DMA

Direct Memory Access

AURIX™ TC2xx Microcontroller Training V1.0 2019-03

Please read the Important Notice and Warnings at the end of this document

DMA

Direct Memory Access

Key Features Customer Benefits

Highlights

› The DMA moves data from source

locations to destination locations without the intervention of the CPU or other on chip devices.

› Up to 128 individually programmable

DMA channels

Flexible DMA channels requests

DMA double buffering

› Possible configuration of the request

type (SW, HW, Auto, ..) per DMA channel

› Transfer continuous data stream to two

destination buffers

› Perform multi DMA transactions from

non contiguous Memory regions

DMA Controller

Interrupt Router

DMARAM:

- DMA Channels

Transaction Control Sets

Bus Master Interface

DMA

Request &

Arbitration

DMA Sub-block:

- Active DMA Channel

- DMA Move Engines

Bus Slave Interface

On Chip Bus

DMA linked list

DMA

Flexible DMA channels requests

› The DMA Channel supports the following types of requests:

– DMA Software Request: initiated by CPU

– DMA Hardware Request: Any peripheral that can trigger an interrupt

can initiate a DMA transaction through the Interrupt Router

– DMA Daisy Chain Request: DMA transaction initiated by the next

higher priority DMA channel

– DMA Auto Start Request: initiated by the loading of the next

Transaction Control Set (TCS) during a DMA Linked List operation

DMA

DMA double buffering

› Double buffer could be selected for source or destination buffering › The application is able to freeze one of the destination buffers for cyclic

software tasks while the other buffer continues to be filled

DMA

Write Moves

On Chip bus

DMA Read Moves

D5 D4

D3 D2 D1 D0

D0 D1 D2 D3 D4 D5

Continuous

Data Stream

Switch

Double Destination Buffering

DMA

DMA linked list

› A linked list operation consists of a series of DMA transactions executed

by the same DMA channel. Each DMA transaction has an unique configuration Set

› If the Auto start request is selected, a DMA transaction will be triggered

after the end of the previous one in the list  no HW or SW trigger is needed

› DMA linked are useful when user wants to transfer data from/to non

contiguous memory locations using one DMA channel and/or one

service request

DMA Transaction 1

• Source @1

• Destination @1

• Data Length 1

DMA Transaction 2

• Source @2

• Destination @2

• Data Length 2

DMA Transaction N

• Source @N

• Destination @N

• Data Length 1

Auto Start

...

Auto

Start

Auto Start

DMA

System integration

› The DMA is connected to both SRI and SPB with master interfaces › This enables the DMA to read and write data from/to any module

DMA

System Peripheral Bus

SRI Cross Bar Interconnect

Master

Interface

CPUs, RAM, Flash

Peripherals

Master Interface

Slave Interface

Application example

DMA hardware requests

› In this example, data is transferred from the ADC output registers to

internal memory without any CPU intervention

DMA

ADC

Interrupt

Router

RAM

1. End of ADC conversion interrupt

2. Trigger a DMA channel transfer

3. Read ADC result register

4. Write data to RAM
