Page 1
PCM-3362
Intel® Atom™ N450 PC/104-Plus SBC, CRT, LVDS,
Ethernet, USB, COM, SATA, Onboard Flash
I2C/SMbus
RS-422/485
Gigabit Ethernet
USB 1/2
USB 3/4
SATA
2GB flash
HD Audio GPIO Front Panel
VxWorks
®
Specifications
CPU Intel Atom N450 1.66 GHz
Front Side Bus 667 MHz
Processor System
Memory
Display
Ethernet
Watchdog Timer
Storage
Internal I/O
Expansion PC/104-Plus slot 1
Power
Environment
Physical Characteristics
Frequency 1.66 GHz
L2 Cache 512 KB
System Chipset Intel Atom N450 + ICH8M
BIOS AMI 16 Mbit
Technology DDR2 667 MHz
Max. Capacity 2 GB
Socket 1 x 200-pin SO-DIMM
Chipset Intel Atom N450 1.66 GHz
VRAM Shared system memory up to 224 MB
Graphics Engine Intel Gen 3.5 graphic core, DX9 compliant, MPEG2 Hardware Acceleration
LVDS Single channel 18-bit single channel LVDS up to WXGA 1366 x 768
CRT Supports up to SXGA 1400 x 1060 @ 60 Hz
Dual Display CRT+LVDS
Speed 10/100/1000 Mbps
Controller ICH8M + Intel 82567V (PHY), support Wake-on-LAN
Connector Pin Header
SATA 1 SATAII, up to 3.0 GB/s (300 MB/s)
Onboard Flash 2 GB (Up to 4 GB)
USB 4 x USB 2.0
Serial
Keyboard/Mouse 1
GPIO 8-bit general purpose input/output
2
I
C 1
Audio Intel High Definition audio interface
Power Type AT/ATX
Power Supply Voltage 5V ± 5% only to boot up (12 V is optional for LCD inverter and add-on card)
Power Consumption (Typical) 2A @ +5V, 5 mA @ +12V
Power Consumption
(Max, test in HCT)
Battery Lithium 3 V / 210 mAH
Power Management ACPI/ APM 1.2
Operational 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 85% RH non-condensing)
Non-Operational -40° C ~ 85° C and 60° C @ 95% RH non-condensing
Dimensions (L x W) 96 x 90 mm (3.8" x 3.5")
Weight 0.162 kg (0.357 lb) (with heat-sink)
Height Top Side: 14.4 mm, 19.4 mm (Z & Z2); Bottom Side: 10.6 mm
Features
Intel® Atom™ N450 1.66 GHz Processor and DDR2 667MHz SDRAM up to
2 GB
Power in
LVDS
Output System Reset
Programmable counter from 1 ~ 255 minutes/ seconds
2 RS-232 from COM1/2, 1 RS-232/422/485 from COM3 (ESD protection for RS-232: Air gap ±15kV, Contact
±8kV)
2.37A @ +5V, 7 mA @ +12V
Supports extended temperature -40 ~ 85° C
Standard 96 x 90 mm dimension and PC/104-Plus expansion connector
Onboard 2 GB flash (4 GB optional)
Supports embedded software APIs and Utilities
Software APIs:
Backlight On/OffWatchdog GPIOH/W MonitorI2C Brightness
Utilities:
Monitoring eSOS Embedded
Security ID
PC/104 CPU Modules
All product specifications are subject to change without notice Last updated : 9-May-2011
Page 2
PCM-3362
Board Diagram
Optional
Audio extension
module
Onboard
Flash 2 GB
1 SATA Ports
4 USB Ports
BIOS
Audio pin
header
8-bit GPIO
CRT connector
LVDS
connector
PCA9555
18-bit LVDS
PATA
300 MB/s
USB 2.0
SPI
HD Audio
PS2 KB/MS
VGA
SMbus
Intel Atom N450
Intel ICH 8 M
Super IO
SCH3114
x 4 DMI
LPC
Single Channel
GLCI/PCIe x1
2 RS-232
1 RS-422/485
DDRII 667 SODIMM
200-pin up to 2 GB
PCI bus
Intel 82567V
(PHY)
PCI-104 connector
PCI to ISA
bridge
ISA
PC/104
Connector
Ordering Information
Part No. CPU Memory On board flash CRT LVDS
Gigabit
Ethernet
USB 2.0 RS-232 RS-422/485
PCM-3362N-S6A1E Atom N450 SODIMM 2 GB Yes 18-bit 1 4 2 1 Passive 0 ~ 60° C
PCM-3362N-S6F4A1E Atom N450 SODIMM 4 GB Yes 18-bit 1 4 2 1 Passive 0 ~ 60° C
PCM-3362Z-1GS6A1E Atom N450 1 GB bundle 2 GB Ye s 18-bit 1 4 2 1 Passive -20 ~ 80° C
PCM-3362Z2-1GS6A1E Atom N450 1 GB bundle 2 GB Yes 18-bit 1 4 2 1 Passive -40 ~ 85° C
Note: Wide temp version has been bundled with extended temperature grade memory module
Packing List
Part No. Description Quantity
1700000898 VGA cable D-SUB 15P(F)/12P-1.25 mm15 cm 1
1700003491 AT power cable 1 x 8P-2.0/B4P-5.08 x 2 15 cm 1
1700060202 Cable 6P-6P-6P PS/2 KB & Mouse 20 cm 1
1703040157 RS-422/485 W/D-SUB COM 4P 15 cm 1
1703060053
1700002332 ATX power cable 20P-13P/8P/3P/3P 13 cm 1
1703100260 USB cable 2port 2.0 mm pitch w/ bracket 26 cm 1
1700071000 SATA data cable 7p 100 cm 1
1703150102 SATA power cable B4P-5.08/SATA 15P 10 cm 1
1701200220 RS-232 x 2 ports 2.0 mm 22 cm 1
1700017863 LAN cable RJ-45/2 x 5P-2.0 15 cm 1
9660104000 PC/104 screw and copper post package 1
1960045487T001
1960045487T001
PCM-3362 SBC
Startup Manual
Utility CD
PS2 Cable 6P (MINI-DIN)-6P (Wafer 2.0 mm)
6 cm
Heatsink for PCM-3362
(79.66 x 77.97 x 12.22 mm)
Heatsink for PCM-3362Z series only
(79.66 x 77.97 x 17.22 mm)
1
1
1
Optional Accessories
Part No. Description
1960047106T001 Heat spreader (79.66 x 77.98 x 10.32 mm) of PCM-3362
1653130421 PCI-104 connector 120pin (Long pin)
165313222B PC/104 connector 64-pin (Long pin)
165312022B PC/104 connector 40-pin (Long pin)
PCA-AUDIO-HDA1E Audio extension module with bracket
1700018427
Audio cable connecting PCM-3362 and PCA-AUDIOHDA1E
Embedded OS/API
Embedded OS/API Part No. Description
WinCE 2070009692 WinCE 6.0 Pro for PCM-3362 V1.3 ENG
Win XPE
QNX V6.5
Linux Ubuntu 10.04
VxWorks V6.8
Software API 205E362000
2070009030 XPE WES2009 Luna Pier V4.0 ENG
2070009031 XPE WES2009 Luna Pier V4.0 MUI24
SUSI 3.0 SW API for PCM-3362
B:20091015 XP
Thermal
Solution
Operating
Temp.
Online Download
www.advantech.com/products
Page 3
Value-Added Software Services
Software API: An interface that defines the ways by which an application program may request services from libraries and/or operating systems. Provides not only the underlying
drivers required but also a rich set of user-friendly, intelligent and integrated interfaces, which speeds development, enhances security and offers add-on value for Advantech platforms.
It plays the role of catalyst between developer and solution, and makes Advantech embedded platforms easier and simpler to adopt and operate with customer applications.
Software APIs
Control Monitor
General Purpose Input/Output is a flexible parallel interface
that allows a variety of custom connections. It allows users
to monitor the level of signal input or set the output status to
switch on/off a device. Our API also provides Programmable
GPIO
SMBus
I2C
GPIO, which allows developers to dynamically set the GPIO
input or output status.
SMBus is the System Management Bus defined by Intel®
Corporation in 1995. It is used in personal computers and
servers for low-speed system management communications.
The SMBus API allows a developer to interface a embedded
system environment and transfer serial messages using the
SMBus protocols, allowing multiple simultaneous device
control.
I2C is a bi-directional two wire bus that was developed by
Philips for use in their televisions in the 1980s.
The I2C API allows a developer to interface with an embedded
system environment and transfer serial messages using the I2C
protocols, allowing multiple simultaneous device control.
Watchdog
Hardware
Monitor
Hardware
Control
Display Power Saving
The Brightness Control API allows a developer to interface with
an embedded device to easily control brightness.
Brightness
Control
CPU Speed
A watchdog timer (WDT) is a device that performs a specific
operation after a certain period of time if something goes wrong
and the system does not recover on its own.
A watchdog timer can be programmed to perform a warm boot
(restarting the system) after a certain number of seconds.
The Hardware Monitor (HWM) API is a system health
supervision API that inspects certain condition indexes, such as
fan speed, temperature and voltage.
The Hardware Control API allows developers to set the PWM
(Pulse Width Modulation) value to adjust fan speed or other
devices; it can also be used to adjust the LCD brightness.
Make use of Intel SpeedStep technology to reduce power power
consumption. The system will automatically adjust the CPU
Speed depending on system loading.
Refers to a series of methods for reducing power consumption in
computers by lowering the clock frequency. These APIs allow the
user to lower the clock from 87.5% to 12.5%.
Backlight
The Backlight API allows a developer to control the backlight
(screen) on/off in an embedded device.
System
Throttling
Software Utilities
The BIOS Flash utility allows customers to update the flash
ROM BIOS version, or use it to back up current BIOS by
copying it from the flash chip to a file on customers’ disk. The
BIOS Flash utility also provides a command line version and
BIOS Flash
Embedded
Security ID
Monitoring
All product specifications are subject to change without notice Last updated : 9-May-2011
API for fast implementation into customized applications.
The embedded application is the most important property of
a system integrator. It contains valuable intellectual property,
design knowledge and innovation, but it is easily copied! The
Embedded Security ID utility provides reliable security functions
for customers to secure their application data within embedded
BIOS.
The Monitoring utility allows the customer to monitor system
health, including voltage, CPU and system temperature and fan
speed. These items are important to a device; if critical errors
happen and are not solved immediately, permanent damage may
be caused.
eSOS
Flash Lock
The eSOS is a small OS stored in BIOS ROM. It will boot up in
case of a main OS crash. It will diagnose the hardware status,
and then send an e-mail to a designated administrator. The
eSOS also provides remote connection: Telnet server and FTP
server, allowing the administrator to rescue the system.
Flash Lock is a mechanism that binds the board and CF card
(SQFlash) together. The user can “Lock” SQFlash via the Flash
Lock function and “Unlock” it via BIOS while booting. A locked
SQFlash cannot be read by any card reader or boot from other
platforms without a BIOS with the “Unlock” feature.
