Impact PT-100 User Manual
PT-100
Posing Table
ASSEMBLY INSTRUCTIONS
Instructions
1.
four screws and mounting bracket from the tabletop with a PH3-size Phillips
screwdriver.
2.
of the riser.
4.
the mounting bracket with the holes in the tabletop. Fasten all four screws until
secure. Do not overtighten. Tip: Insert all four screws before tightening.
5. Stand the pedestal base on the casters, and lock all casters. Insert the bottom
of the column into the open port of the pedestal base. Press down until the
3. Hold the column in one hand, and seat the mounting bracket’s pin holes—
threaded socket, and use the hex key to tighten until secure.
6. Loosen the locking knob, and adjust the tabletop’s height. Tighten the locking
knob to secure the table’s position. Make sure everything is secure before use.
