User manual
LIFTING
When user leaves this chair, pull up the first control rod on the lower
right chassis of cushion to uplift this chair; When user sits on this
chair, pull up the same control rod to lower this chair.
BACKWARD LYING
When user sits on this chair and leans backwards, pull up the second
control rod on the right-hand chassis to lean this chair backwards or put
down control rod to fix this chair. After user leaves this chair, pull the
same control rod again to recover this seat to the original angle.
FOOT SUPPORT
Pull out foot support and rotate it before use.
01
02
4
1
2
3
6
9
11
8
7
10
5
1
2
3
Base
Armrest
Casters
4
Headrest
Decorative covers
5
Gas lift cylinder
6
back cover
7
Headrest cover
8
back & seat cushion joint cover
9
screws AX2
A
B
C
D
03
F
screws BX4
screws CX6
E
screws DX2
E
Allen wrench EX1
Washer for armrest screw FX4
F
10
seat cushion
11
Metal plate
04
1. Press the casters into each leg of the
base.
3. Put the seat cushion on the floor with
seat cushion downside up.
5.Pull the back into the seat tilt
mechainism
2.Pull in the gas lift cylinder into the center
of base.
4.Put the metal plate on backrest and
fasten it with screw C as the picture
show
6.Fasten with screw C
7.Put on the backrest cover and fasten
with screw A as the picture show
9.Put on the cover as the picture show
11.Press on the headrest cover.
short screw
long screw
8.Put the arm washer F on the hole and
fasten it with screw B as the picture
show
10. Put the headrest as shown in the
picture and fasten screws D.
05
06
