Impulse EC800 User Manual

EC800 Series
Fanless Embedded System
Compact size Rich features
Cableless assembly
Fanless
Palm-sized
System Specifi cations
PROCESSOR SYSTEM
• CPU
®
- Intel
- Intel
- Intel
• Chipset
- Intel
MEMORY
• 2GB DDR3 onboard
GRAPHICS
• Intel
• Intel
• 1 DVI-I port supports display resolution up to 1920x1200
• 1 VGA port supports display resolution up to 1920x1200
• 1 micro HDMI port supports display resolution up to 1920x1080
• Smooth Video Playback
- Supports hardware decoders (H.264, VC-1, MPEG-4) with Full HD
STORAGE
• 1 CFast socket
• 1 mSATA module via a Mini PCIe slot
ETHERNET
• 2 Intel
AUDIO
• Realtek
• 1 line-out and 1 mic-in
COM
• 2 DB-9 ports
- 1 DB-9 port supports RS232/422/485 COM port
- 1 DB-9 port supports RS232/422/485 COM or isolated 2-bit In and
• Supports RS485 auto direction control
EXPANSION
• 3 Mini PCIe slots
- 2 slots for communication : One slot supports PCIe x1, USB, and LPC signals for Wi-Fi module
: One slot supports PCIe x1, USB, and 3G signals for 3G or GPRS
- 1 slot for storage : Supports mSATA module
• 1 SIM card socket
• 1 CFast
DIO
• 1 isolated 2-bit In and 2-bit Out DIO via the DB-9 port (signal+power)
• 1 8-bit DIO (4-bit In and 4-bit Out) connector
AtomTM D2550, 1.86GHz, 2x 512K L2, 10W TDP, dual-core
®
AtomTM N2800, 1.86GHz, 2x 512K L2, 6.5W TDP, dual-core
®
AtomTM N2600, 1.60GHz, 2x 512K L2, 3.5W TDP, dual-core
®
NM10 Express Chipset
®
GMA 3650 (Intel® AtomTM D2550/N2800)
®
GMA 3600 (Intel® AtomTM N2600)
1080p video playback capability
®
WG82574L Gigabit Ethernet controllers
®
ALC886 7.1-channel High Defi nition Audio
2-bit Out DIO
or LPC module module
Features
• Intel® AtomTM D2550/N2800/N2600; Intel® NM10
• 2GB DDR3 onboard
• 1 mSATA, 1 CFast
• Supports Wi-Fi, 3G, and GPRS applications
24V
9V
Wi-Fi 3G
Supports Intel® Atom
FRONT I/O PORTS
• 1 DB-9 RS232/422/485 COM
• 1 mic-in
• 2 LAN
• 4 USB 2.0 (Type A)
• 1 CFast socket
• 1 status LED
• 1 hdd LED
• 1 reset button
• 1 power button with LED
POWER
• 9~24V DC power input voltage
ENVIRONMENT
• Temperature
- Operating: 0
- Storage: -40
• Humidity
- Operating: 10% to 85% non-condensing
- Storage: 10% to 90% non-condensing
CONSTRUCTION
• Aluminum
MOUNTING
• Wall/VESA mount
- Mounting brackets and screws (optional)
DIMENSIONS
• 161mm x 32mm x 108.2mm (W x H x D)
WEIGHT
• 700g
OS SUPPORT
• Windows 7 (32-bit)
• Windows Embedded Standard 7 (32-bit)
• Ubuntu 12.04
OTHER FEATURES
• Watchdog Timer function
o
C ~ 60oC
o
C ~ 80oC
Wide Voltage
TM
Isolated
DIO
D2550/N2800/N2600
Rear I/O Ports EC800-CD2040 EC800-CD1440 EC800-CD2041
DC-in power jack Wi-Fi/3G module antenna hole Line-out DVI VGA:DB-15 D-sub micro HDMI COM: DB-9 DIO: DB-9 (signal+power)
111 222 111 110 001 001 212 010
Panel
EC800 Series
Fanless Embedded System
Wi-Fi/3G Antenna
Dimensions
HDD LED
Wi-Fi/3G Antenna
VGA9~24V DC-in COM 2
Line-out
micro HDMI
COM 1
LAN 2
Mic-in
Front View
Rear View
LAN 1
USB
CFast Status LED
Reset
Power
Wi-Fi/3G Antenna
Wi-Fi/3G Antenna
DVI-I9~24V DC-in COM 2/
Line-out
Isolated 4-bit DIO
108.20
32.00
161.00
Right ViewLeft View
Front View
EC800 Series
Mounting
Wall Mounting
Fanless Embedded System
172.00
16.00
80.00
Ø8.50 Ø5.00
VESA Mounting
46.00
184.00
172.00
75.00
75.00
108.00
EC800 Series
Fanless Embedded System
Packing List
• 1 EC800 system unit
• 1 60W power adapter
- AC input: 100-240V, 50-60Hz
- DC output: 12V, 5A max (60W max)
• 6 mounting screws for Mini PCIe module
• 1 Quick Installation Guide
• 1 DVD disk includes:
- Drivers / Manual
Ordering Information
Model Name Part Number Description EC800-CD2040-252 750-EC8000-000G Fanless, Intel Atom D2550, 2 COM, 4 USB, 2GB DDR3 onboard RoHS EC800-CD2040-282 750-EC8000-800G Fanless, Intel Atom N2800, 2 COM, 4 USB, 2GB DDR3 onboard RoHS EC800-CD2040-262 750-EC8000-600G Fanless, Intel Atom N2600, 2 COM, 4 USB, 2GB DDR3 onboard RoHS
EC800-CD2041-252 750-EC8000-100G
EC800-CD1440-252 750-EC8000-400G EC800-CD1440-282 750-EC8000-700G EC800-CD1440-262 750-EC8000-500G
Fanless, Intel Atom D2550, Dual Display, 2 COM, 4 USB, 2GB DDR3 onboard RoHS
Fanless, Intel Atom D2550, 1 COM, 4-bit DIO, 4 USB, 2GB DDR3 onboard RoHS
Fanless, Intel Atom N2800, 1 COM, 4-bit DIO, 4 USB, 2GB DDR3 onboard RoHS
Fanless, Intel Atom N2600, 1 COM, 4-bit DIO, 4 USB, 2GB DDR3 onboard RoHS
The following models will be available upon request. Please contact your sales representative for more information.
Model Name Part Number Description EC800-CD2041-262 750-EC8000-D00G
EC800-CD2041-282 750-EC8000-E00G
Fanless, Intel Atom N2600, Dual Display, 2 COM, 4 USB, 2GB DDR3 onboard RoHS
Fanless, Intel Atom N2800, Dual Display, 2 COM, 4 USB, 2GB DDR3 onboard RoHS
Optional Items
Optional Items Part Number Description SSD mSATA 785- MS32GMF mSATA Full-Size 32GB MLC
785- MS16GMF mSATA Full-Size 16GB MLC 785- MS08GMF mSATA Full-Size 8GB MLC
SSD CFast 785-CFM32G CFast 32GB Wide Temperature MLC
785-CFM16G CFast 16GB Wide Temperature MLC 785-CFM08G CFast 8GB Wide Temperature MLC 785-CFM04G CFast 4GB Wide Temperature MLC
Wall Mount 761-EC8000-000G EC800 Wall Mount kit VESA Mount 761-EC8000-100G EC800 VESA Mount kit Power Cord 785-PWRD Power Cord, Standards (USA/EUR/CH), 1.8m, RoHS
www.dfi .com
DFI reserves the right to change the specifi cations at any time prior to the product's release. Changes thereafter will be based on the product's revision. Please contact your sales representative for the exact revision offered in your area. Refer to the website (www.dfi .com) for the most updated information. All product names mentioned are trademarks of their respective companies. © July 3, 2013 DFI Inc.
