Datasheet, V2.6, 25 Dec 2006

CoolSET™-F2

ICE2A0565/165/265/365 ICE2B0565/165/265/365

ICE2A0565G

ICE2A0565Z ICE2A180Z/280Z

ICE2A765I/2B765I ICE2A765P2/2B765P2 ICE2A380P2

Off-Line SMPS Current Mode Controller with integrated 650V/ 800V CoolMOS™

Power Management & Supply

Never stop thinking.

CoolSET™-F2

Revision History: 2006-12-25 Datasheet

Previous Version: 2.5.

Page Subjects (major changes since last revision)

4,17~22, 24~28, 30~31

For questions on technology, delivery and prices please contact the Infineon Technologies Offices in Germany or the Infineon Technologies Companies and Representatives worldwide: see our webpage at http:// www.infineon.com.

CoolMOS™, CoolSET™ are trademarks of Infineon Technologies AG.

Add ICE2A380P2

Edition 2006-12-25

Published by Infineon Technologies AG, St.-Martin-Strasse 53, D-81541 München

Attention please!

The information herein is given to describe certain components and shall not be considered as warranted characteristics.

Terms of delivery and rights to technical change reserved. We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding

circuits, descriptions and charts stated herein. Infineon Technologies is an approved CECC manufacturer.

Information

For further information on technology, delivery terms and conditions and prices please contact your nearest Infineon Technologies Office in Germany or our Infineon Technologies Representatives worldwide (see address list).

Warnings

Due to technical requirements components may contain dangerous substances. For information on the types in question please contact your nearest Infineon Technologies Office.

Infineon Technologies Components may only be used in life-support devices or systems with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system, or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body, or to support and/or maintain and sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other persons may be endangered.

P-TO220-6-46

P-TO220-6-47

Off-Line SMPS Current Mode Controller with integrated 650V/800V CoolMOS™

CoolSET™-F2

Product Highlights

• Best in class in DIP8, DIP7, TO220 and DSO16/12 packages

• No heat-sink required for DIP8, DIP7 and DSO16/12

• Increased creepage distance for TO220, DIP7 and DSO16/12

• Isolated drain for TO220 packages

• Lowest standby power dissipation

• Enhanced protection functions with Auto Restart Mode

• Pb-free lead plating for all packages; RoHS compliant

Features

• 650V/800V avalanche rugged CoolMOS™

• Only few external components required

• Input Vcc Undervoltage Lockout

• 67kHz/100kHz switching frequency

• Max duty cycle 72%

• Low Power Standby Mode to meet European Commission Requirements

• Thermal Shut Down with Auto Restart

• Overload and Open Loop Protection

• Overvoltage Protection during Auto Restart

• Adjustable Peak Current Limitation via external resistor

• Overall tolerance of Current Limiting < ±5%

• Internal Leading Edge Blanking

• User defined Soft Start

• Soft driving for low EMI

Description

The second generation CoolSET™-F2 provides several special enhancements to satisfy the needs for low power standby and protection features. In standby mode frequency reduction is used to lower the power consumption and support a stable output voltage in this mode. The frequency reduction is limited to 20kHz/21.5 kHz to avoid audible noise. In case of failure modes like open loop, overvoltage or overload due to short circuit the device switches in Auto Restart Mode which is controlled by the internal protection unit. By means of the internal precise peak current limitation, the dimension of the transformer and the secondary diode can be sized lower which leads to more cost effective for the overall system.

PG-DIP-7-1

P-DIP-7-1

PG-DIP-8-6

P-DIP-8-4, -6

PG-TO220-6-47PG-TO220-6-46

PG-DSO-16/12

Typical Application

85 ... 270 VAC

SoftS

Soft Start

Feedback

Low Power

StandBy

Soft-Start Control

PWM-Controller

CoolSET™-F2

VCC

Power

Management

Protect ion Unit

Start -up

VCC

PWM Controller

Current Mode

Precise Low Tolerance

Peak Current Li mitati on

Snubber

Dra in

CoolMOS™

Isense

GND

Feedback

Sense

Converter

DC Output

Version 2.6 3 25 Dec 2006

Overview

CoolSET™-F2

Type Package V

OSC

DSon

230VAC ±15%

85-265 VAC

ICE2A0565 PG-DIP-8-6 650V 100kHz 4.7Ω 23W 13W

ICE2A165 PG-DIP-8-6 650V 100kHz 3.0Ω 31W 18W

ICE2A265 PG-DIP-8-6 650V 100kHz 0.9Ω 52W 32W

ICE2A365 PG-DIP-8-6 650V 100kHz 0.45Ω 67W 45W

ICE2B0565 PG-DIP-8-6 650V 67kHz 4.7Ω 23W 13W

ICE2B165 PG-DIP-8-6 650V 67kHz 3.0Ω 31W 18W

ICE2B265 PG-DIP-8-6 650V 67kHz 0.9Ω 52W 32W

ICE2B365 PG-DIP-8-6 650V 67kHz 0.45Ω 67W 45W

ICE2A0565Z PG-DIP-7-1 650V 100kHz 4.7Ω 23W 13W

ICE2A180Z PG-DIP-7-1 800V 100kHz 3.0Ω 29W 17W

ICE2A280Z PG-DIP-7-1 800V 100KHz 0.8Ω 50W 31W

typ @ T=25°C

Maximum power rating at Ta=75°C, Tj=125°C and with copper area on PCB = 6cm²

Type Package V

OSC

DSon

230VAC ±15%

85-265 VAC

ICE2A0565G PG-DSO-16/12 650V 100kHz 4.7Ω 23W 13W

typ @ T=25°C

Maximum power rating at Ta=75°C, Tj=125°C and with copper area on PCB = 6cm²

Type Package V

OSC

DSon

230VAC ±15%

85-265 VAC

ICE2A765I PG-TO-220-6-46 650V 100kHz 0.45Ω 240W 130W

ICE2B765I PG-TO-220-6-46 650V 67kHz 0.45Ω 240W 130W

ICE2A765P2 PG-TO-220-6-47 650V 100kHz 0.45Ω 240W 130W

ICE2B765P2 PG-TO-220-6-47 650V 67kHz 0.45Ω 240W 130W

ICE2A380P2 PG-TO-220-6-47 800V 100kHz 1.89Ω 111W 60W

typ @ T=25°C

Maximum practical continuous power in an open frame design at Ta=75°C, Tj=125°C and R

thCA

=2.7K/W

Version 2.6 4 25 Dec 2006

CoolSET™-F2

Table of Contents Page

1 Pin Configuration and Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

1.1 Pin Configuration with PG-DIP-8-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

1.2 Pin Configuration with PG-DIP-7-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

1.3 Pin Configuration with PG-TO220-6-46/7 . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.4 Pin Configuration with PG-DSO-16/12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.5 Pin Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

2 Representative Blockdiagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.1 Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.2 Improved Current Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.2.1 PWM-OP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.2.2 PWM-Comparator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.3 Soft-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.4 Oscillator and Frequency Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.4.1 Oscillator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.4.2 Frequency Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.5 Current Limiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.5.1 Leading Edge Blanking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.5.2 Propagation Delay Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

3.6 PWM-Latch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

3.7 Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

3.8 Protection Unit (Auto Restart Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

3.8.1 Overload / Open Loop with Normal Load . . . . . . . . . . . . . . . . . . . . . . . .15

3.8.2 Overvoltage due to Open Loop with No Load . . . . . . . . . . . . . . . . . . . . .16

3.8.3 Thermal Shut Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

4 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

4.1 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

4.2 Thermal Impedance (ICE2X765I and ICE2X765P2) . . . . . . . . . . . . . . . . . .20

4.3 Operating Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

4.4 Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

4.4.1 Supply Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

4.4.2 Internal Voltage Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

4.4.3 Control Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

4.4.4 Protection Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

4.4.5 Current Limiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

4.4.6 CoolMOS™ Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

5 Typical Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . .26

6 Layout Recommendation for C

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

7 Outline Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Version 2.6 5 25 Dec 2006

Pin Configuration and Functionality

1 Pin Configuration and Functionality

CoolSET™-F2

1.1 Pin Configuration with PG-DIP-8-6

Pin Symbol Function

1 SoftS Soft-Start

2 FB Feedback

3 Isense Controller Current Sense Input,

CoolMOS™ Source Output

4Drain

5Drain

6 N.C Not connected

7 VCC Controller Supply Voltage

8 GND Controller Ground

at Tj = 110°C

at Tj = 25°C

650V

/800V2) CoolMOS™ Drain

650V

/800V2) CoolMOS™ Drain

1.2 Pin Configuration with PG-DIP-7-1

Pin Symbol Function

1 SoftS Soft-Start

2 FB Feedback

3 Isense Controller Current Sense Input,

CoolMOS™ Source Output

4 N.C. Not connected

5Drain

7 VCC Controller Supply Voltage

8 GND Controller Ground

at Tj = 110°C

at Tj = 25°C

650V

/800V2) CoolMOS™ Drain

Package PG-DIP-8-6

Sof tS

Is ens e

Dr ain

Figure 1 Pin Configuration PG-DIP-8-6 (top view)

GND

VCCFB

N.C

Dr ain

Package PG-DIP-7-1

Sof tS

Is ens e

n.c.

Figure 2 Pin Configuration PG-DIP-7-1 (top view)

GND

VCCFB

Dr ain

Version 2.6 6 25 Dec 2006

CoolSET™-F2

Pin Configuration and Functionality

1.3 Pin Configuration with PG-TO220-6-46/ 7

Pin Symbol Function

1Drain

650V

CoolMOS™ Drain

3 Isense Controller Current Sense Input,

CoolMOS™ Source Output

4 GND Controller Ground

5 VCC Controller Supply Voltage

6 SoftS Soft-Start

7 FB Feedback

at Tj = 110°C

Package PG-TO220-6-46/47

1.4 Pin Configuration with PG-DSO-16/12

Pin Symbol Function

1 N.C. Not Connected

2 SoftS Soft-Start

3 FB Feedback

4 Isense Controller Current Sense Input,

CoolMOS™ Source Output

5Drain

6Drain

7Drain

8Drain

9 N.C. Not Connected

10 N.C. Not Connected

11 VCC Controller Supply Voltage

12 GND Controller Ground

at Tj = 110°C

650V

CoolMOS™ Drain

650V

CoolMOS™ Drain

650V

CoolMOS™ Drain

234567

Drain

Isense

GND

VCC

SoftS

Figure 3 Pin Configuration PG-TO220-6-46/47

(top view)

Package PG-DSO-16/12

N.C

Soft S

Isense

Drain

Figure 4 Pin Configuration PG-DSO-16/12 (top

view)

GND

VCC

N.C

N.C.

Drain

Version 2.6 7 25 Dec 2006

1.5 Pin Functionality

SoftS (Soft Start & Auto Restart Control)

This pin combines the function of Soft Start in case of Start Up and Auto Restart Mode and the controlling of the Auto Restart Mode in case of an error detection.

FB (Feedback)

The information about the regulation is provided by the FB Pin to the internal Protection Unit and to the internal PWM-Comparator to control the duty cycle.

Isense (Current Sense)

The Current Sense pin senses the voltage developed on the series resistor inserted in the source of the integrated CoolMOS™. When Isense reaches the internal threshold of the Current Limit Comparator, the Driver output is disabled. By this means the Over Current Detection is realized.

Furthermore the current information is provided for the PWM-Comparator to realize the Current Mode.

CoolSET™-F2

Pin Configuration and Functionality

Drain (Drain of integrated CoolMOS™)

Pin Drain is the connection to the Drain of the internal CoolMOS

VCC (Power supply)

This pin is the positive supply of the IC. The operating range is between 8.5V and 21V.

To provide overvoltage protection the driver gets disabled when the voltage becomes higher than 16.5V during Start Up Phase.

GND (Ground)

This pin is the ground of the primary side of the SMPS.

Version 2.6 8 25 Dec 2006

2 Representative Blockdiagram

OUT

Converter

DC Output

CoolSET™-F2

Representative Blockdiagram

Sense

Isense

Optocoupler

PWM

Comparator

Error-Latch

0.3V

10k

220ns

Blanking

Leading Edge

csth

67kHz

100kHz

norm

20kHz

21.5kHz

standby

ICE2Bxxxx

Propagation-Delay

Compensation

Current Limiting

Comparator

Current-Limit

ICE2Axxxx

osc

x3.65

0.8V

norm

standby

Standby Unit

Improved Current Mode

PWM OP

Snubber

Drain

CoolMOS™

Gate

Driver

Soft-Start

Soft Start

PWM-Latch

Comparator

Spike

s 5

Blanking

0.72

Duty Cycle Max

norm

-f

max

Clock

Duty Cycle

Voltage

4.8V

4.0V

Reference

standby

Reset

Power-Up

Oscillator

6.5V

5.3V

Internal Bias

Power Management

13.5V

Reset

Lockout

Power-Down

Undervoltage

Line

VCC

8.5V

16.5V

4.0V

6.5V

Soft-Start

SoftS

5.6V

4.8V

5.3V

6.5V

Soft-Start

>140°C

Thermal Shutdown

Protection Unit

GND

CoolSET™-F2

Start-up

85 ... 270 VAC

VCC

Figure 5 Representative Blockdiagram

Version 2.6 9 25 Dec 2006

CoolSET™-F2

Functional Description

3 Functional Description

3.1 Power Management

Main Line (100V-380V)

Start-Up

Primary Winding

VCC

Power Management

SoftS

Soft-Start

Undervoltage

Lockout

8.5V

Power-Down

Reset

Power-Up

Reset

13.5V

6.5V

Soft-Start

Internal

Bias

Voltage

Reference

RSQ

Error-Latch

Soft-Start Comparator

Error-Detection

6.5V

5.3V

4.8V

4.0V

PWM-Latch

3.2 Improved Current Mode

Soft-Start Comparator

PWM-Latch

RSQ

Driver

PWM Comparator

0.8V

PWM OP

x3.65

Isense

Improved Current Mode

Figure 7 Current Mode

Current Mode means that the duty cycle is controlled by the slope of the primary current. This is done by comparison the FB signal with the amplified current sense signal.

Amplified Current Signal

Figure 6 Power Management

The Undervoltage Lockout monitors the external supply voltage V

. In case the IC is inactive the

VCC

current consumption is max. 55µA. When the SMPS is plugged to the main line the current through R charges the external Capacitor C exceeds the on-threshold V

=13.5V the internal bias

CCon

. When V

VCC

Start-up

VCC

0.8V

Driver

circuit and the voltage reference are switched on. After that the internal bandgap generates a reference voltage V

=6.5V to supply the internal circuits. To

REF

avoid uncontrolled ringing at switch-on a hysteresis is implemented which means that switch-off is only after active mode when Vcc falls below 8.5V.

In case of switch-on a Power Up Reset is done by resetting the internal error-latch in the protection unit.

When V

falls below the off-threshold V

VCC

=8.5V the

CCoff

internal reference is switched off and the Power Down reset let T1 discharging the soft-start capacitor C

Soft-Start

at pin SoftS. Thus it is ensured that at every switch-on the voltage ramp at pin SoftS starts at zero.

Figure 8 Pulse Width Modulation

In case the amplified current sense signal exceeds the FB signal the on-time T

of the driver is finished by

resetting the PWM-Latch (see Figure 8). The primary current is sensed by the external series

resistor R

inserted in the source of the integrated

Sense

CoolMOS™. By means of Current Mode regulation, the

Version 2.6 10 25 Dec 2006

secondary output voltage is insensitive on line variations. Line variation changes the current waveform slope which controls the duty cycle.

The external R

allows an individual adjustment of

Sense

the maximum source current of the integrated CoolMOS™.

Soft-Start Comparator

CoolSET™-F2

Functional Description

OSC

max .

Dut y Cy cle

PWM Comparator

PWM-Latch

Oscillator

0.3V C5

OSC

Gate Driver

0.8V

10k

Ω

x3.65

20pF

PWM OP

Voltage Ramp

Figure 9 Improved Current Mode

To improve the Current Mode during light load conditions the amplified current ramp of the PWM-OP is superimposed on a voltage ramp, which is built by the switch T low pass filter composed of R Figure 10). Every time the oscillator shuts down for max. duty cycle limitation the switch T2 is closed by V

. When the oscillator triggers the Gate Driver T2 is

OSC

opened so that the voltage ramp can start. In case of light load the amplified current ramp is to

small to ensure a stable regulation. In that case the Voltage Ramp is a well defined signal for the comparison with the FB-signal. The duty cycle is then controlled by the slope of the Voltage Ramp.

By means of the Comparator C5, the Gate Driver is switched-off until the voltage ramp exceeds 0.3V. It allows the duty cycle to be reduced continuously till 0% by decreasing V

, the voltage source V1 and the 1st order

below that threshold.

and C1(see Figure 9,

Voltage Ramp

0.8V

0.3V

Gate Driver

Figure 10 Light Load Conditions

3.2.1 PWM-OP

The input of the PWM-OP is applied over the internal leading edge blanking to the external sense resistor R

connected to pin Isense. R

Sense

converts the

Sense

source current into a sense voltage. The sense voltage is amplified with a gain of 3.65 by PWM OP. The output of the PWM-OP is connected to the voltage source V1. The voltage ramp with the superimposed amplified current signal is fed into the positive inputs of the PWMComparator, C5 and the Soft-Start-Comparator.

3.2.2 PWM-Comparator

The PWM-Comparator compares the sensed current signal of the integrated CoolMOS signal V

(see Figure 11). VFB is created by an

external optocoupler or external transistor in combination with the internal pull-up resistor R provides the load information of the feedback circuitry. When the amplified current signal of the integrated CoolMOS™ exceeds the signal V Comparator switches off the Gate Driver.

with the feedback

the PWM-

and

Version 2.6 11 25 Dec 2006

CoolSET™-F2

Functional Description

Optocoupler

6.5V

Soft-Start Comparator

PWM-Latch

PWM Comparator

0.8V

PWM OP

Isense

x3.65

Improved Current Mode

pull-up resistor R

. The Soft-Start-Comparator

Soft-Start

compares the voltage at pin SoftS at the negative input with the ramp signal of the PWM-OP at the positive input. When Soft-Start voltage V Feedback voltage V

the Soft-Start-Comparator limits

is less than

SoftS

the pulse width by resetting the PWM-Latch (see Figure 12). In addition to Start-Up, Soft-Start is also activated at each restart attempt during Auto Restart. By means of the above mentioned C

Soft-Start

the SoftStart can be defined by the user. The Soft-Start is finished when V

exceeds 5.3V. At that time the

SoftS

Protection Unit is activated by Comparator C4 and senses the FB by Comparator C3 wether the voltage is below 4.8V which means that the voltage on the secondary side of the SMPS is settled. The internal Zener Diode at SoftS has a clamp voltage of 5.6V to prevent the internal circuit from saturation (see Figure

13).

6.5V

5.6V

SoftS

Power-Up Reset

Soft-Start

Error-Latch

RSQ

Figure 11 PWM Controlling

3.3 Soft-Start

SoftS

5.6V

5.3V

Soft-Start

Gate Driver

6.5V

5.3V

4.8V

RSQ

Gate Driver

Clock

PWM-Latch

Figure 13 Activation of Protection Unit

The Start-Up time T voltage V Start Phase T

is settled must be shorter than the Soft-

OUT

Soft-Start

Soft Start–

-------------------------------------=

Soft Start–

within the converter output

Start-Up

(see Figure 14).

Soft Start–

1.69×

By means of Soft-Start there is an effective minimization of current and voltage stresses on the integrated CoolMOS™, the clamp circuit and the output overshoot and prevents saturation of the transformer during Start-Up.

Figure 12 Soft-Start Phase

The Soft-Start is realized by the internal pull-up resistor R Figure 5). The Soft-Start voltage V charging the external capacitor C

and the external Capacitor C

Soft-Start

is generated by

SoftS

by the internal

Soft-Start

(see

Version 2.6 12 25 Dec 2006

CoolSET™-F2

Functional Description

SoftS

5.3V

Soft-Start

4.8V

OUT

Start-Up

Figure 14 Start Up Phase

3.4 Oscillator and Frequency Reduction

3.4.1 Oscillator

The oscillator generates a frequency f 100kHz. A resistor, a capacitor and a current source and current sink which determine the frequency are integrated. The charging and discharging current of the implemented oscillator capacitor are internally trimmed, in order to achieve a very accurate switching frequency. The ratio of controlled charge to discharge current is adjusted to reach a max. duty cycle limitation of D

=0.72.

max

= 67kHz/

switch

kHz

100

OSC

21.5

1.0

1.1 1.2 1 .3 1. 4 1.5 1. 6 1.7 1.8 1. 9 2.0

norm

21.5kHz

standby

67kHz

20kHz

ICE2 Bxx x xICE2Axxxx

100kHz

Figure 15 Frequency Dependence

3.5 Current Limiting

There is a cycle by cycle current limiting realized by the Current-Limit Comparator to provide an overcurrent detection. The source current of the integrated CoolMOS R

Sense

transformed to a sense voltage V voltage V V

csth

is sensed via an external sense resistor

. By means of R

exceeds the internal threshold voltage

Sense

the source current is

Sense

. When the

Sense

the Current-Limit-Comparator immediately turns off the gate drive. To prevent the Current Limiting from distortions caused by leading edge spikes a Leading Edge Blanking is integrated at the Current Sense. Furthermore a Propagation Delay Compensation is added to support the immediate shut down of the CoolMOS™ in case of overcurrent.

3.5.1 Leading Edge Blanking

Sense

csth

= 220ns

LEB

3.4.2 Frequency Reduction

The frequency of the oscillator is depending on the voltage at pin FB. The dependence is shown in Figure

15. This feature allows a power supply to operate at lower frequency at light loads thus lowering the switching losses while maintaining good cross regulation performance and low output ripple. In case of low power the power consumption of the whole SMPS can now be reduced very effective. The minimal reachable frequency is limited to 20kHz/21.5 kHz to avoid audible noise in any case.

Figure 16 Leading Edge Blanking

Each time when CoolMOS™ is switched on a leading spike is generated due to the primary-side capacitances and secondary-side rectifier reverse recovery time. To avoid a premature termination of the switching pulse this spike is blanked out with a time constant of t

= 220ns. During that time the output of

LEB

Version 2.6 13 25 Dec 2006

CoolSET™-F2

Functional Description

the Current-Limit Comparator cannot switch off the gate drive.

3.5.2 Propagation Delay Compensation

In case of overcurrent detection by I of CoolMOS™ is delayed due to the propagation delay of the circuit. This delay causes an overshoot of the peak current I

which depends on the ratio of dI/dt of

peak

the peak current (see Figure 17). .

the shut down

Limit

Signal2Signal1

peak2

peak1

Limit

Sense

Overshoot2

Propagation Del ay

Overshoot1

Figure 17 Current Limiting

The overshoot of Signal2 is bigger than of Signal1 due to the steeper rising waveform.

A propagation delay compensation is integrated to bound the overshoot dependent on dI/dt of the rising primary current. That means the propagation delay time between exceeding the current sense threshold V

and the switch off of CoolMOS™ is compensated

csth

over temperature within a range of at least.

peak

Sense

------------×

max. Duty Cycle

≤≤

OSC

Sens

--------------

The propagation delay compensation is done by means of a dynamic threshold voltage V

(see Figure

csth

18). In case of a steeper slope the switch off of the driver is earlier to compensate the delay.

E.g. I

= 0.5A with R

peak

= 2. Without propagation

Sense

delay compensation the current sense threshold is set to a static voltage level V dI/dt = 0.4A/µs, that means dV propagation delay time of i.e. t leads then to a I

overshoot of 14.4%. By means of

peak

=1V. A current ramp of

csth

/dt = 0.8V/µs, and a

Sense

Propagation Delay

=180ns

propagation delay compensation the overshoot is only about 2% (see Figure 19).

Sense

without compensation

V/u s

with compensation

1.3

1.25

1.2

1.15

1.1

Sense

1.05

0.95

0.9 0 0. 2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

Figure 19 Overcurrent Shutdown

3.6 PWM-Latch

The oscillator clock output applies a set pulse to the PWM-Latch when initiating CoolMOS™ conduction. After setting the PWM-Latch can be reset by the PWMOP, the Soft-Start-Comparator, the Current-LimitComparator, Comparator C3 or the Error-Latch of the Protection Unit. In case of resetting the driver is shut down immediately.

3.7 Driver

off ti me

Sense

csth

Propagation Delay

Signal1 Signal2

Figure 18 Dynamic Voltage Threshold V

csth

The driver-stage drives the gate of the CoolMOS™ and is optimized to minimize EMI and to provide high circuit

efficiency. This is done by reducing the switch on slope when reaching the CoolMOS™ threshold. This is achieved by a slope control of the rising edge at the driver’s output (see Figure 20) to the CoolMOS™ gate.

Thus the leading switch on spike is minimized. When CoolMOS™ is switched off, the falling shape of the driver is slowed down when reaching 2V to prevent an

overshoot below ground. Furthermore the driver circuit is designed to eliminate cross conduction of the output stage. At voltages below the undervoltage lockout threshold V

the gate drive is active low.

VCCoff

Version 2.6 14 25 Dec 2006

CoolSET™-F2

Functional Description

ca. t = 130ns

Gate

Figure 20 Internal Gate Rising Slope

3.8 Protection Unit (Auto Restart Mode)

An overload, open loop and overvoltage detection is integrated within the Protection Unit. These three failure modes are latched by an Error-Latch. Additional thermal shutdown is latched by the Error-Latch. In case of those failure modes the Error-Latch is set after a blanking time of 5µs and the CoolMOS™ is shut down. That blanking prevents the Error-Latch from distortions caused by spikes during operation mode.

3.8.1 Overload / Open Loop with Normal Load

Figure 21 shows the Auto Restart Mode in case of overload or open loop with normal load. The detection of open loop or overload is provided by the Comparator C3, C4 and the AND-gate G2 (see Figure 22). The detection is activated by C4 when the voltage at pin SoftS exceeds 5.3V. Till this time the IC operates in the Soft-Start Phase. After this phase the comparator C3 can set the Error-Latch in case of open loop or overload which leads the feedback voltage V threshold of 4.8V. After latching VCC decreases till

8.5V and inactivates the IC. At this time the external

Soft-Start capacitor is discharged by the internal transistor T1 due to Power Down Reset. When the IC is inactive V the Capacitor C R

. Then the Error-Latch is reset by Power Up

Start-Up

increases till V

VCC

by means of the Start-Up Resistor

VCC

CCon

Reset and the external Soft-Start capacitor C charged by the internal pull-up resistor R the Soft-Start Phase which ends when the voltage at pin SoftS exceeds 5.3V the detection of overload and open loop by C3 and G2 is inactive. In this way the Start Up Phase is not detected as an overload.

to exceed the

= 13.5V by charging

Soft-Start

. During

Soft-Start

Overload / Open Loop with Normal Load

5µs Blanking

4.8V

Failure

Det ect i on

Soft S

5.3V

Soft-Start Phase

Dri ve r

VCC

13.5V

8.5V

Burst 1

Figure 21 Auto Restart Mode

SoftS

Soft-Start

6.5V

Power Up Reset

Soft-Start

5.3V

4.8V C3

Resta rt

Error-Latch

6.5V

Figure 22 FB-Detection

Version 2.6 15 25 Dec 2006

CoolSET™-F2

Functional Description

But the Soft-Start Phase must be finished within the Start Up Phase to force the voltage at pin FB below the failure detection threshold of 4.8V.

3.8.2 Overvoltage due to Open Loop with No Load

Open loop & no load condition

5µs Blanking

4.8V

Failure

Detection

SoftS

5.3V

4.0V

Driver

Soft-Start Phase

Overvoltage

Detection Phase

Burst2

Restart

normal operation mode is prevented from overvoltage detection due to varying of VCC concerning the regulation of the converter output. When the voltage V

is above 4.0V the overvoltage detection by C1 is

SoftS

deactivated.

VCC

6.5V C1

16.5V

Soft-Start

4.0V

SoftS

Soft-Start

Power Up Reset

Figure 24 Overvoltage Detection

3.8.3 Thermal Shut Down

Error Latch

VCC

16.5V

13.5V

8.5V

Overvoltage Detection

Figure 23 Auto Restart Mode

Figure 23 shows the Auto Restart Mode for open loop and no load condition. In case of this failure mode the converter output voltage increases and also VCC. An additional protection by the comparators C1, C2 and the AND-gate G1 is implemented to consider this failure mode (see Figure 24).The overvoltage detection is provided by Comparator C1 only in the first time during the Soft-Start Phase till the Soft-Start voltage exceeds the threshold of the Comparator C2 at 4.0V and the voltage at pin FB is above 4.8V. When VCC exceeds 16.5V during the overvoltage detection phase C1 can set the Error-Latch and the Burst Phase during Auto Restart Mode is finished earlier. In that case T

is shorter than T

Burst2

. By means of C2 the

Soft-Start

Thermal Shut Down is latched by the Error-Latch when junction temperature T

of the pwm controller is

exceeding an internal threshold of 140°C. In that case the IC switches in Auto Restart Mode.

Note: All the values which are mentioned in the

functional description are typical. Please refer to Electrical Characteristics for min/max limit values.

Version 2.6 16 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4 Electrical Characteristics

4.1 Absolute Maximum Ratings

Note: Absolute maximum ratings are defined as ratings, which when being exceeded may lead to destruction

of the integrated circuit. For the same reason make sure, that any capacitor that will be connected to pin 6 (VCC) is discharged before assembling the application circuit.

Parameter Symbol Limit Values Unit Remarks

min. max.

Drain Source Voltage ICE2A0565/165/265/365/765I/765P2 ICE2B0565/165/265/365/765I/765P2 ICE2A0565G ICE2A0565Z

Drain Source Voltage ICE2A180Z/280Z/380P2

Pulsed drain current,

limited by T

jmax

ICE2A0565/ ICE2B056/ ICE2A0565G/ ICE2A0565Z

ICE2A165/ ICE2B165

ICE2A265/ ICE2B265

ICE2A365/ ICE2B365

ICE2A180Z I

ICE2A280Z I

ICE2A765P2/ ICE2B765P2/ ICE2A765I/ ICE2B765I

D_Puls1

D_Puls2

D_Puls3

D_Puls4

D_Puls5

D_Puls6

D_Puls7

-650VTj = 110°C

-800VTj = 25°C

2.0 A

3.8 A

9.8 A

23.3 A

4.1 A

14.8 A

19.0 A

ICE2A380P2/ I

D_Puls8

5.7 A

Version 2.6 17 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

Parameter Symbol Limit Values Unit Remarks

min. max.

Avalanche energy, repetitive t max. T

Repetitive avalanche causes additional power losses that can be calculated as PAV=EAR* f

limited by

=150°C

ICE2A0565 E

ICE2A165 E

ICE2A265 E

ICE2A365 E

ICE2B0565 E

ICE2B165 E

ICE2B265 E

ICE2B365 E

ICE2A0565G E

ICE2A0565Z E

ICE2A180Z E

ICE2A280Z E

ICE2A765I E

ICE2B765I E

ICE2A765P2 E

ICE2B765P2 E

ICE2A380P2 E

AR1

AR2

AR3

AR4

AR5

AR6

AR7

AR8

AR9

AR10

AR11

AR12

AR13

AR14

AR15

AR16

AR17

-0.01mJ

-0.07mJ

-0.40mJ

-0.50mJ

-0.01mJ

-0.07mJ

-0.40mJ

-0.50mJ

-0.01mJ

-0.07mJ

-0.40mJ

-0.50mJ

-0.06mJ

Version 2.6 18 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

Parameter Symbol Limit Values Unit Remarks

min. max.

Avalanche current, repetitive tAR limited by max. T

=150°C

Supply Voltage V

FB Voltage V

SoftS Voltage V

Sense

Junction Temperature T

Storage Temperature T

Thermal Resistance Junction-Ambient

ESD Robustness

Equivalent to discharging a 100pF capacitor through a 1.5 kΩ series resistor

ICE2A0565 I

ICE2A165 I

ICE2A265 I

ICE2A365 I

ICE2B0565 I

ICE2B165 I

ICE2B265 I

ICE2B365 I

ICE2A0565G I

ICE2A0565Z I

ICE2A180Z I

ICE2A280Z I

ICE2A765I I

ICE2B765I I

ICE2A765P2 I

ICE2B765P2 I

ICE2A380P2 I

AR1

AR2

AR3

AR4

AR5

AR6

AR7

AR8

AR9

AR10

AR11

AR12

AR13

AR14

AR15

AR16

AR17

SoftS

Sense

thJA1

thJA2

thJA3

ESD

-0.5A

-1A

-2A

-3A

-0.5A

-1A

-2A

-3A

-0.5A

-1A

-2A

-7A

-2.4A

-0.3 22 V

-0.3 6.5 V

-0.3 3 V

-40 150 °C Controller & CoolMOS™

-50 150 °C

- 90 K/W PG-DIP-8-6

- 96 K/W PG-DIP-7-1

- 110 K/W P-DSO-16/12

-22)kV Human Body Model

1kV at pin drain of ICE2x0565, ICE2A0565Z and ICE2A0565G

Version 2.6 19 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4.2 Thermal Impedance (ICE2X765I and ICE2X765P2)

Parameter Symbol Limit Values Unit Remarks

min. max.

Thermal Resistance Junction-Ambient

ICE2A765I ICE2B765I

thJA4

- 74 K/W Free standing with no heat-sink

ICE2A765P2 ICE2B765P2

ICE2A380P2 R

Junction-Case ICE2A765I

thJA5

thJC1

-82K/W

-2.5K/W

ICE2B765I ICE2A765P2 ICE2B765P2

ICE2A380P2 R

thJC2

-2.86K/W

4.3 Operating Range

Note: Within the operating range the IC operates as described in the functional description.

Parameter Symbol Limit Values Unit Remarks

min. max.

Supply Voltage V

Junction Temperature of Controller

JCon

CCoff

21 V

-25 130 °C Limited due to thermal shut down of controller

Junction Temperature of

JCoolMOS

-25 150 °C

CoolMOS™

Version 2.6 20 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4.4 Characteristics

Note: The electrical characteristics involve the spread of values given within the specified supply voltage and

junction temperature range T are related to 25°C. If not otherwise stated, a supply voltage of V

4.4.1 Supply Section

Parameter Symbol Limit Values Unit Test Condition

from – 25 °C to 125 °C.Typical values represent the median values, which

= 15 V is assumed.

min. typ. max.

Start Up Current I

Supply Current with Inactive Gate

Supply Current with Active Gate

ICE2A0565 I

ICE2A165 I

ICE2A265 I

ICE2A365 I

ICE2B0565 I

ICE2B165 I

ICE2B265 I

ICE2B365 I

ICE2A0565G I

ICE2A0565Z I

ICE2A180Z I

ICE2A280Z I

Supply Current with Active Gate

ICE2A765I I

ICE2B765I I

ICE2A765P2 I

ICE2B765P2 I

ICE2A380P2 I

VCC Turn-On Threshold VCC Turn-Off Threshold VCC Turn-On/Off Hysteresis

VCC1

VCC2

VCC3

VCC4

VCC5

VCC6

VCC7

VCC8

VCC9

VCC10

VCC11

VCC12

VCC13

VCC14

VCC15

VCC16

VCC17

VCC18

VCC19

CCon

CCoff

CCHY

-2755µAVCC=V

-5.06.6mAV

-5.36.7mAV

-6.57.8mA

SoftS

= 0

-6.78.0mA

-8.59.8mA

-5.26.7mA

-5.57.0mA

-6.17.3mA

-7.18.3mA

-5.36.7mA

-6.57.8mA

-7.79.0mA

-8.59.8mAV

-7.18.3mA

SoftS

= 0

-8.59.8mA

-7.18.3mA

-6.78.0mA

4.5

13.5

8.5 5

5.5

V V V

CCon

= 0

= 5V

-0.1V

Version 2.6 21 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4.4.2 Internal Voltage Reference

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Trimmed Reference Voltage V

REF

6.37 6.50 6.63 V measured at pin FB

4.4.3 Control Section

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Oscillator Frequency ICE2A0565/165/265/365/765I/765P2 ICE2A0565G/0565Z/180Z/280Z/380P2

Oscillator Frequency ICE2B0565/165/265/365/765I/765P2

Reduced Osc. Frequency ICE2A0565/165/265/365/765I/765P2 ICE2A0565G/0565Z/180Z/280Z/380P2

Reduced Osc. Frequency ICE2B0565/165/265/365/765I/765P2

Frequency Ratio f

osc1/fosc2

ICE2A0565/165/265/365/765I/765P2 ICE2A0565G/0565Z/180Z/280Z/380P2

Frequency Ratio f

osc3/fosc4

ICE2B0565/165/265/365/765I/765P2

OSC1

OSC3

OSC2

OSC4

93 100 107 kHz VFB = 4V

62 67 72 kHz VFB = 4V

-21.5-kHzVFB = 1V

-20-kHzVFB = 1V

4.5 4.65 4.9

3.18 3.35 3.53

Max Duty Cycle D

Min Duty Cycle D

PWM-OP Gain A

Operating Range Min Level V

Operating Range Max level V

Feedback Resistance R

Soft-Start Resistance R

max

min

FBmin

FBmax

Soft-Start

0.67 0.72 0.77

0- - VFB < 0.3V

3.45 3.65 3.85

0.3 - - V

--4.6V

3.0 3.7 4.9 kΩ

42 50 62 kΩ

Version 2.6 22 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4.4.4 Protection Unit

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Over Load & Open Loop

FB2

4.65 4.8 4.95 V V

SoftS

> 5.5V

Detection Limit

Activation Limit of Overload &

SoftS1

5.15 5.3 5.46 V VFB > 5V

Open Loop Detection

Deactivation Limit of Overvoltage Detection

Overvoltage Detection Limit V

Latched Thermal Shutdown T

Spike Blanking t

The parameter is not subject to production test - verified by design/characterization

Spike

SoftS2

VCC1

jSD

3.88 4.0 4.12 V VFB > 5V

> 17.5V

16 16.5 17.2 V V

130 140 150 °C

SoftS

> 5V

< 3.8V

-5-µs

4.4.5 Current Limiting

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Peak Current Limitation (incl. Propagation Delay Time)

csth

0.95 1.0 1.05 V dV

/ dt = 0.6V/µs

sense

Leading Edge Blanking t

LEB

-220-ns

Version 2.6 23 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

4.4.6 CoolMOS™ Section

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Drain Source Breakdown Voltage ICE2A0565/165/265/365/765I/765P2 ICE2B0565/165/265/365/765I/765P2 ICE2A0565G/0565Z

Drain Source Breakdown Voltage ICE2A180Z/280Z/380P2

Drain Source

ICE2A0565 R

On-Resistance

ICE2A165 R

ICE2A265 R

ICE2A365 R

ICE2B0565 R

ICE2B165 R

ICE2B265 R

ICE2B365 R

ICE2A0565G R

ICE2A0565Z R

ICE2A180Z R

ICE2A280Z R

ICE2A765I R

ICE2B765I R

ICE2A765P2 R

ICE2B765P2 R

ICE2A380P2 R

(BR)DSS

DSon1

DSon2

DSon3

DSon4

DSon5

DSon6

DSon7

DSon8

DSon9

DSon10

DSon11

DSon12

DSon13

DSon14

DSon15

DSon16

DSon17

600 650

800 870

4.7

10.0

6.6

0.9

1.9

0.45

0.95

4.7

10.0

6.6

0.9

1.9

0.45

0.95

4.7

10.0

4.7

10.0

6.6

0.8

1.7

0.45

0.95

0.45

0.95

0.45

0.95

0.45

0.95

1.89

4.15

5.5

12.5

3.3

7.3

1.08

2.28

0.54

1.14

5.5

12.5

3.3

7.3

1.08

2.28

0.54

1.14

5.5

12.5

5.5

12.5

3.3

7.3

1.06

2.04

0.54

1.14

0.54

1.14

0.54

1.14

0.54

1.14

2.27

4.98

V V

Ω Ω

Tj=25°C T

=110°C

Tj=25°C T

=110°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Tj=25°C T

=125°C

Version 2.6 24 25 Dec 2006

CoolSET™-F2

Electrical Characteristics

Parameter Symbol Limit Values Unit Test Condition

min. typ. max.

Effective output capacitance, energy related

Zero Gate Voltage Drain Current I

Rise Time t

Fall Time t

Measured in a Typical Flyback Converter Application

ICE2A0565 C

ICE2A165 C

ICE2A265 C

ICE2A365 C

ICE2B0565 C

ICE2B165 C

ICE2B265 C

ICE2B365 C

ICE2A0565G C

ICE2A0565Z C

ICE2A180Z C

ICE2A280Z C

ICE2A765I C

ICE2B765I C

ICE2A765P2 C

ICE2B765P2 C

ICE2A380P2 C

o(er)1

o(er)2

o(er)3

o(er)4

o(er)5

o(er)6

o(er)7

o(er)8

o(er)9

o(er)10

o(er)11

o(er)12

o(er)13

o(er)14

o(er)15

o(er)16

o(er)17

DSS

rise

fall

-4.751-pFVDS =0V to 480V

-7-pF

-21-pF

-30-pF

-4.751-pF

-7-pF

-21-pF

-30-pF

-4.751-pF

-7-pF

-22-pF

-30-pF

-16.8-pF

-0.5-µAV

-30

-ns

VCC

=0V

-301)-ns

Version 2.6 25 25 Dec 2006

5 Typical Performance

Characteristics

CoolSET™-F2

Typical Performance Characteristics

[µA]

VCC1

Start Up Current I

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 25 Start Up Current I

5,9

5,7

5,5

[mA]

VCC2

5,3

5,1

4,9

Supply Current I

4,7

4,5

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

VCC1

vs. T

Junction Temperature [°C]

Figure 26 Static Supply Current I

VCC2

vs. T

PI-001-190101

7,1

6,9

6,7

6,5

[mA]

6,3

VCCi

6,1

5,9

5,7

5,5

5,3

5,1

Supply Current I

4,9

4,7

4,5

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2B365

ICE2B165

ICE2B265

PI-002-190101

ICE2B0565

Junction Temperature [°C]

Figure 28 Supply Current I

8,5

8,3

8,1

7,9

7,7

[mA]

7,5

7,3

VCCi

7,1

6,9

PI-003-190101

6,7

6,5

6,3

6,1

Supply Current I

5,9

5,7

5,5

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A180Z

VCCI

vs. T

ICE2A280Z

PI-002-190101

Junction Temperature [°C]

Figure 29 Supply Current I

VCCI

vs. T

8.9

8.8

8.4

8.0

7.6

[mA]

7.2

VCCi

6.8

6.4

6.0

5.6

5.2

4.8

Supply Current I

4.4

4.0

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A165

ICE2A0565/G/Z

/G/Z

ICE2A365

Junction Temperature [°C]

Figure 27 Supply Current I

VCCI

vs. T

ICE2A265

PI-002-190101

8.7

8.5

8.3

8.1

[mA]

7.9

7.7

VCCi

7.5

7.3

7.1

6.9

6.7

6.5

Supply Current I

6.3

6.1

5.9

-25-15-5 5 152535455565758595105115125

ICE2A765P2

ICE2B765P2

ICE2A380P2

Junction Temperature [°C]

Figure 30 Supply Current I

VCCI

vs. T

Version 2.6 26 25 Dec 2006

PI-002-190101

CoolSET™-F2

Typical Performance Characteristics

13,58

13,56

[V]

13,54

CCon

13,52

13,50

13,48

13,46

13,44

VCC Turn-On Threshold V

13,42

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 31 VCC Turn-On Threshold V

8,67

8,64

[V]

8,61

VCCoff

8,58

8,55

8,52

8,49

8,46

8,43

VCC Turn-Off Threshold V

8,40

-25-15-5 5 152535455565758595105115125

CCon

Junction Temperature [°C]

vs. T

6,510

[V]

6,505

REF

6,500

6,495

PI-004-190101

6,490

6,485

6,480

6,475

6,470

Trimmed Reference Voltage V

-25-15-5 5 152535455565758595105115125

PI-007-190101

Junction Temperature [°C]

Figure 34 Trimmed Reference V

102.0

101.5

101.0

[kHz]

100.5

OSC1

100.0

PI-005-190101

99.5

99.0

98.5

98.0

97.5

Oscillator Frequency f

97.0

-25-15-5 5 152535455565758595105115125

ICE2A0565/G/Z ICE2A165 ICE2A265 ICE2A365 ICE2A180Z ICE2A280Z ICE2A765P2 ICE2A380P2

REF

vs. T

PI-008-190101

Junction Temperature [°C]

Figure 32 VCC Turn-Off Threshold V

5,10

[V]

5,07

CCHY

5,04

5,01

4,98

4,95

4,92

4,89

4,86

4,83

VCC Turn-On/Off Hysteresis V

-25-15-5 5 1525354555657585 95105115125

VCCoff

Junction Temperature [°C]

Figure 33 VCC Turn-On/Off Hysteresis V

vs. T

VCCHY

vs. T

Figure 35 Oscillator Frequency f

70,0

69,5

69,0

[kHz]

68,5

68,0

OSC3

67,5

PI-006-190101

67,0

66,5

66,0

65,5

65,0

64,5

Oscillator Frequency f

64,0

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 36 Oscillator Frequency f

ICE2B0565 ICE2B165 ICE2B265 ICE2B365 ICE2B765P2

OSC1

OSC3

vs. T

PI-008a-190101

Version 2.6 27 25 Dec 2006

CoolSET™-F2

Typical Performance Characteristics

22.0

21.8

[kHz]

21.6

OSC2

21.4

21.2

21.0

20.8

20.6

20.4

20.2

Reduced Osc. Frequency f

20.0

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A0565/G/Z ICE2A165 ICE2A265 ICE2A365 ICE2A180Z ICE2A280Z ICE2A765P2 ICE2A380P2

Junction Temperature [°C]

Figure 37 Reduced Osc. Frequency f

21,0

20,8

[kHz]

20,6

OSC4

20,4

20,2

20,0

19,8

19,6

19,4

19,2

Reduced Osc. Frequency f

19,0

-25-15-5 5 152535455565758595105115125

ICE2B0565 ICE2B165 ICE2B265 ICE2B365 ICE2B765P2

OSC2

Junction Temperature [°C]

vs. T

3,45

3,43

3,41

OSC4

3,39

ICE2B0565 ICE2B165 ICE2B265 ICE2B365 ICE2B765P2

PI-010a-190101

PI-009-190101

Frequency Ratio f

OSC3

3,37

3,35

3,33

3,31

3,29

3,27

3,25

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 40 Frequency Ratio f

0,730

0,728

0,726

0,724

0,722

0,720

PI-009a-190101

0,718

0,716

Max. Duty Cycle

0,714

0,712

0,710

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

OSC3

/ f

OSC4

vs. T

PI-011-190101

Junction Temperature [°C]

Figure 38 Reduced Osc. Frequency f

4.75

4.73

4.71

OSC2

4.69

OSC1

4.67

4.65

4.63

4.61

4.59

Frequency Ratio f

4.57

4.55

-25-15-5 5 152535455565758595105115125

ICE2A0565/G/Z ICE2A165 ICE2A265 ICE2A365 ICE2A180Z ICE2A280Z ICE2A765P2 ICE2A380P2

OSC4

Junction Temperature [°C]

Figure 39 Frequency Ratio f

OSC1

/ f

OSC2

vs. T

Figure 41 Max. Duty Cycle vs. T

3,70

3,69

3,68

3,67

3,66

PI-010-190101

3,65

3,64

3,63

PWM-OP Gain A

3,62

3,61

3,60

-25-15-5 5 152535455565758595105115125

PI-012-190101

Junction Temperature [°C]

Figure 42 PWM-OP Gain AV vs. T

Version 2.6 28 25 Dec 2006

CoolSET™-F2

Typical Performance Characteristics

4,00

3,95

3,90

[kOhm]

3,85

3,80

3,75

3,70

3,65

3,60

3,55

Feedback Resistance R

3,50

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 43 Feedback Resistance RFB vs. T

[kOhm]

Soft-Start

Soft-Start Resistance R

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

5,320

5,315

5,310

[V]

5,305

5,300

Soft-Start1

PI-013-190101

5,295

5,290

5,285

5,280

Detection Limit V

5,275

5,270

-25-15-5 5 152535455565758595105115125

PI-016-190101

Junction Temperature [°C]

Figure 46 Detection Limit V

4,05

4,04

4,03

[V]

4,02

4,01

Soft-Start2

PI-014-190101

4,00

3,99

3,98

3,97

Detection Limit V

3,96

3,95

-25-15-5 5 152535455565758595105115125

Soft-Start1

vs. T

PI-017-190101

Junction Temperature [°C]

Figure 44 Soft-Start Resistance R

4,810

4,805

[V]

4,800

FB2

4,795

4,790

Detection Limit V

4,785

4,780

-25-15-5 5 152535455565758595105115125

Soft-Start

Junction Temperature [°C]

Figure 45 Detection Limit V

FB2

vs. T

Figure 47 Detection Limit V

16,80

16,75

[V]

16,70

VCC1

16,65

16,60

16,55

PI-015-190101

16,50

16,45

16,40

16,35

16,30

16,25

16,20

Overvoltage Detection Limit V

-25-15-5 5 152535455565758595105115125

Soft-Start2

vs. T

PI-018-190101

Junction Temperature [°C]

Figure 48 Overvoltage Detection Limit V

VCC1

vs. T

Version 2.6 29 25 Dec 2006

CoolSET™-F2

Typical Performance Characteristics

1,010

1,008

[V]

1,006

csth

1,004

1,002

1,000

0,998

0,996

0,994

0,992

Peak Current Limitation V

0,990

-25-15-5 5 152535455565758595105115125

Junction Temperature [°C]

Figure 49 Peak Current Limitation V

280

270

[ns]

260

LEB

250

240

230

220

210

200

190

Leading Edge Blanking t

180

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

csth

Junction Temperature [°C]

vs. T

2,2

2,0

1,8

[Ohm]

1,6

dson

1,4

PI-019-190101

1,2

1,0

0,8

On-Resistance R

0,6

0,4

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A265 ICE2B265

PI-022-190101

ICE2A280Z

Junction Temperature [°C]

Figure 52 Drain Source On-Resistance R

ICE2A0565/G/Z ICE2B0565

PI-020-190101

[Ohm]

dson

On-Resistance R

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A165 ICE2B165 ICE2A180Z

DSon

ICE2A380P2

vs. T

PI-022-190101

Junction Temperature [°C]

Figure 50 Leading Edge Blanking V

1,0

0,9

0,8

[Ohm]

0,7

dson

0,6

0,5

0,4

On-Resistance R

0,3

0,2

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A365 ICE2B365

VCC1

Junction Temperature [°C]

Figure 51 Drain Source On-Resistance R

vs. T

DSon

vs. T

Figure 53 Drain Source On-Resistance R

1,0

0,9

0,8

[Ohm]

0,7

dson

PI-022-190101

0,6

0,5

0,4

On-Resistance R

0,3

0,2

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A765P2 ICE2B765P2

Junction Temperature [°C]

Figure 54 Drain Source On-Resistance R

DSon

vs. T

PI-022-190101

Version 2.6 30 25 Dec 2006

720

700

[V]

680

(BR)DSS

660

/G/Z

ICE2A0565/G/Z

640

620

600

580

Breakdown Voltage V

560

-25 -15 -5 5 15 25 35 45 55 65 75 85 95 105 115 125

ICE2A165 ICE2A265 ICE2A365 ICE2B0565 ICE2B165 ICE2B265 ICE2B365 ICE2A765P2 ICE2B765P2

Junction Temperature [°C]

CoolSET™-F2

Typical Performance Characteristics

PI-025-190101

Figure 55 Breakdown Voltage V

940

[V]

920

900

(BR)DSS

880

860

840

820

800

Breakdown Voltage V

780

-25-15-5 5 152535455565758595105115125

ICE2A180Z ICE2A280Z ICE2A380P2

BR(DSS)

vs. T

Junction Temperature [°C]

Figure 56 Breakdown Voltage V

BR(DSS)

vs. T

PI-025-190101

Version 2.6 31 25 Dec 2006

CoolSET™-F2

6 Layout Recommendation for C

Note: Only for ICE2A765I/P2 and ICE2B765I/P2

Soft Start Capacitor Layout Recommendation in Detail

Detail X

Layout Recommendation for C

Figure 57A Layout of Board EVALSF2_ICE2B765P2

To improve the startup behavior of the IC during

startup or auto restart mode, place the soft start

capacitor C

as close as possible to the soft start PIN 6 and

GND PIN 4. More details see Detail X in Figure

57B.

(red section Detail X in Figure 57A)

Figure 57B Detail X, Soft Start Capacitor C18 Layout

Recommendation

Place Soft Start capacitor C18 in the same way as

shown in Detail X (blue mark).

Figure 57 Layout Recommendation for ICE2A765I/P2 and ICE2B765I/P2

Version 2.6 32 25 Dec 2006

7 Outline Dimension

PG-DIP-8-6 (Plastic Dual In-line Package)

CoolSET™-F2

Outline Dimension

Figure 58 PG-DIP-8-6 (Plastic Dual In-line Package)

PG-DIP-7-1 (Plastic Dual In-line Package)

1.7 MAX.

±0.1

0.46

9.52

Index Marking

Does not include plastic or metal protrusion of 0.25 max. per side

±0.25

2.54

0.35

0.38 MIN.

3.25 MIN.

4.37 MAX.

7.87

8.9

±0.38

±1

0.25

6.35

+0.1

±0.25

Figure 59 PG-DIP-7-1 (Plastic Dual In-line Package)

Dimensions in mm

Version 2.6 33 25 Dec 2006

CoolSET™-F2

4.4

9.9

12.1

e t.

9.9

17.5

Outline Dimension

PG-TO220-6-46 Isodrain Package

±0.3

10.2

0...0.15

Figure 60 PG-TO220-6-46 (Isodrain Package)

4 x 1.27

7.5

6.6

7.62

(0.8)

±0.3

8.6

6 x 0.6

+0.1

1.3

-0.02

0.05

0.25 AMB

±0.2

9.2

0.5

±0.1

2.4

±0.1

5.3

±0.3

8.4

±0.3

1) Shear and punch direction no burrs this surfac Back side, heatsink contour All metal surfaces tin plated, except area of cu

PG-TO220-6-47 Isodrain Package

±0.3

15.6

0...0.15

1.274 x

9.5

7.5

6.6

7.62

±0.2 ±0.2

±0.2

2.8

±0.3

8.6

6 x 0.6

4.4

+0.1

1.3

-0.02

-0.15

3.7

0.25 AMB

0.05

±0.2

9.2

0.5

±0.1

2.4

±0.1

5.3

±0.3

8.4

±0.3

1) Shear and punch direction no burrs this surfac Back side, heatsink contour All metal surfaces tin plated, except area of cu

Figure 61 PG-TO220-6-47 (Isodrain Package)

Dimensions in mm

Version 2.6 34 25 Dec 2006

PG-DSO-16/12 (Plastic Dual Small Outline Package)

CoolSET™-F2

Outline Dimension

Figure 62 PG-DSO-16/12 (Plastic Dual Small Outline Package)

Dimensions in mm

Version 2.6 35 25 Dec 2006

Total Quality Management

Qualität hat für uns eine umfassende Bedeutung. Wir wollen allen Ihren Ansprüchen in der bestmöglichen Weise gerecht werden. Es geht uns also nicht nur um die Produktqualität – unsere Anstrengungen gelten gleichermaßen der Lieferqualität und Logistik, dem Service und Support sowie allen sonstigen Beratungs- und Betreuungsleistungen.

Dazu gehört eine bestimmte Geisteshaltung unserer Mitarbeiter. Total Quality im Denken und Handeln gegenüber Kollegen, Lieferanten und Ihnen, unserem Kunden. Unsere Leitlinie ist jede Aufgabe mit „Null Fehlern“ zu lösen – in offener Sichtweise auch über den eigenen Arbeitsplatz hinaus – und uns ständig zu verbessern.

Unternehmensweit orientieren wir uns dabei auch an „top“ (Time Optimized Processes), um Ihnen durch größere Schnelligkeit den entscheidenden Wettbewerbsvorsprung zu verschaffen.

Geben Sie uns die Chance, hohe Leistung durch umfassende Qualität zu beweisen.

Wir werden Sie überzeugen.

Quality takes on an allencompassing significance at Semiconductor Group. For us it means living up to each and every one of your demands in the best possible way. So we are not only concerned with product quality. We direct our efforts equally at quality of supply and logistics, service and support, as well as all the other ways in which we advise and attend to you.

Part of this is the very special attitude of our staff. Total Quality in thought and deed, towards co-workers, suppliers and you, our customer. Our guideline is “do everything with zero defects”, in an open manner that is demonstrated beyond your immediate workplace, and to constantly improve.

Throughout the corporation we also think in terms of Time Optimized Processes (top), greater speed on our part to give you that decisive competitive edge.

Give us the chance to prove the best of performance through the best of quality – you will be convinced.

http://www.infineon.com

Published by Infineon Technologies AG

INFINEON ICE2A0565, ICE2A165, ICE2A265, ICE2A365, ICE2B0565 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
