Infiniti G35 User's Manual

FOREWORD

Thank you for purchasingan INFINITI auto­mobile. This user’s manual is for the navi­gation system only. This manual contains
operating instructions for the INFINITI
Navigation System offered in the INFINITI
G35.

Please read this manual carefully to ensure
safe operation of the navigation system.

O Please read your vehicle’s Owner’s

Manual first.

O Do not remove this manual from the ve-

hicle when selling this vehicle. The next
user of this navigation system may need
the manual.

O Because of possible specification

changes, sections of this manual may
not apply to your vehicle.

O All information, specifications and illus-

trations in this manualare those in effect
at the time ofprinting. INFINITI reserves
the right to change specifications or de­sign at any time without notice.

Table of

Introduction

1

Contents

How does the INFINITI Navigation System work?

What features are available on the INFINITI Navigation System?

How do I operate the INFINITI Navigation System?

How do I program a destination?

How do I use the Point of Interest (POI) feature?

How do I use the address book feature?

How do I use the avoid area feature?

How do I use the automatic rerouting feature?

How do I use the voice guidance feature?

How do I adjust the display?

How do I use the vehicle information?

Information on map data discs

Troubleshooting guide

Index

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1 Introduction

How to use this manual ................................... 1-2

For safe operation ....................................... 1-2

Reference symbols ....................................... 1-2

Safety note....................................................... 1-2

Laser product............................................... 1-3

HOW TO USE THIS MANUAL SAFETY NOTE

This manual uses special words and icons,
organized by function. Please refer to the
following items and familiarize yourself
with them.

FOR SAFE OPERATION

WARNING

This is used to indicate the presence of a
hazard that could cause death or serious
personal injury. To avoid or reduce the risk,
the procedures must be followed precisely.

CAUTION

This is used to indicate the presence of a
hazard that could cause minor or moderate
personal injury or damage to your vehicle.
To avoid or reduce the risk, the procedures
must be followed carefully.

NOTE:

This indicates an item to help you under­stand the maximum performance of your
vehicle. If ignored, it may lead to a mal­function or poor performance.

1-2 Introduction

REFERENCE SYMBOLS

INFO:
This indicates information necessary for

efficient use of your vehicle or accesso­ries.

DEST button

This is a button on the control panel.

View key

This is a select key on the screen. By se­lecting this key you can proceed to the
next function.

This system is primarily designed to help
you reach your destination, and also per­forms other functions as outlined in this
manual. However, you, the driver, must
use the system safely and properly. Infor­mation concerning road conditions, traffic
signs and the availability of services may
not always be up-to-date. The system is

not a substitute for safe, proper, and le­gal driving.

Before using the navigation system,
please read the following safety informa­tion. Always use the system as outlined in
this manual.

WARNING

O When the driver operates the navigation

system or uses the joystick (screen func­tion), first park the vehicle in a safe place
and set the parking brake. Using the sys­tem while driving can distract the driver
and may result in a serious accident. Des­tinations cannot be set while the vehicle
is in motion.

O Do not rely on voice guidance alone. Al-

ways be sure that all driving maneuvers
may be made legally and safely to avoid
an accident.

O Do not disassemble or modify this system.

If you do, it may result in accidents, fire,
or electrical shock.

O Do not use this system if you notice any

malfunction such as a frozen screen or
lack of sound. Continued use of the sys­tem may result in accidents, fire, or elec­trical shock.

O If you notice anyforeign object in the sys-

tem hardware or spilled liquid, or no-

tice smoke or a smell coming from it, stop
using the systemimmediately and contact
an INFINITI dealer. Ignoring such condi­tions may lead to accidents, fire, or elec­trical shock.

NOTE:

Some states/provinces may have laws lim­iting the use of video screens while driving.
Use this system only where legal.

LASER PRODUCT

This navigation system is certified as a
Class 1 laser product.

The navigation system complies with DHHS
Laser-Radiator Standards, 21 CFRChapter 1
subchapter J.

WARNING

O Do not disassemble or modify this system.

There are no user serviceable parts in this
navigation system.

O If maintenance, adjustments and opera-

tions other than those specified in this
manual are attempted, injury due to la-ser
radiation and exposure could occur.

Introduction 1-3

MEMO

1-4 Introduction

2 How does the INFINITI Navigation System

work?

What is a navigation system?........................... 2-2

About the navigation system ....................... 2-2

What is GPS (Global Positioning System)?........ 2-2

Accuracy of positioning................................ 2-2

Positioning adjustment ................................ 2-3

Receiving signals from GPS satellites........... 2-3

Display of GPS information .......................... 2-3

Detailed map coverage areas (MCA) for the

navigation system ............................................ 2-3

When a gray road or dark green road is

displayed on the map ................................. 2-4

WHAT IS A NAVIGATION SYSTEM?

ABOUT THE NAVIGATION SYSTEM

This navigation system combines the data
obtained from the vehicle (by gyro sensor)
and from GPS (Global Positioning System)
satellites to calculate the current location
of the vehicle. This position is then dis­played on the screen, allowing route guid­ance to a destination.

WHAT IS GPS (GLOBAL POSITIONING
SYSTEM)?

GPS is a system developed and operated
by the U.S. Government, covering the en­tire planet. This navigation system re­ceives three or more different radio sig­nals from NAVSTAR (GPS satellites), orbit­ing the earth 13,049 miles (21,000 km)
above ground. The data from different sets
of signals will be trigonometrically calcu­lated to obtain the position of the vehicle.

INFO:
The tracking center in the U.S. controls

signals transmitted from GPS satellites.
This control sometimes results in reduced
accuracy or no signal received at all, in ac­cordance with government requirements.

INV0901

ACCURACY OF POSITIONING

The color of the GPS Indicator on the
upper left corner of the screen indicates
positioning as follows:

O Green: Positioning is possible and ac-

curate

O Yellow: Positioning is possible but ac-

curacy is minimal

O Gray: Positioning is not possible

2-2 How does the INFINITI Navigation System work?

INFO:
For approximately 3 or 4 minutes after

system startup, the GPS indicator
mains gray, even if accurate positioning is
possible.

re-

POSITIONING ADJUSTMENT

When the system judges that the vehicle
position information is not accurate based
on vehicle speed and gyro sensor data cal­culations, the system will adjust the ve­hicle position information using GPS sig­nals.

RECEIVING SIGNALS FROM GPS
SATELLITES

Sometimes, satellite reception is weak.
The following are places where signals
tend to be weak:

O Inside tunnels and parking garages
O Areas with numerous tall buildings
O Under multi-layered highways
O In a dense forest

Vehicles in these areas may not receive
GPS signals (Indicator color: gray).

INFO:
The antenna for GPS is located on the in-

strument panel inside the vehicle. Do not

place any object, especially mobile
phones or transceivers, on the instrument
panel. Because the strength of the GPS

signal is approximately one billionth of
that of TV waves, phones and transceivers
will decrease the strength or may totally
disrupt the signals.

DISPLAY OF GPS INFORMATION

This system displays GPS information.
Please refer to “GPS information display”

on page 11-17.

NOTE:

Directional guidance provided by the navi­gation system does not take carpool lane
driving into consideration, especially
when carpool lanes are separated from
other road lanes.

How does the INFINITI Navigation System work? 2-3

DETAILED MAP COVERAGE AREAS (MCA)
FOR THE NAVIGATION SYSTEM

This system is designed to help you reach
your destination, and also performs other
functions as outlined in this manual. How­ever, you, the driver, must use the system
safely and properly. Information concern­ing road conditions, traffic signs and the
availability of services may not always be
up-to-date. The system is not a substitute
for safe, proper, and legal driving.

Map data covers select metropolitan areas
in the United States.

Map data is available on map DVD-ROM.
For information about map DVD-ROMs,
contact an INFINITI dealer or call the
INFINITI NAVIGATION SYSTEM HELPDESK
at 1-800-777-0325.

Map data includes 2 types of areas: “De­tailed coverage areas” providing all de­tailed road data and other areas showing
“Main roads only”.

NOTE:

Detailed map data is not available in
many areas and is generally limited to se­lect major metropolitan areas.

For information on which metropolitan ar­eas are in detailed coverage areas, please
refer to the INFINITI Navigation System
Software Booklet (included). When you

purchase an updated map DVD-ROM, a
new software booklet will be provided.

WHEN A GRAY ROAD OR DARK
GREEN ROAD IS DISPLAYED ON
THE MAP

O When you are driving on a gray road af-

ter the vehicle has deviated from the
suggested route during route guidance,
automatic rerouting may not start im­mediately.

O The navigation system does not provide

route guidance for dark green roads.
Therefore, if the destination is set on a
dark green road, the enlarged map dis­play will return to the ordinary map
screen at a point on a suggested road
that is near the destination. Also, the
voice guidance will stop at a point on a
suggested road that is near the desti­nation. Refer to “About route guidance”
on page 4-25 for details.

O POI information and street names near

gray roads may not be contained in the
map data.

2-4 How does the INFINITI Navigation System work?

3 What features are available on the INFINITI

Navigation System?

Route guidance ................................................ 3-2

Point of interest (POI) directory........................ 3-2

Address book ................................................... 3-2

Avoid area........................................................ 3-3

Automatic reroute............................................. 3-3

Detour.............................................................. 3-3

Birdview

Voice guidance................................................. 3-4

Short menus .................................................... 3-4

TM

........................................................ 3-4

ROUTE GUIDANCE POINT OF INTEREST (POI) DIRECTORY ADDRESS BOOK

The main feature of the INFINITI Naviga­tion System is Visual and Audio Route
Guidance in selected detailed map cover­age areas. Utilizing a network of GPS (Glo­bal Positioning System) satellites, the
INFINITI Navigation System tracks your lo­cation on the map and directs you where
you want to go.

Once you program a destination covered
by a detailed map, the INFINITI Naviga­tion System will determine a route from
your current location to your destination.
The moving map display and turn-by-turn
voice commands help the driver determine
upcoming turns.

This feature can be especially helpful in
finding unfamiliar locations or businesses.
The system may be unable to set a desti­nation and/or calculate distance when a
destination is outside a detailed map cov­erage area. Additionally, audio route guid­ance may not be available if the destina­tion is outside a detailed map coverage
area. For more information on how to pro­gram a destination, please refer to section

5.

The INFINITI Navigation System offers an
extensive Point of Interest directory in de­tailed map coverage areas. This directory
includes a wide variety of destinations
ranging from gas stations, ATMs, and res­taurants to casinos, ski resorts, shopping
centers and businesses. By accessing the
Point of Interest directory, you can search
for addresses and phone numbers for a
destination, and with a press of a button,
the INFINITI Navigation System will calcu­late a route to the destination.

The Point of Interest directory offers many
uses. For example, the directory can be
sorted by the various types of restaurants
near your current location. If you need an
ATM or gas station, the INFINITI Naviga­tion System can point you to the closest
one or the closest one of your favorite
brand.

For more information on how to use the
Point of Interest directory, please refer to
section 6.

Using the Address Book feature, you will
have the ability to store up to 50 locations
in detailed map coverage areas into a per­sonal directory. This is especially useful
for frequently visited locations, such as
your clients, relatives, or friends. The Ad­dress Book feature will provide you with
easy access to frequently visited locations
when setting them as your destination.

For more information on how to use your
Address Book, please refer to section 7.

3-2 What features are available on the INFINITI Navigation System?

AVOID AREA AUTOMATIC REROUTE DETOUR

By using the Avoid Area feature, you can
identify areas or freeways that you would
like the INFINITI Navigation System to
avoid when plotting routes. For example, if
you know of a freeway or area that is al­ways congested with traffic, you can pro­gram the INFINITI Navigation System to
plot routes that go around that particular
freeway or area.

For more information on the Avoid Area
feature, please refer to section 8.

If you miss a turn while using the Route
Guidance feature, the INFINITI Navigation
System will automatically recalculate a
new route to your destination.

For more information on the Automatic Re­route feature, please refer to section 9.

If you hear about a traffic accident on the
radio that is 4 miles (6 km) ahead of you
and traffic is backing up fast, you can use
the Detour function to calculate an alter­native route that will help you avoid the
gridlock caused by the traffic accident. The
INFINITI Navigation System has the abil­ity to find an alternative route using sec­ondary roads that will return you to pri­mary roads after a specified number of
miles.

For more information on the Detour fea­ture, please refer to section 9.

What features are available on the INFINITI Navigation System? 3-3

BIRDVIEW

The INFINITI Navigation System gives you
a choice of two map viewing styles, a nor­mal 2-dimensional PLANVIEW map and the
3-dimensional BIRDVIEW
BIRDVIEW
area as seen from an elevated perspective,
so you will get a better feel for the route
ahead.

For more information on the BIRDVIEW
feature, please refer to section 11.

TM

TM

TM

map depicts a geographic

map. The 3-D

VOICE GUIDANCE SHORT MENUS

INV0902 INV0903 INV0904

Route guidance is executed using voice
and screen instruction. When the vehicle
approaches an intersection where you
need to turn, the voice guidance tells you
the direction to take.

The system also has the following useful
features:

O Enlarged display of intersections.

TM

O Automatic rerouting when a vehicle is

off the course (when map is displayed).

For more information on the Voice Guid­ance feature, please refer to section 10.

3-4 What features are available on the INFINITI Navigation System?

To make the INFINITI Navigation System
easier to use, there is a short menu func­tion in which the most commonly used
items are listed. When the indicator is il­luminated, the short menus (Easy Mode)
are displayed. When the indicator is
turned off, the default navigation systems
menus (Expert Mode) are displayed.

INFO:
O [Easy Mode] is the default setting on

the initial screen at the delivery of your
new vehicle.

O The term [Expert Mode] is used in this

manual when the

Short Menus key in-

dicator is turned off. When the amber
indicator is highlighted, the system is
set to [Easy Mode].

O When the SETTING , DEST or ROUTE

button is pressed in the [Easy Mode]
screen, the

For more information on the Short
Menu feature, please refer to section 4.

Help key is displayed.

What features are available on the INFINITI Navigation System? 3-5

MEMO

3-6 What features are available on the INFINITI Navigation System?

4 How do I operate the INFINITI Navigation

System?

Opening/closing the liquid crystal (LC)

display ............................................................. 4-2

How to open the LC display ......................... 4-2

How to close the LC display ......................... 4-3

Control panel button functions ........................ 4-4

Names of the components ........................... 4-5

How to use the joystick and the ENTER

button.......................................................... 4-6

How to use the PREVIOUS button .............. 4-6

How to use the CANCEL button ................. 4-6

How to use the SETTING button................. 4-8

How to use the DEST button .................... 4-12

How to use the ROUTE button .................. 4-14

How to eject/insert the disc ........................... 4-16

Start-up screen............................................... 4-18

Confirmation of destination or waypoint .... 4-18

Clearing the memory ...................................... 4-22

Setting the average speed ............................ 4-24

About route guidance ..................................... 4-25

Notes on route guidance ............................ 4-25

About the display error .............................. 4-27

OPENING/CLOSING THE LIQUID CRYSTAL
(LC) DISPLAY

When you use this system, make sure the
engine is running.

NOTE:

If you use the system with the engine not
running (ignition ON or ACC position) for
long periods of time, this may drain the
battery, making it difficult to start the en­gine.

HOW TO OPEN THE LC DISPLAY

CAUTION

rupted due to disconnecting the vehicle
battery etc.

O If it is difficult to see the screen due to

sunlight, tilt thedisplay forward orback­ward to adjust to the desired angle.

O Do not place any objects on the instru-

ment panel. If you drop any objects onto
the instrument panel or spill liquid on it,
it may result in system malfunction.

O To protect the liquid crystal display,

close it when it is not used.

The liquid crystal display opens when:
O the liquid crystal display was open

when the ignition key was turned to
OFF position, then the next time the ig­nition key is turned to ON or ACC posi­tion.

O the button on the upper part of the liq-

uid crystal display is pressed with the

ignition key in ON or ACC position.
INFO:
O The liquid crystal display may not open

if the power supply had been inter-

4-2 How do I operate the INFINITI Navigation System?

INI0112

INI0113

HOW TO CLOSE THE LC DISPLAY

The liquid crystal display closes when:
O the ignition key is turned to OFF posi-

tion.

O the button on the upper part of the liq-

uid crystal display is pressed with the
ignition key in ON or ACC position.

The voice guidance cannot be heard when
the cover is closed.

CAUTION

O Be careful not to pinch your hands or fin-

gers when the liquid crystal display is
closed.

O Do not open/close the liquid crystal dis-

play manually. It may damage the
equipment.

NOTE:

O If the liquid crystal display stays

opened/closed (or partly opened) and

does not move when the button on the

upper part of the liquid crystal display

is pressed, turn the ignition key off and

turn it on again. Then try the

open/close operation again. If the liq-

uid crystal display still does not move,

contact an INFINITI dealer.

O When the liquid crystal display is

tilted, return it to the original position

and then store it. If it is pushed under

tilted conditions, it may be difficult to

store.

O If the side of the display is pushed, it

may be difficult to store.

How do I operate the INFINITI Navigation System? 4-3

CONTROL PANEL BUTTON FUNCTIONS

INI0114

4-4 How do I operate the INFINITI Navigation System?

NAMES OF THE COMPONENTS

1. VOICE button; refer to page 10-4.
Provides upcoming voice command
from the current location.

2. ROUTE button; refer to page 4-14.
Displays the setting menu screen at
the time of route calculation.

3. SETTING button; refer to page 4-8.
Performs various adjustments and set­tings to help you use the navigation
system more effectively.

4. INFO button: refer to section 12.
Displays the [VEHICLE INFORMATION]
or [WARNING] screen.

5. MAP button; refer to page 5-38.
Toggles between the intersection and
the map during route guidance. Re­turns to the map screen from the set­tings screen.

6. DEST button; refer to page 4-12.
Displays the “Set a Destination” menu.

INI0073

7. JOYSTICK and ENTER button; refer to
page 4-6.
Scrolls the map, selects and sets each
setting item.

8. PREVIOUS button; refer to page 4-6.
Returns to the previous screen during
set-up.
Finishes the set-up after it is com­pleted.

9. ZOOM IN / ZOOM OUT button; re­fer to page 11-2.
Alters the scale of the map display.

10. CANCEL button; refer to page 4-6.

Cancels operations or the route guid­ance.

11.

12.

(Day/Night) button; refer to page
11-26.
Changes display brightness.

button; refer to page 4-16.

Ejects the DVD-ROM.

How do I operate the INFINITI Navigation System? 4-5

HOW TO USE THE JOYSTICK AND
THE ENTER BUTTON

The navigation system is operated by se­lecting keys on the screen with the joy­stick and pressing the ENTER button. Be
sure to understand the operation of the
joystick before using the navigation sys­tem.

Selecting the keys on the screen

Use the joystick to select keys on the
screen.

The joystick can be tilted in eight direc­tions. The selected key will be highlighted
in yellow.

INFO:
Use the joystick to scroll the map.

Selecting the function of the
highlighted key

Press the ENTER button.
The display shows the screen to carry out

the function of the selected key (high­lighted in yellow).

HOW TO USE THE

PREVIOUS

BUTTON

This button has two functions.

To return to the previous screen:

When this button is pressed during setup,
setup will be canceled, and the screen will
return to the previous screen.

To finish the set-up:

When this button is pressed after set-up is
completed, the settings will be renewed as
directed, and the screen will return to the
map.

INFO:
When the PREVIOUS button must be

pressed, (for example, after the set-up is
finished) instructions are given in the op­eration procedure of each section in this
manual. If the PREVIOUS button is
pressed when not finished with the set-up,
the setting will be canceled, and the
screen will return to the previous screen.

HOW TO USE THE

CANCEL

BUTTON

This button has two functions:
O Operation is canceled when pushed

during operation.

O The [CONFIRMATION] screen is dis-

played during route guidance in the
present location map.

4-6 How do I operate the INFINITI Navigation System?

INV0905 INV0906

When the CANCEL button is pressed, the
[CONFIRMATION] screen is displayed with
the following three keys.

O All Destinations
O Waypoint 1
O Do not Cancel

When the

All Destinations

key is

selected

The route guidance is turned off tempo­rarily.

1. Select the

2. When the
route guidance is turned off.

INFO:
O When the

will be displayed. When the PREVIOUS
button is pressed, the previous screen
will be displayed.

All Destinations key.

Yes key is selected, the

No key is selected, the map

How do I operate the INFINITI Navigation System? 4-7

O To restart the route guidance, press the

VOICE button.

INFO:
When the

will be displayed. When the PREVIOUS
button is pressed, the previous screen will
be displayed.

When the

No key is selected, the map

Do not Cancel

key is

selected

The [Confirmation] screen will return to the
map screen.

INV0907 INV0908

When the

Waypoint 1

key is

selected

INFO:
This key can be selected only when a way-

point is set.
Route guidance to the next waypoint is de-

leted.

1. Select the

2. When the
waypoint is deleted and route calcula­tion will start.

Waypoint 1 key.

Yes key is selected, the

4-8 How do I operate the INFINITI Navigation System?

HOW TO USE THE

SETTING

BUTTON

When the SETTING button is pressed, the
[SETTINGS] screen is displayed.

WARNING

For safety, some of the functions on the
menu will be disabled while the vehicle is
moving. To use the temporarily disabled
functions, park the vehicle in a safe place,
shift to P or N, and set the parking brake.

To use the navigation system more effec­tively, various adjustments and settings
can be performed.

Clock key:

To adjust the time, select the
Please refer to page 11-29.

Display key:

The key adjusts the display
Brightness/Contrast/Map Background.
Please refer to page 11-22.

Language/Unit key:

Changes language and unit.
Please refer to page 4-9.

Navigation key:

Changes various settings of the navigation
system.
Please refer to page 4-10.

Clock key.

Short Menus key:

This key changes between [Expert Mode]
and [Easy Mode].

Please refer to page 3-4.

Guidance Volume key:

Adjusts or turns off volume of the voice
guidance.

Please refer to “Adjusting the guide vol­ume” on page 10-2.

Help key:

Available only in Easy Mode (Short
menus).

You can see the explanation of naviga­tional functions.

INV1115

When the

Language/Unit

key is

selected

1. The following display will appear when
selecting the
pressing ENTER button.

Language: English or French
Unit: US — Mile, MPG

Metric — km, /100 km

Language/Unit key and

How do I operate the INFINITI Navigation System? 4-9

INV1116 INV0910

2. You can select the language and unit
using the joystick and ENTER button.

When the

Navigation

key is

selected

The following display will appear when se­lecting the
the ENTER button.

View key:

This will let you choose between Bird-

TM

view
Please refer to “Switching between Bird-

TM

view
11-4.

Navigation key and pressing

display and Planview display.

and Planview displays” on page

Heading key:

You can set the map either to show the
vehicle’s current forward direction as up,
or to show North as up.

Please refer to “Changing the display di­rection (in Planview display)” on page 11-

7.
Nearby Display Icons key:

Displays five types of points of interest
around the current location.

Please refer to “Setting with the
key” on page 6-12.

Save Current Location key:

Stores the current vehicle location in the
address book.

Please refer to “Storing current vehicle po­sition” on page 7-4.

Adjust Current Location key:

Corrects the location and direction of the
vehicle icon.

Please refer to “Updating the current ve­hicle location and the direction” on page
11-18.

Nearby

4-10 How do I operate the INFINITI Navigation System?

Auto Re-route On/Off key:

A new route to the desired destination will
automatically be calculated again from the
location when the vehicle deviates from
the suggested route during route guid­ance.

Please refer to “Automatic rerouting” on
page 9-2.

Avoid Area Setting key:

Defines areas to avoid when calculating a
route.

Please refer to “Setting avoid areas” on
page 8-2.

Button Tone/Beep Response key:

This key is used to turn on/off the auto­matic beep sound.

Please refer to “Setting automatic beep
sound” on page 11-21.

Clear Memory key:

Clears all the stored memory (Address
Book, Avoid Area, Previous Dest.).

Please refer to “Clearing the memory” on
page 4-22.

Edit Address Book key:

Changes the names and positions of the
registered locations.

Please refer to “Setting up and editing the
address book” on page 7-2.

GPS Information key:
GPS information will be displayed.
Please refer to “GPS information display”

on page 11-17.

Quick Stop Customer Settings key:
Sets the user-defined [Quick Stop] POI

(Point Of Interest).
Please refer to “Quick stop customer set-

tings” on page 5-45.

Set Average Speed for Estimated Journey Time

Please refer to “Setting the average
speed” on page 4-24.

Tracking On/Off key:
You can choose whether to display the

path from the start to the current position.
Please refer to “Displaying the track” on

page 11-15.

key:

Easy Mode — when the

Short Menus
View key:

Same as in Expert Mode.

Heading key:

Same as in Expert Mode.

key is selected

INV0911

How do I operate the INFINITI Navigation System? 4-11

and shift to P or N, and set the parking
brake.

O Address Book key:
Use this category item if you want to go to

places stored in the address book.
Please refer to “Setting with the

Address Book key” on page 5-3.

O

Previous Dest. key:

You can choose destinations from the last

INV2315

HOW TO USE THE

Sets destinations (final destination and
waypoints) to search for a route.

This will activate various navigational func­tions.

DEST

BUTTON

WARNING

For safety, some of the functions on the
menu will be disabled while the vehicle is
moving. To use the temporarily disabled
functions, park the vehicle in a safe place

10 destinations set.
For details, please refer to “Setting with

the

Previous Dest. key” on page 5-5.

O

Street Address key:

Use this category item if you know the city
name, street name and house number of
the destination (waypoints).

Please refer to “Setting with the

Street Address key” on page 5-7.

O

Intersection key:

Sets a destination using the intersection
of 2 streets.

Please refer to “Setting with the

4-12 How do I operate the INFINITI Navigation System?

Intersection key” on page 5-15.

Point of Interest (POI) key:

O

Use this category item if you want to go to
a restaurant, hotel, gas station or other fa­cility.

Please refer to “Setting with the

Point of Interest (POI) key” on page 6-2.

O

City key:

Sets the destination (waypoint) on the
map screen of the area around the input
city.

Please refer to “Setting with the
key” on page 5-22.

Phone Number key:

O

Use this category item when the destina­tion phone number is known.

Please refer to “Setting with the

Phone Number key” on page 5-26.

O

Map key:

Use this category item if you want to
choose the place directly on the map dis­play.

Please refer to “Setting with the
key” on page 5-29.

City

Map

O Country key:
This key is used to retrieve a location in

another country when it is set as the des­tination (waypoint).

Please refer to “Setting with the
key” on page 5-30.

Country

INV2316

Easy Mode — when the

Short Menus

Help key:
You can see the explanation of the naviga-

tional functions.

Home key:
When you set your home in the address

book, a route home will be calculated by
selecting this key.

If the home is not set beforehand, the set­ting mode will appear to input the home
address.

key is selected

How do I operate the INFINITI Navigation System? 4-13

Please refer to “Setting with the
key” on page 5-31.

Street Address key:

Same as in Expert Mode.

Point of Interest (POI) key:

Same as in Expert Mode.

Country key:

Same as in Expert Mode.

Home

Please refer to “Quick stop” on page 5-44.

Where am I ? key:
Displays the street where the vehicle is

currently located, the previous street, and
the upcoming street.

Please refer to “Where am I ?” on page
5-47.

Route Info key:
Displays the route to the destination.

There are three types of display methods.

O

INV0914

HOW TO USE THE

When the ROUTE button is pressed while
the current location is displayed on the
screen, the display shows the following
keys.

INFO:
When no operations are executed after a

few seconds, the keys will disappear auto­matically.

Quick Stop key:

Selects the destination (waypoints) from a
list of 5 commonly used POI (Points of In­terest).

ROUTE

BUTTON

Complete Route key:

Displays the entire route from the cur­rent location to the destination.

Please refer to “Displaying the com­plete route to the destination” on page
11-10.

O

Turn List key:

Displays a list of the guidance points
for the entire route to the destination
on a simple map.

Please refer to “Displaying turn list” on
page 11-11.

O

Route Simulation key:

Performs a simulation drive on the map

4-14 How do I operate the INFINITI Navigation System?

screen by moving a vehicle icon on all
the routes from the current location to
the destination.

Please refer to “Requesting the simula­tion drive to the destination” on page
11-13.

Edit Route key:
Resets the set destination (waypoint).
Please refer to “Making the system guide

the route with detailed options” on page
5-33.

INV0915 INV0916

Easy Mode — when the

Short Menus
Help key:

You can see the explanation of the naviga­tion functions.

Quick Stop key:

Same as in Expert Mode.

Where am I ? key:

Same as in Expert Mode.

key is selected

Keys that appear when the map is
scrolled with the joystick

You can scroll the map display and get in­formation about the area near your vehicle
and the destination using the joystick.

INFO:
O This function can be used when the

original map disc is inserted.

O You can operate this with the map dis-

play on.

O This function cannot be used when the

system is calculating the route or draw­ing the screen.

How do I operate the INFINITI Navigation System? 4-15

Store Place key:
You can store the location with the cross

pointer.
Please refer to “Storing current vehicle po-

sition” on page 7-4.

Destination # key:
You can set the position as a destination,

using the cross pointer. The maximum
number of destinations is six, and the last
one stored will be the final destination. (#
will appear on the map to denote the se­lected locations from 1 to 6.) Please refer
to “Making the system guide the route

HOW TO EJECT/INSERT THE DISC

with detailed options” on page 5-33. INFO:

The navigation system is installed in the
upper glove box.

This system is provided with the map
DVD-ROM.

NOTE:

Please take great care in handling the
disc.

INI0076

1. Open the cover of the upper glove box.

4-16 How do I operate the INFINITI Navigation System?

INI0077 INI0078 INI0079

2. To insert a disc:
Place the disc in the slot.
It will be drawn in automatically. You
do not have to push it in all the way.

3. To eject the disc:
Press the
disc.

Close the cover.

button, and remove the

CAUTION

O The included map DVD-ROM is designed

specifically for your navigation system.
Do not use it in another system as it
could cause a malfunction.

How do I operate the INFINITI Navigation System? 4-17

START-UP SCREEN

O Do not allow the system to get wet. Ex-

cessive moisture such as spilled liquids
may cause the system to malfunction.

CONFIRMATION OF DESTINATION
OR WAYPOINT

When the engine is turned off during route
calculation and then turned on, the [CON­FIRMATION OF DEST./WAYPOINT] screen
will be displayed after the start-up screen.

INV2317

When you turn the ignition key to ACC, the
above warning is displayed on the screen.
Read the warning and select the

I AGREE (English) or ENTER (Français)

key.
INFO:

If you do not press the ENTER button, the
system will not proceed to the next step
display.

4-18 How do I operate the INFINITI Navigation System?

INV0918 INV0919

In the [CONFIRMATION OF DEST./
WAYPOINT] screen, the following four keys
are displayed.

O To All Destinations
O From Next Waypoint
O Cancel Guidance
O Change (only in Expert Mode)

INFO:
When the PREVIOUS or MAP button is

pressed in this screen, the [Turn by turn]
screen will be displayed.

When the

To All Destinations

key is

selected

Route guidance will start to all
destinations/waypoints from the current
location.

When the

From Next Waypoint

key is

selected

1. Select the From Next Waypoint key.

How do I operate the INFINITI Navigation System? 4-19

Select the key when you want to start
route guidance to the next waypoint/
destination.

INV0920 INV0921

2. When the Yes key is selected, route
guidance to the current waypoint is de­leted and route calculation to the next
destination will start.

INFO:
O If you do not want to delete the route

guidance, select the
screen will return to the map.

O This key can be selected only when a

waypoint is set.

O When the PREVIOUS button is

pressed, the previous screen will be
displayed.

No key and the

4-20 How do I operate the INFINITI Navigation System?

When the

Cancel Guidance

selected

The route guidance is canceled.

1. Select the

Cancel Guidance key.

key is

INV0922 INV0923

2. When the Yes key is selected, route
guidance is canceled.

INFO:
O If you do not want to delete the route

guidance, select the
screen will return to the map.

O Press the VOICE button to activate the

route guidance again.

O When the PREVIOUS button is

pressed, the previous screen will be
displayed.

No key and the

When the

It is possible to edit the route guidance to
the destination.

INFO:
This key is displayed only in [Expert

Mode].

Change

key is selected

1. Select the

Change key.

How do I operate the INFINITI Navigation System? 4-21

INV0924 INV0909

2. The [EDIT ROUTE] screen will be dis­played.

Please refer to “Setting the waypoints” on
page 5-34.

CLEARING THE MEMORY

All the stored data (Address Book, Avoid
Area, Previous Dest) can be cleared.

1. Press the SETTING button.

2. Select the
[SETTINGS] screen.

Navigation key on the

4-22 How do I operate the INFINITI Navigation System?

INV0925 INV0926 INV0927

3. Select the Clear Memory key. 4. Select the Yes key. 5. When the Yes key is selected, the
stored data will be cleared, and the
[NAVIGATION SETTINGS] screen will ap­pear.

How do I operate the INFINITI Navigation System? 4-23

SETTING THE AVERAGE SPEED

This navigation system can calculate and
display the expected arrival time to the
destination. To do this, set average vehicle
speeds when driving on freeways, main
roads and ordinary roads.

The following settings are available.
O Freeway

Default: 55 MPH (90 km/h)
Max: 70 MPH (110 km/h)
Min: 40 MPH (60 km/h)

O Main Roads

Default: 25 MPH (40 km/h)
Max: 50 MPH (80 km/h)
Min: 10 MPH (20 km/h)

O Ordinary Roads

Default: 15 MPH (25 km/h)
Max: 35 MPH (55 km/h)
Min: 5 MPH (10 km/h)

1. Press the SETTING button.

2. Select the
TINGS] screen.

INV0909 INV0928

Navigation key on the [SET-

3. Select the

Set Average Speed for Estimated Journey Time

the [NAVIGATION SETTINGS] screen.

key on

4-24 How do I operate the INFINITI Navigation System?

INV0929 INV2378

4. Move the joystick upward or downward
to select an item you want to change.

5. Move the joystick left or right and set
an average vehicle speed.

INFO:
O It is possible to set the item illumi-

nated in yellow.

O When the

key is selected, all settings return to
default.

Return All Settings to Default

ABOUT ROUTE GUIDANCE

O The INFINITI Navigation System may

not calculate a route if the current ve­hicle location is too far away from the
destination. In this case, please divide
your trip by selecting one or two inter­mediate destinations.

NOTE:

There may be cases that carpool lanes are
included on a suggested road when the
automatic rerouting function is activated
and even if the “Use Time Restricted
Roads” is turned off. Refer to “Setting the
priorities for route calculation” on page
5-35 for details.

O The navigation system does not provide

route guidance for dark green roads.
Therefore, if the destination is set on a
dark green road, the enlarged map dis­play will return to the ordinary map
screen at a point on a suggested road
that is near the destination, and the
distance and direction to the end point
of the suggested road will be displayed
on upper right corner of the screen.
Also, at this time, the voice will say,
“En route to your destination, some
roads contain incomplete map data.
Turn guidance will not be provided in
this area.”

How do I operate the INFINITI Navigation System? 4-25

When approaching the end point of the
suggested road, the voice will say, “Enter­ing the road with incomplete map data.
Please use the direction arrow and dis­tance information to proceed to your des­tination.”
To reach your destination, refer to the map
screen, always follow actual roads and
regulations and drive safely.

NOTES ON ROUTE GUIDANCE

O The route selected by the system may

not be the shortest, nor are other cir­cumstances such as traffic jams consid­ered.

O Because of the inevitable difference in

road conditions and circumstances be­tween the time you use this system and
the time the information was produced
for the DVD, there may be discrepan­cies in roads and regulations. In such
cases, follow the actual information
available.

O During route calculation, the map will

not scroll, however the vehicle icon will
move with the actual vehicle’s move­ment.

O During route calculation, buttons such

as MAP , DEST , ZOOM OUT and

ZOOM IN and the joystick will be dis-

abled.

O In some cases, after the calculation is

complete, it may take some time to get
the calculated route on the display.

O Waypoints that have been passed will

not be covered by the rerouting calcu­lation.

O If you scroll the map while the sug-

gested route is being drawn, it may
take more time to finish drawing.

O If waypoints are set, the system is cal-

culating multiple routes between way-

points simultaneously, and the follow­ing may result.

— If one section (or more) of the routes

between the waypoints is not found,
none of the route will be displayed.

— The route may not connect completely

at some waypoints.

— The route may require a U-turn close to

some waypoints.

O Route calculation may not be completed

in the following cases.

— If there is no main road within a range

of 1.5 miles (2.5 km) from the vehicle,
a message saying so will appear on the
screen. Try requesting route calculation
when the vehicle is closer to the main
road.

— If there is no main road within a range

of 1.5 miles (2.5 km) from the destina­tion or waypoint, a message saying so
will appear on the screen. Try setting
the location closer to the main road.

— If the vehicle is too close to the desti-

nation or if there are no branches of
the roads to the destination. A message
saying so will appear on the screen.

— If it is deemed impossible to reach the

4-26 How do I operate the INFINITI Navigation System?

destination or waypoints because of
traffic regulations, etc.

— If the only route to reach the destina-

tion or waypoints is extremely compli­cated.

— If the destination, current vehicle posi-

tion or waypoint is within the avoid
area.

— If the setting of avoid areas covers the

routes to the destination, route calcula­tion may not be possible.

O The following may occur when the route

is being displayed.

— If you are requesting calculation from

the main road, the origin of the route
may not exactly match the current ve­hicle position.

— If you are requesting calculation to a

destination on the main road, the end
of the route may not exactly match the
destination.

— If you are requesting calculation from

the main road, the system may show a
route from another main road. This may
be because the icon to show the cur­rent vehicle position (vehicle icon) is
not set accurately. In that case, park

the car in a safe place and reset the ve­hicle icon, or continue driving to see if
the vehicle icon appears on the main
road before requesting route calculation
again.

— There are cases in which the system

shows a detoured route to reach the
destination or waypoints, if you set
them from memory or facility informa­tion. In order to correct this, you will
have to be careful about the traffic di­rection, especially when the lanes with
different travel directions are shown
separately. Such places are inter­changes and service areas.

— This system makes no distinction be-

tween limited traffic control and total
control (blockage). It may show a de­toured route even if the road is usable.

— Even if the freeway preference is set to

OFF, the route may be set on them. To
avoid this, set a waypoint on another
road type and request calculation.

— Even if the preference is set to OFF for

a ferry line, the route may be set on it.
To avoid this, set a waypoint on a road
and request calculation.

— Ferry lines, except those which accept

only pedestrians, bicycles and motor­cycles, are stored in this system. When
using them, take into consideration the
travel time required and operational
condition to decide whether to use
them or not.

ABOUT THE DISPLAY ERROR

The following cases may affect the display
accuracy of the vehicle’s position or travel
direction. The accuracy will return to nor­mal if the driving conditions return to nor­mal.

— When there is a similar road nearby.
— When the vehicle is traveling on a long

stretch of straight road or series of
curves with a large radius.

— When the vehicle is traveling in an area

with a grid road system.

— When the vehicle is making consecutive

S curves.

— When the vehicle is at a large Y-shaped

junction.
— When the vehicle is on a loop bridge.
— When the vehicle is on a snow-covered

or unpaved road.
— When the vehicle has made several

How do I operate the INFINITI Navigation System? 4-27

consecutive turns or zigzags.

— When the vehicle is rotated on a park-

ing lot turntable while the ignition
switch is OFF.

— Immediately after the vehicle is driven

out of a parking garage or underground
parking lot.

— When the vehicle has different sizes of

tires or tire chains.

— When the vehicle is moved immediately

after the engine is started.

MEMO

4-28 How do I operate the INFINITI Navigation System?

5 How do I program a destination?

Various ways to set the destination

(or waypoint).................................................... 5-2

Expert mode categories................................ 5-2

Easy mode categories ................................. 5-3

Setting with the
Setting with the
Setting with the
Setting with the
Setting with the

key............................................................. 5-22

Setting with the
Setting with the
Setting with the
Setting with the
Setting with the

(in easy mode) ........................................... 5-31

Address Book key ........... 5-3

Previous Dest. key .......... 5-5

Street Address key........... 5-7

Intersection key ............. 5-15

Point of Interest (POI)

City key.......................... 5-22

Phone Number key......... 5-26

Map key ........................ 5-29

Country key.................... 5-30

Home key

Having the system guide you to the

destinations ................................................... 5-32

Making the system guide the route with

detailed options......................................... 5-33

Adjusting and deleting the preset destination

(waypoints)..................................................... 5-40

To delete a destination .............................. 5-42

All clear.......................................................... 5-43

Quick stop...................................................... 5-44

Quick stop customer setting ...................... 5-45

Where am I? .................................................. 5-47

VARIOUS WAYS TO SET THE
DESTINATION (OR WAYPOINT)

WARNING

To operate the navigation system or to use
the screen functions, first park the vehicle
in a safe place and set the parking brake.
Using the system while driving can distract
the driver and may result in a serious acci­dent.

O City
O Phone Number
O Map

INV2315

EXPERT MODE CATEGORIES

To set the destination and waypoints, you
can choose from the eight categories de­scribed below. Use these options to
choose the best way to find the route to
the destinations and waypoints.

O Address Book
O Previous Dest.
O Street Address
O Intersection
O Point of Interest (POI)

5-2 How do I program a destination?

INV2316

EASY MODE CATEGORIES

When the Expert Mode is canceled, the
following three categories will be dis­played as Easy Mode.

O Home
O Street Address
O Point of Interest (POI)

INFO:
O Use the

Point of Interest (POI) key in the same

way as in Expert Mode.

Address Book key and the

Please refer to “Setting with the

Address Book key” on page 5-3 and

“Setting with the
key” on page 6-2.

O If the

O If you set a destination or waypoints,

O If you want to go to places close to the

O When using either the Point of Interest

Short Menus key is highlighted

in amber in the [SETTINGS] screen, the
screen is in Easy Mode. In this case,
the keys displayed are different from
the screen in Expert Mode.

they will be displayed with icons.

stored locations or facilities, use cat­egories such as facility, nearby facility
or memory for easier setting.

(POI) or nearby Points of Interest cat­egories, the names called up can be set
as the destination if you do not scroll
the screen. If you want to choose a dif­ferent place on the screen from the one
called up, you will have to scroll the
screen.

Point of Interest (POI)

SETTING WITH THE

Address Book

KEY

The Address Book will allow you to store
locations in the memory. This is especially
useful for locations that you visit fre­quently.

Please refer to “Setting up and editing the
address book” on page 7-2.

How do I program a destination? 5-3

INV2315 INV2381 INV2382

1. Press the DEST button.

2. Select the
[DEST. SETTING] screen.

The [DEST. SETTING (Address Book)]
screen will be displayed.

Address Book key on the

5-4 How do I program a destination?

3. Select the item key of your destination
(waypoints) on the [DEST. SETTING (Ad­dress Book)] screen.

4. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

5. To slightly alter the destination.
Select the

screen of the area around the specified
destination (waypoints).

Map key to display the map

INV2383 INV0935

6. If necessary, operate the joystick to ad­just the location of the destination
(waypoint). Press the ENTER button. Se­lect the

The [DEST. SETTING (Address Book)]
screen will be displayed.
To set the destination (waypoint), refer
to “Making the system guide the route
with detailed options” on page 5-33.

Destination key to confirm.

SETTING WITH THE

Previous Dest.

KEY

This system memorizes the last 10 desti­nations previously chosen, allowing you to
set new destinations or waypoints from
them.

How do I program a destination? 5-5

INV2318 INV2384 INV2385

1. Press the DEST button.

2. Select the
[DEST. SETTING] screen.

A total of 10 destinations and locations
previously set will be displayed.

Previous Dest. key on the

5-6 How do I program a destination?

3. Select the item key of your destination
(waypoints) on the [DEST. SETTING (Pre­vious Dest.)] screen.

4. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

5. To slightly alter the destination.
Select the

screen of the area around the specified
destination (waypoints).

Map key to display the map

INV2386 INV0940

6. If necessary, operate the joystick to ad­just the location of the destination
(waypoints). Press the ENTER button.
Select the
The [DEST. SETTING (Previous Dest.)]
screen will be displayed.
To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

Destination key to confirm.

SETTING WITH THE

Street Address

KEY

Sets the destination (waypoints) from the
street names and addresses that you en­ter.

There are two search methods; direct
search by the street names, and search by
the street names after the state/province
and/or the city are defined.

How do I program a destination? 5-7

1. First press the DEST button.

2. Select the

Street Address key.

5-8 How do I program a destination?

INV2319 INV2320 INV2321

Setting with the

The List key is used when you know the
names of the destination and waypoints.

1. A keyboard will be displayed on the
[DEST. SETTING (Street Address)]
screen. Enter the street name you want
to set.

INFO:
It is not possible to enter names if they

are not stored in the DVD-ROM.

List

key

2. Enter the street name of your destina­tion.
For example, enter

3. After entering
The list screen of street names which
begin with

TU will appear.

T , then U.

U , select the List key.

INV2322 INV2324

O If less than 5 suggested streets remain,

they will be displayed automatically
without selecting the

List key.

O The city names and street names will

be displayed.

O Use the joystick to scroll the display.
O When the

Next Search key is selected,
it is possible to narrow down cities. To
use this function, refer to “Setting with
the

City key” on page 5-13.

O When the PREVIOUS button is

pressed, the screen to input street
names will be displayed.

4. Select one street of your destination.

5. Enter the house number.
Select the

OK key.
INFO:
It may not be possible to specify a loca-

tion after selecting the

OK key. In that
case, a list of locations which correspond
to the entered house number will be dis­played.

NOTE:

If a house number is entered and it is not
a “direct hit” for house numbers already
stored in the database, then only a map

How do I program a destination? 5-9

to the general vicinity will be displayed.

INV2325 INV2323

6. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

7. To slightly alter the destination.
Select the

screen of the area around the specified
destination (waypoints).

INFO:
O An approximate location corresponding

to the house number entered is dis­played. If necessary, correct the loca­tion using the joystick.

O The location displayed by the calcula-

tion using the house number may dif­fer from the actual location. In that

Map key to display the map

5-10 How do I program a destination?

case, correct the location using the joy­stick.

INV0948 INV2326

8. If necessary, operate the joystick to ad­just the location of the destination
(waypoint). Press the ENTER button. Se­lect the
The [DEST. SETTING (Street Address)]
screen will be displayed.
To set the destination (waypoint), refer
to “Making the system guide the route
with detailed options” on page 5-33.

Destination key to confirm.

Setting with the

The State key is used when you select a
state/province to set the destination.

1. Select the

State

State key.

key

How do I program a destination? 5-11

INV2327 INV2328 INV2329

2. The display shows the screen to select
states/provinces.
Input a state/province name.

5-12 How do I program a destination?

INFO:
When the

in step 2, the history of the previous five
settings will be listed.

Last 5 States key is selected

3. The display shows the state/province
list.
Select a state/province name.

INV2330 INV2331 INV2332

4. The screen returns to the [DEST. SET­TING (Street Address)] screen.
When the state/province is set, the dis­play shows the selected state/province
next to the

Input the street name.
Please refer to “Setting with the

key” on page 5-8.

State key.

List

Setting with the

The City key is used when you select a
city to set the destination.

1. Select the
O The display shows the screen to select

cities.

City

City key.

key

2. Input a city name.

How do I program a destination? 5-13

INV2333 INV2334 INV2335

INFO:
O When the

in step 2, the history of the previous
five settings will be listed.

O It is not possible to select cities if they

are not in the state/province you set.

Last 5 Cities key is selected

5-14 How do I program a destination?

3. The display shows the city list.
Select a city of your choice.

4. The screen returns to the [DEST. SET­TING (Street Address)] screen.

When the city is set, the display shows
the selected city beside the

Input the street name of your choice.

Proceed to “Setting with the
page 5-8.

City key.

List key” on

SETTING WITH THE

Intersection

KEY

This will allow you to set an intersection
as a destination (waypoints).

1. Press the DEST button.

2. Select the
A keyboard will be displayed.

Intersection key.

INV2336 INV2387

Setting with the

The List key is used when you know the
names of the destinations and waypoints.

1. Enter the first street name where the
destination (waypoints) is located using
the keyboard, then select the

List

key

List key.

How do I program a destination? 5-15

INV2388 INV2389

2. Select the name of the first street.
INFO:
O When the

it is possible to narrow down
states/provinces and cities. To use this
function, refer to “Setting with the

City key” on page 5-20.

O For a road where lanes with different

traffic directions are shown separately,
the list shows first street name, second
street name, ...

O When entering a street name, enter a

minor street name as the first street

Next Search key is selected,

5-16 How do I program a destination?

and the calculation will be easier and
quicker.

3. Enter the second (intersecting) street
name, then select the

INFO:
If there are less than 5 streets which in-

tersect the first street, they will be dis­played automatically without selecting the

List key.

List key.

INV2390 INV2391 INV2392

4. Select the name of the second street.
The [DEST. SETTING (Intersection)] screen

will appear.

5. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

6. To slightly alter the destination.
Select the

Map key to display the map
screen of the area around the specified
destination (waypoints).

How do I program a destination? 5-17

INV0966 INV2393

7. If necessary, operate the joystick to ad­just the location of the destination
(waypoint). Press the ENTER button. Se­lect the
The [DEST. SETTING (Intersection)]
screen will be displayed.
To set the destination (waypoint), refer
to “Making the system guide the route
with detailed options” on page 5-33.

NOTE:

When the corresponding data does not
exist under the following conditions, the
street name list may not be displayed:

Destination key to confirm.

O A street name is being input after the

City key has been selected.

O The list is being displayed by selection

of the

List key.

Setting with the

The State key is used when you select a
state/province to set the destination.

1. Select the

State

State key.

key

5-18 How do I program a destination?

INV2394 INV2395 INV2396

2. The display shows the screen to select
states/provinces.

Input a state/province name.

INFO:
When the

Last 5 States key is selected
in step 2, the history of the previous five
settings will be listed.

3. The display shows the state/province
list.

Select a state/province name.

How do I program a destination? 5-19

INV2397 INV2398 INV2399

4. The screen returns to the [DEST. SET­TING (Intersection)] screen.

When the state/province is set, the dis­play shows the selected state/province
next to the

Input the street name.
Please refer to “Setting with the

key” on page 5-15.

State key.

List

5-20 How do I program a destination?

Setting with the

The City key is used to retrieve an inter­section from the specified city to set the
destination.

1. Select the
O The display shows the screen to select

cities.

City

City key.

key

2. Input a city name.

INV2400 INV2401 INV2402

INFO:
O When the

Last 5 Cities key is selected
in step 2, the history of the previous
five settings will be listed.

O It is not possible to select cities if they

are not in the state/province you set.

3. The display shows the city list.
Select a city of your choice.

4. The screen returns to the [DEST. SET­TING (Intersection)] screen.

When the city is set, the display shows
the selected city next to the

City key.

Input the street name of your choice.

Proceed to “Setting with the

List key” on

page 5-15.

How do I program a destination? 5-21

INV2337 INV2338

SETTING WITH THE

Point of Interest (POI)

The INFINITI Navigation System includes
a database of Point of Interest (POI) loca­tions such as restaurants, hotels, and gas
stations. (refer to section 6.)

By using this feature, you can set a Point
of Interest location as a destination. For
details on how to use the POI feature,
please refer to section 6.

KEY

SETTING WITH THE

Sets the destination (waypoints) on the
map screen of the area in and around the
input city.

1. Press the DEST button.

City

KEY

2. Select the
TING] screen.

City key on the [DEST. SET-

5-22 How do I program a destination?

INV2403 INV2404

Setting with the

The List key is used when you know the
names of the destination and waypoints.

1. Enter the characters of the city name
which you wish to set as a destination
(waypoints) using the keyboard on the
[DEST. SETTING (City)] screen, then se­lect the

INFO:
O When the

of the currently-listed cities will be dis­played.

List key.

List

key

List key is selected, the data

O If less than 5 suggested cities remain,

they will be displayed automatically
without selecting the

List key.

2. Select the city name of your destination
(waypoints) on the [DEST. SETTING
(City)] screen.

How do I program a destination? 5-23

INV2405 INV2406 INV0983

3. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

5-24 How do I program a destination?

4. To slightly alter the destination.
Select the

screen of the area around the specified
destination (waypoints).

Map key to display the map

5. If necessary, operate the joystick to ad­just the location of the destination
(waypoints).
Press the ENTER button. Select the

Destination key to confirm.
The [DEST. SETTING (City)] screen will
be displayed.
To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

INV2407 INV2408 INV2409

Setting with the

The State key is used when you select a
state/province to set the destination.

1. Select the

State

State key.

key

2. The display shows the screen to select
states/provinces.

Input a state/province name.

INFO:
When the

in step 2, the history of the previous five
settings will be listed.

Last 5 States key is selected

How do I program a destination? 5-25

INV2410 INV2411

3. The display shows the state/province
list.

Select a state/province name.

4. The screen returns to the [DEST. SET­TING (City)] screen.

When the state/province is set, the dis­play shows the selected state/province
next to the

Input the city name.
Please refer to “Setting with the

key” on page 5-23.

State key.

List

SETTING WITH THE

Phone Number

KEY

Sets the destination (waypoints) on the
map screen of the area and around the in­put phone number.

1. Press the DEST button.

5-26 How do I program a destination?

INV2339 INV2412 INV2413

2. Select the Phone Number key on the
[DEST. SETTING] screen.

3. Enter the ten-digit phone number of the
destination (waypoints) using the key­board on the [DEST. SETTING (Phone
Number)] screen.

4. If you select the

OK key, the [DEST.
SETTING (Phone Number)] screen will
be displayed.

5. To set the destination (waypoints), re­fer to “Making the system guide the
route with detailed options” on page
5-33.

How do I program a destination? 5-27

INV2414 INV0998 INV2415

6. To slightly alter the destination.
Select the

screen of the area around the specified
destination (waypoints).

Map key to display the map

5-28 How do I program a destination?

7. If necessary, operate the joystick to ad­just the location of the destination
(waypoints).

Press the ENTER button.
Select the
To set the destination (waypoints), refer to

“Making the system guide the route with
detailed options” on page 5-33.

Destination key to confirm.

INFO:
When a hospital is set as a destination, a

telephone number of the destination will
be displayed, if available.

SETTING WITH THE

This will enable you to zoom into the map
for detail and set the desired location.
This works best when you know the loca­tion geographically, or want to check the
geographical surroundings on the map be­fore setting the destinations.

Map

KEY

INV2340 INV1000

1. Press the DEST button.

2. Select the

The map of the entire area will be dis­played.

Map key.

3. Operate the joystick to choose the des­tination (waypoints).

How do I program a destination? 5-29

INV1001 INV2416

4. Adjust the location using the joystick,
and press the ENTER button.

5. Select the
The [DEST. SETTING] screen will appear.

Destination key.

6. Please refer to “Making the system
guide the route with detailed options”
on page 5-30.

INFO:
When the

[DEST. SETTING] screen, route calculation
starts. If you want to add waypoints, se­lect the

OK key is selected in the

Waypoint key.

SETTING WITH THE

When the Street Address , Intersection ,

City , or Point of Interest (POI) key is
used to set the destination (waypoints) in
other countries, they are retrieved from
the areas in the country which has been
set in the country category. When setting
the destination (waypoints) in other coun­tries, select a country first.

Country

KEY

5-30 How do I program a destination?

1. Press the DEST button.
The [DEST. SETTING] screen will be dis-

played.
Select the

Country key.

INV2341 INV2342

2. Select the
Each time the ENTER button is pressed,
the country selection toggles between
USA and Canada.

3. Then, the selected country will be dis­played at the right of the

Country key.

Country key.

SETTING WITH THE

Home

KEY (IN

EASY MODE)

Sets the home as a destination.
INFO:
In the Expert Mode, this key will not be

displayed. Turn on the highlighted green

Short Menus key in the [SETTINGS]

screen.

How do I program a destination? 5-31

1. Press the DEST button.

2. Select the

Home key.

INV2316 INV2417

3. The [DEST. SETTING] screen will be dis­played.
Select the

To set the destination (waypoints), refer to
“Making the system guide the route with
detailed options” on page 5-33.

INFO:
If the home is not registered in the Ad-

dress Book, the [EDIT ADDRESS BOOK
(Street Address)] screen will be displayed.
Please refer to “Setting with the

Street Address key” on page 5-7.

OK key.

HAVING THE SYSTEM GUIDE YOU TO THE
DESTINATIONS

WARNING

To operate the navigation system or to use
the screen functions, first park the vehicle
in a safe place and set the parking brake.
Using the system while driving can distract
the driver and may result in a serious acci­dent.

5-32 How do I program a destination?

INV1006 INV2418

MAKING THE SYSTEM GUIDE THE
ROUTE WITH DETAILED OPTIONS

By choosing the destination from the
menu, you can choose detailed options
such as waypoints and calculation condi­tions and have the system guide you from
the current position to the destination.

Setting the destination

First, you will have to set the destination.

1. Select a destination using one of the
methods described earlier in this chap­ter:

— Address Book
— Previous Destination
— Street Address
— Intersection
— Point of Interest (POI)
— City
— Phone Number
— Map
— Home

2. Set the route priorities and select the
Route Calc. key to calculate the route.

INFO:
O If you select the

route calculation will start without any
waypoints.

O Press the PREVIOUS button to display

the [EDIT ROUTE] screen.

OK key at this point,

How do I program a destination? 5-33

INV1008 INV2343

Setting the waypoints

After you set a destination, you can set
waypoints.

INFO:
O When the ROUTE button is pressed on

the map and the
lected, the [EDIT ROUTE] screen will be
displayed.

O The maximum number of waypoints

that can be set is five (5).

Please refer to “Expert mode categories”
on page 5-2.

Edit Route key is se-

5-34 How do I program a destination?

1. Select the

screen.

key on the [EDIT ROUTE]

key or

The [EDIT ROUTE] screen will be displayed.

2. Select a waypoint destination using one
of the destination selection procedures
outlined earlier in the chapter.

INV1010 INV1011

Select the conditions with high priorities.
If you want to get to your destination in

the shortest time, select the

Shortest Time key.

Selecting the key will turn the indicator
light in the key ON, and selecting the key
again will turn the indicator light OFF.

INFO:
O When you select the

point, route calculation will start with­out any additional waypoints.

O Press the PREVIOUS button to display

the [EDIT ROUTE] screen.

OK key at this

O It is also possible to set a waypoint by

selecting the
[DEST. SETTING] screen.

Waypoint key in the

Setting the priorities for route
calculation

After the setting of destinations and way­points is completed, set the calculation
conditions such as route type with high
priorities.

1. Select the

The screen for setting calculation condi­tions will appear. The conditions with the
indicator light ON will have high priority.

INFO:
When the ROUTE button is pressed on

How do I program a destination? 5-35

Priorities key.

the map and the Edit Route key is se­lected, the [EDIT ROUTE] screen will be
displayed.

5-36 How do I program a destination?

INV1012

2. Select the conditions with high priori­ties.
Select each key on the screen to turn
its respective indicator light ON or OFF.

Shortest Time key:

The route to the destination is calculated
so that you can reach the destination in
the shortest time. In some cases, a free­way or toll road with detours may be rec­ommended.

NOTE:

It may not be the shortest time in all
cases.

Shortest Distance key:

The route to the destination is calculated
so that it is the shortest distance.

NOTE:

It may not be the shortest distance in all
cases.

Minimize Toll Road key:

The route to the destination is calculated
with minimum use of toll roads.

Minimize FWY key:

The route to the destination is calculated
with minimum use of freeways.

Use Time Restricted Roads key:

The route using time restricted roads is
calculated.

INV1013 INV1014

When this key is selected and the OK key
is pressed, a confirmation screen will be
displayed.

When the
culation will start.

INFO:
The system considers time restricted roads

as whole-day restricted.

NOTE:

If the “Use Time Restricted Roads” is not
selected, the navigation system calculates
a route without including carpool lanes.

Yes key is pressed, route cal-

The auto reroute function is activated and
recalculates a route including carpool
lanes if both of the following conditions
are met:

O the auto reroute function is turned ON.

O you deviate from the suggested road

and drive in a carpool lane.

With this auto reroute calculation, a sug­gested route including carpool lanes will
be displayed, and the message “The route
has changed to include time restricted
roads. Please be sure to obey traffic regu­lations.” will be displayed on the screen.
Because the suggested route provided at
this time is calculated without taking
regulations and limitations of time re­stricted roads into consideration at all,
please drive safely and follow the actual
roads and regulations when driving.

NOTE:

When driving on a time restricted road, be
sure to obey traffic regulations.

Use Ferry Route key:

Select this key if you prefer routes with
ferry lines.

Route calculation and guidance

After setting all the items required, you
may proceed to route calculation for guid­ance. After the route calculation is com­pleted, the guidance will start automati­cally.

INFO:
When the ROUTE button is pressed on

the map and the
lected, the [EDIT ROUTE] screen will be
displayed.

Select the

Route calc. key.

Edit Route key is se-

How do I program a destination? 5-37

INV1015 INV1016

Route calculation screen will be displayed.
The suggested route will be displayed with

a thick blue line. If you enter this route,
the voice guide will start.

INFO:
O If you want to cancel the route calcula-

tion, press the CANCEL button.

O If you set a place which is not suitable

as a destination, the suggested route
will not be displayed. In such a case,
the

OK key will be displayed on the
screen. Select the
rect destination.

OK key. Reset a cor-

5-38 How do I program a destination?

Enlarged intersection display

The enlarged map will be displayed dur­ing route guidance, unless the Map but­ton is pressed. If the Map button is

pressed after the route guidance has been
set, the display will switch to the ordinary
map, but when the vehicle approaches a
guide point such as an intersection, the
enlarged map will automatically be dis­played. Once you pass the guide point,
the display will return to the ordinary map.

O If route calculation is not possible with

all the set preferences, the system may
look up a route that does not exactly
correspond to the preferences.

O When deleting the settings of destina-

tions or waypoints, press the ROUTE
button.

INV1017 INV1018

INFO:
O When the Map button is pressed right

before the guide point, only the ordi­nary map will be displayed for the
guide point.

O If route numbers are included in the

map data, route numbers will be dis­played on the left side of the screen.

O If street names are displayed in two

lines, route numbers will not be dis­played.

NOTE:
O When the guide point is close to the

guidance start point, the enlarged map
may not be displayed.

O The guide point name may not be dis-

played.

O The position of the vehicle icon on the

enlarged map may differ from the posi­tion on the current display.

1. Press the MAP or PREVIOUS button.
The map screen will appear.

INFO:
To display the enlarged map, press the

MAP button or PREVIOUS button.

2. When the vehicle arrives at the neigh­borhood of the destination, the route
guidance will end automatically.

INFO:
O To alternate between the map and the

enlarged screen, press the MAP but­ton or PREVIOUS button.

O In the map screen, the distance to the

next guide point and the turning direc-

How do I program a destination? 5-39

tion will be displayed on the right side
of the screen.

ADJUSTING AND DELETING THE PRESET
DESTINATION (WAYPOINTS)

Using the joystick, you can adjust the des­tination (waypoints).

1. Press the ROUTE button.

2. Select the

INV1019

Edit Route key.

5-40 How do I program a destination?

INV1020 INV1021 INV1022

3. Choose the destination (waypoints) you
want to adjust on the [EDIT ROUTE]
screen.

4. The map screen will be displayed for
adjusting. Use the joystick to adjust the
location.

INFO:
When you move the joystick, the

Adjust

key will be displayed.

5. Select the

Adjust key.

The new destination (waypoints) will be
set.

How do I program a destination? 5-41

INV1023 INV1024 INV1025

TO DELETE A DESTINATION

1. To delete the destination (waypoint),
choose the destination (waypoint) in
step 3 and select the

Delete key.

5-42 How do I program a destination?

2. Select the
The preset destination (waypoints) will be

deleted.

Yes key.

3. Press the Map button to return to the
map screen.

INFO:
O To set a new destination (waypoints),

refer to “Expert mode categories” or
“Easy mode categories” on page 5-2.

O If you reset the new destination (way-

points), the older destination (way­points) will be deleted. If you have re­quested a route calculation, the
previous suggested route will be de­leted from memory.

ALL CLEAR

INV1019 INV1177 INV1178

The destination and waypoint can be de­leted at one time.

1. Press the ROUTE button.
Several keys will be displayed on the
right of the screen.

Select the

Edit Route key.

2. The [EDIT ROUTE] screen will be dis­played.

Select the

All Clear key.

3. Select the

Yes key.

How do I program a destination? 5-43

QUICK STOP

INV1026 INV1027 INV1028

The system will display pre-defined POIs
(Points of Interest) in the current vicinity
of the vehicle and the distances to them.
These POIs can be gas stations, hotels,
restaurants, ATM’s or customer­programmed facilities. This function will
operate while the vehicle is moving.

1. Press the ROUTE button.
The display shows several keys on the

right of the screen.
Select the

Quick Stop key.

2. The display shows the [QUICK STOP]
screen.

Select the category of your choice.

INFO:
Five categories are displayed on the

screen. The last one can be customized.
When you use a POI category frequently,
it is convenient to use the quick stop func­tion. Please refer to “Quick stop customer
setting” on page 5-45.

3. The cuisine selection screen is dis­played only when the
key is selected. Select the

All key or Fast Food key.

RESTAURANT

5-44 How do I program a destination?

INV1029 INV1030 INV0909

4. The display shows the direction and
distance from the current vehicle posi­tion to the selected facility.

Select the facility name you want to set
as a destination (waypoints).

5. Set route priorities, then select the
OK key. Route calculation to the des-

tination will be started.

INFO:
If quick stop is set after the destination

was set, the system starts the route calcu­lation to the location as the waypoint. Five
waypoints can be registered at the same
time.

QUICK STOP CUSTOMER SETTING

1. Press the SETTING button.

2. Select the
TINGS] screen.

How do I program a destination? 5-45

Navigation key on the [SET-

INV1031 INV1032 INV1033

3. Select the

Quick Stop Customer Settings

key on the [NAVIGATION SETTINGS]
screen.

5-46 How do I program a destination?

4. Select a facility you frequently visit. For
example, select the

INFINITI DEALER

key.
When it is set, the screen returns to the

previous screen.
Press the MAP button to return to the

map.

5. Press the ROUTE button. Then, select
the

Quick Stop key, and press the
ENTER button. The display shows the
selected facility in the last row.

INV1005 INV1034 INV1035

INFO:
When a hospital is set as a destination, a

telephone number of the destination will
be displayed, if available.

WHERE AM I ?

This key is used to find the name of the
street on which the vehicle is currently lo­cated.

1. Press the ROUTE button.
Several keys appear on the right of the

screen. Select the

Where am I ? key.

2. The display shows the [WHERE AM I ?]
screen, which includes the next, cur­rent, and previous streets. Each one
shows the streets which the vehicle is
approaching, currently traveling on, and
those streets the vehicle was previously
traveling on.
Press the MAP or PREVIOUS button
to return to the map.

How do I program a destination? 5-47

MEMO

5-48 How do I program a destination?

6 How do I use the Point of Interest (POI)

feature?

Setting with the Point of Interest (POI) key.... 6-2

Setting with the
Setting with the
Setting with the
Setting with the

Setting with the

POI categories ............................................... 6-14

Setting the nearby display icons .................... 6-15

List key ............................ 6-2

Category key .................... 6-5

State key.......................... 6-8

City key.......................... 6-10

Nearby key..................... 6-12

SETTING WITH THE

Point of Interest (POI)

The keys in Point of Interest (POI) are List,
Category, State/Province, City and Nearby,
and they are explained below.

KEY

1. First press the DEST button.

2. Select the
on the [DEST. SETTING] screen.

Point of Interest (POI) key

INV2337 INV2419

SETTING WITH THE

The List key is used when you know the
exact names of the destinations and way­points.

1. Input the facility name for your destina­tion, then select the

List

KEY

List key.

6-2 How do I use the Point of Interest (POI) feature?

NOTE:

For a quicker search, input the state/
province, city and category before search­ing for your desired destination.

INFO:
If the system detects that the number of

corresponding facilities or cities is five or
less, the display shows the list screen au­tomatically.

INV2420 INV2421

2. The display shows the screen to select
a facility or the

Info key.

When the

Next Search key is selected, it
is possible to narrow down categories,
states/provinces and cities.

To use this function, refer to “Setting with
the

Category key”, “Setting with the

State key” and “Setting with the City

key” on pages 6-5, 6-8 and 6-10.

How do I use the Point of Interest (POI) feature? 6-3

INV2422 INV2423 INV2422

3. When a facility name is selected, the
display shows the [DEST. SETTING
(POI)] screen to set the destination.

To set priorities, select the
Then, the route calculation will be
started.
When you alter the destination or set
waypoints, select the

Please refer to “Making the system
guide the route with detailed options”
on page 5-33.

Waypoint key.

OK key.

O When the

name of your choice is selected in step
2, the display shows the detailed [Ad­dress] and [Telephone number] of the
selected facility, and the

Enter keys.

6-4 How do I use the Point of Interest (POI) feature?

Info key next to the facility

Map and

O When setting the facility as the destina-

tion, select the
shows the [DEST. SETTING (POI)] screen
to set the destination.
Set priorities and select the
Then, the route calculation will be
started.
When you alter the destination or set
waypoints, select the
Please refer to “Making the system
guide the route with detailed options”
on page 5-33.

Enter key. The display

OK key.

Waypoint key.

INV1042 INV2425 INV2426

O When the Map key is selected, the

display shows the map. When the EN­TER button is pressed, the display
shows the

Destination key.

SETTING WITH THE

The Category key is used when you se­lect a facility category to set the destina­tion.

1. Select the

Category key.

Category

KEY

How do I use the Point of Interest (POI) feature? 6-5

2. The display shows the screen to select
categories.
Input a category name.

INV2427 INV2428 INV2429

INFO:
When the

lected in step 2, the history of the previ­ous five settings will be listed.

Last 5 Categories key is se-

3. The display shows the category list.
Select a category name.

INFO:
When the

the screen to input the cuisine type will be
displayed.

6-6 How do I use the Point of Interest (POI) feature?

RESTAURANT key is selected,

4. The screen returns to the [DEST. SET­TING (POI)] screen.
When the category is set, the display
shows the selected category beside the

Category key.

Input the facility name.

INFO:
O If you do not know the facility name

you want to go to, select the
so that the facility names in the cat­egory will be listed in alphabetical or­der.

O It may take some time to show the list,

List key
