Infiniti G Coupe 2013 User Manual

For your safety, read carefully and keep in this vehicle.

2013 Inﬁniti G Coupe Owner’s Manual

Foreword

GUID-5A04CF95-E0E6-4709-8CAB-124C89524786

Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior craftsmanship with a simple, refined aesthetic sensitivity associated with traditional Japanese culture.

The result is a different notion of luxury and beauty. The car itself is important, but so is the sense of harmony that the vehicle evokes in its driver, and the sense of satisfaction you feel with the INFINITI — from the way it looks and drives to the high level of retailer service.

To ensure that you enjoy your INFINITI to the fullest, we encourage you to read this Owner’s Manual immediately. It explains all of the features, controls and performance characteristics of your INFINITI; it also provides important instructions and safety information.

A separate Warranty Information Booklet is included in your Owner’s literature portfolio. The INFINITI Service and Maintenance Guide explains details about maintaining and servicing your vehicle. Always carry it with you when you take your vehicle to an INFINITI retailer. The Warranty Information Booklet contents provide complete information about all

warranties covering this vehicle, the requirements to keep the warranties in effect as well as the INFINITI Roadside Assistance program.

Additionally, a separate Customer Care and Lemon Law Information Booklet will explain how to resolve any concerns you may have with your vehicle, as well as clarify your rights under your state’s lemon law.

In addition to factory installed options, your vehicle may also be equipped with additional accessories installed by INFINITI or by your INFINITI retailer prior to delivery. It is important that you familiarize yourself with all disclosures, warnings, cautions and instructions concerning proper use of such accessories prior to operating the vehicle and/or accessory. See an INFINITI retailer for details concerning the particular accessories with which your vehicle is equipped.

READ FIRST — THEN DRIVE SAFELY

Before driving your vehicle, read your Owner’s Manual carefully. This will ensure familiarity with controls and maintenance requirements, assisting you in the safe operation of your vehicle.

GUID-31F0CB1B-66AC-4CED-9231-F664F7DF2BA8

WARNING

IMPORTANT SAFETY INFORMATION REMINDERS FOR SAFETY!

Follow these important driving rules to help ensure a safe and comfortable trip for you and your passengers!

. NEVER drive under the influence of

alcohol or drugs.

. ALWAYS observe posted speed limits

and never drive too fast for conditions.

. ALWAYS give your full attention to

driving and avoid using vehicle features or taking other actions that could distract you.

. ALWAYS use your seat belts and appro-

priate child restraint systems. Pre-teen children should be seated in the rear seat.

. ALWAYS provide information about the

proper use of vehicle safety features to all occupants of the vehicle.

. ALWAYS review this Owner’s Manual for

important safety information.

IMPORTANT INFORMATION ABOUT THIS MANUAL

You will see various symbols in this manual. They are used in the following ways:

GUID-7A07B2BC-A0CA-4D51-BC19-17D5E32FD79D

MODIFICATION OF YOUR VEHICLE

This vehicle should not be modified. Modification could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from modification will not be covered under the INFINITI warranties.

WHEN READING THE MANUAL

This manual includes information for all options available on this model. Therefore, you may find some information that does not apply to your vehicle.

All information, specifications and illustrations in this manual are those in effect at the time of printing. INFINITI reserves the right to change specifications or design at any time without notice.

GUID-EA2A5347-A23E-4B25-B5B5-2D387C7A767C

WARNING

This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.

CAUTION

This is used to indicate the presence of a hazard that could cause minor or moderate personal injury or damage to your vehicle. To avoid or reduce the risk, the procedures must be followed carefully.

SIC0697

If you see the symbol above, it means “Do not do this” or “Do not let this happen”.

NOS1274

If you see a symbol similar to those above in an illustration, it means the arrow points to the front of the vehicle.

NOS1275

Arrows in an illustration that are similar to those above indicate movement or action.

NOS1276

Arrows in an illustration that are similar to

those above call attention to an item in the illustration.

CALIFORNIA PROPOSITION 65 WARNING

GUID-EB044E65-691F-4329-B36B-9A16CC2327A4

WARNING

Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

Bluetooth®is a trademark owned by Bluetooth SIG, Inc., and licensed to Visteon Corporation and Clarion Co., Ltd.

Gracenote®is a registered trademark of Gracenote, Inc. The Gracenote logo and logo type, and the “Powered by Gracenote” logo are trademarks of Gracenote.

SiriusXM Satellite Radio requires subscription, sold separately. Not available in Alaska, Hawaii or Guam. For more information, visit www.siriusxm.com.

INFINITI-13P

CALIFORNIA PERCHLORATE ADVISORY

Some vehicle parts, such as lithium batteries, may contain perchlorate material. The following advisory is provided: “Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/ hazardouswaste/perchlorate.”

GUID-EA7BD8B7-2CBA-4547-A06C-879E95A86835

Manual may be reproduced or stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Nissan Motor Co., Ltd.

INFINITI CUSTOMER CARE PROGRAM

GUID-937FDFE0-DEDE-4B6A-9377-9722D819AB0B

INFINITI CARES ... Both INFINITI and your INFINITI retailer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your

INFINITI retailer are our primary concerns.Your INFINITI retailer is always available to assist you with all your automobile sales and service needs.

However, if there is something that your INFINITI retailer cannot assist you with or you would like to provide INFINITI directly with comments or questions, please contact our (INFINITI’s) Consumer Affairs Department using our toll-free number:

For U.S. customers

1-800-662-6200

For Canadian customers

1-800-361-4792

The Consumer Affairs Department will ask for the following information:

. Your name, address, and telephone

number

. Vehicle identification number (on dash

panel)

. Date of purchase

You can write to INFINITI with the information on the left at:

For U.S. customers

INFINITI Division Nissan North America, Inc. Consumer Affairs Department P.O. Box 685003 Franklin, TN 37068-5003 or via e-mail at: nnaconsumeraffairs@nissan-usa.com

For Canadian customers

INFINITI Division Nissan Canada Inc. 5290 Orbitor Drive Mississauga, Ontario L4W 4Z5 or via e-mail at: information.centre@nissancanada. com

If you prefer, visit us at: www.infinitiUSA.com(for U.S. customers)

or www.infiniti.ca(for Canadian customers) We appreciate your interest in INFINITI and

thank you for buying a quality INFINITI vehicle.

. Current odometer reading . Your INFINITI retailer’s name . Your comments or questions

Table of

Illustrated table of contents

Contents

Safety — Seats, seat belts and supplemental restraint system

Instruments and controls

Pre-driving checks and adjustments

Monitor, climate, audio, phone and voice recognition systems

Starting and driving

In case of emergency

Appearance and care

Maintenance and do-it-yourself

Technical and consumer information

Index

0 Illustrated table of contents

Seats, seat belts and Supplemental Restraint

System (SRS) .......................................................... 0-2

Exterior front .......................................................... 0-3

Sedan ................................................................ 0-3

Coupe ................................................................ 0-4

Exterior rear ............................................................ 0-5

Sedan ................................................................ 0-5

Coupe ................................................................ 0-6

Exterior (INFINITI Performance Line model

- Coupe) ................................................................. 0-7

Passenger compartment ......................................... 0-8

Sedan ............................................................... 0-8

Coupe ............................................................... 0-9

Cockpit ................................................................. 0-10

Instrument panel .................................................. 0-11

Meters and gauges .............................................. 0-13

Engine compartment ............................................ 0-14

VQ25HR/VQ37VHR engine .............................. 0-14

Warning and indicator lights ................................ 0-15

SEATS, SEAT BELTS AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

GUID-58411523-3D47-486F-9D5C-79E845EBE0CB

1. Supplemental front-impact air bags (P.1-42)

2. Front seat-mounted side-impact supplemental air bags (P.1-42)

3. Seat belts (P.1-14)

4. Head restraints (P.1-9)

8. Front seats (P.1-3)

9. Seat belts with pretensioners (P.1-55)

10. Rear seat walk-in mechanism (Coupe) (P.1-6)

11. Rear seats (P.1-7) — Child restraints (P.1-24)

12. LATCH (Lower Anchors and Tethers for CHildren) system (P.1-26)

SSI0667

5. Roof-mounted curtain side-impact supplemental air bags (P.1-42)

6. Child restraint anchor points (for top tether strap child restraint) (P.1-28)

7. Occupant classification sensor (pattern sensor) (P.1-47)

0-2 Illustrated table of contents

EXTERIOR FRONT

GUID-8717B1C7-6F7F-40EB-8277-9FF3CC88B2F6

6. Recovery hook (P.6-14)

7. Fog light (P.2-39)

8. Tires

— Wheel and tires (P.8-34, P.9-9) — Flat tire (P.6-2) — Tire pressure monitoring system

(TPMS) (P.2-15, P.5-4)

9. Outside mirrors (P.3-29)

10. Doors

— Keys (P.3-2) — Door locks (P.3-4) — Intelligent Key system (P.3-7) — Remote keyless entry system

(P.3-14)

SSI0643

SEDAN

1. Hood (P.3-17)

GUID-79DD3727-9840-4EBC-90BA-C1063732CCE6

2. Headlight and turn signal

— Operation (P.2-34) — Bulb replacement (P.8-29)

3. Windshield wiper and washer

— Operation (P.2-31) — Maintenance (P.8-22)

4. Moonroof (if so equipped) (P.2-55)

5. Power windows (P.2-52)

Illustrated table of contents 0-3

SSI0806

6. Recovery hook (P.6-14)

7. Fog light (P.2-39)

8. Tires

— Wheel and tires (P.8-34, P.9-9) — Flat tire (P.6-2) — Tire pressure monitoring system

(TPMS) (P.2-15, P.5-4)

9. Outside mirrors (P.3-29)

10. Doors

— Keys (P.3-2) — Door locks (P.3-4) — Intelligent Key system (P.3-7) — Remote keyless entry system

(P.3-14)

COUPE

1. Hood (P.3-17)

GUID-AC0B3EEA-9252-4992-8E97-317D9777AC16

2. Headlight and turn signal

— Operation (P.2-34) — Bulb replacement (P.8-29)

0-4 Illustrated table of contents

3. Windshield wiper and washer

— Operation (P.2-31) — Maintenance (P.8-22)

4. Moonroof (if so equipped) (P.2-55)

5. Power windows (P.2-52)

EXTERIOR REAR

GUID-F8364FC5-18EF-423D-AF68-9A1FF66F1421

6. Rear view camera (if so equipped) (P.4-23)

7. Sonar system (if so equipped) (P.5-49)

8. Trunk

— Intelligent Key system (P.3-7) — Remote keyless entry system

(P.3-14) — Trunk lid (P.3-18)

9. Child safety rear door locks (P.3-6)

JVC0207X

SEDAN

1. High-mounted stop light (Bulb repla-

GUID-45DE1062-D8E4-4EF5-87B4-9A80F0953604

cement) (P.8-29)

2. Rear window defroster (P.2-34)

3. Rear combination light (Bulb replacement) (P.8-29)

4. Satellite antenna (P.4-43)

5. Fuel-filler door

— Operation (P.3-22) — Fuel recommendation (P.9-4)

Illustrated table of contents 0-5

SSI0685

6. Trunk

— Intelligent Key system (P.3-7) — Remote keyless entry system

(P.3-14) — Trunk lid (P.3-18)

7. Sonar system (if so equipped) (P.5-49)

8. Rear combination light (Bulb replacement) (P.8-29)

9. Fuel-filler door

— Operation (P.3-22) — Fuel recommendation (P.9-4)

COUPE

1. High-mounted stop light (model with

GUID-D7686CCA-4082-4CD6-B2BB-FF3FE9F1882F

a rear spoiler) (Bulb replacement) (P.8-29)

2. High-mounted stop light (model without a rear spoiler) (Bulb replacement) (P.8-29)

0-6 Illustrated table of contents

3. Rear window defroster (P.2-34)

4. Satellite antenna (P.4-43)

5. Rear view camera (if so equipped) (P.4-23)

EXTERIOR (INFINITI Performance Line model - Coupe)

GUID-1E4F0232-4B12-4B79-8147-982513185A8C

For INFINITI Coupe/INFINITI Performance Line model, the vehicle parts listed below require special care or caution for treating. Refer to additional information in each section.

SSI0807

1. Recovery hook (P.6-14)

2. Exhaust pipes (P.3-21)

Illustrated table of contents 0-7

PASSENGER COMPARTMENT

GUID-A5806980-63F4-4D06-9561-5DE8B64E9925

SSI0668

8. Map light (P.2-57)

9. Sunglasses holder (P.2-47)

10. Inside rearview mirror

— Operation (P.3-27) — HomeLink

(if so equipped)

(P.2-59) — Compass (if so equipped) (P.2-9)

11. Trunk pass-through/Rear armrest (P.1-13)

12. Rear cup holders (P.2-45)

13. Console box

— Power outlet (P.2-43) — Auxiliary input jacks (if so

equipped) (P.4-81) — USB input operation (if so

equipped) (P.4-69) — iPod

player operation (if so

equipped) (P.4-79)

14. Front cup holders (P.2-45)

SEDAN

1. Coat hooks (P.2-50)

GUID-9EC9EAB0-0B24-4119-B8DE-794F6B9E7C32

2. Rear personal light (P.2-57)

3. Power windows (P.2-52)

4. Outside mirror remote control switch (P.3-29)

0-8 Illustrated table of contents

5. Automatic drive positioner switch (if so equipped) (P.3-30)

6. Sun visors (P.3-26)

7. Moonroof switch (if so equipped) (P.2-55)

SSI0669

7. Map light (P.2-57)

8. Sunglasses holder (P.2-47)

9. Inside rearview mirror

— Operation (P.3-27) — HomeLink

(if so equipped)

(P.2-59) — Compass (if so equipped) (P.2-9)

10. Rear cup holders (P.2-45)

11. Console box

— Power outlet (P.2-43) — Auxiliary input jacks (if so

equipped) (P.4-81) — USB input operation (if so

equipped) (P.4-69) — iPod

player operation (if so

equipped) (P.4-79)

12. Front cup holders (P.2-45)

COUPE

1. Coat hooks (P.2-50)

GUID-3662A08E-793C-483E-8FA6-41A69FDC65AC

2. Power windows (P.2-52)

3. Outside mirror remote control switch (P.3-29)

4. Automatic drive positioner switch (if so equipped) (P.3-30)

5. Sun visors (P.3-26)

6. Moonroof switch (if so equipped) (P.2-55)

Illustrated table of contents 0-9

COCKPIT

GUID-6A5E5003-C9B2-4452-B103-DD9F44DAD191

1. Vehicle Dynamic Control (VDC) OFF switch (P.5-56)

2. Trunk lid release switch (P.3-18)

3. Sonar system off switch (if so equipped) (P.5-51)

0-10 Illustrated table of contents

SIC4683

4. Instrument brightness control switch (P.2-38)

5. TRIP/RESET switch for twin trip odometer (P.2-7)

6. Headlight, fog light and turn signal switch (P.2-34)

7. Paddle shifter (if so equipped) (P.5-16)

8. Steering-wheel-mounted controls (left side)

— ENTER or tuning switch (P.4-83) — BACK switch (P.4-83) — TALK switch (if so equipped)

(P.4-110)/Phone switch (if so equipped) (P.4-85, 4-96)

— Volume control switches (P.4-83) — Source select switch (P.4-83)

9. Trip computer switch (P.2-26)

10. Windshield wiper and washer switch (P.2-31)

11. Steering-wheel-mounted controls (right side)

— Cruise control switches (P.5-22) — Intelligent Cruise Control (ICC)

switches (if so equipped) (P.5-24)

12. Hood release handle (P.3-17)

13. Intelligent Key port (P.5-12)

14. Electric tilting/telescopic steering wheel lever (if so equipped) (P.3-25)

15. Manual tilting/telescopic steering wheel lever (if so equipped) (P.3-25)

16. Steering wheel

— Horn (P.2-40) — Driver supplemental air bag

(P.1-42)

INSTRUMENT PANEL

GUID-5BF1CCAC-1271-471E-83A1-FF109419BE46

1. Side ventilator (P.4-30)

2. Meters and gauges (P.2-6)

3. Center ventilator (P.4-30)

4. Audio system (P.4-41)

5. Clock (P.2-43)

6. Center multi-function control panel

SSI0671

— Navigation system* (if so equipped)

— Vehicle information and setting buttons (P.4-9)

— Bluetooth

Hands-Free Phone Sys-

tem (if so equipped) (P.4-85, P.4-96)

— Audio system (P.4-41)

7. Center display (P.4-3)/Navigation system* (if so equipped)

8. Hazard warning flasher switch (P.2-39)

9. Front passenger supplemental air bag (P.1-42)

10. Fuse box cover (P.8-24)

11. Parking brake (for Automatic Transmission models)

— Parking (P.5-21)

12. Push-button ignition switch (P.5-9)

13. Automatic climate control system (P.4-31)

14. Cigarette lighter and ashtray (if so equipped) (P.2-44) or storage box (if so equipped) (P.2-50)

— Power outlet (if so equipped) (P.2-43)

15. Parking brake (for Manual Transmission models)

— Parking (P.5-21)

16. Heated seat switch (if so equipped) (P.2-40)

17. SNOW mode switch (if so equipped) (P.2-42)

18. Rear window and outside mirror (if so equipped) defroster switch (P.2-34)

Illustrated table of contents 0-11

19. Glove box lid release handle (P.2-48)

20. Trunk release power cancel switch (P.3-19)

*: Refer to the separate Navigation

System Owner’s Manual.

0-12 Illustrated table of contents

METERS AND GAUGES

GUID-E8D7EED7-37CE-4B5F-8ECB-479CB10AB8D6

1. Tachometer (P.2-8)

2. Warning/Indicator lights (P.2-12)

3. Speedometer (P.2-7)

4. Engine coolant temperature gauge (P.2-8)

SIC4288

5. Dot matrix liquid crystal display/ Odometer/twin trip odometer (P.2-20)

6. Fuel gauge (P.2-9)

Illustrated table of contents 0-13

ENGINE COMPARTMENT

GUID-4EFFD432-519B-49EA-B9D3-B7E9FD7A6615

8. Air cleaner (P.8-21)

9. Radiator filler cap (P.8-9)

10. Drive belts (P.8-19)

11. Coolant reservoir (P.8-9)

12. Engine oil dipstick (for VQ37VHR engine model) (P.8-11)

13. Engine oil dipstick (for VQ25HR engine model) (P.8-11)

SDI2709

VQ25HR/VQ37VHR ENGINE

1. Fuse/fusible link holder (P.8-24)

GUID-2D649F04-F3DE-4C0A-877A-1F56F5C15998

2. Battery (P.8-17)

3. Engine oil filler cap (P.8-11)

4. Brake fluid reservoir (P.8-15)

0-14 Illustrated table of contents

5. Clutch fluid reservoir (Manual Transmission models) (P.8-15)

6. Window washer fluid reservoir (P.8-16)

7. Power steering fluid reservoir (P.8-14)

WARNING AND INDICATOR LIGHTS

GUID-20167C10-9FEC-49A8-BD90-B52F0ED487EA

Warning

light

All-Wheel Drive (AWD) warning light (AWD models)*

Name Page

2-12

Warning

light

Name Page

Vehicle Dynamic Control (VDC) warning light

2-17

Anti-lock Braking System (ABS) warning light

Automatic Transmission check warning light

Brake warning light 2-13

Charge warning light 2-14

Engine oil pressure warning light

4 Wheel Active Steer (4WAS) warning light*

Intelligent Cruise Control (ICC) system warning light (orange)*

Intelligent Key warning light 2-15

Low tire pressure warning light 2-15

Master warning light 2-16

Preview Function warning light (orange)*

Seat belt warning light 2-17

Supplemental air bag warning light

2-13

2-14

2-15

2-16

2-17

Indicator

light

Automatic Transmission position indicator light*

Exterior light indicator 2-18

Front fog light indicator light 2-18

Front passenger air bag status light

High beam indicator light 2-18

Malfunction Indicator Light (MIL)

Security indicator light 2-19

Turn signal/hazard indicator lights

Vehicle Dynamic Control (VDC) off indicator light

*: if so equipped

Name Page

2-18

2-19

Illustrated table of contents 0-15

MEMO

0-16 Illustrated table of contents

1 Safety — Seats, seat belts and supplemental

restraint system

Seats ...................................................................... 1-2

Front seats ......................................................... 1-3

Rear seats .......................................................... 1-7

Head restraints (front seats) ............................... 1-9

Head restraints (rear seats) .............................. 1-13

Armrest (if so equipped) ................................... 1-13

Seat belts ............................................................. 1-14

Precautions on seat belt usage ........................ 1-14

Pregnant women .............................................. 1-17

Injured persons ................................................ 1-17

Pre-crash seat belts (front seats) (if

so equipped) .................................................... 1-17

Three-point type seat belt ................................ 1-17

Seat belt extenders .......................................... 1-21

Seat belt maintenance ...................................... 1-21

Child safety .......................................................... 1-22

Infants .............................................................. 1-22

Small children .................................................. 1-23

Larger children ................................................. 1-23

Child restraints ..................................................... 1-24

Precautions on child restraints ......................... 1-24

Lower Anchors and Tethers for CHildren

System (LATCH) ................................................ 1-26

Rear-facing child restraint installation

using LATCH .................................................... 1-28

Rear-facing child restraint installation using

the seat belts ................................................. 1-30

Forward-facing child restraint installation

using LATCH .................................................... 1-33

Forward-facing child restraint installation

using the seat belts ........................................ 1-34

Installing top tether strap ............................... 1-38

Booster seats ................................................. 1-38

Supplemental restraint system ............................. 1-42

Precautions on supplemental

restraint system .............................................. 1-42

INFINITI Advanced Air Bag System

(front seats) .................................................... 1-47

Front seat-mounted side-impact supplemental air bag and roof-mounted curtain side-impact

supplemental air bag systems ........................ 1-53

Seat belts with pretensioners (front seats) ....... 1-55

Supplemental air bag warning labels .............. 1-56

Supplemental air bag warning light ................ 1-56

Repair and replacement procedure .................. 1-57

SEATS

GUID-15F58BF2-1182-4C7C-8EA9-0FDFD873D801

WARNING

. Do not ride in a moving vehicle when the

seatback is reclined. This can be dangerous. The shoulder belt will not be against your body. In an accident, you could be thrown into it and receive neck or other serious injuries. You could also slide under the lap belt and receive serious internal injuries.

. For the most effective protection when

the vehicle is in motion, the seat should be upright. Always sit well back in the

senger sits well back and straight up in the seat. If the seatback is reclined, the risk of sliding under the lap belt and being injured is increased.

CAUTION

When adjusting the seat positions, be sure not to contact any moving parts to avoid possible injuries and/or damages.

SSS0133

seat with both feet on the floor and adjust the seat belt properly. See “Precautions on seat belt usage” (P.1-14).

. After adjustment, gently rock in the seat

to make sure it is securely locked.

. Do not leave children unattended inside

the vehicle. They could unknowingly activate switches or controls. Unattended children could become involved in serious accidents.

. The seatback should not be reclined

further than necessary for comfort. Seat belts are most effective when the pas-

1-2 Safety — Seats, seat belts and supplemental restraint system

FRONT SEATS

Front power seat adjustment

Operating tips:

GUID-D508833B-F102-47A6-A2B6-56CF07852D8B

GUID-78261695-CA4C-40D0-8577-D5ACFE37E844

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

. The power seat motor has an auto-reset

overload protection circuit. If the motor stops during operation, wait 30 seconds, then reactivate the switch.

. Do not operate the power seat switch

for a long period of time when the engine is off. This will discharge the battery.

See “Automatic drive positioner” (P.3-30) for the seat position memory function (if so equipped).

Forward and backward:

Moving the switch

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

forward or backward

will slide the seat forward or backward to the desired position.

Reclining:

Move the recline switch

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

backward until

the desired angle is obtained. To bring the seatback forward again, move the switch

forward.

The reclining feature allows adjustment of the seatback for occupants of different sizes for added comfort and to help obtain proper seat belt fit. (See “Precautions on seat belt usage” (P.1-14).) Also, the seat-

SSS1051

back can be reclined to allow occupants to rest when the vehicle is parked.

Safety — Seats, seat belts and supplemental restraint system 1-3

SSS1052

Seat lifter:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

Push the front or rear end of the switch up or down to adjust the angle of the front portion or height of the seat.

Lumbar support (if so equipped):

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

Type A Push the front or back end of the switch to

adjust the seatback lumbar area.

The lumbar support feature provides lower back support to the driver.

1-4 Safety — Seats, seat belts and supplemental restraint system

Type A

SSS1053

Type B

Move the lever

up or down to adjust the

seatback lumbar area.

SSS0836

SSS0685

SSS1057

SSS1058

Side support (if so equipped):

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

The side support feature provides thigh and torso supports. Push the switch inside

or outside

Push the switch inside

to adjust the thigh area.

or outside

adjust the torso area.

Thigh extension (if so equipped):

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

The front portion of the front seats can be extended forward for seating comfort. Pull up and hold the lever front portion to the desired position.

to extend the

Passenger’s seat slide (if so equipped):

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

Pushing the passenger’s seat slide switch will slide the seat forward or backward to the desired position.

Safety — Seats, seat belts and supplemental restraint system 1-5

Walk-in mechanism (Coupe):

This feature makes it easier to get in and out of the rear seat. Use the following procedure when getting in and out of the rear seat.

If the sun visor is used, close it to the original position before operating the walkin feature.

1. Pull the seatback lever upward fold the front seatback down. Make sure that the front seatback is completely folded down.

2. To slide the front seat forward, firmly push the seatback switch

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

. The front

seat will move forward.

3. Get in or out of the vehicle.

4. To return the front seat to its original position, raise the seatback and push the seatback switch

. To stop the seat sliding, push the

seatback switch seat sliding switch.

. The front passenger seat will stop

returning 7.0 in (177.6 mm) from its front-most position to retain space for the rear passenger.

. Depending on the seat position, the

head restraint may contact the roof

1-6 Safety — Seats, seat belts and supplemental restraint system

again.

again or push the

SSS0786

headlining during the walk-in operation. To prevent possible interference, lower the seat using the seat lifter switch.

CAUTION

. When returning the seat to its original

position, confirm the seat and seatback are locked properly.

. Be careful not to pinch your hand or foot

or bump your head when operating the walk-in seat.

. While operating the walk-in seat, do not

operate the seatback reclining switch. The reclining motor may be damaged.

. Do not place any objects near the

seatback of the front seats. They may be pinched and damaged.

The automatic forwarding and reversing will not work or stop under the following conditions:

. When the vehicle speed is above 4 MPH

(7 km/h) (driver’s seat only).

. When the seat belt is fastened. . When the selector lever is not in the P

(Park) position (Automatic Transmis-

sion model’s driver’s seat) or the parking brake is not applied (Manual Transmission model’s driver’s seat).

. When the door is closed (automatic

forwarding only).

. While the automatic drive positioner

operates.

. When the automatic drive positioner

switches are pushed.

. When the seatback switch is pushed. . When the seat position is adjusted.

Note that the seat must be moved to the front-most position by operating the walkin function or the seat adjusting switches after the battery is disconnected. Otherwise, the seat will not move backward during the walk-in function.

REAR SEATS

Folding (Coupe only)

GUID-58068C6E-B055-4C8D-8938-1936BD5C8640

GUID-985B2C6A-D9B9-4CA7-BE2F-7414DF57F80E

WARNING

. Never allow anyone to ride in the cargo

area or on the rear seat when it is in the fold-down position. Use of these areas by passengers without proper restraints could result in serious injury in an accident or sudden stop.

. Properly secure all cargo with ropes or

straps to help prevent it from sliding or shifting. Do not place cargo higher than the seatbacks. In a sudden stop or collision, unsecured cargo could cause personal injury.

. When returning the seatbacks to the

upright position, be certain they are completely secured in the latched position. If they are not completely secured, passengers may be injured in an accident or sudden stop.

. Closely supervise children when they are

around cars to prevent them from playing and becoming locked in the trunk where they could be seriously injured. Keep the car locked, with the rear

Safety — Seats, seat belts and supplemental restraint system 1-7

seatback and trunk lid securely latched when not in use, and prevent children’s access to car keys.

The rear seatback can be folded according to the following procedure.

SSS0220A

To fold from the trunk:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

3. Fold the rear seatback down

1. Open the trunk lid.

2. Pull the handle

located on the left

side of the trunk. The rear seatback will be unlatched.

1-8 Safety — Seats, seat belts and supplemental restraint system

SSS0219A

To fold from the rear seat:

1. Pull the strap

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

located at the center

bottom of the seatback sideways. The rear seatback will be unlatched.

2. Fold the rear seatback down

SPA2122

SSS0805

To return the seatback:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

1. Fold up the rear seatback.

2. Securely lock the seatback in position.

HEAD RESTRAINTS (front seats)

GUID-8B531645-25BC-4652-833F-432615B358CE

WARNING

Head restraints supplement the other vehicle safety systems. They may provide additional protection against injury in certain rear end collisions. Adjust the head restraints properly, as specified in this section. Check the adjustment after someone else uses the seat. Do not attach anything to the head restraint stalks or remove the head restraint. Do not use the seat if the head restraint has been removed. If the head restraint was removed, reinstall and properly adjust the head restraint before an occupant uses the seating position. Failure to follow these instructions can reduce the effectiveness of the head restraints. This may increase the risk of serious injury or death in a collision.

SSS0989

The illustration shows the seating positions equipped with head restraints. The head restraints of the front seats are adjustable.

Indicates the seating position is

equipped with a head restraint.

Safety — Seats, seat belts and supplemental restraint system 1-9

SSS0992

Components

GUID-DBDCC61D-24FD-4E47-A348-FDC0C6CDF960

1. Head restraint

2. Adjustment notches

Adjustment

Adjust the head restraint so the center is level with the center of your ears.

3. Lock knob

4. Stalk

1-10 Safety — Seats, seat belts and supplemental restraint system

SSS0997

GUID-8B4E4C06-4D63-4200-A51B-5ED68936E652

SSS0993

To raise the head restraint, pull it up.

seating position.

SSS0994

To lower, push and hold the lock knob and push the head restraint down.

SSS0995

Removal

GUID-57DF10FD-7FAA-4FB1-8D61-CC400E811A0D

Use the following procedure to remove the adjustable head restraints.

1. Pull the head restraint up to the highest position.

2. Push and hold the lock knob.

3. Remove the head restraint from the seat.

4. Store the head restraint properly in a secure place so it is not loose in the vehicle.

5. Reinstall and properly adjust the head restraint before an occupant uses the

Safety — Seats, seat belts and supplemental restraint system 1-11

certain rear-end collisions. After the collision, the head restraints return to their original positions.

Adjust the Active Head Restraints properly as described earlier in this section.

SSS0996

Install

GUID-A0266381-3929-4791-B5F4-7F6C9A04687C

1. Align the head restraint stalks with the holes in the seat. Make sure that the head restraint is facing the correct direction. The stalk with the adjustment notches hole with the lock knob

must be installed in the

2. Push and hold the lock knob and push the head restraint down.

3. Properly adjust the head restraint before an occupant uses the seating position.

Front-seat Active Head Restraints

The Active Head Restraint moves forward utilizing the force that the seatback receives from the occupant in a rear-end collision. The movement of the head restraint helps support the occupant’s head by reducing its backward movement and helping absorb some of the forces that may lead to whiplash-type injuries.

Active Head Restraints are effective for collisions at low to medium speeds in which it is said that whiplash-type injury occurs most.

Active Head Restraints operate only in

1-12 Safety — Seats, seat belts and supplemental restraint system

SSS0508

GUID-5D9BA25C-DA31-49D7-B3FB-9413B1B21746

JVR0094X

SSS0678

SSS0677

HEAD RESTRAINTS (rear seats)

GUID-B8D1E43A-60E3-4596-8C90-3AD0A747EA63

The head restraints of the rear seats cannot be removed or adjusted.

Indicates the seating position is

equipped with a head restraint.

ARMREST (if so equipped)

Rear armrest

GUID-A816B76C-44C8-4E8F-8A10-1B4F0B8E76F2

GUID-61E1DB83-21E2-4B96-B569-EF340CDD6AC1

Pull the armrest forward until it is horizontal.

Safety — Seats, seat belts and supplemental restraint system 1-13

Trunk pass-through

GUID-799B2734-1032-4868-BF9B-86682A7F09A9

The rear center seatback can be folded to allow trunk access from inside of the vehicle.

To access the trunk, pull down the rear center armrest and pull out the trunk passthrough lid

To lock the lid, use the mechanical key and turn it to the LOCK position

. To unlock,

turn the mechanical key to the UNLOCK position

. For the mechanical key usage,

see “Keys” (P.3-2). Make sure that the mechanical key is

removed from the trunk pass-through lid

key cylinder before opening or closing the lid. Otherwise the lid and the rear armrest may be damaged.

SEAT BELTS

GUID-B5C09302-142B-4089-942C-50C42BEC0669

PRECAUTIONS ON SEAT BELT USAGE

If you are wearing your seat belt properly adjusted, and you are sitting upright and well back in your seat with both feet on the floor, your chances of being injured or killed in an accident and/or the severity of injury may be greatly reduced. INFINITI strongly encourages you and all of your passengers to buckle up every time you drive, even if your seating position includes a supplemental air bag.

Most U.S. states and Canadian provinces or territories specify that seat belts be worn at all times when a vehicle is being driven.

GUID-4D30048F-6AB3-4FEA-957F-23C643DABF4C

1-14 Safety — Seats, seat belts and supplemental restraint system

WARNING

. Every person who drives or rides in this

vehicle should use a seat belt at all times. Children should be properly restrained in the rear seat and, if appropriate, in a child restraint.

. The seat belt should be properly ad-

justed to a snug fit. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance

SSS0136A

SSS0134A

Safety — Seats, seat belts and supplemental restraint system 1-15

or severity of injury in an accident. Serious injury or death can occur if the seat belt is not worn properly.

. Always route the shoulder belt over your

shoulder and across your chest. Never run the belt behind your back, under your arm or across your neck. The belt should be away from your face and neck, but not falling off your shoulder.

. Position the lap belt as low and snug as

possible AROUND THE HIPS, NOT THE WAIST. A lap belt worn too high could increase the risk of internal injuries in an accident.

. Be sure the seat belt tongue is securely

fastened to the proper buckle.

. Do not wear the seat belt inside out or

twisted. Doing so may reduce its effectiveness.

. Do not allow more than one person to

use the same seat belt.

. Never carry more people in the vehicle

than there are seat belts.

. If the seat belt warning light glows

continuously while the ignition is turned ON with all doors closed and all seat belts fastened, it may indicate a malfunction in the system. Have the system checked by an INFINITI retailer.

. No changes should be made to the seat

belt system. For example, do not modify the seat belt, add material or install devices that may change the seat belt routing or tension. Doing so may affect the operation of the seat belt system. Modifying or tampering with the seat belt system may result in serious perso-

should be done by an INFINITI retailer.

. All seat belt assemblies, including re-

tractors and attaching hardware, should be inspected after any collision by an INFINITI retailer. INFINITI recommends that all seat belt assemblies in use during a collision be replaced unless the collision was minor and the belts show no damage and continue to operate properly.

Seat belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.

. All child restraints and attaching hard-

ware should be inspected after any collision. Always follow the restraint manufacturer’s inspection instructions and replacement recommendations. The child restraints should be replaced if they are damaged.

nal injury.

. Once a seat belt pretensioner has

activated, it cannot be reused and must be replaced together with the retractor. See an INFINITI retailer.

. Removal and installation of the preten-

sioner seat belt system components

1-16 Safety — Seats, seat belts and supplemental restraint system

SSS0016

SSS0014

PREGNANT WOMEN

GUID-AF3C2DF0-16F5-464E-B1C9-A2B02DF135AE

INFINITI recommends that pregnant women use seat belts. The seat belt should be worn snug, and always position the lap belt as low as possible around the hips, not the waist, and place the shoulder belt over your shoulder and across your chest. Never run the lap/shoulder belt over your abdominal area. Contact your doctor for specific recommendations.

INJURED PERSONS

GUID-3574EA04-0EC7-407F-8299-5666BD2D1B17

INFINITI recommends that injured persons use seat belts, depending on the injury. Check with your doctor for specific recommendations.

PRE-CRASH SEAT BELTS (front seats) (if so equipped)

The pre-crash seat belt tightens the seat belt to help restrain front seat occupants under emergency braking. This can help reduce the risk of injury when a collision occurs.

Pre-crash seat belt will not be activated when:

. the brake pedal is not depressed . the seat belt is not fastened

GUID-E8B8D974-2162-458D-A2F5-F4343FCA4064

. the vehicle speed is under 10 MPH (15

km/h)

Always wear your seat belt correctly and sit upright and well back.

If the seat belt warning light blinks even if the driver’s and front passenger’s seat belts are fastened, it may indicate the precrash seat belt system has a malfunction. Have your INFINITI retailer check and repair the system.

THREE-POINT TYPE SEAT BELT

GUID-30E039F3-1C1F-4413-811C-DE74575ADD15

WARNING

. Every person who drives or rides in this

vehicle should use a seat belt at all times.

. Do not ride in a moving vehicle when the

. For the most effective protection when

the vehicle is in motion, the seat should be upright. Always sit well back in the

Safety — Seats, seat belts and supplemental restraint system 1-17

seat with both feet on the floor and adjust the seat belt properly.

. Do not allow children to play with the

seat belts. Most seating positions are equipped with Automatic Locking Retractor (ALR) mode seat belts. If the seat belt becomes wrapped around a child’s neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt can not be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.

Then smoothly pull the belt out of the retractor.

SSS0292

Fastening the seat belts

GUID-B37DD1F9-9FF6-46C4-80B5-F68C6BFB1F41

1. Adjust the seat. (See “Seats” (P.1-2).)

2. Slowly pull the seat belt out of the retractor and insert the tongue into the buckle until you hear and feel the latch engage.

The retractor is designed to lock during a sudden stop or on impact. A slow pulling motion permits the belt to move, and allows you some freedom of movement in the seat.

If the seat belt cannot be pulled from its fully retracted position, firmly pull the belt and release it.

1-18 Safety — Seats, seat belts and supplemental restraint system

SSS0290

3. Position the lap belt portion low and snug on the hips as shown.

4. Pull the shoulder belt portion toward the retractor to take up extra slack. Be sure the shoulder belt is routed over your shoulder and across your chest.

The three-point type seat belts have two modes of operation:

. Emergency Locking Retractor (ELR) . Automatic Locking Retractor (ALR)

The Emergency Locking Retractor (ELR) mode allows the seat belt to extend and retract to allow the driver and passengers some freedom of movement in the seat.

The ELR locks the seat belt when the vehicle slows down rapidly or during impacts.

The Automatic Locking Retractor (ALR) mode (child restraint mode) locks the seat belt for child restraint installation.

When the ALR mode is activated the seat belt cannot be extended again until the seat belt tongue is detached from the buckle and fully retracted. The seat belt returns to the ELR mode after the seat belt fully retracts. For additional information, see “Child restraints” (P.1-24).

The ALR mode should be used only for child restraint installation. During normal seat belt use by an occupant, the ALR mode should not be activated. If it is activated, it may cause uncomfortable seat belt tension.

WARNING

When fastening the seat belts, be certain that seatbacks are completely secured in the latched position. If they are not completely secured, passengers may be injured in an accident or sudden stop.

SSS0326

Unfastening the seat belts

GUID-E5ABF433-63F1-41B4-9060-772462985B76

To unfasten the seat belt, push the button on the buckle. The seat belt automatically retracts.

Checking seat belt operation

GUID-B2C3D22B-2FD8-46E0-9AC6-84735F785EB4

Seat belt retractors are designed to lock seat belt movement by two separate methods:

. When the belt is pulled quickly from the

retractor. . When the vehicle slows down rapidly. To increase your confidence in the seat

belts, check the operation as follows:

. Grasp the shoulder belt and pull

forward quickly. The retractor should lock and restrict further belt movement.

If the retractor does not lock during this check or if you have any question about seat belt operation, see an INFINITI retailer.

Safety — Seats, seat belts and supplemental restraint system 1-19

SSS0687

SSS0294A

WARNING

. After adjustment, release the adjustment

button and try to move the shoulder belt anchor up and down to make sure it is securely fixed in position.

. The shoulder belt anchor height should

be adjusted to the position best for you. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an accident.

Center of rear seat (Sedan)

Selecting correct set of seat belts:

The center seat belt buckle is identified by the CENTER mark tongue can be fastened only into the center seat belt buckle.

GUID-F8C852B7-8F2B-4F66-B9F1-740AF287A7F1

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

. The center seat belt

Shoulder belt height adjustment (for Sedan front seats)

The shoulder belt anchor height should be adjusted to the position best for you. (See “Precautions on seat belt usage” (P.1-14).)

To adjust, push the button move the shoulder belt anchor to the desired position, so that the belt passes over the center of the shoulder. The belt should be away from your face and neck, but not falling off of your shoulder. Release the adjustment button to lock the shoulder belt anchor into position.

1-20 Safety — Seats, seat belts and supplemental restraint system

GUID-9DA0069A-F53D-4536-89F5-3F6983A3F7DF

, and then

SSS0588

Shoulder belt arm (for Coupe front seats)

Before fastening the seat belt, pull the shoulder belt arm forward until it clicks at the lock position. The arm can also be folded down for easier access for rear seat passengers.

Pulling the arm forward will allow an easy access to the belt.

GUID-79A89F1D-4AEA-49A3-B52A-98FCD811131B

SEAT BELT EXTENDERS

GUID-B1D92F02-3294-412F-84BF-88F73FEF6097

If, because of body size or driving position, it is not possible to properly fit the lapshoulder belt and fasten it, an extender that is compatible with the installed seat belts is available that can be purchased. The extender adds approximately 8 in (200 mm) of length and may be used for either the driver or front passenger seating position. See an INFINITI retailer for assistance with purchasing an extender if an extender is required.

WARNING

. Only INFINITI seat belt extenders, made

by the same company which made the original equipment seat belts, should be used with the INFINITI seat belts.

. Adults and children who can use the

standard seat belt should not use an extender. Such unnecessary use could result in serious personal injury in the event of an accident.

. Never use seat belt extenders to install

child restraints. If the child restraint is not secured properly, the child could be seriously injured in a collision or a

sudden stop.

SEAT BELT MAINTENANCE

GUID-FD012A51-6217-44CA-9A47-C28EBAF61CDE

. To clean the seat belt webbing, apply a

mild soap solution or any solution recommended for cleaning upholstery or carpets. Then, wipe with a cloth and allow the seat belts to dry in the shade. Do not allow the seat belts to retract until they are completely dry.

. If dirt builds up in the shoulder belt

guide of the seat belt anchors, the seat

belts may retract slowly. Wipe the shoulder belt guide with a clean, dry cloth.

. Periodically check to see that the seat

belt and the metal components such as

buckles, tongues, retractors, flexible wires and anchors work properly. If loose parts, deterioration, cuts or other damage on the webbing is found, the entire seat belt assembly should be replaced.

Safety — Seats, seat belts and supplemental restraint system 1-21

CHILD SAFETY

GUID-758C3ADB-56E4-4839-A833-17F0574CC784

WARNING

Do not allow children to play with the seat belts. Most seating positions are equipped with Automatic Locking Retractor (ALR) mode seat belts. If the seat belt becomes wrapped around a child’s neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt can not be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.

Children need adults to help protect them. They need to be properly restrained.

In addition to the general information in this manual, child safety information is available from many other sources, including doctors, teachers, government traffic safety offices, and community organizations. Every child is different, so be sure to learn the best way to transport your child.

There are three basic types of child restraint systems:

. Rear-facing child restraint . Forward-facing child restraint . Booster seat

The proper restraint depends on the child’s size. Generally, infants up to about 1 year and less than 20 lbs (9 kg) should be placed in rear-facing child restraints. Forward-facing child restraints are available for children who outgrow rear-facing child restraints and are at least 1 year old. Booster seats are used to help position a vehicle lap/shoulder belt on a child who can no longer use a forward-facing child restraint.

Infants and children need special protection. The vehicle’s seat belts may not fit them properly. The shoulder belt may come too close to the face or neck. The lap belt may not fit over their small hip bones. In an accident, an improperly fitting seat belt could cause serious or fatal injury. Always use appropriate child restraints.

All U.S. states and Canadian provinces or territories require the use of approved child restraints for infants and small

1-22 Safety — Seats, seat belts and supplemental restraint system

WARNING

children. See “Child restraints” (P.1-24). A child restraint may be secured in the

vehicle by using either the LATCH (Lower Anchors and Tethers for CHildren) system or with the vehicle seat belt. See “Child restraints” (P.1-24) for more information.

INFINITI recommends that all pre-teens and children be restrained in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat.

This is especially important because your vehicle has a supplemental restraint system (Air bag system) for the front passenger. See “Supplemental restraint system” (P.1-42).

INFANTS

Infants up to at least 1 year old should be placed in a rear-facing child restraint. INFINITI recommends that infants be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manufacturer’s instructions for installation and use.

GUID-81981691-E72A-4BD1-8C1F-5BB0437EDCA7

SMALL CHILDREN

GUID-4B9EA2FD-B4B7-4495-B26D-F98DBFB5E95B

Children that are over 1 year old and weigh at least 20 lbs (9 kg) should remain in a rear-facing child restraint as long as possible up to the height or weight limit of the child restraint. Children who outgrow the height or weight limit of the rear-facing child restraint and are at least 1 year old should be secured in a forward-facing child restraint with a harness. Refer to the manufacturer’s instructions for minimum and maximum weight and height recommendations. INFINITI recommends that small children be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manufacturer’s instructions for installation and use.

LARGER CHILDREN

GUID-68A06744-D08D-4184-A663-B44714919409

Children should remain in a forward-facing child restraint with a harness until they reach the maximum height or weight limit allowed by the child restraint manufacturer.

Once a child outgrows the height or weight limit of the harness-equipped forward-

facing child restraint, INFINITI recommends that the child be placed in a commercially available booster seat to obtain proper seat belt fit. For a seat belt to fit properly, the booster seat should raise the child so that the shoulder belt is properly positioned across the chest and the top, middle portion of the shoulder. The shoulder belt should not cross the neck or face and should not fall off the shoulder. The lap belt should lie snugly across the lower hips or upper thighs, not the abdomen. A booster seat can only be used in seating positions that have a three-point type seat belt. The booster seat should fit the vehicle seat and have a label certifying that it complies with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. Once the child has grown so the shoulder belt is no longer on or near the face and neck and the lap belt can be positioned properly across the lower hips or upper thighs use the seat belt without the booster seat.

WARNING

Never let a child stand or kneel on any seat and do not allow a child in the cargo area.

The child could be seriously injured or killed in a sudden stop or collision.

Safety — Seats, seat belts and supplemental restraint system 1-23

CHILD RESTRAINTS

GUID-6F253891-941F-476D-B2AD-069FE8CA4BEE

PRECAUTIONS ON CHILD RESTRAINTS

. Failure to follow the warnings and

instructions for proper use and installation of child restraints could result in serious injury or death of a child or other passengers in a sudden stop or collision:

—

The child restraint must be used and

SSS0099

SSS0100

installed properly. Always follow all of the child restraint manufacturer’s instructions for installation and use.

—

Infants and children should never be held on anyone’s lap. Even the strongest adult cannot resist the forces of a collision.

—

Do not put a seat belt around both a child and another passenger.

—

INFINITI recommends that all child restraints be installed in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat. If you must install a forward-facing child restraint in the front seat, see “For-

1-24 Safety — Seats, seat belts and supplemental restraint system

GUID-5FE7E7BB-A112-4287-8A75-C4B83BB8D21F

WARNING

ward-facing child restraint installation using the seat belts” (P.1-34).

—

Even with the INFINITI Advanced Air Bag System, never install a rearfacing child restraint in the front seat. An inflating air bag could seriously injure or kill a child. A rear-facing child restraint must only be used in the rear seat.

—

Be sure to purchase a child restraint that will fit the child and vehicle. Some child restraints may not fit properly in your vehicle.

—

Child restraint anchor points are designed to withstand loads from child restraints that are properly fitted.

—

Never use the anchor points for adult seat belts or harnesses.

—

A child restraint with a top tether strap should not be used in the front passenger seat.

—

Keep seatbacks as upright as possible after fitting the child restraint.

—

Infants and children should always be placed in an appropriate child restraint while in the vehicle.

. When the child restraint is not in use,

keep it secured with the LATCH system or a seat belt. In a sudden stop or collision, loose objects can injure occupants or damage the vehicle.

CAUTION

A child restraint in a closed vehicle can become very hot. Check the seating surface and buckles before placing a child in the child restraint.

This vehicle is equipped with a universal child restraint anchor system, referred to as the LATCH (Lower Anchors and Tethers for CHildren) system. Some child restraints include rigid or webbing-mounted attachments that can be connected to these anchors.

For details, see “Lower Anchors and Tethers for CHildren System (LATCH)” (P.1-

26). If you do not have a LATCH compatible

child restraint, the vehicle seat belts can be used.

Several manufacturers offer child restraints

for infants and small children of various sizes. When selecting any child restraint, keep the following points in mind:

. Choose only a restraint with a label

certifying that it complies with Federal

Motor Vehicle Safety Standard 213 or

Canadian Motor Vehicle Safety Stan-

dard 213. . Check the child restraint in your vehicle

to be sure it is compatible with the

vehicle’s seat and seat belt system. . If the child restraint is compatible with

your vehicle, place your child in the

child restraint and check the various

adjustments to be sure the child

restraint is compatible with your child.

Choose a child restraint that is de-

signed for your child’s height and

weight. Always follow all recommended

procedures.

All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated. Canadian law requires the top tether strap on forward-facing child restraints be secured to the designated anchor point on the vehicle.

SSS0710

LATCH label location (Sedan)

SSS0370B

LATCH label location (Coupe)

Safety — Seats, seat belts and supplemental restraint system 1-25

Lower Anchors and Tethers for CHildren System (LATCH)

Your vehicle is equipped with special anchor points that are used with the LATCH (Lower Anchors and Tethers for CHildren) system compatible child restraints. This system may also be referred to as the ISOFIX or ISOFIX compatible system. With this system, you do not have to use a vehicle seat belt to secure the child restraint.

LATCH lower anchor

GUID-FC181028-F551-4DEE-8F16-CBB822A9F046

GUID-67723C5A-DDB4-4E15-AF32-78083E9EADCF

WARNING

Failure to follow the warnings and instructions for proper use and installation of child restraints could result in serious injury or death of a child or other passengers in a sudden stop or collision:

. Attach LATCH system compatible child

restraints only at the locations shown in the illustration.

. Do not secure a child restraint in the

center rear seating position using the LATCH lower anchors. The child restraint will not be secured properly.

. Inspect the lower anchors by inserting

your fingers into the lower anchor area. Feel to make sure there are no obstructions over the anchors such as seat belt webbing or seat cushion material. The child restraint will not be secured properly if the lower anchors are obstructed.

SSS0637

LATCH lower anchor location (Sedan)

SSS0670

LATCH lower anchor location (Coupe)

1-26 Safety — Seats, seat belts and supplemental restraint system

LATCH lower anchor location

GUID-3814C20E-41C4-468E-AB79-A54C7114E200

The LATCH lower anchors are located at the rear of the seat cushion near the seatback. A label is attached to the seatback to help you locate the LATCH anchors.

SSS0643

LATCH webbing-mounted attachment

SSS0644

LATCH rigid attachment

Safety — Seats, seat belts and supplemental restraint system 1-27

Installing child restraint LATCH lower anchor attachments

LATCH compatible child restraints include two rigid or webbing-mounted attachments that can be connected to two anchors located at certain seating positions in your vehicle. With this system, you do not have to use a vehicle seat belt to secure the child restraint. Check your child restraint for a label stating that it is compatible with LATCH. This information may also be in the instructions provided by the child restraint manufacturer.

When installing a child restraint, carefully read and follow the instructions in this manual and those supplied with the child restraint.

GUID-0C6C8E08-7827-422F-BD89-9B23664ED66D

Top tether anchor point locations

Anchor points are located on the rear parcel shelf.

The child restraint top tether strap must be used when installing the child restraint with the LATCH lower anchor attachments or seat belts. See “Installing top tether strap” (P.1-38).

If you have any questions when installing a top tether strap child restraint on the rear seat, consult an INFINITI retailer for

SSS0791

Sedan

details.

REAR-FACING CHILD RESTRAINT INSTALLATION USING LATCH

Refer to all Warnings and Cautions in the “Child safety” and “Child restraints” sections before installing a child restraint.

Follow these steps to install a rear-facing child restraint using the LATCH system:

1. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

SSS0790

Coupe

1-28 Safety — Seats, seat belts and supplemental restraint system

GUID-6D1BD512-34DB-4B67-9E38-84EBAD1B71D0

GUID-B9CDBDD5-4045-4520-BBEA-6887640CAF59

SSS0648

Rear-facing web-mounted — step 2

2. Secure the child restraint anchor attachments to the LATCH lower anchors. Check to make sure the LATCH attachment is properly attached to the lower anchors.

SSS0649

Rear-facing rigid-mounted — step 2

SSS0639

Rear-facing — step 3

3. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your hand to compress the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.

Safety — Seats, seat belts and supplemental restraint system 1-29

SSS0650

Rear-facing — step 4

4. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attachment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attachment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint or try installing by using the vehicle seat belt (if

applicable). Not all child restraints fit in all types of vehicles.

5. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 4.

SSS0100

REAR-FACING CHILD RESTRAINT INSTALLATION USING THE SEAT BELTS

GUID-68D5DDB8-3F24-4C65-922C-6DD7B90A7477

WARNING

The three-point seat belt with Automatic Locking Retractor (ALR) must be used when installing a child restraint. Failure to use the ALR mode will result in the child restraint not being properly secured. The restraint could tip over or be loose and cause injury to a child in a sudden stop or collision. Also, it can change the operation of the front passenger air bag. See “Front passenger air

bag and status light” (P.1-50).

1-30 Safety — Seats, seat belts and supplemental restraint system

SSS0100

Rear-facing — step 1

Refer to all Warnings and Cautions in the “Child safety” (P.1-22) and “Child restraints” (P.1-24) before installing a child restraint.

Follow these steps to install a rear-facing child restraint using the vehicle seat belts in the rear seats:

1. Child restraints for infants must be

used in the rear-facing direction and therefore must not be used in the front seat. Position the child restraint on the

seat. Always follow the restraint manufacturer’s instructions.

SSS0654

Rear-facing — step 2

2. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the latch engage. Be sure to follow the child restraint manufacturer’s instructions for belt routing.

Safety — Seats, seat belts and supplemental restraint system 1-31

SSS0655

Rear-facing — step 3

3. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the Automatic Locking Retractor (ALR) mode (child restraint mode). It reverts to the Emergency Locking Retractor (ELR) mode when the seat belt is fully retracted.

SSS0656

4. Allow the seat belt to retract. Pull up on

Rear-facing — step 4

the shoulder belt to remove any slack in the belt.

5. Remove any additional slack from the

Rear-facing — step 5

seat belt; press downward and rearward firmly in the center of the child restraint to compress the vehicle seat cushion and seatback while pulling up on the seat belt.

1-32 Safety — Seats, seat belts and supplemental restraint system

SSS0657

SSS0658

Rear-facing — step 6

6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

7. Check to make sure that the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 1 through 6.

After the child restraint is removed and the seat belt fully retracted, the ALR mode (child restraint mode) is canceled.

FORWARD-FACING CHILD RESTRAINT INSTALLATION USING LATCH

Refer to all Warnings and Cautions in the “Child safety” and “Child restraints” sections before installing a child restraint.

Follow these steps to install a forwardfacing child restraint using the LATCH system:

1. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

GUID-C7CEB4CB-D6DD-4996-BA6E-023C4B2CA773

SSS0645

Forward-facing web-mounted — step 2

2. Secure the child restraint anchor attachments to the LATCH lower anchors. Check to make sure the LATCH attachment is properly attached to the lower anchors.

If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point. See “Installing top tether strap” (P.1-38). Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.

SSS0646

Forward-facing rigid-mounted — step 3

3. The back of the child restraint should be secured against the vehicle seatback.

If the seating position does not have an adjustable head restraint and it is interfering with the proper child restraint fit, tr y another seating position or a different child restraint.

Safety — Seats, seat belts and supplemental restraint system 1-33

SSS0647

Forward-facing — step 4

4. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your knee to compress the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.

5. Tighten the tether strap according to the manufacturer’s instructions to remove any slack.

SSS0638

Forward-facing — step 6

6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attachment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attachment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

7. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 1 through 6.

FORWARD-FACING CHILD RESTRAINT INSTALLATION USING THE SEAT BELTS

GUID-B0438CCC-C788-4E94-8FA4-DB4F26EE0A33

WARNING

1-34 Safety — Seats, seat belts and supplemental restraint system

SSS0640

Forward-facing (front passenger seat) —

step 1

Refer to all Warnings and Cautions in the “Child safety” and “Child restraints” sections before installing a child restraint.

Follow these steps to install a forwardfacing child restraint using the vehicle seat belt in the rear seats or in the front passenger seat:

1. If you must install a child restraint in

the front seat, it should be placed in a forward-facing direction only. Move the seat to the rearmost position. Child restraints for infants must be used in the rear-facing direction and, therefore, must not be used in the front seat.

2. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

The back of the child restraint should be secured against the vehicle seatback.

If necessary, adjust or remove the head restraint to obtain the correct child restraint fit. If the head restraint is removed, store it in a secure place. Be

sure to reinstall the head restraint when the child restraint is removed.

See “Head restraints (front seats)” (P.1-

9) for head restraint adjustment, removal and installation information.

If the seating position does not have an adjustable head restraint and it is interfering with the proper child restraint fit, tr y another seating position or a different child restraint.

Safety — Seats, seat belts and supplemental restraint system 1-35

SSS0360B

Forward-facing — step 3

3. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the latch engage. Be sure to follow the child restraint manufacturer’s instructions for belt routing.

If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point (rear seat installation only). See “Installing top tether strap” (P.1-38). Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.

SSS0651

4. Pull the shoulder belt until the belt is

Forward-facing — step 4

fully extended. At this time, the seat belt retractor is in the Automatic Lock-

5. Allow the seat belt to retract. Pull up on

Forward-facing — step 5

the shoulder belt to remove any slack

in the belt. ing Retractor (ALR) mode (child restraint mode). It reverts to Emergency Locking Retractor (ELR) mode when the seat belt is fully retracted.

1-36 Safety — Seats, seat belts and supplemental restraint system

SSS0652

SSS0653

Forward-facing — step 6

6. Remove any additional slack from the seat belt; press downward and rearward firmly in the center of the child restraint with your knee to compress the vehicle seat cushion and seatback while pulling up on the seat belt.

7. Tighten the tether strap according to the manufacturer’s instructions to remove any slack.

9. Check to make sure the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 2 through 8.

SSS0641

Forward-facing — step 8

8. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

SSS0676

Forward-facing — step 10

10.If the child restraint is installed in the front passenger seat, place the ignition switch in the ON position. The front passenger air bag status light should illuminate. If this light is not illuminated, see “Front passenger air bag and status light” (P.1-50). Move

the child restraint to another seating position. Have the system checked by

an INFINITI retailer.

After the child restraint is removed and the seat belt is fully retracted, the ALR mode (child restraint mode) is canceled.

Safety — Seats, seat belts and supplemental restraint system 1-37

INSTALLING TOP TETHER STRAP

First, secure the child restraint with the LATCH lower anchors (rear outboard seat positions only) or the seat belt, as applicable.

1. Flip up the anchor cover from the anchor point which is located directly behind the child seat.

2. Position the top tether strap over the top of the seatback.

3. Secure the tether strap to the tether

SSS0791

Sedan

anchor point on the rear parcel shelf.

4. Refer to the appropriate child restraint installation procedure steps in this section before tightening the tether strap.

If you have any questions when installing a top tether strap, consult your INFINITI retailer for details.

SSS0790

Coupe

1-38 Safety — Seats, seat belts and supplemental restraint system

GUID-C9A5E577-AFA4-46B6-97E2-D077C8A3DBAB

BOOSTER SEATS

Precautions on booster seats

GUID-F369878B-DD25-483E-8198-275B4D15BF3F

GUID-25C42A16-09BB-45D5-A28E-6C3CA2A753FF

WARNING

If a booster seat and seat belt are not used properly, the risk of a child being injured in a sudden stop or collision greatly increases:

. Make sure the shoulder portion of the

belt is away from the child’s face and neck and the lap portion of the belt does not cross the stomach.

. Make sure the shoulder belt is not

behind the child or under the child’s arm.

. A booster seat must only be installed in

a seating position that has a lap/ shoulder belt.

seat is compatible with your child. Always follow all recommended procedures.

LRS0455

Booster seats of various sizes are offered by several manufacturers. When selecting any booster seat, keep the following points in mind:

. Choose only a booster seat with a label

certifying that it complies with Federal Motor Vehicle Safety Standard 213 or Canadian Motor Vehicle Safety Standard 213.

. Check the booster seat in your vehicle

to be sure it is compatible with the vehicle’s seat and seat belt system.

LRS0453

. Make sure the child’s head will be

properly supported by the booster seat or vehicle seat. The seatback must be at or above the center of the child’s ears. For example, if a low back booster seat

is chosen, the vehicle seatback

must be at or above the center of the child’s ears. If the seatback is lower than the center of the child’s ears, a high back booster seat

should be

used.

. If the booster seat is compatible with

your vehicle, place your child in the booster seat and check the various adjustments to be sure the booster

Safety — Seats, seat belts and supplemental restraint system 1-39

LRS0464

All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated.

The instructions in this section apply to booster seat installation in the rear seats or the front passenger seat.

Booster seat installation

GUID-F402278F-CB4D-47C2-8CA5-E6E93C16F092

CAUTION

Do not use the lap/shoulder belt Automatic Locking Retractor (ALR) mode when using a booster seat with the seat belts.

Refer to all Warnings and Cautions in the

“Child safety”, “Child restraints” and “Booster seats” sections earlier in this

section before installing a child restraint. Follow these steps to install a booster seat

in the rear seat or in the front passenger seat:

SSS0640

1. If you must install a booster seat in the

front seat, move the seat to the rearmost position.

2. Position the booster seat on the seat. Only place it in a forward-facing direction. Always follow the booster seat manufacturer’s instructions.

1-40 Safety — Seats, seat belts and supplemental restraint system

LRS0454

Front passenger position

3. The booster seat should be positioned on the vehicle seat so that it is stable.

If necessary, adjust or remove the head restraint to obtain the correct booster seat fit. If the head restraint is removed, store it in a secure place. Be

sure to reinstall the head restraint when the booster seat is removed.

See “Head restraints (front seats)” (P.1-

9) for head restraint, removal and installation information.

If the seating position does not have an adjustable head restraint and it is interfering with the proper booster seat

fit, try another seating position or a different booster seat.

4. Position the lap portion of the seat belt low and snug on the child’s hips. Be sure to follow the booster seat manufacturer’s instructions for adjusting the seat belt routing.

5. Pull the shoulder belt portion of the seat belt toward the retractor to take up extra slack. Be sure the shoulder belt is positioned across the top, middle portion of the child’s shoulder. Be sure to follow the booster seat manufacturer’s instructions for adjusting the seat belt routing.

6. Follow the warnings, cautions and instructions for properly fastening a seat belt shown in “Seat belts” (P.1-

14).

SSS0676

7. If the booster seat is installed in the front passenger seat, push the ignition switch to the ON position. The front passenger air bag status light

may or may not illuminate depending on the size of the child and the type of booster seat used. See “Front passenger air bag and status light” (P.1-50).

Safety — Seats, seat belts and supplemental restraint system 1-41

SUPPLEMENTAL RESTRAINT SYSTEM

GUID-EE61FDD4-27FE-47E6-AA0F-DDD90D621C3B

PRECAUTIONS ON SUPPLEMENTAL RESTRAINT SYSTEM

This Supplemental Restraint System (SRS) section contains important information concerning the driver and passenger front impact supplemental air bags (INFINITI Advanced Air Bag System), front seatmounted side-impact supplemental air bag system, roof-mounted curtain sideimpact supplemental air bag and seat belt with pretensioners.

Supplemental front-impact air bag system:

The INFINITI Advanced Air Bag System can help cushion the impact force to the head and chest of the driver and front passenger in certain frontal collisions.

Front seat-mounted side-impact supplemental air bag system: This system can

help cushion the impact force to the chest and pelvis area of the driver and front passenger in certain side impact collisions. The side air bag is designed to inflate on the side where the vehicle is impacted.

Roof-mounted curtain side-impact supplemental air bag system: This system can

help cushion the impact force to the head of occupants in front and rear outboard seating positions in certain side impact

GUID-95EB1259-7EC1-45A1-A102-14E1973C8879

collisions. The curtain air bags are designed to inflate on the side where the vehicle is impacted.

These supplemental restraint systems are designed to supplement the crash protection provided by the driver and passenger seat belts and are not a substitute for them. Seat belts should always be correctly worn and the occupant seated a suitable distance away from the steering wheel, instrument panel and door finishers. (See “Seat belts” (P.1-14) for instructions and precautions on seat belt usage.)

The supplemental air bags operate only when the ignition switch is in the ON position.

After pushing the ignition switch to the ON position, the supplemental air bag warning light illuminates. The supplemental air bag warning light will turn off after about 7 seconds if the systems are operational.

1-42 Safety — Seats, seat belts and supplemental restraint system

WARNING

. The supplemental front air bags ordina-

rily will not inflate in the event of a side impact, rear impact, rollover, or lower severity frontal collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents.

. The front passenger air bag will not

inflate if the passenger air bag status

SSS0131B

SSS0132B

Safety — Seats, seat belts and supplemental restraint system 1-43

light is lit or if the front passenger seat is unoccupied. See “Front passenger air bag and status light” (P.1-50).

. The seat belts and the supplemental

front air bags are most effective when you are sitting well back and upright in the seat with both feet on the floor. The front air bags inflate with great force. Even with the INFINITI advanced air bag system, if you are unrestrained, leaning forward, sitting sideways or out of position in any way, you are at greater risk of injury or death in a crash. You may also receive serious or fatal injuries from the supplemental front air bag if you are up against it when it inflates. Always sit back against the seatback

and as far-away as practical from the steering wheel or instrument panel. Always use the seat belts.

. The driver and front passenger seat belt

buckles are equipped with sensors that detect if the seat belts are fastened. The Advanced Air Bag System monitors the severity of a collision and seat belt usage then inflates the air bags as needed. Failure to properly wear seat belts can increase the risk or severity of injury in an accident.

. The front passenger seat is equipped

with an occupant classification sensor (pattern sensor) that turns the front passenger air bag OFF under some conditions. This sensor is only used in this seat. Failure to be properly seated and wearing the seat belt can increase the risk or severity of injury in an accident. See “Front passenger air bag and status light” (P.1-50).

. Keep hands on the outside of the

steering wheel. Placing them inside the steering wheel rim could increase the risk of injury if the front air bag inflates.

SSS0007

SSS0006

SSS0008

SSS0009

1-44 Safety — Seats, seat belts and supplemental restraint system

SSS0099

WARNING

. Never let children ride unrestrained or

extend their hands or face out of the window. Do not attempt to hold them in your lap or arms. Some examples of dangerous riding positions are shown in the illustrations.

. Children may be severely injured or

killed when the front air bags, side air bags or curtain air bags inflate if they are not properly restrained. Pre-teens and children should be properly restrained in the rear seat, if possible.

. Even with the INFINITI Advanced Air Bag

System, never install a rear-facing child restraint in the front seat. An inflating front air bag could seriously injure or kill your child. See “Child restraints” (P.1-

24) for details.

SSS0059A

SSS0100

SSS0188A

Safety — Seats, seat belts and supplemental restraint system 1-45

SSS0140

SSS0162

SSS0159

WARNING

Front seat-mounted side-impact supplemental air bags and roof-mounted curtain sideimpact supplemental air bags:

. The front seat-mounted side-impact air

bags and roof-mounted curtain air bags ordinarily will not inflate in the event of a frontal impact, rear impact, rollover or lower severity side collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents.

. The seat belts, side air bags and curtain

air bags are most effective when you are sitting well back and upright in the seat. The side air bag and curtain air bag inflate with great force. Do not allow anyone to place their hand, leg or face near the side air bag on the side of the seatback of the front seat or near the side roof rails. Do not allow anyone sitting in the front seats or rear outboard seats to extend their hand out of the window or lean against the door. Some examples of dangerous riding positions are shown in the previous illustrations.

. When sitting in the rear seat, do not

hold onto the seatback of the front seat. If the supplemental side air bag inflates, you may be seriously injured. Be especially careful with children, who should always be properly restrained. Some examples of dangerous riding positions are shown in the illustrations.

. Do not use seat covers on the front

seatbacks. They may interfere with supplemental side air bag inflation.

1-46 Safety — Seats, seat belts and supplemental restraint system

Sedan

INFINITI ADVANCED AIR BAG SYSTEM (front seats)

1. Crash zone sensor

2. Supplemental front air bag modules (INFINITI Advanced Air Bags)

3. Front seat-mounted side-impact supplemental air bags

GUID-3B909583-1587-4572-B507-DCE34104B7E8

4. Occupant classification sensor (pattern sensor)

5. Occupant classification system control unit

6. Roof-mounted curtain side-impact

supplemental air bags

7. Roof-mounted curtain side-impact supplemental air bag inflators

8. Air bag Control Unit (ACU)

9. Satellite sensors

10. Seat belts with pretensioners

SSS0683

Safety — Seats, seat belts and supplemental restraint system 1-47

1. Crash zone sensor

2. Supplemental front air bag modules (INFINITI Advanced Air Bags)

3. Front seat-mounted side-impact supplemental air bags

4. Occupant classification sensor (pat-

tern sensor)

5. Occupant classification system control unit

6. Roof-mounted curtain side-impact supplemental air bags

7. Roof-mounted curtain side-impact

1-48 Safety — Seats, seat belts and supplemental restraint system

Coupe

SSS0807

supplemental air bag inflators

8. Air bag Control Unit (ACU)

9. Satellite sensors

10. Seat belts with pretensioners

This vehicle is equipped with the INFINITI Advanced Air Bag System for the driver and front passenger seats. This system is designed to meet certification requirements under U.S. regulations. It is also permitted in Canada. However, all of the

information, cautions and warnings in this manual still apply and must be followed.

The driver supplemental front-impact air bag is located in the center of the steering wheel. The front passenger supplemental front-impact air bag is mounted in the instrument panel above the glove box. The front air bags are designed to inflate in higher severity frontal collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity frontal impact. They may not inflate in certain frontal collisions. Vehicle damage (or lack of it) is not always an indication of proper front air bag operation.

The INFINITI Advanced Air Bag System has dual stage air bag inflators. The system monitors information from the crash zone

sensor, the Air bag Control Unit (ACU), seat belt buckle switches and the occupant classification sensor (pattern sensor). Inflator operation is based on the severity of a collision and seat belt usage for the driver. For the front passenger, the occupant classification sensor is also monitored. Based on information from the sensors, only one front air bag may inflate in a crash, depending on the crash severity and whether the front occupants are belted or unbelted. Additionally, the front passenger air bag may be automatically turned OFF under some conditions, depending on the information provided by the occupant classification sensor. If the front passenger air bag is OFF, the passenger air bag status light will be illuminated (if the seat is unoccupied, the light will not be illuminated, but the air bag will be off). (See “Front passenger air bag and status light” (P.1-50) for further details.) One front air bag inflating does not indicate improper performance of the system.

If you have any questions about your air bag system, contact an INFINITI retailer. If you are considering modification of your vehicle due to a disability, you may also contact an INFINITI retailer. Contact infor-

mation is contained in the front of this Owner’s Manual.

When a front air bag inflates, a fairly loud noise may be heard, followed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.

Front air bags, along with the use of seat belts, help to cushion the impact force on the head and chest of the front occupants. They can help save lives and reduce serious injuries. However, an inflating front air bag may cause facial abrasions or other injuries. Front air bags do not provide restraint to the lower body.

Even with INFINITI advanced air bags, seat belts should be correctly worn and the driver and passenger seated upright as far as practical away from the steering wheel or instrument panel. The front air bags inflate quickly in order to help protect the front occupants. Because of this, the force of the front air bag inflating can increase the risk of injury if the occupant is too close to, or is against, the air bag module during inflation.

The front air bags deflate quickly after a collision.

The supplemental front air bags operate only when the ignition switch is in the ON position.

Safety — Seats, seat belts and supplemental restraint system 1-49

of injury in an accident.

Status light:

The front passenger air bag status light

is located on the instrument panel.

After the ignition switch is placed in the "ON" position, the front passenger air bag status light on the instrument panel illuminates for about 7 seconds and then turns off or operates depending on the front passenger seat occupied status. The

SSS0676

Front passenger air bag status light

Front passenger air bag and status light

GUID-F1871FA8-412D-4C8E-B4FC-BB57C13B976F

WARNING

The front passenger air bag is designed to automatically turn OFF under some conditions. Read this section carefully to learn how it operates. Proper use of the seat, seat belt and child restraints is necessary for most effective protection. Failure to follow all instructions in this manual concerning

light operates as follows: . Unoccupied passenger seat: The

OFF and the front passenger air bag is OFF and will not inflate in a crash.

. Passenger seat occupied by a small

adult, child or child restraint as outlined in this section: The nates to indicate that the front passenger air bag is OFF and will not inflate in a crash.

. Occupied passenger seat and the pas-

senger meets the conditions outlined in this section: The light indicate that the front passenger air bag is operational.

the use of seats, seat belts and child restraints can increase the risk or severity

1-50 Safety — Seats, seat belts and supplemental restraint system

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

illumi-

is OFF to

Front passenger air bag:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

The front passenger air bag is designed to automatically turn OFF when the vehicle is operated under some conditions as described below as permitted by U.S. regulations. If the front passenger air bag is OFF, it will not inflate in a crash. The driver air bag and other air bags in your vehicle are not part of this system.

The purpose of the regulation is to help reduce the risk of injury or death from an inflating air bag to certain front passenger seat occupants, such as children, by

requiring the air bag to be automatically turned OFF.

The occupant classification sensor (pattern sensor) is in the front passenger seat cushion and is designed to detect an occupant and objects on the seat. For example, if a child is in the front passenger seat, the Advanced Air Bag System is designed to turn the passenger air bag OFF in accordance with the regulations. Also, if a child restraint of the type specified in the regulations is on the seat, the occupant classification sensor can detect it and cause the air bag to turn OFF.

Front passenger seat adult occupants who are properly seated and using the seat belt

as outlined in this manual should not cause the passenger air bag to be automatically turned OFF. For small adults it may be turned OFF, however, if the occupant does not sit in the seat properly (for example, by not sitting upright, by sitting on an edge of the seat, or by otherwise being out of position), this could cause the sensor to turn the air bag OFF. Always be sure to be seated and wearing the seat belt properly for the most effective protection by the seat belt and supplemental air bag.

INFINITI recommends that pre-teens and children be properly restrained in a rear seat. INFINITI also recommends that appropriate child restraints and booster seats be properly installed in a rear seat. If this is not possible, the occupant classification sensor is designed to operate as described above to turn the front passenger air bag OFF for specified child restraints. Failing to properly secure child restraints and to use the ALR mode (child restraint mode) may allow the restraint to tip or move in an accident or sudden stop. This can also result in the passenger air bag inflating in a crash instead of being OFF. (See “Child restraints” (P.1-24) for proper use and

installation.) If the front passenger seat is not occupied,

the passenger air bag is designed not to inflate in a crash. However, heavy objects placed on the seat could result in air bag inflation, because of the object being detected by the occupant classification sensor. Other conditions could also result in air bag inflation, such as if a child is standing on the seat, or if two children are on the seat, contrary to the instructions in this manual. Always be sure that you and all vehicle occupants are seated and restrained properly.

Using the passenger air bag status light, you can monitor when the front passenger air bag is automatically turned OFF with the seat occupied. The light will not illuminate when the front passenger seat is unoccupied.

If an adult occupant is in the seat but the passenger air bag status light is illuminated (indicating that the air bag is OFF), it could be that the person is a small adult, or is not sitting on the seat properly.

If a child restraint must be used in the front seat, the passenger air bag status light may or may not be illuminated, depending on the size of the child and the type of

Safety — Seats, seat belts and supplemental restraint system 1-51

child restraint being used. If the passenger air bag status light is not illuminated (indicating that the air bag might inflate in a crash), it could be that the child restraint or seat belt is not being used properly. Make sure that the child restraint is installed properly, the seat belt is used properly and the occupant is positioned properly. If the passenger air bag status light is still not illuminated, reposition the occupant or child restraint in a rear seat.

If the passenger air bag status light will not illuminate even though you believe that the child restraint, the seat belts and the occupant are properly positioned, the system may be sensing an unoccupied seat (in which case the air bag is OFF). Your INFINITI retailer can check that the system is OFF by using a special tool. However, until you have confirmed with your retailer that your air bag is working properly, reposition the occupant or child restraint in a rear seat.

The INFINITI advanced air bag system and passenger air bag status light will take a few seconds to register a change in the passenger seat status. However, if the seat becomes unoccupied, the air bag status light will remain off.

If a malfunction occurs in the front passenger air bag system, the supplemental air bag warning light meter and gauges area will blink. Have the system checked by an INFINITI retailer.

, located in the

Other supplemental front-impact air bag precautions

GUID-E1ADE331-8B4D-4EE9-AFF2-60CD469A1D21

WARNING

. Do not place any objects on the steering

wheel pad or on the instrument panel. Also, do not place any objects between any occupant and the steering wheel or instrument panel. Such objects may become dangerous projectiles and cause injury if the front air bags inflate.

. Do not place objects with sharp edges

on the seat. Also, do not place heavy objects on the seat that will leave permanent impressions in the seat. Such objects can damage the seat or occupant classification sensor (pattern sensor). This can affect the operation of the air bag system and result in serious personal injury.

. Do not use water or acidic cleaners (hot

steam cleaners) on the seat. This can

damage the seat or occupant classification sensor. This can also affect the operation of the air bag system and result in serious personal injury.

. Immediately after inflation, several front

air bag system components will be hot. Do not touch them; you may severely burn yourself.

. No unauthorized changes should be

made to any components or wiring of the air bag system. This is to prevent accidental inflation of the supplemental air bag or damage to the supplemental air bag system.

. Do not make unauthorized changes to

your vehicle’s electrical system, suspension system or front end structure. This could affect proper operation of the front air bag system.

. Tampering with the air bag system may

result in serious personal injury. Tampering includes changes to the steering wheel and the instrument panel assembly by placing material over the steering wheel pad and above the instrument panel or by installing additional trim material around the air bag system.

1-52 Safety — Seats, seat belts and supplemental restraint system

. Modifying or tampering with the front

passenger seat may result in serious personal injury. For example, do not change the front seats by placing material on the seat cushion or by installing additional trim material, such as seat covers, on the seat that is not specifically designed to assure proper air bag operation. Additionally, do not stow any objects under the front passenger seat or the seat cushion and seatback. Such objects may interfere with the proper operation of the occupant classification sensor.

. No unauthorized changes should be

made to any components or wiring of the seat belt system. This may affect the front air bag system. Tampering with the seat belt system may result in serious personal injury.

. Work on and around the front air bag

system should be done by an INFINITI retailer. Installation of electrical equipment should also be done by an INFINITI retailer. The Supplemental Restraint System (SRS) wiring harnesses* should not be modified or disconnected. Unauthorized electrical test equipment and probing devices should not be used on

the air bag system.

. A cracked windshield should be replaced

immediately by a qualified repair facility. A cracked windshield could affect the function of the supplemental air bag system.

* The SRS wiring harness connectors

are yellow and orange for easy identification.

When selling your vehicle, we request that you inform the buyer about the front air bag system and guide the buyer to the appropriate sections in this Owner’s Manual.

SSS0521

FRONT SEAT-MOUNTED SIDE-IMPACT SUPPLEMENTAL AIR BAG AND ROOF-MOUNTED CURTAIN SIDE-IMPACT SUPPLEMENTAL AIR BAG SYSTEMS

The side air bags are located in the outside of the seatback of the front seats. The curtain air bags are located in the side roof rails. These systems are designed to meet voluntary guidelines to help reduce the risk of injury to out-of-position occupants.

However, all of the information, cautions and warnings in this manual still apply and must be followed. The side air bags

GUID-5F61E6E2-F68B-4488-A88B-BF098637A002

and curtain air bags are designed to inflate in higher severity side collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity side impact. They are designed to inflate on the side where the vehicle is impacted. They may not inflate in certain side collisions on the side where the vehicle is impacted.

Vehicle damage (or lack of it) is not always an indication of proper supplemental side air bag and curtain side-impact air bag operation.

When side air bags and curtain air bags inflate, a fairly loud noise may be heard, followed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.

Side air bags, along with the use of seat belts, help to cushion the impact force on the chest and pelvis of the front occupants. Curtain air bags help to cushion the impact force to the head of occupants in the front and rear outboard seating positions. They can help save lives and reduce serious injuries. However, an inflating side air bags

Safety — Seats, seat belts and supplemental restraint system 1-53

and curtain air bags may cause abrasions or other injuries. Side air bags and curtain air bags do not provide restraint to the lower body.

The seat belts should be correctly worn and the driver and passenger seated upright as far as practical away from the side air bag. Rear seat passengers should be seated as far away as practical from the door finishers and side roof rails. The side air bags and curtain air bags inflate quickly in order to help protect the occupants. Because of this, the force of the side air bags and curtain air bags inflating can increase the risk of injury if the occupant is too close to, or is against, these air bag modules during inflation. The side air bags and curtain air bags will deflate quickly after the collision is over.

The side air bags and curtain air bags operate only when the ignition switch is in the ON position.

After pushing the ignition switch to the ON position, the supplemental air bag warning light illuminates. The air bag warning light will turn off after about 7 seconds if the systems are operational.

. Do not place any objects near the

seatback of the front seats. Also, do not place any objects (an umbrella, bag, etc.) between the front door finisher and the front seat. Such objects may become dangerous projectiles and cause injury if side air bag inflates.

. Right after inflation, several side air

bags and curtain air bag system components will be hot. Do not touch them; you may severely burn yourself.

. No unauthorized changes should be

made to any components or wiring of side air bag and curtain air bags. This is to prevent damage to or accidental inflation of the side air bag and curtain air bag systems.

. Do not make unauthorized changes to

your vehicle’s electrical system, suspension system or side panel. This could affect proper operation of the side air bag and curtain air bag systems.

. Tampering with the air bag system may

result in serious personal injury. For example, do not change the front seats by placing material near the seatback or

1-54 Safety — Seats, seat belts and supplemental restraint system

WARNING

by installing additional trim material, such as seat covers, around the side air bags.

. Work around and on the side air bag and

curtain air bag systems should be done by an INFINITI retailer. Installation of electrical equipment should also be done by an INFINITI retailer. The Supplemental Restraint System (SRS) wiring harnesses* should not be modified or disconnected. Unauthorized electrical test equipment and probing devices should not be used on the side-impact air bag system.

* The SRS wiring harness connectors

are yellow and orange for easy identification.

When selling your vehicle, we request that you inform the buyer about the side air bag and curtain air bag systems and guide the buyer to the appropriate sections in this Owner’s Manual.

SEAT BELTS WITH PRETENSIONERS (front seats)

GUID-B4FD247A-D4FB-4B61-B23C-EE8ADACDF0A6

WARNING

. The pretensioners cannot be reused after

activation. They must be replaced together with the retractor and buckle as a unit.

. If the vehicle becomes involved in a

collision but a pretensioner is not activated, be sure to have the pretensioner system checked and, if necessary, replaced by an INFINITI retailer.

. No unauthorized changes should be

made to any components or wiring of the pretensioners. This is to prevent damage to or accidental activation of the pretensioner system. Tampering with the pretensioner system may result in serious personal injury.

. Work around and on the pretensioners

should be done by an INFINITI retailer. Installation of electrical equipment should also be done by an INFINITI retailer. Unauthorized electrical test equipment and probing devices should not be used on the pretensioner system.

. If you need to dispose of the preten-

sioner or scrap the vehicle, contact an INFINITI retailer. Correct pretensioner disposal procedures are set forth in the appropriate INFINITI Service Manual. Incorrect disposal procedures could cause personal injury.

The pretensioner system may activate with the supplemental air bag system in certain types of collisions. Working with the seat belt retractor, it helps tighten the seat belt when the vehicle becomes involved in certain types of collisions, helping to restrain front seat occupants.

The pretensioner is encased with the seat belt retractor. These seat belts are used the same way as conventional seat belts.

When a pretensioner seat belt activates, smoke is released and a loud noise may be heard. The smoke is not harmful, and it does not indicate a fire. Care should be taken not to inhale it as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.

After pretensioner activation, load limiters allow the seat belt to release webbing (if necessary) to reduce forces against the

Safety — Seats, seat belts and supplemental restraint system 1-55

chest. The supplemental air bag warning light

is used to indicate malfunctions in the pretensioner system. (See “Supplemental air bag warning light” (P.1-56) for more details.) If the supplemental air bag warning light indicates there is a malfunction, have the system checked by an INFINITI retailer.

When selling your vehicle, we request that you inform the buyer about the seat belt pretensioners and guide the buyer to the appropriate sections in this Owner’s Manual.

SSS1016

SUPPLEMENTAL AIR BAG WARNING LABELS

Warning labels about the supplemental front-impact air bag systems are placed in the vehicle as shown in the illustration.

SRS air bag

The warning labels surface of the sun visors.

GUID-0B65E0E3-218A-4A06-925F-DDB783835748

GUID-E4E32938-35BA-448F-83FA-D791212BFB56

are located on the

SUPPLEMENTAL AIR BAG WARNING LIGHT

The supplemental air bag warning light, displaying monitors the circuits of the supplemental front-impact air bag, front seat-mounted side-impact supplemental air bag, roofmounted curtain side-impact supplemental air bag, and seat belt pretensioner systems. The monitored circuits include the Air bag Control Unit (ACU), satellite sensors, crash zone sensor, occupant classification system, front air bag modules, side air bag modules, curtain air bag modules, pretensioner, front passenger air bag status light

1-56 Safety — Seats, seat belts and supplemental restraint system

SPA1097

GUID-FC2CCCAD-ABA5-4075-9F93-F2472626804E

in the instrument panel,

and all related wiring. When the ignition switch is in the ON

position, the supplemental air bag warning light illuminates for about 7 seconds and then turns off. This means the system is operational.

If any of the following conditions occur, the front air bag, side air bag, curtain air bag and pretensioner systems need servicing:

. The supplemental air bag warning light

remains on approximately 7 seconds after the ignition switch is pushed to the ON position.

. The supplemental air bag warning light

flashes intermittently.

. The supplemental air bag warning light

does not come on at all.

Under these conditions, the front air bag, side air bag, curtain air bag or pretensioner systems may not operate properly. They must be checked and repaired. Take your vehicle to the nearest INFINITI retailer.

WARNING

If the supplemental air bag warning light is on, it could mean that the front air bag, side air bag, curtain air bag and/or pretensioner

systems will not operate in an accident. To help avoid injury to yourself or others, have your vehicle checked by a retailer as soon as possible.

REPAIR AND REPLACEMENT PROCEDURE

The front air bags, side air bags, curtain air bags and pretensioners are designed to activate on a one-time-only basis. As a reminder, unless it is damaged, the supplemental air bag warning light will remain illuminated after inflation has occurred. Repair and replacement of these systems should be done only by an INFINITI retailer.

When maintenance work is required on the vehicle, the front air bags, side air bags, curtain air bags, pretensioners and related parts should be pointed out to the person conducting the maintenance. The ignition switch should always be in the LOCK position when working under the hood or inside the vehicle.

GUID-14E865CD-CF42-4FB6-85F1-2404D96FDE4E

WARNING

. Once a front air bag, side air bag, or

curtain air bag has inflated, the air bag

module will not function again and must be replaced. Additionally, the activated pretensioner must also be replaced. The air bag module and pretensioner should be replaced by an INFINITI retailer. The air bag module and pretensioner system cannot be repaired.

. The front air bag, side air bag, curtain air

bag and the pretensioner system should be inspected by an INFINITI retailer if there is any damage to the front end or side portion of the vehicle.

. If you need to dispose of the supple-

mental air bag or pretensioner or scrap the vehicle, contact an INFINITI retailer. Correct supplemental air bag and seat belt pretensioner system disposal procedures are set forth in the appropriate INFINITI Service Manual. Incorrect disposal procedures could cause personal injury.

Safety — Seats, seat belts and supplemental restraint system 1-57

MEMO

1-58 Safety — Seats, seat belts and supplemental restraint system

2 Instruments and controls

Cockpit ................................................................... 2-3

Instrument panel .................................................... 2-4

Meters and gauges ................................................. 2-6

Speedometer and odometer ............................... 2-7

Tachometer ......................................................... 2-8

Engine coolant temperature gauge ..................... 2-8

Fuel gauge ......................................................... 2-9

Compass (if so equipped) ....................................... 2-9

Zone variation change procedure ...................... 2-11

Warning/indicator lights and

audible reminders ................................................ 2-12

Checking bulbs ................................................. 2-12

Warning lights .................................................. 2-12

Indicator lights ................................................. 2-18

Audible reminders ............................................ 2-19

Dot matrix liquid crystal display ........................... 2-20

Indicators for operation .................................... 2-22

Indicators for maintenance ............................... 2-24

Trip computer ................................................... 2-26

Security systems .................................................. 2-28

Vehicle Security System ................................... 2-28

INFINITI Vehicle Immobilizer System ................. 2-30

Windshield wiper and washer switch .................... 2-31

Rain-sensing auto wiper system (if

so equipped) .................................................... 2-33

Rear window and outside mirror

defroster switch ................................................... 2-34

Headlight and turn signal switch .......................... 2-34

Xenon headlights ............................................ 2-34

Headlight switch ............................................. 2-35

Turn signal switch ........................................... 2-39

Fog light switch .............................................. 2-39

Hazard warning flasher switch ............................. 2-39

Horn .................................................................... 2-40

Heated seats (if so equipped) .............................. 2-40

SNOW mode switch (if so equipped) .................... 2-42

Vehicle Dynamic Control (VDC) OFF switch ............ 2-42

Clock .................................................................... 2-43

Adjusting the time .......................................... 2-43

Power outlet ........................................................ 2-43

Cigarette lighter and ashtrays (if so equipped) ....... 2-44

Front ............................................................... 2-44

Rear ................................................................ 2-45

Storage ................................................................ 2-45

Cup holders .................................................... 2-45

Sunglasses holder ......................................... 2-47

Glove box ....................................................... 2-48

Console box .................................................... 2-48

Card holder (if so equipped) ........................... 2-50

Storage box (if so equipped) ........................... 2-50

Coat hooks ....................................................... 2-50

Stowing golf bags (Coupe) ................................ 2-51

Cargo net retainers ........................................... 2-51

Trunk net for extra window washer fluid

(Canada only; if so equipped) .......................... 2-52

Windows .............................................................. 2-52

Power windows ................................................ 2-52

Moonroof (if so equipped) .................................... 2-55

Automatic moonroof ......................................... 2-55

Interior lights ...................................................... 2-57

Map lights ........................................................ 2-57

Personal lights (Sedan) .................................... 2-57

Interior light control switch ............................... 2-57

Vanity mirror lights .............................................. 2-58

Trunk light ........................................................... 2-59

HomeLink

so equipped) ........................................................ 2-59

Universal Transceiver (if

Programming HomeLink Programming HomeLink

customers and gate openers ........................... 2-62

Operating the HomeLink

................................ 2-60

for Canadian

Universal Transceiver ...................................... 2-62

Programming troubleshooting ......................... 2-62

Clearing the programmed information ............. 2-63

Reprogramming a single HomeLink

button .......................................... 2-63

If your vehicle is stolen .................................. 2-63

COCKPIT

GUID-A9682D04-AAAB-465F-98B6-B6532C9F1362

1. Vehicle Dynamic Control (VDC) OFF switch (P.5-56)

2. Trunk lid release switch (P.3-18)

3. Sonar system off switch (if so equipped) (P.5-51)

SIC4683

4. Instrument brightness control switch (P.2-38)

5. TRIP/RESET switch for twin trip odometer (P.2-7)

6. Headlight, fog light and turn signal switch (P.2-34)

7. Paddle shifter (if so equipped) (P.5-16)

8. Steering-wheel-mounted controls (left side)

— ENTER or tuning switch (P.4-83) — BACK switch (P.4-83) — TALK switch (if so equipped)

(P.4-110)/Phone switch (if so equipped) (P.4-85, 4-96)

— Volume control switches (P.4-83) — Source select switch (P.4-83)

9. Trip computer switch (P.2-26)

10. Windshield wiper and washer switch (P.2-31)

11. Steering-wheel-mounted controls (right side)

— Cruise control switches (P.5-22) — Intelligent Cruise Control (ICC)

switches (if so equipped) (P.5-24)

12. Hood release handle (P.3-17)

13. Intelligent Key port (P.5-12)

14. Electric tilting/telescopic steering wheel lever (if so equipped) (P.3-25)

15. Manual tilting/telescopic steering wheel lever (if so equipped) (P.3-25)

16. Steering wheel

— Horn (P.2-40) — Driver supplemental air bag

(P.1-42)

Instruments and controls 2-3

INSTRUMENT PANEL

GUID-F966D69B-15F8-48D0-A86B-A60F682B16E9

1. Side ventilator (P.4-30)

2. Meters and gauges (P.2-6)

3. Center ventilator (P.4-30)

4. Audio system (P.4-41)

5. Clock (P.2-43)

6. Center multi-function control panel

SSI0671

— Navigation system* (if so equipped)

— Vehicle information and setting buttons (P.4-9)

— Bluetooth

Hands-Free Phone Sys-

tem (if so equipped) (P.4-85, P.4-96)

— Audio system (P.4-41)

7. Center display (P.4-3)/Navigation system* (if so equipped)

8. Hazard warning flasher switch (P.2-39)

9. Front passenger supplemental air bag (P.1-42)

10. Fuse box cover (P.8-24)

11. Parking brake (for Automatic Transmission models)

— Parking (P.5-21)

12. Push-button ignition switch (P.5-9)

13. Automatic climate control system (P.4-31)

14. Cigarette lighter and ashtray (if so equipped) (P.2-44) or storage box (if so equipped) (P.2-50)

— Power outlet (if so equipped) (P.2-43)

15. Parking brake (for Manual Transmission models)

— Parking (P.5-21)

16. Heated seat switch (if so equipped) (P.2-40)

17. SNOW mode switch (if so equipped) (P.2-42)

18. Rear window and outside mirror (if so equipped) defroster switch (P.2-34)

2-4 Instruments and controls

19. Glove box lid release handle (P.2-48)

20. Trunk release power cancel switch (P.3-19)

*: Refer to the separate Navigation

System Owner’s Manual.

Instruments and controls 2-5

METERS AND GAUGES

GUID-50C93020-C345-4E0C-9F52-C7AB04736560

1. Tachometer (P.2-8)

2. Warning/Indicator lights (P.2-12)

3. Speedometer (P.2-7)

4. Engine coolant temperature gauge (P.2-8)

5. Dot matrix liquid crystal display/

may move slightly after the ignition switch is pushed to the LOCK position. This is not a malfunction.

SIC4288

Odometer/twin trip odometer (P.2-20)

6. Fuel gauge (P.2-9) *: The needle indicators in the speed-

ometer, tachometer, engine coolant temperature gauge and fuel gauge

2-6 Instruments and controls

TRIP A ? TRIP B ? TRIP A

Resetting the trip odometer:

Pushing the TRIP A/B RESET switch

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

for

more than 1 second resets the trip odometer to zero.

Average fuel economy and distance to empty information is also available. (See “Dot matrix liquid crystal display” (P.2-20) and “How to use STATUS button” (P.4-9).)

SIC4289

Speedometer

SPEEDOMETER AND ODOMETER

Speedometer

GUID-88FF886D-55BB-496B-8011-CC5C82ACF75E

GUID-87976F68-0541-4C72-B0C4-146B04F072C8

The speedometer indicates vehicle speed in miles per hour (MPH) and kilometers per hour (km/h).

SIC3259

Odometer/twin trip odometer

The odometer

are displayed on the dot matrix crystal

GUID-5C08B138-E7A9-4EA6-BB29-75239C1D6187

and twin trip odometer

display when the ignition switch is in the ON position.

The odometer records the total distance the vehicle has been driven.

The twin trip odometer records the distance of individual trips.

Changing the display:

Pushing the TRIP A/B RESET switch

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

the bottom left of the combination meter panel changes the display as follows:

Instruments and controls 2-7

SIC4290

SIC4291

CAUTION

If the gauge indicates engine coolant temperature near the hot (H) end of the normal range, reduce vehicle speed to decrease temperature. If gauge is over the normal range, stop the vehicle as soon as safely possible. If the engine is overheated, continued operation of the vehicle may seriously damage the engine. See “If your vehicle overheats” (P.6-10) for immediate action required.

TACHOMETER

The tachometer indicates engine speed in revolutions per minute (RPM). Do not rev

the engine into the red zone

GUID-273B358F-40B0-4C4E-9967-70C4BF4F89C7

CAUTION

When engine speed approaches the red zone, shift to a higher gear or reduce engine speed. Operating the engine in the red zone may cause serious engine damage.

2-8 Instruments and controls

ENGINE COOLANT TEMPERATURE GAUGE

The gauge indicates the engine coolant temperature.

The engine coolant temperature is within the normal range when the gauge needle points within the zone illustration.

The engine coolant temperature varies with the outside air temperature and driving conditions.

GUID-0EBFAC15-E62D-4FAB-ADAB-7BCC3D24A957

shown in the

SIC4292

FUEL GAUGE

GUID-A6CE9D87-1196-4EDB-BE07-B0479D286BC3

The gauge indicates the approximate fuel level in the tank.

The gauge may move slightly during braking, turning, acceleration, or going up or down hills.

The gauge needle returns to E (Empty) after the ignition switch is pushed to the OFF position.

Refill the fuel tank before the gauge registers “E” (Empty).

The low fuel warning

appears on the dot matrix liquid crystal display when the fuel tank is getting low. Refuel as soon as it

is convenient, preferably before the gauge reaches “E”. There will be a small reserve of fuel in the tank when the fuel gauge needle reaches “E”.

The

indicates that the fuel-filler door is located on the passenger’s side of the vehicle.

CAUTION

. If the vehicle runs out of fuel, the

malfunction indicator light (MIL) may come on. Refuel as soon as possible. After a few driving trips, the should turn off. If the light remains on after a few driving trips, have the vehicle inspected by an INFINITI retailer.

. For additional information, see “Mal-

function Indicator Light (MIL)” (P.2-18).

light

COMPASS (if so equipped)

GUID-263D42A7-AD19-460F-8531-86F714066C53

SIC3181

When the ignition switch is pushed to the ON position, the compass display indicate the direction of the vehicle’s heading.

If the display reads “C”, calibrate the compass by driving the vehicle in 3 complete circles at less than 5 MPH (8

Instruments and controls 2-9

will

NOS1741

km/h). You can also calibrate the compass by driving your vehicle on your everyday route. The compass will be calibrated once it has tracked 3 complete circles.

To turn on and off the compass manually, push the switch is in the ON position.

switch

while the ignition

SIC0611B

Zone map

2-10 Instruments and controls

ZONE VARIATION CHANGE PROCEDURE

The difference between magnetic north and geographical north is known as variance. In some areas, this difference can sometimes be great enough to cause false compass readings. Follow these instructions to set the variance for your particular location if this happens:

1. Push the seconds. The current zone number will appear in the display.

2. Find your current location and variance number on the zone map.

3. Push the the new zone number appears in the display, then release the switch. After you release the switch, the display will show a compass direction within a few seconds.

GUID-E09E8E8D-3C27-49AC-9DF4-41F27EDC4D72

switch for more than 3

switch repeatedly until

If the compass deviates from the correct indication soon after repeated adjustment, have the compass checked at an INFINITI retailer.

The compass may not indicate the correct compass point in tunnels or while driving up or down a steep hill.

(The compass returns to the correct

compass point when the vehicle moves to an area where the geomagnetism is stabilized.)

CAUTION

. Do not install a ski rack, antenna, etc.,

which are attached to the vehicle by means of a magnet. They affect the operation of the compass.

. When cleaning the mirror, use a paper

towel or similar material dampened with glass cleaner. Do not spray glass cleaner directly on the mirror as it may cause the liquid cleaner to enter the mirror housing.

Instruments and controls 2-11

WARNING/INDICATOR LIGHTS AND AUDIBLE REMINDERS

GUID-4DFBC906-87A9-4F02-A005-17EFB9C1B112

All-Wheel Drive (AWD) warning light (AWD models)*

Anti-lock Braking System (ABS) warning light

Automatic transmission check warning light Master warning light High beam indicator light

Brake warning light

Charge warning light Supplemental air bag warning light Turn signal/hazard indicator lights

Engine oil pressure warning light Vehicle Dynamic Control (VDC) warning light

4 Wheel Active Steer (4WAS) warning light*

CHECKING BULBS

With all doors closed, apply the parking brake and push the ignition switch to the ON position without starting the engine. The following lights will come on (if so equipped):

, or , , , , ,

The following lights come on briefly and then go off (if so equipped):

, or , , , , ,

If any light does not come on, it may indicate a burned-out bulb or an open

GUID-EA46E715-CDC1-4316-A1CC-964FA500463C

Intelligent Cruise Control (ICC) system warning light (orange)*

Intelligent Key warning light Front fog light indicator light

Low tire pressure warning light Front passenger air bag status light

Preview Function warning light (orange)* Malfunction Indicator Light (MIL)

Seat belt warning light Security indicator light

Automatic transmission position indicator light*

circuit in the electrical system. Have the system checked by an INFINITI retailer.

Some indicators and warnings are also displayed on the dot matrix crystal display between the speedometer and tachometer. (See “Dot matrix liquid crystal display” (P.2-20).)

Exterior light indicator

Vehicle Dynamic Control (VDC) off indicator light

*: if so equipped

WARNING LIGHTS

GUID-7D034C77-E122-4514-8406-A8ED72A0DDF7

All-Wheel Drive (AWD) warning

light (AWD models) (if so equipped)

The warning light comes on when the ignition switch is pushed to ON. It turns off soon after the engine is started.

If the AWD system malfunctions, or the diameter of the front and the rear wheels are different, the warning light will either remain illuminated or blink. (See “AllWheel Drive (AWD)” (P.5-46).)

GUID-6272AC4F-020E-4475-8EA4-DEB8ABD3D971

2-12 Instruments and controls

CAUTION

. If the warning light comes on while

driving there may be a malfunction in the AWD system. Reduce the vehicle speed and have your vehicle checked by an INFINITI retailer as soon as possible.

. If the AWD warning light blinks on when

you are driving:

—

blinks rapidly (about twice a second):

Pull off the road in a safe area, and idle the engine. The driving mode will change to 2WD to prevent the AWD system from malfunctioning. If the warning light turns off, you can drive again.

—

blinks slowly (about once every 2 seconds):

Pull off the road in a safe area, and idle the engine. Check that all tire sizes are the same, tire pressure is correct and tires are not worn.

. If the warning light is still on after the

above operations, have your vehicle checked by an INFINITI retailer as soon

as possible.

or Anti-lock Braking

System (ABS) warning light

When the ignition switch is in the ON position, the Anti-lock Braking System (ABS) warning light illuminates and then turns off. This indicates the ABS is operational.

If the ABS warning light illuminates while the engine is running, or while driving, it may indicate the ABS is not functioning properly. Have the system checked by an INFINITI retailer.

If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally, but without antilock assistance. (See “Brake system” (P.5-

52).)

GUID-999CB2F5-4FF3-4D41-ACF3-7E00ED4B6C0F

Automatic transmission check

warning light (if so equipped)

When the ignition switch is pushed to the ON position, the light comes on for 2 seconds. If the light comes on at any other time, it may indicate the transmission is not functioning properly. Have your INFINITI retailer check and repair the transmission.

GUID-A564A816-81E3-40F1-8684-0ED502ABDB57

or Brake warning light

GUID-9EF95796-7290-4F31-AB06-6BE1BB80003D

This light functions for both the parking brake and the foot brake systems.

Parking brake indicator:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

When the ignition switch is in the ON position, the light comes on when the parking brake is applied.

Low brake fluid warning light:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

When the ignition switch is in the ON position, the light warns of a low brake fluid level. If the light comes on while the engine is running with the parking brake not applied, stop the vehicle and perform the following:

1. Check the brake fluid level. If brake fluid is necessary, add fluid and have the system checked by your INFINITI retailer. (See “Brake and clutch fluid” (P.8-15).)

2. If the brake fluid level is correct, have the warning system checked by an INFINITI retailer.

Anti-lock Braking System (ABS) warning indicator:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

When the parking brake is released and the brake fluid level is sufficient, if both the brake warning light and the Anti-lock

Instruments and controls 2-13

Braking System (ABS) warning light illuminate, it may indicate the ABS is not functioning properly. Have the brake system checked, and if necessary repaired, by an INFINITI retailer promptly. (See “Antilock Braking System (ABS) warning light” (P.2-13).)

WARNING

. Your brake system may not be working

properly if the warning light is on. Driving could be dangerous. If you judge it to be safe, drive carefully to the nearest serv ice station for repairs. Otherwise, have your vehicle towed because driving it could be dangerous.

. Pressing the brake pedal with the

engine stopped and/or low brake fluid level may increase your stopping distance and braking will require greater pedal effort as well as pedal travel.

. If the brake fluid level is below the

minimum or MIN mark on the brake fluid reservoir, do not drive until the brake system has been checked at an INFINITI retailer.

Charge warning light

If the light comes on while the engine is running, it may indicate the charging system is not functioning properly. Turn the engine off and check the alternator belt. If the belt is loose, broken, missing or if the light remains on, see an INFINITI retailer immediately.

GUID-C69BB772-79B3-4499-9F43-9AE7FF3014AD

CAUTION

Do not continue driving if the alternator belt is loose, broken or missing.

Engine oil pressure warning

light

This light warns of low engine oil pressure. If the light flickers or comes on during normal driving, pull off the road in a safe area, stop the engine immediately and call an INFINITI retailer or other authorized repair shop.

The engine oil pressure warning light is not designed to indicate a low oil level. Use the dipstick to check the oil level. (See

“Engine oil” (P.8-11).)

GUID-6767AD33-F6A9-4349-9656-7255256FF262

CAUTION

Running the engine with the engine oil pressure warning light on could cause serious damage to the engine almost immediately. Such damage is not covered by warranty. Turn off the engine as soon as it is safe to do so.

4 Wheel Active Steer (4WAS)

warning light (if so equipped)

If the light comes on while the engine is running, it may indicate that there is a malfunction with the 4 Wheel Active Steer (4WAS) portion of the steering system. Push the ignition switch to the OFF position and then to the ON position. If the light does not turn off after cycling the engine, have the system checked by an INFINITI retailer.

For further information about the 4 Wheel Active Steer system, see “4 Wheel Active Steer (4WAS) system” (P.5-58).

If a malfunction occurs in the system, the 4 Wheel Active Steer (4WAS) function will cease but driving can be continued. However, the steering wheel is slightly turned

GUID-F4EA15D8-084C-4F11-9CF5-9BFAB55B87A4

2-14 Instruments and controls

even when driving on a straight road. Drive carefully to the nearest INFINITI retailer.

Intelligent Cruise Control (ICC) system warning light (orange; if so equipped)

This light comes on if there is a malfunction in the Intelligent Cruise Control (ICC) system.

If the warning light comes on, park the vehicle in a safe place. Turn the engine off, restart the engine, resume driving and set the ICC system again.

If it is not possible to set the system or the indicator stays on, it may indicate that the system is malfunctioning. Although the vehicle is still driveable under normal conditions, have the vehicle checked at an INFINITI retailer.

After the ignition switch is pushed to the ON position, this light comes on for about 2 seconds and then turns off.

This light warns of a malfunction with the Intelligent Key system.

If the light comes on while the engine is stopped, it may be impossible to start the engine. If the light comes on while the

GUID-FF29B1E7-F6C4-403D-8621-C6A7F86246EF

Intelligent Key warning light

GUID-7E046839-8973-408F-BF89-AB2223E4A062

engine is running, you can drive the vehicle. However in these cases, contact an INFINITI retailer for repair as soon as possible.

Low tire pressure warning

light

Your vehicle is equipped with a Tire Pressure Monitoring System (TPMS) that monitors the tire pressure of all tires except the spare.

The low tire pressure warning light warns of low tire pressure or indicates that the TPMS is not functioning properly.

After the ignition switch is pushed ON, this light illuminates for about 1 second and turns off.

Low tire pressure warning:

If the vehicle is being driven with low tire pressure, the warning light will illuminate.

A CHECK TIRE PRESSURE warning also appears on the dot matrix liquid crystal display.

When the low tire pressure warning light illuminates, you should stop and adjust the tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label. The low tire

GUID-4B828BB9-9D9C-4BA9-B41A-9EF6D3CB156D

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

pressure warning light does not automatically turn off when the tire pressure is adjusted. After the tire is inflated to the recommended pressure, the vehicle must be driven at speeds above 16 MPH (25 km/h) to activate the TPMS and turn off the low tire pressure warning light. Use a tire pressure gauge to check the tire pressure.

The CHECK TIRE PRESSURE warning is active as long as the low tire pressure warning light remains illuminated.

For additional information, see “Dot matrix liquid crystal display” (P.2-20), “Tire Pressure Monitoring System (TPMS)” (P.5-4) and “Tire Pressure Monitoring System (TPMS)” (P.6-2).

TPMS malfunction:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

If the TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 1 minute when the ignition switch is pushed ON. The light will remain on after 1 minute. Have the system checked by an INFINITI retailer. The CHECK TIRE PRESSURE warning does not appear if the low tire pressure warning light illuminates to indicate a TPMS malfunction.

For additional information, see “Tire Pressure Monitoring System (TPMS)” (P.5-4).

Instruments and controls 2-15

WARNING

. If the light does not illuminate with the

ignition switch pushed ON, have the vehicle checked by an INFINITI retailer as soon as possible.

. If the light illuminates while driving,

avoid sudden steering maneuvers or abrupt braking, reduce vehicle speed, pull off the road to a safe location and stop the vehicle as soon as possible. Driving with under-inflated tires may permanently damage the tires and increase the likelihood of tire failure. Serious vehicle damage could occur and may lead to an accident and could result in serious personal injury. Check the tire pressure for all four tires. Adjust the tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light OFF. If the light still illuminates while driving after adjusting the tire pressure, a tire may be flat. If you have a flat tire, replace it with a spare tire as soon as possible.

. When a spare tire is mounted or a wheel

is replaced, the TPMS will not function and the low tire pressure warning light will flash for approximately 1 minute. The light will remain on after the 1 minute. Contact your INFINITI retailer as soon as possible for tire replacement and/or system resetting.

. Replacing tires with those not originally

specified by INFINITI could affect the proper operation of the TPMS.

CAUTION

. The TPMS is not a substitute for the

regular tire pressure check. Be sure to check the tire pressure regularly.

. If the vehicle is being driven at speeds of

less than 16 MPH (25 km/h), the TPMS may not operate correctly.

. Be sure to install the specified size of

tires to the four wheels correctly.

Master warning light

When the ignition switch is in the ON position, the master warning light illumi-

GUID-BFD238A1-B056-42EA-B9A0-FCCF2B17501F

nates if any of the following are displayed on the dot matrix liquid crystal display:

. No key warning . Low fuel warning . Low washer fluid warning . Parking brake release warning . Door/trunk open warning . Loose fuel cap warning . Check tire pressure warning

See “Dot matrix liquid crystal display” (P.2-

20).

Preview Function warning light

(orange; if so equipped)

The light comes on if there is a malfunction in the Brake Assist (with Preview Function) system.

If the warning light comes on, park the vehicle in a safe place. Turn the engine off, restart the engine, resume driving and set the ICC system again.

GUID-B4E486C7-1748-4EBD-A37A-79C9F389E7E0

2-16 Instruments and controls

Seat belt warning light and chime

The light and chime remind you to fasten seat belts. The light illuminates whenever the ignition switch is pushed to the ON position, and will remain illuminated until the driver’s seat belt is fastened. At the same time, the chime will sound for about 6 seconds unless the driver’s seat belt is securely fastened.

The seat belt warning light for the front passenger will illuminate if the seat belt is not fastened when the front passenger’s seat is occupied. For approximately 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.

See “Seat belts” (P.1-14) for precautions on seat belt usage.

GUID-D581458D-4D08-42CB-98CF-6FDB12BEDBBB

Supplemental air bag warning light

After pushing the ignition switch to the ON position, the supplemental air bag warning light will illuminate. The supplemental air bag warning light will turn off after about 7 seconds if the supplemental front air bag and supplemental side air bag, curtain side-impact air bag systems and/or pre-

GUID-C698CB3F-4874-4667-8C3F-C4879E0088E6

tensioner seat belt are operational. If any of the following conditions occur, the

supplemental front air bag, supplemental side air bag, supplemental curtain sideimpact air bag and pretensioner seat belt needs servicing and your vehicle must be taken to your nearest INFINITI retailer.

. The supplemental air bag warning light

remains on after approximately 7 seconds.

. The supplemental air bag warning light

flashes intermittently.

. The supplemental air bag warning light

does not come on at all.

Unless checked and repaired, the Supplemental Restraint Systems and/or the pretensioner seat belt may not function properly.

For additional information, see “Supplemental restraint system” (P.1-42).

WARNING

If the supplemental air bag warning light is on, it could mean that the supplemental front air bag, supplemental side air bag, curtain side-impact air bag systems and/or pretensioner seat belt will not operate in an

accident. To help avoid injury to yourself or others, have your vehicle checked by a retailer as soon as possible.

Vehicle Dynamic Control (VDC)

warning light

The light will blink when the VDC system or the traction control system is operating, thus alerting the driver that the vehicle is nearing its traction limits. The road surface may be slippery.

When the vehicle dynamic control warning light illuminates, the vehicle dynamic control system is turned on, this light alerts the driver that the vehicle dynamic control system’s fail-safe mode is operating. For example, the vehicle dynamic control system may not be functioning properly. Have the system checked by an INFINITI retailer. If a malfunction occurs in the system, the vehicle dynamic control system function will be canceled but the vehicle is still driveable. Have the system checked by an INFINITI retailer. For additional information, see “Vehicle Dynamic Control (VDC) system” (P.5-56) of this manual.

GUID-4B2E20A8-B5B5-4DB7-8E18-2B75CB592A50

Instruments and controls 2-17

INDICATOR LIGHTS

GUID-6F0BDF2B-2346-4D8D-A381-D1F73487B880

Automatic Transmission (AT) position indicator light (if so equipped)

When the ignition switch is pushed to the “ON” position, the indicator shows the automatic selector position.

In the manual shift mode, when the transmission does not shift to the selected gear due to a transmission protection mode, the AT position indicator light will blink and a chime will sound.

See “Automatic transmission” (P.5-14) for further details.

Exterior light indicator

This indicator illuminates when the headlight switch is turned to the AUTO (if so equipped), front side marker lights, the front parking lights, instrument panel lights, rear combination lights, license plate lights or headlights are on. The indicator turns off when these lights are turned off.

The front fog light indicator light illuminates when the front fog lights are on. (See

GUID-12A09BA6-228C-4AB5-9EA2-02DEE0F0D92F

GUID-719E4302-7BDF-4301-A5E8-B6A39286535A

or position and the

Front fog light indicator light

GUID-E775FCDC-933F-4374-BAC3-DEE01A256BE0

“Fog light switch” (P.2-39).)

Front passenger air bag status

light

The front passenger air bag status light (

) will be lit and the passenger front air bag will be OFF depending on how the front passenger seat is being used.

For front passenger air bag status light operation, see “INFINITI Advanced Air Bag System (front seats)” (P.1-47) of this manual.

This light comes on when the headlight high beam is on and goes out when the low beam is selected.

GUID-6F13EEF6-2D06-42B1-92CB-0A7AAE6D4FDD

High beam indicator light

GUID-CF1B5A86-829A-457D-AB7B-526C908A9C34

Malfunction Indicator Light

(MIL)

If the malfunction indicator light comes on steady or blinks while the engine is running, it may indicate a potential emission control malfunction.

The malfunction indicator light may also come on steady if the fuel-filler cap is loose or missing, or if the vehicle runs out of fuel. Check to make sure the fuel-filler cap is installed and closed tightly, and that the

GUID-31750F29-30E3-4506-AEB2-E92A82111EA9

vehicle has at least 3 US gallons (14 liters) of fuel in the fuel tank.

After a few driving trips, the

light should turn off if no other potential emission control system malfunction exists.

If this indicator light remains on for 20 seconds and then blinks for 10 seconds when the engine is not running, it indicates that the vehicle is not ready for an emission control system inspection/maintenance test. (See “Readiness for Inspection/Maintenance (I/M) test (US only)” (P.9-

26).)

Operation:

GUID-D73A39BF-43C8-459F-9C24-47B7F579C407

The malfunction indicator light will come on in one of two ways:

. Malfunction indicator light on steady —

An emission control system malfunction has been detected. Check the fuelfiller cap if the LOOSE FUEL CAP warning appears in the dot matrix liquid crystal display. If the fuel-filler cap is loose or missing, tighten or install the cap and continue to drive the vehicle. The after a few driving trips. If the

light should turn off

light

does not turn off after a few driving

2-18 Instruments and controls

trips, have the vehicle inspected by an INFINITI retailer. You do not need to have your vehicle towed to the retailer.

. Malfunction indicator light blinking —

An engine misfire has been detected which may damage the emission control system.

To reduce or avoid emission control system damage:

1) Do not drive at speeds above 45 MPH (72 km/h).

2) Avoid hard acceleration or deceleration.

3) Avoid steep uphill grades.

4) If possible, reduce the amount of cargo being hauled or towed.

The malfunction indicator light may stop blinking and remain on.

Have the vehicle inspected by an INFINITI retailer. You do not need to have your vehicle towed to the retailer.

CAUTION

Continued vehicle operation without having the emission control system checked and repaired as necessary could lead to poor driveability, reduced fuel economy, and

possible damage to the emission control system.

Security indicator light

GUID-99C24DC6-544D-45AC-90DB-96CA87927F70

The light blinks when the ignition switch is in the ACC, OFF or LOCK position. This function indicates the security system equipped on the vehicle is operational.

If the security system is malfunctioning, this light will remain on while the ignition switch is in the ON position. For additional information, see “Security systems” (P.2-

28).

Turn signal/hazard indicator

lights

The light flashes when the turn signal switch lever or hazard switch is turned on.

GUID-43A6DFE4-0C5C-4670-8FA3-F545A4863F5C

Vehicle Dynamic Control (VDC)

off indicator light

The light comes on when the vehicle dynamic control off switch is pushed to OFF.This indicates that the vehicle dynamic control system and traction control system are not operating.

GUID-A3E5746E-A6AD-4CFD-BF58-F2861559DFFC

AUDIBLE REMINDERS

Key reminder chime

GUID-41C4B23E-C45A-494B-A7CD-10E6C3CED223

GUID-CF2F9D77-25F2-40E6-8D1D-517CC8383919

A chime will sound if the driver side door is opened while the ignition switch is pushed to the ACC position or pushed to the OFF or LOCK position with the Intelligent Key left in the Intelligent Key port. Make sure the ignition switch is pushed to the OFF position, and take the Intelligent Key with you when leaving the vehicle.

Light reminder chime

GUID-EB436840-830A-402A-A3BA-8D5BCF0162C6

A chime will sound when the driver side door is opened with the light switch in the

or position and the ignition switch

in the ACC, OFF or LOCK position. Turn the light switch off when you leave the

vehicle.

Parking brake reminder chime

GUID-44BA1A13-88DD-4711-BED2-C34A1A0970D0

The parking brake reminder chime will sound if the vehicle is driven at more than 4 MPH (7 km/h) with the parking brake applied. Stop the vehicle and release the parking brake.

Instruments and controls 2-19

Infiniti G Coupe 2013 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
