Indesit KP900CX User Manual
Operating Instructions
Contents
GB
Installation, 2-3
English,2
KP900CX
Positioning and levelling
Electrical connection
Table of characteristics
Description of the appliance, 4
Overall view
Control panel
Start-up and use, 5-7
Setting the time
Using the oven
Cooking modes for Multi-function (1rst Oven)
Cooking modes for conventional-function (2nd Oven)
Practical cooking advice
Oven cooking advice table
COOKER AND OVEN
GB
Using the glass ceramic hob, 10
Precautions and tips, 11
General safety
Disposal
Respecting and conserving the environment
Care and maintenance, 12
Switching the appliance off
Cleaning the appliance
Replacing the oven light bulb
Cleaning the glass ceramic hob
Assistance
Installation
GB
! Before operating your new appliance please read
this instruction booklet carefully. It contains
important information concerning the safe installation
and operation of the appliance.
! Please keep these operating instructions for future
reference. Make sure that the instructions are kept
with the appliance if it is sold, given away or moved.
! The appliance must be installed by a qualified
professional according to the instructions provided.
! Any necessary adjustment or maintenance must be
performed after the cooker has been disconnected
from the electricity supply.
Positioning and levelling
! It is possible to install the appliance alongside
cupboards whose height does not exceed that of the
hob surface.
! Make sure that the wall in contact with the back of
the appliance is made from a non-flammable, heatresistant material (T 90°C).
To install the appliance correctly:
• Place it in the kitchen, the dining room or the bedsit (not in the bathroom).
• If the top of the hob is higher than the cupboards,
the appliance must be installed at least 600 mm
away from them.
• If the cooker is
HOOD
Min. mm.
900
mm.
420
Min.
• Do not position blinds behind the cooker or less
than 200 mm away from its sides.
• Any hoods must be installed according to the
instructions listed in the relevant operating manual.
installed underneath a
wall cabinet, there must
be a minimum distance
of 420 mm between this
mm. with hood
cabinet and the top of
mm. without hood
420
650
700
the hob.
Min. mm.
min.
min.
This distance should be
increased to 700 mm if
the wall cabinets are
flammable (see figure).
Levelling
If it is necessary to level the
appliance, screw the
adjustable feet into the places
provided on each corner of the
base of the cooker (see
figure).
The legs* fit into the slots on
the underside of the base of
the cooker.
Electrical connection
WARNING – THIS APPLIANCE MUST BE
EARTHED.
The appliance is designed to work with alternating
current at the supply voltage and frequency indicated
on the rating plate (situated on the rear part of the
appliance and on the last page of the instruction
booklet) or at the end of the instruction booklet. Make
sure that the local supply voltage corresponds to the
voltage indicated on the rating plate.
To connect directly to the mains supply, a doublepole switch with a contact separation of at least 3
mm suitable for the load and complying with current
standards and regulations, must be fitted between
the appliance and the mains supply outlet. The
yellow-green earth wire must not be interrupted by
the switch. The supply cable must be in such a
position that no part of it can reach a temperature of
50 °C above room temperature. Do not use adapters
or shunts as they could cause heating or burning.
Before connecting to the power supply, make sure
that:
• the limiter valve and the domestic system can
withstand the load from the appliance (see rating
plate);
• the supply system is efficiently earthed according
to standards and laws in force;
• the socket or double-pole switch are easily
accessible when the appliance is installed.
FAILURE TO OBSERVE THE ACCIDENTPREVENTION REGULATIONS RELIEVES THE
MANUFACTURER OF ALL LIABILITY.
Important: the wires in the mains lead are coloured
in accordance with the following code:
2
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the mains lead may not
correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
Connect the Green & Yellow wire to terminal marked
“E” or
Connect the Brown wire to the terminal marked “L” or
coloured Red.
Connect the Blue wire to the terminal marked “N” or
coloured Black.
Replacing the cable
Use a rubber cable of the type H07RN-F with a
suitable cross section 3 x 6 mm².
The yellow-green earth wire must be 2-3 cm longer
than the other wires.
or coloured Green or Green & Yellow.
GB
TECHNICAL DATA (1st Oven )
Oven dimensions
Volume
Voltage and frequency see data plate
ENERGY LABEL
H:34;W:38;D:44 cm
54 Lt
Directive 2002/40/EC on the
label of electric ovens.
Regulation EN 50304
Energy consumption for Natural
convection – heating mode:
Traditional mode
Declared energy consumption
for Forced convection Class –
heating mode:
Multi cooking Mode.
EC Directives: 2006/95/EEC
dated 12/12/06 (Low Voltage)
and subsequent amendments 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent amendments 93/68/EEC dated 22/07/93 and
subsequent amendments 2002/96/EC.
TECHNICAL DATA (2nd Oven)
Dimensions
Volume
Voltage and frequency see data plate
;
ENERGY LABEL
H:33.8;W:24.5;D:43.8 cm
36 l
Directive 2002/40/EC on the
label of electric ovens.
Regulation EN 50304
Energy consumption for Natural
convection – heating mode:
Traditional mode
;
EC Directives: 2006/95/EEC
dated 12/12/06 (Low Voltage)
and subsequent amendments 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent amendments 93/68/EEC dated 22/07/93 and
subsequent amendments 2002/96/EC.
3
Description
of the appliance
GB
Overall view
Control
Panel
2nd. Oven
1st. Oven
Adjustable Feet or Legs
Control panel
HOTPLATE
Control knob
TIMER
knob
THERMOSTAT
knob (1st. OVEN)
1st. OVEN
THERMOSTAT
Indicator light
(1st. OVEN)
SELECTOR
knob (1st. OVEN)
THERMOSTAT
Knob (2nd. OVEN)
2nd. OVEN
THERMOSTAT
Indicator light
(2nd. OVEN)
SELECTOR
knob (2nd. OVEN)
4
