InFocus IN3924 User Manual

1
Declaration of Conformity
Manufacturer: InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, Oregon
Trademarks
NOTE:
FCC Warning
Canada
97223-8368 USA
We declare under our sole responsibility that this projector conforms to the following directives and norms:
Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer, Inc. IBM is a trademark or registered trademark of International Business Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or registered trademarks of Adobe Systems Incorporated. DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.
ErP Directive 2009/125/EC
EMC: EN 55024:2010, EN 55022:2010, EN 61000-3-2:2006+A1:2009+A2:2009, EN 61000-3-3:2008
Low Voltage Directive 2006/95/EC
Safety: IEC 60950-1: 2005;EN 60950-1:2006 +A11:2009
R&TTE Directive: 1999/5/EC
ETSI: EN 300 440, EN 301 489
The receiver portion of this product is a Category III device, as specified in EN 300 440.
This product is covered electrical and electronic equipment under the European Union's Waste from Electrical and Electronic Equipment ("WEEE") Directive (2002/96/EC). The WEEE Directive requires that covered equipment be collected and managed separately from typical household waste in all EU member states. Please follow the guidance of your local environmental authority or ask the shop where you purchased the product for collection or recycling options.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by InFocus Corporation may void authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the device.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes:
(1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
2
Agency Approvals
cULus
Other specific Country Approvals may apply. Please see product certification label.
This document applies to regulatory model IN3924/IN3926.
Input ratings: 100-240Vac, 3.2A, 50-60Hz
InFocus reserves the right to alter product offerings and specifications at any time without notice.
3
Table of Contents
Introduction 5 Positioning the projector 7 Connecting a computer source 8
VGA connection 8
HDMI connection 8
Connecting power 8
Optional computer connections 8 Displaying an image 9 Adjusting the image 10 Connecting a video device 11
Video device connections 11
Composite video connection 11
VGA connection 11
Component video connection 11
S-video connection 11 Shutting down the projector 12 Troubleshooting your setup 12 Using the remote control 20 Using the audio 21 Using the keypad buttons 22 Optimizing computer images 23 Presentation features 23 Optimizing video images 24 Customizing the projector 24 Using the menus
Basic Menu 26
Advanced Menu 27 Controlling the projector through a LAN environment 31
Controlling the projector remotely through a web browser 32 Displaying images through ifPresenter 36 Displaying pictures with a USB storage device 39
LiteBoard™ Wand 41
Charging the Wand’s Battery 41
How to Use the Wand 41
Wand Position and Avoiding Shadows 41
Using More than One Wand 42
25
Wand Features 42 Buttons and Wand Tip 42
Troubleshooting LiteBoard 43
Maintenance 45
Cleaning the lens 45 Using the security lock 45 Replacing the projection lamp 46
