Infiniti G37 2011 Workshop Manual

Page 1
Edition: October 2010 Revision: December 2011 Publication No. SM1E-1H36U1
All Rights Reserved. No part of this Service Manual may be reproduced or stored in a retrieval system, or transmit­ted in any form, or by any means, electronic, mechani­cal, recording or otherwise, without the prior written per­mission of NISSAN MOTOR CO., LTD.

QUICK REFERENCE INDEX

GENERAL INFORMATION
B ENGINE
C ELECTRIC POWER TRAIN
D TRANSMISSION & DRIVELINE
E SUSPENSION
F BRAKES
G STEERING
H RESTRAINTS
I VENTILATION, HEA T ER & AIR
CONDITIONER
J BODY INTERIOR
K BODY EXTERIOR, DOORS,
ROOF & VEHICLE SECURITY
L DRIVER CONTROLS
M ELECTRICAL & POWER CON-
TROL
N DRIVER INFORMATION &
MULTIMEDIA
O CRUISE CONTROL &
DRIVER ASSISTANCE
P MAINTENANCE
GI
General Information
EM
Engine Mechanical
LU
Engine Lubrication System
CO
Engine Cooling System
EC
Engine Control System
FL
Fuel System
EX
Exhaust System
STR
Starting System
ACC
Accelerator Control System
HBC
Hybrid Control System
HBB
Hybrid Battery System
HBR
Hybrid Brake System
EVC
EV Control System
TMS
Traction Motor System
EVB
EV Battery System
VC
Vehicle Charging System
HCO
High Voltage Cooling System
CL
Clutch
TM
Transaxle & Transmission
DLN
Driveline
FAX
Front Axle
RAX
Rear Axle
FSU
Front Suspension
RSU
Rear Suspension
SCS
Suspension Control System
WT
Road Wheels & Tires
BR
Brake System
PB
Parking Brake System
BRC
Brake Control System
ST
Steering System
STC
Steering Control System
SB
Seat Belt
SBC
Seat Belt Control System
SR
SRS Airbag
SRC
SRS Airbag Control System
VTL
Ventilation System
HA
Heater & Air Conditioning System
HAC
Heater & Air Conditioning Control System
INT
Interior
IP
Instrument Panel
SE
Seat
ADP
Automatic Drive Positioner
DLK
Door & Lock
SEC
Security Control System
GW
Glass & Window System
PWC
Power Window Control System
RF
Roof
HD
Hood
EXT
Exterior
BRM
Body Repair
MIR
Mirrors
EXL
Exterior Lighting System
INL
Interior Lighting System
WW
Wiper & Washer
DEF
Defogger
HRN
Horn
VSP
Approaching Vehicle Sound for Pedestrians (VSP)
PWO
Power Outlet
BCS
Body Control System
LAN
LAN System
PCS
Power Control System
CHG
Charging System
PG
Power Supply, Ground & Circuit Elements
MWI
Meter, Warning Lamp & Indicator
WCS
Warning Chime System
SN
Sonar System
AV
Audio, Visual & Navigation System
CCS
Cruise Control System
DAS
Driver Assistance System
DMS
Drive Mode System
MA
Maintenance
A B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Page 2

FOREWORD

This manual contains maintenance and repair procedure for the 2011 INFINITI G Convertible.
In order to assure your safety and the efficient functioning of the vehicle, this manual should be read thoroughly. It is especially important that the PRECAUTIONS in the GI section be completely understood before starting any repair task.
All information in this manual is based on the latest product information at the time of publication. The right is reserved to make changes in specifi­cations and methods at any time without notice.
IMPORTANT SAFETY NOTICE
The proper performance of service is essential for both the safety of the technician and the efficient functioning of the vehicle. The service methods in this Service Manual are described in such a manner that the service may be performed safely and accurately. Service varies with the procedures used, the skills of the technician and the tools and parts available. Accordingly, anyone using service procedures, tools or pa rts which are not specifically recommended by NISSAN must first be completely sat isfied that neither personal safety nor the vehicle’s safety will be jeopardized by the service
method selected.
Page 3
PLEASE HELP MAKE THIS SERVICE MANUAL BETTER!
INFINITI
Your comments are important to INFINITI and will help us to improve our Service Manuals. Use this form to report any issues or comments you may have regarding our Service Manuals. Please print this form and type or write your comments below. Mail or fax to:
SERVICE MANUAL: Model: Year: PUBLICATION NO. (Refer to Quick Reference Index ):
Please describe any Service Manual issues or problems in detail: Page number(s)
R
Nissan North America, Inc. Technical Service Information 39001 Sunrise Drive, P.O. Box 9200 Farmington Hills, MI USA 48331 FAX: (248) 488-3880
Note: Please include a copy of each page, marked with your comments.
Are the trouble diagnosis procedures logical and easy to use? (circle your answer) YES NO
If no, what pagenumber(s)? Please describe the issue or problem in detail:
Is the organization of the manual clear and easy to follow? (circle your answer) YES NO
Please comment:
What information should be included in INFINITI Service Manuals to better support you in servicing or repairing customer vehicles?
Note: Please include a copy of each page,markedwithyourcomments.
DATE: YOUR NAME: POSITION: DEALER: DEALER NO.: ADDRESS: CITY: STATE/PROV./COUNTRY: ZIP/POSTAL CODE:
Page 4
QUICK REFERENCE CHART G CONVERTIBLE
2011
QUICK REFERENCE CHART G CONVERTIBLE PFP:00000
ENGINE TUNE-UP DATA (VQ37VHR) ELS0003W
Engine model VQ37VHR Firing order 1-2-3-4-5-6
2
, psi)
2
, psi)
rpm
650 ± 50
10° ± 5°
157 (1.6, 23)
Idle speed A/T (In “P or N” position) M/T (In Neutral position)
Ignition timing (BTDC at idle speed)
Tensions of drive belt Auto adjustment by auto tens ioner Radiater cap relief pressure
Standard 122.3 - 151.7 (1.2 - 1.5, 18 - 22) Limit 107 (1.1, 16)
Cooling system leakage testing pressure Compression pressure
Standard 1,667 - 2,354 (17 - 24, 242 - 341) Minimum 1,226 (12.5, 178) Differential limit between cylinders 98 (1.0, 14) Make DENSO
Spar k plug (Iridium-tipped type)
Standard type FXE24HR11
Gap
kPa (kg/cm
Stan dard 1.1 mm (0.043 in) Limit 1.4 mm (0.055 in)
kPa (kg/cm
kPa (kg/cm
2
, psi)/200 rpm
Page 5
QUICK REFERENCE CHART G CONVERTIBLE
2011
FRONT WHEEL ALIGNMENT
Wheel size 225/50R18 225/45R19
Minimum –1° 10 (–1.16°)
Camber Degree minute (Decimal degree)
Caster Degree minute (Decimal degree)
Kingpin inclination Degree minute (Decimal degree)
Total toe-in Distance
Toe-in
Toe angle (left wheel or right wheel) Degree minute (Decimal degree)
Measure value under unladen* conditions. *: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Nominal –0° 25 (–0.42°) Maximum 0° 20 (0.33°) Left and right differe nce 0° 33 (0.55°) or less Minimum 4° 05 (4.09°)4° 10′ (4.17°) Nominal 4° 50 (4.83°)4° 55′ (4.92°) Maximum 5° 35 (5.58°)5° 40′ (5.66°) Left and right differe nce 0° 39 (0.65°) or less Minimum 6° 40 (6.67°) Nominal 7° 25 (7.42°) Maximum 8° 10 Minimum 0 mm (0.00 in) Nominal In 1 mm (0.04 in) Maximum In 2 mm (0.08 in) Minimum 0° 00 (0.00°) Nominal In 0° 02 30′′ (0.04°) Maximum In 0° 05 (0.08°)
(8.16°)
ELS0003X
REAR WHEEL ALIGNMENT ELS0003Y
Minimum –1° 50 (–1.83°) Camber Degree minute (Decimal degree)
Total toe-in Distance
Toe-in
Toe angle (left wheel or right wheel) Degree minute (Decimal degree)
Measure value under unladen* conditions. *: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Nominal –1° 20 (–1.33°)
Maximum –0° 50 (–0.84°)
Minimum 0 mm (0.00 in)
Nominal In 2.8 mm (0.110 in)
Maximum In 5.6 mm (0.220 in)
Minimum 0° 00 (0.00°)
Nominal In 0° 07 (0.12°)
Maximum In 0° 14 (0.23°)
BRAKE PEDAL
Unit: mm (in) Brake pedal height (H1) 171.5 - 181.5 (6.75 - 7.15) Depressed brake pedal height (H
[Depressing 490 N (50 kg, 110 lb) while turning the engine ON]
2)
124.0 (4.88) or more
Page 6
QUICK REFERENCE CHART G CONVERTIBLE
FRONT DISC BRAKE
1 Piston Type
Item Limit
Brake pad Wear thickness 2.0 (0.079)
Wear thickness 30.0 (1.181)
Disc rotor
Thickness variation (measured at 8 positions) 0.015 (0.0006) Runout (with it attached to the vehicle) 0.035 (0.0014)
4 Piston Type
Item Limit
Brake pad Wear thickness 2.0 (0.079)
Wear thickness 30.0 (1.181)
Disc rotor
Thickness variation (measured at 8 positions) 0.015 (0.0006) Runout (with it attached to the vehicle) 0.035 (0.0014)
REAR DISC BRAKE
1 Piston Type
Item Limit
Brake pad Wear thickness 2.0 (0.079)
Wear thickness 15.0 (0.591)
Disc rotor
Thickness variation (measured at 8 positions) 0.015 (0.0006) Runout (with it attached to the vehicle) 0.055 (0.0022)
2011
Unit: mm (in)
Unit: mm (in)
Unit: mm (in)
2 Piston Type
Item Limit
Brake pad Wear thickness 2.0 (0.079)
Wear thickness 18.0 (0.709)
Disc rotor
Thickness variation (measured at 8 positions) 0.015 (0.0006) Runout (with it attached to the vehicle) 0.055 (0.0022)
Unit: mm (in)
Page 7
QUICK REFERENCE CHART G CONVERTIBLE
2011
REFILL CAPACITIES
UNIT Liter US measure Fuel tank 75.6 20 gal
Engine coolant capacity [With reservoir tank ( “MAX” level)]
Engine oil
Transmission
Final drive 1.4 3 pt Power steering system 1.0 1-1/8 qt
Air conditioning system
A/T models 8.5 9 qt M/T models 8.6 9-1/8 qt Drain and refill
With oil filter change 4.9 5-1/8 qt
Without oil filter change 4.6 4-7/8 qt Dry engine (Overhaul) 5.7 6 qt A/T 9.2 9-3/4 qt M/T 2.83 6 pt
Compressor oil 0.15 5.07 fl oz Refrigerant 0.55 kg 1.21 lb
ELS00040
Page 8
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
Revision: 2011 December 2011 G Convertible
SECTION GW
A
B
GLASS & WINDOW SYSTEM
CONTENTS
SYMPTOM DIAGNOSIS ...............................2
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ................................................................
Work Flow .................................................................2
Inspection Procedure ................................................4
Diagnostic Worksheet ...............................................6
PRECAUTION ...............................................8
PRECAUTIONS ...................................................8
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
Service Procedure Precautions for Models with a
Pop-up Roll Bar .........................................................
Precaution for Procedure without Cowl Top Cover ......9
Precaution for Battery Service ........ ..........................9
Handling for Adhesive and Primer ............................9
PREPARATION ...........................................10
PREPARATION ..................................................10
Special Service Tools ............................................10
Commercial Service Tools .......................... ...........10
REMOVAL AND INSTALLATION ...............11
WINDSHIELD GLASS .......................................11
Exploded View .........................................................11
Removal and Installation .........................................12
2
Inspection ................................................................13
REAR WINDOW GLASS ..................................14
Exploded View .........................................................14
Removal and Installation .........................................14
Inspection ................................................................15
QUARTER WINDOW GLASS ...........................16
Exploded View .........................................................16
Removal and Installation .........................................16
8
8
Disassembly and Assembly .....................................18
Inspection and Adjustment ......................................18
DOOR GLASS ...................................................22
Exploded View .........................................................22
Removal and Installation .........................................22
Inspection and Adjustment ......................................23
DOOR REGULATOR ........................................27
Exploded View .........................................................27
Removal and Installation .........................................27
Disassembly and Assembly .....................................28
Inspection After Removal ........................................28
Inspection and Adjustment ......................................28
C
D
E
F
G
H
I
J
GW
L
M
N
GW-1
O
P
Page 9
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
SYMPTOM DIAGNOSIS
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work Flow INFOID:0000000006472371
SBT842
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag­nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any customer comments. Refer to GW-6, " conditions that exist when the noise occurs.
• The customer may not be able to provide a detailed description or the location of the noise. Attempt to obtain all the facts and conditions that exist when the noise occurs (or does not occur).
• If there is more than one noise in the vehicle, perform a diagnosis and repair the noise that the customer is concerned about. This can be accomplished by performing a test drive with the customer.
• After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics are provided so that the customer, service adviser, and technician use the same language when describing the noise.
• Squeak – (Like tennis shoes on a clean floor) Squeak characteristics include the light contact / fast movement / brought on by road conditions / hard sur­faces = high-pitched noise / softer surfaces = low-pitched noises / edge to surface = chirping
• Creak – (Like walking on an old wooden floor) Creak characteristics include firm contact / slow movement/twisting with a rotational movement / pitch dependent on materials / often brought on by activity.
• Rattle – (Like shaking a baby rattle) Rattle characteristics include fast repeated contact / vibration or similar movement / loose parts/missing clip or fastener / incorrect clearance.
• Knock – (Like a knock on a door) Knock characteristics include hollow sounds / sometimes repeating / often brought on by driver action.
• Tick – (Like a clock second hand) Tick characteristics include gentle contacting of light materials / loose components / can be caused by driver action or road conditions.
• Thump – (Heavy, muffled knock noise) Thump characteristics include softer knock / dull sounds often brought on by activity.
• Buzz – (Like a bumblebee) Buzz characteristics include high frequency rattle / firm contact.
• Often the degree of acceptable noise level varies depending upon the person. A noise that a technician may judge as acceptable may be very irritating to a customer.
• Weather conditions, especially humidity and temperature, may have a great effect on noise level.
Diagnostic Worksheet". This information is necessary to duplicate the
DUPLICATE THE NOISE AND TEST DRIVE
GW-2
Page 10
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to duplicate the same conditions when the repair is reconfirmed. If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli­cate the noise with the vehicle stopped by doing one or all of the following items:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle “twist”.
5) At idle, apply engine load (electrical load, half-clutch on M/T models, drive position on A/T models).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
• Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
• If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the vehicle body.
A
B
C
D
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related to the concern or symptom. If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1. Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
(Chassis ear: J-39570, engine ear, and mechanics stethoscope).
2. Narrow down the noise to a more specific area and identify the cause of the noise by:
• Removing the component(s) in the area that is / are suspected to be the cause of the noise. Do not use too much force when removing clips and fasteners, otherwise clips and fasteners can be broken or lost during the repair, resulti ng in the creation of new noise.
• Tapping or pushing/pulling the component(s) that is / are suspected to be the cause of the noise. Do not tap or push/pull the component(s) with excessive force, otherwise the noise is eliminated only tempo­rarily.
• Feeling for a vibration by hand by touching the component(s) that is / are suspected to be the cause of the noise.
• Placing a piece of paper between components that are suspected to be the cause of the noise.
• Looking for loose components and contact marks. Refer to GW-4, "
Inspection Procedure".
REPAIR THE CAUSE
• If the cause is a loose component, tighten the component securely.
• If the cause is insufficient clearance between components:
- Separate components by repositioning or loosening and retightening the components, if possible.
- I nsulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape, or ure­thane tape. A NISSAN Squeak and Rattle Kit (J-43980) is available through the authorized NISSAN Parts Department.
CAUTION:
Never use excessive force as many components are constructed of plastic and may be damaged. NOTE:
Always check with the Parts Department for the latest parts information. The following materials are contained in the NISSAN Squeak and Rattle Kit (J-43980). Each item can be ordered separately as needed. URETHANE PADS [1.5 mm (0.059 in) thick] Insulates connectors, harness, etc.
• 76268-9E005: 100 × 135 mm (3.937 × 5.315 in)
• 76884-71L01: 60 × 85 mm (2.362 × 3.346 in)
• 76884-71L02: 15 × 25 mm (0.591 × 0.984 in)
INSULATOR (Foam blocks) Insulates components from contact. Can be used to fill space behind a panel.
• 73982-9E000: 45 mm (1.772 in) thick, 50 × 50 mm (1.969 × 1.969 in)
• 73982-50Y00: 10 mm (0.394 in) thick, 50 × 50 mm (1.969 × 1.969 in)
INSULATOR (Light foam block) 80845-71L00: 30 mm (1.18 in) thick, 30 × 50 mm (1.181 × 1.969 in) FELT CLOTHTAPE
E
F
G
H
I
J
GW
L
M
N
O
P
GW-3
Page 11
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
Used to insulate where movement does not occur. Ideal for instrument panel applications.
• 68370-4B000: 15 × 25 mm (0.591 × 0.984 in) pad
• 68239-13E00: 5 mm ( 0.197 in) wide tape roll The following materials, not found in the kit, can also be used to repair squeaks and rattles. UHMW (TEFLON) TAPE Insulates where slight movement is present. Ideal for instrument panel applications. SILICONE GREASE Used in place of UHMW tape that is visible or does not fit. Only lasts a few months. SILICONE SPRAY Used when grease cannot be applied. DUCT TAPE Used to eliminate movement.
CONFIRM THE REPAIR
After repair is complete, test drive the vehicle to confirm that the cause of noise is repaired by test driving the vehicle. Operate the vehicle under the same conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
Inspection Procedure INFOID:0000000006472372
Refer to Table of Contents for specific component removal and installation information.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between:
1. The cluster lid A and instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar garnish
4. Instrument panel to windshield
5. Instrument panel mounting pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint These incidents can usually be located by tapping or moving the components to duplicate the noise or by pressing on the components while driving to stop the noise. Most of these incidents can be repaired by applying felt cloth tape or silicon spray (in hard to reach areas). Urethane pads can be used to insulate wiring harness.
CAUTION:
Never use silicone spray to isolate a squeak or rattle. If the area is saturated with silicone, the recheck of repair becomes impossible.
CENTER CONSOLE
Components to check include:
1. Shifter assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Check the following items:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon connection to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Tapping, moving the components, or pressing on them while driving to duplicate the conditions can isolate many of these incidents. The areas can usually be insulated with felt cloth tape or insulator foam blocks from the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the customer. In addition check for the following items:
GW-4
Page 12
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
1. Trunk lid dumpers out of adjustment
2. Trunk lid striker out of adjustment
3. Trunk lid torsion bars knocking together
4. A loose license plate or bracket Most of these incidents can be repaired by adjusting, securing, or insulating the item(s) or component(s) caus-
ing the noise.
A
B
SUNROOF/HEADLINING
Noises in the sunroof / headlining area can often be traced to one of the following items:
1. Sunroof lid, rail, linkage, or seals making a rattle or light knocking noise
2. Sunvisor shaft shaking in the holder
3. Front or rear windshield touching headlining and squeaking Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
SEATS
When isolating seat noise it is important to note the position the seat is in and the load placed on the seat when the noise occurs. These conditions should be duplicated when verifying and isolating the cause of the noise. Causes of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then transmitted into the passenger compartment. Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move, or insulate one component at a time and test drive the vehicle. Also, engine RPM or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or insulating the component causing the noise.
C
D
E
F
G
H
I
J
GW
L
M
GW-5
N
O
P
Page 13
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
Diagnostic Worksheet
INFOID:0000000006472373
PIIB8741E
GW-6
Page 14
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: 2011 December 2011 G Convertible
< SYMPTOM DIAGNOSIS >
A
B
C
D
E
F
G
H
I
J
GW
L
M
N
O
PIIB8742E
GW-7
P
Page 15
PRECAUTIONS
Revision: 2011 December 2011 G Convertible
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this Service Manual.
WARNING:
Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see “SRS AIR BAG”.
• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.
INFOID:0000000006472374
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
Always observe the following items for preventing accidental activation.
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury.
• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Service Procedure Precautions for Models with a Pop-up Roll Bar INFOID:0000000006472375
WARNING:
Always observe the following items for preventing accidental activation.
• Risk of passenger injury or death may increase if the pop-up roll bar does not deploy during a roll
over collision. In order to reduce the chance of an incident where the pop-up roll bar is inoperative, all maintenance must be performed by a NISSAN or INFINITI dealer.
• Before removing and installing the pop-up roll bar component parts and harness, always turn the
ignition switch OFF, disconnect the battery negative terminal, and wait for 3 minutes or more. (The purpose of this operation is to discharge electricity that is accumulated in the auxiliary power supply circuit in the air bag diagnosis sensor unit.)
• When repairing, removing, and installing a pop-up roll bar, always refer to SRS AIR BAG and SRS
AIR BAG CONTROL warnings in the Service Manual.
GW-8
Page 16
PRECAUTIONS
Revision: 2011 December 2011 G Convertible
< PRECAUTION >
Precaution for Procedure without Cowl Top Cover INFOID:0000000006472376
When performing the procedure after removing cowl top cover , cover the lower end of windshield with urethane, etc to prevent damage to windshield.
PIIB3706J
A
B
C
D
Precaution for Battery Service INFOID:0000000006472377
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer­ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic window function will not work with the battery disconnected.
Handling for Adhesive and Primer INFOID:0000000006472378
• Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.
• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Open the seal of the primer and adhesive just before application. Discard the remainder.
• Before application, be sure to shake the primer container to stir the contents. If any floating material is found, do not use it.
• If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with soap.
• When using primer and adhesive, always observe the precautions in the instruction manual.
E
F
G
H
I
J
GW
L
GW-9
M
N
O
P
Page 17
PREPARATION
Revision: 2011 December 2011 G Convertible
< PREPARATION >
PREPARATION
PREPARATION
Special Service Tools INFOID:0000000006472379
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool numb er
(Kent-Moore No.)
Tool name
Description
(J-39570) Chassis ear
SIIA0993E
(J-43980) NISSAN Squeak and Rat­tle Kit
SIIA0994E
Locates the noise
Repairs the cause of noise
Commercial Service Tools INFOID:0000000006472380
Tool name Description
Engine ear Locates the noise
SIIA0995E
Holds the windshield glass, side window
Suction lifter
PIIB1805J
Remover tools Removes the clips, pawls and metal clips
JMKIA3050ZZ
glass, back door window glass and door glass
GW-10
Page 18
< REMOVAL AND INSTALLATION >
Revision: 2011 December 2011 G Convertible
WINDSHIELD GLASS
REMOVAL AND INSTALLATION
WINDSHIELD GLASS
Exploded View INFOID:0000000006472381
A
B
C
D
E
F
G
H
1. Windshield molding 2. Spacer 3. Windshield glass
4. Dam rubber (upper, lower) 5. Mirror base 6. Rain sensor bracket
7. Insulator 8. Roof panel 9. Primer
10. Front pillar finisher 11. Dash upper cross member 12. Cowl top cover
13. Adhesive 14. Front pillar outer upper 15. Front pillar garnish
16. Roof front finisher Unit: mm (in) Refer to GI-4, "
Components" for symbols in the figure.
I
J
GW
L
M
N
JMKIA3931GB
O
P
GW-11
Page 19
< REMOVAL AND INSTALLATION >
Revision: 2011 December 2011 G Convertible
WINDSHIELD GLASS
Removal and Installation
INFOID:0000000006472382
REMOVAL
1. Remove the front pillar garnish (LH/RH). Refer to INT-15, "Removal and Installation".
2. Disconnect the inside mirror harness connector.
3. Remove the rain sensor bracket. Refer to WW-108, "
4. Remove body side weather-strip and front pillar finisher. Refer to EXT-33, "
5. Remove the front roof finisher.Refer to the INT-21, "
6. Remove the front wiper arm. Refer to WW-102, "
7. Remove the cowl top cover. Refer to EXT-23, "
8. Apply protective tape around the windshield glass to protect the painted surface from damage.
9. Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing moldings.
NOTE:
Mark the body and the glass with matching marks if the windshield glass is reused.
WARNING:
Always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands when cutting the glass from the vehicle.
CAUTION:
• Never use a cutting knife or power cutting tool when the windshield glass is reused.
• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.
Removal and Installation".
Removal and Installation".
Removal and Installation".
Removal and Installation".
Removal and Installation".
PIIB5779E
INSTALLATION
• The dam rubber should be installed in position.
• Use a Genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.
• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by
passenger room air pressure when all door windows are closed.
• The molding must be installed securely so that it is in position and leaves no clearance.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive is completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
WARNING:
• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them come in contact with the skin and eyes.
• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
• Driving the vehicle before the urethane adhesive is completely cured may affect the performance of
the windshield glass in case of an accident.
CAUTION:
• Perform adjustment of front wiper arms stop location. Refer to WW-102, "
• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months
after the date of manufacture. Adhere carefully to the expiration or manufacture date printed on the box.
• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
Adjustment".
GW-12
Page 20
WINDSHIELD GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely cured. Curing time varies depending on temperature and humidity. The curing time increases under lower temperature and lower humidity.
A
Inspection INFOID:0000000006472383
REPAIRING WATER LEAKAGE FOR WINDSHIELD GLASS
Leakage can be repaired without removing glass. Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass. This can be done by applying water to the windshield glass area while pushing glass outward. Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.
B
C
D
E
F
G
H
I
J
GW
L
M
N
O
P
GW-13
Page 21
REAR WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
REAR WINDOW GLASS
Exploded View INFOID:0000000006472384
JMKIA4029GB
1. Rear window glass 2. Spacer 3. Adhesive
4. Primer 5. Rear roof outer 6. Rear roof inner
7. Rear roof upper garnish 8. Rear roof lower garnish Unit: mm (in) Refer to GI-4, "
Components" for symbols in the figure.
Removal and Installation INFOID:0000000006472385
REMOVAL
1. Remove the headlining. Refer to INT-21, "Removal and Installation".
2. Remove the connectors and grounds for the rear window defogger.
GW-14
Page 22
REAR WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
3. Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing
molding using pliers.
A
B
C
PIIB5779E
NOTE:
Mark the body and the glass with matching marks if a rear window glass is reused.
WARNING:
Always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands when cutting the glass from the vehicle.
CAUTION:
• Never use a cutting knife or power cutting tool when the rear window glass is reused.
• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.
INSTALLATION
• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by passenger compartment air pressure when all door windows are closed.
• The molding must be installed securely so that it is in position and leaves no clearance.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive is completely cured (approximately 24 hours). Curing time varies with temperature and humidity.
WARNING:
• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never
let them come in contact with the skin and eyes.
• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
• Driving the vehicle before the urethane adhesive is completely cured may affect the performance
of the rear window in case of an accident.
CAUTION:
• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six
months after the date of manufacture. Adhere carefully to the expiration or manufacture date printed on the box.
• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely
cured. Curing time varies depending on temperature and humidity. The curing time increases under lower temperature and lower humidity .
D
E
F
G
H
I
J
GW
L
M
N
Inspection INFOID:0000000006472386
REPAIRING WATER LEAKAGE FOR REAR WINDOW GLASS
Leakage can be repaired without removing the glass. Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass. This can be done by applying water to the rear window glass area while pushing glass outward. Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.
GW-15
O
P
Page 23
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
QUARTER WINDOW GLASS
Exploded View INFOID:0000000006472387
JMKIA3932ZZ
1. Power window motor 2. Quarter window glass regulator as­sembly
4. Quarter window glass sash 5. Quarter window glass molding 6. Quarter window glass
3. Quarter window glass weather-strip
Removal and Installation INFOID:0000000006472388
REMOVAL
1. Fully open the roof.
2. Fully open trunk lid assembly.
3. Fully open quarter window glass.
4. Remove rear seat cushion and rear seatback. Refer to SE-256, "
5. Remove body side weather-strip. Refer to INT-15, "
6. Remove rear side finisher. Refer to INT-15, "
7. Remove rear side finisher bracket. Refer toINT-15, "
8. Remove partially trunk lid weather-strip. Refer to DLK-281, "
Installation".
Removal and Installation".
Removal and Installation".
Removal and Installation".
Removal and Installation".
TRUNK LID WEA THERSTRIP : Removal and
GW-16
Page 24
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
9. Operate rear quarter window glass motor switch to raise or lower the quarter window glass until the glass mounting bolts can be seen.
A
: Bolt
10. Remove quarter window glass mounting bolts.
NOTE:
Hold securely quarter window glass when removing the quarter window glass mounting bolts.
11. Remove the rear reinforcement bracket (1).
• Remove quarter window glass regulator mounting nuts (A).
• Remove rear reinforcement bracket mounting bolts (B).
12. Remove quarter window glass from the regulator assembly.
13. Remove the quarter window glass regulator assembly.
1. Disconnect harness connector (A).
2. Remove sealing screen (1) with a cutter knife.
NOTE:
Cut the butyl-tape so that some parts of the butyl-tape do not remain on the sealing screen, if the sealing screen is reused.
3. Remove regulator assembly fixing nut cover (2).
CAUTION:
Never drop water the water coming from drain hose on parts when removing drain hose from sealing screen.
B
C
JMKIA4115ZZ
D
E
F
G
JMKIA3933ZZ
H
I
J
GW
JMKIA3934ZZ
4. Remove quarter window glass regulator assembly fixing nut
as shown in the figure with socket wrench (A).
: Nut
5. Remove the quarter window glass regulator assembly from the body panel.
INSTALLATION
Install in the reverse order of removal.
INSPECTION AFTER REMOVAL
GW-17
JMKIA3935ZZ
L
M
N
O
P
Page 25
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Check that the quarter window glass regulator assembly for the fol­lowing. If a failure is detected, replace or grease it.
• Wire wear
• Quarter window glass regulator assembly deformation
• Grease body condition on each sliding part The arrows in the figure show body grease application points of the body grease.
JMKIA4116ZZ
Disassembly and Assembly INFOID:0000000006472389
DISASSEMBLY
1. Remove the power window motor from quarter window glass regulator assembly.
ASSEMBLY
Assemble in the reverse order of disassembly.
Glass mounting nut Tightening torque : 6.5 N·m (0.66 kg-m, 58 in-lb)
Inspection and Adjustment INFOID:0000000006472390
FITTING INSPECTION
Inclination Adjustment
1. Losses the nut (A) of regulator adjusting bolts.
2. Rotate the regulator adjusting bolts, and then perform the fitting adjusting between the upper end and weather-strip.
JMKIA4117ZZ
GW-18
Page 26
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and corner piece assembly
A
B
C
D
E
F
G
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Remove the door glass. Refer to GW-22, "Removal and Installation".
2. Apply protective tape (B) on door glass at a distance of 24 mm (0.945 in), starting from the door front edge as shown in the figure above.
3. Reinstall the door glass while fitting the corner piece assembly to that distance as shown by the figure above.
H
I
J
GW
L
M
N
O
P
GW-19
Page 27
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass, quarter window glass and weat her-strip
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Half open the glass. (Door glass and quarter window glass)
2. Apply a tape with graduation (D) of 20 mm (0.787 in) on glass (door glass and quarter window glass) start­ing from top edge.
3. Fully close the glass (Door glass and quarter window glass).
4. Check on the graduation mark. It should be 5 mm (0.197 in).
5. If the graduation marks shows more then 5 mm (0.197 in), restart the procedure again.
GW-20
Page 28
QUARTER WINDOW GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and quarter window glass
1. Door glass assembly 2. Quarter window glass sash 3. Quarter wi ndow glass Unit: mm (in)
A
B
C
JMKIA4352GB
D
1. Fully close door glass and quarter window glass.
2. Check that both upper edges of door glass and quarter window glass are the same level.
3. Check that the distance between door glass and quarter window glass sash is 8 mm (0.315 in).
E
F
G
H
I
J
GW
L
GW-21
M
N
O
P
Page 29
DOOR GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
DOOR GLASS
Exploded View INFOID:0000000006472391
JMKIA4347ZZ
1. Door glass assembly 2. Power window motor 3. Module assembly
4. Corner piece assembly
Removal and Installation INFOID:0000000006472392
REMOVAL
1. Remove the door finisher. Refer to INT-12, "Removal and Installation".
2. Operate the power window main switch to raise or lower the door window until the glass mounting bolts can be seen.
3. Remove the glass mounting bolts (A) and loosen slightly the bolt (B).
JMKIA3045ZZ
GW-22
Page 30
DOOR GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
4. Remove the door glass.
• Hold securely the door glass
• Rotate slightly the door glass toward the direction of arrow 1.
• Pull up the door glass as shown by the arrows 2.
JMKIA4348ZZ
5. Remove the corner piece assembly mounting bolts and nut, and then remove the corner piece assembly.
INSTALLATION
Install in the reverse order of removal.
Inspection and Adjustment INFOID:0000000006472393
A
B
C
D
E
SYSTEM INITIALIZATION
Initialize the system if any of the following work is complete. Refer to PWC-5, " ADDITIONAL SERVICE WHEN
REMOVING BATTERY NEGATIVE TERMINAL : Special Repair Requirement".
• Electric power supply to power window switch or motor is interrupted by blown fuse or disconnecting battery cable, etc.
• Removal and installation of the regulator assembly.
• Removal and installation of the motor from the regulator assembly.
• Removal and installation of the harness connector of the power window switch.
• Operation of the regulator assembly as a unit.
• Removal and installation of the door glass.
• Removal and installation of the body side weather-strip and door weather-strip.
• Disconnection and connection of the minus terminal of battery.
CAUTION:
The following specified operations are not performed under the non-initialized condition.
• Auto-up operation
• Anti-pinch function
• Automatic window adjustment function
• Retained power operation
FITTING INSPECTION
F
G
H
I
J
GW
L
M
GW-23
N
O
P
Page 31
DOOR GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and corner piece assembly
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Remove the door glass. Refer to GW-22, "Removal and Installation".
2. Apply protective tape (B) on door glass at a distance of 24 mm (0.945 in), starting from front edge as shown in the figure above.
3. Reinstall the door glass while fitting the corner piece assembly to that protective tape as shown by the fig­ure above.
CAUTION:
• When performing this operation, DTC of air bag (B1262 / B1257) may be displayed.
• When completing this operation, check that no DTC other than DTC of air bag (B1262 / B1257) is dis-
displayed and erase self-diagnosis result of air bag, using CONSULT-III.
• When DTC other than the above is detected, perform diagnosis according to each DTC.
• When DTC other than DTC of air bag (B1262 / B1257) is detected, perform diagnosis according to
each DTC. Refer to SRC-195, "
DTC Index".
GW-24
Page 32
DOOR GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass, quarter windo w gla ss an d we at he r- str ip
A
B
C
D
E
F
G
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Half open the glass. (Door glass and quarter window glass)
2. Apply a tape with graduation (D) of 20 mm (0.787 in) on glass (door glass and quarter window glass) start­ing from top edge.
3. Fully close the glass (Door glass and quarter window glass).
4. Check on the graduation mark.It should be 5 mm (0.197 in).
5. If the graduation mark shows more then 5 mm (0.197 in), restart the procedure again.
H
I
J
GW
L
M
N
O
P
GW-25
Page 33
DOOR GLASS
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and quarter window glass
JMKIA4352GB
1. Door glass assembly 2. Quarter window glass sash 3. Quarter window glass Unit: mm (in)
1. Fully close door glass and quarter window glass.
2. Check that both upper edges of door glass and quarter window glass are the same level.
3. Check that the distance between door glass and quarter window glass sash is 8 mm (0.315 in).
GW-26
Page 34
< REMOVAL AND INSTALLATION >
Revision: 2011 December 2011 G Convertible
DOOR REGULATOR
DOOR REGULATOR
Exploded View INFOID:0000000006472394
A
B
C
D
E
F
G
H
JMKIA4347ZZ
1. Door glass assembly 2. Power window motor 3. Module assembly
4. Corner piece assembly
Removal and Installation INFOID:0000000006472395
REMOVAL
1. Remove the door glass. Refer to GW-22, "Removal and Installation".
2. Reach the key located behind the harness connector (1), pull it down to unlock and then disconnect the power window motor (2) harness connector as shown in the figure.
JMKIA3383ZZ
I
J
GW
L
M
N
O
P
GW-27
Page 35
DOOR REGULATOR
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
3. Remove the module assembly mounting bolts shown by the arrows and then remove both nuts (A) located under the seals.
JMKIA4349ZZ
4. Remove the module assembly from the door panel.
INSTALLATION
Install in the reverse order of removal.
Disassembly and Assembly INFOID:0000000006472396
DISASSEMBLY
Remove the power window motor from the module assembly.
ASSEMBLY
Assemble in the reverse order of disassembly.
Inspection After Removal INFOID:0000000006472397
Check the regulator assembly for the following items. Replace or grease it if a malfunction is detected.
• Wire wear
• Regulator deformation
JMKIA4350ZZ
Inspection and Adjustment INFOID:0000000006472398
SYSTEM INITIALIZATION
Initialize the system if any of the following work is complete. Refer to PWC-5, "ADDITIONAL SERVICE WHEN
REMOVING BATTERY NEGATIVE TERMINAL : Description".
Initialization
Follow the steps below after installing each component to the vehicle. Refer to PWC-5, "ADDITIONAL SER-
VICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Repair Requirement".
FITTING INSPECTION
GW-28
Page 36
DOOR REGULATOR
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and corner piece assembly
A
B
C
D
E
F
G
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Remove the door glass. Refer to GW-22, "Removal and Installation".
2. Apply protective tape (B) on door glass at a distance of 24 mm (0.945 in), starting from front edge as shown in the figure above.
3. Reinstall the door glass while fitting the corner piece assembly to that protective tape as shown by the fig­ure above.
CAUTION:
• When performing this operation, DTC of air bag (B1262 / B1257) may be displayed.
• When completing this operation, check that no DTC other than DTC of air bag (B1262 / B1257) is dis-
displayed and erase self-diagnosis result of air bag, using CONSULT-III.
• When DTC other than the above is detected, perform diagnosis according to each DTC.
• When DTC other than DTC of air bag (B1262 / B1257) is detected, perform diagnosis according to
each DTC. Refer to SRC-195, "
DTC Index".
H
I
J
GW
L
M
N
O
P
GW-29
Page 37
DOOR REGULATOR
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass, quarter window glass and weat her-strip
JMKIA4351GB
1. Corner piece assembly 2. Door glass assembly 3. Weather-strip
4. Roof panel assembly B. Protective tape D. Tape with a graduation mark Unit: mm (in)
1. Half open the glass. (Door glass and quarter window glass)
2. Apply a tape with graduation (D) of 20 mm (0.787 in) on glass (door glass and quarter window glass) start­ing from top edge.
3. Fully close the glass (Door glass and quarter window glass).
4. Check on the graduation mark.It should be 5 mm (0.197 in).
5. If the graduation mark shows more then 5 mm (0.197 in), restart the procedure again.
GW-30
Page 38
DOOR REGULATOR
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
Fitting between door glass and quarter window glass
1. Door glass assembly 2. Quarter window glass sash 3. Quarter window glass Unit: mm (in)
A
B
C
JMKIA4352GB
D
1. Fully close door glass and quarter window glass.
2. Check that both upper edges of door glass and quarter window glass are the same level.
3. Check that the distance between door glass and quarter window glass sash is 8 mm (0.315 in).
E
F
G
H
I
J
GW
L
GW-31
M
N
O
P
Page 39
ENGINE
Revision: 2011 December 2011 G Convertible
A
ACC
SECTION ACC
ACCELERATOR CONTROL SYSTEM
CONTENTS
PRECAUTION ...............................................2
PRECAUTIONS ...................................................2
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
Service Procedure Precautions for Models with a
Pop-up Roll Bar .........................................................
REMOVAL AND INSTALLATION ................3
ACCELERATOR CONTROL SYSTEM .............. 3
Exploded View .......................................................... 3
Removal and Installation .......................................... 3
2
2
Inspection ................................................................. 3
C
D
E
F
G
H
I
J
K
M
N
O
P
L
ACC-1
Page 40
PRECAUTIONS
Revision: 2011 December 2011 G Convertible
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this Service Manual.
WARNING:
Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see “SRS AIR BAG”.
• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.
INFOID:0000000006473050
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
Always observe the following items for preventing accidental activation.
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury.
• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Service Procedure Precautions for Models with a Pop-up Roll Bar INFOID:0000000006473051
WARNING:
Always observe the following items for preventing accidental activation.
• Risk of passenger injury or death may increase if the pop-up roll bar does not deploy during a roll
over collision. In order to reduce the chance of an incident where the pop-up roll bar is inoperative, all maintenance must be performed by a NISSAN or INFINITI dealer.
• Before removing and installing the pop-up roll bar component parts and harness, always turn the
ignition switch OFF, disconnect the battery negative terminal, and wait for 3 minutes or more. (The purpose of this operation is to discharge electricity that is accumulated in the auxiliary power supply circuit in the air bag diagnosis sensor unit.)
• When repairing, removing, and installing a pop-up roll bar, always refer to SRS AIR BAG and SRS
AIR BAG CONTROL warnings in the Service Manual.
ACC-2
Page 41
ACCELERATOR CONTROL SYSTEM
Revision: 2011 December 2011 G Convertible
< REMOVAL AND INSTALLATION >
REMOVAL AND INSTALLATION
ACCELERATOR CONTROL SYSTEM
Exploded View INFOID:0000000006473052
JPBIA0253GB
1. Accelerator pedal assembly 2. Bolt cap : Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
A
ACC
C
D
E
F
G
H
I
Removal and Installation INFOID:0000000006473053
REMOVAL
1. Remove the cap and the inside mounting bolt.
2. Remove accelerator pedal assembly.
3. Disconnect accelerator pedal position sensor harness connector.
CAUTION:
• Never disassemble accelerator lever. Never remove accelerator pedal position sensor from accelerator lever.
• Avoid impact from dropping etc. during handling.
• Be careful to keep accelerator lever away from water.
INSTALLATION
Install in the reverse order of removal.
Inspection INFOID:0000000006473054
INSPECTION AFTER INSTALLATION
• Check accelerator pedal moves smoothly within the whole operation range when it is fully depressed and released.
• Check accelerator pedal securely returns to the fully released position.
• For the electrical inspection of accelerator pedal position sensor, refer to EC-485, "
- CAUTION: When harness connector of accelerator pedal position sensor is disconnected, perform “Accelerator Pedal Released Position Learning”. Refer to EC-19, "
LEARNING : Description".
ACCELERATOR PEDAL RELEASED POSITION
Component Inspection".
J
K
L
M
N
O
P
ACC-3
Page 42
BODY INTERIOR
Revision: 2011 December 2011 G Convertible
A
B
SECTION ADP
AUTOMATIC DRIVE POSITIONER
CONTENTS
BASIC INSPECTION ....................................6
DIAGNOSIS AND REPAIR WORKFLOW .......... 6
Work Flow .................................................................6
INSPECTION AND ADJUSTMENT .....................9
ADDITIONAL SERVICE WHEN REMOVING BAT-
TERY NEGATIVE TERMINAL .....................................
ADDITIONAL SERVICE WHEN REMOVING
BATTERY NEGATIVE TERMINAL : Description ......
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Re-
pair Requirement .......................................................
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ..........................................................
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Description ..................................
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Special Repair Requirement .......
SYSTEM INITIALIZATION ................ .... ... ... ... .... .......10
SYSTEM INITIALIZATION : Description .................10
SYSTEM INITIALIZATION : Special Repair Re-
quirement ................................................................
MEMORY STORING ..................................................10
MEMORY STORING : Description ..........................10
MEMORY STORING : Special Repair Require-
ment ........................................................................
SYSTEM SETTING ................... ... ... ... .... ... ... ... .... .......11
SYSTEM SETTING : Description ............................11
SYSTEM SETTING : Special Repair Requirement
SYSTEM DESCRIPTION .............................13
AUTOMATIC DRIVE POSITIONER SYSTEM ....13
AUTOMATIC DRIVE POSITIONER SYSTEM ...........13
....
10
10
11
AUTOMATIC DRIVE POSITIONER SYSTEM :
System Diagram ......................................................
AUTOMATIC DRIVE POSITIONER SYSTEM :
System Description ..................................................
AUTOMATIC DRIVE POSITIONER SYSTEM :
Component Parts Location ......................................
AUTOMATIC DRIVE POSITIONER SYSTEM :
9
9
9
9
9
9
Component Description ..........................................
MANUAL FUNCTION ................................................19
MANUAL FUNCTION : System Diagram ................19
MANUAL FUNCTION : System Description ............19
MANUAL FUNCTION : Component Parts Loca-
tion ................................ ................................... ........
MANUAL FUNCTION : Component Description .....23
SEAT SYNCHRONIZATION FUNCTION ..................24
SEAT SYNCHRONIZATION FUNCTION : Sys-
tem Diagram ............................................................
SEAT SYNCHRONIZATION FUNCTION : Sys-
tem Description ........................................................
SEAT SYNCHRONIZATION FUNCTION : Com-
ponent Parts Location ..............................................
SEAT SYNCHRONIZATION FUNCTION :
Component Description ..........................................
MEMORY FUNCTION .............. .... ... ...........................29
MEMORY FUNCTION : System Diagram ...............29
MEMORY FUNCTION : System Description ...........29
MEMORY FUNCTION : Component Parts Loca-
tion ................................ ................................... ........
MEMORY FUNCTION : Component Description ....33
INTELLIGENT KEY INTERLOCK FUNCTION ..........34
INTELLIGENT KEY INTERLOCK FUNCTION :
System Diagram ......................................................
INTELLIGENT KEY INTERLOCK FUNCTION :
System Description ..................................................
INTELLIGENT KEY INTERLOCK FUNCTION :
Component Parts Location ......................................
INTELLIGENT KEY INTERLOCK FUNCTION :
Component Description ..........................................
13
14
15
17
21
24
24
26
28
31
34
34
36
38
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-1
Page 43
POWER WALK-IN FUNCTION ................................. 38
Revision: 2011 December 2011 G Convertible
POWER WALK-IN FUNCTION : System Diagram ... 39 POWER WALK-IN FUNCTION : System Descrip-
tion ................................... .......................................
POWER WALK-IN FUNCTION : Component
Parts Location .........................................................
POWER WALK-IN FUNCTION :
Component Description .........................................
39
41
43
DIAGNOSIS SYSTEM (DRIVER SEAT C/U) ..... 45
Diagnosis Description ............................................. 45
CONSULT-III Function ........................................... 45
DRIVER SEAT CONTROL UNIT ............................... 64
DRIVER SEAT CONTROL UNIT :
Diagnosis Procedure .......................... ....................
DRIVER SEAT CONTROL UNIT : Special Repair
Requirement ...........................................................
AUTOMATIC DRIVE POSITIONER CONTROL
UNIT ................................. ......................... .................
AUTOMATIC DRIVE POSITIONER CONTROL
UNIT : Diagnosis Procedure ..................................
AUTOMATIC DRIVE POSITIONER CONTROL
UNIT : Special Repair Requirement ........................
64
65
65
65
66
DTC/CIRCUIT DIAGNOSIS .........................48
U1000 CAN COMM CIRCUIT ............................48
Description ....................... .......................... ............. 48
DTC Logic ............................................................... 48
Diagnosis Procedure ............................................. 48
Special Repair Requirement ................................... 48
B2112 SLIDING MOTOR ...................................49
Description ....................... .......................... ............. 49
DTC Logic ............................................................... 49
Diagnosis Procedure ............................................. 49
B2113 RECLINING MOTOR .............................. 51
Description ....................... .......................... ............. 51
DTC Logic ............................................................... 51
Diagnosis Procedure ............................................. 51
B2118 TILT SENSOR ........................................53
Description ....................... .......................... ............. 53
DTC Logic ............................................................... 53
Diagnosis Procedure ............................................. 53
B2119 TELESCOPIC SENSOR ......................... 56
Description ....................... .......................... ............. 56
DTC Logic ............................................................... 56
Diagnosis Procedure ............................................. 56
B2126 DETENT SW ...........................................59
Description ....................... .......................... ............. 59
DTC Logic ............................................................... 59
Diagnosis Procedure ............................................. 59
B2127 PARKING BRAKE SWITCH .................. 61
Description ....................... .......................... ............. 61
DTC Logic ............................................................... 61
Diagnosis Procedure ............................................. 61
Component Inspection ............................................ 62
B2128 UART COMMUNICATION LINE ............63
Description ....................... .......................... ............. 63
DTC Logic ............................................................... 63
Diagnosis Procedure ............................................. 63
POWER SUPPLY AND GROUND CIRCUIT ..... 64
BCM .............................. ...... ....... ...... ....... ...... ....... ...... 64
BCM : Diagnosis Procedure ................................... 64
SLIDING SWITCH ............................................. 67
Description ..............................................................67
Component Function Check ........................ ..........67
Diagnosis Procedure .......................... ....................67
Component Inspection ............................................68
RECLINING SWITCH ........................................ 69
Description ..............................................................69
Component Function Check ........................ ..........69
Diagnosis Procedure .......................... ....................69
Component Inspection ............................................70
LIFTING SWITCH (FRONT) .............................. 71
Description ..............................................................71
Component Function Check ........................ ..........71
Diagnosis Procedure .......................... ....................71
Component Inspection ............................................72
LIFTING SWITCH (REAR) ................................ 73
Description ..............................................................73
Component Function Check ........................ ..........73
Diagnosis Procedure .......................... ....................73
Component Inspection ............................................74
FORWARD SWITCH ......................................... 75
Description ..............................................................75
Component Function Check ........................ ..........75
Diagnosis Procedure .......................... ....................75
Component Inspection ............................................76
SEAT BELT BUCKLE SWITCH ........................ 77
Description ..............................................................77
Component Function Check ........................ ..........77
Diagnosis Procedure .......................... ....................77
Component Inspection ............................................78
SLIDING LIMIT SWITCH ................................... 79
Description ..............................................................79
Component Function Check ........................ ..........79
Diagnosis Procedure .......................... ....................79
Component Inspection ............................................80
POWER WALK-IN SWITCH .............................. 81
Description ..............................................................81
Component Function Check ........................ ..........81
Diagnosis Procedure .......................... ....................81
Component Inspection ............................................82
ADP-2
Page 44
TILT SWITCH .....................................................83
Revision: 2011 December 2011 G Convertible
Description ..............................................................83
Component Function Check ..................................83
Diagnosis Procedure ..............................................83
Component Inspection ............................................84
TELESCOPIC SWITCH ......................................85
Description ..............................................................85
Component Function Check ..................................85
Diagnosis Procedure ..............................................85
Component Inspection ............................................86
SEAT MEMORY SWITCH ..................................87
Description ..............................................................87
Component Function Check ..................................87
Diagnosis Procedure ..............................................87
Component Inspection ............................................88
DOOR MIRROR REMOTE CONTROL
SWITCH ..............................................................
MIRROR SWITCH .....................................................90
MIRROR SWITCH : Description .............................90
MIRROR SWITCH : Component Function Check ....90
MIRROR SWITCH : Diagnosis Procedure ..............90
MIRROR SWITCH : Component Inspection ...........91
CHANGEOVER SWITCH ..........................................92
CHANGEOVER SWITCH : Description ..................92
CHANGEOVER SWITCH : Component Function
Check ......................................................................
CHANGEOVER SWITCH : Diagnosis Procedure ....92
CHANGEOVER SWITCH : Component Inspec-
tion ..........................................................................
90
92
93
POWER SEAT SWITCH GROUND CIRCUIT ....95
Diagnosis Procedure ..............................................95
TILT &TELESCOPIC SWITCH GROUND CIR-
CUIT ....................................................................
Diagnosis Procedure ..............................................96
96
SLIDING SENSOR .............................................97
Description ..............................................................97
Component Function Check ..................................97
Diagnosis Procedure ..............................................97
RECLINING SENSOR ......................................100
Description ............................................................100
Component Function Check ................................100
Diagnosis Procedure ............................................100
LIFTING SENSOR (FRONT) ............................103
Description ............................................................103
Component Function Check ................................103
Diagnosis Procedure ............................................103
LIFTING SENSOR (REAR) ..............................106
Description ............................................................106
Component Function Check ................................106
Diagnosis Procedure ............................................106
TILT SENSOR .................................................109
Description ....................... ...... ....... ...... ....... ...... ......109
Component Function Check ................................109
Diagnosis Procedure ............................................109
TELESCOPIC SENSOR ..................................112
Description ....................... ...... ....... ...... ....... ...... ......112
Component Function Check ................................112
Diagnosis Procedure ............................................112
MIRROR SENSOR ..........................................115
DRIVER SIDE ...........................................................115
DRIVER SIDE : Description ...................................115
DRIVER SIDE : Component Function Check ......115
DRIVER SIDE : Diagnosis Procedure ..................115
PASSENGER SIDE ..................................................117
PASSENGER SIDE : Description ..........................117
PASSENGER SIDE :
Component Function Check ................................
PASSENGER SIDE : Diagnosis Procedure ..........117
117
SLIDING MOTOR ............................................120
Description ....................... ...... ....... ...... ....... ...... ......120
Component Function Check ................................120
Diagnosis Procedure ............................................120
RECLINING MOTOR .......................................122
Description ....................... ...... ....... ...... ....... ...... ......122
Component Function Check ................................122
Diagnosis Procedure ............................................122
LIFTING MOTOR (FRONT) .............................124
Description ....................... ...... ....... ...... ....... ...... ......124
Component Function Check ................................124
Diagnosis Procedure ............................................124
LIFTING MOTOR (REAR) ...............................126
Description ....................... ...... ....... ...... ....... ...... ......126
Component Function Check ................................126
Diagnosis Procedure ............................................126
TILT MOTOR ...................................................128
Description ....................... ...... ....... ...... ....... ...... ......128
Component Function Check ................................128
Diagnosis Procedure ............................................128
TELESCOPIC MOTOR ...................................130
Description ....................... ...... ....... ...... ....... ...... ......130
Component Function Check ................................130
Diagnosis Procedure ............................................130
DOOR MIRROR MOTOR ................................132
Description ....................... ...... ....... ...... ....... ...... ......132
Component Function Check ..................................132
Diagnosis Procedure .............................................132
SEAT MEMORY INDICATOR .........................134
Description ....................... ...... ....... ...... ....... ...... ......134
Component Function Check ................................134
Diagnosis Procedure ............................................134
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-3
Page 45
DOOR MIRROR SYSTEM ............................... 136
Revision: 2011 December 2011 G Convertible
Wiring Diagram - DOOR MIRROR (WITH AUTO-
MATIC DRIVE POSITIONER) - .............................
136
STEERING TILT ...................................................... 221
STEERING TILT : Description .............................. 221
STEERING TILT : Diagnosis Procedure ............... 221
ECU DIAGNOSIS INFORMATION .............145
DRIVER SEAT CONTROL UNIT (WITH AU-
TOMATIC DRIVE POSITIONER) .....................
Reference Value ..... ... ... ... ......................................145
Wiring Diagram - AUTOMATIC DRIVE POSI-
TIONER CONTROL SYSTEM - .............................
Fail Safe ....................................... .........................164
DTC Index ................................. ............................165
145
151
AUTOMATIC DRIVE POSITIONER CON-
TROL UNIT ......................................................
Reference Value ..... ... ... ... ......................................166
Wiring Diagram - AUTOMATIC DRIVE POSI-
TIONER CONTROL SYSTEM - .............................
166
170
BCM (BODY CONTROL MODULE) ................ 184
Reference Value ..... ... ... ... ......................................184
Wiring Diagram - BCM - ........................................207
Fail-safe ........................... ...................................... 212
DTC Inspection Priority Chart .............................214
DTC Index ................................. ............................215
SYMPTOM DIAGNOSIS ............................218
MANUAL FUNCTION DOES NOT OPERATE . 218
ALL COMPONENT ..................................................218
ALL COMPONENT : Description ...........................218
ALL COMPONENT : Diagnosis Procedure ............218
POWER SEAT .................................... .... ... ... ... .... .....218
POWER SEAT : Description ..................................218
POWER SEAT : Diagnosis Procedure ..................218
STEERING POSITION FUNCTION DOES NOT
OPERATE ................................................................
STEERING POSITION FUNCTION DOES NOT
OPERATE : Description ........................................
STEERING POSITION FUNCTION DOES NOT
OPERATE : Diagnosis Procedure .........................
SEAT SLIDING ...................... .... ... ............................219
SEAT SLIDING : Description .................................219
SEAT SLIDING : Diagnosis Procedure .................219
SEAT RECLINING ...................................................219
SEAT RECLINING : Description ............................219
SEAT RECLINING : Diagnosis Procedure ............220
SEAT LIFTING (FRONT) .........................................220
SEAT LIFTING (FRONT) : Description ..................220
SEAT LIFTING (FRONT) : Diagnosis Procedure ..220
SEAT LIFTING (REAR) ............. ... ............................221
SEAT LIFTING (REAR) : Description ....................221
SEAT LIFTING (REAR) : Diagnosis Procedure .....221
218
218
219
STEERING TELESCOPIC ....................................... 222
STEERING TELESCOPIC : Description ............... 222
STEERING TELESCOPIC : Diagnosis Procedure . 222
DOOR MIRROR ....................................................... 222
DOOR MIRROR : Description ............................... 223
DOOR MIRROR : Diagnosis Procedure ............... 223
MEMORY FUNCTION DOES NOT OPERA TE ..224
ALL COMPONENT ................................... ............... 224
ALL COMPONENT : Description ..........................224
ALL COMPONENT : Diagnosis Procedure ........... 224
SEAT SLIDING ........................................................ 224
SEAT SLIDING : Description ................................ 224
SEAT SLIDING : Diagnosis Procedure ................. 224
SEAT RECLINING ................................................... 225
SEAT RECLINING : Description ........................... 225
SEAT RECLINING : Diagnosis Procedure ............ 225
SEAT LIFTING (FRONT) ......................................... 225
SEAT LIFTING (FRONT) : Description ................. 225
SEAT LIFTING (FRONT) : Diagnosis Procedure .. 225
SEAT LIFTING (REAR) ........................................... 225
SEAT LIFTING (REAR) : Description ................... 226
SEAT LIFTING (REAR) : Diagnosis Procedure .... 226
STEERING TELESCOPIC ....................................... 226
STEERING TELESCOPIC : Description ............... 226
STEERING TELESCOPIC : Diagnosis Procedure . 226
STEERING TILT ...................................................... 226
STEERING TILT : Description .............................. 226
STEERING TILT : Diagnosis Procedure ............... 227
DOOR MIRROR ....................................................... 227
DOOR MIRROR : Description ............................... 227
DOOR MIRROR : Diagnosis Procedure ............... 227
MEMORY INDICATE DOES NOT ILLUMI-
NATE ................................................................
Diagnosis Procedure ..... ... ..................................... 228
228
SEAT SYNCHRONIZATION FUNCTION
DOES NOT OPERATE .....................................
Diagnosis Procedure ..... ... ..................................... 229
229
POWER WALK-IN FUNCTION DOES NOT
OPERATE .........................................................
Diagnosis Procedure ..... ... ..................................... 230
230
INTELLIGENT KEY INTERLOCK FUNCTION
DOES NOT OPERATE .....................................
Diagnosis Procedure ..... ... ..................................... 232
232
NORMAL OPERATING CONDITION ...............233
ADP-4
Page 46
Description ............................................................
Revision: 2011 December 2011 G Convertible
233
PRECAUTION ............................................ 234
PRECAUTIONS ................................................234
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...............................................................
Service Procedure Precautions for Models with a
Pop-up Roll Bar .....................................................
Precaution for Battery Service ........ ......................234
Service ..................................................................234
Work ................................ ...................................... 235
234
234
REMOVAL AND INSTALLATION ............. 236
DRIVER SEAT CONTROL UNIT ......................236
Exploded View ......................................................236
Removal and Installation ........ ... ... .........................236
AUTOMATIC DRIVE POSITIONER CON-
TROL UNIT ......................................................
Exploded View .......................................................237
Removal and Installation .......................................237
237
SEAT MEMORY SWITCH ...............................238
Exploded View .......................................................238
Removal and Installation .......................................238
POWER SEAT SWITCH .................................239
Exploded View .......................................................239
Removal and Installation .......................................239
SIDE SUPPORT SWITCH ...............................240
Exploded View .......................................................240
Removal and Installation .......................................240
TILT&TELESCOPIC SWITCH ........................241
Exploded View .......................................................241
Removal and Installation .......................................241
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
ADP-5
P
Page 47
DIAGNOSIS AND REPAIR WORKFLOW
Revision: 2011 December 2011 G Convertible
< BASIC INSPECTION >
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work Flow INFOID:0000000006471446
OVERALL SEQUENCE
JMJIA2428GB
DETAILED FLOW
ADP-6
Page 48
< BASIC INSPECTION >
Revision: 2011 December 2011 G Convertible
DIAGNOSIS AND REPAIR WORKFLOW
1.GET INFORMATION FOR SYMPTOM
Get the detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred).
>> GO TO 2.
2.CHECK DTC WITH AUTOMATIC DRIVE POSITIONER SYSTEM
Check “Self Diagnostic Result” with CONSULT-III. Refer to ADP-165, " Is any symptom described and any DTC is displayed?
Symptom is described, DTC is displayed.>>GO TO 3. Symptom is not described, DTC is displayed.>>GO TO 6. Symptom is described, DTC is not displayed.>>GO TO 4.
DTC Index"
3.CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer.
>> GO TO 6.
4.CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer.
>> GO TO 5.
5.CHECK NORMAL OPERATING CONDITION
A
B
C
D
E
F
G
H
Check normal operating condition. Refer to ADP-233, " Is the incident normal operation?
YES >> INSPECTION END NO >> GO TO 7.
Description".
6.PERFORM DTC CONFIRMATION PROCEDURE
Perform the confirmation procedure for the detected DTC. Is the DTC displayed?
YES >> GO TO 8. NO >> Check intermittent incident. Refer to GI-43, "
Intermittent Incident".
7.DETECT MALFUNCTIONING SYSTEM BY SYMPTOM DIAGNOSIS
Detect malfunctioning system according to SYMPTOM DIAGNOSIS based on the confirmed symptom in step 4, and determine the trouble diagnosis order based on possible causes and symptom.
>> GO TO 8.
8.PERFORM COMPONENT FUNCTION CHECK
Perform the component function check for the isolated malfunctioning point.
>> GO TO 9.
9.DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE
Isolate the malfunctioning point by performing the diagnosis procedure relevant to the symptom during the component diagnosis.
I
ADP
K
L
M
N
O
P
>> GO TO 10.
10.REPARE OR REPLACE
Repair or replace the malfunctioning part.
ADP-7
Page 49
DIAGNOSIS AND REPAIR WORKFLOW
Revision: 2011 December 2011 G Convertible
< BASIC INSPECTION >
>> GO TO 11.
11.FINAL CHECK
Perform the DTC confirmation procedure (if DTC is detected) or component function check (if no DTC is detected) again, and then check that the malfunction can be repaired securely.
Are all malfunctions corrected?
YES >> INSPECTION END Symptom is detected.>> GO TO 5. DTC is detected.>> GO TO 6.
ADP-8
Page 50
< BASIC INSPECTION >
Revision: 2011 December 2011 G Convertible
INSPECTION AND ADJUSTMENT
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : De­scription
Each function is reset to the following condition when the battery terminal is disconnected.
Function Condition Procedure Memory (Seat, steering, mirror) Erased Perform memory storing Intelligent Key interlock Erased Perform memory storing Seat synchronization OFF
NOTE:
When disconnecting the battery terminal or replacing the driver seat control unit, DTC, registered items of memory storing, and details of system setting detected in the past are erased. Perform operation after check­ing the contents.
INFOID:0000000006471447
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGA TIVE TERMINAL : Spe­cial Repair Requirement
INFOID:0000000006471448
1.SYSTEM INITIALIZATION
Perform system initialization. Refer to ADP-10, "
SYSTEM INITIALIZATION : Description".
A
B
C
D
E
F
G
H
>> GO TO 2.
2.SYSTEM SETTING
Perform system setting. Refer to ADP-11, "
>> GO TO 3.
SYSTEM SETTING : Description".
3.MEMORY STORING
Perform memory storing. Refer to ADP-10, "
>> END
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description
Each function is reset to the following condition when the driver seat control unit is replaced.
Function Condition Procedure Memory (Seat, steering, mirror) Erased Perform memory storing Intelligent Key interlock Erased Perform memory storing Seat synchronization OFF
NOTE:
When disconnecting the battery terminal or replacing the driver seat control unit, DTC, registered items of memory storing, and details of system setting detected in the past are erased. Perform operation after check­ing the contents.
MEMORY STORING : Description".
INFOID:0000000006471449
I
ADP
K
L
M
N
O
P
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re­quirement
INFOID:0000000006471450
1.SYSTEM INITIALIZATION
ADP-9
Page 51
INSPECTION AND ADJUSTMENT
Revision: 2011 December 2011 G Convertible
< BASIC INSPECTION >
Perform system initialization. Refer to ADP-10, "SYSTEM INITIALIZATION : Description".
>> GO TO 2.
2.SYSTEM SETTING
Perform system setting. Refer to ADP-11, "
>> GO TO 3.
SYSTEM SETTING : Description".
3.MEMORY STORING
Perform memory storing. Refer to ADP-10, "
>> END
SYSTEM INITIALIZATION
SYSTEM INITIALIZATION : Description INFOID:0000000006471451
When disconnecting battery negative terminal or replacing control unit, always perform the system initializa­tion. Otherwise, the backward operation for power walk-in function does not activate normally.
SYSTEM INITIALIZATION : Special Repair Requirement INFOID:0000000006471452
INITIALIZATION PROCEDURE
MEMORY STORING : Description".
1. STEP-1
Slide the seat to the front edge.
NOTE:
• STEP-1 is the initialization procedure for power walk-in function.
• If the seat sliding position is already at the front edge, slide the seat rearward once, and then slide it to the front edge again.
>> END
MEMORY STORING
MEMORY STORING : Description INFOID:0000000006471453
Always perform the memory storage when the battery terminal is disconnected or the driver seat control unit is replaced. The memory function and Intelligent Key interlock function will not operate normally if no memory storage is performed.
MEMORY STORING : Special Repair Requirement INFOID:0000000006471454
Memory Storage Procedure
Two positions for the driver seat, steering column and outside mirror can be stored for memory operation by following procedure.
1.STEP 1
Shift AT selector lever to P position (AT model) or applied parking brake (MT model).
>> GO TO 2.
2.STEP 2
Turn ignition switch ON.
>> GO TO 3.
3.STEP 3
Adjust driver seat, steering column and outside mirror position manually.
ADP-10
Page 52
< BASIC INSPECTION >
Revision: 2011 December 2011 G Convertible
INSPECTION AND ADJUSTMENT
>> GO TO 4.
4.STEP 4
1. Push set switch.
NOTE:
• Memory indicator for which driver seat position is already retained in memory is illuminated for 5 sec­onds.
• Memory indicator for which driver seat position is not retained in memory is illuminated for 0.5 second.
2. Push the memory switch (1 or 2) for at least 1 second within 5 seconds after pushing the set switch.
NOTE:
If memory is stored in the same memory switch, the previous memory will be deleted.
Do you need linking of Intelligent Key?
YES >> GO TO 6. NO >> GO TO 5.
5.STEP 5
Confirm the operation of each part with memory operation.
>> END
6.STEP 6
Turn ignition switch OFF (LOCK).
>> GO TO 7.
7.STEP 7
A
B
C
D
E
F
G
H
• Press and release set switch. Memory switch indicator is illuminated for 5 seconds. During memory switch indicator is illuminated, press Intelligent Key unlock button while pressing memory switch 1 or 2.
NOTE:
Memory switch indicator lamp blinks for 5 seconds when registration is complete.
>> GO TO 8.
8.STEP 8
Confirm the operation of each part with memory operation and Intelligent Key interlock operation.
>> END
SYSTEM SETTING
SYSTEM SETTING : Description INFOID:0000000006471455
The setting of the automatic driving positioner system can be changed using the set switch.
SYSTEM SETTING : Special Repair Requirement INFOID:0000000006471456
SETTING PROCEDURE
1.STEP-1
Set the vehicle to the following condition.
• Ignition position: ACC
• A/T selector lever: P position (A/T models)
• Parking brake: Applied only (M/T models)
I
ADP
K
L
M
N
O
P
>> GO TO 2.
2.STEP-2
Press set switch and hold for more than 10 seconds, then confirm blinking of the memory switch indicator.
ADP-11
Page 53
INSPECTION AND ADJUSTMENT
Revision: 2011 December 2011 G Convertible
< BASIC INSPECTION >
• Seat synchronization are ON : Memory switch indicator blink two times.
• Seat synchronization are OFF : Memory switch indicator blink once.
NOTE:
• After memory setting registration, by pushing set switch for approximately 10 seconds, memory switch indi­cator lamp turns 4 seconds. turns OFF, blinks 1 or 2 times, and then the switching operation is complete. Push and hold set switch during the switching operation.
>> END.
ADP-12
Page 54
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
SYSTEM DESCRIPTION
AUTOMATIC DRIVE POSITIONER SYSTEM
AUTOMATIC DRIVE POSITIONER SYSTEM
AUTOMATIC DRIVE POSITIONER SYSTEM : System Diagram INFOID:0000000006471457
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
JMJIA3251GB
ADP-13
Page 55
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
AUTOMATIC DRIVE POSITIONER SYSTEM : System Description
INFOID:0000000006471458
OUTLINE
The system automatically moves the driver seat, steering column and door mirror position by the driver seat control unit and the automatic drive positioner control unit. The driver seat control unit corresponds with the automatic drive positioner control unit by UART communication.
Function Description
Manual function
Seat synchronization function
Memory function
Power walk-in function
Intelligent Key interlock function
NOTE:
The lumbar support system and the side support system are controlled independently with no link to the auto­matic drive positioner system.
The driving position (seat, steeri ng column an d door mirror po sition) can be adjusted by using the power seat switch, tilt & telescopic switch or door mirror remote control switch.
The positions of the steering column and door mirror are adjusted to the proper position automat­ically while linking with manual operation [seat sliding, seat lifting (rear) or seat reclining].
The seat, steering column and outside mirror move to the stored driving position by pressing seat memory switch (1 or 2).
The seat is made to advance when the seat back of driver seat is folded down and press the walk­in switch. The seat is made to retreat to former position when the seat back of driv er seat is folded up and press the walk-in switch.
Perform memory operation, exiting operation and entry operation by Intelligent Key unlock opera­tion or driver side door request switch unlock operation.
ADP-14
Page 56
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
AUTOMATIC DRIVE POSITIONER SYSTEM : Component Parts Location INFOID:0000000006471459
A
B
C
D
E
F
G
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Drive r seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote cont rol switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly)
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
H
I
ADP
K
L
M
N
O
P
ADP-15
Page 57
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2416ZZ
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Sliding limit switch 20. Power walk-in switch
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
ADP-16
Page 58
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Back sid e of se at cu sh io n
24. Sliding, lifting switch (Power seat switch)
AUTOMATIC DRIVE POSITIONER SYSTEM : Component Description INFOID:0000000006471460
A
B
C
D
E
F
G
H
CONTROL UNITS
Item Function
Driver seat control unit
Automatic drive positioner control unit
BCM
Unified meter and A/C amp.
TCM
INPUT PARTS
• Main units of automatic drive positioner system.
• It is connected to the CAN.
• It communicates with the automatic drive positioner control unit via UART com­munication.
• It communicates with the driver seat control unit via UART communication.
• Perform various controls with the instructions of driver seat control unit.
• Perform the controls of the tilt & telescopic, door mirror and the seat memory switch.
Transmit the following status to the driver seat control unit via CAN communication.
• Driver door: OPEN/CLOSE
• Ignition switch position: ACC/ON
• Door lock: UNLOCK (with Intelligent Key or driver side d oor requ est switch oper­ation)
• Key ID
• Key switch: Insert/Pull out Intelligent Key
• Starter: CRANKING/OTHER
Transmit the vehicle speed signal to the driver seat control unit via CAN communi­cation.
Transmit the shift position signal (P range) to the driver seat control unit via CAN communication.
I
ADP
K
L
M
N
O
P
Switches
Item Function Key slot The key switch is installed to detect the key inserted/removed status. Driver side door switch Detect front door (driver side) open/close status.
ADP-17
Page 59
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Item Function A/T shift selector (detention switch) Detect the P range position of A/T selector lever. (A/T models) Parking break switch Detect the parking brake status. (M/T models) Set switch The registration and system setting can be performed with its operation. Memory switch 1/2 The registration and operation can be performed with its operation.
The following switch is installed.
• Reclining swi tch
Power seat switch
Power walk-in switch Perform the power walk-in operation by operating the power walk-in switch. Sliding limit switch Seat belt buckle switch Detect the seat belt fastening/releasing condition. Forward switch
Tilt & telescopic switch
Door mirror remote control switch
• Lifting switch (front)
• Lifting switch (rear)
• Sliding switch The specific parts can be operated with the operation of each switch.
Detect the front end position of se at sli di ng du ri ng th e powe r wal k-in fu nc ti on f ron t ­ward operation.
Detect the folded up/folded down condition of seatback that is the operation condi­tion of power walk-in function.
The following switch is installed.
• Tilt switch
• Tel escopic switch The specific parts can be operated with the operation of each switch.
The following switch is installed.
• Mirror switch
• Changeover switch The specific parts can be operated with the operation of each switch.
Sensors
Item Function Door mirror sensor
(driver side/passenger side) Tilt & telescopic sensor Detect the upward/downward and forward/backward position of steering column. Lifting sensor (front) Detect the upward/downward position of seat lifting (front). Lifting sensor (rear) Detect the upward/downward positi on of seat lifting (rear). Reclining sensor Detect the tilt of seatback. Sliding sensor Detect the forward/backward position of seat.
Detect the upward/downward and leftward/rightward position of outside mirror face.
OUTPUT PARTS
Item Function Door mirror motor
(driver side/passenger side) Tilt & telescopic motor Move the steering column upward/downward and frontward/rearward. Lifting motor (front) Move the seat lifting (front) upward /downward. Lifting motor (rear) Move the seat lifting (rear) upward/downward. Reclining motor Tilt and raise up the seatback. Sliding motor Slide the seat forward/backward. Memory indicator Illuminates or blinks according to the registration/operation status.
Move the outside mirror face upward/downward and leftward/rightward.
SLEEP MODE
• The seat control unit adopts the sleep mode to reduce the electric power consumption.
• The sleep mode is activated when all of the following condition are fulfilled.
1. Ignition switch turn OFF (steering LOCK position)
2. No load is applied to the seat control
ADP-18
Page 60
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
3. The seat control unit 45seconds timer in not activated
4. Set switch and memory switch (1 and 2) turn OFF
WAKE-UP MODE
• The sleep mode is cancelled when any status change is detected for the followings.
1. CAN communication
2. Power seat switch
3. Set switch and memory switch (1 and 2)
4. Power walk-in switch
5. Door mirror switch
6. Steering column switch
MANUAL FUNCTION
MANUAL FUNCTION : System Diagram INFOID:0000000006471461
A
B
C
D
E
F
G
JMJIA3252GB
MANUAL FUNCTION : System Description INFOID:0000000006471462
OUTLINE
The driving position (seat, steering column and door mirror position) can be adjusted manually with power seat switch, tilt & telescopic switch and door mirror remote control switch.
OPERATION PROCEDURE
1. Operate power seat switch, tilt & telescopic switch or door mirror remote control switch.
2. The driver seat, steering column or door mirror operates according to the operation of each switch.
H
I
ADP
K
L
M
N
O
DETAIL FLOW
Seat
ADP-19
P
Page 61
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Order Input Output Control unit condition
Power seat switch
1
(sliding, lifting, rec lin­ing)
Motors
2—
(sliding, lifting, reclin­ing)
Tilt & Telescopic
Order Input Output Control unit condition
1 Tilt & telescopic switch
2—
Sensors
3
(Tilt, telescopic)
*: Tilt does not operates upward when tilt sensor value is less than 1.1 V, tilt does not operate downward when the sensor value is more than 3.9 V. Telescopic does not operates backward when telescopic sensor value is less than 0.5 V, telescopic does not operate forward when the sensor value is more than 4.5 V.
Motors (Tilt, telescopic)
The power seat switch signal is inputted to the driver seat control unit when the power seat switch is operated.
The driver seat control unit outputs signals to each motor accord­ing to the power seat switch input signal.
The tilt & telescopic switch signals are inputted to the automatic drive positioner control uni t when the tilt & telescopic switch are operated.
The automatic drive positioner control unit actuates each motor according to the operation of the tilt & telescopic switch.
The automatic drive positioner control unit recognizes any oper­ation limit of each actuator via each sensor and will not operate the actuator anymore at that time.*
Door Mirror
Order Input Output Control unit condition
Door mirror remote
1
control switch
2—
Sensors
3
(Mirror)
Motors (Door mirror motor)
The door mirror remote control switch signal is inputted to the au­tomatic drive positioner control unit when the door mirror remote control switch is operated.
The automatic drive positioner control unit actuates each motor according to the signal from the door m irror remote con trol switch.
The automatic drive positioner control unit monitors the input of mirror sensor. It stops the operation if the input reaches the oper­ation limit.
NOTE:
The door mirrors can be operated manually when ignition switch is in either ACC or ON position. The ignition switch signal (ACC/ON) is transmitted from BCM to the driver seat control unit via CAN communication and from the driver seat control unit to the automatic drive positioner control unit via UART communication.
ADP-20
Page 62
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
MANUAL FUNCTION : Component Parts Location INFOID:0000000006471463
A
B
C
D
E
F
G
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Drive r seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote cont rol switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly)
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
H
I
ADP
K
L
M
N
O
P
ADP-21
Page 63
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2416ZZ
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Sliding limit switch 20. Power walk-in switch
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
ADP-22
Page 64
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Back sid e of se at cu sh io n
24. Sliding, lifting switch (Power seat switch)
MANUAL FUNCTION : Component Description INFOID:0000000006471464
A
B
C
D
E
F
G
H
CONTROL UNITS
Item Function
Driver seat control unit
Automatic drive positioner control unit
BCM
INPUT PARTS
Switches
Item Function
Power seat switch
Tilt & telescopic switch
• Operates the specific seat motor with the signal from the power seat switch.
• Transmits the ignition switch signal (ACC/ON) via UART communication to the automatic drive positioner control unit.
Operates the specific motor with the signal from til t & telescop ic swit ch or door mi r­ror remote control switch.
Recognizes the following status and transmits it to the driver seat control unit via CAN communication.
• Ignition position: ACC/ON
The following switch is installed.
• Reclining switch
• Lifting switch (front)
• Lifting switch (rear)
• Sliding switch The specific parts can be operated with the operation of each switch.
The following switch is installed.
• Tilt switch
• Telescopic switch The specific parts can be operated with the operation of each switch.
I
ADP
K
L
M
N
O
P
ADP-23
Page 65
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Item Function
Forward switch Detect folded down or folded up of the seat back.
The following switch is installed.
Door mirror remote control switch
Sensors
Item Function Tilt & telescopic sensor Detect the upward/downward & forward/backward position of steering c olumn. Door mirror sensor
(driver side / passenger side)
OUTPUT PARTS
Item Function Door mirror motor
(driver side/passenger side) Tilt & telescopic motor Move the steering column upward/downward and forward/backward. Lifting motor (front) Move the seat lifter (front) upward/downward. Lifting motor (rear) Move the seat lifter (rear) upward/downward. Reclining motor Tilt and raise up the seatback. Sliding motor Slide the seat forward/backward.
• Mirror switch
• Changeover switch The specific parts can be operated with the operation of each swi tch.
Detect the upward/downward and lef tward/right ward position o f outside mirror face.
Move the outside mirror face upward /downward and leftward/rightwa rd.
SEAT SYNCHRONIZATION FUNCTION
SEAT SYNCHRONIZATION FUNCTION : System Diagram INFOID:0000000006471465
JMJIA3253GB
SEAT SYNCHRONIZATION FUNCTION : System Description INFOID:0000000006471466
OUTLINE
ADP-24
Page 66
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
The steering column position and door mirror position is adjusted to the position automatically according to the direction and distance of seat movement when performing the manual operation of sliding, reclining or lifting (rear). This function saves adjusting the mirror and steering column when adjusting the seat.
NOTE:
This function is set to OFF before delivery. (initial setting) For the system setting procedure. Refer to ADP-11, "
OPERATION PROCEDURE
1. Turn ignition switch ON.
2. Adjust seat position [sliding, reclining, lifting (rear)].
3. The steering and outside mirror is adjusted automatically.
NOTE:
• The seat synchronization function will not operate if seat adjusting value is more than limit value.
Item Limit value
Seat sliding 76 mm
Seat reclining 9.1 degrees
Seat lifter (rear) 20 mm
• The seat synchronization function will not operate if the steering column or door mirror moves to the operat­ing end while this function is operating. Perform memory function or drive the vehicle at vehicle speed of 7 km/h or more once to activate this function again.
• If the seat position is uncomfortable after the adjustment, seat position can be adjusted easily by memory operation.
SYSTEM SETTING : Description".
A
B
C
D
E
F
G
OPERATION CONDITION
Satisfy all of the following items. The seat synchronization function is not performed if these items are not sat­isfied.
Item Request status System setting ON Ignition position ON Seat back Folded up A/T selector lever (A/T models) P position Parking break (M/T models) Applied Switch inputs
• Power seat switch
• Tilt & telescopic switch
• Door mirror remote control switch
• Set switch
• Memory switch
OFF
(Not operated)
DETAIL FLOW
When performing the sliding, reclining or lifting (rear) operation in manual function, the driver seat control unit performs the seat synchronization function as follows.
Order Input Output Control unit condition
Sensors
1
[Sliding, reclining, lifting (rear)]
2
Sensors (Tilt, telescopic, outside mirror)
Motors (Tilt, telescopic, out­side mirror)
The driver seat control unit judges the direction and distance of seat movement according to the signal input from each seat sen­sor during manual operation.
Driver seat control unit requests the operation to position accord­ing to the direction and distance of seat movement to the automat­ic drive positioner control unit via UART communication. The automatic drive positioner control unit operates each motor.
Driver seat control unit stops the operation of each motor when the value of each sensor that is input to automatic drive positioner con­trol unit via UART communication reaches the target address.
H
I
ADP
K
L
M
N
O
P
ADP-25
Page 67
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
SEAT SYNCHRONIZATION FUNCTION : Component Parts Location
INFOID:0000000006471467
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Driver seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote control switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly )
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
ADP-26
Page 68
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
A
B
C
D
E
F
G
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Slidin g lim it swit ch 20. Power walk-i n switc h
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
H
I
ADP
K
L
JMJIA2416ZZ
M
N
O
ADP-27
P
Page 69
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Backside of seat cushion
24. Sliding, lifting switch (Power seat switch)
SEAT SYNCHRONIZATION FUNCTION : Component Description
CONTROL UNITS
Item Function
Driver seat control unit Operates the specific seat motor with the signal from the power seat switch. Automatic drive positioner control unit
INPUT PARTS
Switches
Item Function
Power seat switch
Forward switch Detect folded down or folded up of the seat back.
Operates the steering motor and door m irror with the signal from the driver seat control unit.
The following switch is installed.
• Reclining switch
• Lifting switch (front)
• Lifting switch (rear)
• Sliding switch The specific parts can be operated with the operation of each switch.
INFOID:0000000006471468
Sensors
Item Function
Door mirror sensor (driver side/passenger side)
Tilt & telescopic sen sor Detect the upward/downward and forward/backward position of steering column. Lifting sensor (rear) Detect the upward/downward position of seat lifter (rear). Reclining sensor Detect the tilt of seatback. Sliding sensor Detect the frontward/rearward position of seat.
Detect the upward/downward and leftward/rightward position of outside mirror face.
ADP-28
Page 70
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
OUTPUT PARTS
Item Function
Door mirror motor (driver side/passenger side)
Tilt & telescopic motor Move the steering column upward/downward and forward/backward. Lifting motor (rear) Move the seat lifter (rear) upward/downward. Reclining motor Tilt and raise up the seatback. Sliding motor Sl id e the se at forward/backward.
Move the outside mirror face upward/downward and leftward/rightward.
A
B
C
MEMORY FUNCTION
MEMORY FUNCTION : System Diagram INFOID:0000000006471469
D
E
F
G
H
I
ADP
K
JMJIA3254GB
MEMORY FUNCTION : System Description INFOID:0000000006471470
OUTLINE
The driver seat control unit can store the optimum driving positions (seat, steering column and door mirror position) for 2 people. If the front seat position is changed, one-touch (pressing desired memory switch for more than 0.5 second) operation allows changing to the other driving position.
NOTE:
Further information for the memory storing procedure. Refer to ADP-10, "
MEMORY STORING : Description".
OPERATION PROCEDURE
1. Turn ignition switch ON
2. Press desired memory switch for more than 0.5 second.
3. Driver seat, steering and door mirror will move to the memorized position.
OPERATION CONDITION
Satisfy all of the following items. The memory function is not performed if these items are not satisfied.
ADP-29
L
M
N
O
P
Page 71
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Item Request status Ignition position ON Seat back Folded up A/T selector lever (A/T models) P position Parking break (M/T models) Applied Switch inputs
• Power seat switch
• Tilt & telescopic switch
• Door mirror control switch
• Set switch
• Memory switch
DETAIL FLOW
Order Input Output Control unit condition
The memory switch signal is inpu tted to the automatic drive p ositioner
1 Memory switch
Motors (Seat, steering, door mirror)
2—
Memory switch Indica­tor
Sensors
3
(Seat, steering, door mirror)
4—
Memory switch Indica­tor
control unit when memory switch 1 or 2 is operated. Memory switch signal is output to d river seat control unit via UART communication.
Driver seat control unit operates eac h motor of seat when it recogniz­es the memory switch pressed for 0.5 second or more and requests each motor operation to automatic drive positioner control unit via UART communication. The automatic drive position er control unit op­erates each motor.
Driver seat control unit requests the flashing of memory indicator to automatic drive positioner control unit via UART communication while either of the motors is operating. The au to ma tic driv e po si t ion er co n­trol unit illuminates the memory indicator.
Driver seat control unit judges the operating seat position with each seat sensor input. The positions of the steering column and outside mirror are monitored with each sensor signal that is input from auto drive positioner control unit via UART communication. Driver seat control unit stops the operat io n of e ach m otor wh en each part reach­es the recorded address.
Driver seat control unit requests the illumination of memory indicator to auto drive positioner control unit via UART communication after all motors stop. The auto driving positioner control unit illuminates the memory indicator for 5 seconds.
(Not operated)
OFF
ADP-30
Page 72
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
MEMORY FUNCTION : Component Parts Location INFOID:0000000006471471
A
B
C
D
E
F
G
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Drive r seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote cont rol switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly)
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
H
I
ADP
K
L
M
N
O
P
ADP-31
Page 73
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2416ZZ
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Sliding limit switch 20. Power walk-in switch
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
ADP-32
Page 74
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Back sid e of se at cu sh io n
24. Sliding, lifting switch (Power seat switch)
MEMORY FUNCTION : Component Description INFOID:0000000006471472
A
B
C
D
E
F
G
H
CONTROL UNITS
Item Function
• The address of each part is recorded.
Driver seat control unit
Automatic drive positioner control unit
• Operates each motor of seat to the registered position.
• Requests the operations of steering column and door mirror to automatic drive positioner control unit
Operates the steering column and door mirror with the signal from the driver seat control.
INPUT PARTS
Switches
Item Function Memory switch 1/2 The registration and memory function can be performed with its operation. Forward switch Detect folded down or folded up of the seat back.
Sensors
Item Function Door mirror sensor
(driver side/passenger side) Tilt & telescopic sensor Detect the upward/downward and forward/backward position of steering column. Lifting sensor (front) Detect the upward/downward position of seat lifting (front). Lifting sensor (rear) Detect the upward/downward position of seat lifting (rear). Reclining sensor Detect the tilt of seatback. Sliding sensor Detect the forward/backward position of seat.
Detect the upward/downward and leftward/rightward position of outside mirror face.
I
ADP
K
L
M
N
O
P
OUTPUT PARTS
ADP-33
Page 75
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Item Function
Door mirror motor (driver side/passenger side)
Tilt & telescopic motor Move the steeri ng column upward/downward and forward/backward. Lifting motor (front) Move the seat lifter (front) upward/downward. Lifting motor (rear) Move the seat lifter (rear) upward/do wnward. Reclining motor Tilt and raise up the seatback. Sliding motor Slide the seat forward/backward. Memory indicator Illuminates or blinks according to the registration/operation status.
Move the outside mirror face upward/downward and leftward/rightward.
INTELLIGENT KEY INTERLOCK FUNCTION
INTELLIGENT KEY INTERLOCK FUNCTION : System Diagram INFOID:0000000006471473
JMJIA0117GB
INTELLIGENT KEY INTERLOCK FUNCTION : System Description INFOID:0000000006471474
OUTLINE
When unlocking doors by using Intelligent Key or driver side door request switch, the system performs mem­ory operation.
OPERATION PROCEDURE
1. Unlock doors by using Intelligent Key or driver side door request switch.
2. The system performs memory operation, and then performs exit assist operation.
NOTE:
If the seat position is in memorized position before unlocking doors, memory operation does not perform.
NOTE:
Further information for Intelligent Key interlock function. Refer to ADP-10, "
MEMORY STORING : Descrip-
tion".
OPERATION CON DITION
Satisfy all of the following items. The Intelligent Key interlock function is performed if these items are satisfied.
ADP-34
Page 76
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Item Request status Key switch OFF (Key is removed.) Ignition position LOCK Seat back Folded up A/T selector lever (A/T models) P position Parking break (M/T models) Applied Switch inputs
• Power seat switch
• Tilt & telescopic switch
• Door mirror control switch
• Set switch
• Memory switch
OFF
(Not operated)
DETAIL FLOW
Order Input Output Control unit condition
• Door unlock signal
1
2 Driver seat control unit performs the memory function.
(CAN)
• Key ID signal (CAN)
Driver seat control unit receives the door unlock signal and the key ID signal from BCM when unlocking the door with Intelligent Key or driver side door request switch.
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-35
Page 77
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
INTELLIGENT KEY INTERLOCK FUNCTION : Component Parts Location
INFOID:0000000006471475
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Driver seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote control switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly )
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
ADP-36
Page 78
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
A
B
C
D
E
F
G
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Slidin g lim it swit ch 20. Power walk-i n switc h
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
H
I
ADP
K
L
JMJIA2416ZZ
M
N
O
ADP-37
P
Page 79
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Backside of seat cushion
24. Sliding, lifting switch (Power seat switch)
INTELLIGENT KEY INTERLOCK FUNCTION : Component Description
CONTROL UNITS
Item Function
Driver seat control unit It performs memory function after receiving the door unlock signal from BCM. Automatic drive positioner control unit
BCM
Operates the steering column and door mirror with the instructions from the driver seat control unit.
Recognizes the following status and transmits it to the driver seat control unit via CAN communication.
• Door lock: UNLOCK (with Intelligent Key or driver side door request swtich)
POWER WALK-IN FUNCTION
INFOID:0000000006471476
ADP-38
Page 80
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
POWER WALK-IN FUNCTION : System Diagram INFOID:0000000006471477
A
B
C
D
E
F
G
JMJIA2396GB
POWER WALK-IN FUNCTION : System Description INFOID:0000000006471478
OUTLINE
Slide the driver seat automatically with the power walk-in switch operation so as to easily facilitate the entry to the rear seat.
Forward Operation
Slide (forward) the driver seat to the front end position (sliding limit switch: ON) by operating the power walk-in switch when the seatback is folded down. The forward operation is stopped by folding the seatback (forward switch: OFF) during the forward operation.
Backward Operation
The seat back is folded up after performing the forward operation of power walk-in function. Slide (backward) it to the position before performing the forward operation by operating the power walk-in switch. If the manual operation, memory operation, and Intelligent Key interlock operation are performed after per­forming the forward operation, do not perform the backward operation.
OPERATION PROCEDURE
Forward Operation
1. Open driver door.
2. Pull the walk-in lever on the upper part of seatback, and then the seatback is folded down.
3. Press the power walk-in switch.
4. Slide the seat to the front end position.
H
I
ADP
K
L
M
N
O
Backward Operation
1. Open driver door.
2. Fold up the seatback after performing the forward operation.
3. Press the power walk-in switch.
4. Slide the seat to the previous position before the forward operation was performed.
OPERATION CONDITION
Perform the power walk-in function when the following conditions are satisfied.
ADP-39
P
Page 81
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Forward Operation
Item Request status Driver side door Open Driver side seat belt Not fastened Power seat switch (sliding) Not operated Vehicle speed 0 km/h Seat position (sliding) Other than front end Seat back Folded down
Backward Operation
Item Request status Initialize Done Driver side seat belt Not fastened Switch inputs
• Power seat switch (sliding)
• Set switch
• Memory switch Vehicle speed 0 km/h
Seat position (sliding) Seat back Folded up
The seat sliding position wi ll not move after per-
forming the forward operation.
Not operated
DETAIL FLOW
Forward Operation
Order Inputs Outputs Control unit conditio n
1 Forward switch
2 Power walk-in switch
3—
4 Sliding limit switch
Backward Operation
Order Inputs Outputs Control unit conditio n
1 Forward switch
2 Power walk-in switch
3—
4 Sliding sensor
Sliding motor (forward)
Sliding motor (backward)
Driver seat control unit detect s that the seatback is folded down by the signal from the forward swit ch.
The operation signal is inputted to the driver seat control unit when the power walk-in switch is oper­ated.
Driver seat control unit operates the seat sliding motor forward when it detects that the power walk­in switch is operated.
Driver seat control unit stops th e seat sliding motor when it detects that the seat sliding reaches the front end position by the sliding limit switch.
Driver seat control unit detect s that the seatback is folded up by the signal from the forward switch.
The operation signal is inputted to the driver seat control unit when the power walk-in switch is oper­ated.
Driver seat control unit operates the slid in g mot or backward when it detects that the power walk-in switch is operated.
Driver seat control unit stops th e seat sliding motor when the seat sliding position reaches the position before performing the forward operation by the signal from sliding sensor.
ADP-40
Page 82
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
POWER WALK-IN FUNCTION : Component Parts Location INFOID:0000000006471479
A
B
C
D
E
F
G
JMJIA2415ZZ
1. BCM 2. Automatic drive positioner control unit 3. Drive r seat control unit
4. Unified meter and A/C amp. 5. A/T assembly 6. Tilt & telescopic switch
7. Key slot 8. Tilt sensor 9. Telescopic sensor
10. Seat memory switch 11. Door mirror remote cont rol switch A. Dash side lower (passenger side) B. View with instrument driver lower
panel removed (Remove 4WAS front control unit with 4WAS models)
D. Behind cluster lid C E. A/T assembly
(TCM is built in A/T assembly)
G View with steering column cover low-
er and upper removed
C. Backside of seat cushion (driver side)
F. View with instrument driver lower
panel removed
H
I
ADP
K
L
M
N
O
P
ADP-41
Page 83
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2416ZZ
12. Driver side door switch 13. A/T shift selector (detention switch) 14. Parking brake switch
15. Door mirror (driver side) 16. Telescopic motor 17. Tilt motor
18. Forward switch 19. Sliding limit switch 20. Power walk-in switch
21. Seat belt buckle switch (driver side) H. View with center console assembly
is removed.
K. View with seat back pad is removed. L. View with seat cushion pad is re-
I. View with center console assembly
is removed.
moved.
J. View with instrument driver lower
panel is removed.
ADP-42
Page 84
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
JMJIA2455ZZ
22. Reclining motor 23. Reclining switch (Power seat switch)
25. Sliding sensor 26. Lifting motor (front) 27. Sliding motor
28. Lifting motor (rear)
M. View with seat cushion pad and seat-
back pad are removed.
N. Back sid e of se at cu sh io n
24. Sliding, lifting switch (Power seat switch)
POWER WALK-IN FUNCTION : Component Description INFOID:0000000006471480
A
B
C
D
E
F
G
H
CONTROL UNITS
Item Function
• Main units of automatic drive positioner system
Driver seat control unit
BCM
Unified meter and A/C amp.
• It is connected to the CAN.
• It communicates with the automatic drive positioner control unit via UART com­munication.
Transmit the following status to the driver seat control unit via CAN communication.
• Driver door: OPEN/CLOSE
• Starter: CRANKING/OTHER
Transmit the vehicle speed signal to the driver seat control unit via CAN communi­cation.
INPUT PARTS
Switches
Item Function Front door switch (driver side) Detect front door (driver side) open/close status. Power walk-in switch Perform the power walk-in operation by operating the power walk-in switch.
Sliding limit switch Seat belt buckle switch Detect the seat belt fastening/releasing condition. Forward switch
Detect the front end position of seat sliding during the power walk-in function front­ward operation.
Detect the folded up/folded dow n con dit i on of se at back tha t is the op era t ion co nd i­tion of power walk-in function.
I
ADP
K
L
M
N
O
P
Sensors
Item Function Sliding sensor Detect the forward/backward position of seat.
ADP-43
Page 85
AUTOMATIC DRIVE POSITIONER SYSTEM
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
OUTPUT PARTS
Item Function
Sliding motor Slide the seat forward/backward.
ADP-44
Page 86
DIAGNOSIS SYSTEM (DRIVER SEAT C/U)
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (DRIVER SEAT C/U)
Diagnosis Description INFOID:0000000006471481
The automatic drive positioner system can be checked and diagnosed for component operation using CON­SULT-III.
DIAGNOSTIC MODE
Diagnostic mode Description
SELF-DIAG RESULTS Performs self-diagnosis for the auto drive positioner system and displays the results. DATA MONITOR CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ACTIVE TEST Drives each output device. ECU PART NUMBER Displays part numbers of driver seat control unit.
CONSULT-III Function INFOID:0000000006471482
SELF DIAGNOSTIC RESULTS
Refer to ADP-165, "DTC Index".
DATA MONITOR
Monitor Item Unit
SET SW “ON/OFF” ××ON/OFF status judged fr om the setting switch signal. MEMORY SW 1 “ON/OFF” ××ON/OFF status judged from the seat memory switch 1 signal. MEMORY SW 2 “ON/OFF” ××ON/OFF status judged from the seat memory switch 2 signal.
SLIDE SW–FR* SLIDE SW–RR* RECLN SW–FR*
RECLN SW–RR*
LIFT FR SW–UP*
LIFT FR SW–DN*
LIFT RR SW–UP*
LIFT RR SW–DN* MIR CON SW–UP “ON/OFF” ××ON/OFF status judged from the mirror switch (upward) signal.
MIR CON SW–DN “ON/OFF” ××ON/OFF status judged from the mirror sw itch (downward ) signal . MIR CON SW–RH “ON/OFF” ××
MIR CON SW–LH “ON/OFF” ××
MIR CHNG SW–R “ON/OFF” ××
MIR CHNG SW–L “ON/OFF” ××
3
3
3
3
3
3
3
3
“ON/OFF” ××ON/OFF status judged from the sliding switch (forward) signal. “ON/OFF” ××ON/OFF status judged from the sliding switch (backward) signal. “ON/OFF” ××ON/OFF status judged from the reclining switch (forward) signal.
“ON/OFF” ××
“ON/OFF” ××
“ON/OFF” ××
“ON/OFF” ××
“ON/OFF” ××
Displays input signals transmitted from various switches and sensors to driver seat con­trol unit in real time.
Main
Signals
Selection
From
Menu
Contents
ON/OFF status judged fr om the reclining switch (backward) sig­nal.
ON/OFF status judged from the lifting switch front (upward) sig­nal.
ON/OFF status judged from the lifting switch front (downward) signal.
ON/OFF status judged from the lifting switch rear (upward) sig­nal.
ON/OFF status judged from the lifting switch rear (downward) signal.
ON/OFF status judged from the door mirror remote control switch (passenger side) signal.
ON/OFF status judged from the door mirror remote control switch (driver side) signal.
ON/OFF status judged from the door mirror remote control switch (switching to right) signal.
ON/OFF status judged from the door mirror remote control switch (switching to left) signal.
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-45
Page 87
DIAGNOSIS SYSTEM (DRIVER SEAT C/U)
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Selection
From Menu
Contents
Monitor Item Unit
Main
Signals
TILT SW-UP “ON/OFF” ××ON/OFF status judged from the tilt switch (upward) signal. TILT SW -DOWN “ON/OFF” ××ON/OFF status judged from the tilt switch (downward) signal.
TELESCO SW-FR “ON/OFF” ××
TELESCO SW-RR “ON/OFF” ××
FORWARD SW* WALK-IN SW*
3
FWD LIMIT SW* SEAT BELT SW*
DETENT SW
*1
PARK BRAKE SW
3
3
3
*2
“ON/OFF” ××ON/OFF status judged from the forward switch signal. “ON/OFF” ××ON/OFF status judged from the power walk-in switch signal. “ON/OFF” ××ON/OFF status judged from the sliding limit switch signal. “ON/OFF” ××ON/OFF status judged from the seat belt buckle switch signal.
“ON/OFF” ××
“ON/OFF” ××
STARTER SW “ON/OFF” ××
ON/OFF status judged from the tel escopi ng switch (f orward ) sig­nal.
ON/OFF status judged from the telescoping switch (backward) signal.
The selector lever position “OFF (P position) / ON (other than the P position)” judged from the detention switch signal.
The parking brake condition “ON (applied) / OFF (release)” judged from the parking brake switch signal.
Ignition key switch ON (START, ON) /OFF (ACC, OFF) status judged from the ignition sw itch signal.
Val ue (32768) when battery connecti ons are standard. If it mo ves
SLIDE PULSE*
3
––×
backward, the value increas es. I f i t m ov es fo rward , t h e va lu e de­creases.
Val ue (32768) when battery connecti ons are standard. If it mo ves
RECLN PULS*
4
––×
backward, the value increas es. I f i t m ov es fo rward , t h e va lu e de­creases.
LIFT FR PULSE*
LIFT RR PULSE*
4
4
––×
––×
MIR/SEN RH U–D “V” ×
MIR/SEN RH R–L “V” ×
MIR/SEN LH U–D “V” ×
MIR/SEN LH R–L “V” ×
Val ue (32768) when battery connecti ons are standard. If it mo ves DOWN, the value increases. If it moves UP , the value decreases.
Val ue (32768) when battery connecti ons are standard. If it mo ves DOWN, the value increases. If it moves UP , the value decreases.
Voltage input from door mirror sensor (passenger side) upward/ downward is displayed.
Voltage input from door mirror sensor (passenger side) leftward/ rightward is displayed.
Voltage input from door mirror sensor (driver side) upward/down­ward is displayed.
Voltage input from door mirror sensor (driver side) leftward/right­ward is displayed.
TILT SEN “V” × Voltage input from tilt sensor upward/downward is displayed. TELESCO SEN “V” ×
*1
: M/T models display all item except this item.
*2
: A/T models display all item except this item.
3
: Only this item is displayed for driver seat without automatic drive positioner system.
*
4
*
: It is displayed but is not operated for models with driver seat without automatic driver positioner system.
Voltage input from telescopic sensor forward/backward is dis­played.
ACTIVE TEST
CAUTION:
When driving vehicle, never perform active test.
Test item Description SEAT SLIDE Activates/deactivates the sliding motor. SEAT RECLINING Activates/deactivates the reclining motor.
ADP-46
Page 88
DIAGNOSIS SYSTEM (DRIVER SEAT C/U)
Revision: 2011 December 2011 G Convertible
< SYSTEM DESCRIPTION >
Test item Description SEAT LIFTER FR Activates/deactivates the lifting motor (front). SEAT LIFTER RR Activates/deactivates the lifting motor (rear). TILT MOTOR* Activates/deactivates the tilt motor. TELESCO MOTOR* Activates/deactivates the telescopic motor. MIRROR MOTOR RH* Activates/deactivates the mirror motor (passenger side). MIRROR MOTOR LH* Activates/deactivates the mirror motor (driver side). MEMORY SW INDCTR* Turns ON/OFF the memory indicator.
*: Does not display without automatic driver position system.
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-47
Page 89
U1000 CAN COMM CIRCUIT
Revision: 2011 December 2011 G Convertible
< DTC/CIRCUIT DIAGNOSIS >
DTC/CIRCUIT DIAGNOSIS
U1000 CAN COMM CIRCUIT
Description INFOID:0000000006471483
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul­tiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control unit, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H-line, CAN L-line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.
DTC Logic INFOID:0000000006471484
DTC DETECTION LOGIC
DTC No.
U1000
Trouble diagnosis
name
CAN COMM CIR­CUIT
DTC detecting condition Possible cause
• Driver seat control unit cannot communicate to other control units.
• Driver seat control unit cannot communicate for more than the specified time.
Harness or connectors (CAN communication line is open or shorted)
DTC CONFIRMATION PROCEDURE
1.STEP 1
1. Turn ignition switch ON and wait for 3 seconds or more.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-48, "Diagnosis Procedure". NO >> INSPECTION END
Diagnosis Procedure INFOID:0000000006471485
Refer to LAN-14, "Trouble Diagnosis Flow Chart".
Special Repair Requirement INFOID:0000000006471486
Refer to ADP-10, "SYSTEM INITIALIZATION : Description".
ADP-48
Page 90
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2112 SLIDING MOTOR
B2112 SLIDING MOTOR
Description INFOID:0000000006471487
• The seat sliding motor is installed to the seat cushion frame.
• The seat sliding motor is installed with the driver seat control unit.
• Slides the seat frontward/ rearward by changing the rotation direction of sliding motor.
DTC Logic INFOID:0000000006471488
DTC DETECTION LOGIC
NOTE:
First perform diagnosis for B2126 if B2126 is detected.
DTC No.
B2112 SEAT SLIDE
Trouble diagnosis
name
The driver seat control unit detects the output of slid­ing motor output terminal for 0.1 seco nd or more even if the sliding switch is not input.
DTC CONFIRMATION PROCEDURE
DTC detecting condition Possible cause
• Driver seat control unit
• Slide motor harness is power shorted
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-49, "Diagnosis Procedure". NO >> INSPECTION END
Diagnosis Procedure INFOID:0000000006471489
A
B
C
D
E
F
G
H
I
1.CHECK SLIDING MOTOR CIRCUIT (POWER SHORT)
1. Turn ignition switch OFF.
2. Disconnect sliding motor and driver seat control unit connector.
3. Check voltage between sliding motor harness connector and ground.
(+)
Sliding motor
Connector Terminals
B525
35 42
(–)
Ground 0
Is the inspection result normal?
YES >> GO TO 2. NO >> Repair or replace harness.
2.CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect driver seat control unit connector.
2. Check voltage between driver seat control unit harness connector and ground.
(+)
Driver seat control unit
Connector Terminals
B525
Is the inspection result normal?
35 42
(–)
Ground 0
Voltage (V)
(Approx.)
Voltage (V)
(Approx.)
ADP
K
L
M
N
O
P
ADP-49
Page 91
B2112 SLIDING MOTOR
Revision: 2011 December 2011 G Convertible
< DTC/CIRCUIT DIAGNOSIS >
YES >> GO TO 3. NO >> Replace driver seat control unit. Refer to ADP-236, "
3.CHECK INTERMITTENT INCIDENT
Removal and Installation"
Refer to GI-43, "
>> INSPECTION END
Intermittent Incident".
ADP-50
Page 92
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2113 RECLINING MOTOR
B2113 RECLINING MOTOR
Description INFOID:0000000006471490
• The seat reclining motor is installed to the seatback frame.
• The seat reclining motor is activated with the driver seat control unit.
• Tilts the seatback frontward/rearward by changing the rotation direction of reclining motor.
DTC Logic INFOID:0000000006471491
DTC DETECTION LOGIC
NOTE:
First perform diagnosis for B2126 if B2126 is detected.
DTC No.
B2113 SEAT RECLINING
DTC CONFIRMATION PROCEDURE
Trouble diagnosis
name
DTC detecting condition Possible cause
The driver seat control unit det ects the output of re­clining motor output terminal for 0.1 second or more even if the reclining switch is not input.
• Driver seat control unit
• Reclining motor harness is pow­er shorted
1.PEFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-51, "Diagnosis Procedure". NO >> INSPECTION END
Diagnosis Procedure INFOID:0000000006471492
A
B
C
D
E
F
G
H
I
1.CHECK RECLINING MOTOR CIRCUIT (POWER SHORT)
1. Turn ignition switch OFF.
2. Disconnect reclining motor and driver seat control unit connector.
3. Check voltage between reclining motor harness connector and ground.
(+)
Reclining motor
Connector Terminals
B523
36 44
(–)
Ground 0
Is the inspection result normal?
YES >> GO TO 2. NO >> Repair or replace harness.
2.CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect driver seat control unit connector.
2. Check voltage between driver seat control unit harness connector and ground.
(+)
Driver seat control unit
Connector Terminals
B523
Is the inspection result normal?
36 44
(–)
Ground 0
Voltage (V)
(Approx.)
Voltage (V)
(Approx.)
ADP
K
L
M
N
O
P
ADP-51
Page 93
B2113 RECLINING MOTOR
Revision: 2011 December 2011 G Convertible
< DTC/CIRCUIT DIAGNOSIS >
YES >> GO TO 3. NO >> Replace driver seat control unit. Refer to ADP-236, "
3.CHECK INTERMITTENT INCIDENT
Removal and Installation".
Refer to GI-43, "
>> INSPECTION END
Intermittent Incident".
ADP-52
Page 94
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2118 TILT SENSOR
B2118 TILT SENSOR
Description INFOID:0000000006471493
• The tilt sensor is installed to the steering column assembly.
• The resistance of tilt sensor is changed according to the up/down position of steering column.
• The terminal voltage of automatic drive positioner control unit will be changed according to a change of tilt sensor resistance. Automatic drive positioner control unit calculates the tilt position from the voltage.
DTC Logic INFOID:0000000006471494
DTC DETECTION LOGIC
DTC No.
B2118 TIL T SENSOR
DTC CONFIRMATION PROCEDURE
Trouble diagnosis
name
DTC detecting condition Possible cause
The input voltage of tilt sensor is less then 0.1V or more than 4.9V.
• Harness and connectors (Tilt sensor circuit is opened/ shorted, tilt sensor power supply circuit is opened/shorted.)
• Tilt sensor
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-53, "Diagnosis Procedure". NO >> INSPECTION END
A
B
C
D
E
F
G
H
I
Diagnosis Procedure INFOID:0000000006471495
1.CHECK TILT SENSOR SIGNAL
1. Turn ignition switch ON.
2. Select “TILT SEN” in the “Data monitor” mode using CONSULT-III.
3. Check tilt sensor signal under the following condition.
Monitor item Condition Value
Change between
TILT SEN Tilt position
1.1 V (close to top)
3.9 V (close to bottom)
Is the value normal?
YES >> GO TO 6. NO >> GO TO 2.
2.CHECK TILT SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and tilt & telescopic sensor connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M51 7 M48 3 Existed
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Continuity
ADP
K
L
M
N
O
P
ADP-53
Page 95
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2118 TILT SENSOR
Automatic drive positioner control unit
Connector Terminal
M51 7 Not existed
Ground
Continuity
Is the inspection result normal?
YES >> GO TO 3. NO >> Repair or replace harness.
3.CHECK TILT SENSOR POWER SUPPLY
1. Connect automatic drive positioner control unit connector.
2. Turn ignition switch ON.
3. Check voltage between tilt & telescopic sensor harness connector and ground.
(+)
Tilt & telescopic sensor
Connector Terminal
M48 1 Ground 5
(–)
Voltage (V)
(Approx.)
Is the inspection result normal?
YES >> GO TO 5. NO >> GO TO 4.
4.CHECK TILT SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M5233M48 1Existed
Continuity
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Automatic drive positioner control unit
Connector Terminal
M52 33 Not existed
Ground
Continuity
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit. Refer toADP-237, "Removal and Installation". NO >> Repair or replace harness.
5.CHECK TILT SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M5241M48 4Existed
Continuity
Is the inspection result normal?
YES >> Replace tilt & telescopic sensor. NO >> Repair or replace harness.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "
Intermittent Incident".
ADP-54
Page 96
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2118 TILT SENSOR
>> INSPECTION END
A
B
C
D
E
F
G
H
I
ADP
K
L
M
N
O
P
ADP-55
Page 97
B2119 TELESCOPIC SENSOR
Revision: 2011 December 2011 G Convertible
< DTC/CIRCUIT DIAGNOSIS >
B2119 TELESCOPIC SENSOR
Description INFOID:0000000006471496
• The telescopic sensor is installed to the steering column assembly.
• The resistance of telescopic sensor is changed according to the forward/backward position of steering col-
umn.
• The terminal voltage of automatic drive positioner control unit will be changed according to a change of tele-
scopic sensor resistance. Automatic drive positioner control unit calculates the telescopic position from the voltage.
DTC Logic INFOID:0000000006471497
DTC DETECTION LOGIC
DTC No.
B2119
Trouble diagnosis
name
TELESCOPIC SEN­SOR
The input voltage of telescopic sensor is less than
0.1V or more than 4.9V.
DTC detecting condition Possible cause
• Harness and connectors (Telescopic sensor circuit is opened/shorted, telescop ic sen­sor power supply circuit is opened/shorted.)
• Telescopic sensor
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC is detected?
YES >> Perform diagnosis procedure. Refer to ADP-56, "Diagnosis Procedure". NO >> INSPECTION END
Diagnosis Procedure INFOID:0000000006471498
1.CHECK TELESCOPIC SENSOR SIGNAL
1. Turn ignition switch ON.
2. Select “TELESCO SEN” in the “Data monitor” mode using CONSULT-III.
3. Check the tilt sensor signal under the following condition.
Monitor item Condition Value
Change between
TELESCO SEN Telescopi c position
0.5 V (close to top)
4.5 V (close to bottom)
Is the valve normal?
YES >> GO TO 6. NO >> GO TO 2.
2.CHECK TELESCOPIC SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and tilt & telescopic sensor connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M5123M48 2Existed
4. Check continuity between automatic drive positioner control unit harness connector and ground.
ADP-56
Continuity
Page 98
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2119 TELESCOPIC SENSOR
Automatic drive positioner control unit
Connector Terminal
M51 23 Not existed
Ground
Continuity
Is the inspection result normal?
YES >> GO TO 3. NO >> Repair or replace harness.
3.CHECK TELESCOPIC SENSOR POWER SUPPLY
1. Connect automatic drive positioner control unit connector.
2. Turn ignition switch ON.
3. Check voltage between tilt & telescopic sensor harness connector and ground.
(+)
Tilt & telescopic sensor
Connector Terminal
M48 1 Ground 5
(–)
Voltage (V)
(Approx.)
Is the inspection result normal?
YES >> GO TO 5. NO >> GO TO 4.
4.CHECK TELESCOPIC SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
A
B
C
D
E
F
G
H
I
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M52 33 M48 1 Existed
Continuity
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Automatic drive positioner control unit
Connector Terminal
M52 33 Not existed
Ground
Continuity
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit. Refer to ADP-237, "Removal and Installation". NO >> Repair or replace harness.
5.CHECK TELESCOPIC SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive positioner control unit harness connector and tilt & telescopic sensor harness connector.
Automatic drive positioner control unit Tilt & telescopic sensor
Connector Terminal Connector Terminal
M52 41 M48 4 Existed
Continuity
Is the inspection result normal?
YES >> Replace tilt & telescopic sensor. NO >> Repair or replace harness.
6.CHECK INTERMITTENT INCIDENT
ADP
K
L
M
N
O
P
Refer to GI-43, "
Intermittent Incident".
ADP-57
Page 99
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
>> INSPECTION END
B2119 TELESCOPIC SENSOR
ADP-58
Page 100
< DTC/CIRCUIT DIAGNOSIS >
Revision: 2011 December 2011 G Convertible
B2126 DETENT SW
B2126 DETENT SW
Description INFOID:0000000006471499
• Detention switch is installed on A/T shift selector. It is turned OFF when the A/T selector lever is in P posi-
tion.
• The driver seat control unit judges that the A/T selector lever is in P position if continuity does not exist in this
circuit.
DTC Logic INFOID:0000000006471500
DTC DETECTION LOGIC
DTC No.
B2126 DETENT SW
DTC CONFIRMATION PROCEDURE
Trouble diagnosis
name
DTC detecting condition Possible cause
Selector lever is in P positio n and the ve hicle speed of 7 ± 4 km/h is detected.
• Harness and connectors (Detention switch circuit is opened/shorted.)
• Detention switch
• Unified meter and A/C amp. (CAN communication)
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Drive the vehicle at 7 ±4 km/h or more.
2. Check “Self diagnostic result” using CONSULT-III. Is the DTC detected?
YES >> Perform diagnosis procedure. Refer to ADP-59, "Diagnosis Procedure". NO >> INSPECTION END
A
B
C
D
E
F
G
H
I
Diagnosis Procedure INFOID:0000000006471501
1.CHECK DTC WITH “BCM”
Check “Self diagnostic result” for BCM using CONSULT-III. Is the either DTC B2601,B2602, B2603, B2604 or B2605 detected?
YES >> Check the DTC. Refer to BCS-75, "DTC Index". NO >> GO TO 2.
2.CHECK DTC WITH “METER/M&A”
Check “Self diagnostic result” for METER/M&A using CONSULT-III. Is the DTC detected?
YES >> Check the DTC. Refer to MWI-103, "DTC Index". NO >> GO TO 3.
3.CHECK DETENTION SWITCH SIGNAL
1. Turn ignition switch ON.
2. Select “DETENT SW” in the “Data Monitor” mode using CONSULT-III.
3. Check detention switch signal under the following condition.
Monitor item Condition Status
DETENT SW selector leve r
Is the status normal?
YES >> GO TO 5. NO >> GO TO 4.
P position OFF Other than above ON
4.CHECK DETENTION SWITCH CIRCUIT
ADP
K
L
M
N
O
P
ADP-59
Loading...
