AH120A
1702 East B/D IT Venture 78,
Garakbon-Dong, Songpa-Gu, Seoul Korea
INTERNET : http://www.imuon.com
3
TABLE of Contents
1. Product Guide....................................................................4
2. Product features.................................................................5
3. Precautions.........................................................................7
4. Components.......................................................................9
5. Locating the Controls......................................................11
6. Connection.......................................................................13
7. Driver Installation and Folder Generation.....................14
8. User Manual.....................................................................19
9. Q&A....................................................................................30
10. Product Specification....................................................33
11. Customer Support........................................................34
iMuon AH120A is a compact and stylish, portable multi media player
and handheld hard disk. Your iMuon has been designed to perform
a number of functions ranging from displaying DVD quality video or
text files through the built-in QVGA TFT-LCD, playing MP3/WMA
music files or allowing you to enjoy these features on your TV via AV
cable or IR remote control.
iMuon is handy for anyone on the go. While traveling, you can view
movies and video lectures. You can store and view photo albums
and listen to MP3/WMA files. You can also read text files like
electronic novels, essays or other text files. iMuon is compatible with
MP3, WMA, AVI, DivX, XViD, VOB, DAT, MPEG and JPEG multi
media file formats.
Dvix files with subtitles, such as SMI, are supported. Subtitle
languages currently supported are Korean, English, Japanese and
Chinese. Additional languages are also supported through firmware
upgrades available on our web site at www.imuon.com. The player
supports data transfer speeds of 480mbps through a USB 2.0
connection. iMuon can also be used as a 20GB removable hard
disk.
You can connect iMuon to a TV with an AV cable, using the player
like a VTR or you can connect via iMuon’s IR functionality. Through
the TV, you can play all your favorite media files - from Dvix to
MP3s!
4 5
1. Product Guide
2. Product Features
UV coated body and ultra miniature size with a super high
quality, detailed, QVGA quality, color LCD screen with backlight.
Room enough to store up to 30 of your favorite
movies or 4,500 MP3 songs or 40,000 digital photos. The iMuon
combines a modular MPEG-4 video player, MP3 music player, digital
photo album, and data storage into a compact device that fits in the
palm of your hand.
Built-in, QVGA quality, 2.2¡–TFT LCD supporting 260,000
colors.
Video functions support resolution up to a maximum 1920 x
1080 or 30 frames per second (normal video speed).
High quality video and audio play functionality through
Composite out and AV Stereo audio out.
TV out function switch able to NTSC / PAL
Wide bit rate range from 30 ~ 320 kb/s and 5 Equalizers that
change according to desired music genre.
Stores up to 4,500 audio files for your listening pleasure.
S/PDIF output supported to produce 5.1 channel stereo
sound through Coaxial or Optical output (Cable optional).
Plays DivX 3.x, 4.x, 5.x and Xvid video files.
Stores and provides viewing capability for up to 40,000 .jpg
file photos.
JPG Photo
DivX Video
Optical Output
MP3 Audio
5 Equalizer
NTSC/PAL
TV Out
HQ Video
QVGA Display
20GB HDD
Quality Design
7
Stores and provides viewing capability for text files that can
be read on the go.
Allows the player to be operated by the buttons on the
device, wired Remote Control or by wireless Remote Control.
Backlight function allows the backlight on/off time to be
adjusted.
High speed data transfer at a maximum 480Mbps. Firmware
easily upgradeable through the USB port.
Currently supports subtitles in Korean, Japanese,
Chinese and English.
Built-in speakers provide high quality stereo sound
without earphones.
Built-in Li-Polymer battery allows a maximum play
time of 10 hours for MP3 audio files or 5 hours for video files.
Battery is rechargeable through an AC adapter, 24
pin rechargeable cable in the mobile travel kit or by USB cable.
Firmware upgrades and User support available at
www.imuon.com.
Firmware Upgradeable
Rechargeable
Li-Polymer Battery
Stereo Speaker
Multi Language Subtitles
USB 2.0
Back Light
3 Way Control
e-Book Text
6
2. Product Features 3. Precautions
If the AC adapter is plugged in and
begins to smoke, produces a burning
smell or becomes excessively noisy,
unplug immediately. Failure to do so may
result in fire or electrical shock.
When plugging the AC Adapter into the
power outlet, make sure it is properly
plugged into the socket. Failure to do so
may result in fire or electrical shock.
NO!
Do not plug in the AC Power Adapter
with wet hands.
Use Only the AC Power Adapter
supplied with the player. Other adapters
may result in fire or electrical shock.
In stormy weather, unplug the AC
adaptor from the wall outlet. Failure to do
so may result from power surges.
Do not dissemble, repair or alter the
player.
9
■ Main body
■ Wired Remote Control
4. Components
MENU
REW.
F.F
VOL
ON
OFF
VOL
■ Wireless IR Remote Control
8
3. Precautions
Keep the player away from any strong
magnetic force. This can cause
malfunctions in the Hard Drive.
Avoid dropping or physically impacting
the player. Dropping or physically
impacting the player may cause
damage.
Clean the player with a soft cloth or towel.
Never clean the player with a chemical
solution like Benzene, Acetone, paint thinner or
solvent. These chemicals can cause the player
to change color or loose its paint.
Do not leave the player exposed to
excessive dust or sand, moisture,
physical shock or rough surfaces.
Do not leave the player near heat
sources, direct sunlight, or in a car with
closed windows.
Do not dissemble, repair or alter the
player.
11
5. Locating the Controls
Main Body
USB2.0 Ext. I/O RESET DC5V
MENU
REW.
F.F
VOL
ON
OFFVOL
HOLD
Main Menu/Sub Menu
Volume/Menu/Folder Up
Rewind/Previous
Operating Indicator/
Charging Indicator LED
Built-In Speaker
IR Receiver
Remote Control
/Earphone Jack
USB Connection Port
Reset
DC IN 5.0V
24 Pin Expandable
Connection Port
Hold
LCD Window
LCD/
TV Converter
Stop/Power Off
Fast Forward/Next
Volume/Menu/
Folder
Down
Power On/Play/Paus
LCD/TV
* Accessories are subject to change without notice and may vary from images shown.
10
4. Components
■ USB Cable■ Earphones
■ A/V Cable■ AC Adapter (DC 5V 2A)
■ Carrying Case
■ User Manual/Warranty card
■ Install CD
13
6. Connection
1. Connecting to a
USB cable
2. Connecting iMuon to a
24 pin connection cable
3. Connecting iMuon to
the AC Power Adapter
(Video Input - Yellow, Audio Input - White, Red)
PC
USB1.1/2.0
MENU OFF DOWN VOL UP
MIC
ON
MENU
REW.
F.F
VOL
ON
OFF
VOL
Video Cable(Yellow)
Audio Cable(White, Red)
Adapter
Main Body
Main Body
Earphone Remote Control
TV
12
5. Locating the Controls
Wired Remote Control
Wireless IR Remote Control
MENU OFF DOWN VOL VOL UP UP
MIC
HOLD
ON
Hold
Main Menu/Sub Menu End point of the section repeat/
Stop the section repeat
Joy Stick for Multi
Function Control/
Play/Power On
Stop/Power Off Start point of the section repeat
LCD Window
Power Off
Main Menu/Sub Menu
Execution/Play/Save
Previous
Next
Rewind
Fast Forward
End point of section repeat/
stop the section repeat
Zoom In/Out
File Information
Mute
Time Search
Stop
Play
Pause
TV/LCD Converter
Start point of section repeat
NOTE: You must turn the power on after connecting the USB Cable or the
AV Cable or the Wired Remote Control to avoid loss of data or
freezing the computer and/or the device.
14 15
7. Driver Installation and Folder Generation
7. Driver Installation and Folder Generation
Windows 2000/XP
Windows 2000 and Windows XP are programmed to automatically
support USB2.0 storage devices. iMuon can be used without any
program installation.
Windows 98/ME
Although Windows 2000 and Windows XP automatically support USB 2.0,
Windows 98/ME does not. To use iMuon on a Windows 98/ME computer,
you must first install the storage device driver. To install, insert the installation
CD into the CD Rom and follow the prompts. If the installation CD is not
available, you can download the driver at www.iMuon.com.
1. Windows 98/ME has recognized a new piece of hardware and starts its
wizard. Click on Next.
2. Click on the button search for the best driver Now click on Next.
3. Uncheck all of the checked boxes, and then check the box specify the
drive to. Click on Next and Windows will then load the correct drivers.
17
7. Driver Installation and Folder Generation
16
7. Driver Installation and Folder Generation
4. Windows is now ready to install the driver into its operating system. Click
on Next to tell Windows to install the driver.
5. Windows will indicate when it has finished copying the drivers. Click on
Finish. Do not unplug the device from the computer yet.
6. Once finished, you should restart your computer. Upon restart, it will
automatically recognize the connected device. It will be seen as another
hard disk in Windows Explorer.
NOTE: You must properly remove your device from the computer before
disconnecting the USB cable to avoid loss of data or freezing the
computer and/or the device.
Attention: The operating system will not allow you to safely disconnect the
device if you have an open file from it in a running application. You
will have to close all open the device files in any running application.
Sometimes even when files are closed in an application, you will
have to shut down the application. Using the green disconnect
arrow in the system tray will then allow you to safely disconnect the
device.
Windows
To safely disconnect the device, click on the system tray remove icon (green
arrow) and follow the instructions. Wait until you get a message saying that
you can safely unplug the device before disconnecting the USB cable.
19
8. User guide
To turn on the player, push and hold the ON button of the device or
the ON button of the joy stick on the wired remote control. Once the
player is on, the LCD will display the main menu.
NOTE: The player can’t be turned on via the wireless remote control.
To turn on the player
MENU
REW.
F.F
VOL
ON
OFFVOL
MENU OFF DOWN VOL UP
MIC
ON
To turn the player off, push and hold the OFF button on the player or the wired
remote control. You may also press and hold the Power button on the
wireless remote control.
NOTE: When “Hold” is ON, the buttons on the player will not function.
If the player has been stopped or is idle for 30 minutes, it will automatically
turn off per the STOP POWER OFF default setting.
To turn off the player
MENU
REW.
F.F
VOL
ON
OFFVOL
MENU OFF DOWN VOL UP
MIC
ON
18
7. Driver Installation and Folder Generation
To generate folders
The player has the following, basic folders that are listed below.
Folder names may be changed or new folders may be added as
desired by the user.
Audio: Folder to store MP3 and WMA Audio files.
E-BOOK:
Folder to store
*.txt electronic books and other files.
Photo: Folder to store
*.jpg photos.
Video: Folder to store
*.avi, DivX 3.x, 4.x, 5.x, Xvid and mpg video files.
2120
8. User guide
1. Push ON after selecting AUDIO.
2. From the media folder, you can select the Audio
folder where you have stored your audio files. Select
the desired file and press ON to begin play.
To play AUDIO files
8. User guide
To change the display from LCD to TV
iMuon can display images on either the LCD
or a TV. To change the display, push Remote
control. This will switch the display from LCD
on the device to the TV or from the TV to the
LCD on the device.
To use Wireless Remote Control
Please note that the Wireless Remote Control is operational
immediately after the player is turned on. The wireless function will
work properly as long as the transmitter of the wireless remote control
is directed towards the player’s receiver.
To display the MENU
To display the Menu, push the Menu button on the player, wired remote
control or the wireless remote control while the player is in Stop status. The
Menu below will be displayed. From the menu, you can choose the function
you desire.
MENU Options are: AUDIO, VIDEO, PHOTO, E-BOOK, and SETUP.
Increase/decrease volume
Pause/play
Play previous track/next track
Stop/Go to the upper directory in stop status
¢‚¢‚¢”¢”
Fast reverse 10 seconds/fast forward 10 seconds in the current file
A-B Push the A button to select the start point of a section to repeat. An
A icon is displayed in the screen and push B button to end the
section repeat. The selected section is played repeatedly.(Wired
Remote Control/Wireless Remote Control)
Note:You can’t set section repeat function by the device buttons.
Mute Stop sound but continue play (Wireless Remote Control)
Search Browse through audio files while music is playing (Sub
Menu/Wireless Remote Control)
Menu Go to Sub Menu.
Audio Operation
23
8. User guide
Display Show on or off the Menu bar on the bottom of screen
File Search Find and select the file you want while playing
Time Search Select the time within the audio file that you wish to
begin play
The Metro Key for this function is in wireless
Remote Control.
EQ Change the EQ to match your music style.
-None/Dance/Jazz/Classic/Pop/Rock
SAVE Bookmark the current page you’re listening.
After choosing SAVE in Sub Menu, push .
Please note that only the player will only save
(bookmark) information on the last song stored.
LOAD Call the last song you saved.
After choosing LOAD in Sub Menu, Push .
MENU Stop file search while playing.
1. Push ON ¢”after selecting VIDEO.
2. From the media folder, you can select the Video
folder where you have stored your video files. Select
the desired file and press ON ¢”to begin play.
To play VIDEO
22
8. User guide
Press the Menu button on the player, wired Remote Control or the wireless
Remote Control while playing.
Sub MENU
Info Display information on the current file
Mode Select playback mode
Enter Sub MENU
Increase/decrease volume
Pause/play
Play previous video/next video
Stop/Go to the upper directory in stop status
¢‚¢‚¢”¢”
Fast reverse/fast forward (a three-speed control)
To change speeds, push the
¢‚¢‚¢”¢”
button to go from one fast
forward/reverse speed to the next higher speed. Pressing
twice will result in the fastest speed.
Zoom Zoom in or out. (Metro key is in the wireless remote control)
Mute Stop sound but continue play (Wireless Remote Control)
Search Browse through video files while video is playing (Sub
Menu/Wireless Remote Control)
Menu Go to Sub Menu.
Vidio Operation
1 Play one track in the folder and stop
1 Play one track in the folder repeatedly
D Play all tracks in the folder and stop
D Play all tracks in the folder repeatedly
DS Play all tracks and folders in the folder repeatedly
25
8. User guide
To display PHOTOs
1. Push ON after selecting PHOTO.
2. From the media folder, you can select the Photo
folder where you have stored your photo files. Select
the desired file and press ON to display
Display photo
Automatically display a photo slide show(push for 2 or 3 seconds)
Rotate Picture up to 360 degrees in incriments of 90 degrees
Display previous photo/next photo
Stop/Go to the upper directory in stop status
Menu Go to Sub Menu
24
8. User guide
Display Show on or off the Menu bar on the bottom of screen.
Position Change the subtitle position to high/low.
Time Search Select the time within the video file that you wish to begin play.
Metro Key for this function is in wireless Remote Control.
EQ Change the EQ to match your music style.
-None/Dance/Jazz/Classic/Pop/Rock
Zoom/Move Enlarge/reduce the display or move to the left/right to
achieve your desired view.
Push ON
after selecting Zoom mode in Sub Menu
and you can make the player zoom in or out.
Metro Key for this function is in wireless Remote Control.
Subtitle To display subtitles while playing video files
- Korean/English/Japanese/Chinese
Additional languages can be downloaded at www.imuon.com.
SAVE Bookmark the current page you’re viewing.
After choosing SAVE in Sub Menu, push
.
Please note that only the player will only save
(bookmark) information on the last page stored.
LOAD Call the last page you saved.
After choosing LOAD in Sub Menu, Push
.
Press the Menu button on the player, wired Remote Control or the wireless
Remote Control while playing.
Sub MENU
Info Display the information on the file the player is currently playing
Mode Select playback mode
To Enter Sub MENU
Press the Menu button on the player, wired Remote Control or the
wireless Remote Control while displaying
Sub MENU
Info Display file information for the currently displayed photo
Zoom/Move Enlarge/reduce the display or move to the left/right to
achieve your desired view Push ON after selecting
Zoom mode in Sub Menu and you can make zoom in
or out.
Metro Key for this function is in wireless Remote
Control
To Enter Sub MENU
1 Play one track in the folder and stop
1 Play one track in the folder repeatedly
D Play all tracks in the folder and stop
D Play all tracks in the folder repeatedly
DS Play all tracks and folders in the folder repeatedly
27
8. User guide
SETUP
You can set or change functions, using the
¡ª¡
buttons.
After setting up functions, you can go to the Main
Menu if you push the Menu button.
26
8. User guide
e-BOOK
1. Push ON after selecting e-BOOK.
2. From the media folder, you can select the
e-Book folder where you have stored your text
files. Select the desired file and press ON
to display
Display the text
Move to the previous page/next page
Move up/down 10 pages at a time
Stop/Go to the upper directory in stop status
Menu Go to Sub Menu
Press the Menu button on the player, wired Remote Control or the
wireless Remote Control while displaying
Sub MENU
Info Display information for the currently displayed text file
SAVE Bookmark the current page you’re reading.
After choosing SAVE in Sub Menu, push .
Please note that only the player will only save (bookmark)
information on the last page stored.
LOAD Call the last page you saved.
After choosing LOAD in Sub Menu, Push .
GOTO Move the page you want to read.
To Enter Sub MENU
INFO Player setup information is displayed.
SKIN
Default skin can be displayed or you may select a new skin
<ON/OFF>
Video The display direction for video play can be changed.
<VER/HOR>
Subtitle Subtitle font size can be set.
<14/16 Pixels>
e-Book Text font size can be set.
<14/16 Pixels>
OUTLINE Font outline can be set
<ON/OFF>
OFF TIME LCD backlight time can be set. This changes the
amount of time the LCD light will stay lit if the player
is idle, in Audio mode or stop status.
<OFF/5/10/30/60>
LIGHT LCD brightness can be set.
<DARK/BRIGHT>
Photo Automatic slide show time for photo viewing can be set.
<OFF/3/5/7/10/15/20/30>
REMOCON OFF TIME
LCD backlight time of the wired Remote Control can be
set. This changes the amount of time the wired
Remote Control.
LCD light will stay lit if the Remote Control is idle and
not touched.
<OFF/5/10/30/60>
To go to Setup MENU
29
8. User guide
28
8. User guide
iMuon promises you the latest and best features through Firmware
upgrades at www.imuon.com.
To upgrade:
1. Connect the AC adapter to iMuon.
(Caution: Only upgrade the firmware on iMuon with the AC adapter
connected.)
2. Download the latest Firmware upgrade files (loader.sdn, romfs.sdn)
from www.imuon.com
3. Extract the files and save them to the root folder of iMuon.
4. After the files have been copied, remove the USB cable from iMuon
turn the power off.
5. Turn the power back on and the upgrade will be automatically
installed.
At this point, the LCD will display:
“Firmware Upgrade Checking”, “Firmware Upgrade Proceeding”,
After this the Main Menu will be displayed.
6. Connect the USB cable to the player and PC and delete the files
downloaded to the iMuon to upgrade the device.
7. Remove the USB cable from iMuon.
8. Turn on iMuon.
NOTE: Do not turn the player off or disconnect the player from the PC until the
firmware upgrade file is completely copied to the player.
REMOCON COLOR - LCD backlight color of wired Remote control
can be set.
<White/Green/Sky/Purple/Yellow/Blue/Red>
TV STANDARD -TV standard mode can be changed.
<NTSC/PAL>
The player can be charged by AC adapter, USB cable or 24 pin charger in the
mobile travel kit. Rechargeable function is automatically activated when the
AC adapter is connected to the player.
At full discharge, the player needs to be charged for approximately 4 hours. If
the player is used while charging, the charging time can be longer. While
charging, the charge indicator light will be red and will turn off when fully
charged.
NOTE: In case you recharge the player through the USB cable, the
rechargeable function will be activated when the USB cable is
connected to the player and the PC is powered on.
NOTE: When the player is connected to the PC and is powered on, the player
will only function as a removable disk and the play functions will not
operate. While the player is on and acting as a removable disk, the
LED indicator will display a blue light.
NOTE: When connecting the player to the PC to charge, the player should be
powered off before connecting. Powering by USB will also take 2 to 3
times as much time to charge to full capacity as the AC adaptor.
Recharging Method
FIRMWARE UPGRADE
31
9. Q & A
The subtitles are not displayed. Why?
In playing DivX files, the subtitle file name should be the same as the
DivX file name. For example, if video.avi is being played, there should
be a subtitle file named video.smi in the same folder. If the subtitle
file is named differently, the player can not properly display the
subtitles.
Does the player support to AC3, DTS and DTS Pass-through?
The player supports AC3 but does not support DTS or related
functions.
In some video files, no sound can be heard. Why?
If the video file has been coded only in DTS, no sound may be heard.
However, files coded by DTS and AC3 simultaneously will play
sound.
The player doesn’t turn off.
To power off your player, push and hold the OFF button for several
seconds (2 -4 seconds) or use similar power buttons on your wired or
wireless remote controls. If the player still does not power off, please
reboot the player by pressing the Reset button with a pointed object.
If you still have issues, please consult with your iMuon dealer or
contact support at www.imuon.com.
What are the viewing angles of the built-in LCD?
The viewing angles up and down are a maximum 125 degrees and
left and right are a maximum 100 degrees. The viewing angles to see
from the bottom towards the top are a maximum 75 degrees.
Does the player support a Pivot function which switches the
screen display 90 degrees ?
The player automatically supports Pivot functions while playing video
files.
30
I can’t turn on the player with the wireless Remote Control.
It is not possible to turn on the player via wireless remote control.
To save battery time, the IR signal is activated only after the player is
turned on. To turn on the player, please press the ON button or the
wired remote control. You can, however, turn off the player via the
wireless remote control by pressing the Power button.
Which DivX version is supported ?
The player supports to DivX 3.X, 4.X and 5.X and Xvid files.
Why does the screen sometimes freeze for a moment?
The screen may briefly freeze when video files start to play or when
the user is using Fast Forward or Rewind. The freezing is caused by
the hard disk reading and buffering the file to provide a quality video
display.
What subtitle languages are supported ?
The player currently supports subtitles in Korean, English, Chinese,
Japanese and Code characters. iMuon also plans to support
additional languages through firmware upgrades. Check our web
site more details on language availability.
The screen is frozen and the player cannot be turned off.
When the battery is almost fully discharged, the player will go into
standby mode for approximately one hour. During this time, the
LED will be lit but the player will not be turned on.
the subtitles.
9. Q & A
3332
10. Product Specification
9. Q & A
Can I transfer the files by USB 1.1?
Yes. The player is compatible with USB 2.0 and USB 1.1. Please
note that using USB1.1 can result in a significantly slower transfer
speed.
Where can I store a User skin if I want to use it ?
You can store user skins, background.jpg, files in the root folder or in
the Setup Menu. If you set Skin mode to ON, the skin at the root level
will be displayed.
How many e-book lines are displayed ?
The player will display up to 15 lines at one time.
Why does playback stop when I connect my player to the PC with
a USB cable?
If the player is connected to PC with a USB cable, the removable
hard disk activates and all functions stop. The player essentially
goes in to standby mode to store and/or transfer files. To charge the
battery via the PC and the USB cable, please turn the player off
before connecting.
Does the player support NTFS?
This player’s operating system is based on embedded Linux and
supports only FAT32.
Can the player be purchased without the Hard Disk ?
No. The player can only be purchased as a complete product. It is
sealed to prevent damage or malfunctions through disassembly or
tampering.
Category Item Specification
HDD Capacity 20G Byte
Size 1.8
File system FAT32
PC OS support Window 98SE / ME / 2000 / XP,
Mac 8.6 / 9.x and X
Interface USB 1.1/2.0
Power Supply AC Adapter DC 5.0V, 2A
USB 2.0
24 Pins Standard connector for mobile phone
Audio Earphone Output 40mW(L) +40mW(R) at 16Ω Max. Volume
Frequency Range 20~20KHz
Bit rate 32Kbps~320Kbps
S/N rate >90dB
Video Output NTSC / PAL
Composite Video out put 75ohm, 1.0Vpp
S-Video Video out put 75ohm, 1.0Vpp
Component Video out put 75ohm, 1.0Vpp
File Support File Type Mpeg-1, Mpeg-2, Mpeg-4, XivD
AVI file : XivD 3.X, XivD 4.X, XivD 5.X
MP3, WMA
JPEG Image
Power Supply AC Adapter DC 5V, 2A
General LCD QVGA 2.2
USB USB 2.0 (USB 1.1 Compatible)
Dimension 110.5 x 64 x 23 mm
Weight 203g
Operational 0 ~ 40˚C
Temperature
Maximum Playtime Approx. 10 hours (Audio) / 5 hours (Video)
FCC RF
INTERFERENCE ST A TEMENT
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:(1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
FCC ID:SVRAH120A3 MADE IN SEOUL, KOREA
34
11. Support
If your iMuon player is defective or requires servicing, you may either
drop the player by the head office in person or send in the player via
mail or express mail service.
When visiting the head office in person, we will repair the player
immediately. However, we do ask that you call or email us ahead of
time to make a reservation for your visit to insure fast and thorough
support.
If you opt to send in your player via mail or express mail service, we
will repair your iMuon within 5 working days of receipt and send it
back to you. Please send all packages to us prepaid. We will prepay
the freight charges when we return the player to you.
■ Web site :
www.iMuon.com
■ E-mail :
support@iMuon.com
■ Phone :
+82-2-2142-1127
■ Fax :
+82-2-2142-1129
■ Technical support :
BITWIRE Corp.
1702 East B/D IT Venture 78, Garakbon-Dong, Songpa-Gu, Seoul Korea
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are disigned to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particalar installation.
If this equipment does cause harmful interference to radio or television reception
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio, TV technical for help.
- Only shielded interface cable should be used.
Finally, and changes or modifications to the equipment by the user not expressly
approved by the grantee or manufacturer could void the users authority to opteate
such equipment.
Loading...
