the back
cover and press along
the edges until the
latches are fully sealed.
3
Charging the Battery
Before using the phone, it is recommended to fully
charge the battery first.
1. Connect the smaller end of the
USB cable to the USB port of
the device.
2. Connect the other end of the
cable to the USB charger or
other USB port with power
source (for example, laptop).
3. Plug the AC adapter to a wall outlet to start
charging.
Warning
• Charge only indoors and in dry environments.
• For safety, the overheat protection will be active
during charging. If the system temperature reaches
above the maximum level, the device will
automatically stop charging. The device will only
resume charging when normal operating
temperature is reached.
• If there is no response after you press the Power
button or touching the screen, press and hold the Power
button for 8 seconds to force shutdown. If you hold the
Power button for 2 seconds mor
e, it will restart.
Initial Start Up
After installing the SIM card(s) and charging the
battery, the device is ready to be used.
Home Screen
From the Home screen,
you can quickly access
common features and
view notifications of
missed calls, received
messages, check battery
and connection status.
Swipe your finger to the
left or right to access the
applications installed on
the device.
4
Making Your First Call
From the Home screen, tap .
To make a call
1. Enter the phone
number on the
keypad.
2. Tap to correct
any number. Tap
and hold to erase
the entire number.
3. Tap to make a
call.
4. To end the call, tap
.
NOTE:
If you have
inserted two SIM cards,
select the desired SIM
network.
To receive a call
To answer a call, tap and drag it to the right
().
NOTE:
When you tap , it automatically changes to .
5
Contacts
Adding contacts
1. From the Home screen, tap .
2. Tap to add a
contact.
3. Select one of the
location to store the
contact to.
4. Enter the contact
information such as
name, phone
number, email
address, etc.
Done
5. Tap
the contact.
to save
Importing contacts
1. From the Home screen, tap .
2. Tap >
3. Select the contacts
4. Select the contacts
6
Import/
, and choose
export
one of the
options.
location that you
want to copy to.
to copy and tap
Done
