Impact QBG-24, QBG-15 User manual

imp act

Grid for Quikbox

INSTRUCTIONS

Attaching The Grid

1

Remove the grid from the bag
and spread it out completely.

3

Continue attaching the two sides
using the touch fastener, then
attach the bottom.

2

With the touch-fastner edge
facing outwards (towards the
front of the Quikbox), attach the
top edge rst.

4

There will be a small space
between the two grid edges to
accommodate the reective
panels on the Quikbox.
