PCM-3355
AMD LX800/LX600 PC/104 SBC,
CRT, TTL, Ethernet, USB, COM, CFC
TTL LCD VGA
USB
POWER IN
SATA
Fast Ethernet
PS2
RS-422/485INVERTER
Specifications
CPU AMD Geode™ LX800, 500 MHz/AMD Geode™ LX600, 366 MHz
Processor System
Memory
Display
Ethernet
Watchdog Timer
Storage
Internal I/O
Expansion PC/104 slot 1
Power
Environment
Physical Characteristics
Frequency 500 MHz/ 366 MHz
L2 Cache 128 KB
System Chipset AMD CS5536
BIOS Award 4-Mbit
Technology DDR 333/400 MHz
Max. Capacity 1 GB
Socket 1 x 200-pin SODIMM
Chipset AMD Geode LX800/LX600
VRAM Optimized Shared Memory Architecture up to 64 MB system memory
CRT
TTL LCD Supports up to 1600 x 1200 x 32 bpp at 60 Hz for 24-bit single channel TFT
Dual Display CRT+TTL
Speed 10/100 Mbps
Controller Intel 82551QM
Connector Box Header
CompactFlash Compact Flash socket (Type I)
SATA 1 SATA, up to 1.5 Gb/s (150 MB/s) (Transfer from PATA)
Floppy 1 82077AA compatible
USB 2 x USB 2.0
Serial
Parallel (LPT) 1, IEEE 1284, EPP, and ECP compatible
SMBus 1
Keyboard/Mouse 1
Power Type AT
Power Supply Voltage ± 5% only to boot up (12 V is optional for LCD inverter and add on card)
Power Consumption (Typical) LX800: 1.45 A @ +5 V, 2 mA @ +12 V
Power Consumption
(Max, test in HCT)
Power Management ACPI/ APM1.2
Battery Lithium 3 V/210 mAH
Operational 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 85% RH non-condensing)
Non-Operational -40° C ~ 85° C and 60° C @ 95% RH non-condensing
Dimensions (L x W) 96 x 90 mm (3.8" x 3.5")
Weight 0.097 kg (0.214 lb)
Height Top Side: 8.7 mm; Bottom Side: 10.6 mm
Features
AMD low power LX800/500 MHz and LX600/366 MHz Processor
24-bit TFT LCD interface
Supports compact size 96 x 90 mm PC/104 standard dimension
LPT
RS
PC104
Supports up to 1920 x 1440 x 32 bpp at 85 Hz
Supports up to 1600 x 1200 x 32 bpp at 100 Hz
Output System Reset
Programmable counter from 1 ~ 255 minutes/ seconds
2 RS-232 from COM1/2, 1 RS-422/485 from COM3 (ESD protection for RS-232: Air gap ±15kV, Contact
±8kV)
LX800: 1.74 A @ +5 V, 0.1 A @ +12 V
Supports two RS-232, one RS-422/485, and two USB 2.0 ports
Supports Embedded Software API and Utility
Software APIs:
Backlight On/Off
Utilities:
Watchdog
BIOS flash
SMBus
Monitoring
H/W MonitorBrightness
PC/104 CPU Modules
All product specifications are subject to change without notice Last updated : 9-May-2011
Board Diagram
LCD
Connector
24 Bit TTL
AMD Geode
LX800/LX600
Analog RGB
DDR333/400
VGA
DDR SDRAM
SODIMM Socket
PCM-3355
PC/104
PCI to ISA Bridge
CompactFlash
PATA to SATA
Bridge
BIOS
2 RS-232
1 RS-422/485
Watchdog
PATA
LPC Bus
PCI BUS
AMD Geode
CS5536
Super I/O
SCH3114
USB 2.0
Fast Ethernet
Intel 82551QM
USB 2.0 x 2 port
PS/2 KB/MS
LPT
Ordering Information
Part No. CPU Memory TTL SATA
PCM-3355F-L0A1E AMD LX800 SODIMM 24-bit Yes 1 2 2 1 Yes/Yes PC/104 Passive 0 ~ 60° C
PCM-3355L-J0A1E AMD LX600 SODIMM 24-bit No 1 2 2 1 Yes/Yes PC/104 Passive 0 ~ 60° C
PCM-3355Z-512LA1E AMD LX800
PCM-3355Z2-512LA1E AMD LX800
512 MB
bundle
512 MB
bundle
24-bit Yes 1 2 2 1 Yes/Yes PC/104 Passive -20 ~ 80° C
24-bit Yes 1 2 2 1 Yes/Yes PC/104 Passive -40 ~ 85° C
Fast
Ethernet
USB2.0 RS-232 RS-422/485 LPT/KB/MS Expansion
Note: Wide temp version has bundled with extended temperature grade memory module
Thermal
Solution
Operating
Temp.
Packing List
Part No. Description Quantity
1700060202 Cable 6P-6P-6P PS/2 KB & Mouse 20 cm 1
1700260250 LPT Port cable 25P to 26P 2.0 mm 25 cm 1
1703040157 RS-422/485 W/D-SUB COM 4P 15 cm 1
1703060053
1703100121 USB 2-Port cable 10P 12 cm IDC 2.0 mm 1
1700008894 SATA data cable 7P 30 cm 1
1703150102 SATA power cable B4P-5.08/SATA 15P 10 cm 1
1701200220 RS-232 x 2 ports 2.0 mm 22 cm 1
1701160150 VGA Cable 15P to 16P 2.0 mm D-SUB 15 cm 1
1700005158 LAN cable RJ45 10P-2.0 mm 12 cm 1
9660104000 PC/104 screw and copper post package 1
1960016313T000
1960016315T000
PCM-3355 SBC
Startup Manual
Utility CD
PS2 Cable 6P (MINI-DIN)-6P (Wafer 2.0 mm)
6 cm
Heatsink for PCM-3355
(LX800/ LX600, 47.1 x 47.1 x 7.5 mm)
Heatsink for PCM-3355
(CS5536, 22.7 x 22.8 x 6.3 mm)
1
1
1
Optional Accessories
Part No. Description
165313222B PC/104 connector 64-pin (Long pin)
165312022B PC/104 connector 40-pin (Long pin)
Embedded OS/API
Embedded OS/API Part No. Description
WinCE 2070007869 Image CE 6.0 Pro PCM-3355 V1.2 ENG
Win XPE
QNX V6.3.2/ 6.4.1
Linux Ubuntu 9.10
Software API 205E000019
Online Download
2070007790
XPE WES2009 PCM-3355 Image GX3
V4.0 ENG
2070007910 XPE WES2009 GX3 LX800 V4.0 MUI24
SUSI 3.0 SW API for ESBC B: 20091116
XP
www.advantech.com/products
Value-Added Software Services
Software API: An interface that defines the ways by which an application program may request services from libraries and/or operating systems. Provides not only the underlying
drivers required but also a rich set of user-friendly, intelligent and integrated interfaces, which speeds development, enhances security and offers add-on value for Advantech platforms.
It plays the role of catalyst between developer and solution, and makes Advantech embedded platforms easier and simpler to adopt and operate with customer applications.
Software APIs
Control Monitor
General Purpose Input/Output is a flexible parallel interface
that allows a variety of custom connections. It allows users
to monitor the level of signal input or set the output status to
switch on/off a device. Our API also provides Programmable
GPIO
SMBus
I2C
GPIO, which allows developers to dynamically set the GPIO
input or output status.
SMBus is the System Management Bus defined by Intel®
Corporation in 1995. It is used in personal computers and
servers for low-speed system management communications.
The SMBus API allows a developer to interface a embedded
system environment and transfer serial messages using the
SMBus protocols, allowing multiple simultaneous device
control.
I2C is a bi-directional two wire bus that was developed by
Philips for use in their televisions in the 1980s.
The I2C API allows a developer to interface with an embedded
system environment and transfer serial messages using the I2C
protocols, allowing multiple simultaneous device control.
Watchdog
Hardware
Monitor
Hardware
Control
Display Power Saving
The Brightness Control API allows a developer to interface with
an embedded device to easily control brightness.
Brightness
Control
CPU Speed
A watchdog timer (WDT) is a device that performs a specific
operation after a certain period of time if something goes wrong
and the system does not recover on its own.
A watchdog timer can be programmed to perform a warm boot
(restarting the system) after a certain number of seconds.
The Hardware Monitor (HWM) API is a system health
supervision API that inspects certain condition indexes, such as
fan speed, temperature and voltage.
The Hardware Control API allows developers to set the PWM
(Pulse Width Modulation) value to adjust fan speed or other
devices; it can also be used to adjust the LCD brightness.
Make use of Intel SpeedStep technology to reduce power power
consumption. The system will automatically adjust the CPU
Speed depending on system loading.
Refers to a series of methods for reducing power consumption in
computers by lowering the clock frequency. These APIs allow the
user to lower the clock from 87.5% to 12.5%.
Backlight
The Backlight API allows a developer to control the backlight
(screen) on/off in an embedded device.
System
Throttling
Software Utilities
The BIOS Flash utility allows customers to update the flash
ROM BIOS version, or use it to back up current BIOS by
copying it from the flash chip to a file on customers’ disk. The
BIOS Flash utility also provides a command line version and
BIOS Flash
Embedded
Security ID
Monitoring
All product specifications are subject to change without notice Last updated : 9-May-2011
API for fast implementation into customized applications.
The embedded application is the most important property of
a system integrator. It contains valuable intellectual property,
design knowledge and innovation, but it is easily copied! The
Embedded Security ID utility provides reliable security functions
for customers to secure their application data within embedded
BIOS.
The Monitoring utility allows the customer to monitor system
health, including voltage, CPU and system temperature and fan
speed. These items are important to a device; if critical errors
happen and are not solved immediately, permanent damage may
be caused.
eSOS
Flash Lock
The eSOS is a small OS stored in BIOS ROM. It will boot up in
case of a main OS crash. It will diagnose the hardware status,
and then send an e-mail to a designated administrator. The
eSOS also provides remote connection: Telnet server and FTP
server, allowing the administrator to rescue the system.
Flash Lock is a mechanism that binds the board and CF card
(SQFlash) together. The user can “Lock” SQFlash via the Flash
Lock function and “Unlock” it via BIOS while booting. A locked
SQFlash cannot be read by any card reader or boot from other
platforms without a BIOS with the “Unlock” feature.
