Introduction

ACB-104.ULTRA

The ACB-104.ULTRA part number 3514 digital I/O interface provides 48 channels The ACB-104.ULTRA adapter provides the PC/104-Plus computer with a single

channel high-speed multi-protocol serial interface suitable for the most popular communication protocols. This sync/async card provides an ideal solution for highspeed applications including LAN/WAN connectivity. Utilizing the Zilog Z16C32 (IUSC™) on chip DMA controller eliminates bus bandwidth constraints that are placed on typical interface adapters, allowing data rates to reach 10M bps in burst mode. By utilizing the Z16C32's 32 byte FIFO buffer coupled with 256K of on board memory, higher data rates are achieved.

Other Sealevel Sync Products

 PC/104

ACB-104 (P/N 3512) - Z85230 RS-232/422/485/530/530a/V.35

 PCI

Route 56.PCI (P/N 5101) - Z16C32 RS-232/422/485/530/530a/V.35 ACB-MP.PCI (P/N 5102) - Z85230 RS-232/422/485/530/530a/V.35

 Low Profile PCI

ACB-232.LPCI (P/N 5103) - Z85230 RS-232 ACB-Ultra.LPCI (P/N 5104) - Z16C32 RS-232/422/485/530/530a/V.35

 PCMCIA

PC-ACB-MP (P/N 3612) - Z85233 RS-232/422/485/530/530a/V.35

 ISA

ACB-III (P/N 4010) - Z85230 2-Port RS-232 ACB 56 (P/N 4021) - Z85230 RS-232/V.35 ACB-II/EX (P/N 4061) - Z85230 RS-232/422/485/530 ACB 530 (P/N 4111) - Z85230 2-Port RS-422/485/530 Route 56 (P/N 5011) - Z16C32 RS-232/422/485/530/V.35

- 1 -

ACB-104.ULTRA User Manual

Before You Get Started

What’s Included

The ACB-104.ULTRA is shipped with the following items. If any of these items is missing or damaged please contact Sealevel for replacement.

 ACB-104.ULTRA Adapter  PC/104-Plus Mounting Hardware  Sealevel SeaI/O Software CD

Optional Items

Depending upon your application, you are likely to find one or more of the following items useful for interfacing the ACB-104.ULTRA to real-world signals. All items can be purchased from our website (http:\\www.sealevel.com calling 864-843-4343.

 CA-118 – Provides an 8” ribbon cable with an IDC26 connector to a DB-25

Male connector.

 CA-178 – A 6’ shielded cable with a DB-25F connector to an ITU-T ISO-2593

style connector (V.35), and converts the Sealevel DB-25 implementation to the ITU-T V.35 mechanical standard.

 CA-104 – A 6’ extension cable with one DB-25M connector and one DB-

25Fconnector, pinned one-to-one, for use with RS-232 and RS-530.

 CA-107 – A 10” shielded cabling adapter with a DB-25F (RS-530) to a DB-

37M (RS-449 DTE). RS-530 is replacing RS-449 in Telecom applications, but there is still a very large installed base of equipment that still uses the RS-449 pin-out. Both standards use RS-422 to define the electrical specifications and are interchangeable via this adapter cable.

 CA-159 – A 6’ shielded cable with a DB-25F (RS-530) to a DB-15M (X.21),

and converts the standard DB-25 implementation of RS-530 or RS-422 to the ITU-T X.21 standard.

) or by

- 2 -

ACB-104.ULTRA User Manual

Card Setup

Address Selection

As part of the PC/104-Plus specification, a means of selecting the appropriate signals to identify the position in which the adapter is installed in the stack must be provided. This is typically done via Dual 4:1 Mux/Demux chips and a rotary switch. They provide a 5 ohm switch that connects the input and output together. These switches provide a bi-directional path with no signal propagation delay other than the RC delay of the on resistance of the switch and the load capacitance. This is typically 250ps at 50pF Load. Other methods of configuring the modules are possible, but the rotary switch is the most convenient, cleanest and provides for the least possible error in configuration. The clocks are tuned on the Host Board such that the length of CLK3 trace is .0.662" less than CLK2, CLK2 trace is .0.662" less than CLK1, and CLK1 trace is .0.662" less than CLK0. Therefore, the first module on the stack must select CLK0 (the longest trace), the second CLK1, etc. This provides basically no clock skew between modules. The table below shows the appropriate switch setting and signals used for each module in the stack.

Switch Position Module Slot CLKID Address INT0* INT1* INT2* INT3*

0 or 4 1 CLK0 AD20 INTA* INTB* INTC* INTD* 1 or 5 2 CLK1 AD21 INTB* INTC* INTD* INTA* 2 or 6 3 CLK2 AD22 INTC* INTD* INTA* INTB* 3 or 7 4 CLK3 AD23 INTD* INTA* INTB* INTC*

- 3 -

ACB-104.ULTRA User Manual

Software Installation

Windows 95/98/ME/NT/2000/XP Installation

1. Start Windows.

2. Insert the Sealevel Systems CD in to your CD drive.

3. If ‘Auto-Start’ is enabled for this drive the software will automatically launch. Otherwise, point your browser to the ‘Index.htm’ on the root directory of the CD

4. Select ‘Install Software’.

5. Select the Part Number for your adapter from the listing.

6. Select ‘Windows 98/ME/2000/XP’. The setup file will automatically detect the operating environment and install the proper components. Next (depending on the OS version) select the ‘Run this program from its current location’ or ‘Open’ option. Follow the information presented on the screens that follow.

7. A screen may appear with the declaration: “The publisher cannot be determined due to the problems below: Authenticode signature not found.” Please select the ‘Yes’ button and proceed with the installation. This declaration simply means that the Operating System is not aware of the driver being loaded. It will not cause any harm to your system.

8. During setup the user may specify installation directories and other preferred configurations. This program also adds entries to the system registry that are necessary for specifying the operating parameters for each driver. An uninstall option is also included to remove all registry/INI file entries from the system.

- 4 -

ACB-104.ULTRA User Manual

Physical Installation

Extreme care should be taken when installing the adapter to avoid causing damage to the connectors. After the adapter is installed, connect your I/O cable to P1. Please note these connectors are keyed so that pin 1 of the cable matches pin 1 of the connector. The ACB-104.ULTRA is a universal bus add-in board and can be used on either 3V or 5V I/O signaling buses. Universal boards either use the VI/O signal to determine its signaling level or are 3V signaling boards that have 5V-tolerant I/O. Universal boards will work on either 3V or 5V I/O signaling buses. Manufacturers of PC/104-Plus modules must clearly label near or on the PCI connector the module’s PCI signaling capabilities. The ACB-104.ULTRA is clearly labeled ‘Universal’.

Do not install the Adapter in the machine until the software has been fully installed.

1. Turn off power. Disconnect the power cord.

2. Remove the case cover (if applicable).

3. Gently insert the adapter noting proper key orientation of the expansion connector on a PC/104 Plus expansion bus. The adapter is keyed per the current PC/104 and PC/104-Plus Specification. This will aid in preventing the adapter from being inserted incorrectly.

4. Mounting hardware (nylon stand-offs and screws) is provided to ensure a good mechanical connection. Retain any mounting hardware not used to allow for future expansion.

5. Replace the cover.

6. Connect the power cord and power up the machine.

- 5 -

ACB-104.ULTRA User Manual

The ACB-104.ULTRA is now ready for use.

- 6 -

ACB-104.ULTRA User Manual

Technical Description

The Sealevel Systems’ ACB-104.ULTRA adapter was designed for seamless integration into any PC/104-Plus based system. The ACB-104.ULTRA adapter requires one IRQ, an 8 byte block of I/O address and a 16K block or 256K block of memory address and additionally, the IUSC requires a 256 byte block of memory.

Features

 Single channel high speed sync/async wide area network (WAN) interface  RS-232, RS-422/449, EIA-530, V.35 and RS-485 serial interface capability with

versatile cabling options

 Multi-protocol capable including: PPP (point-to-point protocol), Frame Relay,

X.25, high-speed Async, Bi-Sync, Mono-Sync, HDLC, SDLC, etc.

 Ideal for T1, Fractional T1, E1, and ISDN and other WAN applications  On-board Z16C32 (IUSC™) with built in DMA controller and 32 byte FIFO

buffer

 Up to 10 Mbps burst mode  256K of on-board RAM  Link list DMA supported  32-bit data path  OEM Security feature available as an option

IUSC™

The ACB-104.ULTRA is based on a single Zilog Z16C32 IUSC (Integrated Universal Serial Controller). The IUSC has a built-in DMA controller that allows

high-speed data transfers directly to and from the 256K block of on-board memory. The IUSC’s built-in DMA controller supports 4 different modes of DMA transfer: Single Buffer, Pipelined, Array, and Link List. An on-board 20MHz oscillator clocks the IUSC.

RAM

The memory window is located by the BIOS PCI setup. The window size is one 256K linear block. High Memory options - 16 pages of 16K memory blocks totaling 256K or one linear block of 256K memory. In paged mode the registers are located in the I/O registers.

- 7 -

ACB-104.ULTRA User Manual

Status Signal LED Headers

The 3514 has a pair of 2mm two-pin right angle headers at board location P6 (Tx header) and P7 (Rx header) for connecting standard off-board LEDs (headers are Hirose item# DF3-2P-2DS). Pin 1 is +5V (anode) through a 330Ω resistor and can be recognized by a square solder pad on the side of the board opposite the header. Pin 2 is the LED control (cathode), which is driven by 5V CMOS logic (74HC123) and has a round solder pad on the reverse side of the board.

An LED connected to the header can be used to monitor the activity status of synchronous serial communications between the Z16C32 controller and the onboard memory buffer. Using SeaMAC V4, both LEDs will flash when the Z16C32 controller is reading from or writing to the memory buffer (operates similar to the activity LED on an Ethernet LAN card). This will confirm electrical continuity and that the Z16C32 controller is communicating correctly. The LEDs will not flash for sync characters or in cases where the Z16C32 controller is bypassed.

Programming For The LED Headers

Logic on the 3514 monitors local bus (DMA) ownership of the Z16C32 controller and how the on-board memory (256K byte buffer) is accessed. The LED logic treats the on-board buffer as 16 blocks of 16K bytes. The logic assumes that block zero will be used for control data and upper memory reserved for actual data. If the Z16C32 controller reads from memory block one through 15, the Tx LED (P6) will flash at a preset rate. If the Z16C32 controller writes to memory block one through 15, the Rx LED (P7) will flash at a preset rate. The LED headers are tied to the Z16C32 controller and will not flash if the controller is bypassed.

Storing the DMA control information in block zero of the on-board buffer, the LEDs will flash only when actual data is being read from or written to upper buffer memory. The LEDs ignore reads and writes to memory block zero and will not flash. Also, the LEDS will not flash on sync characters since they are not stored in memory. The control and status registers are defined below.

- 8 -

ACB-104.ULTRA User Manual

Control and Status Registers Defined

The control and status registers occupy 8 consecutive locations. The following tables provide a functional description of the bit positions.

Address Mode D7 D6 D5 D4 D3 D2 D1 D0

Base+0 Base+0 Base+1 Base+1 Base+2 Base+2 Base+3 Base+3 Base+4 Base+4 Base+5 Base+5 Base+6 Base+7

RD {0} {0} {0} {1}+ P17 P16 P15 P14

WR ACCEN MEM/IUC X X P17 P16 P15 P14

RD {0} {0} {0} {0} {0} {0} {0} {0}

WR X X X X X X X X

RD LIN/PAGED {0} {1} {0} {0} {0} {0} {0}

WR LIN/PAGED X X X X X X X

RD {0} {0} INTPEND RESTAT {1} {0} {0} {0}

WR SW Board Reset X X X X X X X

RD {0} IRQEN {0} {0} {0} {0} {0} {0}

WR X IRQEN X X X X X X

RD LL RL {0} {0} M3 M2 M1 M0

WR LL RL X X M3 M2 M1 M0

RD SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0 RD SD15 SD14 SD13 SD12 SD11 SD10 SD9 SD8

X = do not care { }= always this value

Control and Status Name Definition

Field Description

ACCEN

MEM/IUC

P17-P14

IRQEN

INTPEND

RESTAT

RL LL

M0-M3

SD0-SD15

1 = Host access to RAM or IUSC enabled; 0 = Host access to RAM or IUSC disabled. (0 on power-up) 1 = Enable Host access to RAM; 0 = Enable Host access to IUSC. (0 on power-up) These bits select which of sixteen 16K RAM pages is visible at the address selected by MA18-MA14. 1 = Interrupts enabled, 0 = Interrupts disabled. (0 on power-up) IUSC interrupt status: 1 = No interrupt pending on IUSC; 0 = Interrupt pending on IUSC. Reset status: 1 = On-board reset inactive; 0 = On-board reset active. Remote loopback Local loopback I/O mode select to SP505 (all 0 on power-up) See Interface Selection table for valid interface options Optional security feature. Unique value per customer or application. (default value = FFFF)

LIN/PAGE

1=256K linear block in high memory only, 0=16X16K pages in low or high memory, (0 on power-up)

- 9 -

ACB-104.ULTRA User Manual

Interface Selection

The ACB-104.ULTRA supports a variety of electrical interfaces. Reference the Control and Status Registers Defined section of this manual for this bit description. There is line termination on RXD, RXC, and TXC in the following modes: RS-530, RS-530A, RS-485T, and V.35.

Reset Circuit

Writing any value to base+3 will reset the Z16C32. Only one write is required. This starts a reset sequence, which lasts about 320 ns. During the reset sequence base+3 bit D4 will read 0. When the reset is complete, base+3 bit D4 will read 1.

The Z16C32 should not be accessed until the reset sequence is complete.

TSET Clock Select

Port5 of Z16C32 is used to select TSET clock source.

 0 selects 16C32 TXC as source  1 selects received TXC as source

Z16C32 Register Access

Pin Source

Port0 20 MHz clock Port1 20 MHz clock D/C (data/control) Address SA6 S/D (serial/DMA) Address SA7 DMA channel registers Base + 0-127 Serial controller base + 128-255

- 10 -

ACB-104.ULTRA User Manual

I/O Signal Derivation

The ACB-104.ULTRA input/output signals are directly generated via the Zilog 16C32 IUSC. The following table defines these signals, their origin pin and signal name following the conventions set by the 16C32 user’s manual. If using a Sealevel Systems, Inc. supplied driver, this is for informational use only.

Signal Source

Transmit Data 16C32 TXD Pin Request To Send 16C32 Port7 Pin Data Terminal Ready 16C32 Port6 Pin Transmit Signal Element Timing 16C32 TXC Pin Receive Data 16C32 RXC Pin Clear To Send 16C32 CTS Pin Data Set Ready 16C32 RXREQ Pin Data Carrier Detect 16C32 DCD Pin Transmit Clock 16C32 TXCO Pin Receive Clock 16C32 RXCO Pin Ring Indicator 16C32 TXREQ Pin

26 Pin Header Signal Layouts

In all modes, Pin 1 has a 1K ohm resistor to GND and pin 13 has a 1K ohm resistor to +5V connection. This is useful for RS-485 biasing. If this presents a problem in your implementation, please contact Sealevel Systems’ Technical Support for aid in removing.

For convenience, the signal layout is shown for the optional IDC26 to DB-25M 8” ribbon cable (Item# CA-118).

- 11 -

ACB-104.ULTRA User Manual

RS-232 Signals

Base+5, M3-M0=2, 0010

Signal Name Header

GND Ground 13 7

RD Receive Data 5 3 Input CTS Clear To Send 9 5 Input DSR Data Set Ready 11 6 Input

DCD Data Carrier Detect 15 8 Input

RI Ring Indicator 18 22 Input

TXC Transmit Clock 4 15 Input

RXC Receive Clock 8 17 Input

TSET Transmit Signal Element Timing 22 24 Output

DTR Data Terminal Ready 14 20 Output

TD Transmit Data 3 2 Output RTS Request To Send 7 4 Output

V.35 Signals

Base+5, M3-M0=E, 1110

Signal Name Header

GND Ground 13 B 7

RDB RX+ Receive Positive 6 T 16 Input

RDA RX- Receive Negative 5 R 3 Input

TXCB TXC+ Transmit Clock Positive 23 AA 12 Input

TXCA TXC- Transmit Clock Negative 4 Y 15 Input RXCB RXC+ Receive Clock Positive 17 X 9 Input RXCA RXC- Receive Clock Negative 8 V 17 Input

TDB TX+ Transmit Positive 2 S 14 Output

TDA TX- Transmit Negative 3 P 2 Output

TSETB TSET+ Transmit Signal Element Timing + 21 W 11 Output

TSETA TSET- Transmit Signal Element Timing - 22 U 24 Output

CTS Clear To Send 9 D 5 Input * DSR Data Set Ready 11 E 6 Input *

DCD Data Carrier Detect 15 F 8 Input *

RI Ring Indicator 18 J 22 Input *

DTR Data Terminal Ready 14 H 20 Output *

RTS Request To Send 7 C 4 Output *

Note: All modem control signals are single ended (un-balanced) with RS-232 signal levels.

Pin #

Pin#

CA-118

Pin #

V.35 CA-118

Mode

Pin #

Mode

- 12 -

ACB-104.ULTRA User Manual

RS-530 (RS-422)

Base+5, M3-M0=D, 1101

Signal Name Header

GND Ground 13 7

RDB RX+ Receive Positive 6 16 Input

RDA RX- Receive Negative 5 3 Input

CTSB CTS+ Clear To Send Positive 25 13 Input

CTSA CTS- Clear To Send Negative 9 5 Input DCDB DCD+ Data Carrier Detect Positive 19 10 Input DCDA DCD- Data Carrier Detect Negative 15 8 Input

TXCB TXC+ Transmit Clock Positive 23 12 Input

TXCA TXC- Transmit Clock Negative 4 15 Input

RXCB RXC+ Receive Clock Positive 17 9 Input

RXCA RXC- Receive Clock Negative 8 17 Input

TDB TX+ Transmit Positive 2 14 Output

TDA TX- Transmit Negative 3 2 Output

RTSB RTS+ Request To Send Positive 12 19 Output

RTSA RTS- Request To Send Negative 7 4 Output

DTRB DTR+ Data Terminal Ready Positive 20 23 Output

DTRA DTR- Data Terminal Ready Negative 14 20 Output

TSETB TSET+ Transmit Signal Element Timing Positive 21 11 Output

TSETA TSET- Transmit Signal Element Timing Negative 22 24 Output

DSRB DSR+ Data Set Ready Positive 18 22 Input

DSRA DSR- Data Set Ready Negative 11 6 Input

Pin #

CA-118

Pin #

Mode

RS-530A

Base+5, M3-M0=F, 1111

Signal Name Header

GND Ground 13 7

RDB RX+ Receive Positive 6 16 Input

RDA RX- Receive Negative 5 3 Input

CTSB CTS+ Clear To Send Positive 25 13 Input

CTSA CTS- Clear To Send Negative 9 5 Input DCDB DCD+ Data Carrier Detect Positive 19 10 Input DCDA DCD- Data Carrier Detect Negative 15 8 Input TXCB TXC+ Transmit Clock Positive 23 12 Input

TXCA TXC- Transmit Clock Negative 4 15 Input RXCB RXC+ Receive Clock Positive 17 9 Input RXCA RXC- Receive Clock Negative 8 17 Input

DSRA DSR- Data Set Ready Negative 11 6 Input

TDB TX+ Transmit Positive 2 14 Output

TDA TX- Transmit Negative 3 2 Output

RTSB RTS+ Request To Send Positive 12 19 Output

RTSA RTS- Request To Send Negative 7 4 Output

TSETB TSET+ Transmit Signal Element Timing Positive 21 11 Output

TSETA TSET- Transmit Signal Element Timing Negative 22 24 Output

DTRA DTR- Data Terminal Ready Negative 14 20 Output

Pin #

CA-118

Pin #

Mode

- 13 -

ACB-104.ULTRA User Manual

RS-485 or RS-485T

Base+5, M3-M0=4, 0100 (With termination) Base+5, M3-M0=5, 0101 (Without termination)

Signal Name Header

GND Ground 13 7 RDB RX+ Receive Positive 6 16 Input RDA RX- Receive Negative 5 3 Input

TXCB TXC+ Transmit Clock Positive 23 12 Input

TXCA TXC- Transmit Clock Negative 4 15 Input

RXCB RXC+ Receive Clock Positive 17 9 Input

RXCA RXC- Receive Clock Negative 8 17 Input

TDB TX+ Transmit Positive 2 14 Output

TDA TX- Transmit Negative 3 2 Output

TSETB TSET+ Transmit Signal Element Timing Positive 21 11 Output

TSETA TSET- Transmit Signal Element Timing Negative 22 24 Output

Pin #

CA-118

Pin #

Mode

ACB-104.ULTRA shown with optional IDC26 to DB-25M 8” ribbon cable (Item# CA-118)

- 14 -

ACB-104.ULTRA User Manual

Specifications

Environmental Specifications

Specification Operating Storage

Temperature

Range

Humidity

Range

Manufacturing

All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel.

Power Consumption

0º to 70º C

(32º to 158º F)

10 to 90% R.H.

Non-Condensing

Supply line

Rating

-50º to 105º C (-58º to 221º F) 10 to 90% R.H.

Non-Condensing

+5 VDC

450mA

- 15 -

ACB-104.ULTRA User Manual

Appendix A – Troubleshooting

Following these simple steps can eliminate most common problems. Install software first. After installing the software then proceed to adding the

hardware. This places the required installation files in the correct locations. Read this manual thoroughly before attempting to install the adapter in your system. Use Device Manager under Windows to verify proper installation. Use the SeaIO Control Panel applet or the Device Manager’s property page for card

identification and configuration. If these steps do not solve your problem, please call Sealevel Systems’ Technical

Support, (864) 843-4343. Our technical support is free and available from 8:00AM5PM Eastern Time Monday through Friday. For email support contact

mailto:support@sealevel.com

- 16 -

ACB-104.ULTRA User Manual

Appendix B - How To Get Assistance

Begin by reading through the Trouble Shooting Guide in Appendix A. If assistance is still needed please see below.

When calling for technical assistance, please have your user manual and current adapter settings. If possible, please have the adapter installed in a computer ready to run diagnostics.

Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many common questions. This section can be found at

http://www.sealevel.com/faq.asp

Sealevel Systems maintains a Home page on the Internet. Our home page address is

http://www.sealevel.com

available via our FTP site that can be accessed from our home page. Technical support is available Monday to Friday from 8:00 a.m. to 5:00 p.m. eastern

time. Technical support can be reached at (864) 843-4343.

. The latest software updates, and newest manuals are

RETURN AUTHORIZATION MUST BE OBTAINED FROM SEALEVEL SYSTEMS BEFORE RETURNED MERCHANDISE WILL BE ACCEPTED. AUTHORIZATION CAN BE OBTAINED BY CALLING SEALEVEL SYSTEMS AND REQUESTING A RETURN MERCHANDISE AUTHORIZATION (RMA) NUMBER.

- 17 -

ACB-104.ULTRA User Manual

Appendix C – Electrical Interface

RS-232

Quite possibly the most widely used communication standard is RS-232. This implementation has been defined and revised several times and is often referred to as RS-232 or EIA/TIA-232. It is defined by the EIA as the Interface between Data Terminal Equipment and Data Circuit- Terminating Equipment Employing Serial Binary Data Interchange. The mechanical implementation of RS-232 is on a 25 pin D sub connector. RS-232 is capable of operating at data rates up to 20 Kbps at distances less than 50 ft. The absolute maximum data rate may vary due to line conditions and cable lengths. RS-232 often operates at

38.4 Kbps over very short distances. The voltage levels defined by RS-232 range from -12 to +12 volts. RS-232 is a single ended or unbalanced interface, meaning that a single electrical signal is compared to a common signal (ground) to determine binary logic states. A voltage of +12 volts (usually +3 to +10 volts) represents a binary 0 (space) and -12 volts (-3 to -10 volts) denotes a binary 1 (mark). The RS-232 and the EIA/TIA-574 specification defines two type of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface.

RS-422

The RS-422 specification defines the electrical characteristics of balanced voltage digital interface circuits. RS-422 is a differential interface that defines voltage levels and driver/receiver electrical specifications. On a differential interface, logic levels are defined by the difference in voltage between a pair of outputs or inputs. In contrast, a single ended interface, for example RS-232, defines the logic levels as the difference in voltage between a single signal and a common ground connection. Differential interfaces are typically more immune to noise or voltage spikes that may occur on the communication lines. Differential interfaces also have greater drive capabilities that allow for longer cable lengths. RS-422 is rated up to 10 Megabits per second and can have cabling 4000 feet long. RS-422 also defines driver and receiver electrical characteristics that will allow 1 driver and up to 32 receivers on the line at once. RS-422 signal levels range from 0 to +5 volts. RS-422 does not define a physical connector.

RS-485

RS-485 is backwardly compatible with RS-422; however, it is optimized for partyline or multi-drop applications. The output of the RS-422/485 driver is capable of being Active (enabled) or Tri-State (disabled). This capability allows multiple ports to be connected in a multi-drop bus and selectively polled. RS-485 allows cable lengths up to 4000 feet and data rates up to 10 Megabits per second. The signal levels for RS-485 are the same as those defined by RS-422. RS-485 has electrical characteristics that allow for 32 drivers and 32 receivers to be connected to one line. This interface is ideal for multi-drop or network environments. RS-485 tri-state driver (not dual-state) will allow the electrical presence of the driver to be removed from the line. Only one driver may be active at a time and the other driver(s) must be tri-stated. RS-485 can be cabled in two ways, two wire and four wire mode. Two wire mode does not allow for full duplex communication, and requires that data be transferred in only one direction at a time. For half-duplex operation, the two transmit pins should be connected to the two receive pins (Tx+ to Rx+ and Tx- to Rx-). Four wire mode allows full duplex data transfers. RS-485 does not define a connector pin-out or a set of modem control signals. RS-485 does not define a physical connector.

- 18 -

ACB-104.ULTRA User Manual

RS-530 / 530A

RS-530 (a.k.a. EIA-530) compatibility means that RS-422 signal levels are met, and the pin-out for the DB-25 connector is specified. The EIA (Electronic Industry Association) created the RS-530 specification to detail the pin-out, and define a full set of modem control signals that can be used for regulating flow control and line status. The major difference between RS-530 and RS-530A lies in some of the modem control interface signals. In RS-530 the signals all of the modem control signals are differential, in RS530A some of these signals are single ended. The RS-530 specification defines two types of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface.

V.35

V.35 is a standard defined by ITU (formerly CCITT) that specifies an electrical, mechanical, and physical interface that is used extensively by high-speed digital carriers such as AT&T Dataphone Digital Service (DDS). ITU V.35 is an international standard that is often refereed to as Data Transmission at 48 Kbps Using 60 - 108 KHz Group-Band Circuits. ITU V.35 electrical characteristics are a combination of unbalanced voltage and balanced current mode signals. Data and clock signals are balanced current mode circuits. These circuits typically have voltage levels from 0.5 Volts to -0.5 Volts (1 Volt differential). The modem control signals are unbalanced signals and are compatible with RS-232. The physical connector is a 34 pin connector that supports 24 data, clock and control signals. The physical connector is defined in the ISO-2593 standard. ITU V.35 specification defines two type of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface.

- 19 -

ACB-104.ULTRA User Manual

Appendix D – Silk Screen – 3514 PCB

- 20 -

ACB-104.ULTRA User Manual

Appendix E - Compliance Notices

Federal Communications Commission Statement

FCC - This equipment has been tested and found to comply with the limits for Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in such case the user will be required to correct the interference at the users expense.

EMC Directive Statement

Products bearing the CE Label fulfill the requirements of the EMC directive (89/336/EEC) and of the low-voltage directive (73/23/EEC) issued by the European Commission.

To obey these directives, the following European standards must be met: EN55022 Class A - “Limits and methods of measurement of radio interference

characteristics of information technology equipment” EN55024 – “Information technology equipment Immunity characteristics Limits and

methods of measurement”. EN60950 (IEC950) - “Safety of information technology equipment, including

electrical business equipment”

Warning

This is a Class A Product. In a domestic environment, this product may cause

radio interference in which case the user may be required to take adequate

measures to prevent or correct the interference.

Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives.

- 21 -

ACB-104.ULTRA User Manual

Warranty

Sealevel's commitment to providing the best I/O solutions is reflected in the Lifetime Warranty that is standard on all Sealevel manufactured products. We are able to offer this warranty due to our control of manufacturing quality and the historically high reliability of our products in the field. Sealevel products are designed and manufactured at its Liberty, South Carolina facility, allowing direct control over

product development, production, burn-in and testing. Sealevel Systems, Inc. (hereafter "Sealevel") warrants that the Product shall conform

to and perform in accordance with published technical specifications and shall be free of defects in materials and workmanship for life. In the event of failure, Sealevel will repair or replace the product at Sealevel's sole discretion. Failures resulting from misapplication or misuse of the Product, failure to adhere to any specifications or instructions, or failure resulting from neglect or abuse are not covered under this warranty.

Warranty service is obtained by delivering the Product to Sealevel and providing proof of purchase. Return authorization must be obtained from Sealevel Systems

before returned merchandise will be accepted. Authorization is obtained by calling Sealevel Systems and requesting a Return Merchandise Authorization (RMA) number. The Customer agrees to insure the Product or assume the risk of

loss or damage in transit, to prepay shipping charges to Sealevel, and to use the original shipping container or equivalent. Warranty is valid only for original purchaser and is not transferable.

Trademarks

Sealevel Systems assumes no liability for any damages, lost profits, lost savings or any other incidental or consequential damage resulting from the use, misuse of, or inability to use this product. Sealevel Systems will not be liable for any claim made by any other related party.

This warranty applies to Sealevel manufactured Product. Product purchased through Sealevel but manufactured by a third party will retain the original manufacturer's warranty.

Sealevel Systems, Incorporated 2779 Greenville Highway P.O. Box 830 Liberty, SC 29657 USA (864) 843-4343 FAX: (864) 843-3067 www.sealevel.com email: support@sealevel.com

Technical Support is available Monday - Friday from 8 a.m. to 5 p.m. Eastern time

Sealevel Systems, Incorporated acknowledges that all trademarks referenced in this manual are the service mark, trademark, or registered trademark of the respective company.

- 22 -

ACB-104.ULTRA User Manual

Impulse ACB-104 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Before You Get Started

Software Installation
