InFocus IN10 Product Sheet

Work Big IN

10

The InFocus Work Big IN10 ultra-mobile projector

is the technological equivalent of a pint-sized

solar burst you can take anywhere. Built around

innovative, compact optics and advanced DLP®

imaging technology the 1800-lumen IN10 will

ensure your brightest idea really sees the light

of day. No matter how large your presentation

space, the IN10 will project a clean, vivid image

while supporting both front and rear projection.

Integrated XGA (1024 x 768) native resolution

will flawlessly display the most media-rich

presentations, including automatic adjustment

for 16:9 video and true HD sources.

Mighty Concentrated

Work Big IN

10

Adjust on the fly

The IN10 weighs a scant 2.4 lbs and easily fits

in your hand – half the weight and size of most

other “mobile” projectors! Enabling you to

travel light while maintaining full presentation

functionality is what the IN10 is built for, so

InFocus integrated key hardware features

designed for ease of use. Such features include

the onboard 1.25:1 zoom lens - an ideal hybrid

for utilizing close quarters such as a trade-show

booth, or taking presentations to a conference

room. Also, the ultra-precise lens-mounted

zoom and focus control enables you to adjust

your image anywhere at anytime without fragile

internal motors to fret over.

Speaking prowess

The IN10 uses a standard 4000-hour lamp, this

amount of life will give you years of maintenance-

free projection with nothing to clean or replace.

This means projector air filters are a thing of the

past and you’ll never be embarrassed by a filter

warning on-screen during your most important

presentation.

• 1800 max ANSI lumens

• 4000 hour lamp life

• 2.4 lbs

• 2.5” x 6” x 7.8”

• Approximately the size of a paperback book

• 1100:1 contrast ratio

The right connections

To make life easier on the road, InFocus has incorporated all the connectivity you’ll ever need in the

new IN10. For high-resolution video and data sources, the integrated M1-DA port offers expansion

to component, HDMI, DVI and-computer connections. Also, the onboard composite and s-video

inputs enable quick connectivity in parallel with the audio input and internal speaker to provide a full

multimedia experience for the audience. This evolved approach to connectivity means when the IN10

is plugged-in to the InFocus LiteShow II wireless device users can finally present data, audio and video

wirelessly!

Heavy on features, light on the scale

3.5mm Audio S-Video Composite
Video

MI-DA

(HDMI, Component, VGA)

LiteShow II Wireless Adaptor

Stream multimedia presentations
or high-resolution video and audio
simultaneously from any computer
in the classroom to your new InFocus
projector.

You’ll never have to switch discs or
mess with multiple computers at the
podium again thanks to LiteShow II.
Along with impressive wireless
functionality, this adaptor also
extends your wireless network’s
strength to keep everyone online and
tuned-in.

Enduring Quality

If you’re happy, InFocus is happy. That’s why
every InFocus projector comes with a standard
limited factory warranty (including parts and
labor) and a limited lamp-replacement warranty.
Extended product & lamp warranty programs are
also available.

For more information about warranty and service
programs in your region, please visit:

www.infocus.com/service

Optional Accessories

Projection Screens
Performance Cables for Digital and HDTV

Cable Adapters
Advanced Remote Controllers

For more information about the IN10, or any
InFocus business or home projector, optional
accessories or service programs please visit:

www.infocus.com

InFocus Corporate Headquar ters:

27500 SW Parkway Avenue
Wilsonville, Oregon 97070-9215, USA
Phone: [phone]
1-800-294-6400
Fax: [phone]

In Europe

Louis Armstrongweg 110
1311 RL Almere
The Netherlands
Freephone: 008000 4636287 (008000 INFOCUS)
Fax: [phone]

In Asia

19 Tanglin Road
7th Floor
Singapore 247909
Phone: [phone]
Fax: [phone]

©2007 InFocus Corporation. All rights reserved. InFocus, In Focus, INFOCUS (stylized), Play Big, Learn Big, Work Big, LP and SP are either registered trademarks or trademarks of
InFocus Corporation in the United States and other countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All other trademarks are used for
identification purposes only and are the property of their respective owners in this and other countries. Part Number: 805-1140-00. WB_IN10_DS_E_012407.

INFOCUS TECHNICAL SPECIFICATIONS

*

Native Resolution XGA 1024 x 768
Display Technology DLP® by Texas Instruments™: 0.7" XGA DDR DMD
Input Sources Computer (M1-DA), video (S-Video and Composite),;

audio (3.5mm mini jack)
Video Input NTSC 3.58, NTSC 4.43, PAL (all), SECAM
Brightness 1800 max ANSI lumens
Contrast Ratio 1100:1 full on/full off
Lamp 125W UHP/4000 Hours**
Digital Keystone Correction ±15° vertical; data/video
Image Offset 110%
Projection Lens Zoom Lens with manual focus and manual zoom adjust
Throw Ratio 1.85 – 2.33:1 (distance/width)
Zoom Ratio 1.25:1
Aspect Ratio 4:3 (standard); 16:9
Audible Noise 32dB
Number of Colors 16.7 million
Image Size (diagonal) 2.7’/0.8m (min) – 22.2’/6.8m (max)
Projection Methods Front, Rear
H-Synch Range 15 – 90 kHz
V-Synch Range 50 – 85 Hz
Dot Clock 10 MHz-165 MHz
Minimum Projection Distance 4.92' (1.5 m)
Audio 1.0 Watt
Control Projector keypad; IR remote control; Wired control through USB
Product Dimensions 6.1” L x 7.8” W x 2.5” H (19.8 cm L x 15.5 cm W x 6.4 cm H)
Product Weight 2.4 lbs (1.09 kg)
Shipping Dimensions 8" H x 20" L x 15" W (20.32 cm H x 50.86 cm W x 38.10 cm L)
Power Consumption 165W
Power Supply 100V – 240V at 50 – 60 Hz
Operating Temperature 5° – 35° C at sea level (0’ to 10,000’); 45° – 95° F
Ships with M1-DA to VGA Computer cable (with tie wrap), power cable (with tie wrap), carry case,

accessories pouch, lens cap, remote control, user guide, detailed reference guide, CD

Menu Languages English, Norwegian, Spanish, Italian, Portuguese, German, French, Chinese (simple), Japanese
Approvals UL and c-UL (US/Canada), FCC-A (US/Canada), CE (CE member countries), GOST (Russia),

TUV GS (Germany), CCC (China), IRAM (Argentina), NOM (Mexico), C-Tick (Australia)

* All specifications subject to change
** Actual lamp life may vary based on the ambient environment. Conditions that may affect

lamp life include temperature, altitude, and rapidly switching the projector on and off.
