Impulse 7161 User Manual
COMM+16.PCI
Users Manual
Part Number 7161
Sealevel Systems, Inc. Telephone: 864.843.4343
PO Box 830 Fax: 864.843.3067
Liberty, SC 29657 USA www.sealevel.com
Contents
INTRODUCTION ....................................................................................................................1
OVERVIEW .........................................................................................................................................1
WHAT’S INCLUDED ............................................................................................................................1
ADDRESS AND IRQ SELECTION ..........................................................................................................1
INSTALLATION .....................................................................................................................2
OPERATING SYSTEM INSTALLATION...................................................................................................2
For Windows Users........................................................................................................................2
Other Operating Systems ................................................................................................................2
SYSTEM INSTALLATION ......................................................................................................................2
T
ECHNICAL DESCRIPTION ..................................................................................................3
CONNECTOR PIN ASSIGNMENTS .........................................................................................................3
DB-25 (RS-232 DTE) (DB-25 Male).........................................................................................3
DB-68 (Micro MDB-68 Female)................................................................................................3
S
PECIFICATIONS ..................................................................................................................4
ENVIRONMENTAL SPECIFICATIONS.....................................................................................................4
POWER CONSUMPTION .......................................................................................................................4
MEAN TIME BETWEEN FAILURES (MTBF).........................................................................................4
PHYSICAL DIMENSIONS ......................................................................................................................4
APPENDIX A - TROUBLESHOOTING ....................................................................................5
APPENDIX B - HOW TO GET ASSISTANCE..........................................................................6
APPENDIX C - ELECTRICAL INTERFACE.............................................................................7
RS-232...............................................................................................................................................7
APPENDIX D - ASYNCHRONOUS COMMUNICATIONS ..........................................................8
APPENDIX E - SILK-SCREEN ...............................................................................................9
APPENDIX F - COMPLIANCE NOTICES ..............................................................................10
FEDERAL COMMUNICATIONS COMMISSION STATEMENT ..................................................................10
EMC DIRECTIVE STATEMENT ..........................................................................................................10
WARRANTY........................................................................................................................11
© Sealevel Systems, Inc.
SL9057 Revision 7/2006
Sealevel Systems, Incorporated. All rights reserved.
Introduction
Introduction
Overview
The Sealevel Systems COMM+16.PCI provides the PC with sixteen RS-232 asynchronous ports. The
COMM+16.PCI allows for connection to any device utilizing the RS-232 electrical interface, such as modems,
data-entry terminals, and plotters.
What’s Included
The COMM+16.PCI is shipped with the following items. If any of these items is missing or damaged, contact the
supplier.
• COMM+16.PCI Serial I/O Adapter
• (2) Micro MDB-68 to eight DB-25 ‘Spider Cable’ P/N CA202
Address and IRQ selection
The COMM+16.PCI is automatically assigned I/O addresses and IRQs by your motherboard BIOS. Adding or
removing other hardware may change the assignment of I/O addresses and IRQs.
• Sealevel Software
Sealevel Systems COMM+16.PCI Page 1
Installation
Installation
Operating System Installation
For Windows Users
Start by choosing Install Software at the beginning of the CD. Choose Asynchronous COM: Port Software,
SeaCOM.
Other Operating Systems
Refer to the appropriate section of the Serial Utilities Software.
System Installation
The COMM+16.PCI is a universal PCI implementation and can be installed in any 5V or 3.3V slot of the PCI
expansion slots.
1. When running Windows 9x/NT install software before installing adapter.
2. Turn off PC power. Disconnect the power cord.
3. Remove the PC case cover.
4. Locate an available PCI slot and remove the blank metal slot cover.
5. Gently insert the COMM+16.PCI into the slot. Make sure that the adapter is seated properly.
6. Replace the screw.
7. Replace the cover.
8. Connect the power cord.
Installation is complete.
Sealevel Systems COMM+16.PCI Page 2
