Infiniti S51-D User Manual

Foreword

Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior craftsmanship with a simple, refined aesthetic sensitivity associated with traditional Japanese culture.

The result is a different notion of luxury and beauty. The car itself is important, but so is the sense of harmony that the vehicle evokes in its driver, and the sense of satisfaction you feel with the INFINITI — from the way it looks and drives to the high level of dealer service.

To ensure that you enjoy your INFINITI to the fullest, we encourage you to read this Owner’s Manual immediately. It explains all of the features, controls and performance characteristics of your INFINITI; it also provides important instructions and safety information.

A separate Warranty Information Booklet is included in your Owner’sliterature portfolio. The INFINITI Service and Maintenance Guide explains details about maintaining and servicing your vehicle. Always carry it with you when you take your vehicle to an INFINITI dealer. The Warranty Information Booklet contents provide complete information about all warranties covering this vehicle, the requirements to keep the warranties in effect

as well as the INFINITI Roadside Assistance program.

Additionally, a separate Customer Care and Lemon Law Information Booklet will explain how to resolve any concerns you may have with your vehicle, as well as clarify your rights under your state’s lemon law.

READ FIRST — THEN DRIVE SAFELY

Before driving your vehicle, read your Owner’s Manual carefully. This will ensure familiarity with controls and maintenance requirements, assisting you in the safe operation of your vehicle.

WARNING

IMPORTANT SAFETY INFORMATION REMINDERS FOR SAFETY!

Follow these important driving rules to help ensure a safe and comfortable trip for you and your passengers!

. NEVER drive under the influence of

alcohol or drugs.

. ALWAYS observe posted speed limits

and never drive too fast for conditions.

. ALWAYS give your full attention to

driving and avoid using vehicle features or taking other actions that could distract you.

. ALWAYS use your seat belts and appro-

priate child restraint systems. Pre-teen children should be seated in the rear seat.

. ALWAYS provide information about the

proper use of vehicle safety features to all occupants of the vehicle.

. ALWAYS review this Owner’s Manual for

important safety information.

ON-PAVEMENT AND OFF-ROAD DRIVING

This vehicle will handle and maneuver differently from an ordinary passenger car because it has a higher center of gravity for off-road use. As with other vehicles with features of this type, failure to operate this vehicle cor rectly may result in loss of control or an accident. Be sure to read “On-pavement and offroad driving precautions”, “Avoiding collision and rollover” and “Driving safety precautions” in the “5. Starting and driving” section of this manual.

MODIFICATION OF YOUR VEHICLE

This vehicle should not be mo dified. Modification could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from modification will not be covered under the INFINITI warranties.

WHEN READING THE MANUAL

This manual includes information for all options available on this model. Therefore, you may find some information that does

not apply to your vehicle.

All information, specifications and illustrations in this manual are those in effect at the time of printing. INFINITI reserves the right to change specifications or design at any time without notice.

IMPORTANT INFORMATION ABOUT THIS MANUAL

You will see various symbols in this manual. They are used in the following ways:

WARNING

This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.

CAUTION

This is used to indicate the presence of a hazard that could cause minor or moderate personal injury or damage to your vehicle. To avoid or reduce the risk, the procedures must be followed carefully.

SIC0697

If you see the symbol above, it means “Do not do this” or “Do not let this happen”.

If you see a symbol similar to those above in an illustration, it means the arrow points to the front of the vehicle.

Arrows in an illustration that are similar to those above indicate movement or action.

Arrows in an illustration that are similar to those above call attention to an item in the illustration.

BLUETOOTH®is a trademark owned by Bluetooth SIG, Inc., U.S.A.

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CALIFORNIA PERCHLORATE ADVISORY

Some vehicle parts, such as lithium batteries, may contain perchlorate material. The following advisory is provided: “Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/ hazardouswaste/perchlorate.”

Gracenote®is a registered trademark of Gracenote, Inc. The Gracenote logo and logo type, and the “Powered by Gracenote” logo are trademarks of Gracenote.

2008 NISSAN MOTOR CO., LTD.

All rights reserved. No part of this Owner’s Manual may be reproduced or stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Nissan Motor Co., Ltd.

INFINITI CUSTOMER CARE PROGRAM

INFINITI CARES ... Both INFINITI and your INFINITI dealer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your

INFINITI dealer are our primar y concerns. Your INFINITI dealer is always available to assist you with all your automobile sales and service needs.

However, if there is something that your INFINITI dealer cannot assist you with or you would like to provide INFINITI directly with comments or questions, please contact our (INFINITI’s) Consumer Affairs Department using our toll-free number:

For U.S. customers

1-800-662-6200

For Canadian customers

1-800-361-4792

We appreciate your interest in INFINITI and thank you for buying a quality INFINITI vehicle.

The Consumer Affairs Department will ask for the following information:

— Your name, address, an d telephone

number

— Vehicle identification number (on dash

panel)

— Date of purchase

— Current odometer reading

— Your INFINITI dealer’s name

— Your comments or questions

You can write to INFINITI with the information on the left at:

For U.S. customers

INFINITI Division Nissan North America, Inc. Consumer Affairs Department P.O. Box 685003 Franklin, TN 37068-5003

For Canadian customers

INFINITI Division Nissan Canada Inc. 5290 Orbitor Drive Mississauga, Ontario L4W 4Z5

Illustrated table of contents

Safety — Seats, seat belts and supplemental restraint system

Instruments and controls

Pre-driving checks and adjustments

Monitor, climate, audio, phone and voice recognition systems

Starting and driving

In case of emergency

Appearance and care

Maintenance and do-it-yourself

Technical and consumer information

Index

0 Illustrated table of contents

Seats, seat belts and Supplemental Restraint

System (SRS) .................................................. 0-2

Exterior front

Exterior rear .................................................... 0-4

Passenger compartment ................................... 0-5

Cockpit ........................................................... 0-6

...................................................0-3

Instrument panel .............................................0-8

Meters and gauges ..........................................0-9

Engine compartment ......................................0-10

VQ35HR engine .........................................0-10

VK50VE engine.......................................... 0-11

SEATS, SEAT BELTS AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

8. Rear seats (P.1-5) — Child restraints (P.1-18)

9. Front seat-mounted side-impact supplemental air bags (P.1-37)

10.Seat belt pretensioner (P.1-50)

11.Front seats (P.1-2) — Occupant classification sensors (weight sensors) (P.1-43)

12.Front passenger air bag status light (P.1-45)

SSI0444

1. Child restraint anchor points (for top tether strap child restraint) (P.1-22)

2. Seat belts (P.1-8)

3. Front-seat Active Head Restraint (P.1-6)

4. Roof-mounted curtain side-impact and rollover supplemental air bags (P.1-37)

0-2 Illustrated table of contents

5. Supplemental front-impact air bags (P.1-37)

6. LATCH (Lower Anchors and Tethers for CHildren) system (P.1-20)

7. Rear armrest (P.1-8)

EXTERIOR FRONT

7. Outside mirrors (P.3-23) — Side view camera (if so equipped) (P.4-26) — Welcome light (P.2-62)

8. Doors

— Keys (P.3-2) — Door locks (P.3-4) — Intelligent Key system (P.3-6) — Remote keyless entry system (P.3-13)

9. Recovery hook (P.6-14)

10.Front view camera (if so equipped) (P.4-

26)

11.Fog light (P.2-42)

12.Sonar sensor — Around View Monitor (if so equipped) (P.4-26)

13.Tires

— Wheel and tires (P.8-31, P.9-9) — Flat tire (P.6-2) — Tire pressure monitoring system

(TPMS) (P.2-16, P.5-3)

SSI0445

1. Hood (P.3-16)

2. Headlight and turn signal (P.2-36)

— Bulb replacement (P.8-19) — Adaptive Front lighting System (AFS)

(if so equipped) (P.2-39)

3. Windshield wiper and washer (P.2-33) — Maintenance (P.8-21)

4. Moonroof (if so equipped) (P.2-60)

5. Roof rack (if so equipped) (P.2-57)

6. Power windows (P.2-58)

Illustrated table of contents 0-3

EXTERIOR REAR

7. Sonar sensor — Around View Monitor (if so equipped) (P.4-26)

8. Rear combination light (Bulb replacement) (P.8-27)

9. Fuel-filler door (P.3-18) — Fuel recommendation (P.9-4)

10.Child safety rear door locks (P.3-6)

SSI0446

1. Rear view camera (if so equipped) (P.4-20)

2. Lift gate (P.3-16)

— Intelligent Key system (P.3-6) — Remote keyless entry system (P.3-13)

0-4 Illustrated table of contents

3. Rear window defroster switch (P.2-36)

4. High-mounted stop light (Bulb replacement) (P.8-27)

5. Rear window wiper and washer (P.2-35) — Maintenance (P.8-22)

6. Antenna (P.4-45)

PASSENGER COMPARTMENT

SSI0447

4. Power window controls (P.2-58)

5. Automatic drive positioner switch (if so equipped) (P.3-24)

6. Sun visors (P.3-21)

7. Moonroof switch (if so equipped) (P.2-60)

8. Map light (P.2-63)

9. Sunglasses holder (P.2-51)

10.Inside rearview mirror (P.3-21) — HomeLink

(if so equipped) (P.2-65)

— Compass (if so equipped) (P.2-9)

11.Cargo cover (if so equipped) (P.2-55)

12.Rear cup holders (P.2-50)

13.Console box

— Power outlet (P.2-49) — Auxiliary input jacks (P.4-72) — INFINITI iPod

Interface System (if so

equipped) (P.4-59)

14.Front cup holders (P.2-50)

1. Coat hooks (P.2-53)

2. Rear personal light (P.2-63)

3. Mobile Entertainment System (MES) (if so equipped)

— Flip-down screen (P.4-72) — Digital Versatile Disc (DVD) drive

(P.4-72)

— Headphones (P.4-75) — DVD remote controller (P.4-76)

Illustrated table of contents 0-5

COCKPIT

1. Outside mirror remote control switch (P.3-23)

2. Adaptive Front lighting System (AFS) switch (if so equipped) (P.2-39)/Headlight aiming control switch (P.2-39)

SIC3823

3. Instrument brightness control switch (P.2-41)

4. Headlight, fog light and turn signal switch (P.2-36)

5. Steering-wheel-mounted controls (left side)

— ENTER or tuning switch (P.4-69) — BACK switch (P.4-69) — TALK switch (if so equipped)

(P.4-111)/Phone switch (if so equipped) (P.4-85)

— Volume control switches (P.4-69) — Source select switch (P.4-69)

6. Trip computer switch (P.2-28)

7. Windshield wiper and washer switch (P.2-33)

8. Steering-wheel-mounted controls (right side)

— Cruise control switches (P.5-25) — Intelligent Cruise Control (ICC)

switches (if so equipped) (P.5-27) — Lane Departure Prevention (LDP) switch (if so equipped) (P.5-18)

9. Intelligent Brake Assist (IBA) off switch (if so equipped) (P.2-46)

10.Vehicle Dynamic Control (VDC) OFF switch (P.5-77)

11.Intelligent Key port (P.5-11)

0-6 Illustrated table of contents

12.Forward Collision Warning (FCW) and Lane Departure Warning (LDW) switch (if so equipped) — Forward Collision Warning (FCW) (P.2-45, 5-61) — Lane Departure Warning (LDW) (P.2-44, 5-18)

13.Distance Control Assist (DCA) switch (if so equipped) (P.2-47)

14.TRIP/RESET switch for twin trip odometer (P.2-6)

15.Electric tilting/telescopic steering wheel lever (if so equipped) (P.3-19)

16.Manual tilting/telescopic steering wheel lever (if so equipped) (P.3-19)

17.Center-console-mounted controls — Climate controlled seat switches (if so equipped) (P.2-43)

— SNOW mode switch (P.2-45) — Continuous Damping Control mode

select switch (if so equipped) (P.2-46, 5-72)

Illustrated table of contents 0-7

INSTRUMENT PANEL

1. Side ventilator (P.4-37)

2. Paddle shifter (if so equipped) (P.5-15)

3. Meters and gauges (P.2-5)

4. Center ventilator (P.4-37)

0-8 Illustrated table of contents

SIC3824

5. Center multi-function control panel

— Navigation system* (if so equipped) — Vehicle information and setting

buttons (P.4-8) — Bluetooth

Hands-Free Phone System (if so equipped) (P.4-85) — Around View Monitor (if so equipped)

(P.4-26)

6. Center display (P.4-2)

7. Clock (P.2-48)

8. Hazard warning flasher switch (P.2-42)

9. Front passenger supplemental air bag (P.1-37)

10.Hood release handle (P.3-16)

11.Fuse box cover (P.8-23)

12.Parking brake (P.5-17)

13.Steering wheel

— Horn (P.2-43) — Driver supplement air bag (P.1-37)

14.Push-button ignition switch (P.5-9)

15.Front passenger air bag status light (P.1-43)

16.Power outlet (P.2-49)

17.Rear window defogger switch (P.2-36)

18.CompactFlash card slot (if so equipped) (P.4-57)

19.Automatic climate control system (P.4-

38)

20.Audio system (P.4-43)

21.Glove box lid release handle (P.2-52)

*: Refer to the separate Navigation System

Owner’s Manual.

METERS AND GAUGES

SIC3825

1. Tachometer (P.2-7)

2. Warning/Indicator lights (P.2-12)

3. Speedometer (P.2-6)

4. Engine coolant temperature gauge (P.2-7)

5. Dot matrix liquid crystal display/Odometer/twin trip odometer (P.2-22)

6. Fuel gauge (P.2-8)

Illustrated table of contents 0-9

ENGINE COMPARTMENT

10.Drive belts (P.8-18)

11.Coolant reservoir (P.8-9)

SDI2262

VQ35HR ENGINE

1. Fuse/fusible link holder (P.8-23)

2. Battery (P.8-16)

3. Radiator filler cap (P.8-9)

4. Engine oil dipstick (P.8-10)

0-10 Illustrated table of contents

5. Engine oil filler cap (P.8-10)

6. Brake fluid reservoir (P.8-15)

7. Window washer fluid reservoir (P.8-15)

8. Power steering fluid reservoir (P.8-14)

9. Air cleaner (P.8-20)

SDI2264

10.Drive belt location (P.8-18)

11.Coolant reservoir (P.8-9)

VK50VE ENGINE

1. Fuse/fusible link holder (P.8-23)

2. Battery (P.8-16)

3. Engine oil filler cap (P.8-10)

4. Radiator filler cap (P.8-9)

5. Engine oil dipstick (P.8-10)

6. Brake fluid reservoir (P.8-15)

7. Window washer fluid reservoir (P.8-15)

8. Power steering fluid reservoir (P.8-14)

9. Air cleaner (P.8-20)

Illustrated table of contents 0-11

MEMO

0-12

Illustrated table of contents

1 Safety — Seats, seat belts and supplemental

restraint system

Seats.............................................................. 1-2

Front seats.................................................. 1-2

Rear seats................................................... 1-5

Head restraint ............................................. 1-6

Front-seat Active Head Restraints .................. 1-7

Armrest (if so equipped)............................... 1-8

Seat belts .......................................................1-8

Precautions on seat belt usage .....................1-8

Child safety............................................... 1-11

Pregnant women........................................ 1-12

Injured persons .........................................1-12

Pre-crash seat belts with comfort function

(front seats) (if so equipped) ......................1-12

Three-point type seat belt .......................... 1-13

Seat belt extenders.................................... 1-17

Seat belt maintenance ............................... 1-17

Child restraints.............................................. 1-18

Precautions on child restraints.................... 1-18

Lower Anchors and Tethers for CHildren

system (LATCH).......................................... 1-20

Top tether strap child restraint.................... 1-22

Child restraint installation using LATCH ....... 1-23

Child restraint installation using the seat

belts......................................................... 1-27

Booster seats ................................................ 1-33

Precautions on booster seats...................... 1-33

Booster seat installation ............................ 1-35

Supplemental restraint system........................ 1-37

Precautions on supplemental restraint

system ..................................................... 1-37

INFINITI Advanced Air Bag System

(front seats) .............................................. 1-43

Front seat-mounted side-impact supplemental air bag and roof-mounted curtain side-impact and rollover

supplemental air bag systems .................... 1-48

Seat belts with pretensioners

(front seats) .............................................. 1-50

Supplemental air bag warning labels........... 1-51

Supplemental air bag warning light............. 1-51

Repair and replacement procedure .............. 1-52

SEATS

WARNING

. Do not ride in a moving vehicle when the

seatback is reclined. This can be dangerous. The shoulder belt will not be against your body. In an accident, you could be thrown into it and receive neck or other serious injuries. You could also slide under the lap belt and receive serious internal injuries.

. For the most effective protection when

the vehicle is in motion, the seat should be upright. Always sit well back in the seat with both feet on the floor and

adjust the seat belt properly. See “PRECAUTIONS ON SEAT BELT USAGE” later in this section.

. After adjustment, gently rock in the seat

to make sure it is securely locked.

. Do not leave children unattended inside

the vehicle. They could unknowingly activate switches or controls. Unattended children could become involved in serious accidents.

1-2 Safety — Seats, seat belts and supplemental restraint system

SSS0133

FRONT SEATS

Front power seat adjustment

Operating tips:

. The power seat motor has an auto-reset

overload protection circuit. If the motor stops during operation, wait 30 seconds, then reactivate the switch.

. Do not operate the power seat switch

for a long period of time when the engine is off. This will discharge the battery.

See “AUTOMATIC DRIVE POSITIONER” in the “3. Pre -driving checks and adjustments” section for the seat position memory function.

CAUTION

When adjusting the seat positions, be sure not to contact any moving parts to avoid possible injuries and/or damages.

SSS0834

SSS0835

Forward and backward:

Moving the switch will slide the seat forward or backward to the desired position.

Reclining:

Move the recline switch the desired angle is obtained. To bring the seatback forward again, move the switch

forward.

The reclining feature allows adjustment of the seatback for occupants of different sizes for added comfort and to help obtain proper seat belt fit. (See “PRECAUTIONS ON SEAT BELT USAGE” later in this section.)

forward or backward

backward until

Also, the seatback can be reclined to allow occupants to rest when the vehicle is parked.

WARNING

The seatback should not be reclined any more than needed for comfort. Seat belts are most effective when the passenger sits well back and straight up in the seat. If the seatback is reclined, the risk of sliding under the lap belt and being injured is increased.

Safety — Seats, seat belts and supplemental restraint system 1-3

Seat lifter:

Push the front or rear end of the switch up or down to adjust the angle or height of the seat.

SSS0795

SSS0685

SSS0893

Lumbar support:

The lumbar support feature provides lower back support to the driver.

Push the front switch to adjust the seatback lumbar area.

or back

end of the

Side support (if so equipped):

The side support feature provides thigh and torso supports. Push the switch inside

or outside

Push the switch inside adjust the torso area.

1-4 Safety — Seats, seat belts and supplemental restraint system

to adjust the thigh area.

or outside

Thigh extension (if so equipped):

The front portion of the front seats can be extended forward for seating comfort. Pull

up and hold the lever

front portion to the desired position.

to extend the

REAR SEATS

WARNING

. Never allow anyone to ride in the cargo

area or on the rear seat when it is in the fold-down position. Use of these areas by passengers without proper restraints could result in serious injury in an accident or sudden stop.

. When returning the seatbacks to the

upright position, be certain they are completely secured in the latched position. If they are not completely secured, passengers may be injured in an accident or sudden stop.

. Properly secure all cargo to help prevent

it from sliding or shifting. Do not place cargo higher than the seatbacks. In a sudden stop or collision, unsecured cargo could cause personal injury.

SSS0894

Reclining

Pull the reclining lever seatback at the desired angle. Release the reclining lever after positioning the seat at the desired angle.

To return the seatback, pull the lever.

The reclining feature allows adjustment of the seatback for occupants of different sizes to help obtain proper seat belt fit. (See “PRECAUTIONS ON SEAT BELT USAGE” later in this section.) The seatback may also be reclined to allow occupants to rest when the vehicle is parked.

and position the

WARNING

. Do not ride in a moving vehicle when the

. For the most effective protection when

the vehicle is in motion, the seat should be upright. Always sit well back in the seat with both feet on the floor and adjust the seat belt properly. See “PRECAUTIONS ON SEAT BELT USAGE” later in this section.

. After adjustment, check to be sure the

seat is securely locked.

Safety — Seats, seat belts and supplemental restraint system 1-5

HEAD RESTRAINT

WARNING

Head restraints should be adjusted properly as they may provide significant protection against injury in an accident. Do not remove them. Check the adjustment after someone else uses the seat.

SSS0895

Folding

Before folding the rear seats:

Remove drink containers from the rear cup holder.

To fold down the seatbacks:

Pull the lever seatback.

Return the rear seatback manually until it securely locks in position.

and fold the

1-6 Safety — Seats, seat belts and supplemental restraint system

SSS0288

Adjustment

To raise the head restraint, push and hold the lock knob seats) and pull it up.

To lower, push and hold the lock knob and push the head restraint down.

(if so equipped for rear

SSS0287

Adjust the head restraint so the center is level with the center of your ears.

SSS0508

FRONT-SEAT ACTIVE HEAD RESTRAINTS

WARNING

. Always adjust the head restraints prop-

erly as specified in the previous section. Failure to do so can reduce the effectiveness of the Active Head Restraint.

. Active Head Restraints are designed to

supplement other safety systems. Always wear seat belts. No system can prevent all injuries in any accident.

. Do not attach anything to the head

restraint stalks. Doing so could impair Active Head Restraint function.

The Active Head Restraint moves forward utilizing the force that the seatback receives from the occupant in a rear-end collision. The movement of the head restraint helps support the occupant’s head by reducing its backward movement and helping absorb some of the forces that may lead to whiplash type injuries.

Active Head Restraints are effective for collisions at low to medium speeds in which it is said that whiplash injury occurs most.

Active Head Restraints operate onl y in certain rear-end collisions. After the collision, the head restraints return to their original positions.

Properly adjust the Active Head Restraints as described in the previous section.

Safety — Seats, seat belts and supplemental restraint system 1-7

SSS0901

ARMREST (if so equipped) Rear armrest

Pull the tab and draw the armrest forward until it is horizontal.

SEAT BELTS

PRECAUTIONS ON SEAT BELT USAGE

If you are wearing your seat belt properly adjusted, and you are sitting upright and well back in your seat with both feet on the floor, your chances of being injured or killed in an accident and/or the severity of injury may be greatly reduced. INFINITI strongly encourages you and all of your passengers to buckle up every time you drive, even if your seating position includes a supplemental air bag.

Most U.S. states and Canadian provinces or territories specify that seat belts be worn at all times when a vehicle is being driven.

1-8 Safety — Seats, seat belts and supplemental restraint system

WARNING

. Every person who drives or rides in this

vehicle should use a seat belt at all times. Children should be properly restrained in the rear seat and, if appropriate, in a child restraint.

. The seat belt should be properly ad-

justed to a snug fit. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an

SSS0136A

SSS0134A

Safety — Seats, seat belts and supplemental restraint system 1-9

accident. Serious injury or death can occur if the seat belt is not worn properly.

. Always route the shoulder belt over your

shoulder and across your chest. Never put the belt behind your back, under your arm or across your neck. The belt should be away from your face and neck, but not falling off your shoulder.

. Position the lap belt as low and snug as

possible AROUND THE HIPS, NOT THE WAIST. A lap belt worn too high could increase the risk of internal injuries in an accident.

. Be sure the seat belt tongue is securely

fastened to the proper buckle.

. Do not wear the seat belt inside out or

twisted. Doing so may reduce its effectiveness.

. Do not allow more than one person to

use the same seat belt.

. Never carry more people in the vehicle

than there are seat belts.

. If the seat belt warning light glows

continuously while the ignition is turned ON with all doors closed and all seat belts fastened, it may indicate a malfunction in the system. Have the system checked by an INFINITI dealer.

. No changes should made to the seat

belt system. For example, do not modify the seat belt, add material, or install devices that may change the seat belt routing or tension. Doing so may affect the operation of the seat belt system. Modifying or tampering with the seat belt system may result in serious

done by an INFINITI dealer.

. All seat belt assemblies, including

retractors and att aching hardware, should be inspected after any collision by an INFINITI dealer. INFINITI recommends that all seat belt assemblies in use during a collision be replaced unless the collision was minor and the belts show no damage and continue to operate properly.

Seat belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.

. All child restraints and attaching hard-

ware should be inspected after any collision. Always follow the restraint manufacturer’s inspection instructions and replacement recommendations. The child restraints should be replaced if they are damaged.

personal injury.

. Once a seat belt pretensioner has

activated, it cannot be reused and must be replaced together with the retractor. See an INFINITI dealer.

. Removal and installation of preten-

sioner system components should be

1-10 Safety — Seats, seat belts and supplemental restraint system

SSS0016

SSS0014

CHILD SAFETY

Children need adults to help protect them. They need to be properly restrained.

In addition to the general information in this manual, child safety information is available from many other sources, including doctors, teachers, government traffic safety offices, and community organizations. Every child is different, so be sure to learn the best way to transport your child.

There are three basic types of child restraint systems:

. Rear facing child restraint

. Front facing child restraint

. Booster seat

The proper restraint depends on the child’s size. Generally, infants (up to about 1 year and less than 20 lb (9 kg)) should be placed in rear facing child restraints. Front facing child restraints are available for children who outgrow rear facing child restraints and are at least 1 year old. Booster seats are used to help position a vehicle lap/shoulder belt on a child who can no longer use a front facing child restraint.

WARNING

Infants and children need special protection. The vehicle’s seat belts may not fit them properly. The shoulder belt may come too close to the face or neck. The lap belt may not fit over their small hip bones. In an accident, an improperly fitting seat belt could cause serious or fatal injury. Always use appropriate child restraints.

All U.S. states and Canadian provinces or territories require the use of approved child restraints for infants and small children. (See “CHILD RESTRAINTS” later in this section.)

Also, there are other types of child restraints available for larger children for additional protection.

INFINITI recommends that all pre-teens and children be restrained in the rear seat. According to accident statistics, children are safer when properly restrained in the rear seat than in the front seat. This is especially important because your vehicle has a supplemental restraint system (air bag system) for the front passenger. (See “SUPPLEMENTAL RESTRAINT SYSTEM” later in this section.)

Safety — Seats, seat belts and supplemental restraint system 1-11

Infants

Infants up to at least one year old should be placed in a rear facing child restraint. INFINITI recommends that infants be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint which fits your vehicle and always follow the manufacturer’s instructions for installation and use.

Small children

Children that are over one year old and weigh at least 20 lb (9 kg) can be placed in a forward facing child restraint. Refer to the manufacturer’s instructions for minimum and maximum weight and height recommendations. INFINITI recommends that small children be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manufacturer’s instructions for installation and use.

Larger children

Children who are too large for child restraints should be seated and restrained by the seat belts which are provided. The seat belt may not fit properly if the child is

less than 4 ft 9 in (142.5 cm) tall and weighs between 40 lb (18 kg) and 80 lb (36 kg). A booster seat should be used to obtain proper seat belt fit.

INFINITI recommends that a child be placed in a commercially available booster seat if the shoulder belt in the child’s seating position fits close to the face or neck or if the lap portion of the seat belt goes across the abdomen. The booster seat should raise the child so that the shoulder belt is properly positioned across the top, middle portion of the shoulder and the lap belt is low on the hips. A booster seat can only be used in seating positions that have a threepoint type seat belt. The booster seat should fit the vehicle seat and have a label certifying that it complies with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. Once the child has grown so the shoulder belt is no longer on or near the face and neck, use the shoulder belt without the booster seat.

WARNING

Never let a child stand or kneel on any seat and do not allow a child in the cargo areas while the vehicle is moving. The child could be seriously injured or killed in an accident

or sudden stop.

PREGNANT WOMEN

INFINITI recommends that pregnant women use seat belts. The seat belt should be worn snug, and always position the lap belt as low as possible around the hips, not the waist, and place the shoulder belt over your shoulder and across your chest. Never run the lap/shoulder belt over your abdominal area. Contact your doctor for specific recommendations.

INJURED PERSONS

INFINITI recommends that injured persons use seat belts, depending on the injury. Check with your doctor for specific recommendations.

PRE-CRASH SEAT BELTS WITH COMFORT FUNCTION (front seats) (if so equipped)

The pre-crash seat belt tightens the seat belt with a motor to help restrain front seat occupants. This helps reduce the risk of injury in a collision.

The motor retracts the seat belt under the following emergency conditions:

. During emergency braking

1-12 Safety — Seats, seat belts and supplemental restraint system

. During sudden steering maneuvers

. Activation of the Intelligent Brake As-

sist (IBA) system. (See “INTELLIGENT BRAKE ASSIST (IBA) SYSTEM” in the “5. Starting and driving” section.)

The pre-crash seat belt will not be active when:

. the seat belt is not fastened

. the vehicle speed is under 10 MPH (15

km/h) during emergency braking

. the vehicle speed is under 16 MPH (30

km/h) during sudden steering maneuvers.

The pre-crash seat belt will not be active when the brake pedal is not depressed except when sudden steering maneuvers occur and the Intelligent Brake Assist (IBA) system activates.

The motor also retracts the seat belt when the seat belt is fastened or unfastened. When the seat belt is fastened, the motor tightens the seat belt for a snug fit. When the seat belt is unfastened, the motor retracts the seat belt. If the seat belt is not fully retracted, the motor retracts the seat belt when the door is opened.

Always wear your seat belt correctly and sit upright and well back.

If the motor cannot retract the seat belt when the seat belt is fastened or unfastened, it may indicate the pre-crash seat belt system has a malfunction. Have your INFINITI dealer check and repair the system.

When the seat belt is retracted repeatedly in a short period of time, the motor may not be able to retract the seat belt. After 30 seconds, the motor reactivates and retracts the seat belt. If the seat belt still cannot be retracted by the motor, the pre-crash seat belt system has a malfunction. Have your INFINITI dealer check and repair the system.

THREE-POINT TYPE SEAT BELT

WARNING

. Every person who drives or rides in this

vehicle should use a seat belt at all times.

. Do not ride in a moving vehicle when the

serious internal injuries.

. For the most effective protection when

the vehicle is in motion, the seat should be upright. Always sit well back in the seat with both feet on the floor and adjust the seat belt properly.

SSS0292

Fastening the seat belts

1. Adjust the seat. (See “SEATS” earlier in this section.)

2. Slowly pull the seat belt out of the retractor and insert the tongue into the buckle until you hear and feel the latch engage.

. The retractor is designed to lock

during a sudden stop or on impact. A slow pulling motion permits the belt to move, and allows you some freedom of movement in the seat.

. If the seat belt cannot be pulled

from its fully retracted position,

Safety — Seats, seat belts and supplemental restraint system 1-13

+ 456 hidden pages

Infiniti S51-D User Manual

Table of Contents
